LAWN TRACTOR MOUNTING KIT INSTRUCTIONS
DEVELOPED BY NORDIC PLOW
™
ASSEMBLY
TIPS
INSTRUCTIONS FAQS & TIPS
SAFETY
Read and understand the plow instructions,
Warranty & FAQ and Tips before use.
Scan the QRC instructional videos on the rst
page or watch the videos on our website before
use: www.nordicplow.com
Always instruct other users before they use
the plow.
OPERATION
Risk of Injury:
• Never allow children to handle the plow.
• Never allow anyone to walk beside or sit on
the plow when in use.
ª Never operate the plow over 2 to 3 mph.
Keep a slow steady speed.
• If you hit an obstruction, immediately stop
the vehicle and reverse direction.
STEP 1 & 2: The side universal mounting plate (part
#77) has 4 sides with various combinations of holes to
line up with those already on the mower. In the rare
case where the holes do not match, it is okay to drill
holes in the mount plate to t your frame.
NOTE: Holes must be identical on both sides.
STEPS 3: There are many ways to attach the boot plate
(part #76) to the mount plates (part #77). The closer the
boot plates are to the machine the better.
STEP 5: A left-sided mount of the handle is shown.
Place bracket (part #75) on the other side if a right
side handle is preferred. Use the axle (part #46) as a
guide before tightening bolts to help keep the holes
on center.
STEP 6: Be sure to include the thick spacers (part #41)
onto the axle and in between the boot plate (part #76)
and the Spring Pivot Bracket (part #10).
1-888-662-7569 (PLOW)
771 W. North Avenue West Chicago, IL 60185
www.nordicplow.com
2
1/2”1/4” 3/8”
1”
2”
H-11201
X 2
22
47189
x4
7069
P-31103
X 2
1”
28
43343
x1
37
43070
x10
36
43001
X 10
38
44072
x10
1”
41 25
712-3083
x2
71
H-46521
X 2
712-3083
x2
72
803JT
x1
73
46
720116
x1
74
802UHT
x1
76
27527
x2
77
27526
x2
75
800HMB
x 1
801LHT
x1
78
804HG
x1
27528
x1
3
1
2
77
36
37
3
36
38
36
37
76
76
37
4
4
36
36
38
5
71
25
71
10
25
5
6
4141
4141
41
7” (178mm)
ASSEMBLY
TIPS
46
2.5”
6
7
70
74
22
78
73
72
74
75
22
74
69
69
22
8
I didn’t shoot this. Did you?
7
These instructions are for the Lawn Tractor Mounting Kit and are 2 of 2 packages.
The Plow and its instructions are packaged and shipped separately.
1-888-662-7569 (PLOW) | 771 W. North Avenue, West Chicago, IL 60185 | www.nordicplow.com
© October 2020
