FOMA® SH905iTV

ISSUE DATE:

NAME:

PHONE NUMBER:

MAIL ADDRESS:

INSTRUCTION MANUAL

‘08.1

Easy Search/Contents/Precautions

Before Using the Handset

Voice/Videophone Calls

PushTalk

Phonebook

Sound/Screen/Light Settings

Security Settings

Camera

i-mode/i-motion/i-Channel

Mail

ppli

Osaifu-Keitai/ToruCa

1Seg

Full Browser/PC Movie

Data Display/Edit/Management

Music&Video Channel/Music Playback

Other Convenient Functions

Character Entry

Network Services

PC Connection Setting

Appendix/External Devices/

Overseas Use

Troubleshooting

Index/Quick Manual

DoCoMo W-CDMA System

Thank you for purchasing the FOMA SH905iTV. Make sure thoroughly read this manual and the manuals included with optional accessories before and during use to ensure proper operation. If any of the contents in this manual are unclear, please contact number listed in “General Inquiries” on the back of this manual. The FOMA SH905iTV is designed to make your everyday life more convenient. Careful use will ensure a long service life.

Using the FOMA terminal

Because it relies on radio signals, the FOMA terminal cannot be

used in places with no signal (such as tunnels, underground, or in buildings), in places with a weak signal or outside the FOMA service area. There may be times when the terminal cannot be used in the upper floors of a building even with no obstructions in sight. There may also be times when the signal is strong and you are not moving but the call is interrupted.

Make sure not to disturb others when using in public places, places

with many people or quiet places.

Because the FOMA terminal uses electrical signals, it is possible for

a third party to listen in on a conversation. However, the W-CDMA system automatically applies privacy to every call, a third party that tries to listen in only hears static.

The FOMA terminal converts conversations into a digital signal and

sends it to the other party over the radio. If the signal cannot be reconverted properly by such as moving to an area with a weak signal, the voice may not be heard correctly.

Keep a separate memo and note information (e.g. phonebook,

schedule, Text memo, Record message, Voice memo, Movie memo) stored in the FOMA terminal. DoCoMo shall not be liable for any loss of content due to a failure, repair, upgrade or other handling of the FOMA terminal.

Save the important data to the microSD Memory Card. Or, forward

and store the information such as a phonebook, mail and schedule to a PC using DoCoMo keitai datalink.

The user hereby agrees that the user shall be solely responsible for

the result of the use of SSL. Neither DoCoMo nor the certifier as listed herein makes any representation and warranty as for the security in the use of SSL. In the event that the user shall sustain damage or loss due to the use of SSL, neither DoCoMo nor the certifier shall be liable for any such damage or loss.

Certifier: VeriSign Japan K.K., Cybertrust Japan, Inc., GlobalSign

This FOMA terminal supports the FOMA Plus-Area and the FOMA

HIGH-SPEED area.

The FOMA terminal can be used only via the FOMA network

provided by DoCoMo and DoCoMo’s roaming area.

K.K., RSA Security Japan Ltd., Secom Trust Systems Co., Ltd.

Using this manual

This FOMA terminal supports Kisekae Tool (nP. 121). When the Custom menu image is changed by Kisekae Tool, some items in the Custom menu may be changed according to the menu history. In addition, some items cannot be selected even if the function numbers are entered. In this case, operation may not run as explained in this manual. Switch the menu screen to the Basic menu (nP. 41) or perform the Reset menu screen (nP. 123).

Download the latest information on this manual from the NTT DoCoMo web page. “User’s Manual (in PDF format)” Download

http://www.nttdocomo.co.jp/english/support/manual/ index.html

※ The URL and contents of this manual are subject to change

without prior notice.

Viewing/Searching this manual

This manual uses illustrations and icons to explain operations for proper phone use.

Icons and screens that appear on the display have been set by

default in accordance with the handset color (Kisekae Tool nP. 121). The explanations in this manual are based on the case when Kisekae Tool is set for the handset color “Silver White”.

The screens and illustrations in this manual are shown as

examples. The actual screens and illustrations may differ.

Searching this manual

Use the following ways to find explanations in this manual.

Index (nP. 506)

Easy search (nP. 4)

Indexed pages (nCover)

(See the next page for details)

Contents

Main functions

Menu list

Quick manual

The basic functions are explained briefly. Cut the Quick manual to keep as a reference when away from home. In addition, the Quick Manual “Overseas Use” is available. Use it when using the FOMA terminal overseas.

Search for function names or service names.

Search for frequently used or convenient functions using easy-to-understand language.

Search this manual using the index on the cover and the sides of pages.

nP. 6

nP. 8

nP. 446

nP. 518

Note that “FOMA SH905iTV” is referred to as the “FOMA terminal”

in this manual.

This manual describes functions using the microSD Memory Card.

Please note that microSD Memory Cards are sold separately. For details on microSD Memory Card nP. 325

This manual refers to microSD Memory Card as “microSD Memory

Card” or “microSD”.

This manual refers to “Osaifu-Keitai compatible i-appli with IC card

function” as “Osaifu-Keitai compatible i-appli”.

Reproduction of this manual in part or in whole is prohibited. The contents of this manual are subject to change without prior

notice.

Notation of keys and operation procedure

This manual refers to keys as simplified icons.

Actual key Notation in this manual

/1 (Refer to “Component names and functions” on

The notation and meaning of operation procedure are shown below.

In the Custom menu, select [Settings]/[Disp/ LED/Power saver].

For details on default settings nP. 446

Viewing the display

The explanations in this manual are based on default settings.

The actual screens may differ depending on settings changed after purchase.

When Flash movies and icons featuring animation effects are

displayed, screens may differ from those described in this manual.

P. 3 0)

Notation Meaning

In the Custom menu, select [Settings] with w and press t b select [Disp/LED/ Power saver] with w and press t.

As an example, how to look up the Alarm function using the Index, Easy search, and Indexed pages are explained below.

Active marker . . . . . . . . . . . . . . . . . 381

Display calendar/date . . . . . . . . 382

Set display category . . . . . . . . . 382

Additional services . . . . . . . . . . . . . 428

Reply message . . . . . . . . . . . . . 428

After-sales service . . . . . . . . . . . . . 489

Alarm . . . . . . . . . . . . . . . . . . . . . . . 384

Quick alarm . . . . . . . . . . . . . . . . 385

Reception/Recording reserve alarm

. . . . . . . . . . . . . . . . . . . . . . . 285

Schedule alarm . . . . . . . . . . . . . 389

Icon image . . . . . . . . . . . . . . . . 124

Key list . . . . . . . . . . . . . . . . . . . 125

Reset menu screen . . . . . . . . . 125

Set background . . . . . . . . . . . . 124

Battery

Battery pack . . . . . . . . . . . . . . . . 48

Charging. . . . . . . . . . . . . . . . . . . 49

Check battery level. . . . . . . . . . . 52

Times of use. . . . . . . . . . . . . . . . 49

Bookmark . . . . . . . . . . . . . . . . . . . 180

Attach to mail . . . . . . . . . . . . . . 181

Other features

Using the desktop clock . . . . . . . . . . . . . . . . . . (Desktop clock) 117

Saving battery power . . . . . . . . . . . . . . . . . (Light/Power saver) 119

Scanning QR codes and bar codes . . . . . . . (Bar code reader) 166

Playing back PC movie. . . . . . . . . . . . . (Internet movie player) 300

Using microSD Memory Cards . . . . . . (microSD Memory Card) 325

Ir-exchanging information . . . . . . . . . . . . . . . . . . .(Ir exchange) 341

Listening to music. . . .(Music&Video Channel/Music playback) 357

Setting the alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Alarm) 384

Using the calculator . . . . . . . . . . . . . . . . . . . . . . . . (Calculator) 396

Using the mobile phone overseas. . . . . . . . . . . (Overseas use) 435

Other Co

Checking settings for various functions . . . . . . <Check settings>380

Multiaccess . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Multiaccess>380

Using Multi Assistant (Multitask). . . . <Multi Assistant (Multitask)>380

Retrieving a recently used function or file. . . . . . <Active marker>381

Turning power on automatically . . . . . . . . . . . . <Auto power ON>382

Turning power off automatically . . . . . . . . . . . <Auto power OFF>383

Sounding alarm after set time passes. . . . . . . . . . . . . . . .<Timer>384

Sounding alarm at set time. . . . . . . . . . . . . . . . . . . . . . . .<Alarm>384

Managing schedules. . . . . . . . . . . . . . . . . . . . . . . . . . <Schedule>386

Accessing functions quickly . . . . . . . . . . . . . . . .<Shortcut menu>392

Content differs from actual pages in this manual.

Index nP. 506

Use this when you know the function or service name, or to search for function names that appear on the display.

Easy search nP. 4

Search for frequently used or convenient functions using easy-to-understand language.

Indexed pages nCover

Search for functions going in the order of “cover” b “beginning of the chapter” b “description page”. The beginning of each chapter shows a table of contents.

P. 3 84

Page that

explains “Alarm”

384

Other Convenient Functions

In the Custom menu, select [LifeKit]/[Timer/ Alarm]/[Alarm].

Select an alarm registration number/t.

Select [Enter Time]/enter a time (24-hour format)/t.

Select [Set repeat]/select a repeat method/t.

Select [Message]/enter a message/t.

Select [Contacts]/select the entry method.

 Select [Search phonebook]/select a name/t.  Select [Direct input]/enter a phone number/t.

Select [Alarm tone]/select an alarm tone/i.

To check an alarm tone: Select an alarm tone/t. To not sound an alarm: Select [Alarm tone]/[Not set].

Select [Alarm volume]/adjust the volume with u/t.

Select [Snooze setting]/[ON]/enter the interval

enter the number of times to ring alarm/t.

Set the alarm’s interval and the number of times to ring the alarm.

Select [Ring duration]/enter the alarm duration/t.

Press i.

ɡ Setting details screen

1Alarm set icon 2Time 3Repeat frequency

4Duration of alarm 5Snooze set icon 6Unsaved

Alarm

Sounding alarm at set time

Setting alarms

Note

Contacts cannot be set while keypad dial lock is set.

When multiple alarms are set to the same time, they are prioritized

in the following order.

• If recording and starting TV programs are set for the same time, Reception reserve alarm is not activated.

Once onlykSet day of weekjDaily

Related Operations

Set alarm from stand-by

In stand-by, enter a time (four digits: 24-hour format) / t/[Quick alarm].

Note (Related operations)

Schedule is registered for the current day (following day if the

time has already passed), [No category] for the category, and [Quick alarm] as the message.

Note

Priority (high b low)

Alarm function

Recording b Reception b Alarm b Schedule

1234

Related operations are explained in a simplified style.

This is the function name as it appears

in the index.

※ Content differs from actual pages in this manual.

Page number

Necessary information, precautions and other information for using functions are explained.

The explanations of screen display are shown. Refer to the screens while using the FOMA terminal (Text which is input, numbers and settings are examples).

The operation is detailed in steps.

Each operation is explained when the operations are different depending on the selected items.

Search by chapter from the index.

Additional information, precautions, and advice relating to operations are explained.

Easy Search

Easy Search/Contents/Precautions

Use this feature to find simple description for any function.

Useful functions for making calls

Notifying caller ID. . . . . . . . . . . . . . . . . . . . . . . . (Notify caller ID) 55

Putting a call on hold while talking . . . . . . . . . . .(Hold active call) 60

Switching to Videophone during voice call

. . . . . . . . . . . (Switching between voice call and Videophone) 61

Adjusting the volume of the other party’s voice

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Earpiece volume) 72

When unable to take a call

Placing a call on hold without answering the call. . . . . (On hold) 72

Indicating that it is necessary to refrain from talking on the mobile phone

. . . . . . . . . . . . . . . . . . . . . . . . . . . (Public Mode (Drive Mode)) 73

. . . . . . . . . . . . . . . . . . . . . . . . . . . (Public Mode (Power OFF)) 74

Recording phone messages

. . . . . . . . . . . . . . (Record message (voice/Videophone calls)) 76

Changing melody and illumination

Setting the ring tone for the caller. . . . . . . . . .(Select ring tone) 101

Changing the ring tone . . . . . . . . . . . . . . . . . . (Select ring tone) 110

Adjusting the ring tone volume . . . . . . . . . (Phone ring volume) 111

Muting the tone of keys pressed . . . . . . (Key/Standby i-motion) 112

Notifying incoming calls with vibration . . . . . . . . . . . . (Vibrator) 113

Setting Manner mode . . . . . . . . . . . . . . . . . . . . (Manner mode) 115

Changing the light color and pattern for incoming calls

. . . . . . . . . . . . . . . (LED color settings/LED pattern settings) 125

Changing the display

Meanings of display icons . . . . . . . . . . . . . . . . (View the display) 34

Switching the menu display . . . . (Menu settings and selections) 41

Changing stand-by wallpaper . . . . . . . . . . . . (Stand-by display) 116

Displaying the calendar. . . . . . . . . . . . . . . . . (Calendar display) 117

Changing the font (font style) . . . . . . . . . . . .(Font style setting) 126

Changing the font size . . . . . . . . . . . . . . . . . . . . . . . (Font size) 127

Keeping the display private . . . . . . . . . . . . . . . . . .(Private filter) 128

Using mail

Sending Deco-mail . . . . . . . . . . . . . . . . . . . . . . . . . (Deco-mail) 202

Sending images . . . . . . . . . . . . . . . . . . . . . . . (File attachment) 206

Sorting and saving mail automatically. . . . . . . . . . . (Sort rules) 221

Using the camera

Shooting panoramic pictures . . . . . . . . . . . . . . . . . (Panorama) 156

Changing the image size . . . . . . . . . . . . . . . . . . . . (Select size) 159

Saving to the microSD Memory Card. . . . .(Switch phone⇔SD) 164

Showing shot images . . . . . . . . . . . . . . . . . . . . . (Image Viewer) 309

Using the 1Seg

Watching 1Seg. . . . . . . . . . . . . . . . . . . . . . . . . .(Activate 1Seg) 278

Changing settings for video, voice, and sound

Recording a 1Seg program . . . . . . . . . . . . . . . . (Record 1Seg) 283

Setting timer to start or record a 1Seg program. . .(Booking list) 284

. . . (1Seg settings) 281

Securing the FOMA terminal

Keeping phonebook contents secret . . . . . . . . . . . .(Set secret) 100

Locking the FOMA terminal remotely in case of loss

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Omakase Lock)

Rejecting calls without caller ID

. . . . . . . . . . . . . . . . . . . (Reject by reason of non-disclosure) 141

Rejecting callers not saved in the phonebook

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Reject unknown) 142

Saving terminal data, such as phonebook from unexpected loss

. . . . . . . . . . . . . . . . . . . . . . . . . . . . (Data Security Service)

134

142

Other features

Using the desktop clock . . . . . . . . . . . . . . . . . . (Desktop clock) 117

Saving battery power . . . . . . . . . . . . . . . . . (Light/Power saver) 119

Scanning QR codes and bar codes . . . . . . . (Bar code reader) 166

Playing back PC movie . . . . . . . . . . . . . (Internet movie player) 300

Using microSD Memory Cards . . . . . . (microSD Memory Card) 325

Ir-exchanging information . . . . . . . . . . . . . . . . . . .(Ir exchange) 341

Listening to music . . . .(Music&Video Channel/Music playback) 357

Setting the alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . (Alarm) 384

Using the calculator . . . . . . . . . . . . . . . . . . . . . . . . (Calculator) 396

Using the mobile phone overseas. . . . . . . . . . . (Overseas use) 435

Updating the software . . . . . . . . . . . . . . . . . . (Software update) 491

Updating the security . . . . . . . . . . . . . . . . . (Scanning function) 497

*1 This service is a paid service. *2 This service is a paid service that requires subscription.

Frequently used functions are described in the Quick manual (nP. 518).

Easy Search/Contents/Precautions

Contents/Precautions

Easy Search/Contents/Precautions

Viewing/Searching this manual . . . . . . . . . . . . . . . . . . . . 1

Easy Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Main functions of the FOMA SH905iTV . . . . . . . . . . . . . . 8

Maximizing use of the FOMA SH905iTV. . . . . . . . . . . . . 10

Safety precautions (to be strictly followed). . . . . . . . . . 12

Handling precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Intellectual property. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Standard parts packaged with unit and main optional

parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Before Using the Handset

P. 29

Voice/ Videophone Calls

P. 57

PushTalk

P. 87

Phonebook

P. 97

Component names and functions, Display, TOUCH CRUISER pad, Menu, Supportbook, FOMA card, Battery pack, Power ON/OFF, Select language, Initial setting, Date settings, Notify caller ID, Own number, etc.

Make calls, Switch between voice call and Videophone, Redial/Received calls, Chaku-moji, WORLD CALL, In-car hands-free, Answer calls, Any key answer, Rotation-link reply, Set when folded, Earpiece volume, Answering hold/On hold, Public mode (Drive mode/Power OFF), Record message, Chara-den, Videophone settings, etc.

Send, Receive, PushTalk phonebook, Set PushTalk, etc.

Save, Group settings, Search, Edit, 2-touch dialing/2-touch mail, etc.

Sound/Screen/ Light Settings

P. 109

Security Settings

P. 129

Camera

P. 145

i-mode/ i-motion/ i-Channel

P. 171

Mail

P. 199

i-appli

P. 233

Osaifu-Keitai/ ToruCa

P. 261

Sound settings, Vibrator, Melody Call setting, Manner mode, Display setting, Power saver set, Kisekae Tool, Machi-chara setting, Themes, Change design of Basic menu, Illumination settings, Display image quality, Font setting, Private filter, etc.

Security code, Writing authentic, UIM Settings, Disable PIN lock, All lock, Omakase Lock, Self mode, Function lock, Keypad dial lock, Multi easy lock, Side key guard, Secret mode, Accept calls/Reject calls, Data Security Service, etc.

Shoot still picture, Shoot movie, Change settings, Bar code reader, Character reader (OCR), Card reader, etc.

View/Operate sites, i-mode password, Login information, Internet access, Bookmark, Screen Memo, Download, Set i-mode, SSL certificates, i-motion, i-Channel, etc.

Compose/Send, Deco-mail, File attachment, Save, Receive, Check new message, Reply/ Forward, Acquire/Check attached file, Mail Box, Mail setting, Message R/F, Emergency report “Area Mail”, SMS, etc.

Download, Run i-appli, Auto start, i-appli stand-by, Manage i-appli, etc.

iC transfer service, Start compatible i-appli, Retrieve ToruCa, ToruCa Viewer, ToruCa settings, IC card lock, etc.

1Seg

P. 273

Full Browser/ PC Movie

P. 293

Data Display/ Edit/ Management

P. 303

Music&Video Channel/Music Playback

P. 357

Other Convenient Functions

P. 379

Character Entry

P. 403

Channel setting, Activate 1Seg, Program guide, Record 1Seg/Record 1Seg as still picture, Booking list, Use Data broadcasting, TVlink, 1Seg settings, etc.

View web pages designed for PC, Set Full Browser, Internet movie player, etc.

Image Viewer, Edit image, i-motion player, Edit movie, Video player, Chara-den player, Machi-chara, Melody player, microSD Memory Card, Manage data, Ir exchange, iC transmission, Voice recorder, PDF Viewer, Document Viewer, Manga&BookReader, etc.

Music&Video Channel, Play back music, Music player, Manage data, Playback settings, SD-Audio, FM transmitter, etc.

Check settings, Multiaccess, Multi Assistant (Multitask), Active marker, Auto power ON/ OFF, Timer, Alarm, Schedule, Shortcut menu, Owner Information, Voice memo, Talk time/cost, Calculator, Text memo, Earphone/ microphone with switch, Reset settings, Delete user data, etc.

5-touch, Save phrases, Copy text, User Dictionary, Download dictionary, Guess conversion, 2-touch, etc.

Network Services

P. 413

PC Connection Setting

P. 429

Overseas Use

P. 435

Appendix/ External Devices/ Troubleshooting

P. 445

Index/Quick Manual

P. 505

Voice Mail, Call Waiting, Call Forwarding, Nuisance Call Blocking, Caller ID request, Dual Network, English guidance, Service number, Arrival Call Action, Remote control, Multi number, 2in1, OFFICEED, Additional service (USSD), etc.

Prepare for data communication, AT Commands, CD-ROM, DoCoMo keitai datalink, etc.

International Roaming (WORLD WING), Make calls, Answer calls, Network search mode, PLMN setting, Operator name display, Roaming guidance, etc.

Menu list, Dial key assignments, Multiaccess combinations, Multi Assistant (Multitask) combinations, Options and accessories, Troubleshooting, List of error messages, Warranty and after-sales services, Software update, Scanning function, Main specifications, etc.

Index, Quick manual, Quick manual “Overseas use”

Easy Search/Contents/Precautions

Main functions of the FOMA SH905iTV

Easy Search/Contents/Precautions

FOMA is the name of DoCoMo’s service based on W-CDMA, which is recognized as a global standard for third generation mobile communications system (IMT-2000).

The world of i-mode

i-mode is an online service used to access useful information from i-mode menu sites (programs) or i-mode supported sites, or easily send and receive e-mail.

Deco-mail/Deco-mail pictograph

Deco-mail/Deco-mail pictograph is available for i-mode mail. Change text color, character size, and background color in message text and insert images or moving pictographs.

P. 202, P. 407

Mega i-appli/Chokkan Game

Download i-appli from sites to play games and automatically update stock prices and weather information. Supporting large Mega i-appli lets you enjoy high-definition 3D games and long RPGs. Also, Chokkan Games to enjoy operations such as “tilting” and “shaking (or swinging)” the mobile phone are supported. The speech recognition is also supported on FOMA SH905iTV, and therefore the operation responding to the voice is available.

P. 234, P. 238

HIGH-SPEED area supported

FOMA HIGH-SPEED area is supported so that high speed communication is available with download speed of up to 3.6 Mbps and upload speed of up to 384 kbps. nP. 430

International roaming

The same FOMA terminal, phone number and mail address as those used in Japan are available overseas (supporting 3G area). In addition, voice/Videophone calls, i-mode, i-mode mail, SMS and network services are available. Moreover, a speech translation for SH, which translates the voice spoken in Japanese to English and the voice spoken in English to Japanese, is pre-installed.

