NUQLEO - Phone NEON TOUCH
Table of Contents
Chapter 1- Introduction
1.1 Package contents
1.2 Safe handling of the product
1.3 Battery instructions
1.4 Disposal information
Chapter 2 - Basic setup
2.1 Installing the battery, SD memory and SIM cards
2.2 Charging your phone
2.3 Switching your Phone on/off
Chapter 3 - Getting started
3.1 Home screen
3.2 Call management
3.3 Messaging center
3.4 Sending a message
3.5 Receiving a message:
3.6 Internet access
Chapter 4 - Settings
4.1 Dual SIM card
4.2 Pen calibration
4.3 Phone settings
4.4 Network settings
4.5 Security settings
4.6 Phonebook
4.7 Connectivity
4.8 Restore factory settings
Chapter 5 - Your organizer
5.1 Using your calendar
5.2 Using your alarm
5.3 Using your calculator
5.4 Managing your les
Chapter 6 - Your entertainment
6.1 Using your camera
6.2 Using your Video recorder
6.3 Using your Ebook reader
6.4 Tuning in the FM radio
6.5 Recording audio les
Table of specications
Appendix 1 - FCC RF Exposure information
Appendix 2 - RF Exposure information
Appendix 3 - Copyright statement
2
NUQLEO - Phone NEON TOUCH
Chapter 1 - Introduction
Thank you for purchasing the NeonTouch Multimedia Phone from Nuqleo. This guide will
show you how to set up your phone and use its basic functions.
Once your phone is up and running, you can visit www.nuqleo.com to nd out more about all
the great features your new mobile phone has.
1.1 Package contents
• NeonTouch Multimedia Phone
• Rechargeable lithium-ion battery 3.7V 600mAh
• AC charger/USB sync/data cable
• Earphones with microphone
• Quick Installation Guide (QIG)
1.2 Safe handling of the product
•
Never expose your phone to direct sunlight or excessive heat. Avoid leaving the
product inside a car with the windows closed.
•
Keep your phone in a dry place. Never expose this product to rain or water.
•
Do not use or store your phone in dusty, dirty areas.
•
Do not use harsh chemicals, soaps or detergents to clean your phone.
•
Do not modify, disassemble, open, drop, crush, or puncture this product.
•
Never disconnect your phone while a download or upload is in progress.
•
Switch off the device in restricted areas or where the use of electronic devices
is prohibited.
•
To protect your hearing, make sure the volume level is not set too high when
plugging the headphones.
1.3 Battery instructions
•
Use only the battery and battery charger specied by the manufacturer.
•
The battery has a limited service life so it will need replacing when it no longer holds
enough charge.
•
Dispose of old batteries at directed places.
•
Do not throw batteries into a re.
•
Do not force the battery when installing it.
•
If the battery overheats or changes color while charging it or storing it, stop using it.
•
Do not expose batteries to high temperatures.
•
Do not charge the battery for more than 24 hours.
3
NUQLEO - Phone NEON TOUCH
1.4 Disposal information
Electrical and electronic products as well as batteries must not be discarded as regular household
waste. As part of the company’s eco-friendly approach, we encourage you to recycle and follow
all applicable local waste regulations to dispose of your used devices properly. Never dispose of
batteries in a re.
Chapter 2 - Basic setup
2.1 Installing the battery, SD memory and SIM cards
Before using your phone for the rst time, you must insert a SIM card. You need to have at
least one available in order to operate on a GSM network, known as Global System for Mobile
Communication.
The installation process is as follows:
Carefully slide down the back cover to remove it.
1.
First, insert SIM Card 1in the slot marked SIM1, and do the same with SIM Card 2
2.
(on the right), if adding a second one on your phone, following the layout printed inside
the back compartment.
Next, insert the SD card (if you have one available) in the corresponding slot located in the
3.
lower right section of the compartment, making sure the contacts of the card are facing
down. Close the tray, press down and slide it up gently to lock it.
Now, proceed with the battery installation by aligning the contacts on the unit with the
4.
connectors inside the compartment.
Finally, replace the phone cover by carefully sliding it upward until it locks into place.
5.
2.2 Charging your phone
You must fully charge the battery prior to using the phone for the rst time. Firmly insert the
•
micro-USB end of the supplied charger into the I/O port on the phone, and the other end to a
standard AC wall outlet or to an available USB port on your computer.
