NTE30111
p
()
LED − Dual Color
3mm Super Fresh Red/Super Blue
Features:
D RoHS Compliant
D Water Clear
Absolute Maximum Ratings: (TA = +25°C unless otherwise specified)
Power Dissipation, P
Super Fresh Red 100mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Super Blue 120mW. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous Forward Current, I
Peak Forward Current (1/10 Duty Ratio, 0.1ms Pulse Width), I
Super Fresh Red 50mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Super Blue 100mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrostatic Discharge (Super Blue Only), ESD 150V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED Junction Temperature, T
Operating Temperature Range, T
Storage Temperature Range, T
DIP Soldering Temperature (During Soldering, 3mm from body, 5sec max), T
d
F
FM
j
opr
stg
L
−25°C to +85°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
−40°C to +100°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+100°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+260°C. . . . . . . . . .
25mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electro−Optical Characteristics:
View Angle of Half Power 2Q 1/2 IF = 20mA − 15 − deg
Forward Voltage
Luminous Intensity (Note 1)
Peak Emission Wavelength
Dominate Wave Length (Note 2)
Note 1. Luminous intensity is measured with an Exeltron 2001, Tolerance = 30%.
Note 2. The dominate wavelength, λ
(TA = +25°C unless otherwise specified)
Parameter Symbol Test Conditions Min Typ Max Unit
Super Fresh Red
Super Blue − 3.70 4.20 V
Super Fresh Red
Super Blue 400 650 − mcd
Super Fresh Red λp IF = 20mA − 635 − nm
Super Blue
Super Fresh Red λd(HUE) IF = 20mA − 626 − nm
Super Blue
, is derived from the CIE Chromaticity Diagram and represents
d
VF IF = 20mA − 2.00 2.50 V
IV IF = 20mA 500 800 − mcd
− 468 − nm
− 470 − nm
the color of the device.
Page 2
.209
(5.30)
.152
(3.85)
Dia
.118 (3.0) Dia
1. Red −
2. Blue −
0.02 (0.7)Max
12
0.03
(1.0)
Min
1.00 (2.54) Min
1.00
(25.4)
Min
