NSMDH-1608
®
Midi
Dehumidifi er
Instruction Manual
www.nscessity.co.uk
IMPORTANT!
KEEP FOR FUTURE
REFERENCE
Please
register your product
on-line at
www.nscessity.co.uk
NSMDH-1608 Instructions 9.11.indd 2 15/11/2010 10:56
2
®
Package Contents
a) 1 x Midi Dehumidifier b) 1x 12V DC Adaptor c) 1 x water pipe
d) This instruction manual
• If you find any of the above is missing, please contact your retailer or call our
Helpline on 0870 765 2574.
Parts Description
®
Mini Dehumidifi er
Model: NSMDH-1608
Front
case
Water level
indicator
Water tank
Back
cover
Power
indicator
Power button
Air inlet
Water full indicator
DC 12V Power
adaptor
Air outlet
NSMDH-1608 Instructions 9.11.indd 3 15/11/2010 10:56
3
®
Safety Instructions
Please read this instruction manual before using your Midi Dehumidifier for the first
time and keep safe for future reference.
When using electrical appliances, basic safety precautions should always be
followed:
1 Always use appliance in accordance with the
instructions.
2 Please ensure that the rated voltage of your
Dehumidifier corresponds to your electric
system before connecting to the mains.
3 Always keep the device out of reach of
children.
4 Do not allow children to play with any
packaging, such as plastic bags.
5 Always check the product for damage
before use.
6 Repairs may only be carried out by an
authorised service centre; incorrect handling
and faulty repairs may lead to danger.
7 If the product malfunctions, or has been
dropped or damaged in any way, return the
complete product to an authorised service
facility for checking and repair.
8 This product is intended for domestic use only
and not for commercial, industrial or outside
use.
9 Always turn off the unit and unplug before
moving it to empty the water tank. Always
use both hands to carry this product.
10 To disconnect from the power supply, grip the
plug and pull it from the power socket. Never
pull by the cord.
11 Do not handle the Power Supply Cord with
wet hands. An electrical shock may result.
12 Do not operate the unit in areas where petrol,
paint, or other flammable liquids are used or
stored.
13 Do not use the unit in artificially hot or humid
conditions or allow it to be used in any
hazardous environment.
14 Do not place the unit near an open flame,
cooking/heating appliance or direct sunlight/
hot surface.
15 Never place the unit in an area where it may
fall into a bath or other water container.
Always use on a dry, level surface.
16 Do not allow water to run inside the motor
housing as this could result in a fire or electric
shock.
17 Do not let the power cord hang over the
edge of a table or counter. Arrange the
power cord away from an area where it may
be tripped over.
18 Never place the power cord under a carpet
or rug.
19 Do not put objects on the product or allow
objects to obstruct the air inlet or outlet
openings.
20 Do not place directly on wooden, delicate
or soft furniture ~ to protect surfaces place a
mat or tray underneath your dehumidifier.
21 The use of attachments or accessories
that are not sold with the product are not
recommended as they may cause injury and
void the warranty.
22 Do not attempt to repair or dismantle the unit
yourself other than to clean the water tank.
As described on page 5. Unskilled repairs will
result in loss of warranty and could endanger
the user or their property.
23 Place the unit 90cm above floor level for best
performance. The unit should never be used
at floor level if the room is carpeted.
24 Use only with the supplied adaptor.
25 Do not connect the unit to a power outlet
using an extension cord.
26 This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
27 If the supply cord is damaged, it must be
replaced by a service engineer in order to
avoid a hazard.
NSMDH-1608 Instructions 9.11.indd 4 15/11/2010 10:56
Introduction
Congratulations on your purchase of the NScessity Midi Dehumidifier NSMDH-1608 which is
designed to remove excess moisture from small enclosed spaces such as small bedrooms,
wardrobes or storage cupboards.
Should your Midi Humidifier not work correctly or your have any questions about its operation,
please visit our website at www.nscessity.co.uk or call our helpline on 0870 765 2574.
Operating Instructions
• Connect the adaptor to the main unit (the connection is on the left side of the unit).
• Check the water tank is inserted correctly.
• Insert the DC plug into the power supply socket.
• Press the Power Switch to “On”. The green power supply indicator will light up and the unit
will start to work.
• To turn off the unit press Power Switch to ‘Off’ position. The green light indicator will switch off
and the unit will stop.
Water Removal:
• A red light will switch on to indicate the tank is full.
• When the water tank is full, the unit will switch off
automatically.
• Before you empty your tank switch off the unit (press the
Power switch to ‘Off’) and disconnect from the mains.
• Hold the unit steady and gently grip the water tank pulling
and removing from the unit.
• To empty the tank, remove the lid on the water tank or pull
the grey rubber plug from the back of the tank and dispose
of the water into a sink or other water container.
• Replace the plug and lid to the water tank, and return to the
unit. Make sure it is fitted securely. The unit will only function
properly if the water tank is correctly positioned.
• Press the power switch to ‘On’ to restart.
Water Pipe (continuous disposal/option):
Should you wish to use the option of continuous disposal the
water will be continuously removed through an overfill pipe
(supplied) please follow the instructions below:
• Remove the grey rubber plug and attached the water pipe
(supplied) into place. Ensure that the other end of the water
pipe is lower that the unit to allow it to drain freely into a
waste pipe or drainage system.
• When the water tank is full excess water will flow out via the
water pipe and into the drainage system of your choice.
• When the water pipe is in use, the ‘TANK FULL’ light will not
function. The unit will operate continuously until turned off.
• Empty and clean the tank at regular intervals to avoid water
becoming stagnant and the build up of bacteria.
