CCP399

Nostalgia Electrics CCP399 User Manual [en, es, fr]

All products are trademarks of Nostalgia Products Group, LLC.
Tous les produits sont des marques de commerces de Nostalgia Products Group, LLC.
Worldwide design & utility patented or patents pending.
Conception mondiale et utilités brevetées ou brevets en instance.
© 2012 Nostalgia Products Group, LLC.
www.nostalgiaelectrics.com
(rev. 09/24/12)
CCP399
Instructions and Recipes Instrucciones y recetas Instructions et recettes
Make everyday a party!
Visit www.nostalgiaelectrics.com for more fun products.
CONTENTS
IMPORTANT PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IMPORTANT SAFEGUARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
PARTS & ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
HOW TO OPERATE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
HELPFUL TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
RECIPES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
RETURNS & WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SAFETY
ENGLISH
Your safety and the safety of others is very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.
Appliance Specications:
120 Volts, 60 Hz 325 Watts, ETL Approved
THIS PRODUCT IS FOR USE IN 120V AC OUTLET ONLY.
2
IMPORTANT PRECAUTIONS
1. NEVER immerse in water.
2. NEVER use near water.
3. NEVER use an abrasive sponge or cloth on the appliance.
4. NEVER use a scouring pad on the appliance.
ENGLISH
5. NEVER leave appliance unattended while in use.
6. NEVER force Kettle in or out of the brackets as this may cause gears to become misaligned and appliance will not operate properly.
7. Unplug unit from outlet when not in use and during cleaning.
8. DO NOT operate this appliance with a damaged cord or plug, nor if the appliance ever malfunctions.
9. DO NOT clean any parts of this appliance in a dishwasher.
10. Keep out of reach of children.
11. This appliance is NOT A TOY.
12. Unsupervised young children and cognitively challenged individuals should never operate this appliance.
13. Young children should be supervised while in proximity of the appliance to ensure that they do not play with it.
IMPORTANT SAFEGUARDS
Basic safety precautions should always be followed when using electrical appliances, including the following:
1. Read all instructions before operating this appliance.
2. Keep door of Main Unit closed while operating. Do not touch Kettle while
3. To protect against electrical shock do not immerse cord, plug or
4. To avoid re or shock hazard, or damage to the unit, this unit should
5. Close supervision is necessary when any appliance is used near children.
6. Unplug from outlet when not in use, before removing parts and before cleaning.
7. DO NOT operate any appliance with a damaged cord or plug, nor if
8. The manufacturer does not recommend the use of accessory
9. DO NOT use outdoors.
10. Position the appliance as close to the outlet as possible
operating; it gets very HOT.
any part of this appliance in water or other liquids.
be plugged into a polarized 120 Volt AC outlet ONLY.
the appliance has been damaged in any manner. Return the appliance to the nearest repair shop for examination or repair.
attachments. Use of accessory attachments may cause injuries.
to prevent injury due to tripping over cord.
3
11. DO NOT leave Kettle motor running once popping has ceased.
12. Extreme caution must be used when moving this appliance.
13. DO NOT use the appliance for other than its intended use.
14. An appliance that is plugged into an outlet should not be left unattended while in operation.
15. Check Kettle for presence of foreign objects prior to use.
16. Make sure the Kettle is properly attached to brackets before operating and that the motor plug is plugged into the Kettle.
17. A short power supply cord is provided to reduce the risk resulting from becoming entangled or tripping over a long cord.
18. Longer detachable power supply cords can be used if care is exercised in their use.
19. The marked electrical rating of an extension cord should be at least as great as the electrical rating of the appliance.
20. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electrical shock, this plug is intended to t into a polarized outlet only one way.
If the plug does not t fully into the outlet, reverse the plug. If it still does not t, contact a qualied electrician. Do not attempt to modify the plug in any way.
SAVE THESE INSTRUCTIONS!
INTRODUCTION
Thank you for purchasing the OLD FASHIONED MOVIE TIME POPCORN CART! This 48" tall vendor-style popcorn cart will be the hit of every party. It yields up to ten cups of hot, fresh, kettle cooked popcorn per batch. The large, stainless steel kettle has a built-in stirring system, resulting in perfectly delicious popcorn every time. This cart has an easy-to-clean design, and a compartment in the base of the unit to store supplies. The vintage look and feel will complement any room, and its accessible height makes serving a snap. With the OLD FASHIONED MOVIE TIME POPCORN CART, popcorn never tasted so good at home!
ENGLISH
4
PARTS & ASSEMBLY
Hardware
ENGLISH
#1 Bolt (10mm) #2 Bolt (38mm) #3 Bolt (60mm) Qty. 10 Qty. 2 Qty. 2
#4 Screw (10mm) #5 Screw (15mm) #6 Flat Washer (6mm) #7 Flat Washer (8mm) Qty. 4 Qty. 2 Qty. 10 Qty. 8
#8 Locking Washer #9 Magnet #10 Nut Cap #11 Nut Qty. 4 Qty. 1 Qty. 2 Qty. 2
#12 Door Handle #13 Sleeve Barrel Qty. 1 Qty. 2
5
Parts
(G)Wheel
(A) Main Unit (B) Storage (C) Push Handle (D) Bottom Plate Compartment
(E) Wheel (2) (F) Base Support (G) Cross Bar (H1) Kernel Measuring
Qty. 2 Qty. 2 Cup (2-oz.)
ENGLISH
(H2) Oil Measuring (I) Leg (J) Popcorn Scoop (K1) Wrench Spoon (1 Tbsp.) Qty. 2
(K2) Wrench
6
Assembly of Base Support
1. Attach Push Handle (C) from inside Storage Compartment (B) using two #1 Bolts and two #6 Flat Washers. Attach two #11 Nuts to bottom.
