nuPro XS-7500
Soundbase
Safety instructions
Operating manual
Technical data
Warranty terms
Page 2
Device approval and conformity
with EC directives
Nubert electronic GmbH hereby declares that this product complies with the
2014/53/EU directives, provided that it is installed and used in accordance with
the manufacturer‘s instructions. The full text of the EU Declaration of Conformity
is available at the following Internet address:
https://www.nubert.de/konformitaetserklaerungen/716/
• Do not change the serial number on the speaker. It is part of the operating
approval.
• If the loudspeaker is repaired or modied by workshops or other third parties
not authorized by Nubert, it loses its operating license.
• Only accessories and devices may be connected which in turn comply with all
legal requirements and are approved.
• The loudspeaker may only be used for the applications specied in the „In-
tended Use“ section
Intended use
This speaker is designed exclusively for sound reproduction in dry rooms. Use
the speaker only as described in this manual. Any other use (particularly safe-
ty-relevant or medical use, installation in open environment like IP-certied prod-
ucts) is considered improper and may result in property damage or even personal
injury. Nubert electronic GmbH does not assume any liability for damages caused
by improper use.
Safety instructions
The entire operating manual, in particular the safety instructions, must be read
in full before connecting and commissioning the device. For your own safety,
be sure to follow all warnings and safety instructions in this manual and on the
speaker. The user is not permitted to carry out any work on the loudspeaker
other than the described work. Keep this document so that you have access to
it at all times. Furthermore, it must also be handed over to possible re-owners.
Key to the symbols
The triangle symbol with exclamation mark (without additional comment)
indicates important instructions for commissioning, operation and maintenance
of the device.
The term Caution! next to the triangle symbol indicates a medium risk. Failure
to observe this warning may result in property damage.
The term Danger! next to the triangle symbol indicates a high risk. Failure to
observe this warning may result in death or personal injury
This symbol indicates that you must read and observe the operating in-
structions and the safety and warning notices in order to operate the device.
This symbol (triangle with lightning) warns of dangerous voltages inside
the enclosure and of hazards due to electric shock.
This symbol indicates that the device complies with electrical protection
class 2 and therefore does not require earthing.
Devices with this symbol may only be used in a dry indoor environment.
Equipment marked with this symbol must not be disposed of with house-
hold waste. Refer to the Disposal and Battery Return section at the end of this
manual.
General information
Neve
r leave the loudspeaker(s) unattended when in use!
Danger of electric shock!
To avoid the risk of electric shock, the speaker may not be opened by the
user. There are no user-serviceable parts inside the speaker.
Service work and repairs are reserved for qualied specialists authorized by
Nubert. If you need service, please contact Nubert electronic GmbH directly
([email protected])!
Danger of suffocation!
Never let children use or play with neither speaker, remote control or packaging
unattended. There is a risk that children will get caught in the packaging lm
and suffocate. Make sure that children cannot remove any small parts from the
devices! These parts, like the remote control battery, could be swallowed and
cause suffocation. In case of swallowing any parts, contact a doctor immediately!
Danger of injury or damage!
When moving the speaker, take care to avoid injury and damage!
Caution!
Since the speaker can only be completely disconnected from the mains at the
mains input on the rear of the unit or by pulling the mains plug from the socket, it
must be positioned so that you have free access to the mains input or mains plug.
If any of the following situations occurs, the loudspeaker must be switched off
immediately and disconnected from the mains. Contact Nubert electronic GmbH
([email protected]) immediately!
• The speaker has been damaged or has fallen down.
• Power cord or plug is damaged
• Objects or liquid have got into the loudspeaker
• The speaker has been exposed to excessive moisture or rain.
• The speaker does not work properly or exhibits a signicant reduction in per-
formance.
• The loudspeaker smells burnt, develops smoke or makes unusual noises.
Caution!
The drivers built into this loudspeaker generate a strong magnetic eld in their
immediate vicinity, which can impair or damage other devices. It is therefore
essential to keep magnetically sensitive devices away from this loudspeaker! Do
not place tube screens, notebooks, hard disks or the like on the speaker!
Only use accessories recommended by Nubert!
Installation instructions
Caution!
An unstable location can damage the speaker.
• Only place the loudspeaker on a at, stable surface and make sure that it
cannot be knocked over!
• Also make sure that no unintentional pulling can occur on the cables to avoid
knocking over the speaker or damaging the connection sockets!
• Keep strong mechanical shocks away from the loudspeaker!
Caution!
Excessive heat build-up inside the unit can shorten its service life or lead to re.
• Never cover the back of the speaker! Make sure that there is a clearance of at
least 10 cm and sufcient air circulation in the back area!
• Do not operate the speaker and remote control near heat sources such as
radiators or stoves!
• Do not set the speaker and remote control to direct sunlight.
• Do not expose to direct sunlight!
• Never place burning candles or similar open re sources on the loudspeaker!
Danger of explosion!
Installation in unsuitable locations can cause explosions. Do not use the speaker
or remote control
• in environments where there is a risk of re or explosion!
• at extremely low or extremely high temperatures!
• near ammable gases or vapours!
• near strong dust!
• near ammable materials!
nuPro XS-7500 · 12/2019 EN
!
!
!
!
!
!
!
!
2
!
!
!
Page 3
Danger of electric shock!
The loudspeaker carries mains voltage and voltages higher than 35 V AC or DC
inside. It has no special protection against the intrusion of liquids or objects into
the system. There is therefore a risk of lethal electric shock.
• Never touch the speaker with wet hands!
• Only use the speaker in a dry place!
• Do not operate it outdoors or in damp rooms!
• The loudspeaker must be protected from liquids of all kinds, including dripping
and splashing water.
•
Do not place any containers containing liquids (e.g. ower vases) on the speak-
er or in the immediate vicinity!