The new battery needs to be initially charged for at least 5 hours.
•
Let the battery drain completely, before recharging it to full capacity once again. Thereafter,
•
allow the battery to charge until the icon on the screen stops blinking.
2.3 Switching your phone on/off
Press and hold the Power/End key for several seconds to switch on the device. Next,
•
the home screen will come up.
To switch off the phone, unlock the screen if necessary, and then press and hold the
•
Power/End key again for several seconds. The device will turn off completely.
4
NUQLEO - Phone NEON TOUCH
Chapter 3 - Getting started
3.1 Home screen
As soon as you power-on your phone, you will see the Home screen. This screen provides quick
access to the things you need most, and key information concerning the current operating
status of your phone.
The Locked interface, by default, will come up after 30 seconds of inactivity. To restore
the home screen, slide the screen downwards using the stylus or your nger.
The home screen contains three default shortcuts, located in the bottom of the display.
For a complete list of all the available applications on the phone, choose the Menu option
located on the lower left corner of your home screen. You will also see a system bar on the
bottom, with four additional shortcuts for your convenience.
3.2 Call management
You can dial a telephone number quickly and easily from your home screen. Simply touch
1.
the phone icon to open into the dial interface. From that menu, you can choose SIM 1 or SIM 2
to make the call.
The call center will also allow you to add a contact to your list or send a MMS or SMS to
2.
that number.
To answer a call, press the Answer/Send key or tap on Answer on the left side of the screen
3.
to accept it. To end a call, or to reject an incoming communication, press the
Power/End key or tap on Reject on the right side the screen
You also have the option of choosing Silent to disable the ringer prior to answering or
4.
rejecting an incoming call.
Emergency calls can be made using the numbers provided by your network operator, even
5.
when your phone is locked or the SIM card is not inserted. Please contact your cellular
service provider for details, as emergency numbers and availability vary by country.
3.3 Messaging center
Messaging lets you send text and multimedia messages to any contact that has an SMS or MMS
device. The multimedia messages include photos, video clips contact information, and voice
memos. What’s more, you can send messages to several contacts at the same time.
3.4 Sending a message
1.
To launch the application, tap on the Messaging center shortcut located on the home
screen, and go to Write message. Then choose the type of message you wish to create:
SMS or MMS.
2.
Tap on the screen to activate the keyboard and start composing your message.
3.
When done, click on the Down arrow icon, followed by Options to attach photos, video
clips, or voice memos, if desired.
4.
From this menu, choose an existing contact from your list or add a new recipient phone
number.
5.
Once the necessary elds are lled out, press Send to transmit your message.
5
NUQLEO - Phone NEON TOUCH
3.5 Receiving a message:
When you receive a new MMS or text message, a ring tone will alert you that a new mes-
1.
sage has been received, along with a notication on the display. New messages can be
viewed directly, but you can also access them by tapping on the Inbox located inside the
Message center menu.
For voice messages, a ring tone will alert you that a new message has been received, along
2.
with a notication on the display. Listen to it by tapping on Call or you may choose Back in
order to retrieve it from the missed calls log.
For missed calls, the notication message will pop up on the display along with the status
3.
icon to alert you of this event. Check them immediately, or access them later by selecting
the Call history menu and opening the Missed call list.
3.6 Internet access
From the Applications menu, select the Services icon and tap Internet service to do
1.
the following:
• Homepage: go to a homepage
• Bookmarks: go to a webpage that you have previously bookmarked
• Search or input an URL: to do a search or input an URL
• Recent pages: to see a page from the list of pages you have seen recently
• Settings: to enter your own Internet settings
Please note that some conguration is needed before using the browser, based on the
2.
specic settings of your local service provider.
Chapter 4 - Settings
4.1 Dual SIM card
Tap to open one SIM card, either 1 or 2 or both.
4.2 Pen calibration
Click anywhere on the screen with your stylus to start calibration and follow the instructions
on the screen.
4.3 Phone settings
4.3.1 Time and date
1. Press the Menu key and then select the Settings icon.
2. From the Settings screen, go to Phone settings, then select Time and date.
In this step, you are able to do any of the following:
•
Set Home city: select your city from a list.
•
Set Time/Date: set the time, date, and whether daylight savings is on or off.
•
Set Format: designate whether the date format is 24 hour or 12 hour. Dene also how
the date will be displayed.
