Nolangroup S p A NCOM8 User Manual
EN
USER INSTRUCTIONS AND SAFETY
Firmware Version: 4.0x
Congratulations on your purchase of an N-Com product.
N-Com B5 was made using the most advanced technologies and the best materials.
Long-running tests and thorough system development have allowed the highest
audio quality to be achieved.
For additional information about B5, and to download high-definition instructions
as well as the latest Firmware version, visit the website www.n-com.it
REFERENCE STANDARDS
The products of the N-Com line are in compliance with standards as per the table
below:
The Bluetooth system complies with the main safety requirements
B5
and other applicable provisions of Directive 99/5/CE, Directive
2009/65/EC, Directive 2011/65/CE, Directive 2012/19/EU
Battery
charger
Directive 2006/95, 2004/108, 2009/65/EC, 2011/65/CE, 2012/19/EU,
2009/125/CE
Battery Directive 2006/66/CE
The Declarations of Compliance can be downloaded from the website www.ncom.it (Download section).
FccID: XXXXXX
XXXXXX
Bluetooth is a registered trademark property of Bluetooth SIG, Inc.
Contents
1. WARNINGS AND SAFETY ............................................................. 4
1.1.Road safety............................................................................. 4
1.2.Switching on the system in safe environments..................................... 4
1.3.Interferences ........................................................................... 4
1.4.Appropriate use........................................................................ 4
1.5.Qualified personnel.................................................................... 5
1.6.Accessories and batteries............................................................. 5
1.7.Disposal................................................................................. 6
2. CONTENT OF THE PACKAGING ...................................................... 6
3. INSTALLATION ......................................................................... 7
3.1.Removing the B5 system from the helmet......................................... 10
4. BASIC FUNCTIONS................................................................... 11
4.1.N-Com Wizard and N-Com App....................................................11
4.1.Pairing up with Bluetooth devices ..................................................11
5. MOBILE PHONE ...................................................................... 12
5.1.Friend Number........................................................................12
5.2.Managing two mobile phones (or Bluetooth devices)............................ 12
6. MUSIC VIA BLUETOOTH – A2DP BLUETOOTH PROTOCOLL .................... 13
7. MUSIC VIA CABLE.................................................................... 13
8. SATELLITE NAVIGATOR FOR MOTORCYCLES..................................... 13
8.1.Navigators on Smartphone (Smart Navi System) .................................14
9. FM RADIO............................................................................. 14
10. AUTO ON / OFF FUNCTION ........................................................ 14
11. RIDER-PASSENGER INTERCOM..................................................... 14
11.1.Rider-Passenger intercom pairing up............................................. 14
11.2.Rider-Passenger intercom function ............................................... 14
12. BIKE TO BIKE INTERCOM............................................................ 15
12.1.Bike-to-Bike Intercom Affiliation (Standard configuration)..................... 15
12.2.Bike to bike intercom function..................................................... 16
13. “UNIVERSAL INTERCOM” INTERCOM.............................................. 17
13.1.Pairing up the UNIVERSAL INTERCOM ...........................................17
13.2.Universal Intercom Function ....................................................... 17
14. SETTING MODE ...................................................................... 18
15. BATTERY AND RECHARGE .......................................................... 18
15.1.Low battery signal................................................................... 18
15.2.Charging the system................................................................ 18
16. SCHEMA RIASSUNTIVO COMANDI – Configurazione standard ................ 19
17. LIMITED WARRANTY ................................................................ 21
17.1.Warranty coverage.................................................................. 21
17.2.Exclusions and limitations of the coverage....................................... 21
17.3.Validity of this limited warranty.................................................... 22
17.4.Procedure for the forwarding of claims........................................... 22
17.5.Product identification............................................................... 22
18. WARRANTY REGISTRATION FORM ................................................ 23
3
1. WARNINGS AND SAFETY
Read this User Manual carefully, as well as the simple rules listed below. Failure to comply with these
rules may lead to dangerous situations.
Caution: The product cannot be used in official or non-official competitions, motordromes, circuits,
racing tracks and the like.
Caution: Installation of the N-Com B5 system results in a weight increase of approximately 107g, which is
added to the weight of the helmet and of the other accessories.
Warning: The electronic components of the N-Com system mounted inside the helmet are not
waterproof. Consequently, make sure the inside of the helmet, including the comfort padding, does
not get wet in order to avoid damage to the system. If it does, remove the N-Com system and the
helmet comfort padding and let it air dry. Remove the battery from its housing and let it dry.
1.1. Road safety
Always obey all Traffic Regulations in force. While riding the motorcycle, your hands should always be
engaged in actually riding the vehicle. Any operation to the N-Com system must be carried out with the
vehicle stopped. Specifically:
Set your cell phone on automatic answer (see the cell phone instructions to do this).
If your cell phone is not equipped with this function, first stop your vehicle in a safe area, in
compliance with Traffic Regulations and then answer the call.
Do not make any calls while riding. Stop your vehicle in a safe place in compliance with Traffic
Regulations, and then make the call.
Adjust the volume so that it does not cause a disturbance or distraction while riding and at the
same time allows you to distinctively hear background noises.
Do not operate your cell phone or other devices connected to N-Com while riding your
motorcycle.
In all cases, obey the Traffic Regulations and remember that riding the motorcycle has absolute
priority over any other manoeuvre.