• If the loudspeaker is moved from a cold environment to a warm room, conden-
sation may form inside the unit. Wait at least six hours until the loudspeaker
has reached room temperature and is dry before switching it on!
• No objects or foreign bodies may get into the device.
• Should the loudspeaker come into contact with liquids or should objects have
got inside, please unplug the mains plug immediately and contact Nubert elec-
Danger of injury or damage!
For speakers with threaded bushings on the underside:
The threaded bushings may be used for upright mounting of the loudspeaker on
suitable base plates only. The threaded bushings on the underside of the loud-
speaker enclosures are not designed for tensile loads and must therefore not be
used as holders for hooks or similar devices in order to suspend the loudspeaker
cabinet. A falling speaker may cause serious injury and damage.
Connection instructions
General connection instructions
• Disconnect the mains plug before changing any wiring on the system!
• Make sure that all connections have been made correctly and that all plugs
are rmly seated in the sockets before connecting the speaker to the mains.
• Use only the intended cables or plug connections for the connections! Failure
to do so may result in damage or malfunction.
•
If you want to disconnect connections on the loudspeaker, always pull the plug,
never the cable!
• Ensure that all plugs are rmly seated in the sockets!
• Only use cables and accessories recommended by Nubert!
Danger of electric shock!
Faulty mains supply systems or excessive mains voltage can lead to electric
shocks.
•
All power supply or antenna systems connected to the loudspeaker must com-
ply with all applicable laws and regulations and be professionally installed by
an approved installation company.
• Use only the appropriate power cord to connect the speaker. Do not modify
the power cord or its plug.
• Make sure that the mains voltage at your location matches the requirements
of the loudspeaker! The correct power supply can be found on the label on the
back of the speaker. It must not be connected to other power supplies.
• Devices of Class 1 construction must be connected to the mains power socket
outlet with a protective earth connection. Make sure that the installation of the
protective earth is carried out correctly!
• When laying the power cables, make sure that they cannot be damaged (e.g.
by heating or mechanical stress)! Pay particular attention to the areas of the
connectors and distributors!
Caution!
Overvoltage in the power supply system (e.g. due to lightning) can damage or
destroy the device and power supply unit.
• An overvoltage protection element can provide a certain degree of protection
against excessively high voltages in the power grid.
• However, the greatest possible protection against damage can only be
achieved with the complete separation from the mains supply.In case of thun-
derstorms or danger of lightning strikes, disconnect the mains cable from the
socket and any antenna plugs from your hi- system!
• If the speaker is not used for a long period of time or is unattended, the power
supply should be disconnected. Disconnect the mains plug from the socket!
Remote control and battery
This product comes with a remote control and a battery. The following must be
observed when handling remote controls and batteries:
If the batteries are discharged, the range of the remote control will de-
crease signicantly. If this happens, replace the batteries immediately. Always
use high-quality CR2025 lithium button cells as replacement batteries. Make
sure that the polarity is correct when inserting the battery into the battery com-
partment!
Caution!
Improper handling can lead to material damage.
• Do not drop the remote control!
• Do not expose the remote control and battery to water or other liquids!
• Do not operate or store the remote control and battery in locations with high
humidity or high or low temperature!
Danger!
Leaking or exploding batteries can pose a health hazard and cause damage to
goods.
• If you do not use the device for a long time or if the batteries are depleted,
remove the batteries from the remote control to prevent discharge, leakage of
acid or explosions.
• Leaking batteries must be replaced immediately.
• If you nd a leaking battery, do not touch the leaking material and dispose of
the batteries immediately!
• Do not touch leaking batteries!
• Should your skin, eyes or mouth come into contact with the leaking material,
clean the affected area immediately with water and contact a doctor!
Danger! Do not ingest battery, chemical burn hazard!
Ingestion of batteries can cause severe internal burns and death within a short
time span.
•
Ensure that batteries do not get into your body by any means, in particular that
they cannot be swallowed!
• Keep new and used batteries away from children.
•
If the battery compartment does not close securely, stop using the product and
keep it away from children.
•
If you think that batteries might have been swallowed or placed inside any part
of the body, seek immediate medical attention!
Equipment marked with this symbol must not be disposed of with house-
hold waste. Refer to the Disposal and Battery Return section at the end of this
manual.
EN 12/2019 · nuPro XS-7500
!
!
!
!
!
!
!
!
!
3
Page 4
nuPro XS-7500 · 12/2019 EN
Unpacking and Scope of Delivery
Unpacking
Avoid using sharp or pointed objects when unpacking your speaker. Please keep the packaging in a safe place in case you need to
transport the speaker at a later date.
Scope of delivery
If the delivery is complete, it contains the following parts:
• 1 nuPro soundbase
• 1 Cloth grille
• 2 Out-rigger feet
• 1 Mounting kit (4 bolts, 1 hex key)
• 1 Remote control with battery
• 1 Mains cable, 3 m
• 1 HDMI ARC adapter
• Signal cables:
– Stereo jack cinch cable (3.5 mm jack cinch), 1.5 m
– Fibre optic cable with TOS-Link plugs, 1.5 m
– USB cable (Type A/Type B), 1.5 m
nuPro XS-7500 soundbase with cloth grille and out-rigger feet with mounting kit
Stereo jack cinch cable
(3.5 mm jack cinch), 1.5 m
Fibre optic cable with TOSLINK plugs, 1.5 m
USB cable (Type A/Type B), 1.5 m
4
Mains cable 3 m
HDMI ARC adapter
Remote control
Page 5
Mounting the out-rigger feet
!
Caution!
Be careful not to scratch the loudspeaker!
Don’t let any items fall into the bass reex ports!
Place the speaker upside down on a soft, non-scratching surface!
Place the out-rigger feet over the threaded bushings as shown in the
picture and mount the feet securely with the supplied bolts and hex
key. You can now turn the loudspeaker around, place it on its feet
and adjust the mini-spikes for a level, stable stand.
