Nokia E70 User Guide

9251117

Issue 1

DECLARATION OF CONFORMITY Hereby, NOKIA CORPORATION declares that this RM-24 product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the Declaration of Conformity can be found at http://www.nokia.com/phones/declaration_of_conformity/.

The crossed-out wheeled bin means that within the European Union the product must be taken to separate collection at the product end-of-life. This applies to your device but also to any enhancements marked with this symbol. Do not dispose of these products as unsorted municipal waste.

Copyright © 2006 Nokia. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of Nokia is prohibited. Nokia, Nokia Connecting People, Xpress-on and Pop-Port are trademarks or registered trademarks of Nokia Corporation. Other product and company names mentioned herein may be

trademarks or tradenames of their respective owners.

Nokia tune is a sound mark of Nokia Corporation.

Includes RSA BSAFE cryptographic or security protocol software from RSA Security.

Java and all Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc.

This product is licensed under the MPEG-4 Visual Patent Portfolio License (i) for personal and noncommercial use in connection with information which has been encoded in compliance with the MPEG-4 Visual Standard by a consumer engaged in a personal and noncommercial activity and (ii) for use in connection with MPEG-4 video provided by a licensed video provider. No license is granted or shall be implied for any other use. Additional information, including that related to promotional, internal, and commercial uses, may be obtained from MPEG LA, LLC. See http:// www.mpegla.com.

Nokia operates a policy of ongoing development. Nokia reserves the right to make changes and improvements to any of the products described in this document without prior notice. Under no circumstances shall Nokia be responsible for any loss of data or income or any special, incidental, consequential or indirect damages howsoever caused. The contents of this document are provided "as is". Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties

of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability or contents of this document. Nokia reserves the right to revise this document or withdraw it at any time without prior notice

The availability of particular products may vary by region. Please check with the Nokia dealer nearest to you. EXPORT CONTROLS

This device may contain commodities, technology, or software subject to export laws and regulations from the US and other countries. Diversion contrary to law is prohibited. 9251117/Issue 1

Contents

For your safety..............................................................................6

NETWORK SERVICES....................................................................................6

Enhancements, batteries, and chargers..............................................6

1. Get started.................................................................................8

Insert the SIM card and battery.............................................................8

Insert a memory card...............................................................................9

Charge the battery.....................................................................................9

Switch on your device...............................................................................9

Enter basic settings.................................................................................10

Keys and parts..........................................................................................10

Fold open................................................................................................10

Fold closed..............................................................................................11

Keyguard....................................................................................................12

Connectors.................................................................................................12

Antennas....................................................................................................12

About the display.....................................................................................13

Standby modes.........................................................................................13

Active standby mode...........................................................................13

Standby mode.......................................................................................13

Shortcuts in standby mode...............................................................13

Display indicators....................................................................................14

Volume control.........................................................................................14

Write text...................................................................................................14

Traditional text input..........................................................................14

Predictive text input............................................................................15

Copy text to the clipboard.................................................................15

Change writing language......................................................................15

Memory.......................................................................................................15

Removable memory............................................................................15

Device memory.....................................................................................15

Monitor device memory.....................................................................15

Memory card..........................................................................................16

MiniSD...................................................................................................16

Use a memory card...........................................................................16

Format a memory card....................................................................16

Memory card security.......................................................................16

Unlock a memory card.....................................................................16

CD-ROM........................................................................................................17

Transfer content between devices.....................................................17

Transfer data from another device.................................................17

Synchronize data with another device..........................................17

2. Your device..............................................................................18

Settings.......................................................................................................18

Menu............................................................................................................18

Help and tutorial......................................................................................18

Device help.............................................................................................18

Tutorial....................................................................................................18

Scroll and make selections...................................................................18

Common actions in several applications.........................................19

3. Make calls.................................................................................20

Answer a call.............................................................................................20

Options during a call...............................................................................20

Forward calls.............................................................................................20

Log................................................................................................................21

Log settings............................................................................................21

Push to talk................................................................................................21

User settings.......................................................................................21

Connection settings..........................................................................22

Push to talk calls...................................................................................22

Callback requests..................................................................................22

Contacts view.........................................................................................22

Create a channel...................................................................................22

Join a channel........................................................................................23

Push to talk log.....................................................................................23

Exit push to talk....................................................................................23

Net calls.......................................................................................................23

Preferred profile...................................................................................23

Device security .........................................................................................24

Define security settings......................................................................24

Change the restriction password....................................................24

Fixed dialing...........................................................................................24

4. Contacts....................................................................................26

Manage contact groups.........................................................................26

Manage default information................................................................26

Copy contacts between SIM and device memory..........................27

Select ringing tones for contacts........................................................27

Business cards...........................................................................................27

5. Messages..................................................................................28

Organize messages.................................................................................28

Search for messages...............................................................................28

Inbox............................................................................................................28

My folders...................................................................................................28

Draft messages.........................................................................................29

Sent messages..........................................................................................29

Outbox.........................................................................................................29

Delivery reports........................................................................................29

Messaging settings..................................................................................29

Other settings........................................................................................29

Text message center settings..............................................................30

Text messages..........................................................................................30

Write and send text messages.........................................................30

Sending options for text messages.............................................30

Reply to received text messages.....................................................30

Text messages on the SIM card........................................................30

Text message settings........................................................................31

Picture messages..................................................................................31

Forward picture messages.............................................................31

Multimedia messages.............................................................................31

Create and send multimedia messages........................................31

Create presentations...........................................................................32

Receive and reply to multimedia messages................................32

View presentations..............................................................................33

View media objects.............................................................................33

View and save multimedia attachments......................................33

Multimedia message settings..........................................................33

E-mail messages......................................................................................34

Set up your e-mail................................................................................34

Connect to mailbox..............................................................................34

View e-mail offline...............................................................................35

Read and reply to e-mail....................................................................35

Delete messages...................................................................................35

E-mail folders.........................................................................................35

Write and send e-mail........................................................................36

E-mail account settings......................................................................36

User settings.......................................................................................36

Retrieval settings..............................................................................37

Automatic retrieval settings..........................................................37

Instant messaging...................................................................................37

Connect to an IM server......................................................................37

Search IM users or IM groups............................................................37

Conversations with a single IM user...............................................38

IM groups................................................................................................38

Group conversations........................................................................38

IM group settings..............................................................................38

Group editing rights.........................................................................39

Ban from groups................................................................................39

IM contacts..............................................................................................39

Blocked contacts................................................................................39

View invitations....................................................................................40

Recorded messaging...........................................................................40

Settings....................................................................................................40

IM server settings..............................................................................40

Special messages.....................................................................................40

Send service commands.....................................................................40

6. Connectivity............................................................................42

Internet access points............................................................................42

Set up an Internet access point for data calls.............................42

C o n t e n t s

Advanced Internet access point settings for data calls............42

Set up an Internet access point for packet data (GPRS)...........43

Advanced Internet access point settings for packet data

(GPRS).......................................................................................................43

Set up an Internet access point for wireless LAN.......................43

Advanced Internet access point settings for wireless

LAN............................................................................................................44

Cable connection......................................................................................44

IP passthrough.........................................................................................44

Set up a data cable to use IP passthrough...................................44

Access point for IP passthrough......................................................44

Advanced IP passthrough access point settings........................44

Bluetooth....................................................................................................45

Start using Bluetooth..........................................................................45

Settings....................................................................................................45

Security tips............................................................................................45

Send data................................................................................................45

Bluetooth connectivity indicators...................................................46

Pair devices............................................................................................46

Authorize a device............................................................................46

Receive data...........................................................................................46

End a Bluetooth connection..............................................................46

SIM access profile.....................................................................................46

Infrared.......................................................................................................47

Data connections.....................................................................................47

Packet data.............................................................................................47

Wireless local area network (WLAN)..............................................48

Connection manager..............................................................................48

View and end active connections....................................................48

Search for wireless LAN......................................................................48

Modem........................................................................................................48

Mobile VPN ................................................................................................49

VPN management................................................................................49

Manage VPN policies............................................................................49

View the VPN log..................................................................................50

Email data roaming................................................................................50

Access point groups.............................................................................50

Configure access point groups for mail and

synchronization....................................................................................50

Take a picture...........................................................................................59

Record a video clip..................................................................................59

Insert pictures into messages.............................................................59

Insert videos into messages................................................................59

Settings.......................................................................................................59

10. Office applications..............................................................61

File manager.............................................................................................61

Manage files...........................................................................................61

Search for files.......................................................................................61

