Page 2
r
y . ..
l
N-5267
Right front view showing Center Drive Arrangement for Grinding Rotor Shafts.
Features
This machine is adaptable to many multiple wheel grinding operations, having independently
controlled right-hand and left-hand wheel units. When the machine is set up with a single wheel,
or two closely spaced narrow wheels, each wheel unit is our standard 10" Type C arrangement.
When set up with two widely spaced wheels, such as for bearings on camshafts, each unit has an
extended spindle which carries the larger outer spindle bearing inside the wide wheel sleeve.
This arrangement prevents excessive wear on the front bearing.
The footstock when opened, automatically retracts the wheels and stops
footstock center leaves the work hole. This safety feature prevents removing of footstock center
from work accidentally during the grinding operation.
Wheel Slide Units are adjustable laterally to suit work by means of a large handwheel at each
end of the machine and are clamped into position by a heavy gib. An auxiliary wheel feed is also
provided at each end of the machine for the respective wheels. This arrangement is independent of
the push buttoii wheel feed control at the front of the machine and is provided to take care of large
adjustments of feed. The push button control of the wheel feed at the front is for small increments.
the work before the
Page 3
Detailed view of table showing gages, work loading carriages, steadyrests and diamond tool holders,
camshaft in place ready for grinding bearings.
All ways are lubricated by one shot oil system. The respective ways of base right-hand and left-
hand wheels units, have independent hand-operated oil pumps permitting selective amounts of oil
to be applied to each unit as operating conditions require.
Standard Equipment
Headstock, motor drive with carbide tipped centers IVz"
Footstock, lever type with carbide tipped center l1/?"
Steadyrests, two bearing type, with carbide tipped work shoes
One balancing type wheel sleeve for a 12" hole wheel, of suitable width for each
wheel slide
One 30" diameter grinding wheel of suitable width
One wheel guard for 30" diameter wheels, including coolant pipes
Micrometric diamond tool holders
Grinding Gages
Two work drive dogs
One Wheel spindle reciprocating attachment for each wheel slide
Electrical Control Panel complete with controls
Page 4
Optioned Equipment
Spacing Collars
Electromatic sizing gages
Extended front bearing for spindle
Specifications
Diameter of centers
Height of work center from floor
Distance between wheel center
Coolant tank capacity in U. S. gallons
Hydraulic reservoir capacity, gallons
Lubricant reservoir capacity, quarts ..
.......................
and work center Maximum, 17V£"; Minimum, 10"
Electrical Equipment
(Not included in Machine Price)
Wheel Drive: 2 - 10 h.p. to 20 h.p., 1800 r.p.m. sleeve bearing motors.
l'/z"
41"
60
40
4
Work Drive:
Pump Drive:
Net Weight — Approximate
Floor Space
Total Height from Floor
NORTON
1 - 34 h.p., 1200 r.p.m. or 34 h.p., adjustable speed 690/2760 r.p.m.
sleeve bearing motor with rheostat.
1-3 h.p., 1200 r.p.m., sleeve bearing motor.
NORTON GRINDERS
_________
COMPANY
New York — Chicago — Detroit Cleveland
ana ZLapp&rs
•
Worcester 6, Massachusetts
_______
Hartford
16,600 lbs.
8' - 10" long
5' - 5"
7 - 2%" wide