EN 12/2019 · nuPro XS-7500
Standard mounting: out-rigger feet pointing outwards
Mounting kit with one pair of out-rigger feet
1x hex key
mini-spike
4x hex
socket screws
2x Out-rigger feet
Low temperatures and Sound
When speakers are shipped and delivered during the cold months
of the year, it is imperative that they adapt to the temperature of
the living area. Low temperatures have a considerable inuence on
the moving parts of a loudspeaker such as diaphragm, voice coil,
bead and spider. The ability of these components to follow rapid
oscillations or to perform large excursions is thus signicantly restricted. This is not dangerous, but “frozen” speakers are far from
their acoustic peak.
Hence our tip: When your new speakers arrive on a cold winter’s
day, just give them a few hours to acclimatise. Your Nubert speakers will thank you with the superior sound quality you have come to
expect from us.
Alternative mounting: out-rigger feet pointing inwards.
This method is recommended if the XS-7500 needs to be placed on
a narrow surface or if heavy objects (more than 50 kg’s) needs to be
placed on the soundbase.
Setup
The nuPro-soundboard XS-7500 is a high-quality, very neutral active
stereo loudspeaker. They impress with an extremely homogeneous,
precise, and “direct” sound reproduction with the nest resolution in
the entire frequency spectrum.
However, even an “honest loudspeaker” is exposed to the manifold
inuences of room acoustics. In order to achieve the most natural
and true-to-life reproduction possible, please observe the following
general installation guidelines:
Due to the rear-facing bass reex ports, the XS-7500 should be
placed at least 5 centimetres from the rear wall in order to ensure
trouble-free operation and to avoid air ow noises. Some distance
to the back- and side walls also helps prevent an increase in the
bass- and fundamental ranges.
Cloth grille
The cloth grille protects the loudspeaker drivers (for example from
curious children who like to press in tweeter domes) and provides a
visual contrast for those who do not like the technical appearance
of loudspeaker drivers. It is carefully placed against the front of the
speaker and held in place magnetically. Please make sure that the
surface of the bafe is not damaged.
With the cloth grill removed, the loudspeaker sounds somewhat
brighter and clearer - the choice is yours!
When placed on a shelf, the best sound is achieved when the front
edge of the speaker is either ush with the shelf or protrudes slightly.
This allows the loudspeaker to radiate the sound freely into the room
and helps to avoid voices sounding like coming through a funnel.
Ideal horizontal listening area
The best listening experience is achieved directly in front of the XS-
7500. If you often need to sit off-centre and thus outside the optimum
listening area, we recommend that you compensate with the sound
controls.
Placing the speaker at the optimum height
The most natural sound is achieved when the tweeters are approximately at ear level. But even 30 degrees above or below the tweeter
axis, the sound is still homogeneous. If the XS-7500 is placed directly beneath your TV, you will in most cases be within the optimum
listening area already. If the speaker needs to be placed lower or
higher, it should ideally be angled so that the tweeters are aimed at
the listening position. If this is not possible, we recommend compensating with the sound-controls.
5
Page 6
nuPro XS-7500 · 12/2019 EN
Connections and application examples
All cables must be connected to the nuPro Soundbase before switching it on,
see also our separate Quick Start Guide.
UsingtheremotecontrolortheNubertX-RemoteApp,youcanselectwhichoftheconnected
devicesyouwanttohearfromtheinputsources(seepage8).
Bluetooth
TheconnectionoptionsofanuProXloudspeakeralso
includeaBluetoothinputforwirelessmusictransmission
fromasmartphone,tablet,orsimilardevice.
Wireless input
ConnectanothercompatibleNubertappliancewirelessly,forinstance
nuProXactivespeakers
nuConnectampXamplier
AUX input:
Source device with
analog line output,
for example
• CD player
• various network players
• PreamplierorAVreceiver
• Smartphones, tablets and
MP3playerswith3.5mmjack
headphonejack
• PCs/laptopsandTVswith3.5mm
jackheadphonejack.
Link Out
outputs the
currentaudiosignal,xedlevel.
Format:SPDIF
96KHz,24bit
AUX
L_in
SUB output:
Connection of an
active subwoofer
SPDIFinOut
Link
SUBR_in Optical1
Coaxial1 Coaxial2
2x SPDIF inputs:
Source devices with electrical digital output, e.g.
• CD player
• various network players
• satellitereceivers
• various radio transmission systems
Digital
USB
Optical2
2x optical inputs:
Source devices with optical
digital output e.g.
• various network players
(e.g.AppleTV)
• Bluetoothreceiver
• TV
• gamingconsole
SERVICE
(NubertService
PortSV1,5A
only)
Digital
USB input:
Source device with USB port such
as computer and laptop.
ThenuProXloudspeakerfunctions
asanexternalsoundcard.
(Seealsothenotesonpage7,sec-
tion USB Connection to Computers)
USB port
TheUSB-portprovides5 V/1.5 A
of power, providing power for
players (e.g. smartphones),
orwirelessradioreceivers.
Italsofunctionsasanadditional
digital audio input:
TheincludedHDMI/ARCadapter
isconnectedhere.
6
Page 7
USB-connection to a computer
Select the USB input on the nuPro master-loudspeaker.
Windows 10
Automatic setup
Connect the nuPro to your computer with a suitable USB cable
(included) and switch on the loudspeaker. Normally, Windows will
automatically install the correct driver and set the speaker as the
default playback device.
Selecting the playback device manually
If the loudspeakers are not automatically set as the standard
playback device or you want to select a different playback device,
either:
1) click on the
loudspeaker symbol in
the taskbar.
You can see the current
playback device above
the level adjustment slider.
Click on the device
and select the xCore
USB Audio device.
