Page 1
SMARTWATCH
NORDVÄL SW101
English
Page 2
HELLO,
Thank you for purchasing the Nordväl SW101 smartwatch.
Let’s get started!
TABLE OF CONTENTS
Declaration of Conformity
What’s in the box
Get to know your smartwatch
Apps to connect your smartwatch to
Get started with your smartwatch
Frequently asked questions
Specifications SW101
3
5
5
6
6
9
11
2
Page 3
DECLARATION OF CONFORMITY
Product information
For the following
Product: radio equipment/smartwatch
Type: SW101
Declaration and applicable standards
Hereby, TJM Supplies B.V. declares that the type of radio equipment/
smartwatch SW101 series conforms to:
Directive EMC 2014/53/EU and the RoHS directive (2011/65/EU) and
its amendment directives 2015/863/EU on the restriction of the use
of certain hazardous substances in electronic equipment.
The full text of the EU declaration of conformity can be found at the
following internet address: www.nordval.eu/declaration-of-conformity/
3
Page 4
Importer
Company: TJM Supplies B.V.
Address: Zompstraat 8
8102 HX Raalte
The Netherlands
Email: [email protected]
Phone number: +31 85-0402973
Business license number: 72016981
VAT number: NL858946439B01
Nordväl® is the registered trademark of TJM Zwerink Holding B.V.
Specifications are subject to change without notice. Copyright©2020 TJM Supplies B.V. All rights reserved.
Manufactured in China
4
Page 5
WHAT’S IN THE BOX
Please check the box for each of the following items before using
your smartwatch:
Nordväl SW101 smartwatch
USB charging cable
User guide
GET TO KNOW YOUR SMARTWATCH
1,4 inch
touch screen
Power on and
activate screen
Heart rate
sensor
Charging
contact
5
Page 6
APPS TO CONNECT YOUR SMARTWATCH TO
Android
Open the Google Play Store and
search “Da Fit” to download and
install the app. You can also scan
the QR code down below to go
straight to the right application.
iOS
Open the App Store and search
“Da Fit” to download and install
the app. You can also scan the QR
code down below to go straight
to the right application.
GET STARTED WITH YOUR SMARTWATCH
Power-on
Long press the side button for 3 seconds or plug in the charger to
charge the smartwatch prior to powering on.
6
Page 7
Connect the smartwatch to your phone
Open the Da Fit app on your smartphone and follow the next steps:
1. Click on "Add Device" (image 1).
When using an Android smartphone, you can connect the smartwatch
directly your smartphone through the Bluetooth settings.
2. Click on your device named “P8a“ in the device list scanned (image 2).
When using an iPhone, your phone will show a Bluetooth pairing request.
You can click on Bluetooth "Pairing" to confirm the Bluetooth link (image 3).
3. You are now connected and ready to use your smartwatch.
Image 1 Image 2
7
Image 3 (iOS)
Page 8
Functions
Turn on the smartwatch to open the main menu, here you will find
the following functions:
Smartwatch interface
App interface
8
Page 9
FREQUENTLY ASKED QUESTIONS
My smartwatch disconnects after a while.
If the “Da fit” app is restricted to stay active in the background, the
device may be disconnected by your phone and requires
re-connecting. The app can be configured to stay active in the
background by changing your phone’s settings of the “Da Fit” app.
I am not receiving push messages.
Allow the app to send push notifications in the app settings.
Is my smartwatch waterproof?
Yes. The smartwatch has a IP67 waterproof rating. This means that it
can withstand up to 5 seconds of immersion with a maximum
depth of up to 1 meter.
Is there a quick screen wake-up activation for my smartwatch?
Yes. There is a smart wake-up activation by wrist movement.
9
Page 10
How can I remove my smartwatch in the app?
You can easily disconnect the device by clicking “remove device” in
the app. Note for iOS users: go after removing the device from the
app to your Bluetooth settings, click on the “ⓘ” and forget the
smartwatch from your smartphone.
How long is my smartwatch covered under warranty?
We provide a 24-month warranty on all our products after purchase
(with some exceptions). Unfortunately we cannot treat product
that have become defective due to incorrect use, fall damage, water
damage, etc.
Your question not answered?
The frequently asked questions, solutions and tips are answered
above. Is your question not listed? Then go to:
www.nordval.eu/smartwatch/sw101/faq
10
Page 11
SPECIFICATIONS SW101
Product name Nordväl SW101
Size / weight 36.6x43x9.3mm / 46g
Chip processor NRF52832 QFAA
Flash memory RAM 64KB, ROM 32MB
Touchscreen 1,4 inch touchscreen, 240x240 pixels
Bluetooth Bluetooth 4.2 or higher
G-Sensor Built in - Boshi 421 sensor
Heartrate sensor Built in - Tianyi Hexin HRS3300
Battery capacity 170 mAh, Lithium polymer battery
Battery duration Use 5-7 days, standby for 20 days
Charging time / type 3 hours / clip charger
Waterproof rate IP67
App compatibility Android 5.1 or higher, iOS 8.0 or higher
App language EN, NL, DE, FR, ES, ITA, PT, KR, RU, AR, ZH
User interface language EN, DE, FR, ES, RU, JA, AR, ZH
11
