Cable Clamps, Self−Aligning
Features
Secures the Routing of Cables, Harnesses, and Hoses
Rounded Edges Protect Against Insulation Abrasion and
Cutting Hoses
Saddle Washer Allows for Quick and Secure Alignment
Manufactured from Durable and Flexible Nylon 66
Available in Natural or UV Black
CC−04
Thickness
Closed Diameter
Center to Center
Mounting Hole
Color Code Chart
0 Black 9 Natural
Cable Clamps (100 per bag)
Screw
NTE Type No.
04−SACL125x #6 .377 / 9.57 .046 / 1.16 .082 / 2.08 .314 / 7.97 .800 / 20.32 CC−04
04−SACL187x #6 .377 / 9.57 .049 / 1.24 .151 / 3.83 .362 / 9.19 .867 / 22.02 CC−04
04−SACL250x #6 .396 / 10.05 .049 / 1.24 .205 / 5.20 .409 / 10.38 .900 / 22.86 CC−04
04−SACL312x #6 .396 / 10.05 .049 / 1.24 .256 / 6.50 .440 / 11.17 .982 / 24.94 CC−04
04−SACL375x #10 .486 / 12.34 .057 / 1.44 .352 / 8.94 .492 / 12.49 1.117 / 28.37 CC−04
04−SACL500x #10 .486 / 12.34 .057 / 1.44 .470 / 11.93 .582 / 14.78 1.233 / 31.31 CC−04
04−SACL625x #10 .486 / 12.34 .060 / 1.52 .564 / 14.32 .622 / 15.79 1.335 / 33.90 CC−04
04−SACL750x #10 .469 / 11.91 .060 / 1.52 .693 / 17.60 .708 / 17.98 1.460 / 37.08 CC−04
04−SACL875x #10 .469 / 11.91 .057 / 1.44 .813 / 20.65 .767 / 19.48 1.577 / 40.05 CC−04
04−SACL1000x #10 .469 / 11.91 .057 / 1.44 .890 / 22.60 .820 / 20.82 1.684 / 42.77 CC−04
04−SACL1250x #10 .469 / 11.91 .065 / 1.65 1.126 / 28.60 .940 / 23.87 2.000 / 50.80 CC−04
04−SACL1500x #10 .486 / 12.34 .060 / 1.52 1.440 / 36.57 .980 / 24.89 2.168 / 55.06 CC−04
Note 1. Replace “x” in device number with corresponding color code from the “Color Code Chart”.
Size
Width
(in. / mm)
Thickness
(in. / mm)
Closed Diameter
in. / mm)
Center to Center
(in. / mm)
Overall Length
(in. / mm)
Diag No.