EN 12/2019 · nuPro XS-7500
Manually selecting the output format in shared mode
Windows allows you to set which sound output format should be
sent to the USB-DAC when operating in shared mode.
Open windows setting and navigate to
>System
>Sound
>properties
>advanced.
You can now select the output format from the drop-down menu.
Note: Playback from applications that uses the exclusive mode is
not affected by this setting. Here, the output settings are determined
by the application.
2) in Windows settings
under
> system
> sound
You can select a
playback device.
macOS
Automatic installation
Connect the nuPro X and the computer using the supplied USB
cable and turn on the loudspeaker.
Normally, the macOS will automatically install the correct driver and
set the speaker as the default playback device.
Manually selecting the output device
If the loudspeakers are not automatically set as the standard playback device or you want to select a different playback device,
please:
In the system settings, navigate to
>Hardware
>Sound
>output device
Manual driver installation
As an alternative to the windows driver, you can download and install a suitable driver from https://www.nubert.de/downloads/61/
Select the xCore USB Audio device.
7
Page 8
nuPro XS-7500
· 12/2019 EN
Remote control
The remote control of the nuPro allows direct access to the permanently required functions:
on/off
After switching on/off the mains switch, the nuPro is in stand-by or
auto-on mode. Use the on key to activate or deactivate the speaker.
Switching the speaker into standby using the app or the remote
control deactivates the automatic power-on feature.
volume and x (mute) keys
The volume can be adjusted with the volume keys. The mute x key
allows you to mute and unmute the speakers.
tone
The remote control also allows easy adjustment of the sound character. Pressing the tone-button activates the corresponding menu
and you can now toggle between bass, mid/high and loudness. With
the arrow-buttons above the tone level marking, you can adjust the
parameter currently selected, like raising or lowering bass intensity,
or adjust mid/hi frequencies up to +/- 10 dB. You can also turn the
loudness on and off.
For more information, refer to the sections tilt control and loudness
on page 14.
wide
By pressing the wide-button repeatedly, you can adjust the intensity
of the wide-effect between 0 (off) and 4 (maximum).
For more details regarding this special sound-stage expanding
DSP-algorithm, please refer to the section virtual sound-stage ex-
pansion on page 14.
wls
Wireless
Aux
analog
analog, wls, coax, opto, (bluetooth) and usb
The 6 buttons on the remote control below are for source selection.
By pressing the buttons for coax, opto and usb repeatedly, you can
switch between 2 functions (toggle).
p1 · p2 · p3
With these buttons you can directly recall 3 presets, which you can
make and save in the setup. Alternatively, a preset can be stored by
pressing and holding the respective button (see page 12).
nuPro X loudspeakers and nuPro soundboards
Remote control signals
The remote control signals from the
soundbars do not interfere with each other, making it possible
to use combinations of speakers and soundbars simultaneously
without accidentally operating the wrong speaker.
coax
opto
Coaxial 1
Coaxial 2
Optical 1
Optical 2
Bluetooth
USB
usb
Digital Port
nuPro Active speakers and
Nubert X-Remote App
As an alternative to the remote control, you can also control
the nuPro X-Series speakers with the Nubert X-Remote App,
downloadable to your mobile device free of charge via the App
Store or Play Store.
It offers the possibility to easily adjust all settings of the active loudspeakers from the listening position.
The app is intuitive and easy to use thanks to easy-to-understand
graphics.
With the X-Remote App, you can adjust all settings of the nuPro XS7500 from the comfort of your listening position. This is particularly
useful when using the X-Room Calibration function.
inuences often cause problems such as boominess or dips in
Room
the low-frequency range. The X-Room Calibration algorithm utilizes
the powerful DSP of the nuPro X-series to optimize the frequency
response in the low frequency range for an optimal listening experience with precise, dynamic bass.
Simply start the measuring procedure in the app from the listening
position. The XS-7500 now plays a test tone which is picked up by
the microphone of your smartphone. Based on the measured data,
the app analyzes and adjusts the low frequency response of the
XS-7500 so that you can enjoy optimal sound quality at the listening
position. You can switch the room correction on or off.
Attention: At present, the X-Room Calibration feature is iOS compatible only.
8
X-Room Calibration
Password entry:
The rst time you pair the X-remote app with a nuPro X device, you
will be prompted to enter a password. The default password is 0000.
A different password can be assigned in the menu to protect the
device from unauthorized access. If the device is reset to the factory
settings (default), the password is also reset to 0000.
Page 9
Wireless sound transmission between Nubert Wireless System products
Nubert X-platform based speakers and appliances can wirelessly
exchange audio- and control-information. These include nuPro X
loudspeakers, nuSub XW subwoofers and the nuConnect am-
plier. The appliance that transmits the signal is the Master, the
receiving appliances are the Slaves. In some appliances this is
precongured, others like the XS-7500 can be exibly congured.
Please refer to the section Setup on page 11.
Depending on which appliance is receiving the signal, please observe the following:
1.
Receiver: nuSub XW
Nubert XW-generation subwoofers are always precongured as
slaves (wls slave).
•
The Master appliance always transmits a full-range signal. Accordingly, crossover frequency and relative level must be set on the
subwoofer.
• The overall level is adjusted on the Master-appliance.
2.
Receiver: nuPro XS-7500 or nuConnect ampX
The nuPro XS-7500 and the nuConnect ampX remain independently
controllable in wls slave mode.
• The received signal is accessed by selecting the wireless (wls)
input.
• Level is set on the receiving device, independently of the Masterappliance.
3.
Receiver: nuPro X loudspeaker
Transmitter: nuPro XS-7500 or nuConnect ampX
No changes can be made to the conguration on the nuPro-X speaker once it is set to wls slave.
• Selecting the correct channel (left, right or mono) must be done
before the wls slave mode is selected, as no channel conguration
information is transmitted from the master-appliance.