Documents.................................................................................................61

View objects in a document..............................................................61

Format documents...............................................................................62

View document structure..................................................................62

Preview the page layout....................................................................62

Find text..................................................................................................62

Table editor............................................................................................63

Sheet............................................................................................................63

Outline view...........................................................................................63

Work with worksheets.......................................................................63

Work with cells......................................................................................64

Insert functions.....................................................................................64

Web links.................................................................................................65

Create and modify charts...................................................................65

Find text..................................................................................................65

Presentation..............................................................................................65

View slide shows...............................................................................65

Show slide shows with a data projector...................................65

Work with different views.................................................................66

Layout view.........................................................................................66

Outline view........................................................................................66

Notes view...........................................................................................66

Master slide view...............................................................................66

Edit presentations................................................................................66

Edit tables...............................................................................................67

Find text in a presentation................................................................67

Screen export............................................................................................67

Show screen content...........................................................................68

Print.............................................................................................................68

7. Web...........................................................................................51

Access points.............................................................................................51

Browse the Web.......................................................................................51

Bookmarks.................................................................................................51

Download items.......................................................................................52

End a connection.....................................................................................52

Clear the cache......................................................................................52

News feeds and blogs............................................................................52

Web settings.............................................................................................52

Services.......................................................................................................53

8. Media applications................................................................54

Gallery..........................................................................................................54

Images.....................................................................................................54

Manage image files..........................................................................54

Organizing images............................................................................55

RealPlayer .................................................................................................55

Play video clips and stream links....................................................55

Send audio files and video clips......................................................55

Receive videos.......................................................................................55

View information about a media clip............................................56

Settings....................................................................................................56

Video settings.....................................................................................56

Connection settings..........................................................................56

Proxy settings.....................................................................................56

Network settings...............................................................................56

Advanced network settings...........................................................56

Music player...............................................................................................56

Listen to music......................................................................................56

Adjust music volume...........................................................................57

Track lists................................................................................................57

Equalizer..................................................................................................57

Voice recorder...........................................................................................57

Play a voice recording.........................................................................58

Flash player................................................................................................58

9. Camera......................................................................................59

11. Settings..................................................................................69

Phone settings..........................................................................................69

General settings....................................................................................69

Standby mode settings.......................................................................69

Display settings.....................................................................................69

Call settings...............................................................................................69

Connection settings................................................................................70

Access points..........................................................................................70

Access point groups.............................................................................70

Packet data.............................................................................................70

Packet data settings.........................................................................70

Net call settings....................................................................................71

Session initiation protocol (SIP) settings......................................71

Edit SIP profiles..................................................................................71

Edit SIP proxy servers.......................................................................71

Edit registration servers..................................................................71

Data call settings..................................................................................72

VPN............................................................................................................72

VPN access points..............................................................................72

VPN access point settings...............................................................72

Wireless LAN...........................................................................................72

Advanced WLAN settings................................................................72

Security settings for wireless LAN access points.....................72

Configurations.......................................................................................74

Date and time settings...........................................................................74

Security settings.......................................................................................74

Network settings.....................................................................................74

Enhancement settings...........................................................................74

Text phone settings.............................................................................74

12. Organiser...............................................................................75

Calendar......................................................................................................75

Create calendar entries.......................................................................75

To-do........................................................................................................75

Calendar settings..................................................................................75

Calendar views......................................................................................76

Send calendar entries.........................................................................76

C o n t e n t s

Add a received calendar entry to your calendar.........................76

Notes............................................................................................................76

Calculator....................................................................................................76

Converter....................................................................................................77

Convert measurements......................................................................77

Set base currency and exchange rate............................................77

Voice mailbox............................................................................................77

Clock.............................................................................................................77

Clock settings.........................................................................................77

Add and delete cities...........................................................................78

13. Tools.......................................................................................79

Positioning.................................................................................................79

Navigator....................................................................................................79

Navigation view....................................................................................79

Position view.........................................................................................79

Trip distance view................................................................................80

Manage waypoints...............................................................................80

Navigator settings................................................................................80

Landmarks.................................................................................................80

Landmark categories...........................................................................80

Edit landmark categories................................................................81

Edit landmarks......................................................................................81

Receive landmarks...............................................................................81

Voice commands......................................................................................81

Use a voice command to make a call.............................................81

Use a voice command to launch an application.........................82

Use voice commands for profiles....................................................82

Voice command settings....................................................................82

Voice aid.....................................................................................................82

Sett. wizard................................................................................................82

E-mail.......................................................................................................82

Push to talk.............................................................................................83

Operator..................................................................................................83

Application manager..............................................................................83

Install applications and software....................................................83

View and remove software...............................................................83

View the installation log....................................................................83

Settings....................................................................................................84

Specify Java application security settings....................................84

Certificate manager.............................................................................84

Manage personal certificates........................................................84

Manage authority certificates.......................................................85

View certificate details....................................................................85

Certificate security settings............................................................85

Nokia Catalogs..........................................................................................85

Open a catalog.......................................................................................85

Open a folder.........................................................................................85

Catalogs settings..................................................................................86

Operating environment.........................................................................95

Medical devices.........................................................................................95

Pacemakers............................................................................................95

Hearing aids...........................................................................................95

Vehicles.......................................................................................................95

Potentially explosive environments..................................................95

Emergency calls........................................................................................96

CERTIFICATION INFORMATION(SAR).....................................................96

THIS MOBILE DEVICE MEETS GUIDELINES FOR EXPOSURE TO

RADIO WAVES.........................................................................................96

Technical information..............................................................97

Index..............................................................................................98

14. Device manager..................................................................87

Server profile settings............................................................................87

Remote configuration network service............................................87

Remote configuration settings........................................................87

Create a configuration profile..........................................................87

Data synchronization.............................................................................88

Create a synchronization profile......................................................88

Synchronization profiles....................................................................88

Synchronization connection settings............................................88

Define synchronization settings for Contacts..............................88

Define synchronization settings for Calendar.............................89

Define synchronization settings for Notes...................................89

15. Personalization...................................................................90

Profiles........................................................................................................90

Select ringing tones.............................................................................90

Change enhancement settings........................................................90

Themes........................................................................................................90

16. Nokia original enhancements........................................92

Enhancements..........................................................................................92

17. Shortcuts...............................................................................93

Care and maintenance.............................................................94

Additional safety information...............................................95

For your safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read the complete user guide for further information.

SWITCH ON SAFELY

Do not switch the device on when wireless phone use is prohibited or when it may cause interference or danger.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect performance.

SWITCH OFF IN HOSPITALS

Follow any restrictions. Switch the device off near medical equipment.

SWITCH OFF IN AIRCRAFT

Follow any restrictions. Wireless devices can cause interference in aircraft.

SWITCH OFF WHEN REFUELLING

Do not use the device at a refueling point. Do not use near fuel or chemicals.

SWITCH OFF NEAR BLASTING

Follow any restrictions. Do not use the device where blasting is in progress.

USE SENSIBLY

Use only in the normal position as explained in the product documentation. Do not touch the antennas unnecessarily.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

ENHANCEMENTS AND BATTERIES

Use only approved enhancements and batteries. Do not connect incompatible products.

WATER-RESISTANCE

Your device is not water-resistant. Keep it dry.

BACK-UP COPIES

Remember to make back-up copies or keep a written record of all important information.

CONNECTING TO OTHER DEVICES

When connecting to any other device, read its user guide for detailed safety instructions. Do not connect incompatible products.

EMERGENCY CALLS

Ensure the phone function of the device is switched on and in service. Press the end key as many times as needed to clear the display and return to the standby mode. Enter the emergency number, then press the call key. Give your location. Do not end the call until given permission to do so.

NETWORK SERVICES

To use the phone you must have service from a wireless service provider. Many of the features in this device depend on features in the wireless network to function. These network services may not be available on all networks or you may have to make specific arrangements with your service provider before you can utilize network services. Your service provider may need to give you additional instructions for their use and explain what charges will apply. Some networks may have limitations that affect how you can use network services. For instance, some networks may not support all language-dependent characters and services.

Your service provider may have requested that certain features be disabled or not activated in your device. If so, they will not appear on your device menu. Your device may also have been specially configured. This configuration may include changes in menu names, menu order and icons. Contact your service provider for more information.

Enhancements, batteries, and chargers

Warning: Use only batteries, chargers, and enhancements approved by Nokia for use with this particular model. The use of any other types may invalidate any approval or warranty, and may be dangerous.