ENGLISH
2. Attach Cross Bar (G) to Base Support (F) and secure with four #1 Bolts and four #6 Flat Washers.
3. Secure Bottom Plate (D) to Base Support (F) using four #1 Bolts and four #6 Flat Washers.
4. Attach Legs (I) to protruding ends of Base Support (F) using two #2 Bolts, two #7 Flat Washers and two #8 Locking Washers.
7
5. Assemble Base Support (F) into the bottom of the Storage Compartment (B) and secure with four #4 Screws.
Assembly of Wheels
1. Place #7 Flat Washer onto #3 Bolt and insert into pre­drilled hole on inside of Base Support (F).
2. Put #7 Flat Washer and #13 Sleeve Barrel on end of inserted #3 Bolt.
3. Attach the Wheel (E) to the #3 Bolt. Place #7 Flat Washer and #8 Locking Washer on Wheel (E). Use the end of Wrench (K2) with small notch to hold the #3 Bolt in place. While holding #3 Bolt in place, tighten the #10 Nut Cap with Wrench (K1).
4. Repeat on other side, following the directions above.
(#7) Flat
Washer
ENGLISH
(#8)
Locking
Washer
(#10)
Nut Cap
(#13)
Sleeve
Barrel
(E)
Wheel
(#3) Bolt
(#7) Flat
Washer
(F)
Base
Support
8
Assembly of Main Unit
ON / OFF / LIGHT Switch
ENGLISH
Attaching Door Handle
1. Attach #9 Magnet to transparent door of Main Unit (A).
2. Place #12 Door Handle using two #5 Screws.
3. Place Main Unit (A) onto the top of the Storage Compartment (B).
4. Ensure that the two inserting pins at the bottom of the Main Unit (A) line up correctly so that Main Unit (A) can be locked under the beam of the Storage Compartment (C).
Crank Handle
Stainless Steel Kettle
9
HOW TO OPERATE
Before rst use, clean the inside of the unit by wiping with a moist, non-abrasive sponge, towel or cloth and then wipe with a non-abrasive dry towel. Wipe down the inside of the Kettle and be sure it is properly placed in the brackets before starting.
1. First, nd a at surface near an electrical outlet before starting. Make sure your cord is away from any water source. It is acceptable to use an extension cord if needed.
2. Gather your popcorn making supplies: popcorn, seasonings, bowls or bags for holding the popcorn, cooking oil, Kernel Measuring Cup (H1) and Oil Measuring Spoon (H2). (Kernel Measuring Cup and Oil Measuring Spoon are included with your unit.)
3. Plug in the appliance while switch is ipped to OFF position.
4. Make sure Kettle is properly secured in support brackets.
5. Make sure Kettle motor is plugged in.
6. Turn appliance ON by ipping the switch on the top of the machine (see illustration above for location of switches). Allow the appliance to run 3-5 minutes to heat up Kettle.
7. Turn unit OFF.
8. Use the Oil Measuring Spoon (H2) supplied with your OLD FASHIONED MOVIE TIME POPCORN CART to add 1 tablespoon of your favorite popcorn cooking oil to the Kettle. For best popping results, it is suggested to use vegetable oil.
9. Add popcorn kernels to the Kettle using supplied Kernel Measuring Cup (H1). NOTE: If you are using pre-measured packages of corn kernels or popcorn making kits, you must still measure out the corn kernels and oil using the supplied Kernel Measuring Cup (H1) and Oil Measuring Spoon (H2). Always follow this rule: 1 Tbsp. oil + 2-oz. popcorn = 8 cups popcorn.
10. Turn the unit ON and close the door. In no time at all, you will hear the popping begin. Fresh, hot popcorn will begin to burst out of the ip lids on the Kettle - just like at the theater!
11. Use your Popcorn Scoop (J) to scoop and serve.
ENGLISH
10
HELPFUL TIPS
NEVER leave the unit unattended while operating.
SMOKING
If your OLD FASHIONED MOVIE TIME POPCORN CART begins to smoke during
ENGLISH
cooking, it may be due to grease build up. In order to reduce smoking, make sure that you clean the inside of the Kettle between uses.
POPCORN
For best results, use an all natural soft-shelled popping corn. Organic popping corn is not recommended for use in your OLD FASHIONED MOVIE TIME POPCORN CART as it has a harder husk and will result in more unpopped kernels.
CLEANING & MAINTENANCE
1. Make sure appliance is unplugged and COMPLETELY COOLED before cleaning. Unplug the outer plug to the outlet as well as the Kettle motor plug inside the Main Unit (A).
2. Use slightly damp, non-abrasive sponge, towel or cloth to wipe down the inside and outside of Main Unit (A), then wipe with a non-abrasive towel to dry.
3. Unplug Kettle motor and remove Kettle from support brackets.
4. Take Kettle out of the Main Unit (A). After removing Kettle from Main Unit (A), ll 2/3 of Kettle with hot, soapy water.
5. Let the Kettle sit for 15 – 20 minutes to cut the grease. (Time may vary – use your own judgment depending on the amount of cleaning necessary.)
6. Empty water. If necessary, use the scrubber side of a cleaning sponge to scrub inside of Kettle.
7. Rinse inside carefully and dry.
8. Wipe outside of Kettle with damp cloth and dry.
NOTE: To protect the motor plug from getting wet, never immerse the Kettle in any liquid. Never place any parts in the dishwasher. Always wash by hand.
11