P. 248, P. 436

Chaku-uta full®/Uta-hodai/Music&Video Channel*/ video clip

* This service is a paid service that requires subscription. Supporting Chaku-uta full downloaded in whole and Uta-hodai with which you can enjoy your favorite songs as much as you like at flat rate using only the mobile phone. Also, Music&Video Channel is supported so that music programs can be automatically downloaded at night and enjoyed if the setting is made in advance. Enjoy the programs with movies on FOMA SH905iTV. In addition, i-motion of up to 10 MB is supported so that a video clip to enjoy a music clip of one entire song is also supported. nP. 358, P. 364, P. 370 “Chaku-uta full” is a registered trademark of the Sony Music

Entertainment (Japan) Inc.

with which one song can be

Osaifu-Keitai/ToruCa

Download Osaifu-Keitai compatible i-appli to deposit electronic money to the IC card in the FOMA terminal, check your balance or view usage history from sites. Moreover, iservice, is pre-installed. This terminal also supports “iC transfer service” that makes transferring data in the IC card easier when the FOMA terminal is changed into a new model. ToruCa is an electronic card available from scanning device and sites. Easily share using mail or Ir exchange. nP. 264

ppli for “DCMX”, a DoCoMo’s credit

P. 250, P. 262

Kisekae Tool

Download the screen of your favorite character, etc. and change the screens such as the stand-by display and menu screens collectively. With FOMA SH905iTV, sort the order to display the menus according to the usage frequency and customize the menu screens. nP. 121

Security Settings

■ Omakase Lock*1 nP. 134

The FOMA terminal can be locked by request when it is lost. The lock can be disabled also by request. Refer to the back cover for details on inquiries. Omakase Lock is a paid service *1 Omakase Lock is a service to lock the handset by the request of

the subscriber. Please note that the lock service can be applied by a request of the subscriber even if the subscriber is not a user of the FOMA terminal.

*2 If Omakase Lock is subscribed while or at the same time as when

the use of FOMA terminal is suspended, the usage fee of Omakase Lock is not charged.

Numerous network services

SMS nP. 229 Voice Mail Service (monthly fees apply) nP. 414 Call Waiting (monthly fees apply) nP. 416 Call Forwarding Service nP. 417 Nuisance Call Blocking Service nP. 418 Dual Network Service (monthly fees apply) nP. 420 2in1 (monthly fees apply) nP. 423

■ Data Security Service nP. 108, P. 142

By using this service, phonebook, images, or messages in the phone can be saved in the Data Storage Center, and the lost data can be restored from the data saved on the network when the phone is lost. In addition, the data saved in the Data Storage Center can be edited and managed using a PC. The edited data can be reflected to the phone. Refer to “Mobile Phone User’s Guide [i-mode] FOMA version” for precautions and details on the Data Security Service and the back cover of this manual for inquiries. This service is a paid service that requires subscription.

Easy Search/Contents/Precautions

■ 3.2 inch full WVGA high-definition large display LCD

Enjoy high quality view of 1Seg, shot still pictures and movies, etc. on the 3.2 inch wide screen. The wide screen also let you enjoy lively i-appli games. In addition, the brightness sensor adjusts the brightness of the backlight according to the detected surrounding light. This is useful for power saving proposes. nP. 121

■ TOUCH CRUISER pad

In the Custom menu, i-mode or Full Browser, put a finger on the TOUCH CRUISER pad and move the pointer to select an item with double-tapping. Alternatively, move the cursor or scroll the screen instead of using Multi-guide key. nP. 41 In addition, Writing authentication is available. nP. 132

■ Internet movie player

Replay streaming of a PC movie from Full Browser. Enjoy assorted contents such as news and sports with high-quality images. nP. 299

■ Manga&BookReader

Read an e-book/e-dictionary/e-comic saved to the microSD Memory Card on the FOMA terminal. In addition, enjoy an e-comic downloaded from sites. nP. 352

■ FM transmitter

Play sound and music of 1Seg or Music&Video Channel of the FOMA terminal with a receiver such as an FM radio or an in-vehicle FM tuner. To do this, transmit the sound and music from the FOMA terminal with FM radio waves and receive the radio waves with the receiver.

P. 378

Maximizing use of the FOMA

During Videophone calls

(J)

Easy Search/Contents/Precautions

SH905iTV

The functions of the FOMA SH905iTV are described below.

Videophone nP. 58, P. 61

Have conversations with the other party who is far away while viewing each other’s image. In default settings, the other party’s voice is played through the speakers. Start conversation as it is. In addition, switch a voice call to a Videophone call during a call.

i-Channel nP. 196

Receive graphical information such as news and weather. Select a channel from the list to retrieve detailed information made with Flash (nP. 174). This service is a paid service that requires subscription. ※ i-Channel is only available in Japanese.

1Seg

■ 1Seg nP. 278

Watch “1Seg”, which is digital terrestrial broadcasting for mobile devices.

■ Video nP. 283, P. 309, P. 321

Record movies and a scene as a still picture for 1Seg program being played. Watch the recorded movies and still pictures with the FOMA terminal.

■ Multi Window nP. 282

While watching 1Seg on Multi Window, use another function.

■ TV timer and Recording timer nP. 284

Set timer for starting or recording TV programs.

PushTalk nP. 88

Simply select the other party from the PushTalk phonebook and press the PushTalk key to communicate with multiple people at once (up to five including yourself).

2in1 nP. 423

2in1 is a service that two phone numbers and two mail addresses can be used on one mobile phone with dedicated mode function as if two different mobile phones are used. Phonebook, mail box, call/ received history, stand-by display, etc. can be used separately in “A mode” and “B mode” on one mobile phone and also be used in “Dual mode” that can control both A and B modes simultaneously. This service is a paid service that requires subscription.

A mode

Phone number: 090-AAAA-AAAA Address: XXA@docomo.ne.jp Phonebook: For A mode

Make a call or send a mail in A mode

Phonebook A Mail BOX A Redial A Voice Mail A

...

Dual mode

B mode

Phone number: 090-BBBB-BBBB Address: XXB@docomo.ne.jp Phonebook: For B mode

Make a call or send a mail in B mode

Phonebook B Mail BOX B Redial B Voice Mail B

...

Phonebook A/B Mail BOX A/B Redial A/B Voice Mail A/B

...

Music playback

■ Music&Video Channel nP. 358

Your favorite music programs are automatically distributed at night. The programs are automatically updated on a regular basis. Enjoy the latest music information at any time.

■ Music player nP. 364

Play back Chaku-uta full® downloaded from sites or Internet web pages and WMA file transferred with Napster

using Music player. Uta-hodai is available. Also play back the data saved to the [Multimedia] folder of i-motion.

■ SD-Audio nP. 375

Use SD-Jukebox and a PC or other devices to save songs from a CD to the microSD Memory Card and play on the FOMA terminal.

Chaku-moji nP. 64

While making a call and ringing the other party, display a message on the other party’s receive display. Viewing the message, the receiver side can know the points and feeling of the other party in advance.

Easy Search/Contents/Precautions

Safety precautions (to be strictly

Easy Search/Contents/Precautions

followed)

Before use, read these “Safety precautions” carefully and use your

FOMA properly. Keep this manual in a safe place for future reference.

These safety precautions contain information intended to prevent

bodily injury to the user and to surrounding people, as well as damage to property, and must be observed at all times.

The following symbols indicate the different degrees of injury or damage that may occur if information provided is not observed and the FOMA terminal is used improperly.

This symbol indicates that

Danger

Warning

Caution

“death or serious bodily injury may directly and immediately result from improper use”.

This symbol indicates that “death or serious bodily injury may result from improper use”.

This symbol indicates that “bodily injury and/or property damage may result from improper use”.

The following symbols indicate specific directions.

Indicates a prohibited action.

Indicates not to disassemble the device.

Indicates not to handle the device with wet hands.

Indicates not to use the device near water or get it wet.

Indicates that instructions specified are compulsory (must be followed).

Indicates that the power cord must be unplugged from the power outlet.

“Safety precautions” is explained in the following six sections.

Handling the FOMA terminal, battery pack, adapters (chargers),

and FOMA card (general). . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 13

Handling the FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . . P. 14

Handling the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 17

Handling the adapters (chargers) . . . . . . . . . . . . . . . . . . . . . . . P. 18

Handling the FOMA card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 19

Handling mobile phones near electronic medical equipment

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 19

Handling the FOMA terminal,

Danger

Warning

battery pack, adapters (chargers), and FOMA card (general)

Do not use, store, or leave the FOMA terminal, battery pack, adapters (chargers) or FOMA card in locations subject to high temperatures, such as near a fire, in direct sunlight, or inside a car on a hot day.

The FOMA terminal may malfunction or become deformed. In addition, the battery pack may leak, overheat, explode, catch fire or suffer performance loss and a reduced service life. Part of the casing may also become hot and cause burns.

Do not attempt to disassemble or modify. In addition, do not attempt to solder.

May cause accidents such as fires, bodily injury, electric shock or malfunction. In addition, the battery pack may leak, overheat, explode or catch fire.

Do not get the FOMA terminal, battery pack, adapters (chargers) or FOMA card wet.

Contact with water, pet urine, and other liquids may cause overheating, electric shock, fire, malfunction or bodily injury. Be attentive to where and how you use the handset.

Use only the battery packs and adapters (chargers) specified by the DoCoMo group companies for use with the FOMA terminal.

The use of devices other than those specified may cause the FOMA terminal, battery pack or other devices to leak, overheat, explode, catch fire or malfunction.

Battery Pack SH15 Desktop Holder SH17 FOMA AC Adapter 01/02 FOMA DC Adapter 01/02 FOMA Dry Battery Adapter 01

FOMA USB Cable with Charge Function 01

FOMA Portable Charging Adapter 01

※

For information on other compatible products, contact a DoCoMo Shop or retailer.

Do not place the FOMA terminal, battery pack, adapters (chargers), or FOMA card inside cooking appliances such as microwave ovens or pressure cookers.

The battery pack may leak, overheat, explode or catch fire, and the FOMA terminal and adapters (chargers) may overheat, emit smoke or catch fire. The internal circuitry may also be damaged.

Do not throw or otherwise subject to strong force or impacts.

The battery pack may leak, overheat, explode or catch fire. Other equipment may also be damaged or cause a fire.

Do not allow conductive materials (such as metal objects and pencil lead) to come into contact with the charger terminal or external device terminal. In addition, do not insert such objects.

The battery pack may short-circuit and cause a fire or malfunction.

Make sure to turn off the mobile phone in locations such as gas stations where flammable gas is generated. In addition, do not charge the battery. It may cause a gas explosion or fire.

To use Osaifu-Keitai in locations such as gas stations, make sure to turn off the power in advance (If the IC card lock is set, disable the lock before turning off the power).

Easy Search/Contents/Precautions

Continued on next page

If you notice anything

Caution

Warning

unusual, such as an unusual

Easy Search/Contents/Precautions

odor, overheating, discoloration or deformation during use, charging or storage, immediately follow the instructions below.

1. Unplug the power cord from the outlet or cigarette lighter socket.

2. Turn off the FOMA terminal.

3. Remove the battery pack from the FOMA terminal.

Continued use (charging) may cause overheating, explosion, or fire. In addition, the battery pack may leak.

Do not leave the FOMA terminal on unstable surfaces, such as on a wobbling table or sloped surface.

The FOMA terminal may fall and cause injury or be damaged.

Do not store the FOMA terminal in locations that are subject to dust, humidity or high temperatures.

May cause a malfunction.

If being used by a child, have a guardian teach them the proper handling procedures. In addition, check that the child is using the FOMA terminal as directed.

May result in bodily injury.

Keep the FOMA terminal out of the reach of young children.

A young child may swallow components or suffer other bodily injury.

Be very careful when using the FOMA terminal connected to adapters (chargers) repeatedly or for long periods of time.

The FOMA terminal, battery pack or adapters (chargers) may become warm if ior 1Seg is used for a long time while charging. Exposure to high temperature areas for a prolonged period of time may cause skin irritations, itchiness, or low-temperature burn in some people.

ppli, Videophone,

Handling the FOMA terminal

Do not aim the Ir (Infrared) data port towards the eyes.

May cause eye injury. In addition, do not aim or direct the Ir data port towards another Ir device as this may cause the device to malfunction.

Do not put the FOMA terminal in the place where it could be affected by an expanded airbag, e.g., on the dashboard.

If the air bag inflates, the FOMA terminal may strike you or others around you, resulting in bodily injury or damage to the FOMA terminal or other property.

If you are using electronic medical equipment, do not put the FOMA terminal in your breast pocket or in the inside pocket of your jacket.

Using the FOMA terminal in close proximity to electronic medical equipment may cause the equipment to malfunction.

Do not allow water or other liquids, metal, flammable material, or other foreign objects to enter the FOMA card or microSD Memory Card port on the FOMA terminal.

May cause a fire, electric shock or other malfunctions.

Do not shine the light at anyone driving a car or other vehicles.

This may prevent a driver from driving safely and cause a traffic accident.

Turn off the FOMA terminal in

Caution

areas where the use of mobile phones is prohibited, such as in aircraft or hospitals.

The FOMA terminal may interfere with the operation of sensitive devices and electronic medical equipment. In addition, if Auto power ON function is set to ON, disable this function before turning off your mobile phone. Follow the instructions given by the respective medical facilities regarding the use of mobile phones on their premises. In addition, actions such as speaking on a mobile phone aboard aircraft are prohibited and may be punishable by law.

During a call in which Hands-free is set, keep the FOMA terminal away from the ears. When you attach the earphone/microphone to the FOMA terminal to play games or music, do not make the volume too loud.

Excessive high volume may damage your hearing. Also it may prevent you from hearing the ambient sounds and cause an accident.

If you have a weak heart, take extra precautions when setting functions such as the Vibrator and Ring tone volume for incoming calls.

Various settings may have effects on your heart.

If you hear thunder while using the FOMA terminal outdoors, put the antenna back into the FOMA terminal, immediately turn it off and move to a safe location.

There is a risk of being struck by lightning and suffering electric shock.

Turn the FOMA terminal off near high-precision electronic devices or devices that use weak electronic signals.

The FOMA terminal may interfere with the operation of sensitive electronic equipment.

Take particular care with the following devices:

Hearing aids, implanted cardiac pacemakers, implanted cardioverter-defibrillators, or other electronic medical equipment. Fire alarms, automatic doors, and other equipment controlled by electronic signals. If you use an implanted cardiac pacemaker, implanted cardioverter-defibrillator or other medical equipment, contact the respective manufacturer or vendor to check whether the operation of the equipment is affected by signals.

In case that the display part or camera lens is damaged, make sure to pay attention to a broken glass and the exposed inside of the FOMA terminal.

The surface of the display is covered by a protective film or the surface of camera lens are covered by a plastic panel so as to minimize the possibility of glass scattering. However, touching the broken display or camera lens may cause injury.

Do not swing the FOMA terminal by its antenna, strap, etc.

The FOMA terminal may strike you or others around you, resulting in bodily injury or damage to the FOMA terminal or other property.

Do not use the FOMA terminal in area with many people.

The antenna may strike others, resulting in an accident such as bodily injury.

Do not use the FOMA terminal with the damaged antenna.

Touching the antenna may cause an accident such as burn or other injuries.

Continued on next page

Easy Search/Contents/Precautions

When using Motion

Easy Search/Contents/Precautions

tracking, confirm the safety of surroundings, hold the FOMA terminal securely and do not swing it around more than necessary.

Use Motion tracking to operate by tilting and shaking (or swinging) the FOMA terminal. The FOMA terminal may hit people or objects, if shaken (or swung) too much, and cause a serious accident or damage, etc.

If using Motion tracking with the FOMA terminal to which metallic straps or others are attached, be careful not to hit people or objects with the straps.

Resulting in bodily injury or damage to the FOMA terminal or other property.

Never place a magnetic card near or in the FOMA terminal.

The stored magnetic data in cash cards, credit cards, telephone cards, floppy disks, etc. may be erased.

Never place magnetized items near the FOMA terminal.

Putting highly magnetized items closer may cause a malfunction.

If the display is broken and the liquid crystal then leaks, do not lick or inhale the liquid or get the liquid on your skin. If the liquid comes into contact with your eyes or mouth, immediately rinse your eyes or mouth with clean water and see a doctor. If the liquid comes into contact with your skin or clothes, immediately wipe it off with alcohol, and wash with water and soap.

The liquid is harmful to your eyes and your skin.

While the ring tone is ringing or a melody is played on the FOMA terminal, do not put the ears closer to the speaker.

This may cause hearing loss.

On the surface of the display, there is a protective film for securing the safety (for preventing the reinforced glass panel from shattering) in case of the damage caused by a drop, impact, etc. Do not forcibly peel off or scratch this film.

Using the FOMA terminal with the film removed may cause a bodily injury when the display is damaged.

Using the FOMA terminal in an automobile may sometimes affect the electronic equipment in some vehicle models.

In such cases, stop using the FOMA terminal, as this could impede safe driving.

Use of the FOMA terminal may cause skin irritations such as itchiness, rashes or eczema in some people. If this occurs, immediately stop using the FOMA terminal and seek medical treatment.

Part Material

Surface of FOMA terminal (display)

Surface of FOMA terminal (the back of display and cabinet hinge)

Metal section of 1Seg antenna

Earphone/ Microphone terminal

External connector terminal

Inside microSD Memory Card slot

Charger terminal

Magnesium

Aluminum Alumite

Brass

Stainless steel

SUS

Surface

treatment

Coating

Chrome plating

Tin plating

–

Gold plating

Do not close the FOMA

Danger

Warning

terminal on your fingers or objects such as the strap.

May result in bodily injury or cause a malfunction.

Watch 1Seg in a well-lit place, keeping a certain distance from the screen.

Otherwise, eyesight may be decreased.

Handling the battery pack

Check the type of battery using the information printed on the battery pack label.

Label Battery type

Li-ion 00 Lithium-ion

Do not touch terminals with metallic objects such as wires. In addition, do not carry or store the battery pack with metallic necklaces, etc.

The battery pack may leak, overheat, explode or catch fire.

If you are having difficulty fitting the battery pack to the FOMA terminal, do not use excessive pressure to force the battery into place. Check that the battery pack is facing the correct direction before you attach it.

The battery pack may leak, overheat, explode or catch fire.

Do not throw the battery pack into a fire.

The battery pack may leak, overheat, explode or catch fire.

Do not puncture, hit with a hammer or step on the battery pack.

The battery pack may leak, overheat, explode or catch fire.

If the battery fluid comes into contact with your eyes, do not rub your eyes but immediately rinse your eyes with clean water. Then seek prompt medical treatment.

May result in loss of eyesight.

If any trouble is found on the battery pack due to an external impact such as a deformation or scratches caused by a drop, immediately stop using it.

The battery pack may leak, overheat, explode or catch fire. Other equipment may also be damaged or catch fire.

If the battery pack is not fully charged after the specified time has elapsed, stop charging.

The battery pack may leak, overheat, explode or catch fire.

If the battery pack leaks or emits an unusual odor, immediately stop use and move it away as far as possible from any flame or fire.

The battery fluid is flammable and could ignite, causing a fire or explosion.

Prevent your pet from biting the battery pack.

The battery pack may leak, overheat, explode or catch fire. Other equipment may also be damaged or catch fire.

Easy Search/Contents/Precautions

Continued on next page

Easy Search/Contents/Precautions

Caution

Warning

Do not dispose of used battery packs in ordinary garbage.

May cause fires or damage to the environment. Place tape over the terminals to insulate unnecessary battery packs, and take them to a DoCoMo Shop, retailer or institution that handles used batteries in your area.

Do not charge a wet battery pack.

The battery pack may overheat, catch fire or explode.

If the battery fluid comes into contact with your skin or clothing, stop using the FOMA terminal immediately and rinse it off thoroughly with clean water.

Battery fluid is harmful to your skin.

Handling the adapters (chargers)

Do not use if the adapter’s (charger’s) cord or power

May cause electric shock, overheating or fire.

cord is damaged.

Never use the AC adapter or desktop holder in humid or steamy locations such as a bathroom.

May result in electric shock.

The DC adapter should only be used in negative grounded vehicles. Never use these adapters in positive grounded vehicles.

May cause a fire.

Do not touch the FOMA terminal or adapters (chargers) if you hear thunder.

There is a risk of being struck by lightning and suffering electric shock.

Take care not to short-circuit the charging terminal when connected to a power outlet or cigarette lighter socket. Also, take care not to allow any part of your body (fingers, etc.) to come into contact with the charging terminal.

May result in a fire, electric shock, equipment malfunction or bodily injury.

Place the charger and desktop holder on stable surfaces when charging. In addition, do not cover or wrap the charger or desktop holder with clothing or bedding.

The FOMA terminal may detach, overheat, or cause a fire or malfunction.

Do not place heavy objects on the power cords and the adapters (chargers) cords.

May cause an electric shock or fire.

Do not handle the cord and plug of the adapters (chargers) with wet hands.

May result in electric shock.

Always use the specified power supply and voltage.

Using the incorrect voltage may cause a fire or malfunction. When using overseas, use the AC adapter that is available overseas. AC adapter: 100 VAC DC adapter: 12/24 VDC (for negative grounded vehicles only) AC adapter available overseas: 100 to 240 VAC (Connect only with household AC outlet)

If the fuse in the DC adapter

Caution

Warning

blows, always replace it with a fuse of the specified type.

Using the fuse other than the specified one may cause a fire or malfunction. Refer to the respective manuals for information on the correct fuse specifications.

Wipe off any dust on the power plug.

May cause a fire.

When plugging the AC adapter into the power outlet, make sure that no metallic straps or other metallic objects are caught between the plug and the socket.

May cause electric shock, short-circuiting or fire.

Always grasp the power plug when unplugging the adapters (chargers) from the power outlet or cigarette lighter socket. Do not forcibly pull by the cord or power cord.

Pulling on the cord may damage the cord and cause an electric shock or fire.

Unplug the power cord from the outlet when not using for a long time.

May cause an electric shock, fire, or equipment malfunction.

Should water or other liquids enter the adapters (chargers), remove the power plug from the outlet or cigarette lighter socket immediately.

May cause an electric shock, smoke emission or fire.

Always unplug the power plug from the outlet or cigarette lighter socket before cleaning the adapters (chargers).

May result in electric shock.

Handling the FOMA card

Be careful with the cutting surface when detaching the FOMA card (IC).

May cause injuries to your hand or fingers.

Handling mobile phones near electronic medical equipment

The safety precautions detailed here conform to the guidelines drawn up by the Electromagnetic Compatibility Conference Japan, regarding the protection of electronic medical equipment from signals emitted by mobile phones.

Observe the following in hospitals or other medical facilities.

Do not take your FOMA terminal into

operating rooms, ICUs (Intensive Care Units) or CCUs (Coronary Care Units).

Turn off your FOMA terminal inside

hospital wards.

Turn off your FOMA terminal even when

you are in an area outside hospital wards, such as a hospital lobby, since electronic medical equipment may be in use nearby.

Where a medical facility has specific

instructions prohibiting the carrying and use of mobile phones, observe those instructions strictly.

If Auto power ON function is set to ON,

disable this function before turning off your mobile phone.

Turn off your FOMA terminal in crowded places such as rush-hour trains in case somebody nearby is using an implanted cardiac pacemaker or implanted cardioverter-defibrillator.

Electromagnetic signals may affect the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Easy Search/Contents/Precautions

Continued on next page

If you have an implanted

Easy Search/Contents/Precautions

cardiac pacemaker or an implanted cardioverter-defibrillator, always carry or use your FOMA terminal at least 22 cm away from your implant.

Electromagnetic signals may affect the operation of implanted cardiac pacemakers and implanted cardioverter-defibrillators.

