SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
Blue MV8B01
PACKAGE DIMENSIONS
0.200 (5.08)
5°
0.180 (4.57)
0.040 (1.02)
0.023 (0.58)
0.017 (0.43)
YP. (2X)
SQ. T
0.100 (2.54)
NOM
Ø 0.230 (5.84)
NOTES:
1. Dimensions for all drawings are in inches (mm).
2. Lead spacing is measured where the leads emerge from the
package.
3. Protruded resin under the flange is 1.5mm (0.059”) max.
0.350 (8.89)
0.330 (8.38)
1.00 (25.4)
MIN
0.050 (1.27)
NOM
FLAT DENOTES
CATHODE
DESCRIPTION
This T-1 3/4 super bright LED has a moderate viewing angle of 20° for concentrated light output. It is made with GaN/SiC
technology LED that emits blue light at 430 nm. It is encapsulated in a water clear epoxy lens package.
FEATURES
•Popular T-1 3/4 package
• Solid state reliability
•Water clear optics
• Standard 100 mil. lead spacing
Page 1 of 4
SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
Blue MV8B01
(T
ABSOLUTE MAXIMUM RATINGS
Parameter Symbol Rating Unit
= 25°C unless otherwise specified)
A
Operating Temperature
Storage Temperature
Lead Soldering Time
Continuous Forward Current
Peak Forward Current
(f = 1.0 KHz, Duty Factor = 1/10)
Reverse Voltage
Power Dissipation
ELECTRICAL / OPTICAL CHARACTERISTICS
Part Number MV8B01A Condition
Luminous Intensity (mcd)
Minimum 300
Typical 450
Forward Voltage (V)
Typical 3.8
Maximum 4.5
Wavelength (nm)
Peak 430
Dominant 465
Spectral Line Half Width (nm) 65
Viewing Angle (°) 20
(T
T
T
T
OPR
STG
SOL
I
FM
V
P
A
I
F
R
D
=25°C)
-40 to +85 °C
-40 to +100 °C
260 for 5 sec °C
30 mA
100 mA
5V
135 mW
I
= 20 mA
F
= 20 mA
I
F
= 20 mA
I
F
I
= 20 mA
F
I
= 20 mA
F
Page 2 of 4
SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
Blue MV8B01
TYPICAL PERFORMANCE CURVES
Fig. 1 Forward Current vs. Forward Voltage
40
30
20
10
FORWARD CURRENT (mA)
0
123 45
VF - FORWARD VOLTAGE (V)
1.0
0.5
Fig. 2 Relative Luminous Intensity vs.
1.25
1.0
0.75
0.5
(NORMALIZED AT 20 mA)
0.25
RELATIVE LUMNOUS INTENSITY
0.0
051015 20 25 30 35 40
Fig. 3 Relative Intensity vs. Wavelength
DC Forward Current
IF - DC FORWARD CURRENT (mA)
RELATIVE INTENSITY
0
380 430 480 530 580 630 680
WAVELENGTH (nm)
Fig. 4 Radiation Diagram
0° 10° 20°
1.0
0.9
0.8
0.7
RELATIVE RADIANT INTENSITY
0.5 0.3 0.1 0.2 0.4 0.5
RADIATION DIAGRAM
30°
40°
50°
60°
70°
80°
90°
Fig. 5 Maximum Forward Current
vs. Ambient Temperature
40
30
20
10
FORWARD CURRENT (mA)
0
-25 0 25 50 75 100
AMBIENT TEMPERATURE TA (°C)
Page 3 of 4
SUPER BRIGHT T-1 3/4 (5 mm)
LED LAMP - Water Clear
Blue MV8B01
DISCLAIMER
FAIRCHILD SEMICONDUCTOR RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO
ANY PRODUCTS HEREIN TO IMPROVE RELIABILITY, FUNCTION OR DESIGN. FAIRCHILD DOES NOT ASSUME
ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED HEREIN;
NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.
LIFE SUPPORT POLICY
FAIRCHILD’S PRODUCTS ARE NOT AUTHORIZED FOR USE AS CRITICAL COMPONENTS IN LIFE SUPPORT DEVICES
OR SYSTEMS WITHOUT THE EXPRESS WRITTEN APPROVAL OF THE PRESIDENT OF FAIRCHILD SEMICONDUCTOR
CORPORATION. As used herein:
1. Life support devices or systems are devices or systems
which, (a) are intended for surgical implant into the body, or
(b) support or sustain life, and (c) whose failure to perform
when properly used in accordance with instructions for use
provided in the labeling, can be reasonably expected to
result in a significant injury of the user.
2. A critical component in any component of a life support
device or system whose failure to perform can be
reasonably expected to cause the failure of the life support
device or system, or to affect its safety or effectiveness.
Page 4 of 4