• The relative level of the slave-loudspeaker(s) can be adjusted
in the sub-menu zone ctrl on the XS-7500 or nuConnect ampX.
Please refer to the section zone ctrl on page 11.
• The overall level is controlled from the Master-appliance.
4.
Receiver: nuPro X loudspeaker
Transmitter: nuPro X loudspeaker
In this most common conguration (see the owner’s manual for
your nuPro X speakers), all settings are made on the Master-loudspeaker.
No changes can be made to the conguration on the nuPro X
speaker set as wls slave, including level and channel selection.
EN 12/2019 · nuPro XS-7500
Further use cases
Augmentation through a pair of nuPro-X loudspeakers
(i.e. X-4000 or X-8000)
The nuPro Soundbase can be supported by a pair of loudspeakers
from the X-series in order to achieve a broader stereo image. The
loudspeakers are placed in the classic stereo triangle and connected wirelessly to the soundbase.
Set the corresponding channel, left or right, in the channel menu
on the loudspeakers you want to add. Now connect the speakers
to soundbase by selecting wls master in the setup menu of the
soundbase and wls slave on both loudspeakers.
The complete, combined system can now be controlled from the
soundbase. We recommend setting the soundbase to mono in the
channel menu in order to achieve a more precise, central vocal
reproduction.
The balance between the soundbase and the speakers can be adjusted in the zone ctrl menu on the soundbase. You can read more
about the menus on page 11.
Use with a subwoofer
If you want to use your XS-7500 together with a wired subwoofer,
you can connect it to the SUB Out output. This output provides the
subwoofer with a low-pass ltered, summed mono signal. You can
set the crossover frequency for the subwoofer in the menu advanced / subwoofer.
The cut-off frequency for XS-7500 is adjusted in the advanced /
system-hp menu (see page 11). The relative level of the subwoo-
fer must be set on the subwoofer itself.
Alternatively, the subwoofer can be connected wirelessly. Please
refer to the Receiver: nuSub XW chapter above.
9
Page 10
nuPro XS-7500 · 12/2019 EN
Menu navigation and settings
Pressing in the volume menu
will access the main menu.
Pressing this key will always take
you back to a higher menu level.
MAIN MENU SUB-MENUS
nuPro
By pressing
or you can access the different menus and
change their settings.
By pressing
Pressing the
you will enter a sub-menu.
key in the middle will conrm a selection you have
made or conrm the choice of a sub-menu. If the loudspeaker is
standby mode, you can activate it by keeping the button pressed
for 4 seconds.
><
>O<
When turning on the nuPro X, the display will show the nuPro
logo for 8 seconds before changing to the volume menu.
volume
input
sound
><
>O<
coax 1 -30dB
><
>O<
The volume menu shows the current input (here the coax 1
input) and volume.
You can adjust the volume using the
and keys:
Maximum level: 0 dB
Minimum level: -100 dB
><
>O<
coax 1
><
>O<
Use the and
aux: Analog line level input
keys to select the input source:
bluetooth: Audio streaming input
wireless: wireless input
coax 1, 2: electric digital inputs
optical 1, 2: optical digital inputs
usb: USB input
port: Digital input
><
>O<
mid high
><
>O<
mid hi 0.0dB
Use the
and keys to raise or lower the mid/high level by
><
>O<
up to 10 dBs. See also page 13, section Tilt control.
bass
><
>O<
bass 0.0dB
Use the
and keys to raise or lower the bass level
><
>O<
by up to 10 dBs.
1010
Continued
on page 11
balance
loudness
5-band eq
><
>O<
left
0.0dB
right
With the
and keys, a volume difference of up to 10 dB
><
>O<
can be set between the two speakers of a stereo pair.
><
>O<
><
>O<
loudness on
Use the
and keys to turn the loudness function on/off.
eq
By pressing the
><
>O<
><
>O<
1khz
+6dB–
+6dB–
0––––
0––––
–6dB–
–6dB–
▲
▲
key in the middle, you enter the eq settings.
><
>O<
Press again to exit. Use the and keys to select the
frequency band you want to adjust and and keys to
change the level.
Page 11
MAIN MENU SUB-MENUS
The sound main
menu, continued from
page 10
wide sound
EN 12/2019 · nuPro XS-7500
><
>O<
wide sound 0
><
>O<
In the sub-menu wide sound, you can adjust the strength of the
wide effect between 0 (off) and 4 (maximum) by pressing the
and buttons. For more details regarding this special
DSP-algorithm that expands the soundstage and provides a
greater sense of spaciousness, please refer to the section
virtual expansion of the soundstage on page 14.
setup
><
>O<
single
><
>O<
In this menu, you can set if and how a wireless connection to
other appliances in the Nubert X-range (e.g. nuPro-X speakers
or the nuConnect ampX) should be established.
If single is selected, the wireless connection is off and the
stand-by power consumption is < 1 Watt. This is the default
setting.
wls master
>O<
In order to stream music to another appliance from the sound-
><
base, select wls master on the soundbase and conrm by
pressing . On the receiving device, select wls slave and
conrm.
Please note: Selecting the correct channel in the channel submenu must be done before the wls slave mode is selected.
In wireless mode, the standby power consumption is
< 2.0 Watts.
wls slave
><
>O<
To enjoy music from another device (e.g.nuPro-X speakers or
the nuConnect ampX), select wls slave on the XS-7500 and
conrm with
On the transmitting device, select wls master
.
and conrm.
Select the wireless input (wls) to listen to the streamed signal.
In wireless mode, the standby power consumption is
< 2.0 Watts.
zone ctrl
Continued
on page 12
><
>O<
local spk
><
>O<
mute
><
>O<
The menu zone ctrl shows up when the XS-7500 is selected as
the wls master (more information above). In the sub-menu
local spk, you can mute the Soundbase by selecting mute and
conrming by pressing . Selecting unmute reactivates the
audio output.
