NSI 404CP, 408CP Installation And Operation Manual

Download
Page 1
LUMA-NET
404CP / 408CP
REMOTE CONTROL PANEL
INSTALLATION AND OPERATION GUIDE
Software Revision 3.00, Version C
INTRODUCTION
The NSI 404CP and 408CP represents a key part of a state of the art, total lighting control system. Combined with NSI dimmers and optionally, an NSI memory control console, a totally integrated system is achieved.
IMPORTANT
• Programming differs from other Luma-net panels, please read instructions.
• Luma-net control panels with software release 3.00 and higher are not directly compatible and will
not operate with older 400CP panels with software prior to release 3.00. Contact dealer or factory for modifications if necessary.
• NSI dimming systems used with these release 3.00 panels require the following software releases:
2408CD, 2408CR, 2404CD release 2.30 and above. DDS 8600/8800/9600/9800 release 1.30 and above. * DDS 6000 release 1.30 and above. * DDS 5300/5500/5600 release 1.30 and above. *
* Optional interface kit required for these units.
NSI CORPORATION 1
Page 2
REMOTE CONTROL PANEL Software Revision 3.00, Version C
WIRING
The 404CP and 408CP will only operate with NSI dimming and control systems explicitly designed for interfacing with it. Communication between the panels and the dimming system is via a 4 wire interface. Three wires carry the RS 422/485 bi-directional data. A fourth wire carries the DC voltage necessary for powering the unit.
Wiring cable between the panels and the dimming system is class 2 and should be at least 22 AWG, 4 conductor shielded, twisted pairs. (BELDEN 8302, 8723; 22 AWG.)
The 404CP and 408CP may be connected to the dimming system via parallel or daisy-chained wiring. Due to power supply current demands, panels must be limited to 5 units per daisy chain run with 22 awg wire, or 10 units with 20 AWG wire.
The Luma-net panels feature plug on wiring terminals. The terminals may be unplugged from the panel to facilitate ease of wiring and testing. Connect the terminals marked remote+, remote-, common, and +15 VDC to the same respective terminals on the dimming system and other Luma-net panels. Use one twisted pair for remote+ and remote- and the other pair for common and +15 VDC.
The wiring to the remote lockout switch, if used, can be simple 2 conductor 22 AWG. Connect the wires from the switch to the lockout+ and lockout- terminals. Any panel or group of panels may be locked-out remotely by interrupting the +15V supply to the panels. This should not affect any other panels still powered, or affect lighting levels currently set.
IMPORTANT: Verify wiring is correct before powering system! Make sure nothing conductive may touch pc board or components!
MOUNTING
The 404CP and 408CP will mount in any standard double-gang electrical box with the 4 screws provided. See below paragraph on system turn-on before final mounting of panels.
SYSTEM TURN-ON
It is very important that the system operation be verified one panel at a time. Else, an improper connection at one panel would cause the entire system to not operate properly and may be difficult to diagnose.
After all terminal plugs have been wired and the dimmer system has been installed and tested, the installer is ready to connect each panel to the system. Panels may be plugged-in while system is live, but the installer must take care not to touch PC board or connections with fingers or metal objects. On daisy-chain runs, the panels closest to the dimming system should be connected first.
404CP and 408CP panels have dip switches to set network ID number and must have their ID programmed before the system power is connected. It is recommended that the installer review the programming procedures for network ID before proceding. A duplicate network ID number will cause the entire network to malfunction.
Connect the first panel and immediately notice whether the POWER LED comes on, indicating power to the panel. The BUSY LED should come on momentarily and then go out and stay out. This indicates a successful reconfiguration of the network. If the BUSY LED flashes slowly, this indicates a duplicate ID number or wiring problem. Program the ID number, if not already, and observe the BUSY LED. (Note, the busy LED also flashes quickly when the program jumper is removed).
Now test the dimmer function by programming one scene or zone and operating the panel. If the dimmer responds, then mount the panel and procede to the next panel in the system and follow the same procedure.
