Cirrus Truck Camper Manual
2017 MODEL 820
Disclaimer and Copyright
All information, illustrations and specifications contained in this manual are based on the latest product
information available at the time of publication approval. When new materials and production techniques are
developed that can improve the quality of its product, or material substitutions are necessary due to availability,
nüCamp RV reserves the right to make such changes
Cirrus Owner’s Manual 2017
nüCamp RV
Publication Date: January 2017
NOTES
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
__________________________________________________________________________________________
TABLE OF CONTENTS
Welcome to the Nücamp RV family and thank you for
selecting a Nücamp RV. product. Congratulations for
choosing a lifestyle that will provide you the freedom to enjoy
recreation wherever you may choose. ...................................... 1
Coverage Provided .......................................................... 1
Owner’s Obligation ......................................................... 1
Limited Warranty ............................................................. 1
Warranty Exclusions ........................................................ 1
Customer Information ...................................................... 2
Taking Delivery ................................................................ 2
Making a Service Appointment ........................................ 2
Organize........................................................................... 2
Waiting at the Repair Facility .......................................... 2
Dealers Responsibilities ................................................... 2
Owners Responsibilities ................................................... 3
Customer Relations Information Safety and Identification
......................................................................................... 3
LP Gas ............................................................................. 3
Fire Safety ........................................................................ 4
Recreational Vehicle Serial Number, Decals, and Data
Plates ............................................................................... 5
Information about This Manual ....................................... 5
Product Changes .............................................................. 5
Owner’s Info Package ...................................................... 5
Identifying Your Camper and Its Components ................ 6
Camper and Truck, Weighing, Loading ........................... 7
Matching Camper and Truck ........................................... 7
Federal Certification Label ............................................. 7
Truck Payload .................................................................. 7
Optional Weights ............................................................. 7
Tires ................................................................................. 7
Axle Weight ...................................................................... 7
Weighing Your Truck & Camper ..................................... 7
Weight Certification Label .............................................. 8
Find Center of Gravity for Loading ................................ 8
Attaching Camper to/Removing from Truck .................... 9
Loading/Removing Camper ............................................. 9
Removing Camper from Truck ........................................10
Electric Jacks ..................................................................10
Jack Remote Control ......................................................10
Jack Fuse Panel Location ............................................... 11
Support Equipment ......................................................... 12
Air Bags .......................................................................... 12
Heavy Duty Shocks ......................................................... 12
Tie downs and Turnbuckles ............................................ 12
Hitching and Towing Systems ......................................... 12
Effects of Prolonged Occupancy..................................... 13
Condensation & Humidity .............................................. 13
Ventilation & Moisture Control ...................................... 13
Fire and Safety................................................................ 14
Fire Extinguishers .......................................................... 14
Smoke Detector ............................................................... 14
Carbon Monoxide Gas Safety Precautions ..................... 15
Carbon Monoxide & Propane Detectors ........................ 15
Backup Camera ..............................................................16
Electrical System ............................................................16
Interior Lighting ............................................................. 17
120-volt AC System ......................................................... 17
12-volt DC system ........................................................... 17
Battery and Compartment ............................................ 17
Battery Information ........................................................ 17
Battery Storage Precautions ........................................... 18
Battery Charging ............................................................ 18
Battery Disconnect Switch .............................................. 18
System Monitor Panel ..................................................... 18
Water Pump Control Switch ...........................................19
Camper Fuse Panel (12-volt Interior Circuits) ..............19
Solar Panel .....................................................................19
120-volt Power Cord ......................................................19
Power Distribution Center ............................................ 20
Ground Fault Circuit Interrupter .................................. 20
A
Power Generator ........................................................... 20
Generator Operating Safety Precautions and Warnings20
Loading the Generator .................................................... 21
Propane Gas Safety......................................................... 21
Propane Tank ................................................................. 22
Filling Propane Tanks ................................................... 22
Using Propane System ................................................... 22
Single Propane Tanks .................................................... 22
Propane Gas Fuel System .............................................. 22
Propane Gas System Troubleshooting ........................... 23
On the Road ................................................................... 23
Loading .......................................................................... 23
Storage ........................................................................... 23
Preparing for Travel ...................................................... 23
Pre-Trip Checks ............................................................. 24
Post-Trip Clean-Up ....................................................... 24
Safe Driving Rules ......................................................... 24
Riding in Camper While Traveling ................................ 24
Campground Regulations .............................................. 24
Equipment ...................................................................... 24
Roof ................................................................................ 25
Compartment Doors....................................................... 25
Vents .............................................................................. 25
Roof Vent........................................................................ 25
Skylight........................................................................... 25
Emergency Exit Window ................................................ 26
Windows and Skylight venting ....................................... 26
Shades ............................................................................ 26
Exterior Lighting ............................................................ 26
Ladder ............................................................................ 26
Entry Door Locks ........................................................... 26
Awning ........................................................................... 28
Rear Awning .................................................................. 28
Camper Bumper/Step ..................................................... 28
Dinette Conversion ........................................................ 28
Fold Down Top Cabinet ................................................. 28
Appliances ..................................................................... 28
Lighting Propane Appliances ........................................ 29
Refrigerator ................................................................... 29
Range ............................................................................. 29
Microwave Oven ............................................................ 30
Alde Heating System .................................................... 30
Roof Mounted Air Conditioner ....................................... 31
Camp Site Cable Inlets .................................................. 32
Roof Mounted Antenna .................................................. 32
LCD TV .......................................................................... 32
Fresh Water System ....................................................... 32
Water Pump ................................................................... 32
Water Tank Fill .............................................................. 33
Filling the Fresh Water Tank ........................................ 33
City Water Connection .................................................. 33
Water System Drain ....................................................... 33
To Drain your Camper: ................................................. 33
Sanitizing Fresh Water System ...................................... 33
Water Filter ................................................................... 34
Shower ........................................................................... 34
Exterior Wash Station (Shower) .................................... 34
Waste System ................................................................. 34
Fresh Water Flush Toilet ............................................... 34
Black Water Holding Tank ............................................ 34
Sewer Hose Storage ....................................................... 34
Bathroom ....................................................................... 34
Toilet .............................................................................. 34
Holding Tanks................................................................ 35
Holding Tank Care/Maintenance .................................. 35
Winterization ................................................................. 36
Operating in Freezing Conditions ................................. 36
Storage ........................................................................... 36
Short-Term Storage ....................................................... 36
Long-Term Storage ........................................................ 36
Storage below Freezing ................................................. 36
Winterizing with RV Antifreeze ...................................... 37
B
Water Heater Bypass 2017 Models ................................ 37
To De-Winterize: ............................................................ 37
Reactivating Camper after Storage ................................ 37
Outside Area .................................................................. 37
12-Volt System ............................................................... 38
120-Volt System ............................................................. 38
Fresh Water System ....................................................... 38
Propane System .............................................................. 38
General .......................................................................... 38
Maintenance ................................................................... 38
General Maintenance ..................................................... 38
Exterior Maintenance .................................................... 38
Exterior Graphics .......................................................... 39
Damage Checks ............................................................. 39
Sealant Renewal ............................................................. 39
Doors and Windows ....................................................... 39
Acrylic Windows/Skylight ............................................. 40
Roof ............................................................................... 40
Jack Brackets ................................................................ 40
Camper Jacks ................................................................ 40
Turnbuckles ................................................................... 40
Air Conditioner ............................................................. 40
Overhead Vents ............................................................. 40
Skylight........................................................................... 41
Exterior Lights ............................................................... 41
Wiring ............................................................................ 41
Battery(s) ....................................................................... 41
Awning ........................................................................... 41
Interior Maintenance ..................................................... 41
Interior Odor .................................................................. 41
Upholstery & Drapes ..................................................... 41
Wall & Ceiling Panels ................................................... 41
Floors & Carpeting........................................................ 41
Wood Product Care ....................................................... 41
Fiberglass Care ............................................................. 41
Laminate Counter Top Care .......................................... 42
Refrigerator ................................................................... 42
Drains ............................................................................ 42
Shower Care .................................................................. 42
Sink Care ....................................................................... 42
Maintenance Chart 1 ..................................................... 43
Maintenance / Repair Schedule ..................................... 44
Camper Loading & Checking ........................................ 44
Component Manufacturers Contact Information ........... 45
1
Welcome to the Nücamp RV family and thank you for
selecting a Nücamp RV. product. Congratulations for
choosing a lifestyle that will provide you the freedom to
enjoy recreation wherever you may choose.
This Owner’s Manual is designed as a Quick Reference
Guide for the operation and care of your new purchase.
For more complete instructions regarding safety,
maintenance and operation of the items used in the
manufacturing of your RV, carefully read the booklets
supplied by the component manufacturers. All
information contained in this manual may not relate to
your specific model; however, booklets supplied by the
component manufacturers and included in your Owner’s
packet will provide any additional information needed.
Your dealership personnel should be able to answer any
questions or concerns you may have regarding your new
product. If your dealer is unable to do so, please feel free
to contact our Customer Service department for
assistance. Your dealership will provide you with the
appropriate contact information.
Please carefully read the Limited Warranty in the front
of this manual. Nücamp RV has no other expressed or
implied warranties of any type. You, as the owner, are
responsible for providing proper maintenance as outlined
in the manual and as set forth in the component
manufacturer’s booklets.
NOTE: FAILURE TO PROPERLY MAINTAIN
YOUR RV COULD RESULT IN LOSS OF
WARRANTY COVERAGE
Several of our component manufacturers carry their own
warranties and require separate warranty information to
be filed with them. Please read all component
manufacturers’ owner’s manuals provided with your RV
and file appropriate individual warranty cards as
required.
You have joined an elite group, and as you begin making
great memories using your new Nücamp RV Camper
we wish you many exciting and adventurous days of
camping.
Coverage Provided
Within the Warranty Period, Nücamp RV is obligated to
repair or replace any part covered by this warranty proven
defective. In the event of such an occurrence, the Owner
should contact the selling dealer for a service appointment. If
it is not possible to return to the selling dealer, call the
Nücamp RV Factory Service Department, and they will
provide you with the location of the nearest authorized dealer
or repair facility. The cost of transporting the Camper to the
dealer or service center shall be incurred and paid for by the
Owner.
Owner’s Obligation
The purchaser must notify Nücamp RV or a Nücamp RV
authorized dealer of any defect promptly upon discovery.
Warranty repairs by a non-Nücamp RV Dealer or service
center must be approved by the Nücamp RV Factory
Warranty Department prior to any work being started.
This is the only warranty given with the purchase of the
Camper other than express or implied warranties given by the
component manufacturers. Any warranties implied by law are
limited to the Warranty Period. Any other warranty, express or
implied, not provided for in this Limited Warranty is waived
by the Owner, to the extent allowed by law.
Limited Warranty
Nücamp RV warrants to the original end user purchaser
(“Owner”) of this Camper, to be free of defects in materials
and workmanship and for structural integrity, under normal
use, with reasonable care and maintenance, for one (1) year
from the date of purchase (the “Warranty Period”), subject to
the exclusions given below.
Warranty Exclusions
This warranty is limited to only items constructed by
Nücamp RV, Nücamp RV therefore makes no warranty
with respect to component parts constructed or
assembled by other manufacturers, including, but not
limited to, all electrical devices (TV, sound systems,
DVD player, antennas, batteries, etc.), the propane
appliances, electrical appliances, heaters, refrigerators,
plumbing fixtures, light fixtures, lights, entrance door
and windows. Such component parts may be warranted
by their respective manufacturers, and copies of such
warranties are included with the Camper.
This warranty does not cover damage caused by or
related to (1) normal wear and tear, (2) accidents, abuse,
misuse, or negligence, (3) failure to comply with
instructions contained in the Owner’s Manual, (4) any
alteration or modification of the Camper, or (5)
environmental conditions, including, but not limited to,
road salt, hail, or windstorm. Nor does this warranty
apply to parts made from cloth, leather, wood, paint, or
chrome, which have been affected by airborne fallout,
including, but not limited to, chemicals and tree sap.
2
No payment or other compensation will be made for
incidental expenses, including, but not limited to,
towing, telephone, transportation, lodging, travel,
gasoline, loss of pay or indirect or consequential damage
including, but not limited to, loss of use of the Camper,
inconvenience, damage or injury to person or property,
or loss of revenue, which might be paid, incurred, or
sustained because of manufacturer’s defect covered by
this warranty. Nücamp RV does not warranty
equipment or accessories installed at any dealership or
other place of business, or by any other party.
As the manufacturer of the Camper that you purchased,
Nücamp RV does not know the purpose you have in
mind for your truck and camper, nor does Nücamp RV
know the Gross Vehicle Weight Rating (“GVWR”) of
your truck. Therefore, Nücamp RV makes no warranties
or representations, express or implied, as to the
performance of your truck with the Camper or whether
the match up of your truck and Camper exceeds the
GVWR as specified by your truck’s manufacturer.
Specifically, there is no express or implied warranty of
merchantability or of fitness for the match of your truck
to any camper.
This Limited Warranty is intended to comply with the
requirements of both State and Federal laws. Any part of
this Limited Warranty in conflict with any law shall be
ineffective to the extent of any such conflict. This
warranty gives you specific legal rights, and you may
also have other rights, which may vary from state to
state.
Customer Information
Taking Delivery
The dealer will complete the Pre-Delivery Inspection /
Warranty Registration form when you take delivery for your
new camper. If you do not have a copy of this form in your
Owners Packet, request a copy for your records. It is an
important part of the history of your Camper.
A qualified dealer representative will perform a ‘walkthrough’ demonstration which will provide you with important
information regarding the operation of your unit. Be sure you
fully understand the information given, and the proper
functioning of your camper, to ensure you have the best
camping experience possible. Your dealer will fully explain all
the system functions and will supply the component
information for products used in the manufacture of your
camper.
Making a Service Appointment
Always call ahead for an appointment unless you have a true
emergency. Monday and Friday are usually the busiest days
for the Service department, as well as just before a holiday.
Give them ample time to schedule your Camper for service.
When you call to schedule your appointment, have the
following information available:
1) VIN. Number or Serial Number containing 17 letters
and digits.
2) Type of Unit (example; Cirrus Camper)
3) Date of Purchase
4) Description of Problem
5) Add photos of damage
6) History of repairs and repair center location (where
the repairs were performed).
7) A calendar with your schedule noted, for
convenience in coordinating a service date that works
for you and the repair center.
Organize
Planning and being prompt when having service is beneficial
for all. When someone misses their appointment, or arrives
late, it disrupts the service schedule for the entire day so drop
your unit off at the scheduled time and on the scheduled date.
Have a list ready, be specific and reasonable with your
expectations. Some repairs may require special order parts.
Waiting at the Repair Facility
For safety reasons, most insurance policies prohibit nonemployee personnel to be in the work area.
If it is necessary for you to wait until the repairs are
completed, most dealers provide you with a safe, comfortable
customer lounge.
Dealers Responsibilities
1) The dealership is responsible for inspecting both
factory and dealer installed components for proper
operation. This is known as the Pre-Delivery
Inspection and Systems Check. This will assure you
that all components are in proper working order and
free of defects prior to you taking delivery.
2) Your dealer is required to provide a thorough and
complete walk-through demonstration. This
demonstration should provide a good understanding
of how your new camper operates.
3) The owner’s information packet should be presented
at this point. This information should include all
warranty cards, component information, operation
and maintenance instructions relating to your new
Camper.
4) All component warranty registration forms should be
discussed and/or completed now. Your selling dealer
should explain and you should fully understand, the
warranty provided on your camper.
3
5) Your dealer should provide you with information
concerning any need for service for your unit,
whether in or out of their area. They should also
provide you with the contact numbers for the
dealership, along with contact information for
Nücamp RV.
Owners Responsibilities
1) Regular and proper maintenance. As the owner, you
have the responsibility to properly maintain your
Camper. Be sure you have service performed in a
timely manner. Don’t ignore a problem; sometimes a
phone call is all that’s needed. The service
technicians will advise you if an appointment needs
to be scheduled.
2) Familiarize yourself with your camper. Observe all
the component manufacturers instructions regarding
the use and service of their products.
3) Complete and return all the warranty cards to each
respective manufacturer. Doing so may help you
avoid the loss of warranty coverage.
NOTE: Modifications to your camper, without written
authorization from Nücamp RV, could result in reduction or
loss of warranty coverage. Contact your dealer before making
such changes.
The following are suggestions to assist you in avoiding most
warranty issues:
1) Read your warranties and review them with your
selling dealer. The dealer’s obligation is to educate
you regarding the proper and safe operation of your
camper and all its’ components.
2) Be sure to inspect the entire camper and note any
service issues.
3) Locate all paperwork and ask any questions you may
have before leaving the dealership.
NOTE: Nücamp RV wants you to have the best possible
adventure with your new Camper. To get the most enjoyment
out of your new Camper and to ensure you fully understand
how it operates, please discuss with your dealer, any questions
or concerns you may have regarding your camper, before
leaving the dealership or using your camper for the first time.
NOTE: Use your new Camper responsibly. Your camper was
not designed to be used as a permanent dwelling but for short
term and recreational use. If you intend to use your Camper as
permanent housing, be advised that it could cause premature
wear on your appliances, furnace, water systems, carpet,
drapes, upholstery, bedding, and interior surfaces. Premature
wear caused by permanent residency may be considered
abnormal or abusive use and could reduce or in some cases,
void your warranty coverage.
Customer Relations Information Safety and
Identification
Your safety, and the safety of others, is very important.
Operating your truck and camper is an important
responsibility.
As you read this manual, statements preceded by the following
words are of special significance:
Indicates a potentially hazardous
situation which, if not avoided, may result in death or serious
injury.
Indicates a potentially hazardous
situation which, if not avoided, may result in damage to the
component, camper, or your truck.
This information is intended to help you reduce the risk of
personal injury and prevent possible damage to others, your
truck, camper and its equipment, or the environment.
To help you make informed decisions about safety, we have
provided operating procedures and other information on labels
in your camper and in this manual. There are also warnings in
the appliance manuals in the Owner’s Information Package.
This information alerts you to potential hazards that could hurt
you or others.
Of course, it is not practical or possible to warn you about all
the hazards associated with operating or maintaining your
camper. You must use your own good judgement.
This manual is filled with important safety information please
read it carefully. If you have any questions regarding
operation, maintenance, or service, please contact your dealer
immediately so he can assist you.
Nücamp RV is required to furnish the following consumer
information as provided by the National Fire Protection
Association and the American National Standards Institute.
The information and warnings found here might also be found
in other chapters of this Owner’s Manual. Please see chapters
titled “Propane System” and “Appliances” for other safety and
operating information.
LP Gas
Propane containers must not be placed or stored inside the tow
vehicle. Propane containers are equipped with safety devices,
which relieve excessive pressure by discharging it to the
atmosphere.
4
There is a label located in the cooking area to remind you to
provide an adequate supply of fresh air for combustion.
It is not safe to use cooking appliances for comfort heating.
Cooking appliances need fresh air for safe operation. Before
Operation:
Open overhead vent or turn on the exhaust fan.
Open window.
Failure to comply could result in death or serious injury.
Unlike homes, the amount of oxygen supply is limited due to
the size of the recreational vehicle, and proper ventilation
when using cooking appliances will avoid dangers of
asphyxiation. It is especially important that cooking
appliances not be used for comfort heating as the danger of
asphyxiation is greater when the appliance is used for long
periods of time.
Portable fuel-burning equipment, including wood and charcoal
grills and stoves shall not be used inside the recreational
vehicle. The use of this equipment inside the recreational
vehicle may cause fires or asphyxiation.
Do not store propane containers (except in the approved space
designed for it), gasoline or other flammable liquids inside the
camper. Fire or explosion may be the result.
All pilot lights, appliances, and their ignitors (see operating
instructions) shall be turned off before refueling of motor fuel.
Tanks and/or propane containers. Failure to comply could
result in death or serious injury.