F o r y o u r s a f e t y

For availability of approved enhancements, please check with your dealer. When you disconnect the power cord of any enhancement, grasp and pull the plug, not the cord.

Your device and its enhancements may contain small parts. Keep them out of reach of small children.

1. Get started

Note: Your service provider may have requested that certain features be disabled or not activated in your device. If so, they do not appear on your device menu. Your device may also have been specially configured for your network provider. This configuration may include changes in menu names, menu order and icons. Contact your service provider for more information. Some models of this device may not be equipped with a camera. If your device has no camera,

some of the applications and features described in this guide will not be available. Model number: Nokia E70-2. Hereinafter referred to as Nokia E70.

Insert the SIM card and battery

Keep all SIM cards out of the reach of small children. For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

1. Always switch the device off, and disconnect the charger before removing the battery.

With the back of the device facing you, press the cover release button (1), and slide the back cover in the direction of the arrow (2).

2. If the battery is installed, lift the battery from the battery compartment in the direction of the arrow to remove it .

3. To release the SIM card holder, slide it in the direction of the arrow (1), and lift it (2). Insert the SIM card into the SIM card

slot (3). Ensure that the beveled corner of the SIM card is pointing up and the contact area on the card is facing the device. Lower the

SIM card holder (4), and slide it until it locks into place (5).

4. To insert the battery, align the contacts of the battery with the corresponding connectors on the battery compartment, insert

in the direction of the arrow, and gently click the battery into place.

G e t s t a r t e d

5. Insert the locking catches of the back cover into the corresponding slots (1), and slide the cover in the direction of the arrow

(2).

Insert a memory card

If you have a memory card, follow the instructions to insert it.

See "Memory," p. 15.

1. Remove the battery cover.

2. Insert the memory card fully into the memory card slot. Ensure that the beveled corner of the memory card is pointing

towards the device and the contact area is facing down.

3. Replace the battery cover.

4. To remove the memory card, press the power key, and select Remove mem. card. Remove the battery cover, and push the

memory card into the device to activate the release mechanism. Then, gently pull the card out of your device.

Important: Do not remove the memory card in the middle of an operation when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

Charge the battery

1. Connect the charger to a wall outlet.

2. Connect the power cord to the bottom of the device. The battery indicator bar starts scrolling on the display. If the battery

is completely discharged, it may take a few minutes before the charging indicator is shown. The device can be used while charging.

3. When the battery is fully charged, the bar stops scrolling. Disconnect the charger from the device, then from the outlet. When the battery charge level is too low for operation, the device switches itself off.

Switch on your device

1. To switch the device on, press the power key.

2. If the device asks for a PIN code, lock code, or security code, enter the code, and select OK.

3. To switch the device off, press the power key.

Tip: When you switch the device on, it may recognize the SIM card provider and configure the correct text message,

multimedia message, and GPRS settings automatically. If not, contact your service provider for the correct settings, or

use the Sett. wizard application. The device can be used without the network dependent phone functions when a SIM card is not inserted, or when the Offline

profile is selected.

G e t s t a r t e d

The picture shows the location of the power key.

Enter basic settings

When you power on the device for the first time, and when you power on the device after the battery has been empty or removed for a longer period of time, your device asks for the city in which you are located, time, and date. You can change the settings later.

1. Select the city in which you are located from the list and OK. To browse for a city, start to type the name of the city, or scroll

to a city. It is important to select the correct city, because scheduled calendar entries that you create can change if the new city is located on a different time zone.

2. Set the time, and select OK.

3. Set the date, and select OK. You can use your device with the fold closed or open. To open the fold, lift the keypad into the direction of the arrow (1). When you open the fold, you can use the full-size keyboard

(2).

The device changes the orientation of the display to portrait or landscape, depending on whether you use the device with the fold open or closed.

Keys and parts

Fold open

1 — Keypad light key. Press the key to illuminate your keypad for a period of time. 2 — Power key 3 — Selection keys 4 — Internet key. Press and hold the key in the standby mode to browse the Web. 5 — Clear (backspace) key

G e t s t a r t e d

6 — Chr key. Press the Chr key to open a character table where you can select special characters. You can also press the Chr key with specific letters, like a or o, to create special characters for those letters.

7 — Menu key. Press the Menu key to access the applications installed in your device. With a long keypress, you can see a list of the active applications and switch between them. In this user guide, "select Menu" refers to pressing this key.

8 — Shift key. Press Shift+character key to produce uppercase letters. 9 — Space bar 10 — Call key 11 — Light sensor and earpiece 12 — Joystick. Press the joystick to enter a selection. Use the joystick to scroll left, right, up, down, or to move around on the

screen. 13 — End key. Press the end key to reject a call, end active calls and held calls, close applications, and with a long keypress, end

data connections (GPRS, data call). 14 — Space bar 15 — Shift key. Press shift and character key to produce uppercase letters. 16 — Ctrl key 17 — Enter key

Tip: Press the clear (backspace) key to delete items such as calendar entries and messages. Press the clear (backspace)

key to delete characters on the left side of the cursor, or shift+clear (backspace) key to delete characters on the right

side of the cursor. The display changes from portrait to landscape when you open the fold. The application that was active the last time the device

was used is shown on the display. When you close the fold, the display changes from landscape to portrait.

Fold closed

1 — Power key 2 — Loudspeaker 3 — Infrared port 4 — Left selection key, joystick, and right selection key. Press either selection key to perform the function shown above it on

the display. Press the joystick to enter a selection or access most commonly used functions in different applications. Use the joystick to scroll left, right, up, down, or to move around on the screen. During a call, scroll left or right with the joystick to change volume.

5 — End key 6 — Clear key 7 — Menu key. Press the Menu key to access the menu. In this User Guide, "select Menu" refers to pressing this key. 8 — Internet key. Press and hold the key in the standby mode to browse the Web. 9 — Microphone. Do not cover the microphone with your hand during phone calls. 10 — Pop-Port™ connector for the USB data cable, headset, and loopset 11 — Charger connector 12 — Edit key. There is no edit key on the fold open keyboard. 13 — Call key

G e t s t a r t e d

14 — Voice key/push to talk (PTT) key. 15 — Display 16 — Earpiece 17 — Light sensor

Keyguard

When the keypad lock is on, calls may be possible to the official emergency number programmed into your device. Use keyguard to prevent the keys on the device from being accidentally pressed.

To lock the keypad in the standby mode, press the left selection key and *. To unlock, press the left selection key and * again.

Tip: To lock the keypad in the Menu or in an open application, press the power key briefly, and

select Lock keypad. To unlock, press the left selection key and *. You can also unlock the device by

opening the fold. You can also lock the device in the standby mode using your lock code. Press the power key, select Lock

phone, and enter your lock code. To unlock, press the left selection key and *. Enter your lock code, and press

the joystick.

Connectors

Warning: When you use the headset, your ability to hear outside sounds may be affected. Do not use the headset

where it can endanger your safety. Battery charger connector

Pop-Port connector for headset and other enhancements

Antennas

Your device has two internal antennas.

Note: As with any other radio transmitting device, do not touch either of the antennas unnecessarily when the device

is switched on. Contact with the antenna affects call quality and may cause the device to operate at a higher power

level than otherwise needed. Not touching the antenna area during a phone call optimises the antenna performance

and the talktime of your device.

The picture shows the normal use of the device at the ear for voice calls.

G e t s t a r t e d

About the display

A small number of missing, discolored, or bright dots may appear on the screen. This is a characteristic of this type of display. Some displays may contain pixels or dots that remain on or off. This is normal, not a fault.

Standby modes

Your device has two different standby modes: standby mode and active standby mode.

Active standby mode

After you have switched on your device and it is ready for use, but you have not entered any characters or made other selections, the device is in the active standby mode. In the active standby mode, you can view your service provider and network, different indicators such as indicators for alarms, and applications you want to access fast.

To select applications that you want to access from active standby, select Standby apps. Scroll to the different shortcut settings, and press the joystick. Scroll to the desired application, and press the joystick.

To activate standby, select Menu > Tools > Settings > Phone > Standby mode > Active standby > Off.

Tip: You can also see the messages in a messaging folder such as inbox or mailbox in the active standby mode. Select

Menu > Messag. > Options > Settings > Other and the folders in Active standby mode.

Standby mode

In the standby mode, you can see different information, such as your service provider, time, and different indicators, such as indicators for alarms.

The picture shows a the display in the standby mode.