Patients receiving medical treatment away from a hospital or medical facility (e.g. home treatment) who are using electronic medical equipment other than implanted cardiac pacemakers or implanted cardioverter-defibrillators should consult the respective manufacturers for information regarding the effects of signals on the equipment.

Electromagnetic signals may affect the operation of electronic medical equipment.

Handling precautions

General notes

Do not expose to water. FOMA terminal,

battery pack, adapters (chargers) and FOMA card are not waterproof. Do not use in humid or steamy areas such as bathrooms and avoid exposing to rain and other forms of moisture. If FOMA terminal is carried close to skin, perspiration may cause internal components to corrode and result in malfunction. Note that if problem is found to be due to moisture, handset and parts are not covered by warranty and in some cases may be irreparable. Even where repairs are possible, repair charges will be incurred since damage is not covered by warranty.

Clean only with a soft and dry cloth (such

as the type used for eyeglasses). The surface of the handset special coating to improve the visibility of the color display. Forceful rubbing of LCD with a dry cloth may scratch LCD surface. Handle the handset carefully and clean using a soft and dry cloth (such as the type used for eyeglasses). Note also that LCD coating may peel off or stain if moisture or soiling is left on the surface for a long period. For the parts made of aluminum, use a wet and twisted cloth to wipe off the dirt easily. Never use chemicals such as alcohol, thinners, benzene or detergents, as these agents may erase the printing on the handset or cause discoloration. Occasionally clean terminals with a dry cotton swab. in poor connections and loss of power. Additionally, keep terminal clean with a dry cloth or cotton swab to prevent charge performance loss.

Do not place the handset near an air

conditioning vent. Condensation formed due to rapid changes in temperature may cause internal corrosion and lead to malfunction.

Unclean terminals may result

’

s LCD has a

Do not apply excessive force to the FOMA

terminal and battery pack when using them. Carrying the handset in a tightly packed bag, or sitting on the handset in your pocket may result in damage to display, other internal components or battery pack. Keeping an external connector device plugged into the external connector terminal or earphone/ microphone terminal may cause a damage to the connector or result in malfunction.

Read the manuals supplied with the

FOMA terminal, adapters (chargers), and desktop holder carefully.

Do not rub or scratch the display with

metal, etc. May scratch the handset and cause malfunction or damage.

Notes about FOMA terminal

Avoid using the handset in extremely high

or low temperatures. Use the FOMA terminal within the range of a temperature between 5℃ and 35℃ and a humidity between 45% and 85%.

Using the handset close to landline

phones, TVs or radios may affect the operation of such equipment. Move as far away as possible from such items before use.

Keep a separate memo and note

information stored in the FOMA terminal. DoCoMo shall not be liable for any loss of content.

When connecting an external connector

device to the external connector terminal or earphone/microphone terminal, do not put it in obliquely or do not pull it while it is plugged in. May damage the handset and cause malfunction.

Do not close FOMA terminal on strap. May

damage the handset and cause malfunction.

FOMA terminal may become warm with

continuous use or during charging. This is normal and not a malfunction.

Do not leave the camera in direct sunlight.

May cause discoloration or burn-in.

Use the FOMA terminal with the earphone/

microphone terminal cover, external connector terminal cover, and microSD Memory Card slot cover on. Dust, water and others enter inside and cause a malfunction.

Do not use the FOMA terminal without the

back cover. May detach the battery pack or cause malfunction or damage.

Do not cover the surface of the display,

keys, or buttons with an extremely thick sticker. May cause malfunction.

While using a microSD Memory Card, do

not remove the card or turn off the FOMA terminal. May cause data loss or malfunction.

Aluminum material is used on the surface

of the FOMA terminal. Aluminum is a soft material. Be careful of possible dents or scratches.

Easy Search/Contents/Precautions

Handling battery pack Handling the adapters

Battery pack is a consumable product.

Easy Search/Contents/Precautions

Though usage time varies with use, change battery if battery level is extremely low even after fully charged. Purchase a new battery pack for specified handset.

Charge battery in areas where ambient

temperature is between 5℃ and 35℃.

Always charge the battery before the first

use or after not using battery for a long time.

The usage time for a battery depends on

the usage and deterioration of battery pack.

Depending on usage, the battery may

swell as it approaches the end of its service life but this will not cause problems.

Do not store or leave the battery pack with

no battery left. Failure to observe this instruction may lower the performance or shorten the life of the battery pack.

(chargers)

Charge battery in areas where ambient

temperature is between 5℃ and 35℃.

Do not charge battery pack in the following

locations:  Areas with high humidity or dust, or in

areas exposed to strong vibrations

 Close to landline phones, TVs, radios,

etc.

Adapters (chargers) may become warm

during charging but this is normal. This is not a malfunction.

Do not use DC adapter to charge battery

when the car engine is not running. May cause car battery to run down.

When using a power outlet with a feature

to prevent the plug from being removed accidentally, follow instructions in the outlet user’s guide.

Do not subject to strong force or impacts.

Also, do not disfigure the charger terminals. May cause a malfunction.

Notes about FOMA card

Do not apply unnecessary force when

inserting/removing the FOMA card.

FOMA card may become warm during

use. This is not a malfunction.

Customer is responsible for malfunctions

arising from inserting FOMA card into a different IC card reader/writer.

Always keep IC area clean. Clean only with a soft and dry cloth (such

as the type used for eyeglasses).

Keep a separate memo and note

information stored in the FOMA card. DoCoMo shall not be liable for any loss of content.

To protect the environment, please take

any unnecessary FOMA cards to your local DoCoMo Shop or retailer.

Avoid using in extremely high or low

temperatures.

Do not damage, touch haphazardly or

short-circuit the IC. May cause data loss or malfunction.

Do not drop or otherwise subject the

FOMA card to severe impact. May cause a malfunction.

Never bend or place heavy objects on the

FOMA card. May cause a malfunction.

Do not insert the FOMA card to the FOMA

terminal with a label or sticker attached on the card. May cause a malfunction.

FeliCa reader/writer

The FeliCa reader/writer function in the

FOMA terminal uses weak electric waves in the handling of which does not require a license of radio station.

The frequency in use is the 13.56 MHz

band. When another reader/writer is being used nearby, keep enough distance from it. Make sure that there is no radio station using the same frequency band in the nearby area.

Notes about FM transmitter

The FM transmitter function in the FOMA

terminal uses weak electric waves in the handling of which does not require a license of radio station.

The frequency in use is the 77.4 to 85.0

MHz band. When using this function, set a frequency, which does not overlap with the frequencies of the FM broadcasting stations in the area, to avoid causing effects to FM radio users in the neighborhood.

Caution

Never use the FOMA terminal that is

modified. Using a modified device violates the Radio Law. The FOMA terminal has acquired the certification of conformity with technical regulations for the specified radio station based on the Radio Law, and the “Technical Conformity Mark ” is printed on the model nameplate of the FOMA terminal as a proof. If the screws of FOMA terminal are removed and a modification is given to the inside, the certification of conformity with technical regulations will become invalid. Never use the FOMA terminal without the valid certification. Doing so violates the Radio Law.

Be careful when using the FOMA terminal

while driving a motor vehicle. While driving, using a mobile phone in hand is regarded as a punishable act. If there is no choice but to receive a call, use Hands-free and tell the caller that you will “call back” and then pull over to a safe place to make a call.

Use the FeliCa reader/writer function only

in Japan. The FeliCa reader/writer function in the FOMA terminal conforms to the domestic radio wave standards. Using the function overseas may result in punishment.

Use the FM transmitter only in Japan. The

FM transmitter in the FOMA terminal conforms to the domestic radio wave standards and has obtained its approval. Using the function overseas may result in punishment.

Easy Search/Contents/Precautions

Intellectual property

Easy Search/Contents/Precautions

Copyrights and rights of portrait

Data with third party copyrights such as text, images, music and

software that is downloaded or acquired via Internet web pages, shot by the FOMA terminal, or acquired from TV or other video cannot be duplicated, altered or publicly transmitted without rightful party’s consent. Only duplicating, quoting, etc. for personal use is permitted under copyright laws. Even if for personal use, filming and recording may be prohibited for demonstrations, performances and exhibitions. Also, shooting another’s image or posting another’s image on Internet web pages without their consent may constitute a violation of one’s right to their image.

Registered trademarks and trademarks

“FOMA”, “mova”, “ToruCa”, “PushTalk”, “PushTalkPlus”, “mopera”,

“mopera U”, “FirstPass”, “Chara-den”, “Deco-mail”, “Chaku-motion”, “i-motion mail”, “i-appli”, “i-appliDX”, “i-motion”, “i-mode”, “i-Channel”, “iD”, “DCMX”, “WORLD WING”, “Public mode”, “DoPa”, “WORLD CALL”, “Dual Network”, “visualnet”, “V-live”, “Security Scan”, “musea”, “sigmarion”, “OFFICEED”, “IMCS”, “i-area”, “2in1”, “Chokkan Game”, the “i-mode” logo, the “FOMA” logo, the “i-αppli” logo, the “DCMX” logo, the “iD” logo, the “HIGH-SPEED” logo are trademarks or registered trademarks of NTT DoCoMo, Inc.

Free Dial logo mark is a registered trademark of NTT

Communications Corporation.

This product includes software licensed from

Catch Phone (Call Waiting) is a registered trademark of Nippon

Telegraph and Telephone Corporation.

Multitask is a registered trademark of NEC Corporation. This product is equipped with NetFront Browser, NetFront Sync

Client and NetFront Browser DTV Profile Wireless Edition by ACCESS Co., Ltd. for an internet browser or other application software.

This product adopts Media: specifications of ACCESS CO., Ltd. for

This product includes modules developed by the Independent

JPEG Group.

ACCESS, NetFront and Media: are trademarks or registered

Document Viewer is powered by Picsel Technologies.

Picsel, Picsel Powered, Picsel Viewer, Picsel Document Viewer and the Picsel cube logo are trademarks or registered trademarks of Picsel Technologies and/or its affiliates.

trademarks of ACCESS Co., Ltd. in Japan and other countries.

Microsoft

, Windows®, Windows Vista®, PowerPoint® and

Windows Media

are trademarks or registered trademarks of

Microsoft Corporation in the U.S.A. and other countries.

Microsoft Excel and Microsoft Word are product names of Microsoft

Corporation in the U.S.A.

Java and all Java-based trademarks and logos are trademarks or

registered trademarks of Sun Microsystems, Inc. in the U.S.A. and other countries.

QuickTime is a registered trademark of Apple Inc., in the US and

other countries.

QR code is a registered trademark of Denso Wave Inc. The microSD logo is a trademark.

Powered by JBlend™ Copyright 2002-2007 Aplix Corporation. All rights reserved. JBlend and JBlend related trademarks are registered trademarks or trademarks of Aplix Corporation in Japan and other countries.

This handset features LCFONT, developed by Sharp Corporation,

to make the LCD easier to view and read. LCフォント/LCFONT

and are registered trademarks of Sharp Corporation.

Heisei font is an intellectual property of Font Development and

Promotion Center of Japanese Standards Association, and “SH Heisei Mincho” is a font developed by DynaComware Corp. with a license.

DynaFont is a registered trademark of DynaComware Taiwan Inc. McAfee

is registered trademarks or trademarks of McAfee, Inc.

and/or its affiliates in the U.S.A. and other countries.

Gガイド, G-GUIDE, Gガイドモバイル, G-GUIDE

MOBILE and the G-GUIDE related logos are registered trademarks of Gemstar-TV Guide International, Inc. and/or its affiliates in Japan.

IrSimple™, IrSS™ or IrSimpleShot™ are trademarks of Infrared

Data Association

ＦｅｌｉＣａ, which uses non-contact IC card technology, was

created by Sony Corporation.

ＦｅｌｉＣａ is a registered trademark of Sony Corporation. b is a registered trademark of FeliCa Networks, Inc. Napster is a registered trademark of Napster, LLC. and/or its

affiliates in the US and/or other countries.

Dolby and the double-D symbol are trademarks of Dolby

Laboratories. FlashFX® Pro™ is a trademark or registered trademark of the Datalight, Inc. in the US. (U.S.Patent Office 5,860,082/6,260,156)

PhotoSolid “AQUOSケータイ

is a registered trademark of Morpho, Inc.

”

, “サイクロイド” and “Cycloid” are trademarks or

registered trademarks of Sharp Corporation.

“TOUCH CRUISER”, “Private filter”, “Wakeup TV”, and “Desktop

clock” are trademarks or registered trademarks of Sharp Corporation.

All other company names and product names are trademarks or

registered trademarks of the respective companies.

Easy Search/Contents/Precautions

Others

Under the MPEG-4 Visual Patent Portfolio License, customers have

Easy Search/Contents/Precautions

licensed permission for the following use of this product to engage in non-profit personal use. Other uses are not permitted.



Encoding MPEG-4 standard video (henceforth referred to as MPEG-4 video).

 Decoding an MPEG-4 video that a customer not engaged in

personal commercial activities has encoded.

 Decoding an MPEG-4 video obtained from a licensed provider. For details on other intended uses, contact MPEG LA, LLC.

This product is licensed under the MPEG-4 Systems Patent

Portfolio License for encoding in compliance with the MPEG-4 Systems Standard. An additional license and payment of royalties are necessary in the following cases.  Data stored or replicated in physical media which is paid for on a

title by title basis.

 Data which is paid for on a title by title basis and is transmitted to

an end user for permanent storage and/or use. Such additional license may be obtained from MPEG LA, LLC. Contact MPEG LA, LLC for additional details.

This product is licensed under the AVC patent portfolio license for

the personal and noncommercial use of a consumer to (i) encode video in compliance with the AVC standard (henceforth referred to as AVC video) and/or (ii) decode AVC video that was encoded by a consumer engaged in a personal and noncommercial activity and/or was obtained from a video provider licensed to provide AVC video. No license is granted or shall be implied for any other use. Additional information may be obtained from MPEG LA, L.L.C. See HTTP://WWW.MPEGLA.COM

Contains Flash

technology by Adobe Systems Incorporated Flash Lite copyright © 1995-2007 Adobe Macromedia Software LLC. All rights reserved. Adobe Reader copyright © 1984-2007 Adobe Systems Incorporated. All rights reserved. Adobe, Flash, Flash Lite and Reader are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

This product uses the GestureTek technology.

Manufactured under license from Dolby Laboratories.

Lite™ and Adobe® Reader®

Licensed by QUALCOMM Incorporated under one or more of the

following United States Patents and/or their counterparts in other nations; 4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,600,754 5,414,796 5,657,420 5,416,797 5,659,569 5,710,784 5,778,338

Content owners use Windows Media digital rights management

(WMDRM) technology to protect their intellectual property, including copyrights. This device uses WMDRM software to access WMDRM-protected contents. If the WMDRM software fails to protect the content, content owners may ask Microsoft to revoke the software’s ability to use WMDRM to play or copy protected content. Revocation does not affect unprotected content. When you download licenses for protected content, you agree that Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade.

CP8 PATENT

This manual refers to each OS (Japanese version) as follows.

 Windows Vista is an abbreviation of Windows Vista

Basic, Home Premium, Business, Enterprise, Ultimate).

 Windows XP is an abbreviation of Microsoft

Professional operating system or Microsoft Home Edition operating system.

 Windows 2000 is an abbreviation of Microsoft

(Home

Windows® XP

Windows® 2000

Professional operating system.

Easy Search/Contents/Precautions

Standard parts packaged with unit and main optional parts

FOMA SH905iTV terminal

(includes warranty and Back Cover SH18)

※ “Manual for PC connection setting” and

“Kuten Code List” in the PDF format are contained.

※ Quick manual can be found on P. 518.

■ Standard package

FOMA AC Adapter 01/02

(includes warranty and user’s guide)

Desktop Holder SH17

(includes user’s guide)

Battery Pack SH15

■ Main optional parts

Manual (this manual)

FOMA SH905iTV CD-ROM

For details on other optional parts nP. 473

Easy Search/Contents/Precautions

Manual

Before Using the Handset

Component names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Viewing the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

TOUCH CRUISER pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Menu settings and selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Displaying the Supportbook. . . . . . . . . . . . . . . . . . .<Supportbook>44

Using a FOMA card . . . . . . . . . . . . . . . . . . . . . . . . . . <FOMA card>45

Inserting and removing the battery pack . . . . . . . . . . . . . . . . . . . . . 48

Charging the FOMA terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

How to check the battery level. . . . . . . . . . . . . . . . . <Battery level>52

Turning the power on and off. . . . . . . . . . . . . . . .<Power ON/OFF>53

Switching the display to English . . . . . . . . . . . . <Select language>53

Making the initial setting . . . . . . . . . . . . . . . . . . . . . <Initial setting>54

Setting the date and time. . . . . . . . . . . . . . . . . . . . <Date settings>54

Sending your own phone number to the other party

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Notify caller ID>55

Checking your phone number . . . . . . . . . . . . . . . . .<Own number>56

Component names and functions

5 6

Before Using the Handset

※ Key illustrations are examples and may look different from actual keys.

1Earpiece

Emits the other party’s voice. Listen to Record message/Voice memo using the earpiece.

2Brightness sensor (nP. 121)

The sensor detects the light of the surrounding area and

automatically adjusts the display brightness and keypad backlight.

Do not cover the sensor area with a sticker. May interfere with the

sensor.

3Main display (nP. 34) 4i-mode/Operation guidance key i (,)

Press to use i-mode (nP. 172).

Press to execute the functions of the operation guidance (nP. 33). Press for 1+ seconds to display the i-appli software list screen

(nP. 235).

5Multi-guide key wt

Move the cursor to select an item and execute or set (nP. 33). Press to display Menu, Redial list screen, Received calls list

screen, Shortcut menu and Active marker.

Press t for 1+ seconds to use Multi easy lock (nP. 138). Press r for 1+ seconds to use IC card lock (nP. 272).

Press u for 1+ seconds to adjust the earpiece volume (nP. 111).

6Mail/Operation guidance key m

Press to use mail functions (nP. 200).

Press to execute the functions of the operation guidance (nP. 33).

Press twice to check new messages (nP. 211). Press for 1+ seconds to display a new mail message screen

(nP. 200).

7Start/Hands-free key s

Press to make or receive a voice call. Press to use Hands-free (nP. 59).

8Dial/Text entry keys 1 to 9, 0, *, #

Press to enter a phone number or text. Press * for 1+ seconds to use the Public mode (Drive mode)

(nP. 73).

Press # for 1+ seconds to use the Manner mode (nP. 115).

Press 1 to 3 for 1+ seconds to use assigned functions

(nP. 392).

Press 5 for 1+ seconds to set font size collectively (nP. 127). Press 7 for 1+ seconds to record voice memo or play voice

memo or recorded message (nP. 79, P. 394).

Press 8 for 1+ seconds to switch modes when the 2in1 is used

(nP. 424). Press 9 for 1+ seconds to reset Kisekae Tool settings (nP. 123).

9Multi/Supportbook key $

Press to view Supportbook (nP. 44). Press to use Multi Assistant (nP. 380).

aMouthpiece

Sends out your own voice.

bSub camera

Use to shoot still pictures of yourself. Use to send images of yourself during a Videophone call.

cTOUCH CRUISER pad (nP. 39)

Slide or double-tap the finger on the TOUCH CRUISER pad to

perform the same operations as those of Multi-guide key (e.g. selecting, executing or setting an item).

dCamera/Operation guidance key C

Press to activate Camera (nP. 153). Press to execute the functions of the operation guidance

(nP. 33).

Press for 1+ seconds to display Data box (nP. 304).

ePhonebook/Operation guidance key a

Press to use the phonebook (nP. 98). Press to execute the functions of the operation guidance

(nP. 33).

Press for 1+ seconds to display the phonebook entry screen

(nP. 99).

fi-Channel/Clear key c (J)

Press to show the channel list (nP. 196). Press to return to the previous screen. Use to delete phone numbers and text.

Before Using the Handset

Continued on next page

gPower/End key H

Press for 2+ seconds to turn the power on/off (nP. 53). Use to end the function being used and return to stand-by

Before Using the Handset

display.

hEco/Private filter key y

Press to use the Eco mode (Power saver) (nP. 119). Press for 1+ seconds to use the Private filter (nP. 128).

iTV key x

Press to use 1Seg (nP. 278).

Press for 1+ seconds to display the 1Seg menu screen.

jEarphone/Microphone terminal

(nP. 398)

Connect a flat-plug earphone/

microphone with switch (sold

separately). An old model of the

earphone/microphone with switch is

available by using an earphone plug

adapter (sold separately).

kSpeakers

Emits ring tones, music, etc. Emits the other party’s voice during hands-free operation.

lmicroSD Memory Card slot (nP. 326) mUp key :

Press for 1+ seconds with the FOMA terminal closed to activate

Music player (nP. 369). Use for 1Seg or Music player.

nDown key +

Use for 1Seg or Music player.

oPushTalk key & (q)

Press to view the PushTalk phonebook (nP. 92). Press with the FOMA terminal closed to scroll from the beginning

of i-Channel ticker in the sub display. Press for 1+ seconds to use the side key guard (nP. 138).

pSub display (nP. 34) qCalled LED/Charging LED/Camera LED

Flashes while receiving a call, etc (nP. 125). Stays lit while charging (nP. 49). Lights while activating the camera (nP. 153). Flashes during shooting (nP. 154, P. 157).

r1Seg antenna (nP. 275)

Use to receive 1Seg.

sStrap ring tInfrared port

Use for the Ir exchange (nP. 341). Use for the Ir remote control (nP. 345).

uFOMA antenna

An antenna is built in. To speak in better conditions, do not cover

the antenna area by hand.

vMain camera

Use to shoot still pictures or movies (nP.

to send a camera image shot during a Videophone call to

Use

the other party (nP. 58).

wFeliCa mark

The IC card is included (The IC card cannot be removed). Use

Osaifu-Keitai holding the FeliCa mark up to the scanning device (nP. 263).

Use to send and receive data via the iC transmission

(nP. 346).

xBack cover (nP. 48)

A radio frequency-preventing sheet is attached on the back of

the back cover. Do not peel off this sheet.

yExternal connector terminal (nP. 50, P. 335) zCharger terminal (nP. 51)

Terminal for recharging with the desktop holder.

146).

How to open the FOMA terminal

Note

avm

When carrying, keeping the FOMA terminal closed as shown in the

diagram for step 1 is recommended.

■ Normal position

Before Using the Handset

Open carefully with both hands.2Push the display back as far as

it will go.

■ Cycloid position

Set to the Cycloid position in stand-by or other screens so that 1Seg is automatically activated.

Open carefully with both hands.2Open the display until it stops

midway.

Rotate the display 90° to the

When rotating the FOMA terminal display, do not rotate in the

opposite direction or further than 90°.

When talking in the Cycloid position, use the flat-plug earphone/

microphone with switch (sold separately) or use hands-free. When talking with the earpiece, switch to the normal position.

right.

How to use the Multi-guide key and Operation guidance key

Use to select or execute the menus that appear in the operation guidance. The following shows the keys allotted to select or execute the menus items that appear in the guidance.