If you smell gas:
Extinguish any open flames, pilot lights and all
smoking materials.
DO NOT touch electrical switches.
Shut off the gas supply at the tank valve(s) or gas
supply connection.
Open doors and other ventilating openings.
DO NOT use the range hood.
Leave the area until the odor clears.
Have the LP system checked and leakage source
corrected before using again.
Overfilling the propane container can result in
uncontrolled gas flow, which can cause fire or
explosion.
A properly filled container will contain
approximately 80% of its volume as liquid propane.
Overfilled Propane tanks must be bled. This is different
than purging the tanks. When the tanks are new, they must be
purged of the oxygen in the tanks used during the tank
manufacturer’s testing procedure prior to being filled with
propane. Overfilled tanks will emit liquid into the propane
system, which can cause problems/plugging with the regulator
used on the tanks, range, and generator. A bathroom scale can
be used to weigh the tanks prior to reinstalling them in the
camper. A 5-gallon tank should not weigh more than 35lbs.
when filled. A 7-gallon tank should not weigh more than
50lbs. when filled. Instructions for bleeding the tanks are
located on a label on the tank.
The following label has been placed in the vehicle near the
range area.
Carbon Monoxide Hazard
Your truck and your camper’s
generator exhaust contain
carbon monoxide gas. You
should have no problem with
carbon monoxide entering the
camper if you maintain your
truck and generator properly.
Have the exhaust system
inspected for leaks. Whenever
The truck and camper is serviced.
The truck or camper was in an accident that may
have damaged the underside.
Carbon monoxide is toxic.
Breathing it in can cause unconsciousness and Death.
Avoid any enclosed areas or activities that expose you to
carbon monoxide.
High levels of carbon monoxide can collect rapidly in
enclosed areas, such as a Truck Camper.
Fire Safety
Fire safety is an important part of owning a Camper. The
following basic rules of fire prevention can help eliminate the
possibility of a fire.
1) Never store flammable liquids inside the Camper.
2) Never leave cooking food unattended.
3) Never smoke in bed and always use an ashtray.
4) Never allow children to play with LP gas or electrical
equipment.
5) Never use an open flame as a flashlight.
6) Immediately repair or replace damaged wiring and
electrical components.
7) Never overload electrical circuits.
8) Locate any LP leaks and have them repaired
immediately.
9) Keep cooking surfaces clean and free from debris.
5
10) Don’t allow rubbish to accumulate.
11) Never clean with a flammable substance.
12) Spray fabrics annually with a flame retardant.
Be sure that everyone in your camper is familiar with the
location of all exits, including exit windows.
If you have a fire evacuate everyone from the camper
immediately.
Do not attempt to use water to put out a fire.
Water can spread some types of fire and electrocution is
possible. Get everyone outside, then decide if you should
attempt to extinguish the fire. If it is a large fire or a chemical
fire, DO NOT HESITATE! Leave the vehicle immediately
and call the fire department.
If you decide it is safe to fight a fire with an extinguisher:
TIP: Use the ‘PASS’ method. Familiarize yourself and all
occupants with this procedure;
Pull the pin (some extinguishers may have a cartridge
you need to push).
Aim the nozzle at the base of the fire.
Squeeze the handle to release the extinguishing
agent.
Spray the base of the fire. (If you aim at the flames,
you won’t extinguish the fire.)
Extinguishers are designed to put out a fire when in its’ initial
stage, not when it’s blazing out of control. If a fire cannot be
approached within 10 feet without risk of causing personal
harm, immediately evacuate the camper, and call 911.
Recreational Vehicle Serial Number, Decals, and Data
Plates
The recreational VIN, (vehicle identification number), label is
located above the license plate holder.
Important:
Always give
model, year and
the V.I.N. (vehicle
identification
number)
information when
ordering parts.
Also, we
recommend that you keep a copy of that information separate
from the Camper in the event of theft or vandalism. You may
be required to supply a copy of this information to the
authorities.
Information about This Manual
This Owner’s Manual is of a general nature only and does not
cover every aspect of all models manufactured by Nücamp
RV. Each owner should read this manual thoroughly and heed
the warnings given herein, as well as those warnings given in
the component instruction manuals contained in the Owner’s
Information Package.
Product Changes
The information contained within this manual is as accurate as
possible at time of printing and generally reflects features,
designs, specifications, and components available at that time.
Nücamp RV reserves the right to make changes to
specifications, features, designs, and components at any time
without any notification. All information printed within this
manual is subject to change after date of printing. Because of
continual product changes throughout the production year and
model year, and inadvertent transcription errors, this
information may not be the most current information available
at time of purchase. Information contained within this manual
may reflect both standard and optional features which may not
be included in your camper.
In the event, you are not the first owner of the vehicle, this
manual may not reflect alterations and options added by
previous owners.
Owner’s Info Package
The owner information package contains valuable documents
explaining details of operation for major appliances, systems
and equipment built into your camper. Included in this
package is warranty information on various appliances and
components in your camper. Warranty registration cards for
these items should be filled out and mailed as soon as possible
after you take delivery of your camper. Since this Owner’s
Manual does not cover every possible detail of equipment and
options installed on or in your camper, these booklets and
instructional material in the package will help you operate,
maintain, and trouble-shoot those items. If you are missing
any of the component material, contact your Nücamp RV
Dealer and request the desired or missing information.
This information should be considered a permanent part
of the camper, and should remain with the camper when it
is sold.
6
Identifying Your Camper and Its Components
For identification purposes, it is recommended that you write the camper serial number inside your camper. Pick a spot behind a
drawer or inside a cabinet. Protect yourself from possible theft and can identify your property. You should keep a copy of this
information at home. If the unit is ever stolen, the police can use the appliance serial number to identify the unit. It is also handy to
have when service is needed.
Please take a few minutes to complete the information. It will be a handy reference for you.
Your Name __________________________ Camper Model ___________________________
Serial Name __________________________ Purchase Date ___________________________
Dealer Name _________________________ Entry Door Key Number ___________________
Address ______________________________________________________________
Insurance Policy Number _________________ Agent’s Name __________________________
Agent’s Phone Number ____________________
Air Conditioner Range/Oven
Manufacturer ___________________________ Manufacturer ___________________
Model _________________________________ Model ________________________________
Serial Number __________________________ Serial Number __________________________
Furnace/Water Heater Refrigerator
Manufacturer – Alde Manufacturer – Norcold
Model _________________________________ Model ________________________________
Serial Number __________________________ Serial Number __________________________
Stereo/DVD Convection or Microwave Oven
Manufacturer __________________________ Manufacturer ___________________________
Model ________________________________ Model _________________________________
Serial Number __________________________ Serial Number __________________________
7
Camper and Truck, Weighing, Loading
Matching Camper and Truck
Selecting the right combination requires understanding a few
guidelines. Your Nücamp RV dealer can be a valuable source
of information when matching a camper to your truck.
The truck bed is mounted to the frame of the truck with
mounts that allow for some movement. It is important to allow
enough clearance between your truck and camper to prevent
damage due to normal racking, twisting and bouncing during
driving conditions. The cab-over of the camper should never
be closer than 1-1/2” to the tallest point of the cab of the truck.
This could be cab marker lights or tracking system antennas, if
installed. Also, ensure that there is a minimum of ¼” clearance
between the truck bed side rails and the camper wing. Some
truck models have a tapered bed, meaning the bed depth is
different between the front and rear. This can make the camper
look tilted (front higher than the rear) along the bed of the
truck.
It may be necessary to place a bed mat in the truck bed to raise
the camper to the minimum clearance requirements. There
must also be a minimum of ½” between where the truck and
camper meet at the back of the truck taillight. Adding a spacer
at the front of the camper or in the front of the truck bed can
help ensure proper clearance. Refer to your Nücamp RV
dealer for proper installation.
Federal Certification Label
Located inside the
wardrobe door. A
Federal
Certification Label
is required by law
on all Campers. It
lists the Gross
Vehicle Weight
Rating (GVWR),
the maximum
weight at which the vehicle may be operated. It also provides
a Gross Axle Weight Rating (GAWR), the maximum weight
allowed for each axle. The GAWR, divided by two, is the
maximum axle rating for each end of an axle.
Truck Payload
Truck ‘payload’ is the amount of weight a truck is designed to
carry. Campers are considered “truck payload”. New trucks
have their payload capacity posted in the glove box or on a
specification sheet supplied with the truck owner’s manual.
Trucks that have many options and/or a 4-wheel drive option
have less payload. To calculate payload, the truck
manufacturers assume all seat positions are filled with persons
weighing 150 pounds each.
Optional Weights
In addition to occupant weight, optional equipment and dealer
installed accessories will change the weight load. As well as
items, you purchased on your trip.
One way to determine the actual payload available is to weigh
the truck full of fuel and with the number of passengers you
will normally be carrying and subtract that weight from the
GVWR.
Tires
Tires are available in a variety of load ratings and sizes, and if
the tires you currently have cannot handle the load, it may be
possible to replace your tires with tires of higher pound
capacity. Bear in mind, that the ultimate capacity of the truck
is determined by the weakest link in the system. This could be
the tires, wheels, suspension, or brakes.
Be sure you also know the load and inflation pressure ratings
for your wheels as well. Often, these are stamped on the inside
of the wheels, but if not, your dealer can help you find out
what they are. Never exceed the maximum load or inflation
pressure of your wheels. The maximum ratings are molded
into the side of the tire. The sidewall of the tire shows
maximum and minimum inflation pressure for that load.
Driving on under-inflated tires can cause the tires to overheat,
which leads to the breakdown of the tire’s internal structure.
Improper inflation also can reduce your ability to control your
vehicle. Tire blowouts occur more during summer months
than any other time of the year. Properly inflated tires last
longer, run quieter, grip better, increase fuel mileage and
safely support and control your vehicle.
Check your tire pressure once a month and each time before
you take a trip with your truck and camper. Use a quality air
pressure gauge to check the pressure. Do not under-inflate or
over-inflate your tires. Inspect your tires for uneven or
excessive wear. Look for bulges, cuts, blisters on the
sidewalls.
When you’re traveling, do as professional commercial drivers
do: inspect your tires regularly and check and adjust cold
inflation pressure every day that you travel.
Individual wheel position weights must not exceed the
maximum tire load capacity. Maximum tire load capacity can
only be achieved utilizing the maximum allowable psi as listed
on the sidewall of the tire.
Axle Weight
The correct way to be sure the camper weight is properly
distributed is to determine the weight on each end of each
axle.
Failure to properly match the camper and truck can result in
undesirable handling characteristics and create a safety hazard.
DO NOT load your vehicle beyond its gross vehicle weight
rating (GVWR) and/or gross axle weight ratings (GAWR).
Weighing Your Truck & Camper
Weighing Your Truck
8
The truck must be weighed with all anticipated
occupants and full of fuel.
Drive onto the scales and note the weight of the total
truck.
Pull forward until the front axle is off the scale and
get the weight on the rear axle.
Subtract the weight on the rear axle from the total
truck weight to get the weight on the front axle.
Weighing Your Camper (Fully Loaded)
With the camper fully loaded with LP and water, (if
you intend to travel with water), pull onto the scales
as before and note the combined weight of the truck
and camper.
Pull forward until the front axle is off the scale and
get the weight on the rear axle.
Subtract the weight on the rear axle from the total
truck and camper weight to arrive at the weight on
the front axle.
Subtract the truck weight from the combined truck
and camper weight for each axle. This amount should
be less than the truck manufacturer’s GAWR, (Gross
Axle Weight Rating). If you are over the GAWR, you
will need to remove or shift weight accordingly.
Once the weight is less than the GAWR, you need to
weigh each individual wheel to ensure your camper is
evenly loaded on each side.
Again, pull on to the scales, but with only the right
front tire on the scales. Pull forward and note the
weight of the right rear tire. Do the same for the left
rear tire. Follow the same procedure for the front tire.
Take the GAWR of the rear axle and divide do the
same for the front. This is the GAWR for each axle
end.
Now subtract the individual wheel weights from the
individual GAWR for each wheel. If the amount is
less, you are within the GAWR for that axle end. If
the amount is more, you are over the GAWR for that
axle end and you will need to adjust how your
camper is loaded to bring the weight down within the
GAWR.
Look in your Yellow Pages under gravel pits, storage
companies or recycling facilities to find certified scales. Call
in advance to determine if they offer public weighing service,
their fees if any, and hours of operation.
NOTE: Cargo can be added to the vehicle up to the maximum
weight specified on the weight label. The combined weight of
the camper and its cargo cannot exceed the stated GVWR.
GVWR (Gross Vehicle Weight Rating) – the maximum
permissible weight of the fully loaded camper.
GAWR (Gross Axle Weight Rating) – the allowable weight,
including cargo that can be safely supported by each axle.
UVW (Unloaded Vehicle Weight) – the weight of the camper
as manufactured. If applicable, it also includes full generator
fluids including fuel, engine oil and coolants.
CCC (Cargo Carrying Capacity) – equal to GVWR minus
each of the following:
UVW
Full fresh water (potable water-used for drinking and
cooking) weight, full water heater and full LP gas
weight.
Weight Certification Label
The weight certification label indicates the gross axle weight
(GAWR). This is the most weight the fully loaded camper can
weigh.
Find Center of Gravity for Loading
Truck
manufacturers are also required to provide a ‘center of gravity
zone’ for camper loading. To determine if your truck/camper
combination is within the proper center of gravity limits, allow
these three steps:
Find the center of gravity for your type model.
Determine the recommended center of gravity zone
for your truck, as listed in your truck owner’s
manual. If you cannot find this information, contact
the nearest manufacturer’s representative for your
truck. The zone is normally measured from the rear
or back of the cargo area.
In a properly matched combination of truck and
camper, point ‘B’ (camper center of gravity) will fall
within points ‘C’ and ‘D’, (truck’s center of gravity
zone).
NOTE: Remember that installed options and the storage of
personal items will affect the listed center of gravity. Care
must be taken to properly balance the camper when loading
your personal items.
Camper’s become overloaded when people put too many
things into them. There is no easy way to determine the weight
you’ve loaded, so there’s a temptation to keep loading until
every available space is filled. People are loading by volume,
but weight is far more important. Unfortunately, you may have
exceeded to load-carrying capacity of the tires before
everything is on board. The only way to tell if your
truck/camper is overloaded is to weigh it fully loaded. The
most critical point about weighing a vehicle is that it must be
weighed with everything on board that will be there while
you’re traveling. That means you must weigh the truck/camper
with passengers, supplies, food, water, propane, and the truck
full of fuel. Bear in mind that water weighs 8.3 lbs. per gallon
9
and propane weighs 4.2 lbs. per gallon. Limiting your onboard water until you arrive at your destination will lower
your total weight. You must know the actual load on the axles
and wheels, and there’s no other way to do it other than on a
commercial scale.
In addition to knowing the total weight, it is crucial to know
the weight on each end of each axle. That’s the only way you
can find out if the load is both within the tire capacity, as well
as whether the load is properly distributed.
You should be able to find certified scales by looking in your
Yellow Pages for moving and storage companies, farm
suppliers, gravel pits, recycling companies or commercial
truck stops. Be sure to call in advance to determine whether
the facility offers public weighing services, their hours of
operation and any fees that might be involved.
Failure to properly match camper and truck can result in
undesirable handling characteristics and create a safety hazard.
In addition to knowing the overall weight that can be safely
loaded in or attached to the truck, you should know how to
distribute the weight in the camper so that correct amounts of
weight are placed on each truck axle. Proper weight
distribution is required for driving stability and will assure that
the truck/camper is not rear, front or side heavy. Heavy
weights placed at the rear end of the truck/camper may cause
undesirable handling characteristics.
When loading the camper, store heavy gear first, keeping it on
or close to the camper floor. Place heavy things far enough
forward to keep the loaded camper’s center of gravity within
the zone recommended by the truck manufacturer. Store only
light objects on high shelves. Distribute weight to obtain even
side-to-side balance of the loaded vehicle. Secure loose items
to prevent weight shifts that could affect the balance of your
vehicle.
Attaching Camper to/Removing from Truck
Swing-Out Brackets: (If equipped)
To load or unload campers on dual rear wheel trucks, special
brackets are installed on the front jacks to clear the fender. To
operate, follow the steps below:
1) Lift jack from the travel notch locked position and
swing outward from the camper body.
2) Position jack so when camper jack is lowered, the
notch and raised tab engage to prevent rotation.
3) Repeat the process for the other front mounted jack.
4) Follow the standard camper loading and removal
procedures below.
Loading/Removing Camper
Keep children and animals away from the area when raising or
lowering the camper. Avoid putting any part of your body
under the camper during the procedure.
Do not tilt the camper sideways while raising it on the jacks.
The jacks could buckle.
Always raise or lower the camper with the front either level or
higher than the back to avoid weight transfer and damage to
jacks or cargo.
Always load and unload camper on firm level ground.
Use caution when loading and unloading the camper on a
windy day. The amount of wind that is dangerous depends on
your exposure and the weight of the camper, etc.
Always keep
front higher
than rear.
Before loading
the camper
onto the truck,
be sure to
attach the tiedowns to the
truck.
1) Extend each jack no more than 4” at once. Starting
with the front jacks, keeping the camper level always.
Repeat this process until the camper clears the truck
body bed by approximately 4”.
2) Slowly back truck under camper making sure to clear
wheel wells and any structure or plumbing located
below the living area. This may take more than one
try.
3) Continue backing until the truck is within a foot of
loaded position. Stop and connect the 7-way power
cord to the 7-way receptacle in the truck bed.
4) Continue backing under the camper until the bumpers
mounted on the crossbar in the truck bed lightly
touch the front of the camper.
5) Slowly lower both rear jacks, then front jacks until
the camper is resting fully on the truck bed.
6) Raise the jacks and secure in place per the
manufacturer’s instructions.
7) Lift and swing front jacks inward (if equipped with
swing-out brackets).
8) Secure the camper to the truck with turnbuckles. The
front turnbuckles must be spring or shock loaded,
while the rear should use solid turnbuckles. Install
both the front and rear turnbuckles per
manufacturer’s instructions.
Safety Tips:
1) Never allow the camper to be occupied while it is
being loaded or unloaded.
2) Never raise the rear of the camper higher than the
front of the camper.
3) Be sure all tie-down devices and electrical devices
are disconnected from the vehicle.
4) Do not load the camper on a windy day. The amount
of wind that is dangerous depends upon your
exposure and the weight of the camper.
5) Only store your camper on level ground.
To Lower Camper:
Retract the rear jacks first so the camper is 4” lower
in the rear than in the front.
When the rear of the camper is lower than the front,
press and hold the ‘ALL JACKS’ button to retract the
jacks. Release the button when the camper is at the
desired height.
10
If the jacks continue to operate push the control
switch and the light will go out. The jacks should
disengage. If they continue to operate, unplug the
jack(s) from their exterior plug and contact your
Nücamp RV service center.
NOTE: When operating the jacks with a low 12V battery, the
‘all jacks’ extend and retract feature may not work. In that
case, use the individual jack buttons to operate the jack.
When operating the jacks by remote control, visually inspect
all four jacks to ensure that they are responding properly and
that you are following proper lifting or lowering camper
procedures.
DO NOT over-extend or over-retract the jacks. The electric
jack has an internal slip clutch to help prevent damage. If a
clicking sound is heard, release switch. Continuing to hold the
switch will cause undue wear on the slip clutch and/or cause
damage to the motor.
Removing Camper from Truck
1) Position the truck/camper combination on firm level
ground. If needed use 12” sq., ¾” plywood support
pads under each jack to prevent sinking into the
ground or asphalt.
2) Disconnect and/or remove the following items;
a) Front and rear turnbuckles
b) 7-way camper power cord
3) Using your remote control, operate all jacks together
until the camper clears the truck bed by 4”. If it is
necessary to operate the jacks individually starting
with the front jacks, extend the jacks no more than 4”
at a time. Keep the camper as level as possible.
