A World of Solutions
Leaders in Life. Safety. Technology
NOTIFIER continuously develops new solutions that improve life safety in buildings
worldwide—an unwavering commitment for over sixty years. Together with our
premier independent distributors, we design, manufacture, integrate, install
and service the world’s leading fi re, voice evacuation, and advanced detection
systems. Now we lead the way with powerful Emergency Communications
Systems (ECS) to save lives and protect property from new and emerging threats
using today’s most innovative communication and networking technologies.
When lives are at risk, trust NOTIFIER total life safety solutions to protect what
matters most.
2 www.notifi er.com
The ONYX® Series: The Ultimate in Life Safety 4
The FireWarden Series 11
Small Scale Solutions and Communicators 14
ONYX FirstVision
TM
Wayfi nding Technology 15
Networking and Integration 16
Emergency Communications Systems 18
Advanced Detection Technology 21
Gas and Flame Detection 23
A World of Solutions 3
The ONYX® Series
The Ultimate in Life Safety and
Emergency Communications Technology
Flexible, Expandable, Backward Compatible
NOTIFIER’s ONYX® Series of intelligent fi re alarm control panels have the fl exibility to meet the needs of any size application. ONYX® Series
panels are easily expanded with NOTI-FIRE-NETTM, NOTIFIER’s intelligent fi re alarm network, to keep pace with your life safety needs.
What’s more, ONYX
so you can add-on or upgrade without having to replace existing devices.
®
Series panels and NOTI-FIRE-NETTM are completely backward compatible with existing NOTIFIER intelligent systems,
Advanced Detection Technology
ONYX® detection delivers a rapid, intelligent response to incipient fi re signatures while substantially reducing nuisance alarms. Specialty
detectors supply stability and very early warning capability where unique hazards and environmental conditions exist that prohibit the use
of traditional smoke detectors.
Integrated Audio Evacuation and Paging
ONYX® Digital Voice Command (DVC), NOTIFIER’s multi-channel digital audio evacuation and paging system, features eight channels
of industry-leading quality audio, fi ve fi refi ghter telephone channels, wire, fi ber or hybrid options, and can broadcast multiple, distinct
messages throughout an entire facility or across a campus simultaneously.
Easy to Use and Maintain
ONYX® Series panels feature full QWERTY keypads, large 80-640 character LCD displays, and intuitive menu options, making it easy
for facility managers to perform routine system maintenance, testing, and basic programming functions such as enabling or disabling
points. If an intelligent device is ever damaged and needs replacement, facility personnel can do so quickly and easily without the need
for special tools or programming software.
4 www.notifi er.com
NFS-320 – Built for Speed
The NFS-320 is engineered for small applications, incorporating features that
minimize installation time, enable faster response times, and simplify maintenance
and usability. The NFS-320 offers all the sophistication and premier performance of
the ONYX Series.
Speed of Installation
With the NFS-320’s auto-program feature, fi re protection can be established in seconds. Additional programming
can be accomplished with the built-in QWERTY keypad or with the VeriFire tools programming utility.
Speed of Detection
NOTIFIER’s patented FlashScan protocol combined with ONYX® Advanced Detection, featured in every ONYX® Series
panel, exceeds worldwide code requirements for response time, and delivers a fast, accurate response to smoke,
carbon monoxide, and/or heat conditions.
Features
• One Signaling Line Circuit (SLC) with 318 devices (159 detectors
and 159 modules), Style 4, 6 or 7
• Four Class A/B built-in NAC (Notifi cation Appliance Circuits)
• Fully fi eld programmable
• Removable chassis design for easy installation and service
• Direct connect to First Command Emergency Communications System
• Networkable with NOTI-FIRE-NET
and ONYXWorks® compatible up to 200 nodes for NFN
• Optional IP or GSM Communicator
• Listed for releasing
TM
, High Speed NOTI-FIRE-NETTM,
Applications
• Nursing Homes
• Elementary Schools
• Places of Worship
• Retail
• Medical Offi ces
A World of Solutions 5
NFS2-640 – Unparalleled
Flexibility
The NFS2-640 is ideal for mid-size applications, and easily expanded via
NOTIFIER’s intelligent fi re alarm network, NOTI-FIRE-NETTM, to accommodate
future building expansion.
Adapts to Your Needs
The NFS2-640’s modular design maximizes fl exibility and allows customization to your specifi c life safety needs.
