Nokia C5 04 User Guide

Nokia C5–04 User Guide

Issue 1.0

2Contents

Contents

Safety 4

Battery removing 4

Find help 5

In-device help 5
Accessibility solutions 5
Extended user guide 5
Support 5
Software updates over the air 6
Update device software using your
PC 7
Access codes 7

Get started 7

Insert the SIM card and battery 7
Insert the memory card 10
Remove the memory card 11
Charge the battery 11
Keys and parts 13
Switch the device on 14
Lock the keys and touch screen 14
Home screen 14
Access the menu 16
Touch screen actions 16
Change the ringing tone 17
Ovi by Nokia 17
About Ovi Store 17

Your device 18

Contacts bar 18
Antenna locations 18
Offline profile 18
Shortcuts 19
Sensor settings and display rotation 19
Headset 20
Attach a wrist strap 20

Make calls 20

Calls 20

Write text 21

Virtual keyboard 21
Handwriting 22
Enter text with the virtual keypad 22
Touch input settings 24

Contacts 25

Save phone numbers and mail
addresses 25
Manage names and numbers 25
Assign default numbers and
addresses 26
Ringing tones, images, and call text for
contacts 26
Copy contacts 27
SIM services 27

Messaging 28

Messaging main view 28
Write and send messages 29
Set up your e-mail 30
E-mail service 30
Mail for Exchange 30
About Ovi Contacts 31
Connect to the service 31
Start using Ovi Contacts 32

Music player 33

Play music 33
Create a playlist 34

Camera 35

Activate the camera 35
Image capture 35
Video recording 36

Gallery 36

View and organize files 36
View images and videos 37

Share online 37

About Share online 37

Contents 3

Subscribe to an online sharing
service 38
Manage your accounts 38
Create a post 38
Post files from Gallery 39

Nokia Video Center 39

View and download video clips 39
Video feeds 41
My videos 41
Transfer videos from your PC 41
Video center settings 42

Web browser 42

Browse the web 42
Add a bookmark 43

Positioning (GPS) 43

About GPS 43
About assisted GPS (A-GPS) 43
Hold your device correctly 44

Maps 44

Maps overview 44
View your location and the map 45
Map view 46
Change the look of the map 46
Download and update maps 47
About positioning methods 47
Find a location 48
View location details 48
Save or view a place or route 49
Send a place to a friend 49
Check in 50
Synchronize your Favorites 51
Get voice guidance 51
Drive to your destination 52
Navigation view 53
Get traffic and safety information 53
Walk to your destination 54
Plan a route 54

Connectivity 56

Protect the environment 56

Save energy 56
Recycle 56

Product and safety information 57

4Safety

Safety

Read these simple guidelines. Not following them may be dangerous or illegal. Read
the complete user guide for further information.

SWITCH OFF IN RESTRICTED AREAS

Switch the device off when cellular phone use is not allowed or when it may
cause interference or danger, for example, in aircraft, near medical
equipment, fuel, chemicals, or blasting areas.

ROAD SAFETY COMES FIRST

Obey all local laws. Always keep your hands free to operate the vehicle while
driving. Your first consideration while driving should be road safety.

INTERFERENCE

All wireless devices may be susceptible to interference, which could affect
performance.

QUALIFIED SERVICE

Only qualified personnel may install or repair this product.

KEEP YOUR DEVICE DRY

Your device is not water-resistant. Keep it dry.

PROTECT YOUR HEARING

Listen to a headset at a moderate level, and do not hold the device near your
ear when the loudspeaker is in use.

Battery removing

Switch the device off and disconnect the charger before removing the battery.

Find help 5

Find help

For local services and warranty information, see the separate booklet.

In-device help

Your device contains instructions to help to use the applications in your device.

To open help texts from the main menu, select Menu > Applications > Help and the
application for which you want to read instructions.

When an application is open, to access the help text for the current view, select

Options > Help.

When you are reading the instructions, to change the size of the help text, select

Options > Decrease font size or Increase font size.

You may find links to related topics at the end of the help text.
If you select an underlined word, a short explanation is displayed.

Help texts use the following indicators:

Link to a related help topic.
Link to the application being discussed.

When you are reading the instructions, to switch between help texts and the application
that is open in the background, select Options > Show open apps. and the desired
application.