Repeat the process until the camper has cleared the
truck bed by approximately 4”.
4) Slowly drive the truck from under the camper until it
clears the camper and the front overhang.
5) Lower the camper with the rear jacks first, the lower
the front jacks no more than 4” at a time.
Always lower camper back down close to ground level. Do
not use Homemade sawhorses, cinderblocks etc. to support the
camper in the raised position. Do not enter or occupy the
camper in a raised position.
Please see link below for recommended support systems. (For
long term storage)
http://www.torklift.com/index.php/products/truck-camperstorage-stability/camper-packer
Your camper is designed to be used while standing on the
jacks in a lowered position without damage to the camper.
When lowering camper, do not allow camper bumper to touch
the ground. Damage may occur. Allow two inches of
clearance to the ground.
Electric Jacks
Electric jacks need 12-volt automotive battery power to
operate. The camper battery must be charged and in good
condition. If the battery is too low to operate the jacks, charge
the battery before using jacks. If the camper is on the truck,
starting the truck’s engine will supply power to the jacks if the
7-way electrical power cord is connected. If no power is
available or battery power is to low switch the power “OFF”
to the receiver. This will eliminate the dynamic braking effect
of the motor. Remove the access cap on the top of the
powerhead. The crank shaft of the gearbox will be accessible
to turn with a 3/8” ratchet wrench. Rotate the wrench counterclockwise to raise the jack and clockwise to lower the jack. Do
not activate the motor with the wrench still on the crank shaft.
Do not use the electric jacks to raise or lower the camper using
only 120-volt power. The converter’s charger will be damaged
if the jacks are operated with 120-volt power through the 12volt converter without a 12-volt battery installed in the
camper.
Before operating the remote control electric camper jacks, be
sure to read and understand the operating instructions that
were provided with your camper pertaining to their safe
operation.
Jack Remote Control
There are two remotes for the jacks, if the remote battery dies
simply plug it into the remote cable port on the activation
switch panel with provided cable, if the black remote doesn’t
there is a backup remote on the jack fuse panel.
The hand held remote control operates on radio frequency,
which is like remote units for garage door openers. The remote
is powered by a battery located under the removable cover on
the back of the remote unit. The remote has a range of up to 20
feet from the camper. Occasional frequency interference from
other nearby remote control devices may occur. This will only
result in momentary pauses during the extend or retract
operation.
11
NOTE: Keep a spare battery available for your remote control
for best wireless performance, it is recommended that you
install a new battery in the remote at the beginning of each
season (1 per year) the battery is # A-23 12 volt Alkaline.
The frequency of your remote-control unit has been pre-set by
the manufacturer. If interference problems routinely occur,
refer to the manufacturer’s instructions in your owner’s packet
to change the frequency.
When controlling the jacks, the following operations are
possible.
Extension or retraction of an individual jack.
Extension or retraction of all 4 jacks.
Paired operation – adjacent jacks can be operated
simultaneously by holding down two jack buttons.
The base receiver for your remote jacks is in door #2 in photo
below.
The receiver uses 12-30 amp fuses that
protect each of the jack circuits. If any of
the jacks do not operate while depressing
the “All Jacks” button on the remote,
check the fuses.
Jack Fuse Panel Location
This panel is located inside storage door #2
To
Lift
Camper: (Extend jacks to ground)
1) First you must turn on the activation switch located
on the cabinet inside the entry door.
2) Press and hold the ‘All Jacks’ extend button. All four
jacks will simultaneously extend until they touch the
ground. Release the button. NOTE: If the jacks do
not extend equally, (jacks can extend unevenly due to
the distance each jack is located from the 12-volt
source), the front jacks lift the heaviest load, and
consequently will raise slower than the rear jacks
conversely, the front jacks will lower faster than the
rear jacks. Extend the front jacks so the camper is 4”
higher in the front than in the rear. Once the camper
front is higher than the rear, press and hold the ‘All
Jacks’ button. Release the button when the camper is
at the desired height. Make sure the front of the
camper stays higher than the rear and is level (side to
side).
3) Use the individual jack buttons to adjust an
individual jack. Press and hold the Extend or Retract
buttons for the individual jacks as needed to keep the
front of the camper 4” higher than the rear, and to
prevent overloading the front jacks. Keep all corners
within 4” of level with each other.
DO NOT use homemade sawhorses, cinder blocks, etc. to
support the camper in the raised position.
DO NOT enter or occupy the camper in a raised position.
To Lower Camper:
1) Retract rear jacks first so the camper is 4” lower in
the rear than in the front. Once the camper rear is
lower than the front, press and hold the ‘All Jacks’
button and retract. Release the button when the
camper is at the desired height.
2) Use the individual jack buttons to adjust an
individual jack. Keep all corners within 4” of level
with each other. If the jacks keep running, push the
control switch and the light will go out. This should
shut off the jacks. If they continue to run, unplug the
jack(s) from their exterior plug and contact your
Nücamp RV service center.
NOTE: When operating the jacks with a low 12-volt battery,
the ‘All Jacks’ extend and retract feature may not work. In that
case, use the individual jack buttons to operate the jacks.
When operating the jacks by remote control, visually inspect
all four jacks to ensure that they are responding properly and
that you are following proper lifting or lowering camper
procedures.
Do not over-extend or over-retract jacks. The electric jack has
an internal slip clutch to help prevent damage; when clicking,
sound is heard, release switch. Continuing to hold the switch
will wear out the slip clutch or cause damage to the motor.
If the jack fails to operate, check these items:
Be certain that the battery in the remote-control unit
is fresh. Keep spare batteries available.
The control switch light located next to the entry
must be on.
You are within range for the remote to operate.
Adequate 12-volt battery power is still available.
The jack electrical cord is securely plugged into the
exterior socket.
Hold the remote vertically (keypad facing you) and
have it between the camper and you.
If other radio frequencies devices are making the jack
pause, lift your finger from the button and press the
button again.
If the jacks still fail to operate, consult your Nücamp RV
service center for more information and help.
Swing-Out Brackets: (If equipped)
To load or unload campers on dual rear wheel trucks, swingout brackets are installed on the front jacks to clear the fender.
To operate, follow the steps below:
1) Lift jack from the travel notch locked position and
swing outward from the camper body.
12
2) Position jack so when camper jack is lowered, the
notch and raised tab engage to prevent rotation.
3) Repeat the process for the other front mounted jack.
4) Follow the standard camper loading and removal
procedures below.
Leveling/Stabilizing Jacks
Prior to lowering the jacks, try and park on a flat level spot
whenever possible; certainly, never on a steep slope. If it is not
possible to move to a more level location, use wood blocks
under the truck tires to assist in leveling. Be sure that the block
is larger than the “footprint” of the tire.
No part of the tire should ever “hang over” the edge of the
block. This includes trucks with dual rear tires. This can cause
internal damage to the tire. Being level is necessary for
comfort, but it is also required for correct operation of your
refrigerator. The jacks should only be used to stabilize the
camper when attached to the truck.
NOTE: Attempting to level your camper and truck using the
jacks can overload your jacks and cause damage to the jacks,
your camper, and tie-down system.
NOTE: If you are unsure of the process, please consult your
Nücamp RV dealer.
Support Equipment
Air Bags
Adding air bags can improve vehicle ride, safety, in handling,
and load hauling. Air bags are used to maintain proper weight
distribution to all the tires to improve steering, braking and tire
wear. Air bags increase spring rate and improve your truck
and camper stability. Air bags are used to raise your loaded
truck back to the normal ride height. A level, balanced vehicle
handles better and provides a safer, more comfortable ride.
Heavy Duty Shocks
An adjustable shock absorber can significantly increase ride
performance in all types of driving conditions, on and offroad.
Tie downs and Turnbuckles
This photo shows the
tie down anchor
point there are two
on each side of the
camper
Check Tie down
anchor bolts for
tightness before each
trip and tighten as
needed.
The camper must be secured to the truck with high quality tied
downs and turnbuckles. The turnbuckles must be spring or
shock loaded.
Turnbuckle Installation
Torklift Fast Gun turn buckle installation video link below.
https://www.youtube.com/watch?v=Ps1AF1Lltrk
Hitching and Towing Systems
A Torklift hitch system is recommended for use when towing
with your truck and Nücamp RV camper. The Super Hitch
Receiver, along with a custom designed bar extension for
campers over 8’ are available from authorized Torklift
Dealers. It can be used with a standard weight carrying ball
mount, or for added capacity, a weight distributing hitch bar
and ball mount.
Qualified personnel should install hitch systems only. Towing
will change the handling and braking characteristics of your
truck/camper package. Do not tow from or attach a hitch bar
or ball to the camper bumper.
Below are two links with the recommended hitch systems if
you desire to use it to tow a trailer.
http://www.torklift.com/index.php/products/towing/superhitch
-receiver-hitches
http://www.torklift.com/index.php/products/towing/superhitch
-supertruss
The Super Hitch
The Super Truss
13
Effects of Prolonged Occupancy
Condensation & Humidity
Your camper was designed primarily for recreational use and
short-term occupancy. If you expect to occupy the camper for
an extended period, be prepared to deal with condensation and
the humid conditions that may be encountered.
The relatively small volume of space and air tight construction
of a modern recreational vehicle means that the normal living
activities of even a few occupants will lead to rapid moisture
saturation of the air contained in the camper and the
appearance of visible moisture, especially in cold weather.
Just as moisture collects on the outside of a glass of cold water
during humid weather, moisture can condense on the inside
surfaces of your camper during use in cold weather when the
relative humidity of interior air is high. This condition is
increased because the insulated walls of the camper are much
thinner than house walls.
Studies indicate that a family of four can vaporize up to three
gallons of water daily, through breathing, cooking, bathing,
and washing. Unless this water vapor is carried outside by
ventilation, or condensed by a dehumidifier, it will condense
on the inside of the windows and walls as moisture, or in cold
weather as frost or ice. The moisture may also condense out of
sight within the walls or the ceiling where it will manifest
itself as warped or stained panels.
Appearance of these conditions may indicate a serious
condensation problem. When you recognize the signs of
excessive moisture and condensation in your camper, you
should act to minimize their effects. DO NOT ignore this
issue. Doing so could result in damage to your camper due to
neglect, and could void or decrease your warranty.
NOTE: Your camper is not designed to be used as permanent
housing. Use of this product for long term or permanent
occupancy may lead to premature deterioration of the
structure, interior finishes, fabrics, carpeting and drapes.
Damage or deterioration due to long-term occupancy may not
be considered normal, and may under the terms of the
warranty constitute misuse, abuse, or neglect, and may
therefore reduce your warranty protection.
Tips to Help Control Humidity in Your Camper:
1) Keep indoor humidity low, if possible below 60%.
(Ideally between 30 and 50%) relative humidity.
Relative humidity can be measured with a moisture
or humidity meter. The meter is inexpensive ($10$50) instrument available at most hardware stores.
Some larger campground stores may also have the
meters.
2) Consider using a small dehumidifier to help rid the
unit of moisture.
3) Avoid hanging wet clothing to dry inside your
camper.
4) When showering or bathing, open the roof vents or
turn on a fan to allow steam and moisture to escape.
Dry the shower walls to prevent water evaporation
into the camper.
5) Be sure no vents are obstructed and that all vents are
properly sealed. Pay attention to appliances that
produce moisture, such as air conditioners, showers,
oven.
6) Consider using the microwave oven instead of the
stovetop to boil water or soups for long periods. If
you choose to use the stove to boil water or soup,
open a window or a vent slightly, (even in cold
weather), to provide a passage for airflow. This will
help restrict the humidity inside your camper.
7) Recirculate the air by using vent fans or small
oscillating fans. If condensation occurs, keep the
windows clean to prevent growth of mold and
mildew.
NOTE: If you have water and/or mold damage caused by
sewage or other contaminated water, it is best to call in a
professional who has experience cleaning living spaces
damaged by contaminated water.
If you have health concerns, consider consulting a health
professional before beginning mold clean up.
Ventilation & Moisture Control
You can reduce interior moisture condensation by taking the
following steps:
Ventilate with outside air. Partially open one or more roof
vents and one or more windows to provide circulation of
outside air into the interior. While this ventilation may
increase furnace-heating load during cold weather, it will
greatly reduce water condensation. Even when it is raining or
snowing, ventilation air from outside will be far drier than
interior air and will effectively reduce condensation inside the
camper.
Minimize moisture release inside the camper. Run the bath
vent fan (or open the bath vent) when bathing to carry water
vapor out of the camper. Avoid making steam from excessive
boiling or use of hot water. Remove water or snow from shoes
before entering to avoid soaking the floor. Avoid drying
overcoats or other clothes inside the camper.
DO NOT HEAT THE CAMPER INTERIOR WITH THE
RANGE OR OVEN!!
In addition to the hazards of toxic fumes and oxygen
depletion, open flames add moisture to the interior air,
increasing condensation. Do not use an air humidifier inside
the camper. Water put into the air by the humidifier will
greatly increase condensation.
Ventilate closets and cabinets. During prolonged use in very
cold weather, leave cabinets and closet doors partially open to
warm and ventilate the interior of storage compartments built
against exterior walls. The airflow will warm the exterior wall
surface, reducing, or eliminating condensation and minimizing
possible ice formation.
Install a dehumidifier. During prolonged, continuous use, a
dehumidifying appliance may be more comfortable and
effective in removing excess moisture from the interior air.
14
While use of a dehumidifier is not a “cure-all”, ventilation,
and moisture reduction continue to be important, operation of
the dehumidifier will reduce the amount of outside air needed
for ventilation. Heating load on the furnace will be reduced,
and the interior will be less drafty.
Dripping Ceilings Vents
During cold weather and even in short term occupancy,
condensation frequently forms on ceiling vents and may even
accumulate to the point of dripping onto the surfaces below.
This is frequently misinterpreted as a “leaking” roof vent but
is most often condensation drippage.
Interior Odor
New units may have a strong odor and even cause eye and
lung irritation when closed in hot weather. This is due to glues
used in production of forest products (plywood, paneling,
etc.). This condition passes with time, but in an extreme
condition, open the door, windows, and vents to allow the
interior to “air out” for several hours.
Fire and Safety
The hazard and possibility of fire exists in all areas of life, and
the recreational lifestyle is no exception. Your camper is a
complex device made up of many materials – some of them
flammable. But like most hazards, the possibility of fire can be
virtually eliminated by recognizing the danger and practicing
common sense safety and maintenance habits.
Recreational vehicle fires are generally caused by unattended
food cooking on the stove or in the oven, faulty or damaged
wiring and electrical devices, fuel leaks (both gasoline and
propane), or carelessness. The most common careless acts
include smoking in bed, leaving children unattended and
cleaning with flammable liquids.
Consider These Fire Safety Suggestions:
Before refueling your truck or any fuel tank near your camper,
be sure to turn off all pilots and appliances in your camper.
Consider the cause and severity of the fire and the risk
involved before trying to put it out. If the fire is major or is fed
by gasoline, propane, or any type of oil product, stand clear of
the vehicle, and wait for the fire department or other
emergency assistance.
If fire damages your camper, do not use it until it has been
thoroughly examined and the cause of the fire is found and
fixed.
All occupants of the camper should become familiar with the
audible sound of the smoke, propane leak and
CO detectors. If an alarm sounds, investigate the cause. Do not
remove the detector to silence the alarm.
Teach everyone in the camper how to use the entry door
locking system and emergency exits. Occasionally open the
emergency exit to prevent the seal from sticking. Always keep
the dead bolt on the entry door in working condition.
Fire Extinguishers
The fire extinguisher in your camper is located near the main
entry door. Your fire extinguisher should be replaced
immediately after use or discharge.
The fire extinguisher
furnished with your
camper is rated for
Class B (gasoline,
grease, flammable
liquids) and Class C
(electrical) fires since
these are the most
common types of fires
in recreational vehicles. Read the instructions on the fire
extinguisher. Know how and when to use it. You and your
family should be familiar with its operation. If you find it
necessary to use the fire extinguisher, stand 45 degrees from
the flame and spray side to side, starting at the top of the
flame. Use caution to avoid standing upwind or uphill. If
flames are climbing, spray vertical and work the retardant
downwards. Dry chemical flame retardant should be cleaned
away as soon as possible.
If you decide it is safe to fight a fire with an extinguisher
TIP: Use the ‘PASS’ method. Familiarize yourself and all
occupants with this procedure;
Pull the pin (some extinguishers may have a cartridge
you need to push).
Aim the nozzle at the base of the fire.
Squeeze the handle to release the extinguishing
agent.
Spray the base of the fire. (If you aim at the flames,
you won’t extinguish the fire.)
Avoid inhaling the dry chemicals from the fire extinguisher.
Although non-toxic, they could cause temporary irritation.
When the fire is out, clean the area as soon as possible. The
dry chemical may cause surface damage if left too long.
DO NOT use water to extinguish a fire.
Water can spread some types of fire and electrocution is
possible.
Smoke Detector
Most fire casualties are caused by inhalation of toxic fumes
(smoke) from a fire and not by flame. The smoke detector
responds to smoke that enters the sensing chamber. It does not
sense gas, heat, or flame. A ceiling mounted, battery powered
smoke detector is in the living /cooking area of your camper.
Please read the smoke detector Owner’s Manual for details on
testing and caring for this important
safety device.
Smoke detectors may not have time to
alarm before the fire causes damage,
injury or even death.
A smoke detector works only for
detecting smoke, not fire. The alarm will
sound only if smoke reaches the sensor.
15
This unit will not alert hearing-impaired residents. (Special
alarms with flashing strobe lights are needed for the hearing
impaired.)
Smoke detectors have a limited life and are not foolproof.
Never attempt to repair this unit. Replace the complete unit if
faulty.
Test the smoke detector after the camper has been in storage,
before each trip, and at least once a week during use.
The smoke detector should never be disabled due to nuisance
or false alarm from cooking smoke, a dusty furnace, etc.
Ventilate your camper with fresh air and the alarm will turn
off. Do not disconnect the battery.
Replace the battery once a year or immediately when the low
battery “beep” signal sounds once a minute. The detector uses
a standard 9-volt battery.
Test smoke detector operation after replacing the battery. If
the smoke detector fails to operate with a new battery, replace
the detector with a new unit.
Carbon Monoxide Gas Safety Precautions
Carbon monoxide gas is colorless, tasteless, and odorless. It is
a combustion by-product of fuel burning engines. The engines
in your truck and generator system (if installed) produce it
constantly while they are operating.
Carbon monoxide gas is deadly. Please read and understand
the following warnings and precautions to protect yourself and
others from the effect of carbon monoxide gas.
Exhaust gases are deadly. DO NOT block the tailpipes or
situate the vehicle in a place where the exhaust gases have any
possibility of accumulating either outside, underneath, or
inside your vehicle of any nearby vehicles.
Outside air movement can carry exhaust gases inside the
vehicle through windows or other openings remote from the
exhaust outlets.
Operate the engine(s) only when safe dispersion of exhaust
gases can be assured, and monitor outside conditions to be
sure that exhaust continues to be dispersed safely.
DO NOT under any circumstances operate any engine/s while
sleeping. Be aware of exhaust gas (carbon monoxide)
poisoning symptoms:
Dizziness
Headache
Weakness and Sleepiness
Nausea
Vomiting
Muscular twitching
Throbbing in temples
Inability to think coherently
If symptoms indicate the possibility of monoxide gas
poisoning:
Turn off engine(s) immediately
Get out into fresh air at once
Summon medical assistance
Check the exhaust systems during routine maintenance and
repair leaks, damages, or obstruction before further operations.
DO NOT modify any exhaust system in any way.
Never disconnect the battery to silence the alarm.
Carbon Monoxide & Propane Detectors
A permanently installed
detector is located near the
floor in the forward
portion of the main
camper floor area. The
unit contains an alarm that
will sound, alerting you to
the presence of propane or carbon monoxide.