■ Operation guidance menu

12345 789

o lkjihgfm

st u

a b

p nq e d c

gr1h a2z2y

ksj

8 2

In the operation guidance, menus appear according to the used function and situation. The following table describes examples of the main operation

Before Using the Handset

guidance menus that appear.

OK Sets the selected item. Submenu Displays the Submenu. Agree Checks selected image, music, etc. Back Returns to the previous screen. Play/Stop Plays/stops i-motion, music, etc. Full-scr Displays selected images, etc. in full screen. Display all Displays sorted files, etc. as a list. 1/1/Zoome Displays selected images, etc. in actual/

Mail Displays the compose message screen. Send Sends a message. Cancel Cancels the operation such as receiving a

SelAll/ClrAll Selects/disables all selectable items

Page ▲/Page ▼ Close Closes the Submenu, etc.

reduced size.

message.

(Up to 50 items can be selected/disabled depending on the function).

Scrolls the display by page.

Viewing the display

Main display

Sub display

※ Icons are shown in the order of main display and sub display.

1Signal status

Indication of the signal strength

]/a

When A (Out of service area) appears, the handset is outside

the service area or in a place with no signal. Signal icon can be

changed (nP. 124).

2Battery level/Charging (nP. 52)

"/b {/k

Battery icon can be changed (nP. 124).

3i-mode/Full Browser (nP. 172, P. 295)

7 = A A

4SSL (nP. 173)

When

i-mode, Full Browser, i-appli or Software update is being used

with Multi Assistant.

5i-appli (nP. 235)

* Indicates that an i-appli is set as the stand-by display, but cannot

be used.

] no p

Strong Weak

Battery level

Charging

B N O

Indicates i-mode/Full browser status

SSL compatible sites are viewed SSL compatible Internet web pages are viewed

o appears while Multi Assistant is used, function such as

i-appli is being activated

i-appli stand-by is being activated i-appli stand-by is set

i-appliDX is being activated

i-appliDX stand-by is being activated i-appliDX stand-by is set

6Overseas 3G network (nP. 440)

4 (green) 4 (red)

7Shortcut menu (nP. 392)

8i-mode mail/SMS/Area Mail received (nP. 209)

U h H v

* Appears when Area Mail is received.

9Message R/F (nP. 225)

ABGIST z8<9>0

The status may not always be indicated even if messages are

held at the i-mode center.

amicroSD Memory Card (nP. 325)

^ (gray)/m

^ (pink)/l

bClock display (nP. 54)

Small clock icon can be changed (nP. 124).

c1Seg being recorded (nP. 283)

3G network (Packet transmission available)

3G network (Packet transmission not available)

Appears when the function can be added to the

Shortcut menu

Indicates the status of the i-mode mail/SMS/ Area Mail reception

[/x

Indicates the status of the memory to store received mail

Indicates the reception status of the Message R/F Indicates the storage status of the Message R/F

microSD Memory Card is inserted

microSD Memory Card is being used

1Seg is being recorded

Before Using the Handset

Continued on next page

dRecord message (nP. 76)

Record message is set

]

Before Using the Handset

When there are messages, D to P appears, indicating the total

number of both types of messages. When there are three Record

messages (voice calls) and two Record messages (Videophone),

k appears.

eSilent (nP. 111)

The phone ring volume [Silent] is set

[

fVibrator (nP. 113)

Vibration mode is set

gManner mode (nP. 115)

Z/f

hPublic mode (Drive mode) (nP. 73)

_/d

iStorage status of i-mode center (nP. 209)

jIC card lock (nP. 272)

H/c

kRestriction indicator (nP. 133, P. 139)

Manner mode is set

Public mode (Drive mode) is set

Mail being held at the center

Mail being held at the center full

IC card is locked

R/i

T U/e V/e

Secret mode is set

Secret data is being edited

Keypad dial lock

All lock is set

Function lock is set

W/e

K (red)/e

K (blue)/e

X/e

lHands-free (nP. 59, P. 89)

; (red) ; (green)

mAlarm (nP. 285, P. 286, P. 384, P. 389)

* Appears only when an Alarm is set for that day.

nMusic&Video Channel program reservation (nP. 359)

oi-mode mail send reservation (nP. 208)

= ;

pEarphone/microphone connection (nP. 400)

Appears when Auto answer for PushTalk is set even if an

earphone/microphone with switch is not connected.

Keypad dial lock/Function lock are set

Secret mode/Function lock/Keypad dial lock are set

Side key guard/Secret mode/Function lock/ Keypad dial lock are set

Side key guard is set

Hands-free active call

Connected to Hands-free compatible device

Alarm is set Schedule alarm is set Reception reserve alarm is set Recording reserve alarm is set Wakeup TV is set

Appears 12 hours before Music&Video Channel program distribution

Mail with send reservation

Mail failed to be automatically sent

When voice/Videophone call in Auto answer setting is set to [ON] and while a flat-plug earphone/microphone with switch (sold separately) is connected When PushTalk in Auto answer setting is set to [ON]

qUSB mode (nP. 335)

FOMA USB Cable with Charge Function 01 (sold

separately) is connected

rFOMA card error

R/j

B/h

sSelf mode (nP. 135)

g/g

tPushTalk (nP. 88)

uIr exchange/External device

t (green)

t (red)

vPrivate filter (nP. 128)

The Private filter icon does not appear while 1Seg is recorded.

Appears when FOMA card is malfunctioning or not inserted

Appears when a card other than the FOMA card is inserted

Self mode is set

During PushTalk transmission

Data is communicated with another device using the Ir exchange function (nP. 341)

Data is sent using the Ir remote control (nP. 345) Connected to an external device and transmitting

packets Connected to an external device and sending/

receiving packet data Connected to an external device and transmitting

64K data

Private filter is set

wStatus of Comics setting (nP. 352)

Frame display is set

Page display is set

Status of Comics setting icon does not appear during hands-free

operation.

xToruCa (nP. 265)

Unread ToruCa

The ToruCa icon does not appear during hands-free operation or

e-comic display.

yMultitask (nP. 380)

Indicates functions that are running. When two or more functions are running, the Multitask icon

appears also in the sub display.

Camera (still picture)

Four or more applications

are running

Videophone

Voice call

Phonebook

PushTalk/PushTalk

phonebook

Modem transmission (appears during data

transmission)

Software update

Receive Ir data

i-appli

i-mode, i-Channel

Camera (movie)

Character reader (OCR)

Bar code reader

Card reader

]

Voice recorder

Schedule

Text memo

Calculator

Manga&BookReader

To ru C a

Alarm

{

Timer

Continued on next page

Before Using the Handset

Note

Stock icon

Message

Number of entries

Full Browser

Before Using the Handset

Mail, SMS, Message R/F,

Check new message

Mail/SMS being

composed

SD-Audio

Data box, Music&Video

Channel

Received calls/Received

messages history

zOperation in progress

A screen other than stand-by appears in the main

display

microSD Memory Card is referred to as [microSD] or [SD] on the

FOMA terminal (nP. 325).

Some of the screen shots in this manual have been modified or

abbreviated.

The display for the FOMA terminal is manufactured using

high-precision technology, but it may occasionally contain dots that fail to light or that remains permanently lit. This is not a malfunction.

The subscreen display time follows the light duration setting.

microSD manager

}

General settings

Record message/Voice

memo Redial/Sent messages

history

Document Viewer

Own number

1Seg

Reception reserve/ Recording reserve alarm

sounds

Checking notices with stock icon

Display stock icons in stand-by when you miss a call or have a new mail. In stand-by, select stock icons to check notice details.

■ Stock icon

Icon Message Page

xx missed call

Recorded messages Fxx message/

Axx message

xx voice mail

xx mail message

xx New Message R P. 225

xx New Message F P. 225

xx new ToruCa P. 265

New auto send result P. 208

Update complete P. 495

Check update P. 495

Check for update

USB mode setting P. 335

Download successful (Music&Video

Channel)

Download failed (Music&Video Channel) P. 359

P. 7 6

P. 7 9

P. 415

P. 210, P. 230

P. 493, P. 494

P. 359

Note

Icon Message Page

Note

Operating range of TOUCH CRUISER pad

The pointer or cursor moves in conjunction with sliding of the finger

Double-tap the finger to select

Charge limit exceeded P. 396

*1 When the 2in1 mode is set to [Dual mode], the number of Number

B also appears.

*2 The message that appears differs depending on the menu screen.

In stand-by, a stock icon appears/t.

Select the stock icon/t.

After the details are checked, the stock icon and message

Stock icons do not appear while the i-motion set as stand-by is

played or the i-appli stand-by is being activated.

Custom menu/Basic menu

disappear.

P. 4 2

TOUCH CRUISER pad

Use TOUCH CRUISER pad to perform the same operations as those of Multi-guide key (e.g. selecting an item, moving the cursor or scrolling the screen).

Move the pointer or double-tap the TOUCH CRUISER pad in the

range where there is a logo, “TOUCH CRUISER”.

Make the finger stand a little bit to operate easily.

In the following cases (screens), the TOUCH CRUISER pad is not available. However, when the Submenu appears, the pad can be operated.

 Stand-by  i-appli  Dial input screen  While making, receiving or during the voice call/Videophone

call/PushTalk, etc.

Before Using the Handset

■ Moving the pointer

e.g.) Custom menu screen

e.g.) Basic menu

screen

In the Custom menu or while i-mode or Full Browser is connected, move the pointer (L, M, K, etc.) up/down, left/right or diagonally to select

Before Using the Handset

an item. In some Custom menus, the pointer shape

varies or the pointer is not supported. Move the pointer to the edge of the screen while i-mode or Full Browser is connected to show

G, R/\, Z

direction of the arrow. If Link is set, and double-tap to move to the linked page.

The pointer moving speed varies depending

on the finger sliding speed.

and scroll the screen to the

■ Moving the cursor

In the Basic menu or Submenu, move the cursor up/down and left/right instead of using the four-way key. When there are multiple pages, move the

cursor to switch the pages.

appears,

■ Determining

After moving the pointer or cursor, double-tap the item pointed with the pointer or cursor to set it instead of using the OK key.

When using the TOUCH CRUISER pad

Avoid using the TOUCH CRUISER pad continuously for 30

minutes or more. Take regular breaks to rest your eyes and do a stretching exercise to relax your finger, hand, wrist, forearm and shoulders.

Do not operate it with unnecessary force or in an improper

posture. May hurt your finger and wrist.

Do not operate the TOUCH CRUISER pad using a pointed

metallic object such as a pen tip. May cause scratches or a failure of the sensor.

This product is designed to be operated with one finger. In the

following cases, the TOUCH CRUISER pad is not activated.

 When operated with a gloved finger  When operated with a pen, ballpoint pen, pencil, etc.  When operated with two or more fingers 

When operated with foreign objects placed on the operation pad

 When operated with a fingernail

The TOUCH CRUISER pad may not be properly operated when

there are droplets or condensation on the operating range or when the operation pad is operated with a wet finger or a moist finger with sweat.

Keep the operating range clean with a dry cloth. When the

operating range gets too dirty, wipe it with a wet cloth and fully dry before using it.

Note that putting a sticker, etc. to the operating range may cause

a malfunction.

Setting the TOUCH CRUISER pad

■ Setting whether to use the TOUCH CRUISER pad

In the Custom menu, select [Settings]/[General

settings]/[TOUCH CRUISER set]/[Usage settings].

Select the setting/t.

■ Setting the pointer speed/scroll speed/double tap

speed

In the Custom menu, select [Settings]/[General

settings]/[TOUCH CRUISER set]. Select an item/t.

Select the speed/t.

Menu settings and selections

Set, change or save functions from the menu screens.

The explanations in this manual are based on how to retrieve a function from the Custom menu.

Setting the start menu <Menu priority>

Set the start menu that displayed when t is pressed in stand-by. When in the Cycloid position, the list appears regardless of the

Menu priority.

Start menu Characteristics

The preset Kisekae Tool (nP. 121) can be selected and set. Each Kisekae Tool consists of different functions and designs. Kisekae Tools can be downloaded from sites and used.

Custom menu

Basic menu

In stand-by, press t/[Settings]/[Disp/LED/

Power saver]/[Menu priority]. Select the start menu/t.

Preset Kisekae Tools

 Silver White  Black  Gold  拡大メニュー(Large)  Simple  ドコモダケ

※ Preset Kisekae Tools differ depending on the

FOMA terminal handset color.

In the Basic menu, input the function number, which is assigned to each function, to quickly retrieve the function to be used. Assigned function numbers nP. 446

Before Using the Handset

■ Switching the set start menu temporarily

Stand-by

Shortcut menu

Basic menuCustom menu

Switch the start menu temporarily. When the stand-by display reappears, the start menu returns to the one set in Menu priority. Use the Shortcut menu to retrieve saved functions quickly. Other

Before Using the Handset

functions can also be saved in the Shortcut menu (nP. 392).

Retrieving a function from each start menu

For details on the available functions nP. 446 Use the Multi-guide key and TOUCH CRUISER pad in both start

menus.

Press the dial key corresponding to the menu item number (U, V,

W, etc.) to select a function. However, in the Custom menu, a

function may not be selected by using the menu item numbers.

The method for selecting functions may differ depending on the

Kisekae Tool set for the Custom menu.

Press c to re-select a function, and the previous screen

reappears. Press H to return to stand-by.

When a stock icon (nP. 38) appears in stand-by, select G to show the start menu.

■ Retrieving from the Custom menu

Example: Retrieving [My picture(phone)] with Multi guide

key or TOUCH CRUISER pad to show still pictures in [Camera]

For the , mark, use the TOUCH CRUISER pad to select an item.

The following shows the screen operated with the TOUCH

CRUISER pad.

When the handset color is “Silver White” When the handset color is “Black” or “Gold” (the screen of the

Custom menu When [Data box]

appears

When [My picture(phone)]

appears

When [Camera]

appears

Custom menu [Data box]

When [My picture(phone)]

appears

When [Camera]

appears

handset color “Black”)

Select a function on the upper part of the screen to show the menu

of the selected function at the lower part of the screen.

* Move the pointer down to select the displayed menu without

double-tapping it.

Before Using the Handset

■ Retrieving from the Basic menu

Note

Basic menu When [My picture(phone)]

appears

911

When [Camera]

appears

Related Operations

Example: Retrieving [My picture(phone)] by entering function

Before Using the Handset

numbers to show still pictures in [Camera]

For the , mark, use the TOUCH CRUISER pad to select an item.

When the Custom menu image is changed by Kisekae Tool, the

operation may differ from the description in this manual. In this case, switch the menu screen to the Basic menu (nP. 41) or perform Reset menu screen (nP. 123).

Supportbook

Displaying the Supportbook

Use this function when unsure of operations. After the Supportbook appears, check the explanation and operation procedures of each function. In addition, directly start functions that were looked up in the Supportbook.

In stand-by, press $.

Select a menu or item/t.

Start functions directly from the Supportbook

In the details screen, select the function to start/t/ [Yes].

Notch

IC (gold)

Fit the notch of the FOMA card to that of the tray.

Tray

Ta b

Note

FOMA card

Using a FOMA card

A FOMA card is an IC card that records personal information, such as phone numbers. A FOMA card can store phonebook data and SMS. By switching FOMA cards, multiple FOMA terminals can be used for different purposes as needed.

If a FOMA card is not inserted, transmission functions such as

voice/Videophone calls, PushTalk transmission, i-mode, mail transmission and packet transmission are not available on the FOMA terminal. In addition, 1Seg cannot be watched.

Inserting and removing a FOMA card

Before inserting or removing the FOMA card, turn off the power,

position the back facing upwards and remove the battery pack. Close and hold the FOMA terminal firmly with your both hands.

■ Inserting

Hook a finger on the tab and pull the tray out (1).

Pull out the tray straight until it stops.

Hold the FOMA card with the IC

facing up and set on the tray (2).

Push the tray all the way in (3).

■ Removing

Hook a finger on the tab, pull the tray out (1) and

remove the FOMA card (2).

Do not allow the FOMA card to fall when removing it.

Inserting or removing the FOMA card forcibly may damage the

card or deform the tray. Use caution.

Refer to the FOMA card user’s guide for more information on the

FOMA card.

Do not misplace the FOMA card once it is taken out. When the tray falls off, slide the tray in straight along the guide rail.

FOMA card security codes

The FOMA card has a “PIN1 code” and a “PIN2 code”. Both are set to [0000] by default but can be changed to a four- to eight-digit number by the user (nP. 133).

Before Using the Handset

FOMA card restriction functions

One’s own FOMA card restriction functions are set for downloaded data, files attached to received mail and i-

ppli that have been run, allowing viewing and playback of data.

When another’s FOMA card is inserted, data with one’s own FOMA card restriction functions set cannot be viewed or played back.

One’s own FOMA card

Another’s FOMA card

Different FOMA card

inserted

The FOMA card has built-in restriction functions as security functions

Before Using the Handset

for protecting personal data and files. When the FOMA card is inserted into the FOMA terminal and data

or files are retrieved using any of the following methods or when an i-appli is running, FOMA card restriction functions are automatically set in the retrieved data or files.  When a file such as an image, melody or PDF is downloaded

from a site or Internet web page

 When a site or Internet web page is saved as a screen memo  When i-mode mail with a file attached is received  When an i-appli is running

Data, files or software with FOMA card restriction functions run only

when in use with the FOMA card inserted at time of acquisition. Display, play, attach to i-mode mail, run software, send data using Ir function and iC transmission function, and copy to microSD Memory Card can be executed. The following indicates the data for which FOMA card restriction is set.

 Melody   Screen memo  Chaku-uta®/Chaku-uta full  Chara-den  File attached to Message R/F  i-motion  ToruCa (details) image  PDF data  Image inserted to Deco-mail or signature  Kisekae Tool  Videophone picture memo  Machi-chara  i-appli (including i-appli stand-by)  Download dictionary  Contents transfer compatible data  Image in Message R/F  Music&Video Channel program  Mail templates with operation restricted data  e-book/e-dictionary/e-comic saved in the [Comic] folder

Image (including animation and Flash movie)

 File attached to i-mode mail other than the following

• ToruCa ・ Phonebook ・Schedule

•Bookmark ・Documents

※“Chaku-uta” is a registered trademark of the Sony Music

Entertainment (Japan) Inc.

The following indicates the settings saved in FOMA card.

 Own Number  PIN setting  SMS expiry  SMS center  Language  SSL certificates  SMS input character

The above operations cannot be performed if the FOMA card

inserted at time of data/file retrieval or i-appli startup is replaced with a different FOMA card.

Explanation that follows refers to the FOMA card inserted at time of

data/files retrieval as “one’s own FOMA card” and other FOMA cards as “another’s FOMA card”.

Note

When one’s own FOMA card is replaced with another’s FOMA

card, the data or files for which FOMA card restriction functions are set cannot be set as stand-by displays or ring tones.

When a FOMA card is replaced with another’s FOMA card, FOMA

card restriction functions are activated and if data or file retrieved from a site is set as the stand-by display or ring tone, the setting is reset to the default. When one’s own FOMA card is re-inserted, the setting returns.

Example: When setting [Melody A], for which FOMA card restriction functions are set, as a ring tone

When one’s own FOMA card is taken out or is replaced with another’s FOMA card, ring tone returns to default setting. When one’s own FOMA card is put back, the ring tone returns to [Melody A].

FOMA card restrictions functions cannot be set for data received

using Ir exchange or data transmission functions, and still pictures/ Continuous mode images/movies shot with the FOMA terminal.

It is possible to move or delete data or files for which FOMA card

restriction functions are set even when another’s FOMA card is inserted.

Running i-appli by selecting highlighted text in i-mode mail display

screen cannot be performed or retrieved when FOMA card restriction functions are set.

If the FOMA card is replaced with another’s FOMA card after

i-appli stand-by is set, the set i-appli cannot be activated in stand-by, and the image set in Stand-by display appears.

Differences in FOMA card functions

Note the following differences between “FOMA card (blue)” and “FOMA card (green/white)” used on the FOMA terminal.

Function

Number of phone number digits available in the FOMA card phonebook

Client certificate operations for FirstPass

Use of WORLD WING Not available Available Service number Not available Available

FOMA card

(blue)

Up to 20 digits Up to 26 digits

Not available Available

About WORLD WING

WORLD WING is a DoCoMo FOMA international roaming service that makes it possible to use the mobile phone number registered in Japan to make and receive calls by the FOMA card (green/white) and supported FOMA terminal. Also, SH905iTV is available in the DoCoMo’s 3G roaming service area only. When using in the GSM service area, the SH905iTV become available if the FOMA card is inserted into GSM supported terminal.

If subscribed to the FOMA service after September 1, 2005, subscription for “WORLD WING” is not required. However, if subscription for “WORLD WING” is canceled at or after subscription for the FOMA service, subscription for “WORLD WING” is required again.

If subscribed to the FOMA service before August 31, 2005 but not

subscribed to “WORLD WING”, subscription for “WORLD WING” is required.

Some payment plans are not available.

When the FOMA card (green/white) is lost or stolen overseas, promptly contact NTT DoCoMo and conduct a procedure for canceling the use of service. Refer to General Inquiries on the back of this manual for inquiries. Note that transmission/calling charges after the FOMA card is lost or stolen are incurred to the subscriber.

FOMA card

(green/white)

Page

P. 9 9

P. 1 91

P. 4 36 P. 4 21

Before Using the Handset

Inserting and removing the battery

Face the side with a recycle mark up.

Ta bs

Tabs

Battery pack connection terminal side

Battery pack

Note

Ta b

pack

Before Using the Handset

Use the battery pack SH15 exclusive to the FOMA terminal.

Turn off the power, close the FOMA terminal, and hold it in your

both hands before inserting or removing the battery pack.

■ Inserting

Lightly push the back cover in the direction of the

arrow ( the back cover (

), slide approximately 2 mm (2) and remove

Insert the battery pack (4).

The battery pack has tabs that make it easy to insert. Attach the battery pack with a recycle mark side faced up.

Reattach the back cover (5).

Position the back cover as shown in the illustration and then

push the back cover and slide into place.

■ Removing

Follow step 1 of “Inserting” to remove the back

cover.

Remove the battery pack.

The battery pack has a tab that makes it easy to remove. Press

the tab with your fingers without placing too much force. Lift the battery pack to remove.

Using unnecessary force when inserting or removing the battery

pack may damage the battery pack and connection terminal (charger terminal) on the FOMA terminal.

Firmly close the back cover. If not closed firmly, the back cover

may come off and the battery pack may fall out due to vibration.

Charging the FOMA terminal

Cautions when charging

The battery pack is not fully charged at the time of purchase. Be sure to charge the battery using the exclusive AC or DC adapter (sold separately) before use.

■ Estimated charge times and LED display

The following figures are estimated times for charging an empty battery pack with the FOMA terminal turned off.

FOMA AC Adapter 01/02 Approx. 120 min FOMA DC Adapter 01/02 Approx. 120 min

Charging LED illuminates in red when charging and turn off when

charging is completed.

Check that the battery pack has been properly inserted when

charging LED flashes red. The LED also flashes red when the battery pack has reached the end of its service life.

