Safety Information
• Read the following safety information carefully
before attempting to operate this device.
• Do not cover the Wireless Lanyard with clothing or
allow anything to touch the water sensors during
operation.
• Watersports are fun and challenging, but involve
inherent risks of injury or death. To increase your
enjoyment of the sport and to reduce your risks, use
common sense and utilize the following safe practices:
• Familiarize yourself with all applicable federal,
state and local laws, the risks inherent in the
sport and the proper use of the equipment.
• Know the waterways.
• Always have a person, other than the driver, as the observer.
• Skier/rider, observer, and driver must agree on hand signals.
• Never start until skier/rider signals he/she is ready. Observer and
skier/rider should maintain constant eye contact.
• Use caution and common sense.
• Only qualified personnel should perform repairs or servicing not covered in
this manual.
• The Base Station alarm is very loud. Avoid prolonged exposure to prevent
hearing damage.
• Periodically wipe the unit with a dry cloth. Do not use abrasives or solvents on
this device.
• The warnings and practices set forth above, represent some common risks
encountered by users. The code does not claim to cover all instances of risk
or danger. Please use common sense and good judgement.
• If you do not agree with the terms and/or conditions set forth in the manual,
please return the unit to the place of purchase within 10 days of purchase.
Warning:
This device is not a substitute for diligent supervision by an
observer during watersports activities. It is the responsibility of
the watercraft owner/operator to know and inform all persons riding in the vessel or using the SkierAlert® of the information presented herein. Unsafe operation will endanger you and others.
Portable
Base Station
MarineLink
®
Wireless Lanyard
-1-
Want to save yourself hours of aggravation? If so, then read this manual
entirely before attempting the installation and/or use.
Page 3
How the SkierAlert® SP Works
When powered on, the Wireless Lanyard and Base Station establish a link, that when broken, sounds an audible and visual alarm. The link can be broken by activation of the water
switch on the Wireless Lanyard or if the Lanyard is taken out of range of the Base Station
(generally 100 feet). This fail safe system ensures that anytime the Base Station and
Wireless Lanyard cannot find each other, an alarm condition is instantly signaled.
Installing the Batteries
The Base Station and Wireless Lanyard both have a battery life of 30 hours of continuous
use. This battery life is maximized by an automatic battery saver system that powers the
units off during inactivity.
• The Base Station will automatically turn off after 10 minutes if it does not detect the
Wireless Lanyard.
• The Wireless Lanyard will automatically turn off after 10 minutes if it is not submersed in
water.
Base Station
1. Using a flat head screwdriver, loosen the screw by turning coun-
terclockwise on the battery cover screw on the back of the unit.
Grasp the screw with your fingers and pull to remove the cover.
DO NOT pry the cover open with a screwdriver.
2. Install three “AAA” batteries, making certain to align them as per
the diagram inside the battery compartment.
3. Lubricate the battery cover seal with Petroleum Jelly
(Vaseline
®
) or Silicon Grease and reinstall the battery cover and
screw.
1.
IMPORTANT:
To ensure the waterproof integrity of your
SkierAlert
®
SP, lubricate the rubber seal around the
battery door on both the Base Station or Wireless
Lanyard with Petroleum Jelly (Vaseline®) or Silicon
Grease each time you change the batteries.
2.
Alignment
Diagram
Screw
-2-
IMPORTANT:
Follow the Testing Wireless Link instructions
before each use to verify that the alarm sounds
when the Wireless Lanyard is immersed in water
or taken out of range of the Base Station.
IMPORTANT:
The SkierAlert
®
SP incorporates an advanced battery
monitoring system. For safety reasons, this system
will not turn on if you install previously used batteries.
ALWA YS install new batteries, from sealed packaging, or the system will not power on.
Page 4
Wireless Lanyard
1. Loosen the finger screws on the back of the belt clip attachment by turn-
ing counterclockwise with your fingers. DO NOT remove the finger
screws from the belt clip assembly.
2. Using your thumb, pry the belt clip attachment free from the lanyard
housing (refer to illustration 2).
3. Insert a coin (a Nickel works best) into the battery cover slot on the back
of the housing and turn counterclockwise until it stops (approximately
1/4”). Leave the coin in the slot and pry the battery cover away from the
housing. DO NOT pry the cover open with a screwdriver.
4. Insert the battery “+” side up as per illustration 4.
5. Lubricate the battery cover seal with Petroleum Jelly (Vaseline
®
) or
Silicon Grease and reinstall the battery cover. Using a coin, turn the
cover clockwise until the arrows are aligned as per illustration 5.
6. Reinsert belt clip attachment (top first) into the lanyard housing, then
snap the bottom in as per illustration 6.
Installing the SkierAlert
®
SP
The SkierAlert
®
SP was designed to be portable, allowing you to take it on
any vessel without having to install the unit each time. Under some circumstance you may need to permanently affix the Base Station to the mounting location.
