Page 1
12V
3Ah
NLP9
INSANE PERFORMANCE.
LITHIUM POWERSPORT BATTERY.
2X
MORE POWER.
DYNAMIC BMS.
Equipped with an auto-enabled, advanced battery management system that
provides maximum protection, performance, and bi-directional cell equalization
for long-lasting stability. No BMS reset needed.
ACTIVE PROTECTION.
Protects against over-charge, extreme-heat, short-circuit, over-discharge,
extreme-cold, and over-current.
SHOCK ABSORBTION.
Designed with a custom rubber dampening base and
foam inserts to extend the life of the battery and keep connections secure.
10X
MORE STARTS.
5X
LONGER LIFE.
TM
no.co
Page 2
UNIVERSAL MOUNTING.
User Guide & Warranty
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT.
Failure to follow these safety instructions may result in ELECTRICAL SHOCK,
EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY
DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not
submerge in water or get wet.
Explosion. Never short-circuit the battery terminals. Do not use with an incompatible charging
device. D
o not attempt to jump start, charge, or discharge the battery if damaged or frozen.
Never charge or discharge the product outside its operating temperatures. Never over-charge or
over-discharge the battery. Never exceed the maximum charging currents of the battery. Never
incinerate.
Fire. The product is an electrical storage device that can emit heat. Do not cover product or place
objects on top of the product. Keep the product away from combustible materials.
Eye Injury.
Wear eye protection when operating product. Batteries can explode and cause flying
and contact poison control immediately.
For more information
and support visit:
DANGER
User Guide & Warranty
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT.
Failure to follow these safety instructions may result in ELECTRICAL SHOCK,
EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY
DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not
submerge in water or get wet.
Explosion. Never short-circuit the battery terminals. Do not use with an incompatible charging
device. D
o not attempt to jump start, charge, or discharge the battery if damaged or frozen.
Never charge or discharge the product outside its operating temperatures. Never over-charge or
over-discharge the battery. Never exceed the maximum charging currents of the battery. Never
incinerate.
Fire. The product is an electrical storage device that can emit heat. Do not cover product or place
objects on top of the product. Keep the product away from combustible materials.
Eye Injury.
Wear eye protection when operating product. Batteries can explode and cause flying
and contact poison control immediately.
For more information
and support visit:
DANGER
User Guide & Warranty
For more information
and support visit:
Modular spacers can be added to alter the size and allow
the battery to be safely and securely mounted. A removable
mounting block allows the battery to fit more applications.
The threaded insert enables direct-mounting for additional
simplicity and security.
Removable
Mounting Block
Threaded Insert
M6-1 Thread Size.
Hex Screw
M6 -1x20mm
FEMALE. SIDE.
T O P.
FRONT.
MULTI-CONNECTION TERMINALS.
Equipped with premium IP 66 waterproof copper PCB
plates. NLP Terminals can be mounted from the front, side,
or top, and can be removed altogether depending on the
application.
RAPID RECHARGE.
Use the Lithium mode on a Genius charger to fully
recharge an NLP battery in minutes. See Genius
models and charging times below.
COMPATABLE SIZES.
BCI SIZES
BT X7A-BS
BTX9-BS
BTR9-BS
YUASA SIZES
YTX9
YTX 7A-BS
YTX9-BS
WHAT'S IN THE BOX
3.64"
(92.5mm)
*Access ories not to scale w ith NLP 9
M6 Hex Sc rew
1mm x 8mm
M6 Hex Sc rew
1mm x 10mm
User Guide
o not attempt to jump start, charge, or discharge the battery if damaged or frozen.
Wear eye protection when operating product. Batteries can explode and cause flying
User Guide & Warranty
For more information
and support visit:
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT.
Failure to follow these safety instructions may result in ELECTRICAL SHOCK,
EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY
DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not
submerge in water or get wet.
Explosion. Never short-circuit the battery terminals. Do not use with an incompatible charging
device. D
Never charge or discharge the product outside its operating temperatures. Never over-charge or
over-discharge the battery. Never exceed the maximum charging currents of the battery. Never
incinerate.
Fire. The product is an electrical storage device that can emit heat. Do not cover product or place
objects on top of the product. Keep the product away from combustible materials.
Eye Injury.
and contact poison control immediately.
5.87"
(149 mm)
M6 Hex Sc rew
1mm x 20mm
Hex Key
ETX SIZES
ETX9
NLP9 Bat tery
12.5mm Spacer
(1) 0.5" 12.5mm Spa cer
3.43"
(87mm)
LxWxH Minimum.
5.87” x 3. 43” x 3.6 4”
(149mm x 87mm x 92 .5mm)
LxWxH Maximum.
5.87” x 3. 43” x 4.13”
(149mm x 87mm x 105mm)
RECHARGE TIME
GENIUS1
GENIUS2
GENIUS5
GENIUS10
180 Minutes
90 Minutes
36 Minutes
TECHNICAL SPECIFICATIONS
BCI SIZE:
CHEMISTRY:
NOMINAL
VOLTAGE:
AMP-HOURS:
WATT-HOURS (WH):
STARTING
CURRENT:
CHARGING
VOLTAGE (V):
CHARGING
CURRENT (A):
OPERATING
TEMPERATURE:
CHARGING
TEMPERATURE:
STORAGE
TEMPERATURE:
LITHIUM
CONTENT:
INTERNAL
BATTERY WEIGHT:
WEIGHT:
VOLUMETRICS:
Lithium Iron Phosphate (LiFePO4)
12.8
38.4
400
14.6V
9A (Max)
-20ºC to 60ºC
-10ºC to 50ºC
-20ºC to 60ºC
3.6 g
0.91 lbs (0.42 kg)
2.29 lbs (1.03 kg)
Retail Packaging:
Dimensions:
6.18” x 4.84” x 4.77”
Weight: 3.17 lbs
UPC: 0-46221-19008-3
Inner Carton:
Dimensions:
6.02” x 4. 37” x 5.04”
Weight: 2.56 lbs
N/A
9
3
Master Carton:
Dimensions:
13.50” x 6.18” x 10.63”
Weight: 15.9 3 lbs
Quantity: 6
UCC: 10046221190080
Units Per Pallet:
324 Uni ts
