Mini Tower Fan
Instruction Manual
www.nscessity.co.uk
IMPORTANT!
KEEP FOR FUTURE
REFERENCE
NSMTF-18
PEFT18 Instruction 8pp.indd 2 17/2/09 18:05:13
Parts Description
1) Front panel
2) Control panel
3) Base
4) Back cover
Package Contents
a) 1 x Mini Tower Fan
b) This instruction manual
• If you find any of the above is missing, please contact your retailer.
4
1
2
3
2
®
®
Mini Tower Fan
Model: NSMTF-18
PEFT18 Instruction 8pp.indd 3 17/2/09 18:05:14
3
®
Safety Instructions
Please read this instruction manual before using your Mini Tower Fan for the first time
and keep safe for future reference.
CAUTION: Read and follow all instructions before operating this fan.
Use the fan only as described in this manual. Misuse may cause a fire or an
electrical shock.
1. Do not operate the fan with a
damaged power cord or plug, after
it malfunctions, has been dropped
or damaged. If the power cord is
damaged it must be replaced by
the manufacturer or a qualified
service engineer to avoid a hazard.
2. Close supervision is necessary when
this fan is used near children and
pets.
3. Always turn off the fan after use,
before cleaning or moving location.
4. Do not insert fingers or other objects
into the fan guard.
5. Do not operate the fan in areas
where petrol, paint or other
flammable liquids are used or
stored.
6. Do not place the fan near an
open flame, cooking or heating
appliance or hot surface.
7. This fan is not intended for use in wet
or damp locations. Never position
the fan in an area where it may fall
into a bath or other water container.
8. This fan should not be operated
outside.
9. Always use on a dry, level surface.
10. Do not let the power cord hang
over the edge of a table or counter.
11. Arrange the power cord away from
an area where it may be tripped
over.
12. Never place the power cord under
a carpet or rug.
13. To disconnect from the power
supply, grip the plug and pull from
the power socket. Never pull by the
cord.
14. Do not hang or mount the fan on a
wall or ceiling.
15. Do not operate if the fan guard is
removed or damaged.
16. This product is designed for
household and light commercial use
ONLY.
PEFT18 Instruction 8pp.indd 4 17/2/09 18:05:14
LOW MED HI
1 2 4
H
ion sleep mode
O
N
/
O
F
F
S
P
E
E
D
S
L
E
E
P
M
O
D
E
I
O
N
O
S
C
T
I
M
E
R
4
®
Control Panel
On/Off - Press to turn the unit on and off.
Speed - Press to select Low, Medium and High fan speeds, press the button three
times to move between the speeds, and a fourth time to stop.
Sleep Mode - This mode will use the set fan speed and step down through the
speeds for 30 minutes for example select sleep mode and High speed, the fan
will alternate through Hi, Med, & Low for 30 mins. Then fan speed will drop to
Med, and alternate between Med & Low for 30 mins, then fan speed it will drop
to Low and alternate between Low and stop for 30mins. After this the cycle will
start again in the selected High speed. When Med fan speed is selected, sleep
mode will alternate between med, low & stop. When low fan speed is selected
sleep mode will alternate between low and stop.
Timer - You can set the run time for 1, 2 or 4 hours. Press the button to move through
the times when the lights go out the timer is off.
Oscillation (OSC) - Press to activate the oscillation feature, for wide distribution of air.
Press button again to stop oscillation.
Ion - Press to switch the Ioniser on releasing negatively charged Ions to aid
air-cleaning, press again to switch off.
PEFT18 Instruction 8pp.indd 5 17/2/09 18:05:14
5
®
BS Plug Wiring
Wiring Instructions
Should it be necessary to change the plug please note the wires in the mains lead
are coloured in accordance with the following code:
BLUE - NEUTRAL
BROWN - LIVE
As the colours of the wires in the mains lead of this appliance may not correspond
with the coloured markings identifying the terminals in your plug, proceed as
follows:
1. The BLUE wire is the NEUTRAL and must be connected to the terminal which is
marked with the letter N or coloured BLACK.
2. The BROWN wire is the LIVE and must be connected to the terminal which is
marked with the letter L or coloured RED.
3. Neither wire is to be connected to the terminal which is marked with the letter E or
or coloured GREEN OR GREEN /YELLOW.
4. Always ensure that the cord grip is positioned and fastened correctly.
If a 13A (BS 1363) fused plug is used it must be fitted with a 3A fuse. If in doubt consult
a qualified electrician.
Wiring for a 13 Amp Plug (BS1363)
Please note: The Earth Terminal is marked with the letter E or Earth Symbol.
WARNING: If the power cord is damaged it must be replaced by a qualified
electrician to avoid a hazard.
Neutral - N
(Blue)
Live - L
(Brown)
3 AMP
PEFT18 Instruction 8pp.indd 6 17/2/09 18:05:14
6
®
Maintenance
CAUTION: SWITCH OFF AND DISCONNECT FROM POWER SUPPLY BEFORE SERVICING
To clean the unit use a soft cloth to wipe off any dust. If the unit is very dirty use a damp
cloth. Do not use any cleaning detergents, sprays or any other chemicals, as these will
damage the unit. Ensure no water enters into the machine.
Specification
Model No: NSMTF-18
Voltage: 220-240V, 50Hz
Rated power: 35w
N.W. 1.5kg
G.W. 2kg
NScessity has a large range of premium products all well
specified and always with that little bit extra.
We endeavour to ensure NScessity Products are the
best you can get in their categories, we are very proud
of them! Please visit our website for further information,
www.NScessity.co.uk
PEFT18 Instruction 8pp.indd 7 17/2/09 18:05:15
7
®
Service and Warranty
NScessity guarantees this product free from defects in materials and workmanship
for a period of one (1) year. Should this unit be operated under conditions other
than those recommended, at voltages other than the voltage indicated on
the unit, or any attempts made to service or modify the unit, this will render this
WARRANTY VOID. The product you buy may sometimes differ slightly from illustration.
This warranty is in addition to, and does not affect, your statutory rights.
• Do not operate the unit with a damaged cord or plug, after the unit malfunctions,
has been dropped or damaged.
• For your convenience, record the complete model number and product name
(located on the Product Identification Plate), the date you purchased the
product, and attach your purchase receipt as proof of purchase.
• To ensure your product is covered by warranty, the complete faulty product
together with your purchase receipt should be returned to your retailer.
Should you have a problem with this product,
please contact our help desk,
Tel: 0870 765 2574 or visit our website at www.NScessity.co.uk
This product has been manufactured to comply with EEC Directives
2006/95/EG and 89/336/EEC
Waste electrical products should not be disposed of with household
waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
PEFT18 Instruction 8pp.indd 8 17/2/09 18:05:15
®