To reduce the risk of carbon monoxide poisoning or propane
gas explosion, test this alarm’s operation after the camper has
been in storage, before each trip and at least once per week
during use.
Do not use a cigarette lighter to test the CO/Propane gas
alarm. Butane gas may damage the sensors.
DO NOT attempt to test the alarm by any other means than by
using the TEST/RESET button. DO NOT attempt to produce
CO to the alarm. The TEST/ RESET button tests all functions
of the alarm and is the ONLY safe way to be sure the alarm is
working properly.
The alarm may be tested at any time. The TEST/Mute switch
is located on the front of the alarm. Press and hold the test
button for 1 second. The alarm is working properly if the
GREEN indicator light changes color to RED and the alarm
beeps 4 times. The Gas LED should also blink Red.
Operation
When the unit is first powered up, the CO sensor requires a ten
(10) minute initial warm-up period to clean the sensor element
and achieve stabilization. The GREEN LED indicator will
flash on and off during the 10-minute warm-up period. This
unit cannot go into a CO alarm during the warm-up period.
After the warm-up period, the GREEN power ON indicator
should glow continuously. If the ON indicator light does not
16
light see the section, “Trouble-Shooting Guide” in the User’s
Manual for this alarm provided in the Owner’s Information
Package.
This alarm will operate normally down to 7-volt DC. It will
not work without power.
CO Alarm
The red CO LED will flash and the alarm will sound 4
“BEEPS” then silent for 5 seconds. These signals indicate that
the CO level is over 70 ppm. IMMEDIATE ACTION IS
REQUIRED. This cycle will continue until the TEST/Mute
button on the front of the alarm is pressed. Ventilate the
Camper. The red light will stay on until the CO has cleared, or
the alarm will reactivate in approximately 6 minutes if the CO
is still present. DO NOT RE-ENTER THE CAMPER. This
alarm will return to normal operation after the Camper’s
properly ventilated.
The CO (Carbon Monoxide) detector is designed to detect
carbon monoxide from any source of combustion. It is NOT
designed to detect smoke, fire, or any other gases.
Procedures to Take During a CO Alarm:
Actuation of this device indicates the presence of the carbon
monoxide (CO) or propane gases, can cause death. If signal
sounds (4 beeps and flashing or solid red light), immediately
turn off all combustion sources and ventilate the premises.
Evacuate the premises immediately. Check that all persons are
accounted for. Do not re-enter the camper until it has been
aired out and the problem corrected. Get the system checked
before restarting appliances.
Carbon monoxide cannot be seen or smelled and Breathing it
in can cause unconsciousness or death.
Propane Gas Alarm
The Red LED will flash and the alarm will sound a steady
tone whenever a dangerous level of propane or methane gas is
detected. IMMEDIATE ACTION IS REQUIRED. The
detector will continue to alarm until the Test/Mute switch on
the front of the alarm is pressed. Ventilate the Camper. The
RED Gas LED will continue to flash until the gas is cleared,
or the gas alarm will reactivate in approximately 5 minutes if
the gas is still present. DO NOT RE-ENTER THE CAMPER.
This alarm will return to normal operation after the Camper is
properly ventilated.
NOTE: This detector senses propane gas in the air, not smoke
or fire or other gases. It detects the presence of propane gas at
the sensor; explosive gas may be present in other areas.
DO NOT attempt to repair the detector. If it fails the test,
check the battery voltage and if it still does not function
properly, replace the entire unit.
Procedures to Take During a Gas Alarm
Turn the propane off at the tank(s), turn off all propane
appliances, extinguish all flames and smoking material and
open all doors and major windows to air out the camper. Do
not re-enter the camper until the alarm stops sounding. If the
alarm sounds a second time after the propane is turned back
on, leave the propane off and have a Nücamp RV Service
Center make the necessary repairs to the source of the propane
leak.
Be aware of the difference between a propane leak versus
propane escaping from an unlit, open burner. Pure propane
from a leaking pipe or fitting is heavier than air and will build
up its heaviest concentration at the floor level first. Propane
from open burners is intentionally mixed with air to induce
burning and will dissipate into the air. The primary purpose of
the detector is to detect propane leaks. The propane from open
burners is mixed with air (oxygen) so that it will burn. When
mixed with air, the propane becomes only marginally heavier
than air and may not sink to the floor. If a burner is left on, the
area around the burner, range and adjoining counter space will
be combustible and will cause injury and damage if ignited.
This condition may exist for an extended period before the
propane can reach the detector’s location and be detected. The
detector only indicates the presence of propane at the sensor.
Propane may be present in other areas.
The detector is powered by the 12-volt DC system and is
always powered if the camper is connected to the truck, a
charged battery, or 120-volt AC power. The fuse for the
detector is in the Power Distribution Center.
NOTE: The detector is continuously powered; disconnect the
battery if you are not using your camper. The detector can
evidentially drain the camper battery.
Backup Camera
The backup camera (optional) is located beside roof ladder on
the rear wall, it is a color camera with a built-in microphone.
Switch location is below the wardrobe door right inside the
entry door, it's a double toggle switch with the one on the right
being the camera switch. The portable monitor that will be in
the truck cab has a 12-volt power plug and a built-in receiver.
Electrical System
The electrical system consists of a primary 12-volt DC system
and a 120-volt AC system. The 12-volt system uses battery
power like that used in automobiles. The 120-volt system
requires a source of 120-volt power provided through the
power supply cord or optional generator. These systems are
17
connected through a power converter. When connected to 120volt power, the converter transforms 120-volt AC input into
12-volt DC power output and charges the storage battery(s)
when installed.
Interior Lighting
The interior lighting operates on 12-volt DC power only.
When connected to a 120-volt source or using the generator,
the power converter transforms 120-volts to 12-volts.
However; when not connected to 120-volts, the entire load of
lights, water pump, exhaust fans, etc., is on your 12-volt
battery(s). Use conservatively to minimize battery
discharging.
120-volt AC System
The 120-volt electrical system supplies power to the following
components:
AC to DC Power Converter
120-volt Outlets (interior and exterior)
Refrigerator
Roof Mounted Air Conditioner (optional)
Microwave Oven
Alde System
Never operate the 120-volt electrical system without
a proper ground.
12-volt DC system
The 12-volt system provides power for the following
components:
Electric Jacks
Interior Lighting
Exterior Lighting
Water Pump
Refrigerator
Alde System
Stereo/CD/DVD Player
TV
Systems Panel Monitor
Fantastic Fan
Accessories plugged into 12-volt outlet
Battery and Compartment
Maintenance of your 12-volt battery(s) is essential for carefree
travel. Be sure to use a heavy-duty, minimum 75 amp/hr.
RV/Marine deep cycle battery. Ensure that they are both the
same size and type battery. Check the battery’s frequently
with the condition meter located on the monitor panel. Also,
check the water level often. The use of a hydrometer is
required to test for the specific gravity of the battery acid.
Hydrometers are available through an auto parts store.
NOTE: The 12-volt battery(s) is not supplied with the camper
by the manufacturer.
Battery Terminology
Deep Cycle Batteries
The term “deep cycle” refers to a battery that has the
capability of deeply discharging hundreds of times.
How it differs from an automotive starting battery is that the
automotive battery is manufactured to specifically provide a
quick burst of energy thousands of times while only being able
to deeply discharge less than 50 cycles during its lifetime. A
Cycle refers to one batter discharge and recharge.
Battery Ratings and Specifications
Marine/RV deep cycle batteries have rating specifications
which include cold cranking amps (CCA), marine cranking
amps (MCA), reserve capacity (RC), and ampere hours (Ah).
RC and approximate Ah ratings may not be listed on the
battery decal. However, they should be available through your
local battery distributor.
Cold Cranking Amps (CCA)
The amount of current (amps) a battery at 0°F (-17.8°C) can
deliver for 30 seconds and maintain at least 1.2 volts per cell
(7.2 volts on a 12-volt battery).
Marine Cranking Amps (MCA)
The amount of discharge current a battery tested at 32°F (0°C)
can deliver for 30 seconds and maintain at least 1.2 per cell
(7.2 volts for a 12-volt battery).
Reserve Capacity (RC)
The amount of time a battery can deliver 25 amps at 80°F
(26.7°C) without falling below 1.75 volts per cell (10.5 volts
on a 12-volt battery). An approximate Ah rating can be
attained by multiplying the battery’s RC rating by 0.6.
Example: 180 RC x 0.6 = 108 Ah.
Ampere hours (Ah)
Tested at 80°F (26.7°C). It is the amount of current (in amps)
a battery can deliver, multiplied by the number of hours,
without falling below 1.75 volts per cell (10.5 volts in a 12volt battery). Most marine/RV deep cycle batteries are rated
on a 20-hour discharging rate. Example: a 100 Ah battery can
deliver 5 amps for 20 hours (amps x hours = Ah). The Ah
rating is important when determining the type and amount of
battery(s) required to meet your specific component needs.
Battery Information
The battery(s) must be securely strapped in the compartment
always.
The battery(s) is charged by the truck’s charging system while
the truck is running or when connected to 120-volt power
through the power converter. If equipped, the onboard
18
generator charges the battery while running through the power
converter.
Check that the battery liquid level is correct (weekly in warm
climate, monthly in cold climate). Using protective gloves,
take the caps off the battery. Look for a ‘fill line’ inside the
battery wall. If the fluid is below the line, add distilled water
as required. Remember to also check the condition of your
truck battery.
Clean battery terminals and cable periodically using a wire
brush and baking soda. Be sure the caps are securely in place
when cleaning. Be sure the wing nuts on top of the battery are
tight. Loose wing nuts can cause arching and intermittent, or
loss of, 12-volt power. Use caution not to touch battery
terminals to metal door frame when removing or installing the
battery. Always disconnect the negative (-) cable first and
reconnect it last.
Remove rings, metal watchbands, and other metal jewelry
before working around a battery. Use caution when using
metal tools. If the tool contacts the battery terminals or metal
connected to them, a short circuit could occur which could
cause personal injury or fire.
DO NOT allow battery electrolyte to contact skin, eyes,
fabrics, or painted surfaces. The electrolyte is a sulfuric acid
solution that could cause serious personal injury or property
damage. Wear eye protection when working with batteries.
Battery Storage Precautions
When you store your camper for a week or more be sure to
disconnect the battery(s). Electronic tuning radios, the propane
detector, and the CO detector all draw a small amount of
current when the battery is connected. Even disconnected
batteries will naturally “self-discharge” about 1 % of capacity
per day. If you intend to store your camper for any length of
time, remove the battery(s). Store it in a cool, dry place and
recharge every month. Batteries will discharge on their own.
Recharging will also help prevent problems with battery
sulfating which leads to premature battery failure.
Battery Charging
Normally the battery(s) will be kept charged by either the
truck charging system while on the road, solar panel, or by the
AC/DC power converter when plugged into AC service. On
those occasions when the battery needs to be charged from a
different charging source, please follow these safety
guidelines:
Disconnect both cables to prevent damage to the
camper’s electrical system
DO NOT smoke near batteries that are being charged
or which have recently been charged. Please note that
batteries are being charged while you drive, and
while you are connected to 120-volt AC power
through the power converter/charging circuit.
Use care when connecting or disconnecting booster
leads or cables while charging. Poor connections are
a common cause of electrical arcs that can cause
explosions.
Check and adjust the electrolyte level before
charging. Fill each cell to the indicator level with
distilled water. Always remove the vent caps (if
equipped) before charging the battery.
Never expose the battery to open flame or electric
spark. Chemical action in the battery generates
hydrogen gas that is flammable and explosive.
To avoid sparks, turn off all electrical components
before connecting the battery cables. Connect the
black or red to the positive (+) post on the battery.
Connect the white cable to the negative (-) post.
NOTE: This is different than the automotive industry which
uses red and black. There are fuses on the front of the power
converter that will protect the camper’s electrical system if
you accidentally connect the battery in reverse.
The 40-amp main circuit fuse will not allow power into the
camper or the battery(s) to be charged when an overload or
short circuit occurs. To reset replace the 40-amp fuse, If the
fuse continues to burn out, a short circuit or overload
condition is indicated. Have the system checked by qualified
personnel.
Battery Disconnect Switch
While in storage
use, the battery disconnect switch to help with slowing down
the discharging of the battery.
System Monitor Panel
The systems
monitor panel may
incorporate controls
and instrumentation
for the water and
holding tank levels,
battery voltage
level, water pump
switch.
Monitor Panel –
Level Indicator Switch
When depressing the monitor switch, indicator lights for the
black (waste), grey (sink and shower), and fresh water, (for
drinking and cooking) tank will illuminate, indicating the
existing condition of each component. The battery level is a
digital display that reflects the battery voltage when the switch
is depressed.
19
Water Pump Control Switch
This rocker switch controls the demand water pump. The
water pump is
pressure sensitive
and starts (with the
switch ON) when
a faucet is open,
causing pressure
in the line to drop.
When the faucet is
closed, pressure
builds in the line
and the pump
stops.
Erroneous indications when checking water levels can be
caused by:
Water with low mineral content. Level is measured
by a very low electrical signal traveling through the
liquid. Some water that is low in mineral content may
not conduct the signal properly. This condition may
be infrequent, but can exist. Check the panel reading
when the fresh water tank is filled. Material trapped
on the sides of the holding tanks may give a full
reading when the tank is empty. Use of a cleaner to
wash out the tank following dumping should help
prevent this condition.
Camper Fuse Panel (12-volt Interior Circuits)
A 12-volt
interior fuse
panel is
installed below
the fridge in the
Power
Distribution
Center to
protect the
interior circuits.
Circuit titles and fuse sizes are all marked inside the
removable access door. If a fuse blows, locate, and correct the
cause. Turn off all lights and motors, and then install a fuse
with the same rating. If fuses continue to blow, a short circuit
is indicated. Have the system checked by your Nücamp RV
Dealer.
Fuses
All the electrical circuits in your camper have fuses to protect
them from short or overload. If something electrical in your
camper stops working, the first thing you should check is for a
blown fuse. Determine from the diagram on the fuse panel,
which fuse or fuses control that component. Check those fuses
first, but check all fuses before deciding that a blown fuse is
not the cause. Replace any fuses and check the component’s
operation.
Do not install fuses with amperage ratings greater than that
specified on the label. (Unless you Notify Nücamp RV and
they indicate it’s safe to do so) Replacing a fuse with one that
has a higher rating greatly increases the chances of damaging
the electrical system. If you do not have a replacement fuse
with the proper rating for the circuit, install one with a lower
rating until you can replace it with the proper rated fuse.
If the replacement fuse of the same rating blows in a short
time. Leave the blown fuse in that circuit and have your
camper checked by your Nücamp RV Dealer.
Solar Panel
The solar panel plugs into the solar ready connector. The solar
panel is designed to “trickle charge” your battery system. It is
not intended to be a fast charger. It also cannot supply large
amounts of current to operate 12-volt DC electrical equipment.
NOTE: Weather conditions will affect the charging rate of the
solar panel. Refer to the solar panel manual supplied in your
Solar Information Package.
120-volt Power Cord
Your camper is equipped with a heavy-duty power cord for
connection to an external 120-volt, 30 amps rated service. The
cord is commonly called the “shore cord”. The cord and plug
are molded together to form a weatherproof assembly. DO
NOT cut or alter the cord in any way. DO NOT remove the
ground pin from the attachment plug. If you must use an
adapter to plug into an electrical service, make sure the ground
is maintained.
Never use a two-conductor extension cord, or any cord that
does not assure appropriate and adequate ground continuity.
Use a 30-amp RV extension cord with a maximum length of
25’.
Never plug the 120-volt cord into an ungrounded
receptacle.
Shore power poses a risk of death due to
electrocution.
Always use a grounded connection.
Never connect to an ungrounded source of shore
power.
Never remove the “third prong” from the shore
power plug.
Risk of fire.
Connect only to source of correct voltage.
Do not overload electrical circuits.
Do not use an extension cord to connect to shower
power.
Replace fuses with like rating.
20
Power Distribution Center
The power
distribution
center consists
of 120-volt
AC, 12-volt
DC and the
power
converter. The
120-volt AC
panel board
containing a 30-amp main breaker and 15 and/or 20-amp
branch circuit breakers. These breakers interrupt the power if
the rated current is exceeded. If a breaker trips repeatedly,
reduce the load on that circuit and have the system checked by
your Nücamp RV Dealer.
Switching from 120-volt AC power to 12-volt DC power is
automatic when the power cord is plugged in or the generator
is on. This powers the 12-volt panel board and the connected
circuits are protected by the installed fuses. Battery charging is
automatic when plugged into 120-volt AC power. The
converter has reverse battery circuitry to prevent damage if the
battery is accidentally connected in reverse. These fuses
protect the power converter from accidental shorting of the
power cables at the battery or reverse polarity caused by
accidental cross connecting the battery. Remember red is
positive (+), white is negative (-). The power converter has a
cooling fan that will run at appropriate times to cool the
converter.
NOTE: Should the converter shutdown during normal
operation, heat may be the cause. The converter has a built-in
automatic-reset thermal breaker that will reset after a cooling
off period. If this occurs frequently, your dealer or qualified
personnel should correct the problem. Be sure not to store
items in front of the vent openings.
Ground Fault Circuit Interrupter
A Ground
Fault Circuit
Interrupter
(GFCI) This
device is
intended to
protect you
against the
hazards of line
to ground
electrical faults and electrical leakage shocks possible when
using appliances in damp areas.
NOTE: The GFCI device does not prevent electrical shock. It
does not protect a person who comes in contact with both the
“hot” and “neutral” sides of the circuit. It does not protect you
against electrical overload.
TEST the GFCI at least once a month while operating on 120volt AC power. To test the GFCI:
Push the TEST button. The RESET button should
pop out, indicating that the protected circuit has been
disconnected.
If the reset button does not pop out when the test
button is pushed, a loss of ground fault protection is
indicated. Do not use the outlet or other outlets on the
same circuit. Have the camper electrical system
checked out at an authorized nüCamp RV Dealer
Service Center. Do not use the system until the
problem has been corrected.
To restore power, push the RESET button.
NOTE: If galley or patio receptacles don’t work, check the
GFCI. Reset the button if necessary. If the GFCI continues to
trip, have the camper electrical system checked at an
authorized nüCamp RV Dealer Service Center or by a
qualified electrician.
Power Generator
Before operating any generator, read, and understand this
section of the manual and the manufacturer’s operating
instructions for your generator. The generator circuit breaker
provides circuit protection while in the “ON” operating mode.
See the Generator Manual for location.
NOTE: Refer to your Generator Owner’s Manual provided in
your Owner’s Information Package for starting, operating,
service and troubleshooting instructions.
Always wait at least three minutes after starting generator
before turning on or plugging in heavy electrical loads, such as
the roof air conditioner and the convection microwave oven.
To stop the generator:
1) Turn off all electrical loads.
2) Let the generator run at no-load for a few minutes, to
stabilize internal engine generator temperatures.
3) Place Start/Stop switch in the Stop position.
Generator Operating Safety Precautions and Warnings
Do not block the generator ventilating air inlets or outlets. The
engine requires a constant supply of cooling air. Restricted
ventilating air inlets or outlets can cause engine failure or fire
from engine overheating.
Do not use generator-ventilating air for heating any interior
living space. Ventilating air can contain high concentrations of
lethal gases.
Exhaust Gas Is Deadly!
Exhaust gases contain carbon monoxide, an odorless and
colorless gas. Carbon monoxide is poisonous and can cause
unconsciousness and death. See the “Carbon Monoxide Safety
Precautions” section in the “Fire and Safety” chapter.
Do not block the tailpipe or situate the camper in a place
where the exhaust gases have any possibility of accumulating
21
either outside, underneath, or inside your vehicle or nearby
vehicles.