The battery pack can also be charged with the FOMA terminal

turned on ({ on the display flashes during charging). When charging is complete, charging LED turns off, and { on the display changes to ".

When the battery becomes warm, charging may automatically stop

even if the battery has not been fully charged. Charging resumes after the temperature lowers to an appropriate temperature. While charging is stopped, charging LED turns off ({ on the display flashes while stopped).

■ Estimated times of use when fully charged

Continuous talk time

FOMA/3G Voice call: Approx. 200 min

Videophone call: Approx. 110 min

Continuous stand-by time

Time for watching 1Seg Approx. 230 min

Continuous talk time is estimated as the usage time at normal

transmission signal strength, and continuous stand-by time is estimated as the usage time while moving with the FOMA terminal closed at normal signal strength. Talk and stand-by times may be reduced by about half depending on conditions including battery level status, stand-by display, Power saver mode, Missed call notice and New unread mail notice settings, temperature and other environmental conditions, and signal strength (no signal or weak signal). Using i-mode reduces talk (transmission) and stand-by times. When i-Channel is subscribed, information is automatically received and updated, so talk (transmission) and stand-by times will be reduced. In addition, when shooting or editing an image, watching 1Seg, composing i-mode mail, activating the downloaded i-appli or the i-appli stand-by, FM transmitter out, or SD-Audio or Music player, the talk (transmission) and stand-by times will be shorten even if calls or i-mode transmission are not made. Some i-appli software may continue transmission even after downloading. To avoid this, set not to connect in advance. The actual usage time is a combination of stand-by time and talk time, and the longer the call duration, the shorter the stand-by time becomes. Time for watching 1Seg depends on conditions including battery level status, functions used, temperature and other environmental conditions.

FOMA/3G

At rest: Approx. 520 hr

When mobile: Approx. 360 hr

■ Battery pack service life

Battery pack is a consumable product. Service time per charge is

gradually reduced every time the battery is charged. When service time per charge is reduced to about half of the default time, this means that the battery pack is approaching the end of its service life. In such a case, it is recommended to replace the battery pack as soon as possible. Depending on usage, the battery pack may swell as it approaches the end of its service life but this will not cause problems.

Before Using the Handset

Continued on next page

Connector (Face the side with the arrows up)

Release buttons

External connector terminal cover

Charging/Called LED

External connector terminal

If i-appli, Videophone, or 1Seg is used while charging for a long time, the service life of the battery pack may become shorter than estimated.

To protect the environment, return used batteries to

Before Using the Handset

NTT DoCoMo, any DoCoMo retailer, or a recycling agency.

■ About charging batteries

Refer to user’s guide of FOMA AC Adapter 01/02 (sold separately),

FOMA AC Adapter 01 for Global use (sold separately), or FOMA DC Adapter 01/02 (sold separately).

FOMA AC Adapter 01 covers only 100 VAC. FOMA AC Adapter 02/

FOMA AC Adapter 01 for Global use covers from 100 VAC to 240 VAC. The shape of the plug for the AC adapter is for 100 VAC (for domestic use). To use the AC adapter of 100 VAC to 240 VAC overseas, a conversion plug adapter that is compatible with the voltage of your country of stay is required. Do not use a transformer for use overseas to charge the battery.

■ Cautions when charging

Do not charge for long periods of time with the power left on. If the

FOMA terminal is left on after charging is complete, the battery pack charge decreases. In such cases, the AC or DC adapter charges the battery again. However, depending on when the FOMA terminal is disconnected from the AC or DC adapter, the battery charge level may be low, the battery alert tone may sound, or the battery may only be usable for a short time.

When the battery is empty and terminal is recharging, charging LED

may not illuminate immediately.

If the alert tone sounds and the power cannot be turned on, charge

the battery for a while.

If the battery empty alert is displayed and charging begins within 60

seconds of the alert tone, the status returns to normal.

While charging, terminal may not turn on even when charging LED

is illuminated in red. Charge longer and try turning power on again.

Frequently recharging the battery when power is still remaining

enough may shorten the life of the battery pack. It is recommended to use the battery to a certain level before recharging.

The battery pack cannot be charged by itself.

Charging using the AC adapter/DC adapter

[Read “FOMA AC adapter 01/02 (sold separately) and FOMA DC adapter 01/02 (sold separately) user’s guide” carefully.]

Battery pack can be charged with FOMA terminal open or in the

Cycloid position.

Open the external connector terminal cover (1) and

insert the AC or DC adapter connector horizontally

into the external connector terminal (

Check the direction (see diagram) of the connector, keep it parallel with the FOMA terminal and firmly push all the way in until it clicks.

Note

100 VAC outlet

For AC adapter

For DC adapter

Cigarette lighter socket

Connector (Face the side with the arrows up)

Note

When insert the AC adapter power plug into an outlet or insert the DC adapter power plug into a car cigarette lighter socket, charge start sound is heard, charging LED illuminates, and charging starts.

When Charge end sound is heard and charging LED turns off, charging is complete.

When removing the connector, always hold the release buttons on both sides (

Do not forcibly insert or remove. May cause damage to the

external connector terminal and the connector.

) and unplug it by pulling out horizontally (2).

Pull the adapter out of the outlet or cigarette lighter socket if it will

not be used for a long time.

Do not forcefully pull the cover on the external connector terminal.

May damage the cover.

Do not place objects near the FOMA terminal when charging. The

FOMA terminal may be damaged.

When using a DC adapter

The DC adapter should only be used in negative grounded

vehicles (12 and 24 VDC).

Do not use with the car engine shut off. May drain the car battery. The DC adapter fuse (2A) is a consumable. For replacement,

purchase a new fuse at a local automobile supply shop.

Refer to the FOMA DC Adapter 01/02 (sold separately) user’s

guide for details.

Charging using the desktop holder

[Read “Desktop holder SH17 (sold separately) user’s guide” carefully.]

Battery pack can be charged with the FOMA terminal open or in the

Cycloid position.

Face the side with the arrows of the AC adapter

connector down and insert it into the connector terminal of the desktop holder.

Keeping the connector parallel with the desktop holder, firmly

push it all the way in until it clicks.

Insert the AC adapter power plug into an outlet.

Place the FOMA terminal into the desktop holder.

Charge start sound is heard, Charging LED illuminates, and charging starts.

Continued on next page

Before Using the Handset

Note

Connector (Face the side with the arrows down)

FOMA AC Adapter 01/02

100 VAC outlet

Charging/Called LED

Insert the code into the groove

Side with the arrow

Connector terminal

Note

Battery level is still sufficient.

Battery level is low.

Battery is almost empty. Charge the battery.

Battery is empty (Power will turn off soon).

{

Battery pack is being charged.

Place the FOMA terminal as the figure shows (1), and push it

in the direction of the arrow (2) until it clicks.

When placing the FOMA terminal in the desktop holder, be careful

that the strap is not caught in between the handset and the desktop holder.

Battery level

How to check the battery level

Pull the AC adapter out of the outlet when left unused for a long

When Charge start sound is not heard or when charging LED does

When Charge end sound is heard and charging LED turns off, charging is complete.

Hold the desktop holder and lift the FOMA terminal out.

period of time.

not illuminate, check that the FOMA terminal is placed securely in the desktop holder (except when terminal is turned off, Manner mode is set or Charge start sound is Silent).

Checking the battery level with sound and display

In the Custom menu, select [Settings]/[General

settings]/[Check status]/[Battery level].

Graphic

Sound Three beeps Two beeps One beep

Status

Wait approximately 2 seconds and the display disappears. The battery level sound is heard at the volume set in Key/

Standby i-motion (nP. 11 2) .

Battery is sufficiently full.

Battery is running low.

Battery is almost empty. Charge the battery.

If the battery runs out

Initial settings

screen

Note

Stand-by display

[Battery empty. Unsaved data will be lost. Ending current operation] appears if battery starts to run out (Press t to clear the message). After a while, an alert tone sounds. The warning screen stating that the battery runs out appears, handset operations are disabled and power turns off after approximately 60 seconds. During a voice/Videophone call, the alert tone sounds and [Battery

empty. Unsaved data will be lost. Ending current operation] appears. The call is disconnected after approximately 20 seconds. At the same time, the screen above appears and after approximately 60 seconds, the power turns off.

Alert tone does not sound when Manner mode or Public mode

(Drive mode) is set (Alert tone sounds during a call).

Power ON/OFF

Turning the power on and off

Turning the power on

Press H (for 2+ seconds).

It may take some time for the wakeup

screen to appear.

The wakeup screen appears followed by the

initial settings screen. Proceed to initial settings (nP. 5 4) .

If initial settings have been completed, the

screen shown on the right appears when power is turned on. This screen is called the “stand-by display”.

■ Turning the power off

Press H (for 2+ seconds).

It may take some time for the power to be

turned off (The end screen appears on the display until the power is turned off).

If initial settings are not yet completed, the setting screen appears

every time the power is turned on.

If the FOMA card is not inserted, [Insert UIM] and a FOMA card

error appear (nP. 37). When [Enter PIN1 code] appears, enter the PIN1 code (nP. 132).

When a FOMA card is replaced with a new card, the terminal

security code (four to eight digits) must be entered after turning on the terminal. If a correct terminal security code is entered, stand-by display appears. When a wrong terminal security code is entered five times, the power is turned off. However, turning on the power again is possible.

When A (Out of service area) appears, the handset is outside the service area or in a place with no signal. Move to a place where the icon disappears.

Select language

Switching the display to English

In the Custom menu, select [設定]/[一般設定]/

[Bilingual]/[English].

Continued on next page

Before Using the Handset

Note

To switch the display language from English to Japanese: In the Custom

Before Using the Handset

menu, select [Settings]

If a FOMA card is inserted, settings are saved to the FOMA card as well. When the setting of the FOMA terminal handset and the setting of the inserted FOMA card are different, the setting in the FOMA card is prioritized.

Initial setting

[General settings]/[Select language]/[

Making the initial setting

The initial settings screen appears automatically when the power is turned on for the first time. Each setting item can also be set from Menu (When the initial settings are complete, the stand-by display appears).

 Date and time settings  Change terminal security code  Key/Standby i-motion  Font size settings

When items that have not been set remain, the setting screen

appears every time the power is turned on.

Set the date and time (nP. 54).

Set the date and time from 00:00 January 1, 2001 to 23:59

December 31, 2050.

Set the Key/Standby i-motion (nP. 112).

Set the font size (nP. 127).

When the initial settings are complete, the software update

function confirmation screen appears. Read the description and select [Agree] (When the initial settings are made from the menu or the software update is set to other than [auto-update], the confirmation screen does not appear).

Press H to cancel the initial settings.

日本語

Date settings

Setting the date and time

Set the date and time on the FOMA terminal. Set to automatically correct the date and time.

In the Custom menu, select

[Settings]/[General settings]/ [Date settings].

Select the [Auto time correction] field/t/select

the setting.

 Select [ON]/i.  Select [OFF]/select the [Date] field/t/enter the date/

t/select the [Time] field/t/enter the time/t/i.

Use 24-hour format. When entering month, day and time, add 0 before numbers one

through nine (example: 01, 02, 03, etc.).

The date and time that are set are saved even if the battery pack is removed, but if the battery pack remains removed for approximately a week or more or the battery remains empty, the settings may be reset. When this happens, set again after charging the battery.

If the date and time are not set correctly, the following functions

cannot be used properly.

 Redial, Received calls  Auto power ON/OFF  Alarm  Schedule  SSL (authentication)  i-appli Auto start  Starting i-appliDX  Reception, Recording  Machi-chara  Record message (voice), Record message (Videophone calls)  Camera image titles/shooting date

Playback or view of i-motion/music data/e-comic with replay restrictions



When Auto time correction is set to [ON]

Related Operations

Note

Related Operations

The FOMA automatically adjusts the time by connecting to the

DoCoMo network’s time information.

When time difference is adjusted, [Time adjusted] appears. When

Auto time correction is set to [ON], the time is sometimes not adjusted for a while. To activate Auto time correction, turn off FOMA terminal power and restart.

Time is not adjusted depending on the signal status. Time may be off by a few seconds. When time difference is adjusted overseas, the local time and date

and ! appear in Redial, Received calls, Received/Sent messages (SMS only), and Received/Sent messages list. The received/sent messages are not displayed in order of the displayed time and date but the mail reception/send.

! does not appear in the Unsent messages for mail messages. If

the date order display is set for the Unsent messages, unsent messages are displayed in the order of the displayed time and date.

Time correction may not be performed depending on the overseas

network.

During overseas use, Japan time and local time (or time set in

City) appear in the dual display except for the following cases.  When Auto time correction is set to [ON] and time correction

information is not being received from an overseas network

 When Auto time correction is set to [OFF] and City is set to the

city in the same time zone as Japan

Change the time zone manually <City>

In the Date settings screen, select the [Auto time correction] field/t/[OFF]/C/select a time zone/ t/select a city/t/i.

Notify caller ID

Sending your own phone number to the other party

Display your number (caller ID) on the other party’s phone (display) when making a voice/Videophone call or transmission PushTalk.

Handset number (caller ID) is important personal information. Be

very careful about your caller ID setting.

The Notify caller ID function is available only on compatible phone

devices.

Setting up Notify caller ID/No caller ID in advance

In the Custom menu, select [Settings]/[NW

Services]/[Notify caller ID]/[Notify caller ID].

Select the setting.

To notify caller ID: Select [Yes]. To not notify caller ID: Select [No].

Notify caller ID cannot be set while A (Out of service area)

appears on the screen.

Check the Notify caller ID setting

In the Custom menu, select [Settings]/[NW Services]/ [Notify caller ID]/[Status request].

Before Using the Handset

Setting up Notify caller ID/No caller ID when

Note

Related Operations

Note

Related Operations

making a call

Specifications made when making a call take priority over the

Before Using the Handset

method for setting in advance.

In stand-by, enter a phone number/C/[Caller ID

setting].

Select the setting.

To notify caller ID: Select [Send own no.]. To not notify caller ID: Select [No caller ID]. To follow the Notify caller ID of the network service (nP. 5 5 ):

Select [As NW setting].

Press s (Phone)/i (V.phone)/& (q) (PushTalk).

Alternatively, set caller ID from Submenus in the Phonebook,

Redial or Received calls details screen.

The method for specifying the caller ID setting when making a

voice call is available for PushTalk transmissions. However, the setting cannot be be made by entering a phone number after 186 or 184 is selected.

Add 186 when dialing (Notify caller ID)

In stand-by, press 186/enter a phone number/ s (Phone)/i (V.phone).

Add 184 when dialing (No caller ID)

In stand-by, press 184/enter a phone number/ s (Phone)/i (V.phone).

Own number

Checking your phone number

In the Custom menu, press 0.

When a change for the Number B of 2in1 or a FOMA card

exchange (2in1 subscriber b 2in1 subscriber) is performed, use the following methods to obtain the correct Number B.

 Set 2in1 function OFF and then perform 2in1 setting again  Check the 2in1 subscription

When a FOMA card exchange (2in1 subscriber b 2in1

nonsubscriber) is performed, set 2in1 function OFF.

Show a telephone number during voice call

During a voice call, press C/[Own number].

Show a telephone number during a Videophone call

During a Videophone call, press C/[Own number].

In the Dual mode (while using 2in1), switch between own numbers of Number A and Number B

In the Own number screen, press i.

Voice/Videophone Calls

Making calls/Videophone calls

Using Videophone. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Making calls/Videophone calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Switching between voice call and Videophone. . . . . . . . . . . . . . . . 61

Using Redial and Received calls . . . . . . . <Redial/Received calls>62

Setting Chaku-moji . . . . . . . . . . . . . . . . . . . . . . . . . . <Chaku-moji>64

Sending touch-tone signals with simple operations . . . <Pause dial>65

Making international calls . . . . . . . . . . . . . . . . . . .<WORLD CALL>66

Setting an international call. . . . . . . . . . . . . . . . . . <Int’l dial assist>67

Setting a first number to phone numbers . . . . . . . . . . .<Int’l prefix>68

Making calls with sub address set . . . . . . . . . . . . . <Sub address>68

Reconnecting disconnected calls automatically

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Reconnect signal>69

Reducing noise interference to hear calls clearly

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Noise reduction>69

Using the handset in a car . . . . . . . . . . . . . . . .<In-car hands-free>69

Answering calls/Videophone calls

Answering calls/Videophone calls. . . . . . . . . . . . . . . . . . . . . . . . . . 70

Switching between voice call and Videophone to receive calls . . . 70

Answering calls by pressing any key . . . . . . . . .<Any key answer>71

Answering calls by rotating the display. . . . . . . . <Rotation-link repl>

Closing the FOMA terminal to end/hold calls . . .

Adjusting the volume during a call . . . . . . . . . . <Earpiece volume>72

<Set when folded>72

When calls/Videophone calls cannot be answered/ could not be answered

Placing calls on hold . . . . . . . . . . . . . . . . . . . . . . . . . . . .<On hold>72

Setting On hold/Hold tone . . . . . . <Set on hold tone/Set hold tone>73

Using the Public Mode (Drive Mode) . . . .<Public Mode (Drive Mode)>73

Using the Public Mode (Power OFF) . . . .<Public Mode (Power OFF)>74

Checking Missed calls . . . . . . . . . . . . . . . . . . . . . . . <Missed calls>76

Recording messages when calls cannot be answered

. . . . . . . . . . . . . . . <Record message (voice/Videophone calls)>76

Recording messages when incoming calls cannot be answered

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<Quick message>78

Playing/Deleting Recorded messages or Voice memos

. . . . . . . . . . <Play/Delete recorded messages or voice memos>79

Chara-den . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Setting the image to send to the other party . . . . . . . . . . . . . . . . . . 81

Setting Hands-free Videophone . . . . . . . . . <Hands-free V.phone>83

Setting the image during Videophone calls. . . . . . . . . . . . . . . . . . . 83

Changing Videophone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Setting to switch between voice call and Videophone

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Notify switch mode>84

Selecting actions for incoming Videophone calls during i-mode

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .<V-phone while packet>85

Saving the other party’s image as a still picture . . . . . <Picture memo>85

Using Videophone

The screen shown is only example. Actual screen may differ.

Normal position

Cycloid position

3 4

3 4 5 6

Talk while viewing each other’s image on the screen.

Videophone transmits at 64K (kbps).

Voice/Videophone Calls

When the other party answers the phone, [Connected to

videophone press l key to enable/disable hands-free] appears. Digital transmission fees are incurred from this point.

Videophone calls cannot be made to emergency numbers (110,

119, and 118).

Make international Videophone calls using “WORLD CALL”,

DoCoMo’s international telephone service (nP. 66).

Videophone communication is available only between terminals

compatible with DoCoMo Videophone.

To talk while viewing each other’s image during a Videophone call,

use the flat-plug earphone/microphone with switch (sold separately) or use Hands-free.

DoCoMo Videophones comply with “3G-324M

international 3GPP Videophones using other standards.

*1 3G-324M: International standard for Videophone systems for

third-generation mobile Videophones.

*2 3GPP (3rd-Generation Partnership Project): A regional

standardization organization to establish the common technical specifications for third-generation mobile telecommunication systems (IMT-2000).

standard”. Connection is not available with

as defined by the

Viewing the screen during Videophone calls

1Main screen: Other party’s image (default) 2Subscreen: Your image (default) 3The brightness of your camera image

4Send image icon

5 0

QRSTU

Dark c Normal b Bright

Appears while sending a camera image

Appears while pausing a camera image

Appears while sending Chara-den in the Full action mode

Appears while sending Chara-den in the Part action mode

Appears while sending a still picture as a substitute

Note

image Appears while sending an image from My picture of

Data box

5Receive image icon

Appears when shooting and saving images of the

other party

6Call duration

Approximate call duration appears on the screen. When the call

duration exceeds 9:59:59, the display resets to 0:00.

7DTMF mode icon

8Hands-free icon

5 6

9Earpiece volume icon

The display brightness during a Videophone call follows the

setting of Original Eco mode in Light/Power saver.

Hands-free in progress

(red)

USB hands-free in progress

(green)

v (Volume 1) to @ (Volume 10)

OFF

Making calls/Videophone calls

Calls may be interrupted even when the signal is strong (]

appears) and you are not moving.

To call selecting Multi Number nP. 423 To call selecting a number when the 2in1 is used nP. 424

In stand-by, enter a phone

number.

Always enter the area code even when the

number is in the same area.

Enter up to 80 digits for phone number. To erase the last digit: Press c. To erase all digits: Press c (for 1+

seconds).

Press s (Phone)/i (V.phone).

Unlike ordinary telephones, mobile phones send call tones in

short beeps before the standard ring tone.

When the other party is busy, there is a busy signal. Disconnect

and try again later.

Operation during a voice call

To display your own phone number: Press C/[Own number]. To enable/disable Hands-free: Press s (for 1+ seconds).

Operation during a Videophone call

To display your own phone number: Press C/[Own number]. To enable/disable Hands-free: Press s. To switch between Substitute image and My side: Press i. To set light: Press C/[Videophone]/[Lighting]. To send touch-tone signals while sending a camera image:

Enter numbers to send.

To send touch-tone signals while sending a Chara-den: Press

C/[DTMF mode]/[ON]/enter numbers to send.

Press H to end the call.

When the 2in1 mode is set to [Dual mode], the screen for selecting

a phone number appears after step 2. Select the phone number from [Number A]/[Number B].

Voice/Videophone Calls

Continued on next page

Note

Related Operations

Note

Voice calls

Calls can be made even when steps 1 and 2 are reversed. If no

operations are performed for approximately 5 seconds after

Voice/Videophone Calls

entering the phone number, the call is made.

Videophone calls

Videophone call is not connected when placed to an unsupported

handset. In addition, it is not connected to devices such as PHS phones for which 64K cannot be used due to network conditions.

If Call Waiting is subscribed to, the number is recorded in

Received calls and the stock icon B (missed call) appears when a voice/Videophone call is received during a Videophone call.

During a Videophone call, i-mode mail and Message R/F are held

at the i-mode center. When the sending/receiving of audio or video fails, the Videophone

call is not automatically restored. Make the Videophone call again.

When your image taken with the camera is sent during a

Videophone call in the Cycloid position, the displayed image is made larger than that in the normal position.

When the Videophone call does not connect

When the Videophone call does not connect, a message explaining the reason appears. The other party’s actual conditions may vary depending upon the type of phone and network service subscriptions.  [Check number, then redial]: A call is made to unused phone

number.

 [Busy]: The other party is engaged in a call (The message may

appear during a packet transmission depending on the other party’s terminal).

 [Your call is being forwarded]: The other party’s handset is set

to forward Videophone calls.

 [Out of service area/power off]: The other party is outside the

service area, or their mobile phone is turned off.

 [Set caller ID to on]: Connected without notifying caller ID

(When calling visualnet, etc.).

 [Redial using voice call]: The other party’s handset is set to the

Call Forwarding Service and the forwarding destination does not support Videophone.

 [Busy with packet transmission]: The other party is performing a

packet transmission.

