Nutek NTIJ User Manual

AL-2020-EDP
OLED 900MHz Color 2-way Alarm & Remote Start
Operation Guide
Temporary cover. Color cover is in a separate le.
2
Table Of Contents
Introduction ................................................................................................................... 3
Controller & Transmitter Overview................................................................................ 4
The Controller Status Screen ................................................................................... 4
The 1-Way Transmitter ............................................................................................. 5
Controller & Transmitter Functions ............................................................................... 5
Other Remote Start Features ....................................................................................... 9
Low Battery/Low Temp Automatic Starting ............................................................... 9
Manual Transmission Starting ................................................................................ 10
Security System Features .......................................................................................... 10
Pre-Warn Detection ................................................................................................ 10
Using The Valet Switch ................................................................................................11
The Status Light ......................................................................................................... 12
Multi-Car Operation & Vehicle Proles ....................................................................... 14
Multi-car Operation ................................................................................................. 14
Selecting Vehicle #1 or Vehicle #2 ......................................................................... 14
Programming Controller Options ................................................................................ 15
Button Lock ............................................................................................................ 15
Setting The Clock ................................................................................................... 16
Power Save Mode .................................................................................................. 16
Screen Lighting ...................................................................................................... 16
Selecting Button Beep ............................................................................................ 17
Demo Mode ............................................................................................................ 17
Selecting Melody & Vibrate modes......................................................................... 17
Anti-Carjacking Protection .......................................................................................... 18
Programming Controllers/Transmitters ....................................................................... 18
Programming Controllers/Transmitters (cont’d) .......................................................... 19
Programming Features ............................................................................................... 19
User Programmable Features .................................................................................... 20
Installer Programmable Features ............................................................................... 23
Programmable Features Matrix .................................................................................. 27
3
Introduction
Congratulations for choosing one of the most versatile, fully-featured vehicle secu­rity and convenience systems available today. Omega Research & Development has been a leader in vehicle security products for nearly 4 decades. Please take the time
to read this manual thoroughly so you can fully enjoy the benets and features this
system offers. In this manual, you will primarily learn about 5 user interface components and how they work together in alerting you to system changes as well as how you can control system operations. Keep in mind that the operations described in this manual are writ-
ten to only reect the default system settings. Be sure to discuss any customization
with your installer so you can remember any variations from this guide.
Controllers: The system has a 2-way controller that, in addition to controlling the
system, it will give you conrmations on system operations as well as violation alerts.
A 1-way transmitter is also included. It is a standard remote control that still gives
you control over all features but without conrmations. The next section covers the
controllers’ operations in detail.
The Status Lights: These lights are built into the system’s window-mounted antenna. They give you a visual indication of the system’s current state and provide troubleshooting indicators. The operations of the status lights are covered later in this manual.
The Valet Switch: This push button gives you access to system programming, transmitter/controller programming, and valet functions. It is also built into the sys­tem’s window-mounted antenna. The valet switch’s operations are also covered later in this manual.
Flashing Lights: The system is connected to your vehicle’s parking lights to
provide a 360 degree visual conrmation, warning, & deterrence in almost all system
operations. Each operation described in this manual also includes the corresponding indicator from the ashing lights. The ashing lights primarily provide visual deter­rence when the system is violated.
Siren and/or Horn Sounding: The system includes an electronic siren that offers
conrmation chirps during daily operations and programming. It is also the primary
means of alerting anyone near your vehicle that the system has been violated. The system is capable of sounding the vehicle’s horn in addition to, or in place of, the electronic siren. Most system functions have a corresponding audible alert that is described throughout this manual. Becoming familiar with these alerts will help you to instantly understand any changes in the system’s status.
4
THE 2-WAY CONTROLLER
Controller & Transmitter Overview
Controller part number: 153-03
1) Antenna: Sends commands to the system and
receives conrmations for 2-way functions.
2) OLED Display: Displays all controller functions as well as the status of your system.
3) Blue LED: Flashes while transmitting and indi­cates battery charging status.
4) Control Buttons: These are the primary use buttons. They control the system and are used to navigate the menu options.
5) Charger Port: This is where you plug in the charger to recharge the controller’s battery.
6) Programming Button: This is used for setting controller features, programming the clock, and many other functions see “other controller func­tions” later in this manual.
6
1
4
5
2
Battery Level Indicator*
Clock/Timer
Current System State
Vehicle Image (Selectable)
Alarm Clock ON icon
Vehicle Name (Programmable)
Melody Indicator
Vibration Mode Indicator
Lock/Unlock Indicator
2-way In Range
Indicator
*The controller is powered by a built-in rechargeable battery. When the battery level indicator shows a low battery, plug the supplied USB cable into the controller, then connect the other end to the supplied AC adapter, car adapter, or your computer’s
USB port. While charging, the indicator will ash from empty to full and the blue LED will ash once every 5 seconds while charging. When full, the indicator will be solid
green and the blue LED will turn on solid.