6
NUQLEO - Phone NEON TOUCH
4.3.2 Schedule power on/off
Power on/off display: you can set the time for the display when powering it on or off.
4.3.3 Setting the phone’s language
1. When the Main screen is displayed, press the Menu key and then select the
Settings icon.
2. From the Settings screen, go to Phone settings, then select Language.
You can then choose one of the following languages:
English
•
French
•
Spanish
•
Italian
•
4.3.4. Preferred input method
1.
When the Main screen is displayed, press the Menu key and then select the
Settings icon.
2.
From the Settings screen, go to Phone settings and then select Preferred input method.
Finally, select one of the input methods and press the Menu key to conrm your selection.
4.3.5 Display
1.
When the Main screen is displayed, press the Menu key and then select the
Settings icon.
2.
From the Settings screen, go to Phone settings, then select Display.
In this menu, the user can customize any of the following parameters:
•
Wallpaper: You can change the wallpaper for your phone by using an image from either
the system or stored on the phone by you.
•
Power on display: You can set the animation for the display when powering the
phone on. By default, it is set to the Nuqleo animation, but you can set your own under
the User dened option.
4.3.6 Flight mode
1.
When the Main screen is displayed, press the Menu key and then select the Settings icon
followed by Phone settings and then go to Flight mode.
2.
Tap to enable Normal mode or Flight mode.
4.4 Network settings
1.
When the Main screen is displayed, press the Menu key and then select the Settings icon
followed by Network settings.
2.
Tap SIM 1 or SIM 2 to do a New search, to Select the network or to select the Automatic
or Manual mode.
3.
GPRS transfer preference:
Data prefer
•
Call prefer
•
7
NUQLEO - Phone NEON TOUCH
4.5 Security settings
The phone can be locked to prevent the unintended activation of your device, or to protect
it against the unauthorized use of your phone or account. There are 3 security options you
can resort to by choosing.
Applications menu> Settings > Security settings:
1.
Keypad/Screen lock: it locks your screen at the set interval.
2.
Phone lock: set up a password to lock your phone.
The factory default is 1122.
3.
SIM PIN: set up a PIN code to control access to your card. The initial account PIN is
provided by your mobile service provider.
4.6 Phonebook
From the home screen, select the shortcut to activate the phonebook. On the Phonebook
screen, you may:
4.6.1 Select Add new contact followed by Options to:
1.
Select: to enter a new contact.
2.
Caller groups: to add a new caller group.
3.
Phonebook settings: to congure your own preferences such as Preferred storage for
your contacts, Speed dial, Extra numbers and Memory status.
4.6.2 Select a contact followed by Options to:
Call, send text or multimedia messages to a contact or edit or delete information about
a contact.
4.7 Connectivity
4.7.1 Bluetooth®
When the Main screen is displayed, press the Menu key and then select the Settings icon
followed by Connectivity and Bluetooth®. On the Bluetooth® screen, you will be able
to set the following congurations to pair your phone with a Bluetooth® device.
• Power: tap to turn the Bluetooth® it on or off
• Visibility: tap to make your phone visible
• My device: tap to start a search to discover a new device.
• Search audio device: tap to start a search to discover a new audio device.
• My name: put a name to your device so that it can be identied when detected and then,
tap Options followed by Done, Cancel or the Input method.
• Advanced: tap to see options such as Audio path, Storage, My address.
4.7.2 Data account
Tap to see, enter or edit information about your service provider for SIM1 and SIM2 cards.
4.8 Restore factory settings
Tap to input the phone password in order to restore the original settings.
8
NUQLEO - Phone NEON TOUCH
Chapter 5 – Your organizer
5.1 Using your calendar
When the Main screen is displayed, press the Menu key and then select the Calendar icon.
Tap Options on the Calendar screen to have different calendar views and to manage your
events by selecting one of the following:
•
View, View all, Add an event and Delete an event.
•
Jump to date: This view goes to the date you enter.
•
Go to today: This view shows you a monthly view and the current date.
•
Go to weekly view: This view shows you the current week.
5.2 Using your alarm
When the Main screen is displayed, press the Menu key and then select the Organizer icon to
open the Alarm.
1. Select one of ve alarm slots and press the Menu key to Edit the slot.
2. On the Edit screen, you have the following options:
• You can switch the alarm on or off.
• You can set the alarm time.