1 — Service provider 2 — Signal strength indicator 3 — Command for left selection key 4 — Command for right selection key 5 — Battery strength indicator

Shortcuts in standby mode

In the standby mode, you can use the following shortcuts. These shortcuts are usually not available in the active standby mode, where the joystick is used for normal scrolling.

To view the most recently dialed numbers, press the call key. Scroll to a number or name, and press the call key again to call the number.

To call your voice mailbox (network service), press and hold 1. To view calendar information, scroll right. To write and send text messages, scroll left. To open the contacts list, press the joystick. To change the profile, press the power key briefly, scroll to the profile you want, and press the joystick to activate the profile. To open Services and connect to the Web, press 0. To activate the camera, scroll up with the joystick. To change these shortcuts, select Menu > Tools > Settings > Phone > Standby mode.

G e t s t a r t e d

Display indicators

The device is being used in a GSM network. The bar next to the icon indicates the signal strength of the network at your

current location. The higher the bar, the stronger the signal.

The battery charge level. The higher the bar, the stronger the charge in the battery.

You have one or more unread messages in the Inbox folder in Messag..

You have received new e-mail in the remote mailbox. You have one or more missed phone calls.

An alarm is active. You have selected the silent profile, and the device does not ring for an incoming call or message. Bluetooth is activated.

An infrared connection is active. If the indicator blinks, your device is trying to connect to the other device, or the connection

has been lost.

A GPRS or EGPRS packet data connection is available. A GPRS or EGPRS packet data connection is active. A GPRS or EGPRS packet data connection is on hold.

You have set the device to scan for wireless LANs, and a wireless LAN is available.

A wireless LAN connection is active in a network that does not have encryption.

A wireless LAN connection is active in a network that has encryption.

Your device is connected to a PC with a USB data cable.

A data call is active.

IP passthrough is active.

and Indicate the phone line that you have selected, if you have subscribed to two phone lines (network service).

All calls are forwarded to another number.

A headset is connected to the device.

The connection to a headset with Bluetooth connectivity has been lost.

A hands-free car kit is connected to the device.

A loopset is connected to the device.

A Text phone is connected to the device.

Your device is synchronizing.

You have an ongoing push to talk connection.

Volume control

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely

loud. To adjust the volume during a call, scroll left or right. To adjust the volume when using the loudspeaker, scroll left or right.

Write text

Traditional text input

is shown on the top right of the display when you are writing text using traditional text input. and indicate the selected case. indicates that the first letter of the word is written in uppercase and all the other

letters will automatically be written in lowercase. indicates number mode.

• Press a number key 1–9 repeatedly until the desired character appears. There are more characters available for a number key

than are printed on the key.

• To insert a number, press and hold the number key.

• To switch between letter and number mode, press and hold #.

G e t s t a r t e d

• If the next letter is located on the same key as the present one, wait until the cursor appears, and enter the letter.

• To erase a character, press the clear key. Press and hold the clear key to clear more than one character.

• To access the most common punctuation marks, press the 1 key. Press 1 repeatedly to reach the desired punctuation mark.

Press * to open a list of special characters. Use the joystick to move through the list, and select a character.

• To insert a space, press 0. To move the cursor to the next line, press 0 three times.

• To switch between the different character cases, press #.

Predictive text input

1. To activate predictive text input, press the edit key, and select Predictive text on. This activates predictive text input for all

editors in the device. The indicator is shown on the top right of the display when you are writing text using predictive text input.

2. To write the desired word, press 2–9. Press each key only once for one letter.

3. When you have finished writing the word and it is correct, to confirm it, scroll right, or press 0 to add a space.

If the word is not correct, press * repeatedly to view the matching words the dictionary has found one by one. If the ? character is shown after the word, the word you intended to write is not in the dictionary. To add a word to the

dictionary, select Spell, enter the word (up to 32 letters) using traditional text input, and select OK. The word is added to the dictionary. When the dictionary is full, a new word replaces the oldest added word.

4. Start writing the next word.

Tip: To set predictive text input on or off, press # twice quickly.

Write the first half of a compound word; to confirm it, scroll right. Write the last part of the compound word. To complete the compound word, press 0 to add a space.

To turn predictive text input off for all editors in the device, press the edit key, and select Predictive text > Off.

Copy text to the clipboard

1. To select letters and words, press and hold the edit key. At the same time, scroll in the direction necessary to highlight the

word, phrase, or line of text you want to copy. As the selection moves, the text is highlighted.

2. To copy the text to the clipboard, while still holding the edit key, select Copy. To insert the text into a document, press and

hold the edit key, and select Paste.

Change writing language

If you are writing text, for example a note or a message, you can change the writing language. When you are writing and press a key several times to reach a specific character, changing the writing language gives you access to a different characters.

For example, if you are writing text using a non-Latin alphabet and want to write Latin characters for Web addresses, select

Options > Writing language and the writing language to have access to a language that uses Latin characters.

If you are writing with the fold open, press Shift+Chr to change the language.

Memory

There are two types of memory into which you can save data or install applications: device memory and removable memory.

Removable memory

Removable memory is data storage that is not built into your device, such as a SIM card or a memory card. A SIM card stores different information, such as information about the network operator and contacts. A memory card serves as external storage media for software applications, pictures, music, contacts, text, or any other form of electronic data. High-capacity memory cards are available.

Device memory

Memory that is built into your device is a dynamic memory pool shared by many applications. The amount of internal memory available varies but cannot be increased past the maximum factory setting. Data stored on the device, such as software applications, pictures, and music, consume on-device memory.

Monitor device memory

Select Menu > Options > Memory details.

G e t s t a r t e d

You can see how much memory is currently in use, how much free memory remains, and how much memory is consumed by each data type. For example, you can see how much memory your e-mail messages, text documents, or calendar appointments consume.

To switch between device memory and memory card statistics, select Memory details > Phone mem. or Memory details > Memory

card.

Tip: To ensure that you have adequate memory, you should regularly delete or transfer data to a memory card or PC.

Memory card

Use only compatible miniSD MultiMediaCards (MMC) with this device. Other memory cards, such as Reduced Size MultiMediaCards, do not fit in the MMC card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted.

Your Nokia device only supports the FAT16 file system for memory cards. If you use a memory card from another device or if you want to ensure compatibility of the memory card with your Nokia device, you may need to format the memory card with your Nokia device. However, all data in the memory card is permanently deleted if you format the memory card.

It is recommended to back up device memory regularly to the memory card. The information can be restored to your device later. To back up information from phone memory to a memory card, select Menu > Tools > Memory card > Options > Backup

phone mem. To restore information from the memory card to the phone memory, select Menu > Tools > Memory card > Options > Restore from card.

Do not remove a memory card when the card is being accessed. Removing the card in the middle of an operation may damage the memory card as well as the device, and data stored on the card may be corrupted.

If you cannot use a memory card in your device, you may have the wrong type of memory card, the card may not be formatted for your device, or the card has a corrupted file system.

Tip: You can install and remove a memory card without removing the battery or powering off the device.

MiniSD This device uses a mini Secure Digital (SD) card.

Check the compatibility of a miniSD with its manufacturer or provider. Use only compatible miniSD cards with this device. Other memory cards, such as MultiMediaCards (MMC) or full-size SD cards, do not fit in the miniSD card slot and are not compatible with this device. Using an incompatible memory card may damage the memory card as well as the device, and data stored on the incompatible card may be corrupted. Keep all memory cards out of the reach of small children.

Use a memory card Select Menu > Tools > Memory card.

Select Options, and select from the following:

• Remove mem. card — Eject the memory card safely.

• Backup phone mem. — Back up important information, such as your calendar entries or contacts, to your memory card.

• Restore from card — Restore the backup from the memory card to your phone.

• Format mem. card — Format a memory card for your device.

• Set password — Create a password for the memory card.

• Memory details — Monitor the memory consumption of applications and data.

Format a memory card When a memory card is formatted, all data on the card is lost permanently. Consult your retailer to find out if you must format

the memory card before you can use it. To format a memory card, select Options > Format mem. card. When formatting is complete, enter a name for the memory card.

Memory card security You can protect a memory card with a password to prevent unauthorized access. To set a password, select Options > Set

password. The password can be up to 8 characters long and is case-sensitive. The password is stored in your device and you do

not need to enter it again while you use the memory card on the same device. If you use the memory card on another device, you are asked for the password. Not all memory cards support password protection.

To remove the memory card password, select Options > Remove password. When you remove the password, the data on the memory card is not protected against unauthorized use.

Unlock a memory card To open a locked memory card, select Options > Unlock memory card. Enter the password.