Accessibility solutions

Nokia is committed to making mobile phones easy to use for all individuals, including
those with disabilities. For more information, visit the Nokia website at
www.nokiaaccessibility.com.

Extended user guide

An extended version of this user guide is available on the product support pages of the
Nokia website. Some applications or functions are explained only in the extended user
guide.

Support

When you want to learn more about how to use your product or you are unsure how
your device should function, go to www.nokia.com/support, or using a cellular phone,

6Find help

www.nokia.mobi/support. You can also select Menu > Applications > Help in your
device.

If this does not resolve your issue, do one of the following:

• Reboot your device. Switch off the device, and remove the battery. After about a
minute, replace the battery, and switch on the device.

• Restore the original factory settings.

• Update your device software.

If your issue remains unsolved, contact Nokia for repair options. Go to www.nokia.com/
repair, or in Latin America, www.nokia-latinoamerica.com/centrosdeservicio. Before
sending your device for repair, always back up the data in your device.

Software updates over the air

Select Menu > Applications > Tools > SW update.

With Software update (network service), you can check if there are updates available
for your device software or applications, and download them to your device.

After updating your device software or applications using Software update, the
instructions related to the updated applications in the user guide or the helps may no
longer be up to date.

To download the available updates, select
not want to download, select the updates from the list.

To view information on an update, select the update and

To view the status of previous updates, select

Select Options and from the following:

Update via PC — Update your device using a PC. This option replaces the Start update
option when updates are only available using the Nokia Software Updater PC
application.

View update history — View the status of previous updates.
Settings — Modify the settings, such as the default access point used for downloading

updates.
Disclaimer — View the Nokia license agreement.

. To unmark specific updates that you do

.

.

Get started 7

Update device software using your PC

You can use the Nokia Ovi Suite PC application to u pda te y our devic e so ftw are . You n eed
a compatible PC, a high-speed internet connection, and a compatible USB data cable to
connect your device to the PC.

To get more information and to download the Nokia Ovi Suite application, go to
www.ovi.com/suite.

Access codes

PIN code — Protect your device and SIM card against unauthorized use. The PIN code
(4 - 8 digits) is usually supplied with the SIM card.

PIN2 code — This code (4 - 8 digits) is supplied with some SIM cards, and is required to
access some functions in your device.

If you forget an access code, contact the network service provider whose SIM card is in
your device. After three consecutive incorrect PIN or PIN2 code entries, the code is
blocked, and you need the PUK or PUK2 code to unblock it.

PUK code and PUK2 code — These codes (8 digits) are required to change a blocked PIN
code or PIN2 code, respectively. If the codes are not supplied with the SIM card, contact
the network service provider whose SIM card is in your device.

IMEI number — This number (15 digits) is used to identify valid devices in the GSM
network. Devices that are, for example, stolen, can be blocked from accessing the
network. The IMEI number for your device can be found under the battery.

Lock code (also known as security code) — The lock code helps you to protect your device
against unauthorized use. You can create and change the code, and set the device to
request the code. Keep the new code secret and in a safe place separate from your
device. If you forget the code and your device is locked, your device will require service
and additional charges may apply. Additional charges may apply, and all the personal
data in your device may be deleted. For more information, contact a Nokia Care Point
or your device dealer.

Get started

Insert the SIM card and battery

Safe removal. Always switch the device off and disconnect the charger before removing
the battery.

Important: Do not use a mini-UICC SIM card, also known as a micro-SIM card, a

micro-SIM card with an adapter, or a SIM card that has a mini-UICC cutout (see figure)
in this device. A micro-SIM card is smaller than the standard SIM card. This device does
not support the use of micro-SIM cards and use of incompatible SIM cards may damage
the card or the device, and may corrupt data stored on the card.

8Get started

A SIM card may be already inserted in the device. If not, do the following:

1 Remove the back cover.

2 Remove the battery, if inserted.

3 Slide the SIM card holder, to unlock it.

4 Lift the SIM card holder up.

Get started 9

5 Make sure the contact area of the SIM card is facing toward the device, and slide the

SIM card into the SIM card holder.

6 Lower the SIM card holder into place. Slide the SIM card holder, to lock it.
7 Line up the battery contacts, and insert the battery.

8 To replace the cover, direct the top locking catches toward their slots, and press

down until the cover locks into place.

