250 WATT
POW ER INVERTER
MODEL: S LX-250- DRV
PLUG YOUR INVERTER INTO THE
LIGHTER SOCKET OR CLAMP ON TO
YOUR VEHICLE BATTERY TO CONNECT.
THEN PLUG YOUR DEVICE INTO THE
INVERTER FOR POWER.
SPECIFICATIONS
TM
HOUSEHOLD POWER
FROM A 12V B ATTERY
Charge laptops, smart phones, tablets, camera
batteries and MP3 players. Make vacations with
the kids more relaxing as they watch movies and
play games without the fear of batteries going
dead. Run a mobile oce - print receipts, make
copies, send emails… and never miss a call from
your boss while you’re playing hooky.
DESIGN F EATURES
- Light weight, compact, highly portable
- Easy to install and operate
- 2.1 Amp USB Port (compatible with all new
release smart phones)
- Load controlled cooling fan
- Cool surface technology
- Soft start technology
- Low battery input alarm
- Universal protection circuit – thermal, battery,
overload, short circuit & earth fault
- Safety certied to UL standards
- 2 YEAR W ARR ANTY
BATTERY SYSTEM VOLTAGE 12 VDC
NOMINAL INPUT VOLTAGE 12.5 VDC
INPUT VOLTAGE RANGE
INPUT
INPUT CURRE NT AT CONTINUOUS POWER 22.3A to 24.2A
INPUT CURRE NT AT NO LOAD 0.2A to 0.3A
OUTPUT VOLTAGE WAVE FORM Modied Sine Wave
OUTPUT VOLTAGE (FREQUENCY)
OUTPUT POWE R, CONTINUOUS (RES ISTIVE LOAD) 250W
OUTPUT POWE R, SURGE (<1 SEC., RES ISTIVE LOAD)
OUTPUT
PEAK E FFICIENCY (AT 50% OF CONTINUOUS POWER) 90%
USB CHARGING PORT USB 3.0, Connector Type “A”: 5 VDC, 2.1A
LOW INPUT VOLTAGE ALARM 10.8 VDC ± 0.3 VDC
LOW INPUT VOLTAGE SHUTDOWN 10.5 VDC ± 0.3 VDC
HIGH INPUT VOLTAGE SHUTDOWN 15.4 VDC ± 0.2 VDC
OVERLOAD AND GROUND FAULT SHUT DOWN Yes. Latches in shutdown condition. Manual
OVER TEMPE RATURE SHUTDOWN Yes. Auto reset on cooling down.
PR O TECT IO N S
COOLING FAN Load controlled: Switches ON at 8W to 12W
INPUT FUSE : 32V, AUTOMOTIVE TYPE ATC (INSIDE
THE UNIT, NOT USER ACCESSIBLE )
DC INPUT M4 Thumb Screw
AC OUTPUT One NEMA5-15 R Outlet
OUTLETS
OPER ATING TEMPE RATURE RANGE 0°C to 25°C / 32°F to 77°F at 100% loading;
OPER ATING HUMIDITY
NEUTRAL TO CHASSIS BONDING No. Neutral of the NE MA5-15R AC Outlet is
DIMENSIONS (W x D x H)
GENERAL
WEIGHT 0.42 kg / 0.92 lb
DC INPUT CABLES INCLUDED AWG#16 Cable with 12V power plug (12V plug
Safety Compliance Conforms to UL S TD 458
> 10.8 VDC to < 15.4 VDC
115VAC + 10% / -2%; 60 Hz ± 5%
500W
reset: Switch OFF the ON/ OFF Switch, wait 3
mins & Switch ON again.
30A
26°C to 35°C / 78.8°F to 95°F at 80% loading
< 80%; Non-condensing
isolated from the chassis
114.4 x 150 x 46 mm
4.5 x 5.9 x 1.8 in
contains replaceable 250V, 8A fuse - Bussmann
Type AGC-8); AWG#14 Cable with battery clamps
SAFETY
NOTE: Specications are subject to change without notice
12002-SLX-250-D RV-1113
450 WATT
POW ER INVERTER
MODEL: S LX-450- DRV
PLUG YOUR INVERTER INTO THE
LIGHTER SOCKET OR CLAMP ON TO
YOUR VEHICLE BATTERY TO CONNECT.