G e t s t a r t e d

CD-ROM

The sales package CD-ROM is compatible with Windows 98SE, Windows ME, Windows 2000, and Windows XP. You can install Nokia PC Suite from the CD-ROM. Nokia PC Suite can be used only with Windows 2000 and Windows XP.

Transfer content between devices

You can transfer content, such as contacts, from a compatible Nokia device to your Nokia E70 using Bluetooth connectivity or infrared. The type of content that can be transferred depends on the phone model. If the other device supports synchronization, you can also synchronize data between the other device and your Nokia E70.

Transfer data from another device

Tip: If you transfer data from your previous phone, the phone may require you to insert the SIM card. Your Nokia E70

does not need a SIM card when transferring data. To start transferring data from a compatible device, select Menu > Tools > Transfer.

1. In the information view, select Continue.

2. Select Via Bluetooth. Both devices must support the selected connection type.

3. Activate Bluetooth in your other device, and select Continue in your Nokia E70 to start searching for devices with active

Bluetooth connectivity.

4. Select Stop in your Nokia E70 after it has found your other device.

5. Select your other device from the list. You are asked to enter a passcode (1 to 16 digits) on your Nokia E70. The passcode is

used only once to confirm this connection.

6. Enter the code on your Nokia E70, and select OK. Enter the passcode on your other device, and select OK. The devices are now

paired. See "Pair devices," p. 46. For some phone models, the Transfer data application is sent to your other device as a message. To install Transfer data on

your other device, open the message, and follow the instructions on the display.

7. From your Nokia E70, select the content you want to transfer from your other device, and OK. Infrared connectivity

1. In the information view, select Continue.

2. Select Via infrared. Both devices must support the selected connection type.

3. Connect the two devices. See "Infrared," p. 47.

4. From your Nokia E70, select the content you want to transfer from your other device, and OK. Content is copied from the memory of the other device to the corresponding location in your device. Copying time depends on

the amount of data to be transferred. You can also cancel and continue later. The necessary steps for data transfer may vary depending on your device, and whether you have interrupted data transfer

earlier. The items that you can transfer vary depending on the other device.

Synchronize data with another device

If you have previously transferred data to your Nokia E70, and your other device supports synchronization, you can use

Transfer to keep the data of the two devices up to date.

1. Select Phones, and press the joystick.

2. Scroll to the device from which you transferred data, and press the joystick.

3. Select Synchronise, and press the joystick. The devices start synchronizing using the same connection type that you selected

when you originally transferred data. Only the data that you originally selected for data transfer is synchronized.

To modify the data transfer and synchronization settings, select Synchronise, scroll to a device, press the joystick, and select

Edit.

2. Your device

Settings

When you switch the device on, it may recognize the SIM card provider and configure the correct text message, multimedia message, and GPRS settings automatically. You may also receive the settings as a special text message from your service provider.

The Menu is a starting point from which you can open all applications in the device or on a memory card. The Menu contains applications and folders, which are groups of similar applications. Use the joystick to scroll up and down on the screen.

Applications that you install are saved in the Installat. folder by default. To open an application, scroll to it, and press the joystick. To view the applications in a list, select Options > Change view > List. To return back to the grid view, select Options > Change

view > Grid.

To view the memory consumption of different applications and data stored on the device or memory card and to check the amount of free memory, select Options > Memory details and the memory.

To rearrange the folder, scroll to the application you want to move, and select Options > Move. A check mark is placed beside the application. Scroll to a new location, and select OK.

To move an application to a different folder, scroll to the application you want to move to another folder, and select Options >

Move to folder, the new folder, and OK.

To download applications from the Web, select Options > App. downloads. To create a new folder, select Options > New folder. You cannot create folders inside folders. To rename a new folder, select Options > Rename.

Tip: To switch between several open applications, press and hold the menu key. The application-switching window

opens and displays the open applications. Scroll to an application, and press the joystick to switch to it.

Help and tutorial

You can find answers to your questions while using the device even with no user guide present, because your device includes both a task-specific help and a tutorial.

Tip: Task-specific means you can access instructions from Options lists.

Device help

You can access the device help from an open application or from the Menu. When you have an application open, select

Options > Help to read instructions for the current view.

To open help from Menu, select Help > Help. In Help, you can select categories for which you want to see instructions. Scroll to a category, such as Messaging, and press the joystick to see what instructions (help topics) are available. While you are reading the topic, scroll left or right to see the other topics in that category.

When you are reading the instructions, press and hold the menu key to switch between help and the application that is open in the background.

Tutorial

The tutorial provides you information about your device and shows you how to use it. To access the tutorial in the menu, select Menu > Help, open Tutorial and the section you want to view.

Scroll and make selections

Use the joystick to move and make selections. With the joystick, you can move up, down, left and right in the Menu or in different applications or lists. You can also press the joystick to open applications, files, or edit settings.

To select text, press and hold the edit key, and scroll left or right until you have selected the text. To select different items, such as messages, files, or contacts, scroll up, down, left or right to highlight the item you want to

select. Select Options > Mark/Unmark > Mark to select one item or Options > Mark/Unmark > Mark all to select all items.

Tip: To select almost all items, first select Options > Mark/Unmark > Mark all, then select the items you do not want,

and Options > Mark/Unmark > Unmark.

Y o u r d e v i c e

To select an object (for example, an attachment in a document) scroll to the object so that square markers appear on each side of the object.

Common actions in several applications

You can find the following actions in several applications: To switch between open applications, press and hold the menu key to see a list of open applications. Select an application. To change the profile or switch off or lock the device, press the power key briefly. To save a file, select Options > Save. There are different save options depending on the application you use. To send a file, select Options > Send. You can send a file in an e-mail or multimedia message, or using infrared or Bluetooth. To print to a compatible printer, select Options > Print. You can preview items that you want to print, or edit the way printed

pages look. Before you can print, you must define a compatible printer to your device. To copy, press the edit key, and select the text with the joystick. Press and hold the edit key, and select Copy. To paste, scroll to

where you want to paste the text, press and hold the edit key, and select Paste. This method may not work in applications such as Documents that have their own copy and paste commands.

To delete a file, press the clear key, or select Options > Delete. To insert characters such as question marks or parentheses to text, press *.

See "Print," p. 68.

3. Make calls

When the device is locked, calls still may be possible to the official emergency number programmed into your device. In the offline profile, you may need to enter the lock code and change the device to a calling profile before making any call,

including a call to an emergency number. To make and receive calls, the device must be switched on, must have a valid SIM card installed, and must be located in a service

area. The GPRS connection is put on hold during voice calls. Enter the phone number, including the area code, and press the call key. If you enter an incorrect character, press the clear key.

Tip: For international calls, press * twice to add the + character that replaces the international access code; and enter

the country code, area code (omit the leading 0, if necessary), and phone number. To end the call or cancel the call attempt, press the end key.

To make a call using the saved contacts, select Contacts in the standby mode. Enter the first letters of the name, scroll to the name, and press the call key. See "Contacts," p. 26.

Press the call key to view up to 20 numbers that you last called or attempted to call. Scroll to the desired number or name, and press the call key to dial the number. See "Log," p. 21.

To adjust the volume of an active call, scroll left or right with the joystick. When you open the fold of the device during a call, the loudspeaker is activated. To call your voice mailbox (network service) in the standby mode, press and hold 1, or press 1, then the call key.

Answer a call

Note: The actual invoice for calls and services from your service provider may vary, depending on network features,

rounding off for billing, taxes, and so forth. To answer a call, press the call key. To mute a ringing tone instead of answering a call, select Silence. To answer a new call during a call when Call waiting is activated, press the call key. The first call is put on hold. To end the active

call, press the end key.

Options during a call

Select Options for the following options during a call:

• Mute — Listen to the active conversation, but your voice cannot be heard by the other parties of the call.

• Unmute — Your voice can be heard again by the other parties of the call.

• Drop — Drop a party from the active call.

• End active call — End the currently active call.

• Menu — View the applications menu of your device.

• Hold — Place the active call on hold.

• Unhold — Remove the active call from hold.

• New call — Place a new call while on a call, if conference calling (network service) is available.

• Answer — Answer an incoming call while on a call, if Call waiting is activated.

• Reject — Reject an incoming call while on a call, if Call waiting is activated.

• Lock keypad — Lock the device keypad while on a call.

• Conference — Merge an active and a held call into a conference call (network service).

• Private — Converse privately with a selected participant during a conference call (network service).

• Swap — Alternate between an active and a held call (network service).