And should those needs change in the future, the NFS2-640 can adapt with the addition or removal of system modules.
Adapts to Your Environment
The NFS2-640 self-optimizes each individual sensor alarm thresholds to speed response times and minimize, if not eliminate, nuisance alarms.
Features
• One Signaling Line Circuit (SLC), expandable to two, Style 4, 6 or 7
• 318 devices per SLC (159 detectors and 159 modules), 636 devices
per panel or network node
• 80-character, 640-character, or displayless (network node) operator interface options
• ONYX Intelligent Sensing - nine levels of sensitivity, drift
compensation and maintenance alert, and auto detector test
• 6.0 Amp switch mode power supply
• Fully fi eld programmable with 80-character display
• Optional Integrated Digital Voice Command with eight channels
of high quality digital audio and fi refi ghter telephone on a single cable
• Networkable with NOTI-FIRE-NET
and ONYXWorks compatible up to 200 nodes for NFN
• Optional IP or GSM Communicator
• Listed for releasing
TM
, High Speed NOTI-FIRE-NETTM,
Applications
• Dormitories
• Warehouses
• Big Box Retail Stores
• Low-rise Offi ce Buildings
• K-12 Schools
• Theaters
6 www.notifi er.com
The ONYX® Series
NFS2-640
Fire Alarm
Control Panel
NFS-320/NFS2-640 Confi gurations
Digital or Analog Audio Loop*
Integrated Digital Voice Evacuation
EIA-485
Speaker Circuit
FDU-80
NFS-320
Fire Alarm Control Panel
FSP-851
Photo Detector
FCO-851
IntelliQuad
Photo/CO Detector
TM
PLUS
DNR
Duct Detector
FAPT-851
Acclimate Plus
Detector
FSL-751
VIEW Detector
FST-851
Thermal Detector
EIA-485
EIA-232
EIA-485
EIA-485
ACM-24AT
LCD2-80
Firefi ghter Telephone Circuit
Digital Audio Amplifi er*
*NFS2-640 must have an NCA-2 (not shown)
to support Digital Audio Amplifi ers
Speaker Circuit
Speaker Circuit
First CommandTM NFC-100
First Command
TM
Voice Evacuation System
FSC-851
IntelliQuad
Multi-Criteria
Detector
XCD
Gas Detector
XP Series
TM
Multi-Module
FMM-1
Monitor Module
NBG-12LX
Addressable
Manual Pull Station
FMM-1
Monitor Module
FZM-1
2-Wire Detector
Monitor Module
ACPS-610
Addressable Charger
Power Supply
PRN-6 Printer
CO1224T
2151
Photo Detector
P2R
Horn/Strobe
P2R
Horn/Strobe
P2R
Horn/Strobe
Intelligent Devices Peripheral Devices
A World of Solutions 7
NFS2-3030 – Sheer Power
and Performance
The NFS2-3030, with its impressive point capacity and powerful programming
options, is the complete solution for large scale applications requiring superior
performance.
Customization
The modular design of the NFS2-3030 allows authorized users to view and control the system from anywhere in the facility.
Capacity
The NFS2-3030 supports over 3,000 intelligent devices on ten Signaling Line Circuits (SLCs) – perfect for protecting high-rises,
large manufacturing plants, or multiple campus buildings with a single panel. When additional protection is required, the NFS2-3030
can be expanded with additional panels using NOTI-FIRE-NETTM, NOTIFIER’s intelligent fi re alarm network.
Features
• Up to 10 Signaling Line Circuits Style 4, 6 or 7
• Point Capacity: Up to 159 detectors and 159 modules per SLC
• Large 640-character LCD backlit display or displayless
• Networkable with NOTI-FIRE-NET
and ONYXWorks® compatible up to 200 nodes for NFN
• Built-in Degraded Mode option.
• Include 9 levels of alarm and pre-alarm, cooperative sensing
and self-optimizing pre-alarm
• Optional integrated Digital Voice Command (DVC)
• EIA-485 annunciators, including custom graphics
• Optional IP or GSM Communicator
• FM6320 approved gas detection system
• Listed for releasing
TM
, High Speed NOTI-FIRE-NETTM,
Applications
• Colleges and Universities
• Hospitals
• High-rise Buildings
• Hotels
• Airports
• Military Bases
• Stadiums
8 www.notifi er.com
The ONYX® Series
Digital Voice Command
– Integrated Emergency
Communications
ONYX® Digital Voice Command (DVC) is NOTIFIER’s most powerful Emergency
Communications System (ECS), designed to communicate one- or two-way emergency
messages to individuals and groups, plus paging with the NFS2-640 and NFS2-3030.