Outside air movement can carry exhaust gases inside the
vehicle through windows or other openings remote from the
exhaust opening. Operate the engine (s) only when safe
dispersion of exhaust gases can be assured, and monitor
outside conditions to be sure that exhaust continues to be
dispersed safely.
Do not operate the generator when parked in or near high
grass or brush areas. Exhaust heat may cause a fire.
Loading the Generator
The generator can power (depending on size) AC motors, air
conditioners, AC/DC converters and other appliances. How
much load can be serviced depends upon the generator power
rating, temperature, and altitude. The generator will shut down
or its circuit breakers will trip if the sum of the loads exceeds
the generator’s power. Allow the air conditioner to operate on
the thermostat setting. If manually operated, it may cause an
overload condition. Applying excessively high electrical loads
may damage the generator and may shorten its life.
To avoid overloading the generator, add up the rated watts of
all electrical lighting, appliance, tool, and motor loads the
generator will power at one time. This total should not be
greater than the wattage capacity of the generator. If an
electrical device nameplate gives only volts and amps,
multiply volts’ time’s amps to obtain watts (volts x amps =
watts). Some electric motors require more watts of power (or
amps of current) for starting than for continuous operation.
Typical Appliance Loads
Appliance Load (Watts) Load (Amps)
Coming soon
Power VS. Altitude
Note also that air density decreases as altitude and ambient air
temperature increase, causing the generator power to decrease.
Power decreases approximately 3.5 percent of rated power for
each 1000 feet of increase in elevation and 1 percent each
10°F (5.6°C) rise in temperature above 85°F (29°C).
Elevation above Maximum Power
Sea Level
Up to 500 feet 2500 watts (rated)
2500 feet 2325 watts
5500 feet 2063 watts
Above 5500 feet 2063 watts minus 87 watts each
1000 feet
Propane Gas Safety
Please observe the warnings and cautions contained in this
section as well as the manufacturers supplied information with
each gas appliance.
Propane is stored in a high-pressure tank in liquid form and is
delivered to the appliances in a gaseous form. The propane
canister(s) must not be placed or stored inside a vehicle. The
container(s) are equipped with safety devices that relieve
excess pressure by discharging propane to the atmosphere.
Safety Precautions
Propane is highly flammable and heavier than air. It’s treated
to have a garlic like odor to aid in detecting a leak. If a leak
should occur, the propane can collect in pockets along the
floor and thereby dissipate in the air. If left unnoticed, it could
result in suffocation or an explosion.
If you smell propane
1) Extinguish any open flames, pilot lights and all
smoking materials.
Do not touch electrical switches.
Shut off the propane supply connection.
Open door and other ventilating openings.
Leave the area until odor clears.
Have the propane system checked and
leakage source corrected before using again.
2) Inspect the entire propane system for leaks or
damaged parts before each trip.
3) Never check for leaks with an open flame. Use an
approved leak detection solution or a non-ammoniate,
non-chlorinated soap solution only. If the leak cannot
be located, have the system checked by qualified
personnel.
4) Always be careful when drilling holes or fastening
objects to the camper. A nail or screw could puncture
the propane supply lines.
5) Do not restrict access to propane tanks. In an
emergency, the tank service valve must be easily
accessible. Do not store items or block ventilation
openings in the propane compartment.
6) Do not use any propane tanks other than those
furnished with your camper.
Turn off main propane valve and individually
turn off all propane appliances or electrically
disconnect automatic ignition appliances
before entering propane bulk plant or motor
fuel service station. When not individually
turned off, automatic ignition appliances may
continue to spark.
Do not fill propane containers to more than
80% capacity. Overfilling can result in
uncontrolled propane flow that causes fire
and explosion. A properly filled container
holds about 80% of its volume as liquid.
7) Do not use a wrench or pliers to close the service
valve. This valve is designed to be closed leak-tight
by hand. If a tool is required to stop a leak, the valve
probably needs repair or replacement.
8) When attaching the hose connector to the valve, don’t
force, jam or cross-thread the fitting. Always check
fitting for leaks after tightening.
9) Be sure the tanks are securely fastened when
mounted on the camper.
22
10) Consult a Nücamp RV Dealer for any propane
system repair.
11) Always think safety, never guess. If you are not sure,
please seek a qualified service technician or a
certified LP service center.
Turn off main propane valve and individually turn off all
propane appliances or electrically disconnect automatic
ignition appliances before entering propane bulk plant or
motor fuel service station. When not individually turned off,
automatic ignition appliances may continue to spark.
Do not fill propane containers to more than 80% capacity.
Over filling can result in uncontrolled propane flow that can
cause fire and explosion. A properly filled container holds
about 80% of its volume as liquid.
Propane Tank
All new propane tanks must be purged of air and moisture
before filling for the first time. The propane tanks should be
filled per the instructions on the tank safety labels.
Filling should be done only at authorized propane fueling
stations. Please observe the following instructions when filling
the storage tanks.
D.O.T. regulation # 173-34 prohibits propane tanks from
being refilled inside the RV. The tank(s) must be removed
from the compartment to be properly inspected before
refilling. Use propane tanks in their proper position.
Filling Propane Tanks
1) A small amount of anhydrous methanol (3/4 oz. per 5
gal) can be added before filling an empty tank to
prevent freeze ups. Check with your propane.
2) The law requires least a 20% vapor space for safety.
A special liquid level valve is installed in the tank
when the tank has reached 80% of its volume as
liquid propane. Stop filling when liquid appears at
this valve.
3) Use vapor only. All propane appliances for cooking,
heating, lighting, water heating, and refrigeration are
designed to operate on propane vapor only.
Therefore, all propane tanks designed for vapor
service must be transported, installed, and used in the
proper position. Propane containers are permanently
marked with “TOP” stamped on tank, welded to the
tank or “ARROWS must point up” stamped in the
guard or bracket to identify the proper position.
4) Do not transport, install, or use a vertical cylinder in
a horizontal or upside down position. Liquid propane
could enter systems designed for vapor only, creating
a hazardous condition.
5) Do not carry or store filled or empty propane
containers inside your camper. Propane containers
are equipped with a safety device that relieves
excessive pressure by discharging gas to the
atmosphere. Leaks can occur at valves and fittings.
Always store propane tanks with the valves closed.
6) Always use the dust cap when transporting or storing
disconnected tanks (full or empty).
7) All propane tanks must be securely attached in the
proper position for intended use. Use all brackets
provided to ensure proper support and positioning.
8) Route all propane lines carefully and avoid kinking
the lines. A kinked hose can limit or cutoff the flow
of propane through the system.
Using Propane System
It is normal to have a slight gas odor when initially opening
the outlet valve. Fully open and seat valve by hand only to
prevent leakage past the valve stem. If an odor seems to linger
perform a leak test.
Keep outlet valves closed when not using the propane system.
Do not attempt to adjust the regulator. The manufacturer has
preset it. If any adjustment is required, a qualified propane
service technician using special equipment must make it.
Single Propane Tanks
Single propane tanks are equipped with a two-stage regulator.
Be sure the regulator is securely fastened to the tank with the
diaphragm vent facing downward. When using the tank,
simply open the valve.
Propane Gas Fuel System
Propane gas systems are installed to operate a variety of
appliances, such as stoves, refrigerators, heating units and
water heaters. The exhaust fumes from burning propane gas
are odorless and can cause death or serious brain injury if
inhaled. The exhaust from propane appliances must be
directed to the outdoors. You must have an operating carbon
monoxide detector in the accommodation space of your
camper.
Carbon Monoxide can cause brain damage or even
death.
Make certain the exhaust from Propane appliances is
directed to the outdoors.
Have a working carbon monoxide detector in the
accommodation spaces of your trailer before
operating Propane gas appliance.
Do not operate portable grills, portable stoves,
portable lanterns, or portable heaters inside the
trailer.
When used for the first time, or after a period of storage, the
Propane gas lines will be full of air and must be purged of air,
before the appliance will stay lit. Have the Propane gas lines
purged by your Nücamp RV Dealer, or a Propane gas dealer.
A Propane gas system is designed to operate with a supply of
Propane gas only, NOT natural gas. A natural gas supply is
unsafe for the system’s pressure regulation devices.
23
Risk of death due to fire or explosion.
Do not connect a Propane gas system to a supply of
natural gas.
Extinguish all pilot lights and turn off all appliances
before refilling fuel or Propane gas tanks.
Do not fill the tank with any gas other than Propane.
Do not store Propane gas tanks inside the camper.
Keep the shutoff valve on your Propane gas tank closed
always, except when you are operating a Propane gas
appliance. Before opening the Propane shutoff valve, turn off
all Propane gas appliances. If an appliance is on when you
open the shutoff valve, Propane gas can accumulate in the
camper, which can result in an explosion.
Propane gas leaks can result in fire or explosion. If your
camper is equipped with a Propane gas system, it must also be
equipped with a Propane gas detector. The Propane gas
detector will be located near the floor to detect the heavierthan-air Propane gas. If a leak is suspected, use a soapy water
solution to search for the leak. Do not use a solution that
contains ammonia or chlorine (common in window and other
household cleaning compounds), because those chemicals will
cause Propane piping corrosion.
Risk of fire or explosion
If Propane gas is detected (by smell or by the
Propane gas detector):
Do not touch electrical switches
Extinguish flames and pilot lights
Open door for ventilation
Shut off Propane gas supply at the Propane tank
Leave the area until odor clears
Correct the source of Propane gas leakage before
using Propane appliances.
Do not use a flame to locate the source of a propane
gas leak.
Propane gas is compressed into liquid form. Propane gas must
be completely vaporized before being burned.
NOTE: Propane gas will operate at temperatures as low as
minus 44° Fahrenheit (-44° F).
Propane gas is prohibited on some roadways, bridges, and
tunnels. Check a map and with Department of Transportation
(or with the AAA) for travel routes that do not have such
restrictions.
Propane Gas System Troubleshooting
Having liquid “gas” at your appliances is an
indication that the Propane gas tank is overfilled, or
that the temperature is too cold.
If your Propane gas appliances do not stay lit, it
might be because your Propane gas system is
contaminated with air or moisture. Many Propane gas
vendors have facilities to purge the air from a
Propane gas system.
If your Propane gas system is not providing gas, even
when the shutoff valve is open, it might be because
the Propane gas regulator has frozen water in it.
Risk of fire or explosion.
Never us a flame, heat lamp or hair dryer to thaw a
Propane gas regulator.
Use an incandescent light bulb to warm the regulator.
Do not remove the regulator cover or attempt to
service the Propane gas regulator.
On the Road
Loading
When loading camper gear, store heavy items first and place
down low. Distribute weight as evenly as possible from side to
side. Remember: overloading or uneven loading can create a
serious safety hazard or may even shorten the service life of
chassis components. Do not load upper cabinets with heavy
items. Secure and brace stored items so they don’t move
during travel, thereby shifting the load in the camper. Do not
load heavy items near the end of the camper or on the rear
bumper. Carry only as much water as needed for travel use or
to balance the load. Whenever possible, empty the waste water
holding tanks before traveling.
Storage
All cabinets and storage areas should have the heaviest items
on the bottom and lighter items overhead. After loading you
should have the skillets and can goods on the floor or bottom
shelf, and the cereals and crackers in the overheads. Use the
unbreakable type plates and saucers, and consider storing your
dishtowels around them.
Clothing hung in wardrobes should be kept on hangers that
snap over the clothes rods to keep them from “jumping” off on
rough roads.
Preparing for Travel
Properly preparing for a trip before you leave can make things
more enjoyable. Make a list of items you will need or wish to
take. Keep in mind the following categories:
Bathroom supplies
Bedding
Cleaning items
Clothing
Fire Extinguisher
First aid items
Food
Holding tank chemical
Kitchenware
Personal items
Road flares
Tools
24
Pre-Trip Checks
(Exterior)
1) Connect battery(s) and check condition.
2) Check for fluid leaks.
3) Check that access doors are securely closed.
4) Check all running lights, taillights, and electrical
system.
5) Be sure tie downs and stabilizers are securely
tightened.
6) If equipped check back up camera function
(Interior)
1) Secure all loose items.
2) Close all drawers and cabinets.
3) Secure microwave and refrigerator doors.
4) Check that entry door is locked.
5) Latch all windows and skylights in the second
latching position.
(Systems)
1) Fill fresh water tank.
2) Drain holding tanks and secure drain cap.
3) Check operation of interior lights and appliances.
4) Check propane gas level. Check for kinked propane
lines and possible leaks.
Post-Trip Clean-Up
1) Clean unit and check for damage.
2) Drain waste-holding tanks.
3) Clean waste drain hose and secure drain cap.
4) Drain fresh water tank.
5) Close outlet valve on propane tank.
6) Disconnect the battery cables or turn off battery
disconnect switch if equipped.
Safe Driving Rules
Your truck will have different handling and stopping
characteristics when it is carrying the camper. The following
rules will help you develop needed skills for safe Camper
driving.
Travel slowly with your new truck/camper combination, until
you have learned the handling and stopping characteristics of
the combination. Practice turning, stopping, and backing in a
secluded place away from traffic.
Do not permit a driver who is inexperienced to operate your
truck/camper combination without your direct supervision.
Remember its slow speed for beginners.
Drive at moderate speeds allowing for adverse highway and
wind conditions. Even under the best of conditions, do not
exceed 55 miles per hour. As speed increases, driving
stability, stopping ability, and ability to make emergency
maneuvers are greatly reduced.
Reduce speed before starting down hills – even short ones –
and avoid heavy braking on downgrades. Truck stability is
reduced when traveling downhill.
Slow down before entering turns and avoid heavy braking in
turns. Truck stability is reduced in turns, and the weight of the
camper on the truck will affect the way the truck handles.
Avoid quick steering movements that can reduce truck
stability.
Maintain at least twice the normal stopping distance while
carrying your camper. The increased weight of the camper on
the truck requires greater stopping distance.
Use lower gears on long grades. Downshift on upgrades to
avoid overheating or undue engine loads. Downshift on
downgrades to allow engine braking to assist in controlling
vehicle speed. Avoid continuous or frequent brake application.
The added weight of the camper can cause brakes to overheat
and fade.
Allow amply time for passing. Your acceleration will be
much slower when you are carrying the camper.
Become familiar with the position of the truck in traffic, and
be cautious when maneuvering to allow for its length and
width. Always allow extra room to corner and to change lanes.
Learn to use the side mirrors to view the road behind and to
the sides. Check them often.
Allow for extra height of your camper. Check for low
hanging tree branches or other obstructions whenever you
drive, park, or when pulling in for fuel or service. Always
check overhead clearance of overpasses and bridges,
especially if you drive with the roof vents slightly open or if
the camper is equipped with a roof air conditioner, roof rack,
TV/radio antenna, or a satellite dish.
Measure your height from the ground to the highest point on
the roof. Write it down on a piece of tape and put it in a visible
place in your truck. This will help you when you get to that
“low overpass”.
Riding in Camper While Traveling
For the safety of passengers, it is not advisable to ride in the
camper while traveling. In some states, it may be illegal. If it
is necessary, care must be taken to remain seated while
moving.
Campground Regulations
You should always check the campground regulation on
arrival. This will avoid any unnecessary conflict with the
campground management and/or other campground users.
NOTE: Some campgrounds do not allow the camper to be
removed from the truck.
Equipment
Some features described here do not appear on all Nücamp
RV models Nücamp RV is continuously changing and
25
upgrading appliances for better usage and for your
convenience. For that reason, the style you have may not be
exactly what is described in this manual. In this manual, you
will find general information for the operation of the
appliances for more detailed information, please refer to the
appliance manuals provided to you in your Nücamp RV
Owner’s packet.
After taking delivery of your Nücamp RV camper, spend
some time familiarizing yourself with the exterior and interior
features. Your interior has been designed with utility and
comfort in mind to provide spaciousness and versatility.
Familiarize yourself with the bedding and dining arrangements
as well as the various storage areas inside and out.
Each appliance in your camper is warranted by its’
manufacturer. It is very important that you review all the
literature provided in the Owner’s packet that came with your
camper. Fill out and return all warranty registration cards as
required by the appliance manufacturers. If you have any
questions regarding the operation of the appliances in your
unit, contact your selling dealer. Also, please notify your
dealer of any shortage of literature you may have.
It is important that you read all the manufacturer’s information
provided, regarding both operation and maintenance of the
appliance. Pay close attention to all safety precautions given
and follow them closely. Keep all literature, including this
manual with the camper for easy reference. If service on any
appliance is required, contact your dealer or an authorized
service representative of the appliance manufacturer. Most
appliance manufacturers have toll free service telephone
numbers for your convenience. You will find some listed
under the Component Manufacturers.
Roof
All Nücamp RV models have a fully decked and laminated
roof that may be walked on from front to rear. When walking
on the roof use deck shoes as leather shoes become slippery
and can also leave marks on the decking. When on the roof,
use caution to avoid slips and falls. Use caution when loading
sharp articles on the roof as you can gouge or puncture the
roof. If you add accessories or new equipment on the roof, use
a qualified installer, or consult your dealer. Care must be taken
when working on the roof to avoid disrupting the seals which
could void your warranty.
Compartment Doors
Various exterior compartment doors provide access to certain
appliances, controls, and general storage.
Outside storage compartments are not air sealed or vented
enclosures Do not store hazardous chemicals/materials or
flammable, volatile liquids in these areas.
The Propane Tank Compartment Door provides access to the
storage propane tank(s) and regulator valve(s). This
compartment door must remain unlocked as required by
National Fire Protection Association (NFPA) to allow
immediate access in case of a propane leak or fire.
The Refrigerator Vent/Door provides access to the rear of the
refrigerator for service and supplies inlet ventilation for proper
operation.
The exterior Service Center Door #2 provides access to the
jack control center.
The Exterior Service Center Door #3 provides access to waste
tank dump valves, fresh water tank drain valve.
Vents
All exterior vents and louvers provided need air circulation.
Be sure not to block these vents because damage to
equipment, as well as hazards to individuals could result.
Roof Vent
The roof vents are operated from inside and have built-in
screens. To operate, turn the crank on the vent clockwise to
open and adjust. The bath vent may be equipped with a 12volt exhaust fan. The switch to control the fan is located on the
vent.
Skylight
This skylight
is dual pane
and opens. It
has a sliding
screen.
To open;
Depress the
button on the
latches and
turn to open.
And tighten
knobs on the
window stays.
To close;
Loosen the window stay knob, close and latch.
The shade and screen operate independently of each other and are
engaged by connecting to each other and sliding.
Close the skylight completely when traveling and leave shade
partially open. The shade could pull up into the vent due to
Fridge vent door
26
negative pressure in the camper. If camper is parked in extremely
bright sunlight, leave shade partially open. If completely closed
heat buildup can cause damage to the dome.
Do not stand on the acrylic glass Skylight.
Close the Skylight completely before driving off.
Damage can occur to the shade if the shade is not closed
and the Skylight is open while driving.
Do not open Skylight when it rains or when there is a
strong wind.
Emergency Exit Window
The
emergency exit
window is in
the cab over or
dinette area of
the camper and
is identified by
the red
handle(s) and
EXIT label.
Read and understand these instructions before you need to use
them. The emergency exit window provides an escape route in
case the camper must be evacuated under emergency
conditions and the path to the main entry door is blocked.
To operate the emergency exit window, push in the latch
button and turn to open the red handle(s) and swing the
window outward. The window is hinged at the bottom.
When parked, be sure trees or other obstacles do not block
the exit window.
Windows and Skylight venting
The latches on windows and skylights allow you 2 position
latching.
The first position is used when you want a water and airtight
seal while traveling.
The second position allows you to vent the camper and still
have the windows and skylight locked.
Shades
Screen/Night Shades
The screen/night shades are dual-purpose window covering
that provides privacy at night and bug control during the day.
Exterior Lighting
Your camper is equipped with exterior lights and normally
found on autos to comply with state and federal regulations.
It’s important not to alter the lights or the reflecting markers.