• Send DTMF — Send touch tone strings (for example, passwords). Enter the string or search for it in Contacts, and select

DTMF.

• Transfer — Connect the held call to the active call and disconnect yourself from the call (network service). The available options may vary.

Forward calls

Select Menu > Tools > Settings > Call divert. Forward incoming calls to your voice mailbox or to another phone number. For details, contact your service provider.

1. Select a call type from the following:

• Voice calls — Incoming voice calls.

• Data calls — Incoming data calls.

M a k e c a l l s

2. Select one of the following call forwarding options:

• All voice calls, or All data calls. — Forward all incoming voice or data calls.

• If busy — Forward incoming calls when you have an active call.

• If not answered — Forward incoming calls after your device rings for a specified period of time. Define the time you let

the device ring before forwarding the call in the Delay time: field.

• If out of reach — Forward calls when the device is switched off or out of network coverage.

• If not available — Activate the last three settings at the same time. This option forwards calls if your device is busy, not

answered, or out of reach.

3. Select Activate. To check the current forwarding status, scroll to the forwarding option, and select Options > Check status. To stop forwarding voice calls, scroll to the forwarding option, and select Options > Cancel.

Call restriction and call forwarding cannot be active at the same time.

Log

Select Menu > Log. In the Log, you can view information about the communication history of the device.

To view the logs for recent voice calls, their approximate duration, and packed data connections, select Recent calls, Call

duration, or Packet data.

To sort the events by type or direction, scroll right to open the general log, and select Options > Filter. Scroll to a filter type, and press the joystick. Select the type or direction, and press the joystick.

To set the time how long all communication events are held in the log, select Options > Settings > Log duration, an option, and

OK.

To clear missed and received calls and dialed numbers, select Recent calls > Options > Clear recent calls. To reply to a caller with a message, select Recent calls > Missed calls > Options > Create message. You can send text messages

and multimedia messages. To add the caller or the sender of a message to Contacts, select the caller or sender of a message and Recent calls > Missed

calls > Options > Add to Contacts.

To view the amount of data sent or received using GPRS, select Packet data. To clear the GPRS counters, select Options > Clear counters. Enter your lock code, and select OK.

Log settings

To set the time for keeping all communication events in the Log, select Options > Settings > Log duration, an option from the list, and OK.

To see the call duration during the call, select Options > Settings > Show call duration > Yes.

Push to talk

Select Menu > Connect. > PTT. Push to talk (PTT) (network service) provides direct voice communication connected with the push of a key. With push to talk,

you can use your device as you would use a walkie-talkie. You can use push to talk to have a conversation with one person or with a group of people, or to join a channel. A channel is

like a chat room: you can call the channel to see if anyone is online. The channel call does not alert the other participants; the participants just join the channel and start speaking with each other.

In push to talk communication, one person talks while the other participants listen through the built-in loudspeaker. Participants take turns responding to each other. Because only one participant can talk at a time, the maximum duration of a speech turn is limited. For details of the speech turn duration for your network, contact your network operator or service provider.

Remember to hold the device in front of you during a push to talk call so you can see the display. Speak towards the microphone, and do not cover the loudspeaker with your hands.

Phone calls always take priority over push to talk. Before you can use push to talk, you must define the push to talk access point and push to talk settings. You may receive the

settings in a special text message from the service provider that offers the push to talk service. User settings

Select Options > Settings > User settings. Define the following:

M a k e c a l l s

• Incoming PTT calls — Select Notify if you want to see a notification of incoming calls. Select Auto-accept if you want push to

talk calls to be answered automatically. Select Not allowed if you want push to talk calls to be rejected automatically.

• PTT call alert tone — Select Set by profile if you want the incoming call alert setting for push to talk to follow your profile

settings. If your profile is silent, you are not available to others using push to talk, except for callback requests.

• Callback request tone — Define the ringing tone for callback requests.

• Application start-up — Select if you want to log in to the push to talk service when you switch on your device.

• Default nickname — Enter your default nickname (20 characters maximum) that is displayed to other users.

• Show my PTT address — Define if you want callers to see your push to talk address. You can let all callers see the address,

show the address only to one-to-one callers or channel participants, or hide the address from all callers.

• Show my login status — Define whether your login to the push to talk server is shown or hidden from other users. Connection settings

Select Options > Settings > Connection settings. Define the following:

• Domain — Enter the domain name obtained from your service provider.

• Access point name — Select the push to talk access point.

• Server address — Enter the IP address or domain name of the push to talk server obtained from your service provider.

• User name — Enter your user name obtained from your service provider.

• Password — Enter a password, if required, to log into the push to talk service. The password is provided by the service provider.

If you have set Application start-up on in User settings, push to talk automatically logs in to the service when started. If not, you must log in manually.

To log in to a push to talk service, select Options > Settings > Connection settings, and enter your User name, Password,

Domain, Server address, and Access point name. Select Options > Switch PTT on.

When the Ringing type setting of your device is set to Beep once or Silent, or there is an ongoing phone call, you cannot make or receive push to talk calls.

Push to talk calls

Warning: Do not hold the device near your ear when the loudspeaker is in use, because the volume may be extremely

loud. Select Options > PTT contacts.

To make a push to talk call, select one or several contacts from the list, and press the voice key. Remember to hold the device in front of you during a push to talk call so you can see the display. The display informs you when it is your turn to speak. Speak towards the microphone, and do not cover the loudspeaker with your hands. Press and hold the voice key the entire time you are talking. When you have finished talking, release the key.

To end the push to talk call, press the end key. Answer or reject a call - When you receive a push to talk call, press the call key to answer the call or the end key to dismiss the

call.

Callback requests

To send a callback request, select Options > PTT contacts, scroll to the desired contact, and select Options > Send callback

request.

To answer a callback request, select Show to open the callback request. To make a push to talk call to the sender, press the voice key.

Contacts view

To view, add, modify, delete, or call contacts, select Options > PTT contacts. A list of names from your device Contacts application is displayed with information about their login status.

To call a selected contact, select Options > Talk 1 to 1. To make a group call, select Options > Make PTT group call. To send the contact a request to call you, select Options > Send callback request.

Create a channel

A channel is like a chat room: you can call the channel to see if anyone is online. The channel call does not alert the other participants; the participants just join the channel and start speaking with each other.

To create a channel, select Options > New channel > Create new. Select Options and define the following:

M a k e c a l l s

• Channel name — Write the channel name.

• Channel privacy — Select Private or Public.

• Nickname in channel — Enter your nickname (20 characters maximum) that is displayed to other users.

• Channel thumbnail — Insert a picture that describes the channel.

To delete a channel, press the clear key. When you log in to push to talk, push to talk automatically connects to the channels that were active when the application was

last closed.

To register a channel to the push to talk service, select Options > Register. To edit the channel details, select Options > Edit.

Join a channel

To join a channel, select Options > PTT channels. Select the channel you want to talk to, and press the voice key. Remember to hold the device in front of you during a push to talk call so you can see the display. The display informs you when it is your turn to speak. Speak towards the microphone, and do not cover the loudspeaker with your hands. Press and hold the voice key the entire time you are talking. When you have finished talking, release the key.

To switch between channels during multiple calls, select Swap. The active channel is highlighted. To view the currently active participants in the channel, select Options > Active members. To invite a participant to a channel, select Options > Send invitation.

Push to talk log

To open the push to talk log, select Options > PTT log. The log shows the date, time, duration, and other details of your push to talk calls.

Tip: To initiate a one-to-one call from PTT log, select the desired log event and press the voice key.

Exit push to talk

Select Options > Exit. Select Yes to log out and close the service. Press No if you want to keep the application active on the background.

Net calls

Your device supports voice calls over the Internet (Internet calls). Your device attempts emergency calls primarily over cellular networks. If an emergency call using cellular networks is not successful, then your device attempts an emergency call through your Internet call provider. Due to the established nature of cellular telephony, you should use cellular networks for emergency calls, if possible. If you have cellular network coverage available, please make sure that your cellular phone is switched on and ready to make calls before you attempt an emergency call. The capability for an emergency call using Internet telephony depends on the availability of a WLAN network and your Internet call provider's implementation of emergency call capabilities. Contact your Internet call provider to check the Internet telephony emergency call capability.

VoIP (voice over Internet protocol) technology is a set of protocols that facilitate phone calls over an IP network, such as the Internet. VoIP phone calls can be established between computers, between mobile phones, and between a VoIP device and a traditional telephone. To make or receive a VoIP call, your device must be within WLAN coverage, for example.