NSI CORPORATION 2
Page 3
REMOTE CONTROL PANEL Software Revision 3.00, Version C LEDS
LEDS
The PWR LED indicates the presence of +15VDC to the panel.
The BUSY LED indicates the following:
Off Normal state when there is no activity. Short Blinks A message is being sent on the network. Steady on or Slow flashing Network trying to reconfigure (bad ID?)
While programming, the following actions are normal.
Quickly flashing Programming mode, no mode selected. Off Programming mode, mode selected.
LOCKOUT
Any 404CP and 408CP may be disabled from operation with a remote key switch or other contact closure. Several Luma-net panels of the same version may be connected to the same contacts in parallel as long as polarity is maintained.
Closing the contact will prevent connected panels from operating, regardless of button presses.
Luma-net panels may also be locked out by causing a switch to disconnect the +15V supply to the panels.
NSI CORPORATION 3
Page 4
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Factory Default Setting:
PROGRAMMING
Several parameters must be programmed into the 404CP / 408CP for it to operate properly:
Dimmer channel assignments for each scene
Dimmer levels for each scene.
Fade time for each scene.
Master / Slave operation.
Network ID number (IMPORTANT).
Optionally, the unit may be ordered preprogrammed from the factory. Any field modifications can be made if necessary.
Factory Default Setting:
The 404CP and 408CP are programmed at the factory for scene 1-3 (1-7) to be set for channel 1-4 (1-8) respectively. Scene 4 (8) is programmed for dimmers 1-8 off. The fade rate and other parameters are also set to factory defaults. This may be acceptable for initial testing. If necessary to return the 400CP panel to it’s factory default settings (except network ID), follow this procedure:
1. Remove program jumper block and disconnect plug-in terminal block.
2. Hold down all SCENE 1-4 buttons while connecting terminal block.
3. Setting is complete when busy light begins to flash after several seconds.
Full Memory Clear:
The 404CP does not implement this function. Normally, the 408CP will not require memory clearing. Once the memory is cleared, all parameters, including fade rate, must be reprogrammed. Unless it is necessary to clear memory to remove a large or unknown programming, skip these steps.
1. Remove program jumper block and disconnect terminal block.
2. Hold down all SCENE 5-8 buttons while connecting the terminal block.
3. Setting is complete when busy light begins to flash after several seconds.
Prepare the 404CP and 408CP for reprogramming:
In order to program the panels, a jumper block must be removed from the program jumper pins. This will allow data to be stored in the eeprom memory. At this point the BUSY LED will start flashing, indicating that you are in the program select mode.
IMPORTANT: After programming it is important to replace the programming jumper block so memory will be protected.
NSI CORPORATION 4
Page 5
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Assigning dimmer channels to each scene.
Assigning dimmer channels to each scene.
Each of the scenes of the 404CP and 408CP must be programmed with the desired dimmer channel assignments. Only the dimmer channels assigned will be affected by each scene button.
In order to easily identify dimmer channels while programming, the system should have all installed lamps or loads operational. If this is not possible, the panel to be programmed should be temporarily connected nearby to the dimmer units so that the control LEDs of the dimmers may be observed to verify channel selection.
To program each scene:
1. Make sure that the 404CP or 408CP is in the program select mode as discussed. The BUSY LED should
be flashing.
2. Press the SCENE 2 button to select "dimmer assignment mode" and the BUSY LED will stop flashing.
3. Press button representing desired scene to be programmed. At this point, all currently assigned dimmers will
come on. The current dimmer selector will be set to one.
4. Use the buttons marked as UP and DOWN in diagram to increment or decrement the dimmer channel selector.
Tap the buttons the required number of times to reach the dimmer channel to be assigned.
5. Use the ADD and DELETE buttons to add or delete this dimmer from the zone. The lamps connected to
this dimmer channel will come on full when the ADD button is pressed. Observe lamps or dimmer LEDs to verify correct channel has been selected.
6. Next, exit this programming mode; press both the UP and DOWN buttons at the same time. The BUSY
LED will start flashing again when both buttons are released.