NOTIFIER’s solutions are scalable, ECS technologies that can be implemented in phases
and integrated as they’re brought online - enhancing continuity and control.
Superior Message Clarity
From message storage to amplifi er output, the voice message remains
in a digital format to eliminate distortion and deliver unequaled clarity.
Broadcast Multiple Messages Simultaneously
ONYX® DVC features 8 channels of industry leading quality audio, 5 fi refi ghter telephone channels,
wire, fi ber or mixed media networking options, and can broadcast multiple, distinct messages throughout
your entire facility simultaneously. With ONYX
pertaining to their location and proximity to the emergency.
®
DVC, building occupants will receive clear voice instructions
Features
• Up to 32 minutes of standard quality or 4 minutes of high
quality digital audio storage of user-selected/created messages
and tones. Wire, single- and multi-mode fi ber-optic media options
• 4-channel analog audio supported with optional DVC-AO
• Up to 1000 audio sequences.
• Message prioritization
• Flexible programming for distribution of messages
• Direct connection with up to 32 Digital Audio Loop (DAL) devices.
• Optional DS-RFM, DS-FM, and DS-SFM fi ber modules may
be used to convert one or both Digital Audio Ports for operation
with single-mode or multi-mode fi ber
• DCC (Display and Control Center) capabilities when used with optional DVC-KD
• Firefi ghters’ Telephone Communications to local FFT riser on DVC, 32 local DAL
device FFT risers, and FFT communication to additional command stations
A World of Solutions 9
The ONYX® Series
NFS2-3030 Confi guration
Digital or Analog Audio Loop*
EIA-485
EIA-485
Integrated Digital Voice Evacuation
Speaker Circuit
FDU-80
NFS2-3030
Fire Alarm
Control Panel
FSP-851
Photo Detector
FCO-851
IntelliQuad
Photo/CO Detector
TM
PLUS
DNR
Duct Detector
FAPT-851
Acclimate Plus
Detector
FSL-751
VIEW Detector
FST-851
Thermal Detector
EIA-485
EIA-232
SCS
Smoke Control
Digital Audio Amplifi er
Digital Audio Amplifi er
Station
LCD-160* Display
Firefi ghter Telephone Circuit
Speaker Circuit
Firefi ghter Telephone Circuit
Custom Graphics
Annunciator
ACM-24AT
LCD2-80*
Analog Audio Risers
Digital Audio Risers
Phone Risers
FSC-851
IntelliQuad
Multi-Criteria
Detector
XCD
Gas Detector
TM
Multi-Module
FMM-4-20
4-20 MA Module
NBG-12LX
Addressable
Manual Pull Station
10 www.notifi er.com
XP Series
PRN-6 Printer
FMM-1
Monitor Module
FZM-1
2-Wire Detector
Monitor Module
ACPS-610
Addressable Charger
Power Supply
CO1224T
2151
Photo Detector
P2R
Horn/Strobe
P2R
Horn/Strobe
P2R
Horn/Strobe
Intelligent Devices Peripheral Devices
*RDP port can support LCD-160 or LCD2-80 in
Terminal Mode, but not at the same time.
The FireWarden Series
State of the Art Simplicity
NOTIFIER’s FireWarden 50 and 100-2 intelligent life safety systems are perfect for facilities requiring simple, yet, state-of-the-art life safety
that is easy to install, test, and maintain. With the FireWarden Series, you can now have the benefi ts of advanced addressable technology
with an investment comparable to conventional systems. For applications where emergency voice evacuation is required, NOTIFIER offers
the First CommandTM, a versatile voice evacuation system that integrates quickly and easily with new or existing life safety systems.
Quick and Easy Programming
The Auto-Programming feature quickly identifi es, confi gures, and stores detector
and module types, establishing fi re protection for an entire facility within seconds.
Additional system programming can be performed easily using the on-board keypad,
PS2 computer keyboard, or Windows® based programming utility.
