SM6500AA-2
NIPPON PRECISION CIRCUITS INC.
RC Network with ESD Protection
OVERVIEW
The SM6500AA-2 is an RC network with built-in ESD protection diode. It is ideal for applications such as
IEEE1284 parallel port terminator filters where ESD protection and EMI noise elimination are required.
FEATURES
■
IEEE1284 parallel port terminator filter and integrated protection devices
■
EMI noise elimination filter
■
ESD protection: ± 8kV (contact discharge)
■
28-pin QSOP package
*1: Typ ic al value
*1
PACKAGE DIMENSIONS
(Unit: mm)
9.89 ± 0.09
0.22 ± 0.03
0.635
0.25 ± 0.05
ORDERING INFORMATION
De vice Pack ag e
SM6500AA-2 28-pin QSOP
0.10
3.90 ± 0.09
−0.1
+0.05
0.2
−0.21
+0.2
6.0
1.47 ± 0.1
0 to 8
0.355
7 ± 3
0.835 ± 0.435
NIPPON PRECISION CIRCUITS—1
CIRCUIT DIAGRAM
SM6500AA-2
R1
1
2
3
4
5
6
721
8
10
11
12
13
R1
R1
R1
R1
C
C
R1
R2
C
R1
R2
C
R1
R2
C
R1
R2
C
R1
R2
C
C
R2
C
R2
C
R2
R1
C
R1
C
R1
C
R1
28
C
R1
27
C
26
25
24
23
22
20
199
18
17
R1
14
R2
16
C
R1
15
C
NIPPON PRECISION CIRCUITS—2
PIN DESCRIPTION
(Top view)
128
2
3
4
5
6
7
8
9
10
11
12
13
14
27
26
SM6500AA
25
24
23
22
21
20
19
18
17
16
15
SM6500AA-2
Number Description
1 ESD protection circuit with pull-up resistor.
Circuit diagram
2
8
10
12
15
27
28
Input Outp ut Terminator filter circuit
326
425
524
623
721
919
11 18
13 17
14 16
20 Supply
22 Ground
■
Circuit diagram
■
220pF
Input Output
R2
33Ω
220pF
CC
V
R1
2.2kΩ
C
VCC
R1
2.2kΩ
C
NIPPON PRECISION CIRCUITS—3
SM6500AA-2
ELECTRICAL CHARACTERISTICS
Parameter Condition Rating Unit
DC resistance
R1 2.2 k
R2 33
Resistance variation ±15 %
Resistance temperature coefficient 500 ± 350 pp m
Resistance power rating 100 m W
Electrostatic capacitance 220 pF
Electrostatic capacitance variation ±15 %
Diode maximum leakage current 25
For ward clamp voltage
Re verse clamp voltage +1µA, 25
Maximum operating voltage V
°
C, max V
−
1µA, 25
CC
CC
°
C 7.5 ± 1 V
°
C 7.0 ± 1 V
1µA
6V
Maximum power dissipation 1W
Ope rating temperature range
−
20 to 85
Ω
Ω
°
C
FILTER INSERTION LOSS (typical characteristics)
S
(Ta = 25 ° C) S
12
0
-10
-20
-30
Gain (dB)
-40
-50
-60
1.00E+05 1.00E+06 1.00E+07 1.00E+08 1.00E+09 1.00E+10
Frequency (Hz)
Measurement Circuit (pin 14 to pin 16)
R2
(Ta = 25 ° C)
21
0
-10
-20
-30
Gain (dB)
-40
-50
-60
1.00E+05 1.00E+06 1.00E+07 1.00E+08 1.00E+09 1.00E+10
R1
C
Frequency (Hz)
1614
HP8 753 B Ne twork Analyzer
HP85046A S-parameter Test Set
NIPPON PRECISION CIRCUITS—4