To Attach the Base Station
1. Locate a mounting location that is smooth (windshield, fiberglass
dashboard, etc.).
2. Thoroughly clean the location removing any surface debris
(dried salt, sand, dust, etc).
3. Dampen the suction cups with water and press down on the top of
the left suction cup as per illustration 1 to the right.
4. While holding the suction cup down as per step 3 above, turn the
locking nut clockwise until snug, as per illustration 2.
5. Repeat steps 3 and 4 on the right suction cup.
6. Wiggle the Base Station to ensure that it is securely affixed to the
mounting location. If you cannot find a secure location using the
suction cup mounts, use screws to permanently affix it to the vessel.
-3-
WARNING:
The Base Station must be securely affixed to the mounting location. If
the suction cups do not securely affix the unit to the mounting location,
you must permanently affix it by replacing the suction cups with screws.
Failure to do so may cause damage to the unit, the vessel, or injury to
the occupants of the vessel.
3.
4.
5.
6.
1
2
1.
Finger
Screws
2.
Page 5
To Attach the Wireless Lanyard
1. Turn the hand screws counterclockwise and open the belt clip
assembly as per illustration 1.
2. Insert the belt into the assembly making certain that the face of the
lanyard is pointed away from the life jacket or clothing. Tighten the
hand screws by turning clockwise.
Turning the SkierAlert
®
SP ON/OFF
For the system to work properly , both unit s must be powered on. T urn
the Wireless Lanyard on first.
Wireless Lanyard
1. To turn ON, press and HOLD the power button until the LED
begins flashing (approximately 3 seconds). Release the button.
2. To turn OFF, press and HOLD the power button until the LED
stops flashing (approximately 3 seconds). Release the button.
Base Station
1. To turn ON, press and HOLD the power button until the audible
alarm sounds (approximately 3 seconds). Release the button, the
LED will flash indicating that the unit is on.
2. To turn OFF, press and HOLD the power button until the audible
alarm sounds (approximately 3 seconds). Release the button, the
LED will no longer flash.
Setting the Base Station Audible Alarm Volume
there are three volume settings: Low, Medium, & High. Each setting
is indicated by a solid LED.
• Low - "Low Bat. Base" illuminated
• Medium - "Low Bat. Base" and Alarm illuminated
• High - all three LED’s illuminated
To Set the Volume
1. While powered ON, press and hold the Base St ation button for 2 seconds. (All the LED’s
will blink indicating that you have accessed Volume Control Setup.)
2. To adjust the volume, press and release the button. The alarm setting will sound and the
corresponding LED's will be lit. (Each press of the button sets the volume to the next
level.)
3. The Base Station will automatically return to normal operation if you do not press the but-
ton for 5 seconds.
Power Button
Power
Button
LED’s
1.
2.
IMPORTANT:
The Wireless Lanyard MUST be affixed to a life jacket or clothing belt
using the integrated belt clip assembly. • To prevent accidental loss, do
not use the unit without securely affixing it using the belt clip assembly. •
To prevent false alarms,
do not cover the Wireless Lanyard with cloth-
ing or allow anything to touch the water sensors during operation.
• If using the Lanyard for tubing or towables, mount it on the back of a life
jacket to prevent accidental activation of the water sensors.
-4-
Page 6
Battery Monitoring System
The SkierAlert
®
SP incorporates a battery monitoring system for
both the Wireless Lanyard and Base St ation. When either battery
is low, the receiver will sound an audible alarm (chirp) every 60
seconds to remind the operator to replace the battery.
• If a low battery is detected in the Base Station, the "Low Bat.
Base" LED will blink.
• If a low battery is detected in the Wireless Lanyard, the "Low
Bat. Lanyard" LED will blink and the LED on the Lanyard will
be solid.
Using the SkierAlert
®
SP
When activated, the Base Station and Wireless Lanyard establish a wireless link. The link
can be broken if the Wireless Lanyard is submerged in water, or if the Lanyard is taken out
of range of the Base Station (generally 100 feet).
When the link is broken:
• The audible alarm will sound.
• The “ALARM” LED on the Base Station will blink fast.
Testing the Wireless Link.
1. Power both the Base Station and the Wireless Lanyard ON.
2. Locate the water sensors on the Wireless Lanyard (illustration 1).
3. Place your thumb over the water sensors, making sure to cover both sensors (illus-
tration 2).
4. The alarm will sound indicating that the link is established and the system is ready for
use.
Low Bat.
Lanyard
Low Bat.
Base
IMPORTANT:
To ensure proper linking of the Base
Station and Wireless Lanyard, you
must test the link before each use.
IMPORTANT:
The alarm remains muted until the Base Station links up with
Wireless Lanyard. The MUTE is then disabled so that the
alarm will sound if the link between the Lanyard and Base
Station is broken again. Make certain that the link is established before each use by verifying that the ALARM LED is of f.