In the sub-menu wireless, you
><
can mute wirelessly the connec-
>O<
wireless
><
>O<
mute
ted systems by selecting mute
and conrming by pressing .
><
>O<
unmute
Selecting unmute reactivates
the audio output.
zone level
><
>O<
level 0 dB
><
>O<
In the sub-menu zone level, you can adjust the relative level of
the wirelessly connected systems by +/- 10 dB.
1111
Page 12
nuPro XS-7500
· 12/2019 EN
MAIN MENU SUB-MENUS
bluetooth
channel
advanced
><
>O<
pair
><
>O<
Use the and keys to choose between pair and reset.
Pressing the key when pair is shown in the display starts the
pairing procedure and the loudspeaker can now be paired with
a compatible smartphone, tablet or computer. Pairing mode is
active for 60 seconds.
reset
><
>O<
Pressing the key when reset is shown in the display delete all
paired devices from the memory of the nuPro loudspeaker. This
can be necessary when more than 8 devices are stored.
><
>O<
stereo
><
>O<
Here you can set whether the Soundbase should play in
mono or stereo.
Wirelessly attached systems are not affected by this setting.
><
>O<
system-hp
><
>O<
hpf 10Hz
><
>O<
Here you can set the low-cut frequency of the nuPro. This is
particularly useful when used in conjunction with a subwoofer.
To set the cut-off frequency, select system hp by pressing .
You can now change the 10 Hz default value in 1 Hz steps by
pressing the the and keys.
subwoofer
analog gain
preset
><
>O<
lpf 140Hz
><
>O<
The subwoofer output only outputs low frequency sounds.
The desired cut-off frequency can be set under this menu item.
To do this, use the
and keys.
Note: The SUB out signal is a summed mono signal.
><
>O<
gain 0dB
><
>O<
The input sensitivity for the analogue AUX and XLR inputs can
be set to either 0 dB or +6 dB using the
><
>O<
preset 1
><
>O<
and keys.
Here you can recall
a previously saved
preset by selecting
preset 1, 2 or 3 and
key.
><
>O<
save as
conrm with the
><
>O<
save as p1
12
Continued on
page 13
To save a preset, select save as. Choose in which of the three
memories you wish to save your settings, using the
or
keys and conrm with the key. All settings in the menu
sound, system hp, subwoofer, analog gain and the (de-)
activation of the X-Room Calibration (Nubert X-Remote App)
are saved.
Page 13
MAIN MENU SUB-MENUS
The advanced main menu,
continued from page 12
display set
EN 12/2019 · nuPro XS-7500
><
>O<
content
><
>O<
volume
><
>O<
auto power
Display content sets
whether the display
shows…
light
Display light adjusts the
brightness of the display:
><
>O<
the volume menu
or the nuPro logo .
normal
normal
permanent full brightness
><
>O<
autodim
the displays dims
automatically after
10 seconds
auto off
the display turns off
automatically after
><
>O<
auto power on
><
>O<
10 seconds.
The nuPro’s electronics have an automatic standby function
that automatically switches the loudspeaker into power-saving
mode when it is not needed – and also switches it back on
again automatically when a signal is detected. If the menu item
off is selected here, this is automatically deactivated.
Note: For more information on the automatic standby function,
see page 13 in the Design and Engineering section
.
default
><
>O<
default to
factory setting?
><
>O<
This menu item is used to restore the loudspeaker to the factory
settings. Press the
button to conrm the reset operation.
Loading is displayed until the reset is complete.
Note: Alternatively, the reset can be performed at any time by
pressing the key for 6 seconds.
Note: If no settings are made, the display automatically changes back to displaying the volume or the nuPro
logo after 8 seconds. As the display changes, all settings made are automatically saved. However, if power is
disconnected before the automatic saving takes place, the last saved settings will be loaded on restart.
13
Page 14
nuPro XS-7500
· 12/2019 EN
Construction and technology
Tilt Control
The midrange/treble adjustment of the nuPro loudspeakers has the
characteristics of a so-called “Tilt control”. While standard treble controls “bend” the frequency response and thus produce colourations,
this control continuously affects the frequency response in a linear
fashion. This perfectly preserves the basic tonal character of the
loudspeaker and the harmony of the sound image. The Mid/Hi tone
control allows an increase or decrease of the frequency response
with a maximum of 10 dB at 20 kHz.
Analog gain
The input sensitivity for the analog inputs XLR and AUX can be
adjusted in 2 steps (0 dB / +6 dB).
Digital Signal Processing
For maximum delity, the signal path of a nuPro X loudspeaker
is kept virtually entirely digital: Digital input signals go straight to
the digital signal processor (DSP), which then handles frequency
distribution and optimization of the frequency response. Analogue
sources are rst converted to a digital signal by high-quality A/D
converters. The signal remains digital all the way into the power
ampliers in order to achieve the best possible precision and signal
to noise ratio.
Sound format
The nuPro X loudspeakers process signals at the digital inputs in
“PCM” format. It may therefore be necessary to adjust the settings of
players such as TV sets or game consoles accordingly. To do this,
select “PCM” as the output format in the playback menu. Please also
refer to the manual of your source device.
Turning off multiple nuPro X loudspeakers
If the XS-7500 is switched into stand by either the remote or the
auto-off function, all wirelessly connected loudspeakers are automatically set to stand by as well.
Latency
The nuPro X Soundbase has a very low latency of 7.6 ms when set
up as single or wls slave.
If the XS-7500 is used in the wls master conguration, the latency
increases to 27.5 ms in order to assure correct time-alignment between the master- and slave loudspeaker.
Virtual sound-stage expansion
A complex DSP-algorithm calculates and extracts additional spatial
information that can be added to the original signal. When added,
the soundstage is virtually broadened and expanded.
