SpectrAlert® Advance
Field-Selectable
Mass Notification Devices
General
SpectrAlert® Advance mass notification devices and accessories combine application versatility with all the time- and
money-saving benefits of the SpectrAlert Advance line.
SpectrAlert Advance, the broadest and most versatile line of
notification devices available, includes a wide range of
devices to meet mass notification application requirements.
ALERT-printed on white housings, SW-ALERT, SWH-ALERT
and SPSW-ALERT amber lens strobes and speaker strobes
provide visual signaling for mass notification in compliance
with ANSI/UL 1638 Standard for General Signaling Visible
Appliances. Other ALERT-printed models provide clear
lenses for use with color lens strobe attachments (amber,
blue, green, and red) that easily attach to strobe and speaker
strobe devices without a candela derating.
In addition, SpectrAlert Advance mass notification devices
include plain (non-printed) strobes, horn strobes and speaker
strobes. These devices, along with ALERT-printed devices
and SpectrAlert Advance accessories, can meet a wide
range of requirements for indoor and outdoor applications,
including mass notification, general signaling, severe
weather and emergency response.
All SpectrAlert Advance mass notification and general signaling devices are compatible with the entire SpectrAlert
Advance and include all the same time- and money-saving
innovations. For example, plug-in designs simplify installation
and reduce costly ground faults; universal mounting plates
with onboard shorting springs test wiring continuity to speed
installation and protect devices from damage; and fieldselectable settings provide versatility and enable installers to
quickly set each device to meet application requirements.
Mass Notification Features
• Plain or ALERT-printed white housings
• Amber lens strobes and speaker strobes
• Color lens attachments for use with clear lens wall or ceiling strobes
• Meets DOD specification requirements
SpectrAlert Advance Features
• Plug-in design for simplified installation and troubleshooting
• Mounting plate shorting spring easily tests wiring continuity
• Automatic selection of 12- or 24-volt operation at 15 and
15/75 candela
• Field-selectable candela settings of 15, 15/75, 30, 75, 95,
110, 115, 135, 150, 177, 185 (please refer to Equivalent
Candela Rating for UL 1971 Table)
• Rated from 32°F to 120°F (0°C to 49°C) (indoor devices);
-40°F to 151°F (-40°C to 66°C) (NEMA 4X, IP56 weatherproof devices)
• Optional tamper-resistant Torx head screw
• Compatible with System Sensor synchronization protocol
DN-60517:A
Audio/Visual Devices
SPSCW-P with LENS-RC SPSW-ALERT
SW-CLR-ALERT SW-ALERT
SpectrAlert® Advance Specifications
ARCHITECTURAL/ENGINEERING SPECIFICATIONS
GENERAL
SpectrAlert Advance strobes and horn strobes shall mount to
a standard 4” x 4” x 1.5” back box, 4-inch octagon back box
or double-gang back box. Two-wire products shall also mount
to a single-gang 2” x 4” x 1 7/8” (5.08 x 10.16 x 4.76 cm) back
box. SpectrAlert Advance speaker strobes shall mount to a 4
x 4 x 2 1/8-inch (10.16 x 10.16 x 5.40 cm) back box. A universal mounting plate shall be used for mounting ceiling and wall
products. The notification appliance circuit wiring and amplifier wiring shall terminate at the universal mounting plate.
Also, SpectrAlert Advance products, when used with the
Sync•Circuit™ Module accessory, shall be powered from a
non-coded notification appliance circuit output and shall
operate on a nominal 12 or 24 volts. When used with the
Sync•Circuit Module, 12-volt-rated notification appliance circuit outputs shall operate between 9 and 17.5 volts; 24-voltrated notification appliance circuit outputs shall operate
between 17 and 33 volts. Indoor SpectrAlert Advance products shall operate between 32°F and 120°F (0°C and 49°C)
from a regulated DC or full-wave rectified unfiltered power
supply. Strobes, horn strobes and speaker strobes shall have
field-selectable candela settings, including 15, 15/75, 30, 75,
95, 110, 115, 135, 150, 177 and 185.
STROBE
The strobe shall be a System Sensor SpectrAlert Advance
Model _______ listed to UL 1971 (clear lens strobes) and
shall be approved for fire protective service or shall be
approved for fire protective service as listed in ANSI/UL 1638
(amber lens strobes). The strobe shall be wired as a primarysignaling notification appliance and comply with the Ameri-
DN-60517:A • 06/02/2009 — Page 1 of 6
cans with Disabilities Act requirements for visible signaling
appliances, flashing at 1 Hz over the strobe’s entire operating
voltage range. The strobe light shall consist of a xenon flash
tube and associated lens/reflector system.