Before you can make net calls, you need to create a net telephone profile. When the profile is ready, you can make a net call from all applications where you can create a regular voice call. To make a net call in standby mode to an address that does not start with a digit, press any number key, then press # for a few seconds to clear the display and to switch the device from number mode to letter mode. Write the address and press the call key. If you have the fold open, and you have created a net telephone profile, write the address and press the call key.

You must define session initiation protocols (SIP) settings in Menu > Tools > Settings > Connection > SIP settings and VoIP settings in Menu > Tools > Settings > Call and Menu > Tools > Settings > Call > Connection. Contact your service provider for more information and correct settings.

Preferred profile

Select Menu > Connect. > Internet tel. to change settings. Before you can select the default profile, you must create profiles in Menu > Tools > Settings > Connection > Internet tel.

settings.

To select the profile that is used by default when you make net calls, select Preferred profile, and press the joystick. Scroll to the desired profile, and press the joystick.

M a k e c a l l s

Only those profiles where you have selected Registration > When needed setting in Menu > Tools > Settings > Connection >

Internet tel. settings are shown in the list.

To change the registration of your net telephone profiles, scroll to the profile that you want to register or unregister, and press the joystick. Press the joystick again to select Registered or Not registered.

To save your settings, select Back.

Device security

Select Menu > Tools > Settings > Security > Phone and SIM. You can modify the security settings for the PIN code, automatic lock, and SIM card change, and change codes and passwords. Avoid using codes that are similar to emergency numbers to prevent accidental dialing of the emergency number. Codes are shown as asterisks. When you change a code, enter the current code, then the new code twice.

Define security settings

To define device and SIM card settings, select a setting and Options > Change. When calls are limited to closed user groups, calls may be possible to the official emergency number programmed into your

device. Define the following settings:

• PIN code request — Select On to request that the PIN code is entered each time the device is switched on. This setting cannot

be changed if the device is switched off. Some SIM cards do not allow turning off the PIN code request.

• PIN code — Change the PIN code. The PIN code must be 4 to 8 numbers long. The PIN code protects your SIM card against

unauthorized use and is provided with the SIM card. After three consecutive incorrect PIN code entries, the PIN code is blocked, and you need to use the PUK code to unblock it before you can use the SIM card again.

• PIN2 code — Change the PIN2 code. The PIN2 code must be 4 to 8 numbers long. The PIN2 code is required to access some

functions of the device and is provided with the SIM card. After three consecutive incorrect PIN2 code entries, the PIN2 code is blocked, and you need to use the PUK2 code to unblock it before you can use the SIM card again.

• Autolock period — Set a time-out after which the device is automatically locked and can be used only if the correct lock code

is entered. Enter a number for the time-out in minutes, or select None to turn off the autolock period. When the device is locked, you can still answer incoming calls and calls may still be possible to the official emergency number programmed into your device.

• Lock code — The new code can be 4-256 characters long. Both alphabets and digits can be used, and both uppercase and

lowercase alphabets are possible. The device notifies you if the lock code is not properly formatted. The device remembers the previously used lock codes and prevents you from using the same lock code several times.

• Lock if SIM changed — Set the device to ask for the lock code when an unknown, new SIM card is inserted into your device.

The device maintains a list of SIM cards that are recognized as the owner’s cards.

• Allow remote lock — If you set this option on, you can lock the device by sending a predefined text message from another

phone. When you set this option on, you need to enter the remote lock message and confirm the message. The message must be at least 5 characters long.

• Closed user group (network service) — Specify a group of people to whom you can call and who can call you.

• Confirm SIM services (network service) — Set the device to display confirmation messages when you are using a SIM card

service.

Change the restriction password

To change the password used for restricting voice and data calls, select Menu > Tools > Settings > Call barring > Cellular call

barring > Options > Edit barrings passw.. Enter the current code, then the new code twice. The restriction password must be

four digits long. For details, contact your service provider.

Fixed dialing

When fixed dialing is activated, calls may be possible to the official emergency number programmed into your device. Select Menu > Contacts > Options > SIM contacts > Fixed dialling contacts. With the fixed dialing service, you can restrict calls from your device to only certain phone numbers. Not all SIM cards support

the fixed dialing service. Contact your service provider for more information. Select Options, and select from the following options:

• Activ. fixed dialling — Restrict calls from your device. To cancel the service, select Deact. fixed dialling. You need your PIN2

code to activate and deactivate fixed dialing or edit your fixed dialing contacts. Contact your service provider if you do not have the code.

M a k e c a l l s

• New SIM contact — Add a phone number to the list of numbers to which calls are allowed. Enter the contact name and phone

number. To restrict calls by a country prefix, enter the country prefix in New SIM contact. All phone numbers to which calls are allowed must start with this country prefix.

• Copy to Contacts — Copy the fixed dialing contact to Contacts.

• Add from Contacts — Copy a contact from Contacts to your fixed dialing list.

Tip: To send text messages to the SIM contacts while the fixed dialing service is active, you need to add the text message

center number to the fixed dialing list. To view or edit a phone number to which calls from your device are allowed, select Options > SIM contacts > Fixed dialling

contacts.

To call the contact, press the call key. To edit the phone number, select Options > Edit. You may need your PIN2 code to edit your fixed dialing numbers. To delete the contact, press the clear key.

4. Contacts

Select Menu > Contacts. Manage all of your contact information, such as phone numbers and addresses. Add a personal ringing tone, voice tag, or a

thumbnail image to a contact. Send contact information to compatible devices or receive contact information as business cards from compatible devices, and add them to your own list of contacts.

To add a contact, select Options > New contact. Enter the contact information, and select Done. To edit information in a contact card, scroll to the contact, and select Options > Edit and from the following options:

• Add thumbnail — Add a thumbnail image is displayed when a contact calls you. The image must be previously saved to your

device or memory card.

• Remove thumbnail — Remove the image from the contact card.

• Add detail — Add fields of information to a contact card, such as Job title.

• Delete detail — Delete any details that you added to a contact card.

• Edit label — Edit the field names of the contact card.

• Writing language — Select the writing language for the contact card.

Manage contact groups

Create a contact group so that you can send text or e-mail messages to several recipients at the same time.

1. Scroll to the right, and select Options > New group.

2. Enter a name for the group or use the default name, and select OK.

3. Open the group, and select Options > Add members.

4. Scroll to each contact you want to add to the group, and press the joystick to mark it.

5. Select OK to add all marked contacts to the group.

The following options are available when you select Options in the contact groups view:

• PTT options — Make a push to talk call either to an individual or to a group, or send a callback request.

• Open — Open the contact group and view the group members.

• Create message — Send a message.

• New group — Create a new contact group.

• Delete — Delete a contact group.

• Rename — Rename the contact group.

• Ringing tone — Assign a ringing tone to a contact group.

• Contacts info — View the information for a contact group.

• Settings — Set the name display settings for contact group members.

To remove a contact from a contact group, open the contact group. Scroll to the contact you want to remove, and select

Options > Remove from group > Yes.

Tip: To check the group in which a contact belongs, select Menu > Contacts. Scroll to the contact, and select Options >

Belongs to groups.

To view or edit a contact within a contact group, open the contact group. Scroll to the contact you want to view or edit, and select Options and from the following options:

• Open — Opens the contact and displays contact information.

• Call — Select Voice call, and call the contact.

• Create message — Create and send a text message or multimedia message to the contact.

• Remove from group — Remove the contact from the contact group.

• Belongs to groups — View all contact groups that a contact belongs to.

Manage default information

Assign a default number or address to a contact so you can easily call or send a message to the default number or address, even if several numbers or addresses are saved to that contact.

To change default information for a contact, open the contact, and select Options > Defaults. Select the number or address you want to set as a default and OK.

The default number or address is underlined in the contact.

C o n t a c t s

Copy contacts between SIM and device memory

For availability and information on using SIM card services, contact your SIM card vendor. This may be the service provider, network operator, or other vendor.

To copy contacts from a SIM card to device memory, select Options > SIM contacts > SIM directory to open the SIM directory. Mark the contacts you want to copy, or select Mark all to copy all contacts. Select Options > Copy to Contacts.

To copy contacts from the device memory to a SIM card, select Options > Copy to SIM direct.. Mark the contacts you want to copy, or select Mark all to copy all contacts. Select Options > Copy to SIM direct..

Select Options > SIM contacts > SIM directory to see the names and numbers stored on the SIM card. In the SIM directory, you can add, edit, or copy numbers to Contacts, and you can make calls.