THEN PLUG YOUR DEVICE INTO THE
INVERTER FOR POWER.
SPECIFICATIONS
TM
HOUSEHOLD POWER
FROM A 12V B ATTERY
Charge laptops, smart phones, tablets, camera
batteries and MP3 players. Make vacations with
the kids more relaxing as they watch movies and
play games without the fear of batteries going
dead. Run a mobile oce - print receipts, make
copies, send emails… and never miss a call from
your boss while you’re playing hooky.
DESIGN F EATURES
- Light weight, compact, highly portable
- Easy to install and operate
- 2.1 Amp USB Port (compatible with all new
release smart phones)
- Load controlled cooling fan
- Cool surface technology
- Soft start technology
- Low battery input alarm
- Universal protection circuit – thermal, battery,
overload, short circuit & earth fault
- Safety certied to UL standards
- 2 YEAR W ARR ANTY
ON
5VDC 500mh
OUTPUT: 115V AC
BATTERY SYSTEM VOLTAGE 12 VDC
NOMINAL INPUT VOLTAGE 12.5 VDC
INPUT VOLTAGE RANGE
INPUT
INPUT CURRE NT AT CONTINUOUS POWER 41.3A to 43.3A
INPUT CURRE NT AT NO LOAD 0.25A to 0.35A
OUTPUT VOLTAGE WAVE FORM Modied Sine Wave
OUTPUT VOLTAGE (FREQUENCY)
OUTPUT POWE R, CONTINUOUS (RES ISTIVE LOAD) 450W
OUTPUT POWE R, SURGE (<1 SEC., RES ISTIVE LOAD)
OUTPUT
PEAK E FFICIENCY (AT 50% OF CONTINUOUS POWER) 90%
USB CHARGING PORT USB 3.0, Connector Type “A”: 5 VDC, 2.1A
LOW INPUT VOLTAGE ALARM 10.8 VDC ± 0.3 VDC
LOW INPUT VOLTAGE SHUTDOWN 10.5 VDC ± 0.3 VDC
HIGH INPUT VOLTAGE SHUTDOWN 15.4 VDC ± 0.2 VDC
OVERLOAD AND GROUND FAULT SHUT DOWN Yes. Latches in shutdown condition. Manual
OVER TEMPE RATURE SHUTDOWN Yes. Auto reset on cooling down.
PR O TECT IO N S
COOLING FAN Load controlled: Switches ON at 8W to 12W
INPUT FUSE : 32V, AUTOMOTIVE TYPE ATC (INSIDE
THE UNIT, NOT USER ACCESSIBLE )
DC INPUT M4 Thumb Screw
AC OUTPUT Two NEMA5-15 R Outlets
OUTLETS
OPER ATING TEMPE RATURE RANGE 0°C to 25°C / 32°F to 77°F at 100% loading;
OPER ATING HUMIDITY
NEUTRAL TO CHASSIS BONDING No. Neutral of the NE MA5-15R AC Outlet is
DIMENSIONS (W x D x H)
GENERAL
WEIGHT 0.6 kg / 1.3 lb
DC INPUT CABLES INCLUDED AWG#16 Cable with 12V power plug (12V plug
Safety Compliance Conforms to UL S TD 458
SAFETY
NOTE: Specications are subject to change without notice
> 10.8 VDC to < 15.4 VDC
115VAC + 10% / -2%; 60 Hz ± 5%
900W
reset: Switch OFF the ON/ OFF Switch, wait 3
mins & Switch ON again.