10 Get started

If the SIM card is not properly in place, the device can only be used in the offline profile.

Insert the memory card

Use only compatible memory cards approved by Nokia for use with this device.
Incompatible cards may damage the card and the device and corrupt data stored on the
card.

1 Remove the back cover.

2 Make sure the contact area of a compatible memory card is facing down, and insert

it into the memory card slot.

Get started 11

3 Push the card in, until you hear a click.

4 Replace the back cover.

Remove the memory card

Important: Do not remove the memory card when an application is using it.

Doing so may damage the memory card and the device, and corrupt data stored on the
card.

1 If the device is switched on, before you remove the card, press the power key, and

select Remove memory card.

2When Remove memory card? Some applications will be closed. is displayed,

select Yes.

3When Remove memory card and press 'OK' is displayed, remove the back cover

of the device, and push the card in, until you hear a click.

4 Pull out the memory card, and replace the back cover. If the device is switched on,

select OK.

Charge the battery

Your battery has been partially charged at the factory, but you may need to recharge it
before you can switch on your device for the first time. If the device indicates a low
charge, do the following:

1 Connect the charger to a wall outlet.
2 Connect the charger to the device.

12 Get started

3 When the device indicates a full charge, disconnect the charger from the device,

then from the wall outlet.

You do not need to charge the battery for a specific length of time, and you can use the
device while it is charging. If the battery is completely discharged, it may take several
minutes before the charging indicator appears on the display or before any calls can be
made.

Tip: Disconnect the charger from the wall outlet when the charger is not in use. A
charger that is connected to the outlet consumes power even when it is not connected
to the device.

USB charging

You can use USB charging when a wall outlet is not available. Data can be transferred
while charging the device. The efficiency of USB charging power varies significantly, and
it may take a long time for charging to start and the device to start functioning.

1 Use a compatible USB data cable to connect your device to a compatible USB device.

Depending on the type of the device that is used for charging, it may take a while
for charging to start.

2 If the device is switched on, select the appropriate USB mode.

Only connect your device to products that have USB-IF logo.

Keys and parts

1 Wrist strap hole
2 Nokia AV connector (3.5 mm)
3 Micro USB connector
4 Volume/Zoom key
5 Lock key
6 Earpiece
7 Touch screen
8 Call key
9 Menu key
10 End/power key
11 Camera lens
12 Loudspeaker
13 Microphone

Get started 13

14 Get started

Switch the device on

1 Press and hold the power key.
2 If the device asks for a PIN code or lock code, enter it, and select OK. To delete a

number, select

. The factory setting for the lock code is 12345.

3 Select your location. If you accidentally select the wrong location, select Back.
4 Enter the date and time. When using the 12-hour time format, to switch between

a.m. and p.m., select any number.

Lock the keys and touch screen

To lock the touch screen and the keys, press the lock key on the side of the device.

To unlock, press the lock key on the side of the device, and select the unlock icon on the
screen.

When the touch screen and keys are locked, the touch screen is switched off and the
keys are inactive.

The screen and keys may be locked automatically after a period of inactivity.
To change the settings for automatic screen and key locking, select Menu > Settings

and Phone > Phone mgmt. > Auto. keyguard > Keypad autolock period.

Home screen

The home screen is your starting point where you can collect all your important contacts
or application shortcuts.

Get started 15

Interactive display elements

To open the clock application, tap the clock (1).

To open calendar or change profiles in the home screen, tap the date or the profile name
(2).

To view or change connectivity settings (

), or to view missed events, tap the top right

corner (3).

To make a phone call, select

To open Contacts, select

(4), or, if the contacts bar is active, select Telephone.

(5), or, if the contacts bar is active, select Contacts.

To open the main menu, press the menu key (6).

Start using the contacts bar

To add a contact to the contacts bar, in the home screen, select and a contact, and
follow the displayed instructions.

Contacts need to be saved in the phone memory.

To add a new contact to your contacts list, select

> Options > New contact, and

follow the displayed instructions.
Contacts added from the contacts bar are always saved to the phone memory.

16 Get started

Change the home screen theme

To change the home screen theme or the shortcuts, select Menu > Settings and

Personal > Home screen.

Access the menu

To access the menu, press the menu key.

To open an application or folder in the menu, select the item.