Ease of Maintenance and Troubleshooting
Using the programming utility, authorized users can view system parameters,
including: current system status, detector sensitivity, history fi les, voltages, and
other information remotely. Because devices in trouble are individually identifi ed,
technicians can quickly and accurately diagnose the problem and respond to the
service call fully prepared to correct the issue.
A World of Solutions 11
The FireWarden Series
FireWarden-50
– A Non-Conventional Approach
The FireWarden-50 is perfect for smaller buildings requiring a minimal amount of
initiating and notifi cation devices - installations typically served by conventional panels.
Offering all the benefi ts of addressable technology, including support for up to 50
addressable devices of any type on a single SLC loop, the FireWarden-50 represents
a highly competitive and favorable alternative to today’s conventional systems.
Features
• One Style 4, 6, or 7 SLC
• Supports up to 50 addressable devices (any mix of detectors and modules)
• Two Class A or B, independently programmable NACs
• 2.7 amp power supply
• Integrated Digital Alarm Communicator Transmitter (DACT)
• Optional IP or GSM Communicator
• 80-character LCD display
• Up to 8 remote annunciation devices: 80-character LCD, graphic annunciator, printer
Applications
banks, child care centers,
places of worship, restaurants,
and small retail stores.
FireWarden-100-2
– An Intelligent Option
The FireWarden-100-2 is designed for applications requiring more advanced
addressable intelligence, fl exible programming options, and robust power supply
for driving horns, strobes, and auxiliary devices.
With features such as remote upload/download programming and diagnostics,
point identifi cation, drift compensation, built in DACT, and NAC synchronization,
the FireWarden-100-2 delivers big system performance on a smaller scale.
Features
• One Style 4, 6, or 7 SLC
• Up to 198 addressable devices, (99 detectors/99 modules)
• Four Class B or two Class A NACs
• 3 amp power supply, expandable to 6 amps
• Up to 32 remote annunciators: 80-character LCD
• Integrated Digital Alarm Communicator Transmitter (DACT)
• Optional IP or GSM Communicator
• 80-character LCD display
Applications
cinemas, department stores,
food stores, elementary schools,
and small nursing homes
or assisted living facilities.
12 www.notifi er.com
Applications
auditoriums, theatres,
restaurants, places of worship,
and museums.
First Command
TM
Emergency
Communications – Quick
and Easy Integration
NOTIFIER’S First CommandTM is optimal for small facilities that require voice evacuation
or emergency communications systems. First Command
and separate fi refi ghter telephone system integrates quickly and easily with new
or existing NOTIFIER life safety systems, or any other competitive panel.
Features
• Single or dual, independently programmable, 25 watt speaker circuits
• Each fi eld-recordable message can be 60 seconds
• Up to 14 distinct messages
• All-call feature
• Live paging with built-in microphone
• Supports multiple Local Operator Consoles (LOCs) or Remote Paging Units (RPUs)
TM
voice evacuation, paging,
To Central Station Over
Telephone Network
EIA-485 Loop
from FireWarden-100-2
FireWarden Series Confi guration
FireWarden-50 or
FireWarden-100-2
Fire Alarm
Control Panel
SLC Loop
NDM-100
Dual Monitor Module
24VDC
ANN-BUS
EIA-232
EIA-485
NP-100
Photo Detector
DNR
Duct Detector
NI-100
Ion Detector
MM-100/MM-100P
FDU-80
Up to Eight Speaker Circuits
N-ANN-80
NH-100
Thermal Detector
NZM-100-6
NZM-100
2-Wire Detector
Monitor Module
PRN-6 Printer
NOT-BG12LX Addressable
Manual Pull Station
NCM-100
Control Module
2151
Photo Detector
First Command
Voice Evacuation System
TM
First Command
NFC-125DA
TM
A World of Solutions 13
Small Scale Solutions
and Communicators
Spartan-25
25-Zone Fire Alarm Control Panel
• 25 SLC points
• 120/240 volt operation
• Two amp power supply
• Two class B NACs
• Five zones
• Built-in dialer
• LEDs for system status; alarm, trouble,
supervisory, etc.