7. A new scene can be programmed at any time by repeating the above procedure.
NSI CORPORATION 5
Page 6
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Assigning dimmer levels to each scene.
Assigning dimmer levels to each scene.
Each of the scenes of the 404CP and 408CP must be programmed with the desired levels for each dimmer assigned to the scene.
In order to easily identify dimmer channels while programming, the system should have all installed lamps or loads operational. If this is not possible, the panel to be programmed should be temporarily connected nearby to the dimmer units so that the control LEDs of the dimmers may be observed to verify channel selection.
To program each scene:
1. Make sure that the 404CP or 408CP is in the program select mode as discussed. The BUSY LED should
be flashing.
2. Press the SCENE 1 button to select "dimmer level mode" and the BUSY LED will stop flashing.
3. Press button representing desired scene to be programmed. At this point, all currently assigned dimmers will
come on to the currently programmed levels (normally at zero brightness). The current dimmer selector will be set to the first previously assigned dimmer.
4. Use the buttons marked as UP and DOWN in diagram to increment or decrement the dimmer channel selector
through the assigned dimmers. Tap the buttons the required number of times to reach the dimmer channel to be programmed.
5. Use the INCREASE and DECREASE buttons to change the dimmer brightness. The lamps connected to this
dimmer channel will come on full when the INCREASE button is pressed and held down. A tap of the INCREASE or DECREASE button will cause a fine change in brightness, a push and hold motion will cause a rapid change. Observe lamps or dimmer LEDs to verify correct channel has been selected.
6. Next, exit this programming mode; press both the UP and DOWN buttons at the same time. The BUSY
LED will start flashing again when both buttons are released.
7. A new scene can be programmed at any time by following the above procedure.
NSI CORPORATION 6
Page 7
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Scene fade time programming.
Scene fade time programming.
Each scene may be programmed with an individual fade time. This is the time it will take the dimmer channels assigned to go from full off to full on and visa versa. Fade time can vary from 0 to 13 seconds. A fade time of 0 seconds will cause instant full on or full off operation whenever the scene buttons are pressed. If the factory default setting of 5 seconds is desired for each zone then this step may be ignored.
To program scene fade time:
1. Make sure that the 404CP or 408CP is in the program select mode as discussed.
2. Press the SCENE 3 button to enter the "Fade time mode", and the BUSY LED will stop flashing.
3. Select the desired scene by pressing the associated button as shown in the diagram.
4. Press button marked with desired fade time in seconds.
5. Unit will exit this programming mode after the release of the button and the BUSY LED will start flashing
again.
NSI CORPORATION 7
Page 8
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Master/Slave Mode
Master/Slave Mode
404CP or 408CP panels may be slaved to one another. Several panels may act as slaves to a master panel which contains the programming. The slaves will mimic the master LED’s and will operate the scenes and fade times of the master. This is ideal for installations with several panels in one room.
To make a panel into a master (factory default); set the Master\Slave ID to 0. To make a panel into a slave; set the Master/Slave ID to the Network ID of the desired master to slave to.
To set Master/Slave ID number:
1. Make sure that the 404CP or 408CP is in the program mode as discussed.
2. Press the scene 4 button and the BUSY LED will stop flashing
3. Look up the necessary sequence of 1’s and 0’s for the ID number on the chart at the end of this section.
4. Using the two buttons indicated below, enter the eight number sequence of 1’s and 0’s.
5. The unit will exit this program mode at the release of the eighth press, and the BUSY LED will start flashing
again.
NOTE : All other programming (except network ID) will have no effect if unit is made into a slave. The master unit will contain the programming for all units slaved to it. Slave units must still have a unique Network ID number (see following section).
NSI CORPORATION 8
Page 9
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C Network ID number.
Network ID number.
Since the Luma-net System is a digital network, all panels and devices attached (except dimmers) must have a unique network ID number.
If two panels have the same network ID number, the entire network will stop functioning.
Panels need not be in program mode to change network ID number, since a dipwitch is used.