 [Upper limit has been exceeded. Connection failed]: Upper limit

that has been set by payment plans with limit function (Type Limit or Family Wide Limit) has been exceeded.

 [Please make your call from the i-mode web page]: A

Videophone call is directly made to the V-live which should be accessed after connecting to i-mode. Access a site run by the contents provider and view it by making a Videophone call from the link.

 [Connection failed]: Appears in cases other than any reasons.

Hands-free

Precautions on using Hands-free n“Setting Hands-free

Videophone” on P. 83

Cannot be operated when receiving a call and dialing a voice call. Hands-free is disabled when a call ends.

Place calls on hold <Hold Active Call>

1 During a call, press C/[Hold Active Call].

Alternatively, press t during a Videophone call.

2 To resume a call, press s.

Alternatively, press C during a voice call. Press i during a Videophone call to resume with a

substitute image.

Add to phonebook during a voice call

During a voice call, press C/[Add to phonebook]/add to the phonebook.

Note (Related operations)

Hold Active Call

Note

Switching from voice call to Videophone

The other party hears the hold tone, and the call is placed on

hold. For Videophone calls, the image set in Hold image is sent to the other party. The image is sent to the other party with [Hold] superimposed.

Calls stay on hold even when the FOMA terminal is closed. Set

when folded does not apply.

Switching between voice call and Videophone

Switch between voice call and Videophone for placed calls.

Notify switch mode must be set to “Activate” for the other party’s

FOMA terminal.

Received calls cannot be switched. Have the other party switch.

Press C during a call/[Switch to v.phone]/[chg to

voice call]/[Yes].

Alternatively, press a to switch. Switching takes approximately 5 seconds. Switching may take

more time depending on signal status. [Please wait for a while] appears and a guidance message is played.

Voice/Videophone Calls

Calls cannot be switched while 1Seg is being activated. When switching between voice call and Videophone, the call

duration resets to 0 seconds.

Calls may not be switched from voice call to Videophone nor from

Videophone to voice call and may be disconnected depending on signal status.

Switching is not included in the talk time and charges are not

incurred.

Switching from voice call to Videophone

The other party’s camera image does not appear if the other party

selects to not show image.

When performing packet transmissions, disconnect packet

transmission before switching to Videophone.

Continued on next page

Note

Redial list Received calls list

Types of calls

Types of received calls

If a call is switched to Videophone, Hands-free is activated regardless of the call status before the switching.

Calls received with Call Waiting cannot be switched from voice call

Voice/Videophone Calls

to Videophone.

Switching from Videophone to voice call

Hands-free is disabled.

Redial/Received calls

Using Redial and Received calls

The FOMA terminal keeps a record of the 30 most recent phone numbers to which calls were made (including PushTalk).

If the same number was called multiple times, only the most recent

is recorded. However, when 186 or 184 are added to a phone number, the call is recorded as a separate redial.

Each call is recorded in Redial if PushTalk transmission is sent to

multiple parties or the call is made using the PushTalk group or PushTalkPlus.

When 2in1 is used, up to 30 Redials of each Number A and Number

B are saved respectively.

Name appears if saved in phonebook. For PushTalk, the other party’s name or the PushTalk group name

appears.

In stand-by, press r (I) (Redial)/q (M)

(Received calls).

To display the details screen: Select a phone number/t. To switch between the Redial and Received calls list screen:

Press i.

To switch between the Next and Previous: Press v.

Select a phone number and dial.

Voice call: Press s. Videophone: Press t/i. PushTalk: Press & (q).

Types of calls

No icon Voice call

Videophone call

64K data communications (only for Received calls)

International call

1 to 3

ab ac

Types of received calls

Multi Number outgoing/incoming call (Only when Multi Number is set)

Number B outgoing/incoming call (Only when the

2in1 [Dual mode] is used)

Chaku-moji (only for Received calls)

PushTalk (When transmitted to one person)

PushTalk (When transmitted to multiple people)

PushTalk (Using PushTalkPlus)

Calls that were answered or put on hold

Calls that left a recorded message

Calls that were not answered, calls that forwarded to a

Note

Related Operations

Note (Related operations)

forwarding number or Voice Mail Service center, or calls that were rejected because of Reject calls

Even if a call is switched between voice call and Videophone, the

received call type depends on the type used when the call was made or answered.

When a call is received from a caller using Dial-in, a number

different from the caller’s Dial-in number may appear.

If a call is made from Received calls with Chaku-moji, the received

Chaku-moji is not sent.

If the same number is saved in the phonebook, the name with the

smallest memory number appears.

When time difference is adjusted overseas, the local time and date

and ! appear.

P. 140), Accept calls (nP. 140), Reject unknown

(

P. 142), Reject by reason of non-disclosure

(

P. 141), Public mode (Drive mode) (nP. 7 3 )

(

Compose a message from Redial and Received calls

1 In the list screen, select a phone number/C.

In the details screen: Press C.

2 Select [Compose message]/compose/send a

message.

Add a phone number and the date and time of Redials/ Received calls in the schedule

1 In the list screen, select a phone number/C.

In the details screen: Press C.

2 Select [Create schedule]/save a schedule.

Perform Display all/Limit display

In the list screen/details screen, press C/[Display all]/ [Limit display].

Check the ringing time from Received calls

In the details screen, press C/[Ringing time].

To end viewing: Select [Agree].

Voice/Videophone Calls

Add to the phonebook from Redial and Received calls

1 In the list screen, select a phone number/C.

In the details screen: Press C.

2 Select [Add to phonebook]/add to the phonebook.

Delete Redial/Received calls <Delete>

In the list screen, select a phone number

In the details screen: Press C/[Delete one]/proceed to

step 3.

2 Select the deleting method.

 Select [Delete one]. 

Select [Delete all]/enter the terminal security code/t.

3 Select [Yes].

/C/

[Delete].

Deleting

If all Redials are deleted, Chaku-moji Sent messages are also

deleted.

If all Redials/Received calls are deleted, all Redials/Received

calls of Number A and Number B are also deleted respectively.

Display all/Limit display

When Set mute ring time is set to [ON] and Missed call history is

set to [OFF] and the following call not saved in phonebook is received, the number does not appear in Received calls.

 The call is disconnected during mute seconds duration  The call is disconnected due to weak signal strength

However, select [Display all] to show Received calls.

Ringing time

Ringing time cannot be checked for items with g in the received

calls list.

Continued on next page

A ringing time of [0:00] appears when a call is rejected due to

Note (Related operations)

Reject calls, Accept calls, Reject unknown, Reject by reason of non-disclosure and Public mode (Drive mode) settings.

Voice/Videophone Calls

Chaku-moji

Setting Chaku-moji

Send a message (Chaku-moji) at the same time when making a voice call or Videophone call to display it on the other party’s ringing phone and to previously tell the points.

Send up to 10 single/double-byte characters, pictographs or symbols. Charges are applied to the sender side. Not applied to the receiver side. Refer to DoCoMo’s web site or “Mobile Phone User’s Guide [Network Services]” for details and compatible models of Chaku-moji.

While All lock is set or Function lock is applied to Chaku-moji,

Chaku-moji is not displayed even if it is received. When the lock is disabled, the message contents can be checked in the received calls details screen.

Ahead of the Chaku-moji messages on the send and receive

displays, e appears.

Chaku-moji appears only while a call is receiving (calling). When

the call is answered, Chaku-moji disappears.

Example: When Chaku-moji is received for a voice call

Editing and setting Chaku-moji message

■ Saving a Chaku-moji message <Create message>

Save up to ten Chaku-moji messages.

In the Custom menu, select [Settings]/[Other NW

Services]/[Chaku-moji]/[Create message]. Select a number/ i.

To check a saved Chaku-moji message: Select a number/t.

Enter a message/t.

■ Enabling/Disabling Chaku-moji display

In the Custom menu, select [Settings]/[Other NW

Services]/[Chaku-moji]/[Message display]. Select the display method/t.

Dialing with Chaku-moji message <Chaku-moji>

In stand-by, enter a phone number/C/

[Chaku-moji].

Select a Chaku-moji message.

 Select [Create message]/enter a Chaku-moji message/

 Select [Select message]/select a Chaku-moji message/

 Select [Sent messages]/select a Chaku-moji message/

Note

Related Operations

Note

Press s (Phone)/i (V.phone).

If Chaku-moji reaches the recipient, [Transmission completed]

appears and transmission charges are incurred.

Alternatively, make calls with Chaku-moji messages from Submenus in the Phonebook, Redial or Received calls details screen.

On Redial voice call, Chaku-moji used when Videophone was

dialed will be automatically sent.

In the following setting, transmission charges are applied.

 When the sending result does not appear even if the other party

has sent Chaku-moji depending on the signal strength

 When a call is shorter than the set ringing time of the Set mute

ring time

When the call recipient is in the following setting, Chaku-moji does

not appear and transmission charges are not incurred even if dialed with Chaku-moji.  When the recipient’s terminal does not support Chaku-moji

When a call is received from numbers rejected by the message



display settings In addition, when the call recipient is in the following setting or status, the send results do not appear on the sender side display (Chaku-moji is not recorded in Received calls on the receiver side).



When outside the service area or the power is turned off



When the Public mode (Drive mode) is set  When the answering duration for Record message is set to [0

seconds]

The ten most recently sent messages are recorded as Sent

messages.

For overseas usage, Chaku-moji cannot be sent or received. Chaku-moji does not support PushTalk.

Delete Sent messages of Chaku-moji

1 In step 2 of “Dialing with Chaku-moji message”,

select [Sent messages]/select a Chaku-moji message/C.

2 Select the deletion method.

 Select [Delete one].  Select [Delete all]/enter the terminal security code/

3 Select [Yes].

Pause dial

Sending touch-tone signals with simple operations

Use services such as ticket reservations and bank balance inquiries, with simple operations by saving the combinations of phone numbers and messages (numbers) in the phonebook.

Send touch-tone signals of the pressed number one at a time

during a call by pressing the dial keys.

Saving touch-tone data to the phonebook

Enter a phone number in the phonebook/o.

Press o to enter a pause [P]. Alternatively, slide the finger up

on the TOUCH CRUISER pad to enter it.

Continued on next page

Voice/Videophone Calls

Enter the number to send/t.

Enter the number and press o to continue adding numbers.

Save the phonebook entry.

Sending messages using touch-tone signals

Voice/Videophone Calls

Pause dial is available only for voice calls.

Make a voice call from the phonebook with a

touch-tone signal.

The numbers after [P] appear on the screen.

Press i at the appropriate time to send.

The numbers after [P] are sent with touch-tone signals. When multiple numbers separated by [P] are saved, press i

for each number.

Some equipment may not be able to receive signals properly.

WORLD CALL

Making international calls

WORLD CALL is an international calling service available from DoCoMo mobile phones. “WORLD CALL” is registered when services are registered (Registration for “WORLD CALL” is optional).

[Calling Method] 009130 O 010 O Country code O Area code (city code) O Other party’s phone number O s The calling method shown above can be saved on the FOMA

terminal phonebook.

For area codes (city codes) that begin with 0, omit the 0 when

entering (However, include the 0 when calling Italy).

Call to about 240 countries and regions worldwide. “WORLD CALL” charges are billed with the monthly mobile phone

charges.

Subscription and monthly usage fees are free. Check an estimate of the most recent call duration on the display

when using the WORLD CALL (nP. 395).

When using a phonebook, Redial or Received calls, 009130010 is

automatically added to make calls.

Change in procedures for making international calls

Because “MY LINE” service is not available for mobile communications, WORLD CALL also cannot be used with “MY LINE”. With the offering of the “MY LINE” service, the entering procedures for international calls have changed. The former entering procedure (procedure listed above without 010) cannot be used.

For further details on WORLD CALL, contact the number listed in

“General Inquiries” on the back of this manual.

To make an international call through a company other than

DoCoMo, contact the representative companies directly for instructions.

Some payment plans may not be available.

When calling Videophone compatible specific overseas 3G mobile phone customers, use “International Videophone” by making the call in Videophone mode after the entering method above. Refer to the DoCoMo web page for information on available

countries and providers.

Depending on the other party’s international Videophone terminal,

the image that appears on the FOMA terminal may be distorted, or connection may not be possible.

Int’l dial assist

Setting an international call

Automatically adding the international access code/country code <Auto conversion>

When making an international call from Japan, enter [+] before dialing the overseas number to automatically place the international access code. When making an international call to Japan, convert the first [0] in the phone number to the country code automatically and make a call.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[Int’l dial assist]/ [Auto conversion].

Select the [Int’l prefix conv] field/t/[ON].

Set international access codes as auto prefix in the IDD prefix setting.

Select the [Country code conv] field/t/[ON]/

select the country to add/t.

Select among country codes saved in the Set country code.

Press i..

■ Using [+] to make an international call

Press 0 for 1+ seconds to enter [+].

In stand-by, press 0 (for 1+ seconds)/enter the

country code, area code (city code) and other party’s phone number/s.

The number with the international access code, which is

converted from [+], appears.

Select [Call].

To not convert [+] to the international access code: Select

[Original number].

Setting numbers other than WORLD CALL

Save up to ten international access codes used when international

calls are made from Japan.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[Int’l dial assist]/ [IDD prefix setting].

Select a number to save as a new entry/t.

To change a saved number: Select a number/t/[Change]. To delete a saved number: Select a number/t/[Delete]/

[Yes].

To set/disable Auto prefix: Select a number/t/[Prefix/

cancel].

• w appears to the right of the name.

Enter a name/t.

Enter up to 14 single-byte (7 double-byte) characters for a

name.

Enter a prefix/t.

Press 0 for 1+ seconds to enter [+]. Up to 16 digits can be entered for a prefix.

■

Selecting an international access code

Enter only the country code, area code (city code) and the phone number to make international calls.

In stand-by, enter the country code, area code (city

code) and other party’s phone number/C.

In the phonebook entry details screen: Press C/[Number

settings].

In the details screen of Redials/Received calls: Press C.

Select [Add prefix setting]/[International Call].

Continued on next page

Voice/Videophone Calls

Select the international access code/t/s.

Note

Setting country codes <Set country code>

Save up to 30 country codes to make international calls from overseas.

Voice/Videophone Calls

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[Int’l dial assist]/[Set country code].

Select a number to save as a new entry/t.

To change a saved country code: Select a number/t/[Edit]. To delete a saved country code: Select a number/t/

[Delete]/[Yes].

Enter a country name/t.

Enter up to 14 single-byte (7 double-byte) characters for a

country name.

Enter a country code/t.

Up to six digits can be entered including [+] for a country code.

Int’l prefix

Setting a first number to phone numbers

Save up to five prefixes, including international access codes, to

place at the beginning of phone numbers. The numbers are also available when calls are made from a phonebook, Redial or Received calls.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[Int’l prefix]. Select a number to save as a new entry/t.

To change a saved number: Select a number/t/[Change].

To delete a saved number: Select a number

/t/

[Delete]/[Yes].

Enter a prefix/t.

Press 0 for 1+ seconds to enter [+]. Up to 16 digits can be entered for a prefix.

Calling with prefixes <Select prefix>

In stand-by, enter a phone number/C.

In the phonebook entry details screen: Press C/[Number settings].

In the details screen of Redials/Received calls: Press C.

Select [Add prefix setting]/[Select prefix].

Select a prefix/t/s.

Sub address

Making calls with sub address set

Using sub address allows calls to be made to specific terminals when calling an ISDN terminal.

A sub address is a number assigned to a terminal when there are

multiple ISDN terminals for a single ISDN line. It is used in selecting contents for V-live.

In the Custom menu, select [Settings]/[Phone

settings]/[Other settings]/[Sub address]/[ON].

■ Making calls with sub address set

Ask the other party for their phone number and sub address.

In stand-by, enter a phone number, press * and

enter a sub address/s.

If b is entered at the beginning of a phone number or after 186,

184 or a prefix, the numbers after

number.

are recognized as the phone

Reconnect signal

Note

Reconnecting disconnected calls automatically

Reconnect signal is also available for PushTalk transmissions. The amount of time that can elapse to reconnect varies depending

on signal strength. The estimated time is approximately 10 seconds.

The other party hears no sound until the call is reconnected (up to

approximately 10 seconds). Charges are incurred for this duration.

In the Custom menu, select [Settings]/[Phone

settings]/[In-call settings]/[Reconnect signal]. Select an alarm tone/t.

Noise reduction

Reducing noise interference to hear calls clearly

It is recommended that this function be kept set to [ON].

In the Custom menu, select [Settings]/[Phone

settings]/[In-call settings]/[Noise reduction]/ [ON].

Noise reduction processes sound to make conversations clearer.

Sound quality may vary depending on surrounding noise and tone of the voice.

In-car hands-free

Using the handset in a car

Use the In-Car Hands-Free Kit 01 (sold separately) to connect hands-free devices such as car navigation to the FOMA terminal, and make/receive voice calls from the device. Refer to the user’s guide of each product for more details. Use a FOMA In-Car Hands-Free Cable 01 (sold separately) for the In-Car Hands-Free Kit 01 (sold separately).

Functions such as display settings, ring tones and Public mode

(Drive mode) call functions follow the FOMA terminal settings for incoming calls.

If a hands-free device has sound enabled, the device plays a ring

tone even when the FOMA terminal is set to the Manner mode or [Silent].

When the FOMA terminal sound is enabled, Set when folded is

followed if the handset is closed during a call. If the device sound is enabled, the call continues when the FOMA terminal is closed regardless of Set when folded.

Record message settings are followed even when the handset is

connected to the device.

Some handset functions may not be available depending on

device characteristics and specifications.

Voice/Videophone Calls

Answering calls/Videophone calls

Note

When receiving a call, verify it using ring tone, called LED, vibrator, and others.

Voice/Videophone Calls

When a call is received, the ring tone sounds and

the called LED flashes.

[Calling]/[Incoming videophone] appears while receiving a call.

A Multi Number name appears to the right of [Calling]/[Incoming videophone] when a call is received from a saved Multi Number.

When caller ID is sent, the phone number appears. If the other

party’s name and phone number are saved in the phonebook, they appear on the screen. When Picture call is saved in the phonebook, the image appears on the screen.

When the caller does not send caller ID, a non-disclosure

reason message appears.

• [User unset]: When the caller purposely withholds caller ID

• [Payphone]: When the call is received from a payphone

• [Not support]: When the caller cannot send caller ID, such as when the call is received from overseas or ordinary (landline) telephones via various transfer services (However, caller ID may still appear depending on the company)

Operation while receiving a call

On hold (nP. 72) Quick silent (nP. 115) Quick message (nP. 78) Manner mode set/disable (nP. 115) Forwarding with Call Forwarding Service: Press C/[Forward

calls].

Forwarding with Voice Mail Service: Press C/[Auto forward]. Call Rejection: Press C/[Call Rejection].

Press s.

For voice calls, calls can be received with Any key answer

(nP. 7 1 ).

To answer with a substitute image (Videophone): Press i.

Press H to end the call.

For a Videophone call, when images are not received from the

other party, a black screen appears.

When the handset beeps during a voice call indicating an incoming call

When any of services such as Voice Mail, Call Forwarding or Call

Waiting is subscribed to and Set arrival act is set to “Activate” while Arrival call act is set to [Answer], the following services can be performed when the handset beeps during a call.

 Call Forwarding Service (nP. 417)  Voice Mail Service (nP. 414)  Call Waiting (nP. 416)

Switching between voice call and Videophone to receive calls

The caller (other party) selects to switch between voice call and Videophone.

The call recipient cannot switch (Available with models that support

switching between voice call and Videophone).

Notify switch mode (nP. 84) must be set to “Activate” for the

recipient’s FOMA terminal.

The caller switches between Videophone and voice

Note

Switching from voice call to Videophone

call during a call.

Switching takes approximately 5 seconds. Switching may take

more time depending on signal status. [Please wait for a while] appears and a guidance message is played.

Switching from voice call to Videophone

When the caller switches to Videophone call, a guidance

message is played and the screen above appears before switching. Select [Yes] to send your image to the other party. Select [No] to send an image of [テレビ電話代替] with [Camera Off] superimposed.

Switching from Videophone to voice call

When the caller switches to voice call during Videophone call, a

guidance message is played before switching. Start conversation in voice call.

Switching is not available when another screen is displayed from

the Multi Assistant, while a call is on hold, during a packet transmission call, or when the FOMA terminal is closed. When any function is activated from the Submenu, switching may not be available.

Any key answer

Answering calls by pressing any key

Set Any key answer so that calls can be answered with the keys other than the ones normally used.

Normal Any key answer

Voice ca ll s1 to 9, 0, *, t, w, i, m, a, c,

Videophone s, i – PushTalk s, & (q) 1 to 9, 0, *, t, i, C, m, a, c,

* Calls cannot be received with x and y while 1Seg is being

activated.

In the Custom menu, select [Settings]/[Phone

$, x

, y

settings]/[Incoming settings]/[Any key answer]/[ON].

Rotation-link repl

Answering calls by rotating the display

If a voice/Videophone call or PushTalk is received in the Cycloid position, the call can be received just by returning the handset to the normal position.

In the Custom menu, select [Settings]/[Phone

settings]/[Incoming settings]/[Rotation-link repl]/[ON].

Voice/Videophone Calls

Note

Set when folded

Closing the FOMA terminal to end/ hold calls

Voice/Videophone Calls

In the Custom menu, select [Settings]/[Phone

settings]/[Set when folded]. Select an item/t.

Select a setting/t.

When set to [Hold sound], the set hold tone plays. Hold tone can

be changed. For Videophone calls, the image set in Hold image is sent to the other party.

When set to [Silent], the hold tone does not play. For Videophone

calls, the Chara-den or still picture set in Substitute image is sent to the other party.

When set to [Hold sound] or [Silent], open the FOMA terminal to

resume the call.

If a device such as a flat-plug earphone/microphone with switch

(sold separately) is connected, the call can continue while the handset is closed regardless of Set when folded.

For voice/Videophone calls, if the earphone/microphone is

disconnected while the FOMA terminal is closed, the call will become mute when [Silent] or [Finish call] is set, or the call is put on hold when [Hold sound] is set. The call resumes when the earphone/microphone is reconnected or the handset is opened. For PushTalk, if the earphone/microphone is disconnected while the FOMA terminal is closed, the call can be continued through the speaker whether set to Set when folded.

For PushTalk, when [Speaker phone] is set, open the FOMA

terminal to retrieve the transmission status of PT hands-free.

Earpiece volume

Adjusting the volume during a call

Select from [Volume 1] to [Volume 10]. The volume remains at an adjusted level even when the handset is

turned off or the battery pack is removed.

To adjust the earpiece volume when in stand-by nP. 111

During a call, press o/p.

Alternatively, press :/+. Or, select [Earpiece volume] from Submenu during a

Videophone call.

Press u to adjust the volume.

Alternatively, press :/+ to adjust the volume. After adjusting the volume, wait approximately 2 seconds and

the call display reappears.

On hold

Placing calls on hold

The other party is charged for the call while on hold. If subscribed to Call Forwarding Service or Voice Mail Service, a

received call is forwarded to the set destination or connected to the Voice Mail Service center (nP. 70).