THE CONTROLLER STATUS SCREEN
3
4
5
Controller & Transmitter Overview (cont’d)
“lock” button
“trunk”
button
“unlock”
button
“start” button
Transmitter part number: 1410-03
Call your dealer or visit www.caralarm.com to order replacement transmitters.
Transmitter battery replacement:
Remove the small screw from the lower back case, and separate the transmitter halves. Replace the CR2032 batteries and reassemble the transmitter case.
THE 1-WAY TRANSMITTER
Controller & Transmitter Functions
LOCK / ARM: Press and release the “LOCK” button.
THE SIREN WILL CHIRP & THE PARKING LIGHTS WILL •
FLASH ONCE.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE LOCK/ARM ANIMATION AND BEEP ONCE
NOTE: PRESSING LOCK TWICE IN 5 SECONDS STARTS THE PARKING TIMER. THE CLOCK WILL CHANGE TO 0:00 AND START COUNTING IN MINUTES & HOURS.
(1-WAY TRANSMITTER: PRESS THE LOCK BUTTON)
UNLOCK / DISARM: Press and release the “UNLOCK” button.
THE SIREN WILL CHIRP TWICE & THE PARKING • LIGHTS WILL FLASH TWICE THEN ILLUMINATE FOR 30 SECONDS.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE UNLOCK/ DISARM ANIMATION AND BEEP TWICE.
(1-WAY TRANSMITTER: PRESS THE UNLOCK BUTTON)
6
Controller & Transmitter Functions (cont’d)
TRUNK RELEASE / CHANNEL 2: Press the “TRUNK” button for 3
seconds.
THE SYSTEM WILL DISARM AND THE TRUNK WILL •
OPEN (IF EQUIPPED).
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE TRUNK RELEASE ANIMATION AND BEEP TWICE
(1-WAY TRANSMITTER: PRESS AND HOLD THE TRUNK BUTTON FOR 3 SECONDS)
REMOTE START: Press and release the “ ” button twice within 5 seconds. (see user feature #21 for additional options)
THE PARKING LIGHTS WILL FLASH ONCE AND THE • STATUS LIGHT WILL FLASH RAPID GREEN.
THE SYSTEM WILL TURN ON THE IGNITIONS AND • PROCEED TO START THE ENGINE.
ONCE THE ENGINE IS RUNNING, THE PARKING • LIGHTS WILL TURN ON AND STAY ON AND THE STATUS LIGHTS WILL FLASH SLOW GREEN.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE REMOTE START ANIMATION AND PLAY A MELODY.
THE CLOCK WILL CHANGE TO 0:00 TO START THE • REMOTE START TIMER. IT WILL TIME HOW LONG THE ENGINE RUNS IN MINUTES & HOURS. (1-WAY TRANSMITTER: PRESS THE START BUTTON
TWICE IN 5 SECONDS)
*
If the engine stalls, the system will make up to 3 more attempts.• Each time you park your vehicle, set the climate controls to give you the de-•
sired interior temperature when you use the remote start.
The engine will run for the preset run time (see user feature #22).
Run Time Extender• : Press the “ ” icon one time while in remote start mode
to restart the engine run timer. The timer on the controller will restart at “0:00”.
NOTE: This can only be used once per remote start cycle. The controller will also give you
“run time expiration” warning (2 chirps) 1 minute before the remote start cycle ends.
If you decide not to drive your vehicle, you can turn off the remote start using •
the same method to turn it on (Default = press “start” twice in 5 seconds)
NOTE: If user feature #21 is programmed for 1 press, the 1st press = Run Time Extender so an additional press is required.
Upon entering the vehicle during remote start mode, turn the ignition key to • the “ON/RUN” position (NOT START!!). When you press the brake pedal, the remote start will turn off allowing the ignition key to take over.
*
x2
7
Controller & Transmitter Functions (cont’d)
CHANNEL 3: Press and hold the “CH3” icon for 3 seconds.
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 3 •
OUTPUT.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE CHANNEL 3 ANIMATION AND VOICE ALERT.
(1-WAY TRANSMITTER: PRESS AND HOLD THE TRUNK & START BUTTONS FOR 3 SECONDS)
CHANNEL 4 (IF EQUIPPED): Press and hold the “LOCK” & “TRUNK” buttons for 3 seconds.
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 4 • OUTPUT.
THERE IS NO 2-WAY CONFIRMATION FOR THIS • FUNCTION.