HORN STROBE COMBINATION
The horn strobe shall be a System Sensor SpectrAlert
Advance Model _______ listed to UL 1971 and UL 464 and
shall be approved for fire protective service. The horn strobe
shall be wired as a primary-signaling notification appliance
and comply with the Americans with Disabilities Act requirements for visible signaling appliances, flashing at 1 Hz over
the strobe’s entire operating voltage range. The strobe light
shall consist of a xenon flash tube and associated lens/reflector system. The horn shall have three audibility options and
an option to switch between a temporal three-pattern and a
non-temporal (continuous) pattern. These options shall be
set by a multiple position switch. The horn and horn strobe
models shall operate on a coded or non-coded power supply.
SPEAKER STROBE COMBINATION
The speaker strobe shall be a System Sensor SpectrAlert
Advance Model __________ listed to UL 1480 and UL 1971
and be approved for fire protective signaling systems.
Speaker shall be capable of operating at 25.0 or 70.7 nominal Vrms selected via rotary switch, and shall have a frequency range of 400 to 4000 Hz. Speaker shall have power
taps that are selected by rotary switch. The strobe shall comply with the NFPA 72 requirements for visible signaling appliances, flashing at 1 Hz over the strobe’s entire operating
voltage range. The strobe light shall consist of a xenon flash
tube and associated lens/reflector system.
OUTDOOR PRODUCTS
SpectrAlert Advance outdoor strobes, horn strobes and
speaker strobes shall be listed for outdoor use by UL and
shall operate between –40°F and 151°F (–40°C and 66°C).
The products shall be listed for use with a System Sensor
outdoor/weatherproof back box with half-inch and threefourths-inch conduit entries.
SYNCHRONIZATION MODULE
The module shall be a System Sensor Sync•Circuit model
MDL3R or MDL3W listed to UL 464 and shall be approved for
fire protective service. The module shall synchronize SpectrAlert strobes at 1 Hz and horns at temporal three. Also,
while operating the strobes, the module shall silence the
horns on horn strobe models over a single pair of wires. The
module shall mount to a 4 11/16 x 4 11/16 x 2 1/8-inch (11.90
x 11.90 x 5.40 cm) back box. The module shall also control
two Style Y (class B) circuits or one Style Z (class A) circuit.
The module shall synchronize multiple zones. Daisy chaining
two or more synchronization modules together will synchronize all the zones they control. The module shall not operate
on a coded power supply.
COLOR LENS STROBE ATTACHMENT
The System Sensor SpectrAlert Advance color lens attachments shall be approved for fire protective service as listed in
UL 1638. The lens attachments shall only be used with (plain
non-fire-printed) System Sensor strobe devices. They shall
mount to any wall or ceiling strobe and be rated from –35°F
to 151°F (-37°C to 66°C).
Specifications
PHYSICAL SPECIFICATIONS
Standard Operating Temperature: 32°F to 120°F (0°C to
49°C)
K Series Operating Temperature: -40°F to 151°F (-40°C to
66°C)
Humidity Range: 10 to 93% non-condensing (indoor models)
Dimensions:
– Wall-Mount Strobe and Horn Strobe (including lens):
5.6” L x 4.7” W x 2.5” D
– SPS Speaker Strobe (including lens and speaker):
6.0” L x 5.0” W x 4.7” D
– Ceiling-Mount Strobe (including lens): 6.8” diameter
x 2.5” D
ELECTRICAL/OPERATING SPECIFICATIONS
Nominal Voltage (strobes and horn strobes): Regulated
12 DC/FWR or regulated 24 DC/FWR
Nominal Voltage (speakers): 25 V or 70.7 V (nominal)