This effect can set to 4 different levels:
• Set to “0”, the effect is deactivated
• Set to “1”, the effect is soft
• Set to “4”, the effect is the most pronounced. This setting is recommended when a very expansive soundstage is wanted and
precise location is less important.
Auto-off function
The auto on/off function reacts differently, depending on the selected
input: If no signal is present at the analog input, the loudspeaker is
set to stand by after 20 minutes. As soon as an analog input signal is
detected, the speaker switches back on. At the other inputs, the activity of the connected source is monitored, allowing the loudspeaker
to switch off or on instantly. At the SPDIF, Optical, Port and AES/
EBU inputs, the presence of the digital data stream is monitored,
while at at the USB input the presence of USB supply voltage is detected. The standby power consumption depends on the operating
mode. See page 11, section setup.
Note: Modern computers often have USB sockets that deliver constant voltage (e.g. for charging a mobile phone) even when the computer is switched off. If you want to use the auto-on function of your
nuPro active loudspeakers in conjunction with the USB input, you
must use a USB connector that powers off with the computer.
Auto-on function
The nuPro speakers have an auto-on function that automatically
wakes up the loudspeaker from standby mode. This function is only
active if the loudspeaker was set to standby by the auto-off function. To wake up the loudspeaker, a signal must be present at the
input that was selected when the loudspeaker went into standby
(this function is not available at the Bluetooth and HDMI-ARC dongle inputs. If the speaker was set to standby using the remote control or the app, the auto-on function is disabled.
Loudness
This function can be used to make a volume-dependent frequency
response correction that compensates for limitations in the human
hearing. At low levels, human hearing is less sensitive in the bassrange. In order to compensate for this, the loudness function increases the bass-level with up to 10 dB when activated.
-10
-20
-30
-40
-50
Volume controller setting [dB]
-60
20 50 100 200 500 1k 2k 5k 10k 20 k
Frequency (Hz)
Frequency response correction relative to volume settings
14
Page 15
EN 12/2019 · nuPro XS-7500
Technical Data nuPro XS-7500
Principle Active Soundboard with
DSP technology for Hi-Fi and
multimedia applications
Bestückung 2x tweeters with
25 mm fabric dome
4x 119 mm midrange drivers
with polypropylene cone,
2x 204 mm bass drivers
with polypropylene composite cone
Power of built-in ampliers 4 x 90 Watt + 2 x 110 Watt
(rated power)
4 x 130 Watt + 2 x 150 Watt
(music power)
Frequency response 25 – 22 000 Hz +/- 3 dB
Input sensitivity 0.3 V
Max. Input 4.5 V
Standby power consumption 0.7 Watt (single)
1.8 Watt (wls master / wls slave)
Changing the mode of operation,
see page 11
Maximum sampling rates at
all digital connections 24 bit / 192 kHz
Radio frequency bands and radio transmitting power
Bluetooth module:
2402 – 2480 MHz 9,75 dBm / 9,5 mW
Network module
(wireless mode):
5180 – 5240 MHz 15,75 dBm / 37,6 mW
5736 – 5818 MHz 15,75 dBm / 37,6 mW
Supported SBC, AAC, aptX
Bluetooth Codecs aptXTM Low Latency
Hight
14.3 / 16.8 cm
(housing only/with out-rigger feet)
Width
120 / 128.7 cm
(Out-rigger feet outwards/inwards)
Depth
37 / 39 cm
(housing only/with amplier)
Weight 32.5 kg
for analog gain +6 dB
eff
rms
TM
HD,
Care and cleaning tips
!
Caution!
Improper handling of the speaker may result in damage.
• Always unplug the speaker before cleaning it!
• Before recommissioning, make sure that all connections are correct, that there are no short circuits and that the speaker is completely dry.
• Never use strong cleaning agents or solvents such as petrol, spirit or similar!
Enclosure
We recommend commercial window cleaner sprayed onto a cotton
cloth. This allows almost all ngerprints and dust to be easily removed. Alternatively, you can also use window active foam.
We advise against the use of microbre cloths! These can cause
mini scratches in the surface.
Diaphragms and Speaker Chassis
To remove dust from a loudspeaker chassis, a lint-free cotton cloth
is sufcient to wipe the membrane lightly with very little pressure.
The tweeters of all Nubert loudspeakers are equipped with a protective grille so that they can also be wiped off with low pressure. If
the dust cannot be completely removed, a make-up brush from the
drugstore is suitable.
Service
If you have any questions or problems during the commissioning of
your Nubert system, please do not hesitate to contact our service
team:
Phone:
0800 68 23 780 (toll-free, within Germany)
0049 7171 92690-118 (international)
E-mail:
[email protected]
Please have your customer number ready!
15
Page 16
Warranty terms
Your provider and contractual partner:
Nubert electronic GmbH, Goethestr. 69, 73525 Schwäbisch Gmünd,
Germany (German)
Phone: +49 7171 92690-0 · Fax: +49 7171 92690-145 · E-Mail: [email protected]
Managing Director: Günther Nubert · Register court AG Ulm, HRB 700296
Tax ID No.: DE 16758584 · WEEE Reg. No. DE 48888173
Nubert warrants the Nubert product described in this manual to the purchaser under the following terms and conditions.
The purchaser‘s statutory warranty claims, in particular for subsequent performance and, if applicable, damages in the event of defects, shall remain unrestrictedly with the
purchaser and shall be fully available to our customers.
1. The warranty period for the Nubert product and its electronic components described in this manual is 2 years from the date of delivery.
Your proof of purchase is the proof of guarantee.