• Uses Windows Internet Explorer
programming via laptop Ethernet port
• UL/ULC listed
®
for
SFP-5UD
5-Zone Control Communicator
• 5 Class B zones (Class A with option
module)
• Built-in digital communicator
• 2 Style Y/Class B NAC’s
(Style 2/Class A Optional) 3.0 amps
• Optional IP Communicator
SFP-10UD
10-Zone Control Communicator
• 10 Class B zones (Class A with
option module)
• Built-in digital communicator
• 4 Style Y/Class B NAC’s
(Style 2/Class A Opt.) 7.0 amps
• Optional IP or GSM Communicator
SFP-2402
2-Zone Control
• 2 Class B Initiating Device Circuits
(Zones); i3 ready
• 1 Class B Notifi cation Appliance Circuits,
3.0 Amps and programmable strobe
synchronization
• Form-C Alarm and Trouble relays
SFP-2404
4-Zone Control
• 4 Class B Initiating Device Circuits (Zones)
with Class A option module; i3 ready
• 2 Class B Notifi cation Appliance Circuits,
3.0 amps expandable to 6.0 amps, with
Class A option and programmable strobe
synchronization
• Form-C Alarm, Trouble and Supervisory
relays
RP Series Releasing Controls
• Two models – RP-2001 for pre-action
deluge, RP-2002 for agent release
• Six zones – cross zone, abort and
manual release
• Four Notifi cation Appliance Circuits
– 2 for release, 2 for warning
411 Series Communicators
• Three models available:
411 – Slave Communicator
411UD – Slave Communicator
with upload/download
411UDAC – Stand-alone Communicator
with upload/download
• Up to four input channels (three on the 411)
• Fully programmable with
PRO-411 or with Windows
utility (up/download models)
®
IPGSM-4G Communicator
• IPGSM-4G Fire Alarm Communicator
• Eliminates phone line expense
• Multiple path for improved connectivity
IP Communicator
• IPDACT-2/UD Fire Alarm Communicator
• Eliminates standard phone line expense
• Ninety second supervision of communication
circuit
14 www.notifi er.com
ONYX FirstVision
TM
ONYX FirstVision
TM
Points the Way
In an emergency, the only thing more important than speed is reliable
information. With ONYX FirstVision
mander goes directly to the system’s interactive touch screen to quickly
assess critical information, such as the origin of a fi re, how fast and in
which direction it is spreading, and the access or exit routes that are
affected. Armed with this knowledge, fi refi ghters and other emergency
personnel can quickly develop and execute a safer, more effective
response that can potentially reduce the loss of property and life.
Get the Whole Picture, Quickly and Accurately
Current annunciators only display information from the fi re alarm control panel, usually no more than which devices are in alarm.
On its 19” LCD, wall mounted touch screen, ONYX FirstVision
devices, potential hazards, additional access and egress routes, as well as standpipe, stairway and emergency shutoff locations
throughout the building. Anything that might help or hinder an emergency responder is clearly indicated.
TM
displays entire fl oor plans with the location of all active alarm system
TM
, a fi rst responder or incident com-
See the Whole Campus
or a Single Detector
Using ONYX FirstVisionTM, emergency responders quickly identify
any and all areas of concern within an individual building or
multiple buildings throughout a campus. With an entire campus
in their view, incident commanders can direct arriving personnel
and apparatus to strategic positions around the emergency.
Then, with just a few touches of the screen, they can narrow
their focus down to an individual building, fl oor, or room
-even a single, activated smoke detector.
A World of Solutions 15
Networking & Integration
Unite Multiple Systems
IP Network
DACR
NOTIFIER
Fire Panels
DACR
ONYX
FirstVision
into One with ONYXWorks
ONYXWorks® gives you total control over your life safety system.
Whether you need to monitor a single building, a campus, or a
citywide or global enterprise, ONYXWorks
workstation that integrates NOTIFIER systems over a single network.
Highly Intuitive Interface
Hi
The intuitive ONYXWorks® interface displays building fl oor plans with interactive,
three-dimensional fi re, security, CCTV, and includes clear, concise instructions
on what actions must be taken for both fi re and non-fi re events. Customizable
screens and multiple confi guration options facilitate set up, minimize operator
training and allow you to adapt the system to your needs.
OAX2-24V
LED Sign
TM
Speak Locally, Act Globally, with NOTIFY-IP
When responding to an event, a coordinated response can save lives and
preserve property. NOTIFY-IP, a plug-in to ONYXWorks, broadcasts encrypted,
real-time voice instructions to a single facility or to multiple locations worldwide
using an IP network connection. With NOTIFY-IP, the network connection is
continuously monitored to ensure system integrity and reliability.