To set Network ID number:
1. Locate dipswitch on rear of unit as illustrated below.
2. Set the switches as per the chart on the following page.
NSI CORPORATION 9
Page 10
REMOTE CONTROL PANEL PROGRAMMING Software Revision 3.00, Version C ID number codes / dipswitch settings
ID number codes / dipswitch settings
ID number 12345678 ID number 12345678 ID number 12345678 0 00000000 1 10000000 2 01000000 3 11000000 4 00100000 5 10100000 6 01100000 7 11100000 8 00010000 9 10010000 10 01010000 11 11010000 12 00110000 13 10110000 14 01110000 15 11110000 16 00001000 17 10001000 18 01001000 19 11001000 20 00101000 21 10101000 22 01101000 23 11101000 24 00011000 25 10011000 26 01011000 27 11011000 28 00111000 29 10111000 30 01111000 31 11111000 32 00000100 33 10000100 34 01000100 35 11000100 36 00100100 37 10100100 38 01100100 39 11100100 40 00010100 41 10010100 42 01010100 43 11010100 44 00110100 45 10110100 46 01110100 47 11110100 48 00001100 49 10001100 50 01001100 51 11001100 52 00101100 53 10101100 54 01101100 55 11101100 56 00011100 57 10011100 58 01011100 59 11011100 60 00111100 61 10111100 62 01111100 63 11111100 64 00000010 65 10000010 66 01000010 67 11000010 68 00100010 69 10100010 70 01100010 71 11100010 72 00010010 73 10010010 74 01010010 75 11010010 76 00110010 77 10110010 78 01110010 79 11110010 80 00001010 81 10001010 82 01001010 83 11001010 84 00101010 85 10101010 86 01101010 87 11101010 88 00011010 89 10011010 90 01011010 91 11011010 92 00111010 93 10111010 94 01111010 95 11111010 96 00000110 97 10000110 98 01000110 99 11000110 100 00100110 101 10100110 102 01100110 103 11100110 104 00010110 105 10010110 106 01010110 107 11010110 108 00110110 109 10110110 110 01110110 111 11110110 112 00001110 113 10001110 114 01001110 115 11001110 116 00101110 117 10101110 118 01101110 119 11101110 120 00011110 121 10011110 122 01011110 123 11011110 124 00111110 125 10111110 126 01111110 127 11111110
For channels 129 - 256 Set dipswitch 1-7 as above and set dipswitch #8 on.
NSI CORPORATION 10
Page 11
REMOTE CONTROL PANEL OPERATION Software Revision 3.00, Version C To select a scene:
OPERATION
To select a scene:
Press the button of the scene desired. The LED above each scene indicates that the scene is currently active. The LED will go out when an operation on the same or different panel causes a change to a dimmer contained in the active scene
To restore control from a console:
Simply perform a change in the channel level from the console. The lighting channel will then fade back to the new console level at the factory default fade rate. Once the console level matches or is moved past the lighting level, full console control will be resumed for that channel.
NSI CORPORATION 11
Page 12
REMOTE CONTROL PANEL OPERATION Software Revision 3.00, Version C NSI Corporation Limited Warranty
WARRANTY
NSI Corporation Limited Warranty
NSI Corporation warrants new electronics products to be free from defective materials and workmanship for a period of one (1) year from the date of purchase to the original owner when purchased from an authorized NSI dealer.
The purchaser is responsible for completing and mailing to NSI, within 15 days of purchase, the warranty registration card enclosed with each product. NSI products that have been subject to accident, alteration, abuse, or defacing of the serial number are not covered by this warranty. The normal wear and tear of items such as knobs, jacks, and switches are not covered under this warranty.
NSI Corporation is not liable for any incidental or consequential damages resulting from defect or failure other than repairs of the NSI product subject to the terms of this warranty. This warranty gives you specific legal rights, and you may have other rights which vary from state to state. This warranty is expressly in lieu of all other agreements and warranties expressed or implied except as may be otherwise required by law.
NSI CORPORATION 12