70A (2 x 35A in parallel)
26°C to 35°C / 78.8°F to 95°F at 80% loading
< 80%; Non-condensing
isolated from the chassis
154 x 151 x 56.5 mm
6.1 x 6.0 x 2.2 in
contains replaceable 250V, 8A fuse - Bussmann
Type AGC-8); AWG#12 Cable with battery clamps
12002-SLX-450-D RV-1113
800 WATT
POW ER INVERTER
MODEL: S LX-800- DRV
PLUG YOUR INVERTER INTO THE
LIGHTER SOCKET OR CLAMP ON TO
YOUR VEHICLE BATTERY TO CONNECT.
THEN PLUG YOUR DEVICE INTO THE
INVERTER FOR POWER.
SPECIFICATIONS
TM
HOUSEHOLD POWER
FROM A 12V B ATTERY
Charge laptops, smart phones, tablets, camera
batteries and MP3 players. Make vacations with
the kids more relaxing as they watch movies and
play games without the fear of batteries going
dead. Run a mobile oce - print receipts, make
copies, send emails… and never miss a call from
your boss while you’re playing hooky.
DESIGN F EATURES
- Light weight, compact, highly portable
- Easy to install and operate
- 2.1 Amp USB Port (compatible with all new
release smart phones)
- Load controlled cooling fan
- Cool surface technology
- Soft start technology
- Low battery input alarm
- Universal protection circuit – thermal, battery,
overload, short circuit & earth fault
- Safety certied to UL standards
- 2 YEAR W ARR ANTY
BATTERY SYSTEM VOLTAGE 12 VDC
NOMINAL INPUT VOLTAGE 12.5 VDC
INPUT VOLTAGE RANGE
INPUT
INPUT CURRE NT AT CONTINUOUS POWER 72A to 75A
INPUT CURRE NT AT NO LOAD 0.25A to 0.35A
OUTPUT VOLTAGE WAVE FORM Modied Sine Wave
OUTPUT VOLTAGE (FREQUENCY)
OUTPUT POWE R, CONTINUOUS (RES ISTIVE LOAD) 800W
OUTPUT POWE R, SURGE (<1 SEC., RES ISTIVE LOAD)
OUTPUT
PEAK E FFICIENCY (AT 50% OF CONTINUOUS POWER) 90%
USB CHARGING PORT USB 3.0, Connector Type “A”: 5 VDC, 2.1A
LOW INPUT VOLTAGE ALARM 10.8 VDC ± 0.3 VDC
LOW INPUT VOLTAGE SHUTDOWN 10.5 VDC ± 0.3 VDC
HIGH INPUT VOLTAGE SHUTDOWN 15.4 VDC ± 0.2 VDC
OVERLOAD AND GROUND FAULT SHUT DOWN Yes. Latches in shutdown condition. Manual
OVER TEMPE RATURE SHUTDOWN Yes. Auto reset on cooling down.
PR O TECT IO N S
COOLING FAN Load controlled: Switches ON at 35W to 45W
INPUT FUSE : 32V, AUTOMOTIVE TYPE ATC (INSIDE
THE UNIT, NOT USER ACCESSIBLE )
DC INPUT M4 Thumb Screw
AC OUTPUT Two NEMA5-15 R Outlets
OUTLETS
OPER ATING TEMPE RATURE RANGE 0°C to 25°C / 32°F to 77°F at 100% loading;
OPER ATING HUMIDITY
NEUTRAL TO CHASSIS BONDING No. Neutral of the NE MA5-15R AC Outlet is
DIMENSIONS (W x D x H)
GENERAL
WEIGHT 1.32 kg / 2.91 lb
DC INPUT CABLES INCLUDED AWG#8 Cable with battery clamps
Safety Compliance Conforms to UL S TD 458
> 10.8 VDC to < 15.4 VDC
115VAC + 10% / -2%; 60 Hz ± 5%
1600W
reset: Switch OFF the ON/ OFF switch, wait 3
mins and Switch ON again.
105A (3 x 35A in parallel)
26°C to 35°C / 78.8°F to 95°F at 80% loading
< 80%; Non-condensing
isolated from the chassis
180 x 218 x 59 mm
7.0 x 8.6 x 2.4 in
SAFETY
NOTE: Specications are subject to change without notice
12002-SLX-800-D RV-1113