Check the exterior lighting frequently and replace any
inoperative or damaged lighting fixtures as soon as possible.
Ladder
It is critical that all racks and
accessories be properly and securely
attached to your camper. Improper
attachment could result in an accident
or damage to your camper’s roof.
Check the attachments prior to use and
periodically inspect for adjustments,
wear, and damage.
Large, long, or oversize items will
require additional strapping/tie downs. Do not underestimate
the power of the wind.
Entry Door Locks
27
RV Lock Keypad/Remote Programming and Syncing
Instructions Version 4.0
(Additional Remote(s) can be purchased at www.rvlock.com)
Programming a new code into your RV Lock Keypad
1. Write your desired “new” code below then read all
instructions before you start the programming
process as this will make the programming much
easier.
2. While holding down the “8” button, press the “lock”
button and release both. (You will hear a long
confirming beep – this signifies that you have entered
the programming mode.)
3. Type in the keypad existing code, for example 1234,
then press lock. (1234 is the default code from the
factory and after the “code reset” button is held
down.)
4. Now type in the new code written below (up to 8
digits), the press lock.
5. Again, type in the same new code as written below
and press lock. (A long confirmation beep from the
keypad confirms and completes programming).
6. Test to ensure your new code works by typing in
your new code and press the lock/unlock button. The
Keypad should confirm the accepted code by a long
beep and then actuate the handles deadbolt.
7.
NOTE:
If programming of Keypad is unsuccessful or you
forget your code, simply press, and hold down the
“Code Reset” button for 5-10 seconds on the back
handle and start again at step #1. (A long tone will
confirm the reset to the default “1234” code.)
Programming mode is only 12 seconds long, so
keypad will reset to former code/operation after 10
seconds of being idle during programming mode. (If
you take too long or make a mistake, simply wait 10
seconds, and start over at step 1.)
Always keep your keys OUTSIDE of your coach in
case of electronics/battery failure.
Changing the batteries on your RV Lock products
will not cause your handle to forget the current code
or remote programming.
TONE CHART:
Long beep – Confirmation/Correct code
5 shore beeps – Error/Wrong code
Short set of tones after your input your code and
before the dead bolt extends signifies that the
batteries are getting low and will need to be changed
soon.
- Code can be between 0 and 8 digits long, we recommend
at least 4 digits for security.
New Code: _____ _____ _____ _____ _____ _____
_____ _____
Synchronizing the RV Lock handle with your optional RV
Lock Remote(s)
1. Turn the FOB switch to “on” and lightly press the
“FOB LEARN” button located above the ON/OFF
switch on the back of the handle. A short quick bee
will confirm that you have entered the programming
mode.
2. Now press the LOCK button on your remote until the
handle confirms with a long beep. (Usually takes one
or two times). Additional pressing of the
LOCK/UNLOCK button will actuate the deadbolt on
your RV Lock handle.
- If remote programming did not work or if you have
additional remotes to program, repeat steps 1 and 2.
- Holding down the LEARN button for 10 seconds
will remove all previously synced remotes from the
handles memory.
- You can have up to 10 remotes operating the
same RV Lock handle. Remote FOB’s can control
multiple RV Lock handles.
- You must hold the remote buttons down for a
couple of seconds to actuate the handle, this is a
safety feature against accidental pushes in
pockets.
Changing the Batteries on your RV Lock Handle
**Remove the two (2) screws holding the battery cover on the
back handle next to the “on/off” switch. Install four (4) AA
alkaline batteries. NOTE: Install high quality, fully charged
alkaline batteries. Batteries should last at least 12 months in
between changes depending on usage. (Remove batteries at
the end of the season and/or during large gaps between trips to
avoid drainage and/or leaking batteries and possible damage.)
After new batteries are in, a beep will confirm that the handle
has power. Replace the battery cover and screws. (DO NOT
OVERTIGHTEN) Changing the batteries on your RV Lock
handle will not change the current code or remote
programming. If you choose not to use the remote FOB’s, you
can turn the wireless switch to “off” to save power and simply
use the keypad.
Be sure all occupants in the camper know how to operate the
entry door lock and deadbolt as well as the emergency exits in
case of emergency.
When traveling, lock the deadbolt. This will reduce the
possibility of the door opening while on the road.
28
Awning
To operate
awning press
the select
button on the
jack remote
and hold it for
5 seconds, an
LED will
indicate bright
red for the
four-jack mode
and green for the two-auxiliary device mode, the top four
buttons on the remote will operate the two auxiliary devices.
The bottom four buttons and the “All” buttons will be
inoperative during Auxiliary mode.
An operating and maintenance guide for your awning(s) is
included in your Owner’s Information Package. It contains
instructions for opening and closing the awning, as well as
maintenance and care instructions.
You should make sure your traveling companion is also
familiar with the operation of the awning. If a sudden wind
should come up, or if high winds are in forecast, the awning
should be retracted, stowed and the travel locks engaged.
Awnings damage such as a bent tube, torn canvas, or broken
arms due to high winds or water are not covered by warranty.
Rear Awning
If your camper is equipped with a rear awning you will find
the crank to extend it in the wardrobe right inside of entry
door.
Camper Bumper/Step
The aluminum bumper has sealed taillights and backup lights.
Use the fold down step when entering or exiting the camper.
Dinette Conversion
To convert table into a bed push down both buttons where
table top connects with the rail on the wall, then press the
button on the leg to fold it and move the table to the bottom
rail.
Reverse procedure to return the dinette to the seating position.
Fold Down Top Cabinet
The fold-down top cabinet is located over the dinette. To
lower, open the latches located inside the cabinet at each end
and lower the cabinet front. To store the cabinet, reverse the
procedure.
Appliances
Follow the operating and maintenance instructions supplied by
the appliance manufacturer for safe and dependable use. The
following information is supplied as only a supplement to that
provided with each appliance. If you have a problem, see your
local nüCamp RV service center http://cirrus-
truckcamper.com/dealer-locator/ or call the appliance
29
manufacturer listed under the Component Manufacturers
contact list.
Each appliance in your camper is warranted by its’
manufacturer. It is very important that you review all the
literature provided in the Owner’s packet that came with your
camper. Fill out and return all warranty registration cards as
required by the appliance manufacturers. If you have any
questions regarding the operation of the appliances in your
unit, contact your selling dealer. Also, please notify your
dealer of any shortage of literature you may have.
After taking delivery of your Nücamp RV camper, spend
some time familiarizing yourself with the exterior and interior
features. Your interior has been designed with utility and
comfort in mind to provide spaciousness and versatility.
Familiarize yourself with the bedding and dining arrangements
as well as the various storage areas inside and out.
Lighting Propane Appliances
NOTE: New propane tanks or empty tanks that have been
sitting with the valve open for a period must be purged of air
and moisture prior to filling. Air trapped in the propane lines
may delay the initial lighting of any appliance. It could take
several seconds or minutes for the propane to reach the
appliance. To purge some of the air from the propane system,
first light a burner on the range. The other appliances will then
light more quickly.
The first time the furnace or oven is operated, paints and oils
used in manufacturing may generate some smoke and fumes.
If this occurs, open doors and windows to air out the camper.
These materials should burn off in a short time. Always follow
the appliance manufacturer’s lighting and operating
instructions.
Refrigerator
The refrigerator operates on 120-volt AC power, propane
and/or 12-volt DC. The operating instructions supplied in the
Owner’s Information Package will help you with detailed
information from the manufacturer.
The recreational vehicle propane type refrigerator operates on
the “absorption” principle and therefore must be reasonably
level. When your camper is stationary, it should be leveled for
comfortable living. If you can occupy the camper comfortably,
the refrigerator unit should perform well. If the refrigerator
unit is not “close to level”, it may not function properly and
your food will not be adequately cooled. When the RV is in
motion, the continuous movement will not affect operation.
The operating instructions are printed inside near the controls
and may be found in the manufacturer’s instructions manual.
Operating Tips
Operate the refrigerator on 120-volts for 8 hours (overnight)
before you leave on a trip. This will allow the refrigerator to
get cold.
Pre-cool food and drinks before putting them into the camper
refrigerator. For off-truck use, some refrigerator models must
have 12-volt battery hookup to power the electronic controls.
Refer to the supplied appliance manuals for proper operating
instructions.
Gas Mode
This mode provides LP gas only. The control system activates
the ignition system and attempts to light the burner for a
period of approximately 45 seconds, at 2 minute intervals. If
unsuccessful, the indicator lamp will not illuminate. Check
Fridge Owner’s manual to trouble shoot.
DC Mode
When DC mode is chosen, the refrigerator will operate by
pulling power from the battery/s. In most cases, the
refrigerator controls will work down to 10.6v DC, causing a
drain on the battery/s.
Please Note: a 3-way fridge in 12-volt mode isn’t designed to
cool your fridge only to help maintain fridge’s current
temperature. Please See Fridge owner’s manual.
Purging Air from the Lines
If the refrigerator has not been used for a long period or if the
LP tanks have just been refilled, air may be trapped in the
supply lines. Purge the air from the lines by pressing ON/OFF
button to OFF and then back to ON, 3-4 times. If repeated
attempts fail to start the LP gas operation, check to make sure
the LP tanks are not empty and that all manual shutoff valves
in the lines are open.
Range
The gas burners and oven use propane gas for fuel. Operation
is similar to the range in your home. However, cook
temperatures will vary from home ranges depending on the
altitude.
Before turning on the main propane supply, be sure all burner
and control knobs are in the “OFF” position.
Cooking appliances need fresh air for safe operation.
Before operation:
1) Open window.
The warning label is in the cooking area to remind you to
provide an adequate supply of fresh air for combustion. Unlike
homes, the amount of oxygen supply is limited due to the size
of the recreational vehicle, and proper ventilation when using
the cooking appliance(s) will avoid danger of asphyxiation. It
is especially important that cooking appliances not be used for
comfort heating as the danger of asphyxiation is greater when
the appliance is used for long periods of time. Never use
portable fuel-burning equipment, including wood and charcoal
grills and stoves inside the vehicle because a fire or explosion
may result.
Lighting Surface Burners
The surface burners will feature match lit ignition. Be sure all
control knobs are in the OFF position before supplying gas to
the appliance. Be sure the main LP gas supply is on before
lighting the burner.
If the burner does not light within 4 seconds, or if the flame
should go out during cooking, turn the burner OFF. If gas has
accumulated and a strong gas odor is detected, open a
30
window, and wait 5 minutes for the gas odor to dissipate
before relighting the burner.
NOTE: If the appliance has not been operated for a period,
the surface burners may be difficult to light, as air may have
accumulated in the gas line.
Do not turn the burner control knobs ON, allowing gas to
escape before lighting a match or using an electronic igniting
device.
To Bleed Air from Line
Hold a lighted match next to the burner.
Turn the surface burner control know to the LITE
position.
When the burner lights, turn the knob back to the on
position.
Depending upon your model, follow procedure for
either ‘Match lit’ ignition or ‘Piezo’ ignition.
Match lit Ignition
1) Hold a lighted match next to the desired surface
burner head.
2) Push in and turn the surface burner control knob to
the LITE position.
3) When the burner lights, adjust the knob between HI
and LOW to select the desired flame size.
4) After cooking, turn the surface burner knob to the
OFF position.
It is not safe to use cooking appliances for comfort heating.
Microwave Oven
Please read all instructions that come with the microwave
oven before use. The microwave should never be operated
empty.
When operating on your generator power is limited. If the roof
air conditioner is operating there may not be enough power to
operate the microwave. Turn the air conditioner control to
“fan only” setting to use microwave.
Alde Heating System
Operating the Alde Heater
Alde heater comes with its own manual please read its
instruction on how to operate the heater.
Turn on the water pump and open hot water at the kitchen
sink, and at the shower and when water flows continuously the
heater is full. More details in the water pump section of this
manual.
The quickest way to do this is attaching a hose to the city
water fill.
Please note: For winter camping you may use the ALDE
system for your heat source while the water system has been
winterized, you will not damage the heater or any of its
components as long as you have properly drained the heater
tank from any RV winterizing fluids (if you didn’t use RV
anti-freeze to winterize the camper but instead used air to
blow out the system there is a nothing you need to do to use
the heater for heat) if you did use Anti-freeze to winterize you
only need to open the Alde relieve valve to drain the Antifreeze from the tank.
31
When you’re
setting up the
heater for the
first time you
will want to
test the water
temperature
coming out of
the faucet and
adjust it by
using the
Mixing valve
located close
to the Alde unit this adds cold water to hot water before it gets
to the faucet to avoid getting water burns.
Please use caution water can be extremely hot coming out of
the heater.
Turning the mixing valve knob to the positive side will
increase the water temperature, if you have adjusted the knob
to its standard max setting please follow the instructions below
on how to increase the max temperature setting on the mixing
valve.
Increasing the Maximum Temperature:
Turn the knob counterclockwise to (+). Loosen the screw
and move the knob out to the side. Then turn the knob
clockwise to (-) without it being engaged. Adjustments are
carried out in small steps. A ¼ turn corresponds to
approximately 7° C (44.6° F). Reinstall the knob and check
that it engages with the teeth. Tighten the screw and then
turn the knob to max (+). Max. Calibration for increasing
the temperature is a ½ turn.
Reducing the Maximum Temperature:
Do the procedure in reverse, Turn the knob clockwise to (-)
and the disengaged knob anticlockwise to (+)?
Do not plug the pressure-temperature relief valve under any
circumstances.
If the water heater will be “out of service” for some time, it
should be drained. See “Storage” chapter for more
information.
When using hot water faucets in the camper for the first time
after heating water, open the valve slowly to reduce water
splattering from pressure build up.
Water Odor
Odor from the water is not a service issue. Many water
supplies contain enough Sulphur to produce a ‘rotten egg’
odor. It is not harmful, only unpleasant. The solution is to
chlorinate the water. You may add about 6 oz. of common
household liquid bleach per 10 gal. Of water in the tank.
Run the chlorinated water throughout the system by opening
each faucet one at a time until you smell the chlorine. Let the
camper sit for a few -*days and the chlorine should take care
of the problem. However, you must then remove the chlorine
by flushing the system with fresh water. You may need to do
this more than once, if this is a frequent occurrence, consider
adding a filtering system as a prevention.
Roof Mounted Air Conditioner
The roof-mounted Air Conditioner operates on 120-volt
power, which is supplied through the 30-amp power cord,
from an outside 120-volt power service, if equipped. The
factory installed air conditioner is a high efficiency, power
saver unit.
The air conditioner will provide cooled air for your comfort.
However, it is the largest single load of electrical usage. It is
important to manage your electrical usage when you have
either an air conditioner or microwave oven installed or both.
1) Be sure air conditioner is OFF before connecting
electricity.
2) When the air conditioner has been shut down, wait at
least five minutes before restarting.
3) Do not operate without a filter installed.
Helpful Notes When Using the Air Conditioner
Keep window curtains closed.
Air conditioner removes moisture from the air and it is normal
to have water discharge off the roof.
Experience has shown that some RV parks may experience
reduced power (low voltage) on days with high heat or
humidity, commonly referred to as a “brown out”. This
condition may result in the air conditioner circuit breaker
tripping in your power distribution center. This protects your
air conditioner motor from damage and is necessary during
low voltage conditions. This breaker tripping is sometimes
perceived as a fault in your camper, but it is a necessary
“safety valve”.
Cooling
1) Park the camper in a shaded area.
2) Use window shades, blinds, or curtains.
3) Keep windows and doors shut or minimize usage.
4) Avoid the use of heat producing appliances.
5) Installing window awnings will reduce heat gain by
removing direct exposure to the sun.
Starting the air conditioner in the morning and giving it a head
start on the expected high outdoor ambient temperature, will
greatly improve its ability to maintain the desired indoor
temperature.
Whether using the HEATING or the COOLING function of
your thermostat, condensation can always be an issue.
Keeping you Camper at a constant temperature helps keep
condensation at a minimum.
Mixing Valve
32
Camp Site Cable Inlets
The park cable inlet is located on the driver’s side of the
camper. The park cable inlet allows for the connection from
the campground cable service to the camper.
Roof Mounted Antenna
The roof mounted TV antenna is designed for reception of
local television signals. Consult the manufacturer’s operation
instructions for proper use.
To Play TV or Cable Audio on Camper speakers’ press source
button on DVD player and select Rear Aux. speakers for your
audio input.
LCD TV
If equipped,
your camper
may have a
LCD TV.
The unit runs
on 12-volt.
Instructional
material can
be found in
the Owner’s
Information
Package.
Exterior Speakers
Your camper is equipped with exterior mounted speakers. The
speakers are located on the curbside of the camper. The wiring
for these speakers terminates at the stereo location. If a
CD/DVD player is installed, the exterior speakers are
connected to the speaker control zones on the stereo.
Fresh Water System
Your Camper is outfitted with a system designed to provide
fresh (potable) water service from an onboard water tank or a
city water connection with a fresh water tank fill located on
the roadside of the camper.
When connecting to the city water hookup, use only a nontoxic water hose, available at most RV supply stores. Since
water pressures at campgrounds and household hookups vary,
you should install an inline pressure regulator at the water
supply faucet. This will protect both the camper water system
and supply hose from excessively high water pressure. (This
comes supplied with the Camper)
Water provided from outside the recreational vehicle, is
pressurized by the system from which it is delivered. When
you connect your recreational vehicle to an outside source, the
fresh water tank and the water pump are kept separate from
the remainder of the system by in-line check valves.
DO NOT turn the pump on if the fresh water tank is empty.
Doing so could cause damage to the pump.
Water Pump
The pump is not equipped with a dry tank shut-off switch.
Turn the pump switch OFF if water in tank becomes depleted
or when system is not in use. The pump operates when water
pressure drops below a predetermined pressure. A drop-in
pressure occurs when a faucet or a toilet valve is opened.
When the faucet is closed, the pump shuts off as soon as the
system is re-pressurized.
Turn the pump ON to pressurize the water system. When the
faucet is opened, the water may sputter for a few seconds. This
is normal and no cause for alarm. The water flow will become
steady when all air is bled from the water lines. If a faucet is
open slightly, allowing water to flow slowly, the pump may
pressurize the plumbing faster than the water is released,
causing the pump to cycle on and off.
A built-in check valve prevents back flow and protects the
pump and fresh water tank from excessive city water system
pressures. The pump operates at 3 GPM and 55 PSI. At free
flow the pump draws approximately 7.5 amps. A fuse in the
power center protects the water pump circuit. When traveling,
always turn OFF the water pump. This will reduce the
possibility of water flowing during travel. If the pump cycles
on and off when no water is being used, you may have a partly
open faucet, a leak in the water system or an empty water
Camp Site Cable Connector
TV Antenna
33
tank. Never attempt to service the pump without first turning
off the power and opening all faucets to relieve pressure in the
water system.
Water Tank Fill
3/8 hose adapter link: http://www.amazon.com/Anderson-
Metals-Garden-FittingConnector/dp/B006PKMU7U/ref=pd_sim_86_11?ie=UTF8&
dpID=51uF4RcaeaL&dpSrc=sims&preST=_AC_UL160_SR1
60%2C160_&refRID=10EHMTB3KCACCK7J85FN
The fresh water system should be sanitized at the initial filling,
after a period of storage or if contaminated. See “Sanitize
Fresh Water System” in this section.
Please fill tank slowly.
Filling the Fresh Water Tank:
1) Make sure fresh water tank drain valve is closed,
located in the compartment door #3
2) Remove cap on fresh water fill inlet.
3) Using a 3/8 hose adapter, fill the water tank through
the exterior fill spout slowly at a low volume until
water overflows out of the vent or check tank monitor
and fill until it reads 100%.
4) Set pump control switch to ON.
5) Open each faucet one by one until water flows
evenly, and no air bubbles are evident.
6) Top off water tank through the exterior fill spout to
replace water used in filling the water heater and
purging the water lines of air.
7) Replace cap and lock the access door.