Select ringing tones for contacts

Select a ringing tone for a contact or contact group. If the caller's phone number is sent with the call and your device recognizes the number, the ringing tone plays when the contact calls you.

To select a ringing tone for a contact or contacts group, open the contact or contact group, and select Options > Ringing tone. A list of ringing tones opens. Select the ringing tone you want to use and OK.

To remove the ringing tone, select Default tone from the list of ringing tones.

Business cards

Select Menu > Contacts. You can send, receive, view, and save contact cards as business cards in vCard or Nokia Compact Business Card format. You can send business cards to compatible devices using SMS, MMS, or e-mail, or an infrared or Bluetooth connection.

To send a business card, select the contact card from the contacts list, and select Options > Send. Select Via text message, Via

multimedia, Via e-mail, Via Bluetooth, or Via infrared. Enter the phone number or address, or add a recipient from the contacts

list. Select Options > Send. If you select SMS as the sending method, contact cards are sent without images. To view a received business card, select Open from the displayed notification, or open the message from the inbox folder in

Messag..

To save a business card, select Options > Save business card when the incoming message appears on the device. To save a received business card, select Options > Save business card. To delete a received business card, select Options > Delete.

5. Messages

Select Menu > Messag.. Before sending or receiving messages, you may need to do the following:

• Insert a valid SIM card in the device and be located in a service area of the cellular network.

• Verify that the network supports the messaging features you want to use and that they are activated on your SIM card.

• Define Internet access point (IAP) settings on the device. See "Connection settings," p. 70.

• Define e-mail account settings on the device. See "E-mail account settings," p. 36.

• Define SMS settings on the device. See "Text messages," p. 30.

• Define MMS settings on the device. See "Multimedia message settings," p. 33.

The device may recognize the SIM card provider and automatically configure some of the message settings. If not, you may need to define the settings manually, or contact your service provider, network operator, or Internet service provider to configure the settings.

The Messag. application displays each type of messaging folder in a list format with the newest message displayed first in each folder.

Select one of the following:

• New message — Create and send a new text, multimedia, or e-mail message.

• Inbox — View received messages, except e-mails and cell broadcast messages.

• My folders — Create your own folders to store messages and templates.

• Mailbox — View and reply to received e-mail.

• Drafts — Store messages that have not been sent.

• Sent — Store messages that have been sent.

• Outbox — View messages waiting to be sent.

• Reports — View information about the delivery of sent messages.

Organize messages

To create a new folder to organize your messages, select My folders > Options > New folder. Enter the folder name, and select

OK.

To rename a folder, select the folder and Options > Rename folder. Enter the new folder name, and select OK. You can only rename folders that you have created.

To move a message to another folder, open the message, and select Options > Move to folder, the folder, and OK. To sort messages in a specific order, select Options > Sort by. You can sort the messages by Date, Sender, Subject, or Message

type.

To view the properties of a message, select the message and Options > Message details.

Search for messages

To search for a message, open the folder in which you want to search, select Options > Find. Enter the search term, and select

OK.

Inbox

Select Menu > Messag. > Inbox. To view a message, scroll to the message, and press the joystick. To forward a sent or received message, open the message, and select Options > Forward. It may not be possible to forward

some messages. To reply to a received message, open the message, and select Options > Reply.

My folders

To view messages saved in your own folders or to use message templates, select My folders. To view a message, scroll to it, and press the joystick. To view, edit, create, or send message templates, select Templates, and press the joystick.

Select Options and from the following:

• Create message — Write and send a message.

M e s s a g e s

• Sort by — Arrange your messages according to sender, type, or other info.

• Move to folder — Save a message in another folder. Scroll to the desired folder, and select OK.

• New folder — Create new folders.

The available options may vary. To delete a message or folder, scroll to it, and press the clear key.

Draft messages

Messages that you have created, but not yet sent, are stored in the Drafts folder. To view or edit a message, scroll to it, and press the joystick. To send the message, select Options > Send. To delete a message, scroll to it, and press the clear key.

Tip: To delete multiple messages, scroll to each message, and simultaneously press the edit key and joystick. A check

mark appears next to these messages. Once you have marked the messages, press the clear key.

Sent messages

Your last 20 sent messages are automatically saved in the Sent folder. To change the number of saved messages, select

Messag. and select Options > Settings > Other.

Select Options and select from the following:

• Create message — Write and send a message.

• Message details. — View information about the message.

• Sort by — Arrange your messages according to sender, type, or other info.

• Move to folder — Save a message in another folder. Scroll to the desired folder, and select OK.

• New folder — Create new folders.

Tip: To move multiple messages, scroll to each message, and simultaneously press the edit key and joystick to mark it. Once you have marked the desired messages, select Options > Move to folder.

The available options may vary. To delete a message, scroll to it, and press the clear key.

Outbox

Select Menu > Messag. > Outbox. To send a message from the Outbox, select the message, and Options > Send. To cancel the sending of a message in the Outbox, select the message, and Options > Defer sending.

Delivery reports

To keep track of your text and multimedia messages after sending, select Reports. You can receive or reject delivery reports in text message and multimedia message settings. Select Options > Settings > Text

msg. or Multimedia message > Receive report.

No delivery reports can be received for messages sent to e-mail addresses.

Tip: To call a message recipient, scroll to the delivery report, and press the call key.

Messaging settings

Select Options > Settings. To define or edit settings for different message types, select Text message, Multimedia message, E-mail, Service message, Cell

broadcast, or Other. See "Text messages," p. 30. See "Multimedia message settings," p. 33. See "E-mail account settings," p. 36.

Other settings

Select Menu > Messag. > Options > Settings > Other. Select from the following:

• Save sent messages — Select whether to store sent messages in the Sent folder.

M e s s a g e s

• No. of saved msgs. — Enter the number of sent messages that you want to save. When the limit is reached, the oldest message

is deleted.

• Active standby mode — Select the messaging folder (for example, your inbox or an e-mail account) that you want to see in

the active standby mode.

• Folder view — Define how you want the messages in the inbox to be shown.

• Memory in use — Select where to save your received messages. You can save messages to memory card only if a memory

card is inserted.

The settings available for editing may vary.

Text message center settings

Select Options > Settings > Text msg. > Message centres. To edit message centers, select the message center, and Options > Edit. To add new message centers, select Options > New msg. centre. To delete message centers, select the message center, and press the clear key.

Text messages

Your device supports the sending of text messages beyond the normal 160-character limit. If your message exceeds 160 characters, it will be sent as a series of two or more messages.

In the navigation bar, you can see the message length indicator counting backwards from 160. For example, 10 (2) means that you can still add 10 characters for the text to be sent as two messages.

Note that using special (Unicode) characters such as ë, â, á, ì take up more space.

Write and send text messages

Select Menu > Messag. > New message > Text message.

1. In the To field, press the joystick to select recipients from Contacts, or enter the recipients' mobile phone numbers manually.

If you enter more than one number, separate the numbers with a semicolon. To insert a semicolon, press *.

2. Enter the text of the message. To use a template, select Options > Insert > Template.

3. Select Options > Send to send the message.

Note: When sending messages, your device may display Message Sent. This is an indication that the message has been sent by your device to the message center number programmed into your device. This is not an indication that the message has been received at the intended destination. For more details about messaging services, check

with your service provider. Sending options for text messages To set sending options for the text message, select Options > Sending options.

Define the following:

• Msg. centre in use — Select a message center to send the message.

• Character encoding — Select Reduced support to use automatic character conversion to another encoding system when

available.

• Receive report — Select Yes if you want that the network sends you delivery reports on your messages (network service).

• Message validity — Select how long the message center resends your message if the first attempt fails (network service). If

the recipient cannot be reached within the validity period, the message is deleted from the message center.

• Message sent as — Convert the message to another format, such as Text, Paging, or E-mail. Change this option only if you are

sure that your message center is able to convert text messages into these other formats. Contact your network operator.

• Reply via same ctr. — Select whether you want the reply message to be sent using the same text message center number

(network service).

Reply to received text messages

To reply to a text message, open the message from the Inbox. Select Options > Reply. Enter the text of the message, and select

Options > Send.

To call the sender of a text message, open the message from the Inbox and select Options > Call.

Text messages on the SIM card

Text messages may be stored on your SIM card. Before you can view SIM messages, you must copy the messages to a folder in the device. After copying the messages to a folder, you can view them in the folder or delete them from the SIM card.

Select Options > SIM messages.

+ 179 hidden pages