2. Contents of the warranty claim
The guarantee applies to all parts and labour costs from delivery. It includes and is limited to the free repair or replacement of the defective part in the event of a material
defect in the goods (e.g. Material defect or manufacturing defect). In addition, Nubert shall bear the costs of the return shipment of the affected product from or to the curb
in the case of justifi ed warranty claims, provided that the goods are within the countries of the European Union and the shipment was previously agreed with Nubert. Additional services are possible as a gesture of goodwill in accordance with Nubert’s free discretion. For the duration of the guarantee, it is assumed that the material defect
was already present at the time of transfer of risk. Replaced parts become the property of Nubert. Warranty services do not extend the warranty period, nor do they set a
new warranty period in motion. The warranty period for installed spare parts ends with the warranty period for the entire device. The promise or the execution of warranty
services is made without recognition of a performance obligation according to statutory warranty law.
3. The warranty claim does not apply in the case of
• repair attempts of any kind not previously agreed upon with Nubert
• improper operating environment or improper storage (e.g. damage due to moisture or particularly high or low temperatures)
• improper transport packaging (the original transport packaging, correctly used, provides suffi cient protection)
• improper transport, if the transport was not previously agreed upon with Nubert (Nubert organizes the transport for you with Nubert selected
Transport company. You will receive return tickets with the corresponding postage paid returns).
• improper mechanical effects on the goods (e.g. on housing, switches, connection sockets or antennas)
• improper operation, improper mounting (e.g. switches, antennas) or improper connection (e.g. operation on defective or unsuitable amplifi ers or other source devices
with DC voltage or unusually high hum voltage at the source device output).
4. Disassembled components
Do not disassemble any components from our equipment and do not send in any such individual parts until you have contacted Nubert Service and agreed on this measure.
5. What to do in the event of a warranty claim
If possible, pack the defective device in its original carton with a copy of the purchase receipt and a meaningful description of the defect. Please note our shipping instructions. Please contact the Nubert team for a return or refund:
• Telephone within Germany 0800-68 23 780 (toll free) • Phone international: +49 7171 92690-118 • Fax: +49 7171 92690-145 • E-mail: [email protected]
Of course, you can also return your defective product to the Nubert Service in Schwäbisch Gmünd or Aalen:
• Nubert electronic GmbH, Goethestr. 69, D-73525 Schwäbisch Gmünd, Germany • Nubert electronic GmbH, Bahnhofstr. 111, D-73430 Aalen, Germany.
Shipping information: We recommend that you always keep the original carton, along with the protective foam inserts. Tip: Folding saves space! This is the only way to
ensure a safe return shipment in the worst-case scenario. If, in exceptional cases, you use a different packaging, it should protect professionally against the typical dangers
of shipping and have special protective cushions or equivalent protective devices. We would like to draw your attention to the fact that we accept no liability for damage
caused by improper packaging for which you are responsible!
For questions and individual advice, please dial our special numbers:
• Calls from Germany - Toll Free 0800-6823780
• Calls from abroad +49 7171 92690-118
Our hotline is available from
Monday to Friday from 10:00-18:00 and Saturdays from 9:00-13:00.
nuPro XS-7500 · © Nubert 12/2019 EN
Disposal and battery return
Environmental protection: Ingredients, e.g. chemical pollutants in old appliances, can damage the environment and health if stored improperly, in particular if they are
not shatterproof or disposed of properly by persons not authorised to do so. Especially in the case of illegal exports, there is no guarantee that the environment and human
health will be protected from damage. Old appliances can also contain recyclable raw materials, old appliances can be repaired or parts can be reused and thus considerably protect the environment. Old appliances must therefore not be disposed of with normal household waste or exported illegally. As an end user, you are legally obliged to
return or properly dispose of electrical equipment.
Batteries:
Ingredients, e.g. chemical type of batteries, can damage the environment and health if not stored and disposed of properly. At the same time, recyclable raw materials may
also be included. Batteries must therefore not be disposed of with normal household waste. As an end user, you are legally obliged to return used batteries. You can return
batteries after use to the seller or in the designated collection points (e.g. in public collection points in your municipality or in the trade) free of charge or send them back
free of charge. You can also send the batteries back to the seller free of charge by post, whereby any requirements of the dangerous goods law must be observed. The sale
at points of sale is limited to the quantities customary for end users for disposal as well as used batteries which the distributor carries or has carried in its product range.
• Battery return
The symbol with the crossed-out dustbin reminds you not to put batteries in the household waste.
Under this symbol you can also fi nd the following symbols with the following meaning about ingredients:
Pb = battery contains more than 0.004 mass percent lead, Cd = battery contains more than 0.002 mass percent cadmium,
Hg = battery contains more than 0.0005 mass percent mercury.
• Old appliances
Electrical and electronic equipment is also marked with the crossed-out wheelie bin symbol. The symbol indicates that you,
as the owner of this appliance, may not dispose of it with your household waste (grey bin, yellow bin, organic waste bin, paper or glass).
You can send the device to the municipal collection points to be collected separately from unsorted municipal waste for reuse. Used batteries and accumulators which are
not enclosed by the waste equipment shall be separated from it at a collection point prior to delivery.
Old appliances can also be returned to us directly in our shops or shipped back to us for disposal. Please send an Email to [email protected] for a free return shipping label.
You can also request this by calling +49 7171-92690118. Please then send the old device to the following address:
Nubert electronic GmbH, Goethestr. 69, D-73525 Schwäbisch Gmünd, Germany.
Please ensure that the old appliance is properly packaged for shipment so that breakage is avoided as far as possible and mechanical compaction or breakage can be ruled
out. The acceptance of waste equipment may be refused if there is a risk to human health and safety due to contamination.
Please note: You are responsible for the deletion of personal data on the waste equipment to be disposed of.
As of: 26.7.2019
Technical changes, errors and misprints excepted - You will fi nd our General Terms and Conditions (AGB) on our website: www.nubert.de/agb.htm
Nubert electronic GmbH
Goethestr. 69
73525 Schwäbisch Gmünd
Germany
E-mail: [email protected]
Hotline service:
• Calls from Germany - Toll Free 0800-6823780
• Calls from abroad +49 7171 92690-118
Loading...