City Water Connection
Attaching to an Outside Source of Water
1) Remove the cap from the fresh water inlet on the side
of the Camper.
2) Attach one end of the fresh water hose to the outside
source of water.
3) Connect the other end of the hose to the camper city
water inlet.
4) Turn on the outside source of water. Gradually open
the hot & cold water at the sinks and tub to clear air
from the lines.
5) Close the faucets when the water is flowing freely.
Water System Drain
The water system should be drained if it will be out of service
for more than one week. This will prevent algae and bacteria
contamination of your fresh water system.
To Drain your Camper:
1) The camper should be level and pump control switch
in OFF position.
2) Open all faucets and shower-head.
3) Open water tank drain valve.
4) Open Alde relief valve. (See Winterization and
Storage section for more info.)
Sanitizing Fresh Water
System
Sanitize the fresh water
system and piping at
initial use, at least once a
year and whenever the
camper sits for a prolonged period. This will help keep the
tank and lines fresh and will discourage the growth of bacteria
and other organisms that can contaminate the water supply.
Rinse the tank with a chlorine/fresh water solution as follow:
1) Drain water system. (See Drain Water System).
2) Prepare a chlorine solution with one gallon of water
and ¼ cup household bleach.
3) Pour one gallon of solution for each 15 gallons of
tank capacity into fill spout.
4) Fill tank with fresh water.
5) Open each faucet and water heater relief valve until
water flows evenly.
6) Set pump switch to OFF.
7) Allow solution to stand for 3 hours.
8) Drain and flush with fresh water.
9) To remove any chlorine taste or odor, fill tank with
one-quart vinegar to 5 gallons of water. Allow
solution to remain in tank several days if possible.
10) Drain and flush with fresh water.
Potable water only. Sanitize, flush and drain before using. See
instruction manual. Failure to comply could result in death or
serious injury.
Fresh Tank Fill
City Water Connection
3/8 Hose Adapter
34
Water Filter
An in-line water
filter attached to the
inlet side of the
water pump filters
dirt, mineral scale,
or organic matter out
of the fresh water
system. If you
suspect a clogged
filter, it is easily
removed and cleaned. Loosen the clear filter cap at the inlet
end of the filter.
Flush out and clean screen.
Reverse procedure to install and check for leaks.
Inspect the filter after the first 90 days of use, clean it
if necessary, and inspect annually thereafter.
Shower
The shower-head is removable for hand-held use and equipped
with a water flow control device to allow you to conserve
water while showering. After showering, there may be some
water discharge at the sink faucet. This water is draining from
the shower hose through an anti-siphon valve in the faucet and
is normal.
Due to design precautions, hand held shower-heads, when in
the “hold” position must have a built-in leak rate of less than 1
gallon per 30 minutes of time. This leakage is not a defect but
is an attempt to reduce the possibility of scalding accidents
due to temperature changes from fluctuating water pressure.
Exterior Wash Station (Shower)
The exterior wash station is in the service center on the
roadside compartment for exterior use. It uses water from the
fresh water tank or when connected to the city water hookup.
The shower-head is equipped with a flow control to allow you
to conserve water. This flow control is not a permanent shut
off.
After use of the shower, the water must be shut off at control
valves or possible damage could occur to the shower-head
and/or hose.
For severe weather camping, by-pass valves are provided to
shut off the water to the exterior wash station to prevent the
system from freezing.
Waste System
The waste holding system in your camper is made up of sinks,
shower, toilet plumbing drain and vent lines, “gray water”
holding tank, and “black water” holding tank. The holding
tanks make the system completely self-contained and allow
you to dispose of wastewater at your convenience. A flexible
sewer hose is used to connect the holding tank outlet to the
inlet of an approved wastewater dump station or sewer system.
Fresh Water Flush Toilet
Your camper is equipped with a marine-type recreational
vehicle toilet. This toilet is especially designed to operate with
a minimum of water usage. The flushing mechanism, a handoperated lever, allows a valve in the bottom of the bowl to
open, permitting the contents to be flushed into the holding
tank below. A stream of water under pressure from the
camper’s water system swirls around the bowl, cleaning and
flushing the contents. Most models have two levers, each
working independently of the other so the bowl can be filled
with water prior to use. For additional information, please
refer to the operating manual supplied with the toilet.
NOTE: If the toilet requires a water supply for proper use.
This can be from either a city water hookup, if available, or
from the on board fresh water tank supply. The 12-volt water
pump switch must be in the “ON” position when using water
from the tank.
Black Water Holding Tank
This holding tank must be primed with 2 gallons of water and
one odor control chemical package at each initial use. Add
more odor control chemical if needed until dumping is
required. Refer to the chemical package available at most RV
outlets for specific instructions.
Sewer Hose Storage
Located in the bumper
Bathroom
The bathroom walls are sealed and waterproof; so, do not
worry if water splashes on it. Some models are equipped with
a power roof vent in the bathroom.
Toilet
The toilet is designed to flush with a minimal amount of water
and still provide for proper disposal and odor control. Toilet
chemicals are available at most RV retail outlets. Review the
35
manufacturer’s owner’s manual supplied with the toilet for
proper use, maintenance, and chemical usage. The toilet paper
dispenser is mounted inside the lavvy door under the sink.
Information on the toilet plumbing can be found in the “Waste
System” section.
Holding Tanks
The holding tanks terminate in a valve arrangement that
permits each tank to be dumped separately or together. The
valves are called “knife valves”. A blade closes the opening in
the sewer drain pipes. The blade is connected to an extension
handle that is pulled to release the contents of the tanks(s).
During self-containment use, the sewer outlet line should be
securely capped and valves closed to prevent leakage of waste
material on the ground or pavement.
Holding tanks are enclosed sewer systems and as such must be
drained into an approved dump station. Both black and gray
water holding tanks must be drained and thoroughly rinsed to
prevent accumulation of harmful or toxic materials.
Dump the holding tanks only when they are about 2/3 full. If
necessary, fill the tanks with water to 2/3 full.
This provides sufficient water to ensure complete flushing of
waste material into the sewer line. Whenever possible, dump
the holding tanks before traveling.
The holding tanks outlet is set up to be used with a removable
fitting that locks onto the outlet with clockwise twist. The
sewer drain hose is clamped on this fitting when you need to
drain the holding tanks. When you are operating selfcontained, or you store the camper, install the protective cap in
place of the removable hose.
The sewer (dump) hose is compressed and stored in the
camper’s hose carrier.
When you want to drain the holding tanks:
1) Attach the sewer hose to the dump outlet.
2) Extend the hose and insert the hose end into the
sewer or dump station inlet, pushing it firmly into the
opening to be secure. In some cases, adapters may be
necessary between the hose and inlet.
3) Arrange the sewer hose so it slopes evenly and is
supported to maintain the slope.
4) Dump the black water holding tank first. Grasp the
handle of the black water knife valve firmly and slide
the valve open with a steady pull.
5) Allow enough time for the tank to drain completely.
Rinse and flush the tank and drain hose through the
toilet with a bucket of water or a hose.
6) When the tank flow stops, push the handle in to close
the valve.
7) Pull the handle for the grey water holding tank.
Repeat steps 4 through 6. This tank is dumped last to
aid in flushing the drain hose.
8) Remove the sewer hose and replace the outlet cap.
9) Rinse out the sewer hose with fresh water and
remove the sewer hose from the dump station.
10) Replace sewer or dump station cover(s).
11) Store the sewer hose.
NOTE: To facilitate draining, the camper should be slightly
higher in the front. Also, raise the passenger side of the
camper to allow drainage toward drains located on the driver’s
side.
If you are parked at a site with a sewer hookup, keep the black
water knife valve closed to allow the waste level to build up.
The outlet will probably clog if you leave the knife valve open
continually. Run enough water into the tank to cover the
bottom. This will aid the breakup of solid wastes. The gray
water tank valve may be left open.
Holding Tank Care/Maintenance
Since holding tanks don’t rely on any sophisticated
mechanical devices for their operation, they are virtually
trouble-free. The most common problem is also an unpleasant
one, clogging. You can minimize chances of clogging by
keeping the following considerations in mind:
Keep the black water tank drain valve closed. Be sure
to cover the tank bottom with water after dumping.
Movement while driving will help to liquefy the
solids.
Use only toilet tissue formulated for use in septic
tank or RV sanitation systems.
Keep both drain valves closed and locked, and the
drain cap tightly in place when using the system on
the road.
Use only cleaners that are approved for use in septic
tank or RV sanitation systems.
Use a special holding tank deodorant chemical
approved for septic tank systems in the black and
grey water holding tanks. These chemicals aid the
breakdown of waste and make the system much more
pleasant to use.
Do not put facial tissue, paper, grease, ethylene
glycol-based or other automotive antifreeze, sanitary
napkins, or household toilet cleaners in the holding
tanks.
Do not put anything solid in either tank that could
scratch or puncture the tank.
If the drain system does get clogged:
Use a hand-operated probe to loosen stubborn
accumulations.
Seriously clogged P-traps may require disassembly.
Be careful not to over tighten when reassembling.
Do not use harsh household drain cleaners. Do not use
motorized drain augers.
Sometimes the holding tank valve will get clogged. In this
case, a hand-operated auger may be necessary. Be ready to
close the valve quickly once the clog is cleared. If the seal gets
damaged, it must be replaced.
Do not use the same hose you use for filling the potable water
tank or for the connection to the city water inlet. Use a
36
different hose to ensure that you will not contaminate your
fresh water supply.
Winterization
Operating in Freezing Conditions
If water freezes inside the system, it can damage piping and
equipment.
Keeping the interior warm will aid in preventing water in the
storage tank, pump, and piping from freezing.
Add non-toxic anti-freeze to the holding tank(s). Refer to the
instructions that came with the anti-freeze.
Propane for the appliances will work down to 44 degrees
below zero (-44°).
Storage
The following checklists will help you perform the steps
necessary to prepare your camper for storage. Use the
checklist that applies to the storage conditions you anticipate.
These checklists do not include every detail required, and you
may want to expand them to suit your needs.
Short-Term Storage
(Less than 45 days – Above Freezing)
1) Wash the exterior.
2) Park the camper as level as possible front to rear and
side to side.
3) Before disconnecting the battery cables, check the
charge in the battery. Recharge as necessary. Clean
terminals, top and sides of battery and battery box.
Leave the battery disconnected or switch the battery
disconnections switch to the “OFF” position.
4) Drain the holding tanks, toilet, and fresh water tank.
Turn off the water pump and water heater.
5) Turn off the propane at tank valve.
6) Turn off the refrigerator, furnace, all range and oven
burner valves and pilot.
7) Remove all perishables from refrigerator and galley
cabinets. Leave the refrigerator door open to reduce
odor buildup. An open box or tray of baking soda in
the refrigerator will help absorb odors.
8) Close and lock all windows. Be sure the vent fan and
range hood fan switches are off.
9) Cap and close the holding tank drain, city water inlet
and fresh water fill spout.
10) Turn off all radios, TV’s, interior and exterior lights.
11) Close the mini blinds and day/night shades.
12) Disconnect the 120-volt power cord and store in
compartment.
13) If removing the camper from the truck, see procedure
and warning in the “Loading and Unloading Camper”
section.
14) Check the camper weekly.
Long-Term Storage
(Above Freezing)
1) Perform all the preceding short-term storage steps.
2) Operate air conditioner periodically to lubricate
compressor seals.
3) Remove and place the battery in a cool, dry area.
Check the battery charge every 30 days. Recharge as
necessary.
4) Check the sealants around all roof seams, body
seams, and windows. Reseal if necessary.
5) Prepare the generator (if equipped). See generator
Operating Manual included in the Owner’s
Information Package.
6) Remove the smoke detector’s battery. Leave the
cover open as a reminder to replace the battery.
Storage below Freezing
To avoid damage to the plumbing fixtures and other
components, we recommend that your camper plumbing
systems be properly drained and have antifreeze protection or
be drained and blown out with air. The following is a
procedure checklist you can follow if you prefer to winterize
your camper yourself. Many owners prefer a Nücamp RV
Dealer Service Center perform this service.
These are instructions on how to winterize the Campers
with VIN# that have letters FS in the VIN and numbers 01
thru 96 at the end of the VIN. You must use air to blow out
the water lines, please follow the instructions below.
1) Perform all steps in the short and long term storage
procedures.
2) Turn the water pump ON and open all hot and cold
water faucets. When the flow of the water stops, turn
the pump OFF.
3) Drain the fresh water tank by opening the fresh water
tank drain and leaving open, the drain is in door
number 3.
4) While having the Alde relieve valve and fresh water
tank drain valve open disconnect the hoses on each
side of the water pump until all the water is drain out.
After the water is drained out reattach the hoses.
5) Drain the water heater by opening the Alde relief
valve.
6) Attach the air blow out plug to the city water
connection, leaving all the valves and faucets open
connect the air hose and blow out all the leftover
water that couldn’t be drained out. Depress the toilet
flush pedal or hand-operated lever. Below is a link
for the blow out plug needed.
http://www.walmart.com/ip/29764314?wmlspartner=
wlpa&adid=22222222227021475530&wl0=&wl1=g
&wl2=c&wl3=40838463032&wl4=&wl5=pla&wl6=
78651722432&veh=sem
7) After all the water is
blown out, disconnect the air
hose, and Shut OFF all
faucets, fresh water tank drain
valve, water heater pressure
relief valve.
8) Drain the showerhead and
hose by disconnecting the hose at the faucet from the
inside and outside shower.
9) Drain the waste water system by following the
normal procedure for draining the holding tanks.
37
10) Pour 2 to 3 cups of RV Antifreeze down each drain to
fill the drain traps with antifreeze.
Draining the water system alone will not provide adequate
cold weather protection. If the camper is to be unheated during
freezing temperatures, consult your dealer for the best
winterizing procedure for your climate. Your dealer can
supply you with one of the special non-toxic antifreezes that
are safe and approved for use in RV water systems. Follow the
instructions furnished with the antifreeze.
Do not use automotive or windshield washer antifreeze in the
camper water system. These could be harmful if swallowed.
Winterizing with RV Antifreeze
1) Make sure the water pump switch is off.
2) Insert the hose from the winterizing valve into a
container of RV approved non-toxic antifreeze.
3) Turn the water heater bypass valve to Bypass
position and drain the water heater by opening the
safety relief valve.
4) Open faucets to relieve pressure. (Hot and Cold)
Open the hot and cold low point drains.
5) Drain the water tank by opening the tank drain and
leave open to drain completely.
6) After the system is completely drained, close all
faucets and turn off the low point drain valves.
7) Turn the winterize valve to “Winterize” position.
8) Turn ON the water pump switch.
9) Open the hot water faucet farthest from the water
tank. When antifreeze appears, let at least one cup
run down the drain to winterize the P-trap. Do the
same to all other water outlets, hot and cold,
including shower, toilet, and outside shower.
10) Turn OFF the pump switch.
11) Open a water faucet to relieve pressure, and then
close.
12) The procedure is complete.
Water Heater Bypass 2017 Models
The water heater bypass valve is located behind the water
heater and is used when winterizing the water system for
storage. By rotating the lever to the bypass position, antifreeze
will not enter the water heater requiring less antifreeze to
protect the water system plumbing. Follow the instructions
shown on the valve.
NOTE: Be sure to drain the water heater by opening the drain
plug at the bottom of the heater and open the pressure relief
valve.
To De-Winterize:
1) First, fill the water tank.
2) Turn the winterizing valve to normal flow position.
3) Turn the water heater bypass valve to “bypass”; this
will keep antifreeze from entering the water heater.
4) Turn ON the water pump switch.
5) Open the water faucet farthest from water tank,
catching antifreeze in a container for future use, until
clear water appears. Shut off the faucet. Do this to all
other faucets and the showerhead, including outside
shower.
6) Turn the water heater bypass valve to normal flow
position.
7) Open a hot water faucet until water appears.
8) Your system is now ready for use.
Reactivating Camper after Storage
The following procedure checklist assumes that you stored the
camper with care. If you didn’t and extensive freeze damage
or other serious deterioration may have occurred, please
consult your Nücamp RV Dealer Service Center for advice.
Outside Area
1) Thoroughly inspect the outside of the camper and
open all doors and compartments. Check for animals
or insect intrusion, water damage or other
deterioration.
2) Remove all appliance vent, ceiling vent and air
conditioner coverings. Be sure all furnace, water
heater, and refrigerator openings are clear and free of
debris or insect nests, webs, etc.
NOTE: Spiders and other small insects climb into
burner tube(s). The spiders create webs, build nests
and lay eggs. These webs and nests can be very
small, but they are very strong and can block the flow
of gas.
Mud Daubers are another insect to watch out for. It is
not uncommon for Mud Daubers to build their mud
Alde Relieve Valve
Hook up for winterizing
38
huts in places like the furnace exhaust ports. This can
be dangerous in two ways. First by causing a
restriction that could cause carbon monoxide to build
up on the inside of the camper, second, the same
restriction can also cause heat and flame problems
which could cause a fire. Both scenarios are
dangerous and can cause death.
3) Open vents and windows.
12-Volt System
1) Prior to the battery installation, check charge level.
Refill and recharge as necessary. Inspect cable ends
and ensure that terminals are clean and free of
corrosion. Place the battery into the compartment,
install tie downs, and connect cables. Turn battery
switch to “USE” position. Check battery condition on
monitor panel.
2) Be sure all 12-volt DC and 120-volt AC circuit
breakers are ON.
3) Inspect and operate all 12-volt lights and accessories.
120-Volt System
1) Inspect the 120-volt electrical system: Power cord,
converter, and outlets. If defects are found, refer
service to a Nücamp RV Dealer Service Center.
2) Prepare the AC generator (if equipped) for operation
following instructions in the generator operating
manual in your Owner’s Information Package.
3) Operate 120-volt AC appliances and air conditioner.
Fresh Water System
1) If the fresh water system has been winterized, drain
the antifreeze from fresh water system.
2) Turn the water pump on and open all faucets until
flow of antifreeze stops.
3) Do not let antifreeze stand on plastic sinks or outside
shower components or stains may occur.
4) Open the water heater bypass valves.
5) Flush and sanitize the fresh water system as outlined
in the “Fresh Water System” section.
6) Operate all faucets and fixtures in the fresh water
system. Check for leaks at all joints and fittings.
Repair if necessary.
Propane System
1) Turn on propane valve and inspect all pipes and
fittings in the propane system. Check for leaks as
outlined in the “Propane System” section.
2) Operate each propane appliance. Observe all burners
and pilot flames for proper color and size. If there are
any problems, refer to an authorized Nücamp RV
Dealer Service Center.
General
1) Install new 9-volt battery in smoke detector.
2) Check the monitor panel operation.
3) Open and operate vents and vent fans.
Maintenance
1) Check the sealant around all roof, body seams, and
windows. Reseal if necessary. See “Sealant renewal”
subsection of the “MAINTENANCE” section.
2) Lubricate all exterior locks, hinges, and latches.
3) Wash and wax the exterior. Inspect the body for
scratches or other damage. Touch-up or repair as
necessary.
General Maintenance
This section explains why it is important to keep your camper
well maintained, how to preserve the appearance of the
exterior and interior and to follow basic maintenance safety
precautions. Also included are several things you can do to
help prevent corrosion. This section also includes
Maintenance Schedules for when service should be performed
on your camper and instructions for simple maintenance tasks
you may want to take care of yourself. Regularly maintaining
your camper is the best way to protect your investment. Proper
maintenance is essential to your safety and will also reward
you with many years of trouble-free use of your camper. The
Maintenance Schedules specifies how often you should have
your camper serviced and what things need attention. It is
essential that you have your camper serviced as scheduled to
retain its high level of safety and dependability.
Keep accurate records of maintenance, service performed and
follow all owner obligations, as required, to keep warranty in
force.