®
is a single-point-of-control
®
Fire and Security Panels with DACT
Gives you total control over your system
16 www.notifi er.com
ONYXWorks System Features
• Supports NOTIFIER’s NOTI-FIRE-NET and High Speed NOTI-FIRE-NETTM networks
• Connects new and existing equipment into a Local Area Network (LAN)
or Wide Area Network (WAN)
• Supports Digital Alarm Communicator Receiver interface for monitoring
of remote panels
• Graphic Editing mode allows for on-site or off-site programming of fl oor
plan screens, devices and navigational buttons
• Windows
• Redundant hard drives for enhanced survivability
• Alpha-numeric pager support
• E-mail notifi cation
• Displays real-time event messaging on LED Sign from the NOTI-FIRE-NET
• Supports the monitoring and control of aspirating detectors from NOTIFIER’s
Intelligent Aspirating System Detectors (IASD) and VESDAnet Network
®
7 64 bit platform
TM
NOTI-FIRE-NET
TM
– Peace of
Mind with Enhanced Survivability
The NOTI-FIRE-NETTM intelligent life safety network links multiple NOTIFIER intelligent fi re alarm control panels together as one
for cooperative control and network-wide monitoring. Each fi re alarm panel on NOTI-FIRE-NET
and continues to operate independently, yet cohesively, as part of a unifi ed network. This prevents the loss of a single node from
compromising other panels. The result is greater system survivability.
TM
maintains individual programming
NCA-2 ONYXWorks®
Workstation
NOTIFIER Fire Panels
NOTI-FIRE-NET
NWS
ONYX FirstVision
TM
Web Server
TM
Easily Accommodates Future Growth
NOTI-FIRE-NET
your current system without having to replace existing equipment. As your facility grows, it is easy to expand the network to meet your needs.
TM
supports all ONYX® Series panels and is backward compatible to Legacy NOTIFIER Fire Alarm Control Panels, so you can upgrade
NOTI-FIRE-NET System Features
• Supports ONYX® Series fi re alarm control panels: NFS-320, NFS2-640, NFS2-3030 (NFS-3030, NFS-640)
• Network Control Annunciator to annunciate network events and provide network control
• BACnet Gateway supports industry standard BACnet/IP connectivity to Building Automation Systems
• Modbus Gateway supports industry standard Modbus/IP connectivity to industrial control systems
• The Common Alerting Protocol (CAP) Gateway supports industry standard CAP connectivity
to Distributed Recipient’s Mass Notifi cation Systems (DRMNS)
• Interfaces to the Xtralis
• OAX2-24V LED Sign displays real-time event monitoring and messaging override ability
• NOTI-FIRE-NET
• ONYX FirstVisionTM technology is an intuitive touch screen display for fi rst responders
TM
VESDAnet network using a VESDA-HLI Gateway
TM
Web Server (NWS) provides remote read status capabilities, instant e-mail and text messaging
High Speed NOTI-FIRE-NET System Features
• Supports all ONYX® Series Fire Alarm Control Panels
• Supports NWS, FirstVision
• Increased network node capacity to 200 nodes for large applications
• Increased network communication speeds to 12Mb for Wire and 100Mb for Multi-Mode and Single-Mode Fiber
TM
, BACnet and Modus, CAP, VESDA-HLI, SLC-IM and LED Sign Gateway applications
A World of Solutions 17
Emergency Communicatio
From Localized Emergencies to Global Events
– Inform Everyone.
In a wide scale emergency, keeping people informed is critical to keeping them safe. Notifying more people
of a dangerous and potentially life threatening situation can prevent further injuries and save more lives.
Such situations require an emergency communications system to broadcast live, up-to-the minute emergency
information to everyone in a building, campus, or multiple facilities spread across a city, state…even the globe.
Distributed Digital Voice Evacuation
Digital Voice Command (DVC) systems can be distributed throughout multiple buildings and linked together via the NOTI-FIRE-NETTM intelligent
network. Each system can operate independently in case of a building-specifi c emergency, or cohesively as part of a unifi ed emergency
communications system for large-scale emergencies. Using the DVC command center, authorized personnel can distribute emergency voice
messages to an entire campus or just to specifi c areas. Applications include Universities, High Rise Buildings, Corporate Campuses,
Industrial Facilities, Chemical and Utility Plants, Ports, Mass Transit Hubs, Sports Arenas, and Government Complexes.