• You can choose if and when to repeat the alarm: Once, Everyday, or Custom.
• You can choose to have the alarm play a ring tone or a tone selected from your le.
• You can choose to have the alarm snooze for a certain amount of time.
5.3 Using your calculator
When the Main screen is displayed, press the Menu key and then select the Calculator icon.
The Navigation key is used to designate the arithmetic operation. For example, if you want
to add two numbers, you would enter the rst number, press the Navigation key upwards to
enter the addition symbol, and then enter the second number. Pressing the Menu key will
complete the equation and give you the result.
5.4 Managing your les
When the Main screen is displayed, press the Menu key and then select the File manager icon.
On the File manager screen, select Options followed by Phone to perform the following actions:
1. Open: to see the les stored on your phone.
2. Memory card: to see the les stored on your memory card, format and see the details
of your memory card.
9
NUQLEO - Phone NEON TOUCH
Chapter 6 – Your entertainment
6.1 Using your camera
When the Main screen is displayed, press the Menu key and then select the Camera icon.
Tap Options on the camera screen to do the following:
1.
Switch to camera: change from Camcorder mode to Camera mode.
2.
Photos: see your photos with the Image viewer and tap Options to see information of
your image, choose the style you want to use when browsing, send your image, and use it
as wallpaper or as display when powering your phone on or off.
3.
Camera settings: select and save your own congurations to take your snapshot.
4.
Image settings: resize and adjust the quality of your photograph.
5.
White balance: select different modes to adjust the lightning of your image.
6.
Scene mode: select different exposure times to shoot your photograph.
6.2 Using your video recorder
When the Main screen is displayed, press the Menu key and then select the Camera icon.
Tap Options on the lower left corner of the screen, to do the following: era screen to do
the following:
1.
Switch to video recorder: change from Camera mode to Camcorder mode.
2.
Camcorder settings: select and save your own congurations for your video.
3.
Video settings: adjust the quality of your video.
4.
White balance: select different modes to adjust the lightning of your video.
5.
Effect settings: select your own effect congurations for your video.
6.
Storage: select the device to save your video.
6.3 Using your Ebook reader
When the Main screen is displayed, press the Menu key and then select the Ebook reader icon.
Tap Options on the Bookshelf screen and Global settings to select the following options:
• Font size
• Scroll by page or line
• Scroll speed
• Select storage (Memory card/Phone)
6.4 Tuning in the FM radio
When the Main screen is displayed, press the Menu key and then select the FM radio icon. In order
to listen to the radio, you will have to plug in the earphones. You can control the radio by tapping the
controls on the radio screen.
Tap Options on the lower left corner of the radio screen to do the following:
10
NUQLEO - Phone NEON TOUCH
1.
Channel list: to play, delete or edit a channel from the Channel list.
2.
Manual input: to enter a radio station manually.
3.
Auto search: to do an automatic search and save channels
4.
Settings: to select radio settings such as Background play, Loudspeaker, Audio quality
and Record storage.
5.
Record: plug in your earphones and you will be able to tune and record your favorite FM
radio station in real time, save it in .wav format le for play back.
6.
File list: to Play, Send, Use, Rename or Delete your sound les.
The controls are as follows:
• Navigation key down: turns the radio on or off.
• Navigation key right or left: changes the radio station.
6.5 Recording audio les
When the Main screen is displayed, press the Menu key and then select the Audio recording
icon. Tap the Option icon to open the Audio recording screen. Use the Red button in the
center to start recording, the Square to stop and save it and the Play icon to reproduce it.
You can also select Options to perform the following actions:
1.
New record: select this option to Play, Record, Stop, Fast forward and Rewind an
audio le
2.
List: select this option to Play, Rename, Delete, Use and Send your audio le.
3.
Settings: select this option to store your audio le on the Phone or the Memory card
and to adjust the quality of your le.
