Minimax XT single gas detection
delivers advanced, full feature
functionality and user configurability
Lumidor Minimax XT
Minimax XT is the result of customer
inspired partnerships. The unit is technically
crafted to be, quite simply, the easiest and
most cost effective to use single gas on
the market. Utilizing patented sensing
technologies, the Minimax XT provides 24/7
user confidence. That means solid, reliable,
continuous protection... always.
Lumidor identified that the market demanded
more than tiny good looks in a single gas. Our
valued partners said that in addition to a small
and rugged design, single gas monitors must
offer comprehensive sensor options, simple
operation and most importantly, reliable, and
accurate readings – without false alarms triggered
by common radio interference.
Simple one button operation reduces time
consuming and costly training issues. Our unique
Temperature Compensation and Cell Output
Decay Compensation features ensure improved
accuracy across wide temperature ranges,
providing our 2 year, no calibration needed facility.
Cost Effective
• No calibration required
• Unit may be calibrated if site procedures
necessitate
• Remaining lifetime display enables planned
replacement
• 24 month continuous operation
• Low cost investment
Easy to Use
• Out-of-the-box solution
• Provided with an interactive
Training Guide available
• One button operation
Excellent EMC/RFI performance
• No false alarms due to common radio
interference or cell phones
• Complies with toughest industrial
standards for RFI immunity and EMC
compatibility reliable operation
Reliable Operation
• Uses patented SureCell™ (CO and
H2S only) and Reflex* technology
• Stable and accurate gas readings
• Intrinsically safe
Compact Design
• Small ergonomic design
• Lightweight
• Comfortable to wear
Durable housing
• Waterproof to IP67
• Rugged and impact resistant
• Weather resistant
Versatile clip design
• Includes crocodile clip - clips
anywhere to prevent accidental loss
Large Display
Uses distinctive icons to illustrate:
• Battery life status
• Actual gas reading during alarm
• Peak reading and when it occurred
• Remaining lifetime
• Alarm status
• Test status
Demanding Alarms
• Distinctive two-tone alarm
• Rapid flashing alarm alerts user of danger
• Vibrating alarm signals alarm in progress
• Low battery alarm – indicates unit nearing
end of life
Minimax XT
M
i
n
i
m
a
x
X
P
/
X
T
M
i
n
i
m
a
x
X
P
/
X
T
M
i
n
i
m
a
x
X
P
/
X
T
M
i
n
i
m
a
x
X
P
/
X
T
M
i
n
i
m
a
x
X
P
/
X
T
M
i
n
i
m
a
x
X
P
/
X
T
IP67
RA
TED
General Specication
Standard Specication
General Disposable single gas monitor for the protection of personnel against toxic and Oxygen gas hazards
Maximum Operating Life 2 years after activation
Shelf Life 12 months before activation (CO and H
Sensor Range Carbon Monoxide CO 0 to 1000 ppm (display: 0-200 ppm)
Hydrogen Sulphide H
Oxygen O
0 to 30%v/v (display: 0-25.0%v/v)
2
S 0 to 100 ppm (display: 0-100 ppm)
2
Alarm Set Points CO 35 ppm 100 ppm
(Note: Other alarm settings H
are available upon request)
O
Calibration CO/H
O
S 10 ppm 15 ppm
2
23.5% 19.5%
2
S Zero adjustment (optional Span)
2
Span adjustment
2
Operating Temperature -4°F to +122°F (-20°C to +50°C)
Humidity 5-95% RH (non-condensing)
Audible Alarm 95db at 4in (10cm)
Visual Alarm High intensity red LEDs
Vibrating Alarm Supplied as standard
Display Custom LCD
Sensor Type Electrochemical
Battery 3.6V non-replaceable Lithium battery
IP Rating IP67 (NEMA 4 & 6)
Intrinsic Safety Europe: II 2G EEx ia IIC T4 (ATEX)
UL/cUL: Class 1, Div 1, Groups A, B, C, D T4
RFI/EMC CE EN50270:1999 and EN55011
Dimensions 3.4"(H) x 2"(W) x 1.1"(D)
(87mm x 50mm x 27mm)
Weight CO/H
O
*ReexTM not available for all sensors
S 73g (2.57oz)
2
82.3g (2.90oz)
2
S), 6 months before activation (O2)
2
1 leveL
2 leveL
Display Details
Batter
y
Test Fail icon
Life time, alarm reading
Test pass icon
Level 2, CO, H
Level 1, CO, H
Level 2, O
S
2
S, O
2
2
2
Life time: Months, days, hours
Concentration units
Low peak
High peak
* Oxygen detection products must only be used
to detect oxygen depletion in air.