Maximum Supervisory Voltage (speakers): 50 VDC
Operating Voltage Range: 8 to 17.5 V (12 V nominal) or 17
to 33 V (24 V nominal)
Strobe Flash Rate: 1 flash per second
Speaker Frequency Range: 400 to 4000 Hz
Speaker Power: ¼, ½, 1, 2 watts
SPEAKER SOUND OUTPUT
UL Reverberant (dBA @ 10 ft.) 2W 1W 1/2W 1/4W
Wall-Mount SPS Series 85 82 79 76
Wall-Mount SPV Series 90 87 84 81
Ceiling-Mount SPC Series 86 83 80 77
Ceiling-Mount SPCV Series 90 87 84 81
UL CURRENT DRAW DATA
UL Max. Strobe Current Draw (mA RMS)
8–17.5 Volts 16–33 Volts
Candela DC FWR DC FWR
15* 123 128 66 71
15/75* 142 148 77 81
Standard Candela Range
High Candela
Range
30* NA NA 94 96
75* NA NA 158 153
95* NA NA 181 176
110 NA NA 202 195
115 NA NA 210 205
135 NA NA 228 207
150 NA NA 246 220
177 NA NA 281 251
185 NA NA 286 258
Page 2 of 6 — DN-60517:A • 06/02/2009
UL Max. Current Draw (mA RMS), 2-Wire Horn Strobe, Standard Candela Range (15– 115 cd)
8–17.5 Volts 16–33 Volts
15 15/75 15 15/75 30 75 95 110 115
DC Input
Temporal High 137 147 79 90 107 176 194 212 218
Temporal Medium 132 144 69 80 97 157 182 201 210
Temporal Low 132 143 66 77 93 154 179 198 207
Non-Temporal High 141 152 91 100 116 176 201 221 229
Non-Temporal Medium 133 145 75 85 102 163 187 207 216
Non-Temporal Low 131 144 68 79 96 156 182 201 210
FWR Input
Temporal High 136 155 88 97 112 168 190 210 218
Temporal Medium 129 152 78 88 103 160 184 202 206
Temporal Low 129 151 76 86 101 160 184 194 201
Non-Temporal High 142 161 103 112 126 181 203 221 229
Non-Temporal Medium 134 155 85 95 110 166 189 208 216
Non-Temporal Low 132 154 80 90 105 161 184 202 211
UL Max. Current Draw (mA RMS), 2-Wire Horn
Strobe, High Candela Range (135–185 cd)
16–33 Volts
135 150 177 185
DC Input
Temporal High 245 259 290 297
Temporal Medium 235 253 288 297
Temporal Low 232 251 282 292
Non-Temporal High 255 270 303 309
Non-Temporal Medium 242 259 293 299
Non-Temporal Low 238 254 291 295
FWR Input
Temporal High 215 231 258 265
Temporal Medium 209 224 250 258
Temporal Low 207 221 248 256
Non-Temporal High 233 248 275 281
Non-Temporal Medium 219 232 262 267
Non-Temporal Low 214 229 256 262
DN-60517:A • 06/02/2009 — Page 3 of 6
EQUIVALENT CANDELA RATING FOR UL 1971
Amber Lens Strobe Output (cd)
Listed Candela
15 15 12
15/75 15/75 15/75
30 30 24
75 75 60
95 95 75
110 110 85
115 115 90
135 135 110
150 150 120
177 177 140
185 185 150
NOTE: UL 1971 is not applicable to mass notification devices,
but these readings were obtained using the measurement procedure specified under UL 1971.
On-Axis Rating
(UL 1638)
Equivalent cd
Rating for UL
1971 Profile
CANDELA DERATING/OUTDOOR DEVICES
Strobe Output (cd)
Listed Candela
15
15/75
30
75 44
95 70
110 110
115 115
135 135
150 150
177 177
185 185
NOTE: For K series products used at low temperatures, listed candela ratings must be
reduced in accordance with this table.
Candela rating
at –40°F (-40°C)
Do not use
below 32°F (0°C)
Page 4 of 6 — DN-60517:A • 06/02/2009
Horn Tones and Sound Output Data (dBA)
24-Volt Nominal
8–17.5 Volts 16–33 Volts Reverberant Anechoic
Switch Position Sound Pattern dB DC FWR DC FWR DC FWR DC FWR
1 Temporal High 78 78 84 84 88 88 99 98
2 Temporal Medium 74 74 80 80 86 86 96 96
3 Temporal Low 71 73 76 76 83 80 94 89
4 Non-temporal High 82 82 88 88 93 92 100 100
5 Non-temporal Medium 78 78 85 85 90 90 98 98
6 Non-temporal Low 75 75 81 81 88 84 96 92
7† Coded High 82 82 88 88 93 92 101 101
8† Coded Medium 78 78 85 85 90 90 97 98
9† Coded Low 75 75 81 81 88 85 96 92
Settings 7, 8 and 9 are not available on 2-wire horn strobe.