11
NUQLEO - Phone NEON TOUCH
Table of specications
Size and weight
Technology
/Platform
Memory
Display
Entertainment
Camera
Connectivity
Sound
Battery*
Other
Height
Width
Depth
Weight
Single USB Jack
Network
Phone type
Operating system
SIM
Phonebook
Call records
Internal
Expandable
Type
Size
Resolution
Radio
TV
GPS
Video and audio player
Vibrate alert
Messaging
Browser
Camera Integrated 0.3 MP camera, with zoom and video recording capability
Wi-Fi
Bluetooth®
Flight mode
Keypad
USB Tethering
Alert types
Speakerphone
Earphone jack
Type and capacity
Standby time
Talk time
Warranty
Languages
Certications
98 mm
54 mm
11.5 mm
90g approx (with battery)
Data/charging
Quad band GSM 2G, at 850/900/1800/1900 MHz
Multimedia
N/A
Dual SIM card capability
20 dialed calls, 20 missed calls, 20 received calls
300 entries
8MB ROM +4MB RAM (64Mb+32Mb)
Supports up to 16 GB with micro SD card slot
Full resistive display
2.4 inches
QVGA, 240 x 320 pixels
Yes
Yes
N/A
MP3, MIDI, MP4, 3 GP and AVI formats
Yes
SMS, MMS
WAP compliant with GPRS, for high speed data transmission
and smooth internet connection
N/A
Yes
Yes
Compact onscreen QWERTY keypad
N/A
Multiple polyphonic ringtones
Yes
Yes
Li-ion battery, 3.7 V 600mAh
Up to 9 days
Up to 4 hours
Yes
Multilingual: English, Spanish, Italian and French
FCC
Please note duration times vary depending on usage patterns and conditions. Battery power
*
consumption depends on factors, such as network conguration, signal strength, operating
temperature, features selected; vibrate mode, backlight settings, browser use, frequency of
calls, and voice, data, and other application usage patterns.
Specications subject to change without notice.
12
NUQLEO - Phone NEON TOUCH
Appendix 1 - FCC RF Exposure information
WARNING! Read this information before using your phone
In August 1986 the Federal Communications Commission (FCC) of the United States with
its action in Report and order FCC 96-326 adopted an updated safety standard for human
exposure to radio frequency (RF) electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard previously set by both
U.S. and international standards bodies. The design of this phone complies with the FCC
guidelines and these international standards. Use only the supplied or an approved antenna.
Unauthorized antennas modications, or attachments could impair call quality, damage the
phone, or result in violation of FCC regulations. Do not use the phone with a damaged antenna.
If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact
your local dealer for replacement antenna.
Body-worn operation
This device was tested for typical body-worn operations with the back of the phone kept 1.5cm
from the body. To comply with FCC RF exposure requirements, a minimum separation distance
of 1.5cm must be maintained between the user’s body and the back of the phone, including the
antenna, whether extended or retracted. Third-party belt-clips, holsters and similar accessories
containing metallic components shall not be used. Body-worn accessories that cannot maintain
1.5cm separation distance between the user’s body and the back of the phone, and have not
been tested for typical body-worn operations may not comply with FCC RF exposure limits and
should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
Your wireless handheld portable telephone is a low power radio transmitter and receiver.
When it is ON, it receives and also sends out radio frequency (RF) signals. In August, 1996,
the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety
levels for hand-held wireless phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
<ANSIC95.1> (1992) / <NCRP Report 86> (1986) / <ICIMIRP> (1996)
Those standards were based on comprehensive and periodic evaluations of the relevant
scientic literature. For example, over 120 scientists, engineers, and physicians from
universities, government health agencies, and industry reviewed the available body of research
to develop the ANSI Standard (C95.1). Nevertheless, we recommend that you use a hands-free
kit with your phone (such as an earpiece or headset) to avoid potential exposure to RF energy.
The design of your phone complies with the FCC guidelines (and those standards).
Use only the supplied or an approved replacement antenna. Unauthorized antennas,
modications, or attachments could damage the phone and may violate FCC regulations.
13
NUQLEO - Phone NEON TOUCH
Normal position
Hold the phone as you would any other telephone with the antenna pointed up and over your
shoulder.
Tips on efcient operation
For your phone to operate most efciently:
• Extend your antenna fully.
• Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna
affects call quality and may cause the phone to operate at a higher power level than
otherwise needed.
Appendix 2 - RF Exposure information
FCC RF Exposure requirements: The highest SAR value reported under this standard during
product certication for use next to the body with the minimum separation distance of 1.5cm
is 0.555W/kg, next to the head is 1.144W/kg. This transmitter must not be collocated or
operating in conjunction with any other antenna or transmitter.
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
Appendix 3 – Copyright statement
Reproduction of this manual or any part thereof is forbidden without written consent from
Nuqleo.
14
Loading...
