Sports Smart Watch
User Manual
Thank you for choosing our smart band. You can
read this manual thoroughly to understand the
use of the equipment and how to do it simply.
The Company reserves the right to make changes
to the contents of this manual without prior
notice without prior notice.
Product configuration:
1. Smart Watch * 1
2. Data cable* 1
3. Manual * 1
This product supports IP68 waterproof, so it’s
available to wear it while wash hands, swim, take
a shower, etc.
Key Description:
A: Page up
B: Page down
C: Short press to confirm, long press to enter the
sports mode
D: Short press to return, long press to boot.
E: Shortcut page up / down button
Charging Description: This product uses magnetic
charger. Align the charging head at the back of the
charging contact, will automatically adsorb the
charge.
Please note that the two contacts of the charging
cable can not touch the conductive object at the
same time, otherwise it will cause short circuit
combustion.
How to connect the phone:
(1) IOS, Andriod System Phone users:
Through the phone browser to scan the back of
the QR code and select the first download.
Or sweep with a WeChat. When you open the
interface, and then click the upper right option,
select the mobile browser to open and download.
(2)Android Phone: download “Fundo” app from
Google Play;
IOS phone: download “Fundo” app from App
Store;
Open “Fundo” app and Bluetooth function from
your phone after finish install, click “more” as
below, then click “connect watch”. And then point
the upper right corner of the "search", search
Smart Device and can be connected,
When the upper left corner of the watch has a
Bluetooth logo, on behalf of the connection is
successful.
●Firmware upgrade: At normal Bluetooth connect
ion status, enter FunDo, click More on the bottom
right corner, find the firmware upgrade item, clic
k it. If there is a new version, you will be prompte
d to upgrade, click YES, there will be a progress ba
r afre you click YES, the upgrade process will take
3-5 minutes. The device will automatically boot a
nd connect with smartphone after the upgrade is
complete. Please disconnect the device, then con
nect again. Please note that if the progress bar is s
tuck, please do not do any thing, let the progress
work slowly until it is complete.
Since there would be some difference of
Bluetooth protocol for different smart phones, it
may cause Bluetooth connection unstable
sometimes. Turn off Bluetooth on the phone,
then re-connect the and phone.
Main Features: (first to open the APP on the
mobile phone and connect to, in order to achieve
the following functions)
● Standby interface: Enter the main menu, dial
function to replace, there are a variety of dial can
be replaced.
● Pedometer: display the number of steps in a day,
save data at 12 o’clock every night and reset to 0.
● Distance: show the day's step distance, save
data at 12 o’clock every night, and reset to 0
● Calories: show the calorie burned of the day,
save data at 12 o’clock every night and reset to 0.
● Heart rate: press the enter key to test and scan
the surface capillary of the skin by green light to
get the heart rate data, switch to other menus to
stop measuring, normal heart rate is generally
60-90 times / minute, professional athletes will be
less than 60 times, when doing strenuous exercise
will reach more than 200 times. Long term
exercises can increase heart and lung.
● Sleep monitoring: the smart watch will open
this function automatically from 9p.m to 9 a.m.
every night. You can check the detailed data of
sleep quality by connecting APP on the phone.
● Sports: Press Enter to enter multi-sport mode,
press the touch key to select the sport mode.
Selected a mode, press Enter to start the sport,
short press Return to stop, the watch will save the
sport data automatically, then return to
multi-sport mode. There are jogging, biking,
swimming, basketball, table tennis, badminton,
hiking, love and football modes in the multi-sport
mode. Each exercise data has movement time,
calories consumption, and heart rate (swimming
mode without heart rate)
● Notifications: synchronous mobile phone end
notification function, such as Facebook,
WhatsApp and so on, if you want to display the
notifies with content, need to setup to display the
details of Facebook and WhatsApp notice
function in the APP in the cellphone, it can show
the latest 8 notifications, press the enter key to
read, press the touch key to next message , short
press return key to back. It will vibrate for
incoming calls and messages.
● Tooling: Software version (check the Bluetooth
address and name), Bluetooth camera (APP side
to open the Bluetooth camera, watch side click to
take pictures, long press to exit). Find the phone
(find the bracelet) shutdown (select the shutdown,
press long press).
● Language: support in English and Chinese
display, the default is automatically synchronized,
what language is the phone, the shows what
language.
● Stopwatch: press the enter key to enter, then
press again to pause.
● Alarm: Can set several alarm clocks through
the APP on mobile phone.
● Data transmission: need to download FunDo
APP on mobile phone, after the connection is
successful, the date of Pedometer, heart rate,
sleep quality, and multi-sport mode can be
transmitted to the APP on the mobile phone.
Some data needs to be manually synchronized.
Warranty
1. If it appears quality problems caused by
manufacturing, materials, design within one year
（since the day of purchase）, we will offer free
warranty for. We will offer free warranty for
battery and adapter within 6 months. Premise is
using normally and correctly.
2. About the fault caused by the users personal
reasons, we don't offer free warranty, as follows:
1). Disassemble or refit the product.
2). Caused by immodesty drop
3). All artificial damage or misuse (such as: make
water into the host, the external force shatter,
scratch damage of peripheral components, etc.),
all these are beyond the scope of the warranty.
3. When ask for free warranty, you must provide a
warranty card with the seal of purchase place and
purchase date.
4. If you met problems during use, please contact
the shop customer service which you bought
from.
5. Please make the final products as the standard.
Date of purchase:
IMEI code:
Buy store:
Customer signature:
Clerk Signature:
Shop stamp:
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