†
DN-60517:A • 06/02/2009 — Page 5 of 6
Product Line Information
ALERT DEVICES
SW-ALERT: Strobe, Standard cd, White, Amber Lens
SWH-ALERT: Strobe, High cd, White, Amber Lens
SW-CLR-ALERT: Strobe, Standard cd, White, Clear Lens
SCW-CLR-ALERT: Strobe, Standard cd, White, Clear Lens
SPSW-ALERT: Speaker Strobe, Standard cd, White, Amber
Lens
SPSCW-CLR-ALERT: Speaker Strobe, Standard cd, White,
Clear Lens
PLAIN WALL STROBES
SR-P: Strobe, Standard cd, Red, Clear Lens
SRH-P: Strobe, High cd, Red, Clear Lens
SW-P: Strobe, Standard cd, White, Clear Lens
SWH-P: Strobe, High cd, White, Clear Lens
SRK-P: Strobe, Standard cd, Red, Clear Lens, Outdoor
SRHK-P: Strobe, High cd, Red, Clear Lens, Outdoor
SWK-P: Strobe, Standard cd, White, Clear Lens, Outdoor
SWHK-P: Strobe, High cd, White, Clear Lens, Outdoor
PLAIN CEILING STROBES
SCW-P: Strobe, Standard cd, White, Clear Lens
PLAIN WALL HORN STROBES
P2R-P: Horn Strobe, Standard cd, Red, Clear Lens
P2W-P: Horn Strobe, Standard cd, White, Clear Lens
P2WH-P: Horn Strobe, High cd, White, Clear Lens
P2RK-P: Horn Strobe, Standard cd, Red, Clear Lens, Out-
door
P2RHK-P: Horn Strobe, High cd, Red, Clear Lens, Outdoor
P2WK-P: Horn Strobe, Standard cd, White, Clear Lens, Out-
door
P2WHK-P: Horn Strobe, High cd, White, Clear Lens, Outdoor
PLAIN CEILING HORN STROBE
PC2R-P: Horn Strobe, Standard cd, Red, Clear Lens
PC2W-P: Horn Strobe, Standard cd, White, Clear Lens
PC2WH-P: Horn Strobe, High cd, White, Clear Lens
PLAIN WALL SPEAKER STROBE
SPSW-P: Speaker Strobe, Standard cd, White, Clear Lens
SPSR-P: Speaker Strobe, Standard cd, Red, Clear Lens
SPSWH-P: Speaker Strobe, High cd, White, Clear Lens
SPSRH-P: Speaker Strobe, High cd, Red, Clear Lens
SPSWV-P: Speaker Strobe, Standard cd, White, High Vol-
ume, Clear Lens
SPSRV-P: Speaker Strobe, Standard cd, Red, High Volume,
Clear Lens
SPSWK-P: Speaker Strobe, Standard cd, White, Clear Lens,
Outdoor
SPSRK-P: Speaker Strobe, Standard cd, Red, Clear Lens,
Outdoor
PLAIN CEILING SPEAKER STROBE
SPSCW-P: Speaker Strobe, Standard cd, White, Clear Lens
SPSCWH-P: Speaker Strobe, High cd, White, Clear Lens
SPSCWV-P: Speaker Strobe, White, High Volume, Clear
Lens
SPSCWVH-P: Speaker Strobe, White, High cd, High Volume,
Clear Lens
NOTE: All –P models have a plain housing (no “FIRE” marking on
cover). All outdoor units with a “K” designation in the part number
include a weatherproof back box. All “ALERT” models are printed
as such.
Agency Listings
• UL-Listed:
– S4048 Speaker & Speaker Strobes
– S4011 Horn Strobes**
– S5512 Strobes
– S3593 Strobes*, SW-ALERT
– UL3594 SWH-ALERT
• CSFM-Listed:
– 7125-1653:188 Horn Strobe**
– 7125-1653:186 Strobes
– 7125-1653:187 Strobes*
– 7125-1653:198 Alert Strobes
– 7320-1653: 201 Speaker & Speaker Strobes**
– 7125-1653:186
– 7300-1653:198 SW-CLR-ALERT
•FM Approved
– 3023572 Horn Strobes**
– 3030863 Speaker & Speaker Strobes
*(outdoor) **(indoor and outdoor)
For more information, contact Notifier. Phone: (203) 484-7161, FAX: (203) 484-7118.
Page 6 of 6 — DN-60517:A • 06/02/2009
FlashScan®, NOTIFIER® and System Sensor® are registered trademarks
of Honeywell International Inc.
©2009 by Honeywell International Inc. All rights reserved. Unauthorized use
of this document is strictly prohibited.
This document is not intended to be used for installation purposes.
We try to keep our product information up-to-date and accurate.
We cannot cover all specific applications or anticipate all requirements.
All specifications are subject to change without notice.
www.notifier.com
Made in the U.S. A.
Loading...
