Owner’s
Manual
Model: PLUS4900
For Technical Assistance, please call (800) 638-3600,
or visit www.magnadyne.com
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference; and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications
to this equipment. Such modifications could void the user’s authority to operate the equipment.
PLUS4900-UM.qxp 11/26/2008 1:49 PM Page 1
R
Congratulations on your purchase of a quality Carbine automotive security system. Carbine security
products are technologically superior and have been designed to provide you with years of trouble
free operation.
The information enclosed will provide a ready reference of the operation and maintenance of your
new Carbine security system. Please take a moment to read through this manual fully before use.
Transmitter Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-2
Alarm Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3-4
System Arming / Disarming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4-6
Panic Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Valet Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6-7
Speciality Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-8
Anti-Car Jacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Contents
Transmitter Operation
1
PLUS4900-UM.qxp 11/26/2008 1:49 PM Page 2
Lock Doors & Arms System
Press and Release
Arm and Delete the Internal Shock
Sensor and Optional External Sensor
Transmitter Button
System Function Remark
Car Locator
System Must be Armed for 30
seconds or longer
Press Twice within 3 Seconds
Silent Arming/Disarming Ignition in “OFF” Position
Ignition in “ON” Position,
Press and Hold for 2 Seconds
Channel #4 Output
Unlock Doors & Disarm System
Two Step Door Unlock and
Disarm System
Press Twice within 3 Seconds
Trunk Release - Channel 3
Press and Hold for 1.5 Seconds
Passive Arming Bypass
Press While the System
is in “Disarmed” Mode
Arm System with
Hidden Alarm Function
Press within 3 Seconds
-
+
+
+
-
-
-
-
Panic Function Press and Hold for 3 seconds.
+
Only when Black/White wire
is Programmed for CH4 Output
Press and Release
Enter Valet Mode by Remote
Exit Valet Mode by Remote
Push both Together
Push both together
Transmitter Operation
Active Manual Anti-Car Jacking Mode
2
PLUS4900-UM.qxp 11/26/2008 1:49 PM Page 3
Flash Function
1 Flash System is Armed
2 Flashes System is Disarmed
3 Flashes Disarmed / Triggered
3 or 6 Flashes Progressive Car Finder
Chirp Function
1 Chirp System is Armed
2 Chirps System is Disarmed
3 Chirps System is Armed with Ajar Warning
4 Chirps System is Disarmed with Tamper Warning
2,3,6 Chirps Progressive Car Finder
Parking Light Indicators
Chirp Indicators
LED Function
OFF System is Disarmed
Slow Flashing System is Armed
Fast Flashing System in Automatic Arming
1 Flash Every 5 Seconds System in Valet Mode (When Ignition Key Off)
2 Flashes - Pause Zone 2, Trigger on Trunk/Hook
3 Flashes - Pause Zone 3, Trigger on Door Switch
4 Flashes - Pause Zone 4, Trigger on Shock Sensor
5 Flashes - Pause Zone 5, Trigger on Ignition Switch
LED Indicator
3