During an incoming call, press H.

When a voice call is received, the other party hears the hold tone.

When a Videophone call is received, the On hold image set by

your FOMA terminal is sent to the other party with [On hold] superimposed.

To disconnect a call while on hold, press H, or when the other

party disconnects the call, the call is disconnected (The call is saved in Received calls).

Press s when ready to answer.

Press i during a Videophone call to answer with a substitute

image.

Set on hold tone/Set hold tone

Setting On hold/Hold tone

Set the on hold guidance and hold tone that the other party hears.

The following guidances are preset as on hold tone.

[On hold tone 1]

ただいま電話に出ることができません。そのままお待ちになるか、しばらくたってからおかけ直しください。

[On hold tone 2]

I can’t take your call now. Please hold the line for a moment or call me back later, thank you.

In the Custom menu, select [Settings]/[Snd/

Vibrator/Manner]/[Hold/On hold tone]. Select an item/t.

Select an on hold tone/hold tone.

To select the preset on hold tone: Select [On hold tone 1]/[On

hold tone 2].

To select the preset hold tone: Select [Hold melody 1]/[Hold

melody 2].

To check the on hold tone/hold tone: Select an on hold tone/hold

tone/i.

To record and set the Voice memo: Select [Original]/

[Record]/record/[Play]/select a memo/i.

• To stop the recording: During recording, press t.

To set the recorded Voice memo: Select [Original]/[Play]/

select a memo/i.

Public Mode (Drive Mode)

Using the Public Mode (Drive Mode)

The Public mode is an automatic answering service used to ensure manner in public places. When a voice call is received, the caller hears a message indicating you are driving or otherwise unable to speak (on the train, bus, in a movie theater, and others) and the call is disconnected.

Activating/Deactivating the Public mode is only available in

stand-by (Available even when A is showing on the screen).

Calls can be made normally in Public mode. This function is not available during data transmissions. A message requesting caller ID is played when [User unset] calls

are received while Caller ID Request is set to “Activate” (The Public mode guidance message is not played).

In stand-by, press * (for 1+ seconds).

The Public mode is set and _ appears. A message stating the owner of the phone is driving or is in a

place that does not allow mobile phone use is played to the other party.

If Manner mode is also set, Public mode setting is prioritized.

Disabling Public Mode (Drive Mode)

In stand-by, press * (for 1+ seconds).

• Public mode is disabled and _ disappears.

Voice/Videophone Calls

■ When the Public mode (Drive mode) is set

Note

A ring tone does not sound when a voice/Videophone or PushTalk call is received. The stock icon B (missed call) appears on the display and the call is saved in Received calls (nP. 62). When a voice call is received, the caller hears a message indicating

Voice/Videophone Calls

that you are driving or otherwise unable to speak and the call is disconnected. When a Videophone call is received, the Public mode video guidance is played to the other party and the call is disconnected. If the handset is turned off or in a place with no signal, the guidance for outside service area plays.

The FOMA terminal will not vibrate when i-mode mail, SMS, or

Message R/F is received even if the Vibration mode is set. Although a ring tone does not sound, the message is received automatically, and the received mail icon appears. When Area Mail is received, the dedicated alarm tone (beep sound), vibrator and called LED are not activated.

When data transmission is received, vibrator, ring tone and called

LED are not activated.

An incoming PushTalk is automatically disconnected and

[Connection failed] appears on the caller’s display. The Driving mode status can be notified to all connecting members if 3+ people have participated.

For arrival call actions when the Public mode (Drive mode) and

various network services are set at the same time n“Arrival call actions while the Public mode (Drive mode/Power OFF) and various network services are set” on P. 75

Even if the alarm time arrives in the Public mode, the alarm does

not sound. Called LED, vibrator and sub display are not activated.

Public Mode (Power OFF)

Using the Public Mode (Power OFF)

The Public mode (Power OFF) is an automatic answering service used to ensure manner in public places. Set the Public mode (Power OFF) to play a message for the caller indicating that the power is off and you are unable to speak (in a hospital, airplane, train near the priority seats), and the call ends.

In stand-by, press *25251/s.

The Public mode (Power OFF) is set (Nothing changes in

stand-by). When a call is received while the Public mode (Power OFF) is set, a message indicating that the owner of the phone is currently in a place that does not allow mobile phone use is played.

Disabling the Public mode (Power OFF)

In stand-by, press *25250/s.

• The Public mode (Power OFF) is disabled.

Checking the Public mode (Power OFF) setting

In stand-by, press *25259/s.

• Check the current setting.

■ When the Public mode (Power OFF) is set

The Public mode (Power OFF) remains set until disabled. The setting is not canceled when the power is turned ON. The Public mode (Power OFF) message is played when the handset is outside the service area or in a place with no signal. When a call is received, a message indicating that the owner of the phone is in a place that does not allow mobile phone use is played and the call is disconnected. An incoming PushTalk is automatically disconnected and [Connection failed] appears on the caller’s display. Members are notified that the owner of the phone is not a participant in the call when 3+ people have participated.

For arrival call actions when the Public mode (Power OFF) and

various network services are set at the same time n“Arrival call actions while the Public mode (Drive mode/Power OFF) and various network services are set” on P. 75

Arrival call actions while the Public mode (Drive mode/Power OFF) and various network services are set

Service

Voice Mail Service

Call Forwarding Service

When a voice call is

received

Public mode guidance

message is played to the other party and the call is connected to the Voice Mail Service center.

Public mode guidance

message is played to the other party and the call is forwarded to the destination.

The Public mode

guidance message that the other party hears follows Call Forwarding Service guidance settings.

When a Videophone call is

received

Public mode video

guidance is not played to the other party and the call is connected to

the Voice Mail Service center.

Public mode video

guidance is not played to the other party and the Videophone is forwarded to destination.

If the forwarding number

is not a 3G-324M compliant Videophone, the call is not connected.

Service

Nuisance Call Blocking Service

Caller ID Request Service

* The Public mode guidance message is not played when ring time is

set to 0 seconds and the call is connected to “Voice Mail Service” or “Call Forwarding Service”. The call is not saved in “Received calls” and the stock icon B (missed call) does not appear in the stand-by display.

When a voice call is

received

When a call is received from a number registered to the Nuisance Call Blocking Service, the call rejection message is played to the other party and the call is disconnected.

When calls are received

from all other numbers, Public mode guidance message is played to the other party and the call is disconnected.

When the caller ID is not

sent, the Caller ID request message plays and the call is disconnected.

When the caller ID is

sent, Public mode guidance message is played to the other party and the call is disconnected.

When a Videophone call is

received

When a call is received from a number registered to the Nuisance Call Blocking Service, call rejection video guidance is played to the other party and the call is disconnected.

When calls are received

from all other numbers, Public mode video guidance is played to the other party and the call is disconnected.

When the caller ID is not

sent, the Caller ID request video guidance is played to the other party and the call is disconnected.

When the caller ID is

sent, Public mode video guidance is played to the other party and the call is disconnected.

Voice/Videophone Calls

Missed calls

Note

Record message

Checking Missed calls

If an incoming call is not answered, the stock icon B (missed calls) and the number of missed calls appear in the

Voice/Videophone Calls

stand-by display (missed calls).

If missed calls are checked or the stock icon is selected and c is

pressed for 1+ seconds, the stock icon disappears.

In stand-by, press t.

Alternatively, press q (M) to check Received calls.

Select the stock icon B (missed call)/t.

Use the same operations as Received calls to make calls and

Record message (voice/Videophone calls)

Recording messages when calls cannot be answered

Set Record message to record messages when a call cannot be answered. When a voice call is received, a voice message is played and the caller’s message is recorded. When a Videophone call is received, a reply image is sent and the caller’s message and image are recorded.

Record message is not available when the FOMA terminal is turned

off or outside the service area. This function is convenient when used in conjunction with Voice Mail Service.

The Received calls list appears. D appears next to missed calls.

check other entries in Received calls.

Record up to three Record messages for voice calls (about 15 seconds each). Voice memos recorded during a voice call or in stand-by are also included in these three Record messages for voice calls.

Record up to two Record messages for Videophone calls (about 15

seconds each).

The number of recorded message icons appearing in stand-by is

the total number of Record messages (voice/Videophone calls) and Voice memo.

Record message cannot be set/disabled in the Manner mode.

Setting Record message (voice/Videophone calls)

In the Custom menu, select [Settings]/[Phone

settings]/[Record message]/[Record message]/[ON].

Record message is set and ] appears on

the display.

When a message is recorded, an icon

appears to show the number of messages. Example: D (for one message), E (for two messages), and others. When there are three Record messages (voice calls) and two Record messages (Videophone), does not respond when a voice/Videophone call is received. Delete unnecessary messages to reactivate Record message.

Disabling the Record message

Set Record message to [OFF].

For Voice Mail Service, record up to 20 messages of up to

approximately 3 minutes each. When Voice Mail Service is set, messages are saved at the Voice Mail Service center even if there are three Record messages (voice calls) or two Record messages (Videophone).

appears and Record message

When Record message (voice/Videophone calls)

Indicator Time

Voice call record

message

Videophone record

message

Note

Related Operations

is set

When a call is received, Record message is

activated after set answering duration (nP. 77).

The reply image appears. When a voice call is received, the

caller hears a voice guidance message. When a Videophone call is received, the caller hears a reply message and the image set in Videophone reply image is sent.

Press s to answer a call while playing a reply message,

recording sounds or movies. Press i to answer a Videophone call with a substitute image sent.

Record the caller’s message.

The caller hears a beep when recording starts. The indicator and time are estimates. While a message is recorded (voice call), the caller’s voice can

be heard through the earpiece. When the Manner mode is set, caller’s voice cannot be heard through the earpiece.

Record message (voice call) may not be saved if approximately 3

seconds or less.

Saved contents may be lost due to malfunctions, repairs or other

handling of the FOMA terminal. DoCoMo shall not be liable for any loss of content. It is recommended that a memo be kept of contents for Record message (voice/Videophone calls).

While Record message is activated (Videophone) or a

Videophone message is recorded, the reply image set on your FOMA terminal is sent to the other party with [Msg answering] or [Recording message] superimposed.

During recording, another call cannot be answered. The other

party hears a busy signal.

Record message is not available when the Public mode (Drive

mode) is set.

Set the message response time <Answering duration>

In the Custom menu, select [Settings]/[Phone settings]/[Record message]/[Answering duration]/ enter the answering duration/t.

To set response time for Record message immediately started:

Enter [000 seconds].

Voice/Videophone Calls

Continued on next page

Set reply messages <Set reply messages>

Note (Related operations)

1 In the Custom menu, select [Settings]/[Phone

settings]/[Record message]/[Reply message].

2 Select the type of messages.

Voice/Videophone Calls

To select the preset Reply message: Select [Reply

message 1]/[Reply msg 2(Eng)].

• To check the Reply message: Select the Reply

message/i.

To set after recording the Voice memo: Select [Original]/

[Record]/record/[Play]/select the memo/i.

• To stop the recording: While recording, press t.

To set the recorded Voice memo: Select [Original]/

[Play]/select the memo/i.

Set the reply image for Videophone Record message

<V.phone reply image>

1 In the Custom menu, select [Settings]/[Phone

settings]/[Record message]/[V.phone reply image].

2 Select a still picture/i.

To check the still picture: Select the still picture/t.

Answering duration

Cannot be set to the same time as the Auto answer setting. When Record message is set simultaneously with Voice Mail

Service or Call Forwarding Service, the priority will depend on the set ringing time.

To prioritize Record message, set answering duration shorter

than for Voice Mail Service or Call Forwarding Service.

Reply message

The following guidance messages are preset for the Reply

message.  [Reply message 1]

ただいま電話に出ることができません。ピーッという発信音のあとに、お名前とご用件をお話しください。

 [Reply msg 2(Eng)]

I can’t take your call now. Please leave your message, thank you.

Returns to default setting when original reply message is

deleted (nP. 79).

Videophone reply image

For images that can be sent n“Setting the image to send to

the other party” on P. 81

Quick message

Recording messages when incoming calls cannot be answered

Record a message for an incoming voice/Videophone call when Record message is not set.

During an incoming call, press C/[Record

message].

Alternatively, press 7 (for 1+ seconds) during an incoming call

to record.

Record messages nP. 7 6

Play/Delete recorded messages or voice memos

Memo list

Related Operations

Note (Related operations)

Indicator

Record message

for voice calls

Playing/Deleting Recorded messages or Voice memos

When Show received calls is set to [OFF], the memo list does not

appear and Recorded messages and Voice memos cannot be played/deleted.

Playing Recorded messages or Voice memos

The playback volume follows the Earpiece volume settings.

In the Custom menu, select

[LifeKit]/[Voice memo/Rec msg]/ [Play].

In stand-by: Press 7 (for 1+ seconds)/[Play].

When the stock icon F (message) appears

In stand-by, press t/select the stock icon F (Record

message)/t/[Play].

w appears next to memos that have not been played.

Types of message/memo Types of phone

Record message No icon Voice call

(

Voice memo during call

Voice memo in stand-by

Videophone call

Select a memo/t.

To stop the playback: Press t. The playback of Recorded messages and

Voice memos automatically stops when a call is received or the alarm sounds.

Deleting Recorded messages or Voice memos

In the memo list, select a memo/C/select the

deletion method/t/[Yes].

Lock Recorded message and Voice memo

In the Custom menu, select [LifeKit]/[Voice memo/Rec msg]/[Function lock]/enter the terminal security code/t/[ON].

For details on Function lock nP. 136

Voice/Videophone Calls

Chara-den

キャラ（女性） Woman キャラ（男性） Man

Chara-den nP. 322 During a Videophone call, set an image to send to the other party

Voice/Videophone Calls

as a Chara-den (nP. 81).

Preset Chara-den

The [キャラ（女性）] and [キャラ（男性）] are supported in the

Full-action mode and the Part-action mode.

Switching Chara-den during a Videophone call

Switch to send a different Chara-den during a Videophone call.

While sending Chara-den as a substitute image,

press C/[Chara-den set]/[Change Chara-den]/ select Chara-den/i.

Switching between Full-action and Part-action

While sending Chara-den as a substitute image,

press C/[Chara-den set]/[Change action].

Alternatively, press o (for 1+ seconds) to switch. Modes are switched between Full-action and Part-action.

Making Chara-den perform actions <Action list>

Alternatively, enter the action number by pressing 1 to 9 to have

the character perform an action.

Perform different actions together in the Part-action mode. Depending on the Chara-den, some actions are performed

automatically or may not be performed.

While sending Chara-den as a

substitute image, press C/ [Chara-den set]/[Action list].

Alternatively, press m or p (for 1+

seconds) to display the action list.

Select an action/t.

To end the action: Press 0. To display details: Select an action/i.

Setting the image to send to the

Note

Related Operations

Note (Related operations)

Note

other party

The following images can be sent during a Videophone call.

Use JPEG or GIF images saved in My picture of Data box that are

set to QCIF: 176×144. However, animated GIFs are not available.

Still pictures that are restricted for output from the FOMA terminal

are not available. Still pictures shot with the FOMA terminal are available regardless of File restriction (Still pictures are not available).

Changing the image to send during a call

Change the image to send during a Videophone call. Images set by Change send img are disabled when a Videophone

ends.

During a Videophone call, press C/[Change send

img].

Press i during a Videophone call to switch between camera

image and substitute image.

Select the image to send.

 Select [My side] (to switch to a camera image).  Select [Substitute image]/select a still picture/i.  Select [Chara-den]/select Chara-den/i.

Still pictures saved onto a microSD Memory Card are not available

directly. Copy to the [Acquired data] folder in My picture (phone) of Data box.

When the DTMF mode is set to [ON], the Chara-den key

operations become unavailable because of the touch-tone signals sent with the dial keys.

Voice/Videophone Calls

Zoom in and zoom out

1 During a Videophone call, press r/q. 2 Press v to adjust the zoom.

For the maximum zoom: Press a./For the minimum zoom:

Press m.

Switch between the main camera and the sub camera

During a Videophone call, press m (or press C/[Main/ sub camera]).

Send a still picture from Data box <File playback>

During a Videophone call, press C/[Change send img]/[File playback]/select a still picture/i.

Adjust brightness

During a Videophone call, press u (for 1+ seconds) to adjust brightness.

Zoom in/Zoom out

Set up to 22 zoom levels for main camera and 2 zoom levels for

sub camera.

Continued on next page

Switching the cameras

Note (Related operations)

Note

Priority (high b low)


Set a substitute image in the phonebook b Set a substitute image in the Videophone setting

When a Videophone call ends, the camera is reset to the sub

camera.

Voice/Videophone Calls

Alternatively, when the DTMF mode is set to [OFF], press # to

switch the cameras.

If the battery level is $ or less or if the camera area gets

hotter, the message stating that the camera cannot be used appears. The main camera becomes unavailable and is switched to a substitute image. During the sub camera is used, switching to the main camera is not possible.

Changing an image when making a call

<V.phone image>

The Videophone image is only enabled for one time.

In stand-by, enter a phone number/C.

In the phonebook entry details screen: Press C. In the details screen of Redials/Received calls: Press C.

Select [V.phone image].

Select the image to send.

 Select [My side] (camera image).  Select [Chara-den]/select Chara-den/i.

Setting a substitute image, On hold image or Hold image <Substitute image/On hold image/Hold image>

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[Set sending image]. Select an item/t.

Select an image/i.

While sending a still picture as substitute image, the still picture is

sent to the other party with [Camera Off] superimposed. If Chara-den is set, [Camera Off] does not appear.

Substitute images are sent in the following order.

Setting the outgoing image quality

Prefer img qual To place an emphasis on shape and color Normal To create a balance of clarity and movement Prefer motion spd To place an emphasis on movement

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[Visual preference].

During a Videophone call: Press C/[Videophone set]/[Visual

preference].

Select the image quality/t.

Image quality settings for the sender and receiver during a

Videophone call differ.

When the setting is made during a Videophone call, the setting is

only enabled for one time.

Hands-free V.phone

Note

Show me small Other

Show me big

Upper left

Lower right

Setting Hands-free Videophone

Set whether to automatically switch to Hands-free for Videophone calls.

When switching to Hands-free during a call nP. 59

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[Hands-free V.phone].

Select a setting/t.

Speak from approximately 20 to 40 cm away from the mouthpiece.

When the surroundings are noisy, sound may break up and the call may not be satisfactory.

When using Hands-free outdoors or in a location where

surroundings are noisy, use the flat-plug earphone/microphone with switch (sold separately).

If sound breaks up during a Hands-free call, lower the Earpiece

volume.

Setting the image during Videophone calls

Change the image displayed during Videophone calls.

■ Setting the Videophone display

The Videophone display setting and the subscreen position setting

remain even after a Videophone call ends.

Videophone display setting Subscreen

display setting

Voice/Videophone Calls

Continued on next page

During a Videophone call, press C/

Related Operations

Note (Related operations)

Note

[Videophone]/[Display setting]/[Subscreen disp].

In the Custom menu: Select [Settings]/[Phone settings]/

[Videophone set]/[Display setting]/[Subscreen position].

Voice/Videophone Calls

Select the display method/t.

Pause your camera image to send the image

During a Videophone call, press C/[Change send img]/[Self-portrait]/[Pause].

To disable Pause: Press i/c.

Make your camera image a normal image

During a Videophone call, press C/[Change send img]/[Self-portrait]/[Reverse on/off].

Pause

Paused camera image can be sent. While paused, your image is sent to the other party with

[Stopped] superimposed.

If the position is changed during the pause, Pause is disabled. When a Videophone call ends, the setting is reset.

Reverse on/off

Normal image is displayed as it is seen, and Mirror image is

seen with its left and right reversed.

The other party sees the normal image regardless of the setting. Reverse on/off is not available while a substitute image is sent

or the handset is in the Cycloid position.

<Pause>

Changing Videophone settings

Redialing as a voice call automatically

When a Videophone call is not connected, the call is automatically switched to the voice call and made again. If Videophone communication is started, Redial voice call is not

performed.

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[Redial voice call]/ [ON].

If a call is redialed as a voice call, voice call charges are incurred. Note that Redial voice call may not work if a call is placed to an

ISDN synchronous 64K, PIAFS access point or an ISDN Videophone that does not support the 3G-324M standard (nP. 58) (as of December 2007), or if an invalid phone number is dialed by mistake. In addition, charges may be incurred.

Notify switch mode

Setting to switch between voice call and Videophone

This setting lets the other party know whether the FOMA terminal can be switched between voice call and Videophone.

When Notify switch mode is set to “Deactivate”, the other party

cannot switch the call.

Notify switch mode cannot be changed during voice calls,

Videophone calls or outside the service area.

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[Notify switch mode].

Select a setting/t/[Yes].

To check settings: Select [Check Indication].

V-phone while packet

Selecting actions for incoming Videophone calls during i-mode

V-phone priority Answers incoming Videophone calls. Packet priority Rejects incoming Videophone calls. Voice mail Automatically connects to Voice Mail Service. Call forwarding Automatically connects to Call Forwarding

Videophone calls, during PushTalk transmission, Software update,

Pattern definitions update or data transmission using packet transmission, are rejected.

In the Custom menu, select [Settings]/[Phone

settings]/[Videophone set]/[V-phone while packet]/select an arrival action/t.

[V-phone priority] setting does not automatically end the packet

transmission unless the Videophone is answered (The packet transmission is disconnected when the call is answered).

To set to [Voice mail] or [Call forwarding], registration for the

respective service is required. If [Voice mail] or [Call forwarding] is set without subscription, a Videophone call is set to [Packet priority].

Service.

Picture memo

Saving the other party’s image as a still picture

During a Videophone call, take a still picture of the other party.

When Display Setting is set to [Me], this operation is not possible. The shot size applicable to still picture is QCIF: 176×144. The picture is saved to the [Camera] folder in My picture of Data

box.

The shot still picture cannot be output from the FOMA terminal.

During a Videophone call, press C/[Picture

memo]/t.

Shutter does not sound. While still pictures are being shot, your image is sent to the

other party with [Recording] superimposed.

Voice/Videophone Calls

LMEMO9

PushTalk

What is PushTalk?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Sending PushTalk transmissions . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Adding a member during PushTalk transmission

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Add member>90

Receiving PushTalk transmissions . . . . . . . . . . . . . . . . . . . . . . . . . 91

Adding to the PushTalk phonebook. . . . . . . <Add to PushTalk PB>92

Using the PushTalk phonebook to send PushTalk transmissions. . 94

Deleting PushTalk phonebook entries. . . . . . . . . . . . . . . . . . . . . . . 95

Setting PushTalk send/receive options . . . . . . . . . <Set PushTalk>96

What is PushTalk?

1 2

Press the PushTalk key, recall PushTalk phonebook entries, select the other party, and press the PushTalk key again to easily communicate with multiple people at once (up to five including yourself). Transmission fees are incurred each

PushTalk

time the key is pressed (transmission is sent).