Worldwide Emergency Notifi cation
over IP Technology
NOTIFY-IP uses voice over IP technology to send live, direct voice instructions for
preserving life and property throughout a large facility, campus, or multiple facilities
across the world. Within seconds, facilities all over the world can be notifi ed of a potential or existing emergency. Activation of NOTIFY-IP is simple; the operator selects
the desired paging location(s), clicks the “Start Paging” button, and speaks into the
microphone with the appropriate emergency message. Applications include Global
Corporations, Industrial Facilities, Chemical and Utility Plants, Ports, Mass
Transit Hubs, Sports Arenas, and Government Complexes.
18 www.notifi er.com
ns Systems
Displays
Land Line
Telephones
Unifying Critical Communications
Distributed Recipient Emergency Communications alerts
large and targeted audiences quickly and reliably with critical
communication to desktop systems, public displays, telephones
and wireless devices to ensure that the messages are received
within seconds, not minutes, reducing the risk of employees
taking incorrect action or putting themselves in danger.
Cellular
Phones
Text
Messaging
Desktop
Alerts
E-mail
Alerts
A World of Solutions 19
Emergency Communications
First Command
TM
– Integrated, Expandable
Emergency Communications
NOTIFIER’s First CommandTM is a compact, standalone voice evacuation
and emergency communications system that can be used in many
common building types to meet life safety code or end user requirements
for voice or paging during an emergency. It’s an integrated system that
can be easily expanded to include many of the advanced features found
in NOTIFIER’s more sophisticated Digital Voice Command system such
as backup amplifi cation, remote microphones, fi refi ghters telephones,
local operating consoles and remote paging units.
First CommandTM Integration
With direct integration to NOTIFIER’s addressable ONYX® or FireWarden panels, the fi re alarm control panel can take direct control of First
Command
responding with the correct message appropriate for that incident or emergency. Programming the integrated First CommandTM system
is done via a serial communications by using a built in programming utility from a laptop with a web browser. First CommandTM can be
added to buildings with non-NOTIFIER fi re panels via contact closures and make the most of fi re panels already installed.
TM
during an incident. The fi re alarm control panel and First CommandTM will act as one unit in identifying the alarm location and
Powerful Features
The First CommandTM main unit has 50 watts of audio power with the option of sending the message to up to eight discrete speaker
circuits. The addition of a second, optional amplifi er raises the power output to 100 watts or 50 watts of backup power. Up to fourteen
unique messages can be stored in First Command
either automatically via programming or manually by the incident commander. Distributed amplifi ers can be added to the main unit for
TM
and then directed to the areas of the building where the emergency is unfolding
system expansion up to 1,100 watts of speaker power split over 24 speaker
circuits. If called for by the system designer, up to a total of eight Local Operating
Consoles (LOCs), Remote Paging Units (RPUs), or Remote Microphones (RMs)
can be added to First Command
can be installed through the building. If an incident occurs near a LOC or RPU,
more precise incident management is possible.
TM
via an easy-to-wire interface. LOCs or RPUs
20 www.notifi er.com
Advanced Detection
Speed, Stability,
and Reliability
NOTIFIER’s ONYX® Series intelligent life safety systems respond rapidly
to incipient fi re signatures with unmatched precision. At the same time,
they signifi cantly reduce the occurrence of nuisance alarms. It’s all made
possible by NOTIFIER’s ONYX
Advanced Detection is comprised of two key elements: a set of complex
software algorithms found in all ONYX Series fi re alarm panels and a suite
of advanced, specialty detectors. From mission-critical applications where
even a trace amount of undetected smoke is unacceptable, to environments
where the presence of dust, moisture, or theater smoke is the norm,
ONYX Advanced Detection is the answer.
®
Advanced Detection technology. ONYX®
A World of Solutions 21
Advanced Detection
IntelliQuadTM PLUS – Combination
Smoke / Carbon Monoxide (CO) Detector
NOTIFIER’s IntelliQuadTM PLUS detector is a plug-in, addressable device that provides both fi re and Carbon
Monoxide (CO) detection. For fi re, the detector combines four separate sensing elements in one unit (smoke, CO,
infrared, and heat) to sense multiple components of a fi re. This approach has enhanced sensitivity to real fi re
with heightened immunity to nuisance particulate. For CO, the detector’s electrochemical sensing cell creates
a separate signal for life safety CO detection. When used together with our addressable sounder base, you
can replace as many as four separate devices for a cleaner and more effi cient installation.
