I HiP
FEATU RES
NORTON
RUGGED — For Heavy Stock
Removal
PRECISE — For Close Tolerances
and Fine Finish
Wheel
THE grinding wheel spindle unit is the heart of a precision
grinder. On its qualities depends the ability of the grinder to give
ENDURING PRECISION.
The Norton Wheel Spindle Unit is the heart of Norton
Cylindrical Grinders from 4" to 36" swing capacity. It has
time-proved its ability to deliver ENDURING PRECISION in
thousands of plants throughout the world.
Improved and refined in the new Type CTU and other
Norton Grinders, this famous Norton “
the ruggedness for heavy stock removal, and the precision
for finest finishes and closest tolerances.
It gives Norton Grinders the ENDURING PRECISION
to enable you to meet today’s—and tomorrow's
Heart
” provides
Spindle Unit
DESIGN HIGHLIGHTS
© In the Norton Wheel Spindle Unit design, a ruggedly pro
portioned spindle of toughened, wear-resistant steel runs on a
film of filtered lubricant in long, heavy, hard-bronze bearings.
These bearings provide support over practically the entire circum-
ference of the spindle.
® This Norton unit offers extreme resistance to wheel pressures,
belt pulls, and to those other factors that tend to reduce precision
and shorten life.
•
Long and continuous bearings surfaces confer extreme rigidity
and insure low unit pressure. This low unit pressure helps to
maintain adequate lubrication and sustains efficiency.
O This heavy duty bearing design, plus precision bored casings,
assures permanent alignment between wheel spindle and work
center-lines.
• Over 50% of spindle body sup
ported in tv/o super-duty size, hard
bronze bearings.
• The Norton spindle stays on its fixed
center-line—no shifting is possible.
• Spindle is rigidly supported over
practically its entire circumference.
• Bearing length over twice the diam-
eter—a very desirable feature.
• Bearings automatically flooded
by filtered lubricant.
•
Heavy-duty end thrust bearing at .
center of spindle is flood lubricated.
• Self-contained lubricating unit
within wheel spindle housing delivers
film of filtered lubricant between
spindle and bearings.
__
RUGGED—Hogging stock from
a Meehanife casting
• Automatic lubricant flow clearly
visible through bull’s-eyes—an important
safety feature.
• Extremely low unit pressure due
to long and continuous bearing sur
faces.
• Wheel speed changes possible
out readjustment of bearings.
• Ruggedly proportioned spindle is
toughened to resist wear.
• An unmatched service record
many thousands in use. Less than 7%
replacement bearings sold.
with
<
—
i
mm
Page 3
OERE
Cylindrical Grinding Machines which
have the famous Norton Wheel Spindle
Unit. They are indicative of the wide
are just a few of the Norton
variety of grinding operations which
are being performed with the advan
tages of this time-proven Norton unit.
No. 2 CAM-O-MATIC* Grinder
10' Type CD Grinder
J. F. OWENS MACHINERY COMPANY
1810 Erie Boulevard East
NORTON
SYRACUSE 1, NEW YORK