Muting the Audible Alarm
Pressing the button on the Base Station during an alarm condition will mute the audible
alarm, yet the ALARM LED will continue to blink. Pressing and releasing the button anytime during an alarm condition will toggle the mute on and off. The Mute can only be set
when there is an alarm condition.
1.
IMPORTANT:
If the “Low Bat. Base” or ”Low Bat. Lanyard” LED’s are blinking, discontinue use
immediately and refer to the “Installing the Batteries” and “Battery Monitoring
System” sections in this manual.
2.
-5-
Page 7
Troubleshooting and Frequently Asked Questions
There is Water in the Wireless Lanyard's Battery Compartment:
Under some circumstances, accidental flooding of the unit may not cause failure of the
unit. Open the battery compartment and remove the battery. If the unit was flooded with
saltwater, soak it in fresh tap water for 5 minutes with the battery compartment open.
Shake the excess water from the unit, and place it in a dry place for 24 hours.
Reinstall the battery, making sure to lubricate the battery door seal with Petroleum Jelly
(Vaseline
®
) or Silicon Grease. Test the waterproof integrity of the unit by soaking it in
fresh tap water for 5 minutes.
The Base Station’s Suction Cups Will Not Hold the Unit Securely:
Locate a mounting location that is smooth (windshield, fiberglass
dashboard, etc.). Thoroughly clean the location, removing any surface debris (dried salt, sand, dust, etc). Dampen the suction cups, and
follow the instructions in the “Installation Section” of this manual. It is
very important that the thumb nut on the suction cups is pressed firmly down while turning as per the illustration to the right. If the suc-
tion cups do not securely affix the unit to the mounting location,
you must permanently affix it by replacing the suction cups with
permanent screws.
The Low Battery LED’s Are Flashing on the Base Station:
The flashing LED’s indicate that a low battery condition is being detected. Replace the
batteries with a new set taken from a sealed package. Keep in mind that batteries may
test properly on a battery tester, but may not power the units properly because of the
load induced on them by the SkierAlert
®
SP.
I Can’t Get the System to Turn On, Even After Installing New Batteries:
The SkierAlert
®
SP incorporates an advanced battery monitoring system. For safety
reasons, this system will not turn on if you install previously used batteries. ALWAYS
install new batteries, from sealed packaging, or the system will not power on.
I’m Experiencing False Alarms:
The most likely cause of a false alarm condition is the improper placement of the
Wireless Lanyard. DO NOT place the Lanyard under clothing or anything that may
cause activation of the water sensors. If you are using the unit for tubing or on passengers of towables, keep in mind that the water sensors can be falsely activated by touching a wet surface. Always mount the Lanyard in a manner that will prevent the water
sensors from touching any surface.
How Do I Know if the System Is Functioning Properly:
To ensure proper linking of the Base Station and Wireless Lanyard, you
can test the link by turning both units on and placing your thumb over
both water sensors on the Lanyard. The Base Station should sound an
audible and visual alarm within 2 seconds.
-6-
Page 8
Made in China. Tested to comply with FCC, CE
and ROHS standards. Visit our website for compliance and warranty information. All Specifications
and Prices Subject to Change Without Notice.
NorCross Marine Products, Inc
Phone: 888-NorCross (888-667-2767)
www.norcrossmarine.com
Warning:
© 2006 NorCross Marine Products Inc., All Rights Reserved. ALL
unauthorized copying of the content of this manual without the
expressed written consent of NorCross Marine Products, Inc will be
prosecuted to the fullest extent of the law.
To be eligible for the 2 year product warranty, you must register
your product within 15 days of purchase. Please visit our
Customer Service Center on our website to register. Make a copy
of your original purchase receipt and store it in a safe place. You
will need to present it in the rare occurrence that you need to send
your product in for service.
Will the Wireless Lanyard float?
The Wireless Lanyard is "neutrally buoyant", meaning it will not sink, however it may be
hard to spot of it comes off while in use. Be sure to secure the lanyard tightly using the
hand screws.
Can I Use Multiple Wireless Lanyards at One Time?
No. When powered on, the Wireless Lanyard and Base Station establish a link, that
when broken, sounds an audible and visual alarm. If more than one Wireless Lanyard is
active, the Base Station will not detect a broken signal from a single Wireless Lanyard.
Advanced Troubleshooting
If you have questions about this product, please visit our Customer Service Center on
our website at www.norcrossmarine.com (You may also call us toll free at 888-667-
2767) where you can find information relating to:
• Warranty Details
• Warranty Registration
• Troubleshooting
• Product Knowledgebase
• Product Specifications
• Parts & Accessories
FCC Notice
This device complies with FCC Part 15 Rules and Industry Canada RSS210 Issue 2
Regulations. Operation is subject to the following tow conditions:
• this device may not cause harmful interference; and,
• this device must accept any interference received, including interference that may
cause undesired operation
Changes or modifications not expressly approved by NorCross Marine Products, Inc,
could void the user’s authority to operate the equipment.
Loading...