4
®
Water Bobber
Rubber
Plug
Water Pipe
NSMDH-1608 Instructions 9.11.indd 5 15/11/2010 10:56
5
®
Cleaning & Maintenance
• Before you clean the appliance, switch off the unit and disconnect from the power supply.
• Do not spray with water, immerse in water, or use abrasive cleaning, liquids or chemical
agents (Alcohol, Gasoline etc.) to clean the appliance as these may damage the
surface.
• Use a damp cloth to clean the product housing.
• Do not allow water to leak into the internal parts of the unit.
Cleaning the water tank
If your water tank is not cleaned and disinfected on a regular basis, the water may become
slimy and may develop an odour. This probably means that there is bacteria build up.
Therefore once you have cleaned the water tank of your Dehumidifier, it should be disinfected/
sterilised.
• Remove the water tank from the unit (as explained in operating instructions above).
• Remove lid/rubber plug and drain water if needed.
• Rinse out with clean water by removing the water tank and the water tank lid. Once the
water tank has been cleaned with water, wipe the unit dry.
• Replace lid/rubber plug, wipe away any excess water from the surface of the tank.
• Reposition water tank securely in the main unit.
Disinfection of the Water Tank
• Fill the base with clean water and sterilisation fluid (or tablet) – available from most chemists
and hardware stores.
• Allow this solution to soak as directed on the pack. Occasionally, gently swish the solution so
it covers the tank evenly.
• Once soaking time has passed, pour the solution down the drain, being careful not to spill
any.
• Rinse the base several times until the odour has dissipated. Never allow any solution to
remain in your humidifier.
WARNING
• Do not switch on the dehumidifier while the sterilisation solution is in the water tank.
• Rinse the tank thoroughly with clean water and dry it before reusing the device.
• Do not immerse the main unit in water.
Storage
If the unit is not going to be used for a long period of time, we recommend:
• Cleaning it as detailed above.
• Air dry thoroughly before storing.
• Ensure the power adaptor is safely stored with the unit.
• Store in its original packaging in a cool, dry, dust free area away from heat sources & direct
sunlight.
Note: Do not store the unit until it is completely dry. Failure to do so may cause bacteria,
mould spores and fungus to grow & multiply in any residual dampness.
NSMDH-1608 Instructions 9.11.indd 6 15/11/2010 10:56
6
®
Troubleshooting
Problem Possible Cause Solution
The dehumidifi er
doesn’t work
• Is it plugged in?
• Is the water tank fi tted
correctly?
• Is the water tank full
• Is the temperature below
5°C
• Check connection to unit
and mains
• Position tank correctly in
the unit
• Empty tank
• The unit cannot operate
effectively at temperatures
below 5°
The dehumidifi er
doesn’t seem to
perform
• Is the air inlet or outlet
blocked?
• The humidity may already
be low in the room
• Clean outlets
• Dehumidifi cation is not
necessary
Tank full
indicator always
on
• The water tank may be full
or not fi tted properly
• Remove tank from unit and
empty it or re-adjust as
necessary
The unit is
leaking
• Tank could be damaged
• The surface may be uneven
• Check the tank is in good
condition & not cracked
• Check unit is on a level
surface
The unit is very
noisy
• Uneven surface
• Ensure the unit is placed on
a level surface
Recycling and Disposal
The WEEE directive (Waste Electrical and Electronic Equipment; 2002/96/EC) has
been put in place to ensure that products are recycled using best available
treatment, recovery and recycling techniques to ensure human health and high
level environment protection. Your product is designed and manufactured with
high quality materials and components, which can be recycled and reused.
Do not mix products bearing the crossed out bin symbol with your
general household waste. Please recycle where facilities exist.
Check with your Local Authority or retailer for recycling advice.
NSMDH-1608 Instructions 9.11.indd 7 15/11/2010 10:56
7
®
Service and Warranty
• Do not use any product that has been damaged in any way. Return the complete
product to the place of purchase for inspection, repair or replacement.
• For your convenience, record the date you received the product below, and
attach your purchase receipt docket as proof of purchase.
• To ensure your product is covered by warranty, the complete product together
with your purchase receipt should be returned to your retailer.
NScessity guarantees this product free from defects in materials and workmanship
for a period of one (1) year. Should this unit be operated under conditions other
than those recommended or any attempts made to modify the unit or if the
product has been re-sold, this will render the WARRANTY VOID.
The product you buy may sometimes differ slightly from the illustration.
This warranty is in addition to, and does not affect, your statutory rights.
Should you have a problem with this product,
please contact our help desk on Tel: 0870 765 2574
or visit our website at www.NScessity.co.uk
This product has been manufactured to comply with
CE directives 2006/95/EC & 2004/10B/EC
NScessity has a large range of premium products.
We endeavour to ensure NScessity Products are the
best you can get in their categories, we are very proud
of them! Please visit our website for further information,
www.NScessity.co.uk
Date of purchase:
Place of purchase:
NSMDH-1608 Instructions 9.11.indd 8 15/11/2010 10:56
essentials
®
Tel: 0870 765 2574
www.nscessity.co.uk
GU8 6BD
NSMDH-1608 /IM/1011
Copyright © NScessity. All rights reserved
Specification
Model No: NSMDH-1608
Voltage Frequency: 230V ~ 50Hz
Power: 65W
Output : DC12V
Tank capacity: 2.2L
Extraction rate: max 600ml/day (30% / 80% RH)
Weight: 2.1kg
Dimensions: 360 x 230 x 140 mm
Instruction Manual
www.nscessity.co.uk
NSMDH-1608 Instructions 9.11.indd 1 15/11/2010 10:56
Loading...