1.2. Switching on the system in safe environments
When using the N-Com system, comply with all limitations and instructions related to the use of
cell phones.
Do not turn on your cell phone or the N-Com system whenever their use is forbidden or when the
devices can cause interference or dangerous situations.
Turn off while refuelling. Do not use the N-Com system in filling stations. Do not use the device
near combustible materials or chemical products.
Turn off in proximity to explosive materials.
1.3. Interferences
All phones and devices with wireless signal transmission are subject to interferences that may affect the
performance of the device connected to them. These interferences are not ascribable to a defect of the
N-Com system.
1.4. Appropriate use
Use the device only in the normal position, as described in the product documentation. Do not attempt
to disassemble, tamper with or modify any part of the N-Com system.
4
Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected
to it before you use the system on the road.
Caution: Adjusting the volume to very high levels may cause damage to your hearing.
Caution: Adjust the volume of the N-Com system (where provided) and of the audio sources connected
to it so as to avoid audio reproduction at high volumes. Constant exposure to high audio volumes
may damage your hearing.
Caution: An incorrect installation of the system in the helmet may alter the aerodynamic and safety
characteristics of the helmet itself, thus creating dangerous conditions. Install the N-Com system
according to the instructions provided in the product documentation. In case of doubt, please
contact your local N-Com dealer.
Warning: Listening to other equipment should not interfere with driving the vehicle, which must be the
top priority at all times. Carry out all operations on the electronic equipment and on the N-Com
system with the vehicle stopped, in compliance with Traffic Regulations.
Caution: The N-Com system allows reception of the FM radio signal. Any radio licence fees are to the
user’s charge.
1.5. Qualified personnel
Only qualified personnel can carry out technical assistance on this product. In case of any
malfunction, always turn to your local dealer.
The helmet is a safety device. Tampering with it and/or with the electronic system inside the
helmet, in addition to invalidating the product warranty, can also lead to dangerous situations.
1.6. Accessories and batteries
Only use the type of batteries, battery chargers and accessories approved by Nolan for the specific
model.
The use of a battery type different from the recommended one may lead to dangerous situations
and invalidate the warranty.
Contact your local dealer to see about the availability of approved accessories.
When disconnecting the power supply cable of any accessory or of the battery charger, always
grab and pull the plug not the cable.
Do not use batteries for purposes other than the prescribed ones.
Never use batteries or battery chargers that turn out to be damaged.
Do not short-circuit the battery.
Keep the battery at a temperature between 0° / +45°C (charging); -20° / +60 °C (in use).
Danger of fire or explosion: do not throw the batteries into a fire nor expose them to high
temperatures!
Do not throw out batteries together with household refuse. The batteries should be disposed of in
compliance with local regulations
Do not wear the helmet while the battery is recharging.
The helmet should never be left within the reach of unsupervised children in order to prevent
damage to their health caused by access to the batteries.
Battery Li-Po 523450P Litio 3,7V – 1000 mAh
Battery charger S-TR-009L 100/240V – 50/60 Hz 5V - 0.5 A
B5
5
1.7. Disposal
Refer to this user manual and to manuals related to other parts of the N-Com system in order to
disassemble the system from the helmet. Once the system has been disassembled, dispose of it
according to the following instructions:
The proper disposal of obsolete equipment contributes to preventing possible negative
consequences on people’s health and on the environment.
For more detailed information on the disposal of obsolete equipment, contact your municipality, a
waste disposal service or the store where the product was purchased.
The presence of a crossed-out wheelie bin indicates that in the European Union the
product is subject to separate collection at the end of its useful life.
Do not dispose of these products together with undifferentiated urban waste.
2. CONTENT OF THE PACKAGING
The N-Com B5 package contains:
N-Com B5 system
Mini USB wire Battery charger
Key Microphone foam
6
B5
3. INSTALLATION
Important: Prior to installing the N-Com system, it is recommended to write down the identification
code affixed to the product (see chapter 17.5).
You can download the installation video from www.n-com.it N-Com / Download section.
Before you install the B5 system on the helmet, make sure it turns on properly. Press the “on” key
for about 2 seconds, until the LED lights up and you hear a beep in the headset. Proceed with the
installation.
Remove the cheek padding (see helmet instructions).
Remove the helmet edge gasket using the
special tool (Fig. 1).
Remove the “N-Com” plugs found at the
back of the shell gasket and on the left side
of the helmet (Fig. 1).
Fig. 1
Completely remove the gasket as shown in
Fig. 2; by doing so you also remove the
padding.
Fig. 2
Prior to installing the N-Com system, remove any filling foam material found in the helmet.
Option 1: remove the bottom element in foam material and the filling materials in the housings of the N-
Com earpieces located in the EPS cheek pads.
Option 2: remove the left and right side filling material as well as the filling material in the housings of the
N-Com earpieces located in the EPS cheek pads.
7
Option 1
N.B.: Keep the filling material in case you wish to use the helmet without the N-Com system in the future.
Option 2
Place the system in the special housing in
the back of the helmet, pushing it all the
way into the groove (Fig. 3).
Fig. 3
Fold the antenna back inside the shell.
Fix the cable inside the helmet and make
sure the right fixing clip snaps into its
housing (Fig. 4)
Fig. 4
8