Refer to the DoCoMo’s web site or “Mobile Phone User’s Guide

[Network Services]” for details and compatible models of PushTalk.

■ PushTalkPlus*

PushTalkPlus is a service to access a phonebook saved on the network and to communicate with up to 20 people (including yourself) at once. In addition, enjoy other useful functions such as checking the status of other members with more convenient use than PushTalk. Refer to the PushTalkPlus guide provided at the time of

subscription for details of the service.

* Subscription is required.

PushTalk transmission screen layout

2Group name

Group name saved in the PushTalk phonebook or the network

phonebook appears.

3Members

Name appears if saved in the phonebook. If the call is

transmitted from PushTalkPlus, the name saved in the network phonebook appears. Phone number appears for unregistered participants.

4Status of members

Transmission status of each member is shown. When a status

changes while connected, a tone indicating that the user is connected or disconnected (leaving PushTalk) sounds and the status shown changes.

 Connected: Participating in PushTalk.  Disconnected

PushTalk, the other party is out of the service area, or the other party has power turned off.

 Driving  Calling: Ringing the other party.

Scroll bar appears when all members cannot be shown on the

screen at once. Scroll with v to view members.

*1 Phone number appears for unregistered participants. Image also

appears if phonebook Picture call is set. If the call is transmitted from PushTalkPlus, the name saved in the network phonebook appears, and the image does not appear even if Picture call is set.

*2 Appears only when PushTalk transmission is in progress with

three or more participants.

: No reply, the other party has ended

: The other party has Public mode (Drive mode) set.

1Speaker’s name

Name of the person who is currently speaking

 Myself: When you are the speaker (have the right to speak)  No display: Nobody is speaking  ?: When the speaker is not identified

appears.

Note

Sending PushTalk transmissions

Use packet transmissions and press the PushTalk key to communicate easily.

Only one person can speak at once. Press & (q) to get the right to

speak. Voice can only be transmitted when granted the right to speak. When granted the right to speak, other people’s voices are inaudible.

PushTalk charges are incurred for the caller while & (q) is pressed

and the right to speak is being granted.

PushTalk and PushTalkPlus cannot be used with the Number B of

2in1.

In stand-by, enter a phone number.

Alternatively, use one of the following methods.

From the PushTalk phonebook (nP. 94) From the phonebook (nP. 103) From Redial (nP. 62) From Received calls (nP. 62) With Notify caller ID/No caller ID (nP. 56) Using Phone To function (nP. 188)

Press & (q).

flashes at the upper left of the display while dialing. When the other party replies, a tone indicating that the user is connected sounds,

appears.

To activate/deactivate Hands-free: Press s/i. For details on adjusting the volume nP. 72

• Adjust the earpiece volume with side keys when the FOMA

To speak, speak while pressing & (q) when

speaker’s name is blank.

lights and the PushTalk transmission screen

terminal is closed.

The right to speak is granted, a right-obtained tone sounds, and

[Myself] appears for the speaker’s name.

An error tone sounds if & (q) is pressed while another person is

speaking. Release & (q) when finished speaking. A right-released tone sounds.

Press H to end the transmissions.

The number of times the right to speak was granted is shown.

PushTalk calls cannot be made to emergency numbers (110, 119,

and 118). Even if the transmission of some members (including sender) is

disconnected, other members can continue PushTalk transmission.

There is a time limit when speaking. If the right to speak keeps

obtained for a set time, a tone indicating that the speaking time is over sounds and the right to speak is terminated.

i-mode transmission is disconnected if PushTalk transmission is

sent during i-mode.

When Set PushTalk arrival action is set to [Answer], press s to

end PushTalk transmission and answer voice calls received during PushTalk transmission.

When a voice call is received while a hands-free call is in

progress, hands-free is disabled if the voice call is answered.

PushTalk is automatically disconnected when no one speaks for a

set length of time.

When the PushTalk sender has set the network service’s Notify

caller ID (nP. 55) to “Send ID”, phone numbers for the caller and all members are notified. If set to “No ID”, [No ID] appears for the speaker and member fields on the handsets of all the members who received the transmission. The phone number is important personal information. Be careful when sending caller ID.

Approximate number of times the right to speak was obtained

appears when PushTalk transmission is ended. 999 is the maximum value that appears. When exceeded, [|||] appears.

Continued on next page

PushTalk

During PushTalk transmission, i-mode mail and Message R/F are

Related Operations

Note (Related operations)

Note

held at the i-mode center. However, SMS are received automatically even during PushTalk transmission.

PushTalk

Return to a PushTalk conversation with multiple members after disconnecting

Select Redial/Received calls/& (q).

Press C during PushTalk transmission/[Add

member].

Alternatively, press m during PushTalk transmission to add a

member.

Select the adding method and send a transmission.

 Select [View phonebook]/select a name/t.  Select [View PT phonebook]/select a name i

(repeatable)/C.

 Select [Direct input]/enter a phone number/C.

When a PushTalk call is disconnected, or when a PushTalk call

cannot be answered after the PushTalk transmissions with multiple members, the transmissions can only be rejoined by calling the member from the Received calls/Redial if the PushTalk transmissions are still in progress.

If the PushTalk transmission has been ended, a new

transmission is sent from you.

Add member

Adding a member during PushTalk transmission

When a PushTalk sender is Myself, add a member during PushTalk transmission.

When calling from PushTalkPlus, a member cannot be added. Even if a member is added during transmission, it is not recorded in

Redial. It is not recorded in Received Calls on the other party’s terminal that has been already in transmission.

Add up to four members to send a transmission as many times as

necessary. When the transmissions are already sent to four members, re-calling a disconnected member is available, but a new member cannot be added.

When the other party on the PushTalk transmission uses a model

which does not support the Add member function, the other party’s terminal may operate as follows.



When a member is added, the added member does not appear and a tone indicating that the member is connected does not sound.



When an added member speaks, [?] appears for the speaker name field.

 When an added member leaves PushTalk, a tone indicating

that the member is disconnected does not sound.

When a PushTalk sender has set the network service’s Notify caller ID (

nP. 55

numbers are sent to all the members including the added members. If set to “No ID”, [No ID] appears for the speaker and member fields on the handsets of all the members including the added members. However, when the other party on the PushTalk transmission uses a model which does not support the Add member function, the added members do not appear on the other party’s screen regardless of the caller ID setting.

When the 2in1 mode is set to [A mode], the entries saved in the

phonebook whose Phonebook 2in1 set is set to [B] cannot be displayed.

) to “Send ID”, the sender and all members’ phone

Receiving PushTalk transmissions

Note

When PushTalk is received, the ring tone sounds

and the called LED flashes.

The following operations can be performed during an incoming call.

 Quick silent (nP. 115)  Manner mode enable/disable (nP. 115)  To disconnect: Press H (When the FOMA terminal is

closed: Press :).

Press & (q)/s.

A PushTalk call can also be received with Any key answer

(nP. 7 1 ) .

When receiving a PushTalk call in the Cycloid position, switch to

the normal position to receive the call (nP. 71).

A call is answered with hands-free if the FOMA terminal is

closed. The operation follows Hands-free PT when the FOMA terminal is open (nP. 96).

a at the upper left of the display lights and the PushTalk

transmission screen appears.

The transmission procedures are the same as those of

“Sending PushTalk transmissions” on P. 89.

For details on adjusting the volume n“Adjusting the volume

during a call” on P. 72

Press H to end the transmissions.

When Set auto answer is set to [ON], received PushTalk calls are

automatically answered with hands-free. However, calls are not answered automatically even if Set auto answer is set to [ON] while in the Manner mode.

To accept/reject calls from specified callers, set Accept calls,

Reject calls, and Reject unknown. The settings are common with voice/Videophone call. However, they are not applied to transmissions from PushTalkPlus.

PushTalk calls received during a voice/Videophone call or data

transmission are not connected. During a voice call, the call is recorded in Received calls, and the stock icon B (missed call) appears. During a Videophone call or data communication, the call is not recorded.

When a Videophone call, 64K data communication, or different

PushTalk call is received during PushTalk transmission, the call is recorded in Received calls and the PushTalk transmission is continued. When Set PushTalk arrival action is set to [Answer], press s to end PushTalk transmission and answer voice calls received during PushTalk transmission. If Set PushTalk arrival action is set to other than [Answer], the call is recorded in Received calls and the PushTalk transmission is continued.

When i-mode arrival action is set to [PushTalk preferred], i-mode transmission is disconnected and PushTalk is connected if PushTalk is received during i-mode. When set to [i-mode preferred], PushTalk is not connected nor recorded in Received calls.

When a PushTalk call is received while Public mode (Drive mode)

is set and the handset is turned on, the call is not connected but is recorded in Received calls and the stock icon B (missed call) appears. [Driving] appears for the status on the other member’s transmission screen. The message does not appear if the other party is one person.

PushTalk

Add to PushTalk PB

PushTalk group list

PushTalk member list

Group members screen

& (q)

Adding to the PushTalk phonebook

Entries saved to the PushTalk phonebook are also saved to the FOMA terminal handset phonebook. Save an entry to the FOMA terminal handset phonebook and save the name, reading and one phone number to the

PushTalk

PushTalk phonebook. Save entries already saved in the FOMA terminal handset phonebook to the PushTalk phonebook. Up to 1,000 entries can be saved in the PushTalk phonebook (nP. 98).

When the 2in1 mode is set to [B mode], saving to the PushTalk

phonebook is not available.

When the 2in1 mode is set to [Dual mode], the entries saved in the

phonebook whose Phonebook 2in1 set is set to [B] cannot be saved in the PushTalk phonebook.

When the 2in1 mode is set to [A mode], the entries saved in the

phonebook whose Phonebook 2in1 set is set to [B] cannot be displayed.

■ Entry items that can be saved in one PushTalk

phonebook entry

Icon Item Details

Name Enter a name.

= B

Reading Reading is entered automatically.

PushTalk group

PushTalk phone number

Entries can be sorted and saved in 1 to 9 PushTalk groups.

Save a phone number for PushTalk.

■ PushTalk phonebook

Select a group from the PushTalk group list or select members from the PushTalk member list to send a transmission to the members saved in the PushTalk phonebook. Press m to switch between the PushTalk group list screen and the PushTalk member list screen.

■ Adding

In the PushTalk member list screen, press C/[New].

Add to the PushTalk phonebook.

 Select [View phonebook]/select a name/t.

• When multiple phone numbers are saved, select a name,

press i, select a phone number to use for PushTalk, and press t.

 Select [Direct input]/add to the phonebook.

• The FOMA terminal handset phonebook name entry screen appears.

• For details on saving n“Saving to the phonebook” on P. 99

Registering to the PushTalk group

Related Operations

Set groups in the PushTalk phonebook to easily call all members of a PushTalk group. Save up to 19 members per group. Up to four people can be called

simultaneously.

Save up to nine groups. Also, editing group names is available.

■ Creating a new PushTalk group <New group>

To create a new group, delete an already registered group from [グループ１] to [グループ９] in advance (nP. 95).

In the PushTalk member list screen/the PushTalk

group list screen, press C/[Set PushTalk group]/[New group].

Enter a PushTalk group name/t.

Enter up to 20 single-byte (10 double-byte) characters for a

PushTalk group name.

Edit the PushTalk group name <Edit group name>

1 In the PushTalk group list screen, select a group/

C/[Set PushTalk group]/[Edit group name].

In the PushTalk member list screen: Press C/[Set

PushTalk group]/[Edit group name]/select a group/t.

2 Edit the group name/t.

■ Adding to the PushTalk group <Add PushTalk group>

Save PushTalk phonebook entries that are already saved as PushTalk members.

In the PushTalk member list screen, select a name/i.

Repeat step 1 to select multiple names. When nothing is checked, only the entry at the position of the

cursor is selected.

Press C/[Add PushTalk group].

Select the PushTalk group/t/select a save

location/t.

If the selected location already has a member saved, the

member is overwritten. The same phone number cannot be saved more than once to the same group.

Selecting a save location is not necessary if multiple names are

selected in step 1.

Add to the PushTalk group from the PushTalk group list screen

1 In the PushTalk group list screen, select a group/C.

In the Group members screen: Press C.

Select [Set PushTalk group]/[Add PushTalk group] select a name t (repeatable)/i.

■ Editing PushTalk phonebook entries <Edit data>

Change phone numbers and groups of saved PushTalk phonebook entries.

In the PushTalk member list screen, select a

name/C/[Edit data]. Select an item/t/edit the PushTalk phonebook

entry.

PushTalk

Continued on next page

Related Operations

To change phone numbers, select a phone number and select other phone numbers saved to the FOMA terminal handset phonebook entry.

To change the group to save, select in order of the group to be

changed, the group to change and the save list.

To add and save to other groups, select [No groups], select the

group to save, and select the save list.

PushTalk

Press i/[Yes].

Using the PushTalk phonebook to send PushTalk transmissions

Save members in the PushTalk phonebook in advance.

When the 2in1 mode is set to [B mode], the PushTalk phonebook

cannot be used.

When the 2in1 mode is set to [Dual mode], the phonebook whose

Phonebook 2in1 set is set to [B] cannot be used.

■ Sending from PushTalk groups

Transmit to up to four people at once.

In the PushTalk group list screen, select the other

party.

To send PushTalk transmissions to all members of a group: Select a group. To send PushTalk transmissions to some members of a group: Select a group

• E appears for selected entries, and H appears for

unselected entries.

• When nothing is checked, only the party at the position of the cursor is selected.

Press & (q).

/t/

select a name i (repeatable).

Transmission procedures n“Sending PushTalk transmissions” on P. 8 9

When [Exceeds max number of simultaneous calls] appears,

five or more saved members are set. Select up to four members and send transmissions.

■ Selecting the other party and sending a

transmission

In the PushTalk member list screen, select a name

i (repeatable).

Quick search: Enter each character to view the closest entry

sequentially.

Press & (q).

Receive transmissions automatically <Set auto answer>

In the PushTalk member list screen, press C/[Set PushTalk]/[Set auto answer]/[ON].

Set the ring duration <Ring time setting>

In the PushTalk member list screen, press C/[Set PushTalk]/[Ring time setting]/enter the duration of ring tone/t.

Set the operation when the FOMA terminal is closed during PushTalk transmission

In the PushTalk member list screen, press C/[Set PushTalk]/[Set when folded]/select the setting/t.

Select Send own no. or No caller ID when send a transmission

In the PushTalk member list screen, press C/[Caller ID setting]/select the setting/t.

Note (Related operations)

Set auto answer

When a call is received with Auto answer, the call is

automatically switched to hands-free. Auto answer is not available while in the Manner mode.

The Set auto answer in the PushTalk phonebook is linked with

the PushTalk in Auto answer setting.

Ring time setting

When calls are not answered within the set duration in a

transmission with multiple people, [Disconnected] appears on the other members’ transmission screens.

The Ring time setting in the PushTalk phonebook is linked with

PT ring time set in Ring time setting.

Ring time setting cannot be selected when Set auto answer is

set to [ON].

Set when folded

Select to end the transmission or activate speakers when the

FOMA terminal is closed.

The Set when folded in the PushTalk phonebook is linked with

the PushTalk in the Set when folded.

Caller ID setting

When Caller ID setting is set to [Send own no.], phone numbers

for the caller and all members are notified. If set to [No caller ID], [No ID] appears for the speaker and member fields on the handsets of all the members who received the transmission.

If Caller ID setting is set when PushTalk transmission is sent, it

is prioritized than the network service’s Notify caller ID (nP. 55).

When Caller ID setting is set to [As NW setting], a call is made

according to the network service’s Notify caller ID.

Network connection

A PushTalkPlus subscription is required to use the network

connection.

Deleting PushTalk phonebook entries

In the PushTalk member list screen, select a

name/C/[Delete].

Select the deletion method.

 Select [Delete one].  Select [Delete selected]/select a name t (repeatable)/

 Select [Delete all]/enter the terminal security code/t.

Select the phonebook type to delete/t/[Yes].

Deleting the PushTalk group <Delete>

In the PushTalk group list screen, select a group/

C/[Delete]. Select the deletion method/t/[Yes].

Deleting members from PushTalk groups

In the PushTalk group list screen, select a group/

t. Select a name/C/[Delete from group].

Select the deletion method.

 Select [Delete one]/[Yes].  Select [Delete selected]/select a name t (repeatable)/

C/[Yes].

 Select [Del all in group]/[Yes].

PushTalk

Set PushTalk

Note

Setting PushTalk send/receive options

Set the following items.

Item Setting details Page

Ring time setting Set the duration to sound the PushTalk

PushTalk

Set auto answer Set whether to automatically answer

Set PT arrival act

i-mode arrival act

Hands-free PT

Set when folded Set [Finish call] or [Speaker phone] (other

Set mute ring time

Reconnect signal

ring tone.

PushTalk transmissions. Set actions for voice calls received during

PushTalk transmissions. Set to receive/reject PushTalk

transmissions received during i-mode transmissions.

Set whether to automatically switch to Hands-free when PushTalk transmissions start.

party’s voice is heard through the speakers) to engage when the FOMA terminal is closed during a transmission.

Set the number of seconds to delay the start of ring tone for calls from unknown callers and calls with no ID. This setting is applied to both voice/Videophone calls.

Set to automatically reconnect when a transmission is disconnected due to signal conditions. This setting is applied to both voice/Videophone calls.

P. 11 4

P. 400

P. 9 6

P. 191

P. 9 6

P. 7 2

P. 141

P. 6 9

Selecting actions for incoming calls during a transmission

Voice Mail Automatically connect to Voice Mail Service*. Call Forwarding Automatically connect to Call Forwarding Service*. Call Rejection Reject calls. Answer Select to continue PushTalk transmission or end

* Subscription is required to use these services. If Set PT arrival act

is set without subscription, a voice call is set to [Answer].

In the Custom menu, select [Settings]/[Phone

and answer the incoming voice call.

settings]/[Set PushTalk]/[Set PT arrival act].

In the PushTalk member list screen: Press C/[Set

PushTalk]/[Set PT arrival act].

Select the arrival act/t.

Setting the PushTalk hands-free operation

<Hands-free PT>

The setting is switched to hands-free regardless of Hands-free PT if

the FOMA terminal is closed.

In the Custom menu, select [Settings]/[Phone

settings]/[Set PushTalk]/[Hands-free PT].

In the PushTalk member list screen: Press C/[Set

PushTalk]/[Hands-free PT].

Select the setting/t.

The setting cannot be switched to hands-free while in the Manner

mode even if Hands-free PT is set to [ON].

Phonebook

Phonebooks available on the FOMA terminal. . . . . . . . . . . . . . . . . 98

Saving to the phonebook

. . . . . . . . . . . . . . . <Add to phonebook/FOMA card phonebook>99

Setting groups . . . . . . . . . . . . . . . . . . . . . . . . . . <Group settings>103

Making calls from the phonebook . . . . . . . . <Search phonebook>103

Editing phonebook entries. . . . . . . . . . . . . . . . . . . . <Edit entries>106

Deleting phonebook entries. . . . . . . . . . . . . . . . . <Delete entries>107

Calling and sending mail with a few key strokes

. . . . . . . . . . . . . . . . . . . . . . . . . . <2-touch dialing/2-touch mail>107

Saving (restoring/updating) the phonebook to the Data Storage

Center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . <Data Sec. Service>108

Phonebooks available on the FOMA terminal

Use FOMA terminal handset phonebook and FOMA card phonebook. Save items such as names, phone numbers and mail addresses for FOMA terminal handset and FOMA card phonebooks.

Phonebook

FOMA terminal handset phonebook, FOMA card phonebook and PushTalk phonebook

Entries saved in FOMA card phonebook are available even if your FOMA card is inserted into other FOMA terminals. To use phonebook on other FOMA terminals, save numbers in FOMA card phonebook. For details on PushTalk phonebook nP. 92

■ Number of entries in phonebook

Phonebook Number of entries

FOMA terminal handset phonebook 1,000 FOMA card phonebook 50 PushTalk phonebook 1,000

■ Entry items for one phonebook

Entry status

Icon Item Details

Name Enter a name. One One

Reading

Group

Reading is entered automatically.

Entries can be sorted in groups.

FOMA

terminal

handset

One One

groups

FOMA

card

groups

Icon Item Details

Save phone numbers. In the

9/S

S/T

P G

;

Phone

number

Mail

address

Company/ school

Department

Title Enter title. One –

Postal code

Postal address

Birthday Enter a birthday. One –

Memo Save memos. One –

Secret

Secret code

Select ring tone

FOMA terminal handset phonebook, select from one of nine icons for each phone number.

Save mail addresses. In the FOMA terminal handset phonebook, select from one of six icons for each address.

Enter company/school name.

Enter department. One –

Enter postal code. One –

Enter postal address. One –

Keep privacy by hiding phonebook entries. Set to keep phonebook entries private.

Enter secret code specified by the other party. Use when sending mail.

Differentiate callers using specific ring tones or Chaku-motion.

Entry status

FOMA terminal handset

Three One

One –

A –

FOMA

card

NTT SH905iTV User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Using the FOMA terminal

Using this manual

Viewing/Searching this manual

Easy Search

Contents/Precautions

Contents

Main functions of the FOMA SH905iTV

Handling precautions

Intellectual property

Standard parts packaged with unit and main optional parts

Before Using the Handset

Component names and functions

Viewing the display

TOUCH CRUISER pad

Menu settings and selections

Displaying the Supportbook

Using a FOMA card

Charging the FOMA terminal

How to check the battery level

Turning the power on and off

Switching the display to English

Making the initial setting

Setting the date and time

Sending your own phone number to the other party

Checking your phone number

Voice/Videophone Calls

Using Videophone

Making calls/Videophone calls

Switching between voice call and Videophone

Using Redial and Received calls

Setting Chaku-moji

Sending touch-tone signals with simple operations

Making international calls

Setting an international call

Setting a first number to phone numbers

Making calls with sub address set

Reconnecting disconnected calls automatically

Reducing noise interference to hear calls clearly

Using the handset in a car

Answering calls/Videophone calls

Switching between voice call and Videophone to receive calls

Answering calls by pressing any key

Answering calls by rotating the display

Closing the FOMA terminal to end/ hold calls

Adjusting the volume during a call

Placing calls on hold

Setting On hold/Hold tone

Using the Public Mode (Drive Mode)

Using the Public Mode (Power OFF)

Checking Missed calls

Recording messages when calls cannot be answered

Recording messages when incoming calls cannot be answered

Playing/Deleting Recorded messages or Voice memos

Chara-den

Setting Hands-free Videophone

Setting the image during Videophone calls

Changing Videophone settings

Setting to switch between voice call and Videophone

Selecting actions for incoming Videophone calls during i-mode

Saving the other party’s image as a still picture

PushTalk

What is PushTalk?

Sending PushTalk transmissions

Adding a member during PushTalk transmission

Receiving PushTalk transmissions

Adding to the PushTalk phonebook

Using the PushTalk phonebook to send PushTalk transmissions

Deleting PushTalk phonebook entries

Setting PushTalk send/receive options

Phonebook

Phonebooks available on the FOMA terminal