(1-WAY TRANSMITTER: PRESS AND HOLD THE LOCK & TRUNK BUTTONS FOR 3 SECONDS)
CHANNEL 5 (IF EQUIPPED): Press and hold the “UNLOCK” & “ “ buttons for 3 seocnds
YOUR SYSTEM WILL ACTIVATE THE CHANNEL 5 • OUTPUT.
THERE IS NO 2-WAY CONFIRMATION FOR THIS • FUNCTION.
(1-WAY TRANSMITTER: PRESS AND HOLD THE UN­LOCK & START BUTTONS FOR 3 SECONDS)
*
8
PANIC: Press and hold the “LOCK” or “UNLOCK” button for 3 seconds.
THE SIREN/HORN WILL SOUND, THE PARKING • LIGHTS WILL FLASH, AND THE DOORS WILL LOCK OR UNLOCK DEPENDING WHICH ICON IS PRESSED.
(1-WAY TRANSMITTER: PRESS AND HOLD THE LOCK OR UNLOCK BUTTON FOR 3 SECONDS)
Controller & Transmitter Functions (cont’d)
SILENT ARM / DISARM: Press and release the “TRUNK” button
twice in 5 seconds.
THE PARKING LIGHTS WILL FLASH, AND THE • DOORS WILL LOCK/ARM OR UNLOCK/DISARM DE­PENDING ON THE CURRENT SYSTEM STATUS.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL PLAY THE LOCK/ ARM OR UNLOCK/DISARM ANIMATION.
(1-WAY TRANSMITTER: PRESS RELEASE THE “TRUNK” BUTTON TWICE IN 5 SECONDS)
SENSOR BYPASS: Press and release the “TRUNK” button within 5 seconds of locking/arming the alarm system.
THE SYSTEM WILL GIVE ONE CHIRP TO INDICATE • THE SENSOR IS BYPASSED.
UPON RECEIVING CONFIRMATION FROM YOUR • SYSTEM, THE CONTROLLER WILL ALSO CHIRP ONCE.
(1-WAY TRANSMITTER: PRESS AND RELEASE THE “TRUNK” BUTTON WITHIN 5 SECONDS OF ARMING THE SYSTEM)
THEN
x2
OR
9
AUXILIARY FUNCTIONS 1-4:
The actual operation of these functions will vary from car to car. They are designed
to operate extra vehicle functions like automatic sliding doors or motorized hatches.
Aux 1-4 are virtual outputs only available on certain vehicles when this system is
integrated with the vehicle’s data network. Consult with your installer to nd out if any of these functions are available for your vehicle. If so, conrm each operation with the
controller and write each function in the blank spaces provided below.
- Auxiliary 1 Function (___________________): To activate this function, press and release the “trunk” and “start” buttons simultaneously).
- Auxiliary 2 Function (___________________): To activate this function, press and release the “lock” and “trunk” buttons simultaneously).
- Auxiliary 3 Function (___________________): To activate this function, press and release the “unlock” and “start” buttons simultaneously).
- Auxiliary 4 Function (___________________): To activate this function, press and release the “unlock” and “trunk” buttons simultaneously).
Controller & Transmitter Functions (cont’d)
Other Remote Start Features
It is typically recommended that vehicles equipped with turbocharged engines
allow the engine to idle for after driving to cool the turbocharger. When this Installer Programmable Feature (#4) is enabled, the system will automatically keep the engine running as follows:
• With the engine running, hold the brake pedal and engage the parking
brake. When the brake pedal is released, the system will keep the engine running for the programmed time (1, 2, or 3 minutes), and then automatically turn it off.
• The system may be locked while the engine is running. Turbo Timer can be
prevented from engaging, or “bypassed” if desired, by turning the engine off before engaging the parking brake, or if it’s already engaged, step on the brake pedal to turn the engine off.
This feature will automatically start the engine should the vehicle battery drop below 11 volts or the interior temperature drop to 15 (or 32) degrees fahrenheit. This feature is very useful when the vehicle is parked for a long period of time in cold climates. You must activate these features each time you park your car to use them.
• Turn the ignition switch “on”, then “off” (engine not running), and within 7 seconds
press the valet switch twice. If there is a 2 second delay without additional valet but­ton presses, the horn will honk 3 times activating low voltage start mode.
• To activate low temp starting, enter low voltage start mode as described above
but, before the horn honks, press the valet switch 1 time (15 degrees) or 2 times (32
degrees) within 5 seconds. The horn will honk to conrm your selection.
NOTE: When low temp start mode is activated, low voltage start is also activated. These features will operate once every two hours until the ignition key is turned “ON”.
LOW BATTERY/LOW TEMP AUTOMATIC STARTING
TURBO TIMER FEATURE