IntelliQuadTM – The Ultimate Multi-criteria Detector
IntelliQuadTM senses smoke particulates, carbon monoxide (CO), heat, and infrared signatures simultaneously
to determine the presence of a fi re condition. Sensor readings are continually evaluated against one another,
allowing the detector to operate normally with high immunity to nuisance conditions, while quickly responding
to true alarm events.
AcclimateTM – Self-optimizes, Senses Heat and Smoke
The AcclimateTM Plus detector combines thermal and photoelectric technologies into a single device.
It constantly monitors ambient heat and particulate conditions, adjusting sensitivity parameters and
alarm thresholds automatically to maximize detection across a broad range of fi re types.
VIEWTM Laser Detector – Super Sensitive
Spot-type Detection
The VIEWTM laser smoke sensor is programmable to be up to 100 times
more sensitive than standard photoelectric smoke detection technology.
TM
VIEW
is ideal for critical applications where even a trace of undetected
smoke is unacceptable or where high air fl ows can make traditional
smoke detectors ineffective.
Aspirating Smoke Detection – Early
Warning in Challenging Environments
Intelligent Fire Alarm Aspiration Sensing Technology® (FAAST) provides early warning
of an impending fi re hazard. FAAST can buy time to investigate an alarm and initiate
an appropriate response to prevent injury, property damage, or business disruption.
With a wide sensitivity range and multi-level warnings, even minute levels of smoke
can be detected before a fi re has time to escalate. Connect the unit to the building’s
Ethernet portal to provide access and monitoring from anywhere in the world.
22 www.notifi er.com
AAAA
Gas and Flame Detection
Fully Integrated Gas
and Flame Detection
Almost anywhere that people gather for work or leisure,
indoors or out, there is a potential risk of exposure to toxic
or fl ammable gases. Whether it is a school, dormitory, offi ce
building, shopping center, swimming pool, manufacturing plant
or warehouse, it is important to protect people, and to comply
with legal requirements for gas monitoring. In addition to
protecting building occupants, gas detection systems can
also prevent untimely and costly business disruptions.
An Added Level of Protection
With over 60 years experience leading the fi re alarm industry, NOTIFIER understands life safety. Hazardous and toxic gases are present in virtually
every commercial environment and can threaten the safety of building occupants. That’s why NOTIFIER offers a comprehensive suite of gas detection
products for a wide range of commercial and industrial environments—all of which integrate seamlessly with our proven life safety systems.
Programmable Event Threshold Maximizes Flexibility
The FMM-4-20 module is user programmable for up to fi ve different event thresholds, which are based on the concentration level of the gas being
monitored. When the gas reaches a designated threshold, the NFS2-3030 system responds by executing the appropriate pre-programmed response.
Events can be individually labeled as any one of the following conditions: Fire, Security, Supervisory, Non-Fire Trouble, Pre-Alarm, Non-Fire, and
Critical Process.
The Need for Flame Detection
While the use of heat and smoke detection covers many traditional applications,
the addition of fl ame detection offers a higher level of protection in critical, highrisk and high-value installations. Honeywell’s Fire Sentry series of fl ame detectors
includes a broad offering of industry leading fl ame detection options, providing
solutions for everything from safe areas to harsh and high risk applications
…and everything in between. Regardless of the area you’re protecting
- boiler rooms, paint booths, fuel storage / refueling facilities, gas and oil
production facilities, or aircraft hangars – Honeywell’s Fire Sentry series
of fl ame detectors has the right product for the job.
A World of Solutions 23
NOTIFIER WORLD HEADQUARTERS
12 Clintonville Road
Northford, CT 06472
United States of America
Tel: 203-484-7161
Fax: 203-484-7118
www.notifi er.com
For information on regional offi ce locations throughout the world, please visit www.notifi er.com.
www.notifi er.com
For over 60 years, NOTIFIER has been a leader in the fi re alarm industry. Today, we are
the largest manufacturer of engineered fi re alarm, advanced detection, and emergency
communications systems. With over 400 distributors worldwide, and regional support
operations on every continent, we offer the fl exibility and options your business needs.
NOTIFIER - Leaders in Life. Safety. Technology.
Follow NOTIFIER on:
M-B-PI2 5/13
Loading...