Touch screen actions

Open an application or other screen element

Tap the application or element once.
To view the options available for the opened item, select Options or, if available, select

an icon from a toolbar.

Access functions quickly

Tap and hold the item. A pop-up menu with available options opens. For example, to
send an image, tap and hold the image, and from the pop-up menu, select the
appropriate option.

Tip: To see the options available for an opened item, such as an image or a video, tap
the screen.

Select

In this user documentation, opening applications or items by tapping them is called
"selecting". If you need to select several items in a sequence, the menu items to select
are separated by arrows.

For example, to select Options > Help, tap Options, and then tap Help.

Scroll

To scroll up or down in lists that have a scroll bar, drag the slider of the scroll bar.

Touch screen backlight

The touch screen backlight is turned off after a period of inactivity. To turn the screen
backlight on, tap the screen.

Get started 17

If the touch screen and keys are locked, tapping the screen does not turn the screen
backlight on.

Change the ringing tone

Select Menu > Settings and Personal > Profiles.

You can use profiles to set and customize the ringing tones, message alert tones, and
other tones for different events, environments, or caller groups.

To customize a profile, go to the profile, and select Customize.

Ovi by Nokia

With Ovi by Nokia, you can find new places and services, and stay in touch with

your friends. You can do, for example, the following:

• Download games, applications, videos, and ringing tones to your device

• Find your way with free walk and drive navigation, plan trips, and view locations

on a map

• Get a free Ovi Mail account

• Buy music

Some items are free of charge, others you may need to pay for.

The available services may also vary by country or region, and not all languages are
supported.

To access Nokia's Ovi services, go to www.ovi.com, and register your own Nokia account.

For more help and information, go to www.ovi.com.

About Ovi Store

With Ovi Store, you can download mobile games, applications, videos, pictures,
themes, and ringing tones to your device. Some items are free of charge; others you
need to pay for with your credit card or in your phone bill. The availability of payment
methods depends on your country of residence and your network service provider. Ovi
Store offers content that is compatible with your mobile device and relevant to your
tastes and location.

18 Your device

Your device

Contacts bar

To add a contact to the home screen, in the home screen, select

contact, and follow the instructions.

To communicate with a contact, select the contact and from the following:

— Call the contact.

— Send a message to the contact.

— Add a link to an Ovi contact. If you want to chat to an Ovi contact, select the

contact. The icon changes to

— Refresh the contact's web feeds.

To view past communication events with a contact, select the contact. To view the
details of a communication event, select the event.

To close the view, select Options > Exit.

Antenna locations

Avoid touching the antenna area unnecessarily while the antenna is transmitting or
receiving. Contact with antennas affects the communication quality and may cause a
higher power level during operation and may reduce the battery life.

. To start chatting, select the icon.

> Options > New

GPS antenna Bluetooth antenna

Cellular antenna

Offline profile

The offline profile lets you use the device without connecting to the wireless cellular
network. When the offline profile is active, you can use your device without a SIM card.

Your device 19

Activate the offline profile

Press the power key briefly, and select Offline.

When you activate the offline profile, the connection to the cellular network is closed.
All radio frequency signals to and from the device to the cellular network are prevented.
If you try to send messages using the cellular network, they are placed in the Outbox
folder to be sent later.

Important: In the offline profile you cannot make or receive any calls, or use

other features that require cellular network coverage. You may be able to call the official
emergency number programmed into your device. To make calls, you must first change
to another profile.

Shortcuts

To switch between open applications, press and hold the menu key.
Leaving applications running in the background increases the demand on battery power

and reduces the battery life.

To change the profile, press the power key, and select a profile.

To call your voice mailbox (network service), in the dialer, tap and hold 1.

To open a list of last dialed numbers, in the home screen, press the call key.

To use voice commands, in the home screen, press and hold the call key.

Sensor settings and display rotation

When you activate the sensors in your device, you can control certain functions by
turning the device.

Select Menu > Settings and Phone > Sensor settings.

Select from the following:

Sensors — Activate the sensors.
Turning control — Select Silencing calls and Snoozing alarms to mute calls and

snooze alarms by turning your device so that the display faces down. SelectAuto-rotate

display to rotate the display content automatically when you turn the device on its left

side or back to a vertical position. Some applications and features may not support
rotating the display content.