Exterior Maintenance
Some exterior parts of your camper are made of fiberglass,
metal, rubber, and plastic materials. The finish on these parts
is durable, but not indestructible. Any material and finish will
deteriorate over time. Exposure to sunlight, moisture, and
airborne pollutants can chemically alter the composition of the
base and finish materials and cause dulling and fading of the
finish. Generally, changes in the finish due to the weather are
cosmetic. There are on the surface of the part and do not affect
its strength.
The best insurance against these effects is routine
maintenance. If the finish is not washed thoroughly and
waxed, the surface can deteriorate very rapidly. The following
guidelines can help you reduce these weathering effects
Wash the exterior at least once a month using a mild liquid
detergent. Never use strong abrasives to clean the exterior
surfaces. Wash your camper in a shady area, not in direct
sunlight. If the camper is parked in the sun, move it into the
shade and let the exterior cool down before you start.
Chemical solvents and strong cleaners can damage the siding,
roofing, metal, and plastic trims on your camper. Rinse the
camper thoroughly with cool water to remove loose dirt. Fill a
bucket with cool water. Mix in a mild detergent, such as
dishwashing liquid or a product made especially for auto or
RV washing. Wash the camper using the water and mild
detergent solution and a soft-bristle brush, sponge, or soft
39
cloth. Start at the top and work your way down. Rinse
frequently. Check the surface for road tar, tree sap, etc.
Remove these stains with tar remover or turpentine. Rinse it
off immediately so it does not harm the finish. Remember to
re-wax these areas, even if the rest of the camper does not
need waxing. When you have washed, and rinsed the whole
exterior, dry it with a chamois or soft towel. Letting it air-dry
will cause dulling and water spots. As you dry your camper,
inspect around the seals and repair as necessary.
Wax the exterior at least once a year, preferably twice. Use
automotive waxes or cleaners/polishes developed for use on
fiberglass boats, showers, and tubs. Be sure to follow the
directions on the wax container. Come cleaners and waxes are
recommended for use on only certain types of surfaces.
Exterior streaking is reduced with more frequent waxing. Do
not use abrasive cleaners or rubbing compounds. Always wash
and dry the whole camper before waxing it. Rubbing alcohol
can be used on caulking that show signs of yellowing.
You should clean your roof at least four (4) times a year. For
normal cleaning use a mild liquid detergent and water mixture,
or Murphy’s Oil Soap with a soft nylon brush or sponge. Do
not use solid or granulated cleaners, as they will mar the
finish. For more difficult stains, use a cloth dampened with
mineral spirits. DO NOT use mineral spirits in a large area or
allow it to soak into the roof membrane.
Roof is slippery when wet.
Exterior Graphics
The pressure sensitive vinyl graphics installed on the exterior
surface of your camper require little maintenance and should
be treated similarly to a painted surface. The following
cleaning and maintenance recommendations should be
followed to ensure the maximum appearance and performance
of your exterior graphics.
Wash your graphics with the same solution as noted above for
washing the exterior of your camper. Be sure to rinse
thoroughly.
Test any cleaning solution on a small section of the graphic
before using the cleaning solution on a larger surface. A nonabrasive cleaner, suitable for high quality painted surfaces, is
recommended. The cleaning solution should be neither high
acidic nor highly alkaline; a pH range of 3 to 11 is
recommended. The cleaning solution should be free of strong
solvents or alcohol. Avoid contact of window cleaners that
contain ammonia.
Damage Checks
It is important to periodically check the exterior for damage.
Pay attention to the following areas:
Waste tanks and plumbing lines.
Propane tanks and assembly.
Sealants around doors, roof, vents, and window.
Exterior lighting.
Sealant Renewal
The adhesives and sealants used in the construction of your
camper were developed to remain waterproof under sustained
effects of weather and vibration. However, even the finest
materials will eventually dry out and lose their effectiveness
under the constant heat of the sun, attack by other elements
and road vibration. This section outlines the procedures that
you must follow to maintain the weather-resistant integrity of
you camper.
Leak damage caused by neglecting to follow these procedures
may affect your warranty.
Your nüCamp RV Dealer can perform the resealing
inspection and work for you, and has current information on
sealants used in your camper and can recommend the
appropriate sealants if you prefer to do this work yourself.
Always use the recommended sealants.
To protect your camper from possible water intrusion damage,
your unit should be inspected thoroughly and resealed biannually. Inspect the sealant around the roof moldings,
windows, and doors at least every six months. If any of the
following are evident during inspection, the affected areas
must be resealed:
Weathering or drying of sealant.
Sealant cracked or peeling.
Voids in sealant.
Shrunken or separated sealant.
Clean all areas to be resealed with mineral spirits.
Make sure that all areas to be resealed are dry before
new sealant is applied.
Mineral spirits are a flammable liquid. Use extreme
care when handling. Do not expose to open flame,
sparks, or smoking materials. Do not use in
unventilated areas.
Check and tighten any loose fasteners. Be careful not
to over-tighten, or stripping will occur.
If you find any of the above:
If areas on the roof need to be resealed, remove any loose or
cracked sealant being careful not to damage the roof. Use a
wooden or plastic scraper that will not gouge, pierce, or
otherwise damage the roof. The roof can be cut or punctured
by sharp objects.
Apply the new sealant in a continuous bead along the seams
and flanges, being careful not to leave any voids. Apply
enough sealant to flow over the heads of all fasteners.
Allow at least 48 hours for the sealant to set completely (firm
and tack-free when pushed with the thumb) before washing or
waxing the camper.
Doors and Windows
Lubricate door hinges, locks, and window mechanisms
periodically with powdered graphite. Clean window frames
and tracks to ensure easy operation. Clean the glass windows,
inside and out, with a commercially available glass cleaner.
You can also use a mixture of one-part white vinegar to ten
parts water. This will remove the haze that builds up on the
inside of the glass windows. Use a soft cloth or paper towels
40
to clean all glass. Clean the seals with a damp cloth or mild
detergent every three to six months, taking care not to use
strong solvents, as they will damage the seals. A coat of
natural silicone lubricant applied after the seal has dried will
keep it flexible. This is a good practice for all the rubber seals
in your camper. If the camper is exposed to salt air, more
frequent lubrication will be required.
Acrylic Windows/Skylight
Keep your acrylic windows and/or skylight vent looking and
performing like new by using the proper care, products, and
techniques, and by understanding a little about the material
you are working with. Acrylic windows and/or skylight vents
can be scratched with a rough cloth, harsh soaps, or cleaning
products and these must be avoided. When cleaning a
window/skylight vent always remove as much abrasive dirt as
possible without touching the surface. It’s also a good idea to
remove jewelry, which can cause deep scratches. Ideally this
would involve flushing the surface with water and allowing
the accumulated bug residue to soak, possibly with a mild dish
washing liquid added to the water. Use a non-abrasive soap or
detergent and water. Use a soft sponge, cloth or chamois and
rinse often to keep it free of grit. Wash up and down or side to
side, never is a circular motion. After a final flushing with
more water carefully dry with a clean soft cloth, a good rule of
thumb is to gently (let the weight of the cloth do the work)
wick up the excess water on your first pass which will also
wick up any residual loose particles. With windows, start at
the top of the window and work down turning the cloth to a
fresh side after each pass. Again, do not use a circular motion
on the windows/skylight vent. Acrylic Cleaning Kits are
available from your Nücamp RV Dealer.
NOTE: Never use abrasive, caustic cleaners, alcohol, or
solvents as they can cause permanent damage to the finish.
DO NOT use Windex as it will damage the acrylic. Never use
any petroleum based cleaners, or caustic chemicals on your
windows/skylight vent.
DO NOT use WD-40 (as it is petroleum based). Never use a
razor blade, putty knife, or abrasive pad to clean your
windows/skylight vent. Do not use a high-pressure spray
nozzle when rinsing your windows/skylight vent after
washing. Avoid washing windows/skylight vent in direct
sunlight.
Freezing Weather
Vinyl seals around windows and doors should be cleaned
regularly and kept pliable by using a silicone spray or
lubricant. Follow the directions on the product container. Keep
screens, exit latches and window slides clean and free of
debris. Periodically test the operation of all windows and their
components. If you are unsure about the correct methods of
lubrication and adjustment, check with your dealer.
DO NOT cover emergency window(s). These exit windows
must remain accessible always. Be sure all occupants and
guests know which windows are the emergency exit windows
and understand how to use them.
Roof
Twice a year inspection of roof components is necessary to
ensure seams and seals are not cracked or worn. Proper
maintenance of seals is necessary to keep moisture from
entering and causing severe damage such as rot, mold, or
mildew. If you encounter dry, cracked or weathered seals,
reseal or replace as necessary.
Use extreme caution when storing items on the roof. The roof
can be very slippery when wet.
Jack Brackets
The corner jack brackets need to be inspected each time the
camper is to be loaded or removed from the truck. These
brackets can loosen and the seals separate during regular use
due to rocking, while loading or unloading or while the
camper is being stored. Retighten the bolts until they are snug
and reseal the brackets as needed. Do not over-tighten as this
can cause the fasteners to strip-out, creating the possibility of
losing the jacks during travel.
Camper Jacks
The internal parts of the jacks are permanently lubricated at
the factory and do not require any further lubrication. At least
once each camping season fully extend the jacks and clean dirt
and grime from outside of the inner tube. Coat the entire
outside of the tube with silicone spray lubricant. This will
protect the finish of the inner tube and provide lubrication
between the jack’s tubes. Clean dirt and automotive polish or
wax to the outer tube of the jacks to maintain the appearance.
Turnbuckles
Each time the turnbuckles are installed, and any time they
begin to squeak, place a few drops of oil into the turnbuckle
barrel at the captive hook end. This will reduce squeaking
caused when the turnbuckles dry out.
It is important that the turnbuckles be kept clean and protected
from corrosive agents, such as salt spray, acid, rain, etc. This
is best done by cleaning and waxing turnbuckles with a good
automotive wax or chrome polish.
Air Conditioner
The air conditioner mounting bolts should be checked for
tightness after the first 500 miles. Removing the interior
shroud and inspecting the four (4) bolts located in the corners
of the roof opening accomplishes this. Aside from securing the
air conditioner to the roof, these fasteners apply pressure to the
sealing gasket between the air conditioner and the top of the
roof. Loose fasteners could cause water intrusion around the
roof opening.
Overhead Vents
The vents can be cleaned from the top of the camper. Use
soapy water on the vent cover. The screens may be vacuumed
41
or lightly brushed to remove accumulation of leaves or other
debris. Lubricate the gears and mechanism yearly with a light,
water resistant grease.
Skylight
The skylight/s should be cleaned at least once a year. Rinse
the skylight/s with lukewarm water. Wash with mild soap and
lukewarm water using a soft cloth or sponge and gently wash
to loosen dirt and grime. DO NOT SCRUB or use brushes or
squeegees. Repeat rinse and dry with a soft cloth to prevent
water spotting.
Exterior Lights
Check the operation of your camper’s exterior lights prior to
each trip. This should also include your truck’s lighting. An
inoperative bulb or fixture can create an unsafe condition by
reducing your ability to signal your intentions to other drivers.
When replacing exterior bulbs, take care that the sealant
around the light is not disturbed. When replacing exterior LED
fixtures, ensure the new fixture is installed using a
recommended sealant. Your Nücamp RV Dealer can assist
you with a replacement of the fixture and/or provide
information on the appropriate sealants if you prefer to do this
work yourself.
Wiring
Make sure the connector-plug prongs and receptacles are
clean. Lightly coat all electrical terminal connections with
non-conducting (dielectric), light waterproof grease. Clean the
prongs with very fine sandpaper, being careful not to damage
the contact area.
Battery(s)
Your camper is outfitted with a battery(s) that operates
lighting, jacks, slide-outs, or other accessories. The battery(s)
may be kept charged either by the truck, by the generator or
shore power.
A disconnect switch is provided to disconnect the battery(s)
when you do not plan to be using the camper for an extended
period, such as seasonal storage.
The battery must be kept in a charged condition during
storage. The battery could freeze and break if it becomes
discharged.
Awning
An operating and maintenance guide for your awning/s
included in your Owner’s Information Package. It contains
instructions for opening and closing the awning, as well as
maintenance and care instructions.
Interior Maintenance
Interior Odor
New campers may have a strong odor and even cause eye
irritation when closed in hot weather. This is due to glues used
in the cabinetry and paneling. This condition passes with time
but in an extreme condition open the entry door and all
windows and allow the inside to air out for several hours.
Upholstery & Drapes
Draperies, mattress covers, upholstery and wall pads are
manufactured from quality materials and should be dry
cleaned only. Some dry-cleaning methods will damage vinyl
or plastic found on cushions and drapes. Be sure to consult
your local cleaners. Frequent vacuuming or light brushes
between cleanings will help prevent accumulation of dirt and
grime. Use of water based or detergent based cleaners may
cause shrinking. Water stains may become permanent. Minor
spills should be cleaned up quickly to avoid staining. The
affected area should be blotted, not rubbed, to prevent the
stain from working deeper into the fabric. On vinyl upholstery,
remove dirt and dust with a vacuum cleaner. Wipe the vinyl
with a soft cloth and dampen in a solution of mild soap and
water. Use the same solution with a soft-bristle brush on more
difficult spots. You can also use commercially-available spray
or foam-type vinyl cleaners.
Do not use lacquer thinner, nail polish remover, carbon
tetrachloride, gasoline, or naphtha for any cleaning purposes.
These products may cause damage to the material being
cleaned, and are highly flammable or poisonous.
Wall & Ceiling Panels
The paneling and ceiling of your camper may be any of
several finishes and textures. Never use harsh detergents or
abrasive cleaners on walls or ceilings. Most surfaces will clean
with a soft cloth moistened with mild liquid detergent in warm
water. Do not use large amounts of water, which could
saturate the material.
Floors & Carpeting
Vinyl flooring requires only washing and periodic waxing.
Vacuum the carpeting frequently to remove dirt. Ground-in
dirt will make the carpet wear our faster. Periodically
shampoo the carpet to keep it looking new. Use one of the
foam-type carpet cleaners on the market. Follow the
instructions that come with the cleaner, applying it with a
sponge or soft brush. Keep the carpeting as dry as possible by
not adding water to the foam.
Wood Product Care
Remove dust with a clean slightly damp cloth. Buff with a
soft, dry cloth. Never use harsh detergents and solvents.
Fiberglass Care
Do not use abrasive cleaners or scouring powders. Use of
abrasive cleaners will dull or damage the surface of this
product and could leave scratches. If material gets scratched,
easy polishing brings back the original shine. It is
recommended you use a gel cleaner or household cleaner
made for fiberglass and acrylic.
Do not use scouring pads, steel wool, “scotch brite” type
scratch pads, or any other abrasive scrubbers. Wipe only with
a soft cloth or sponge.
42
Laminate Counter Top Care
Use a mild dishwashing liquid with warm water to clean your
laminate tops. Use a soft cloth for both washing and drying.
Abrasive cleaners, steel wool or gritty cleaners will damage
the surface.
Refrigerator
Clean interior with mild soap and water after each trip. Defrost
freezer and empty ice trays. When defrosting, place dry towels
in the refrigerator to absorb the water. Place trays containing
hot water into freezer compartment. After defrosting (when
the freezer compartment and condenser are frost-free), remove
the damp towels and water trays and use a clean cloth towel to
dry off refrigerator. Leave the door open for a few hours after
cleaning.
Drains
If a stoppage develops in the sink or shower drain, DO NOT
use lye or any strong chemicals. Strong chemicals can harm
the plastic in your waste system. A standard wire drain cleaner
is recommended.
Shower Care
For routine cleaning use a non-abrasive cleaner. Household
fiberglass cleaners are recommended. Never use harsh
detergents or abrasive cleaners. Never use a razor blade or
steel wool to clean the surfaces.
Sink Care
Do not use abrasive cleaners or scouring powders. Use of
abrasive cleaners will dull or damage the surface of this
product and could leave scratches. If material gets scratched,
easy polishing brings back the original shine. It is
recommended you use a gel cleaner or household cleaner
made for fiberglass and acrylic.
DO NOT use scouring pads, steel wool, “scotch brite” type
scratch pads, or any other abrasive scrubbers. Wipe only with
a soft cloth or sponge.
Always use a cutting board or a sink protector when using
knives or sharp objects. It is recommended that you use
protective mats, racks, or dishpans to help protect your sink.
Always allow pans to cool before setting them in your sink
43
Maintenance Chart 1
Service to Be Performed
Each Trip
Before Use
At Set-Up &
Weekly
Monthly
Inspect wiring, connector plug and receptacles
X
Check exterior lighting
X
Inspect & tighten mounting bolts on each jack corner
X
Inspect & secure camper anchors
X
Test propane leak detector for proper operation
X
Test carbon monoxide detector for proper operation
X
Test smoke detector for proper operation
X
Inspect generator exhaust muffler & tailpipe clamps
X
Check fire extinguisher
X
Inspect/clean battery cables, terminals, tighten wing nuts
X
Check battery charge (in storage)
X
Check battery electrolyte (in use)
X
Test GFCI (ground fault circuit interrupter)
X
Wash exterior
X
Inspect water pump filter
X
Bleed propane tanks after filling per instruction label on tank/s
X
Inspect TV strap for secure fit and that TV tray latch is engaged
X
Maintenance Chart 2
*Item marked with asterisk requires special equipment and/or qualified LP technician
Service to Be Performed
Every Six Month
Yearly
& After
Prolonged Storage
Inspect camper jacks & lubricate per manufacturer's instructions
X
Inspect roof sealants (required)
X
Inspect compartment & access doors, moldings & window seals (required)
X
Inspect all hot, cold, & drain plumbing
X
Sanitize fresh water tank
X
Complete propane pressure check & system check *
X
Clean & lubricate overhead vents
X
Lubricate locks, hinges & hardware
X
Replace smoke detector battery
X
Inspect & tighten air conditioner mounting bolts
X
Lubricate TV antenna per manufacturers recommendations
X
Lubricate slide mechanism along each side of the slide arms
X
Wax Exterior X
44
Maintenance / Repair Schedule
Date
Maintenance/Service Procedure
Service Center Name/Address/Phone
Camper Loading & Checking
1) Load the camper onto the truck following the procedure in the “Loading and Unloading” section.
2) Check the operation of taillights, turn signals, backup lights, clearance lights, license plate lights, and emergency flashers.
Your camper should now be ready for a new traveling season. If you choose, your nüCampRV Dealer can double check your
preparation and correct any defects or make any necessary adjustments.
45
Exterior Sealant Chart
Coming soon
Schematics
Coming soon
Component Manufacturers Contact Information
These items have Standalone warranty coverage from the Component manufacturer.
(1) Axles (Dexter Axle) phone 574-295-7888 (http://www.dexteraxle.com/contact_us______)
(2) Tires (Tredit Tire) phone 855-8-TREDIT (855-887-3348) (warranty@tredittire.com)
(3) Radio/DVD Player/Monitor/Speakers (ASA Electronics) phone 877-305-0445 call for immediate Customer Service Support
and 877-845-8750 for Technical Assistance. (http://www.asaelectronics.com//customerservice)
(4) Hot Water/Heat (Alde) phone 360-608-4803 (http://www.alde.se/us/support/alde-service-locations/) or info@alde.us
(5) Batteries (Dealer Provided) contact your dealer.
(6) Power Converter (WFCO Distribution) phone 1-877-294-8997 (http://wfcoelectronics.com/contact/)
(7) Power Roof Vent (Atwood Mobile Fan-Tastic Vent) phone 800-521-0298 (ftvservice@atwoodmobile.com)
(8) Air Conditioners (contact the factory at 330-852-4811)
(9) Microwaves (Call the factory for contact information phone 330-852-4811)
(10) Stoves (Call the factory for contact information phone 330-852-4811)
(11) Refrigerator phone 1-800-543-1219 (http://www.thetford.com/customer-support/dealer-and-service-center-locator/)
info@thetford.com
Loading...
