12V
7.8Ah
NLP30
INSANE PERFORMANCE.
LITHIUM POWERSPORT BATTERY.
2X
MORE POWER.
DYNAMIC BMS.
Equipped with an auto-enabled, advanced battery management system that
provides maximum protection, performance, and bi-directional cell equalization
for long-lasting stability. No BMS reset needed.
ACTIVE PROTECTION.
Protects against over-charge, extreme-heat, short-circuit, over-discharge,
extreme-cold, and over-current.
SHOCK ABSORBTION.
Designed with a custom rubber dampening base and
foam inserts to extend the life of the battery and keep connections secure.
10X
MORE STARTS.
5X
LONGER LIFE.
TM
no.co
Page 2
UNIVERSAL MOUNTING.
User Guide & Warranty
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT.
Failure to follow these safety instructions may result in ELECTRICAL SHOCK,
EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY
DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not
submerge in water or get wet.
Explosion. Never short-circuit the battery terminals. Do not use with an incompatible charging
device. D
o not attempt to jump start, charge, or discharge the battery if damaged or frozen.
Never charge or discharge the product outside its operating temperatures. Never over-charge or
over-discharge the battery. Never exceed the maximum charging currents of the battery. Never
incinerate.
Fire. The product is an electrical storage device that can emit heat. Do not cover product or place
objects on top of the product. Keep the product away from combustible materials.
Eye Injury.
Wear eye protection when operating product. Batteries can explode and cause flying
and contact poison control immediately.
For more information
and support visit:
DANGER
User Guide & Warranty
For more information
and support visit:
The removable mounting block allows the battery to fit more
applications. The threaded insert enables direct-mounting for
additional simplicity and security.
Removable
Mounting Block
Threaded Insert
M10-1.5 Thread Size.
Hex Screw
M10-1.5x20mm
FEMALE. SIDE.
T O P.
FRONT.
COMPATABLE SIZES.
BCI SIZES
BTX30L-BS
BTX30L
WHAT'S IN THE BOX
6.89"
(175mm)
*Access ories not to scale w ith NLP 30
M6 Hex Sc rew
1mm x 8mm
M6 Hex Sc rew
1mm x 10mm
YUASA SIZES
GYZ32HL
YIX30L
6.54"
(166 mm)
M10 Hex Screw
1.5mm x 20mm
ETX SIZES
ETX30L
NLP30 Battery
4.96"
(126 mm)
LxWxH
6.54” x 4. 96 ” x 6.89”
(166mm x 126mm x 175mm)
User Guide
DANGER
READ AND UNDERSTAND ALL SAFETY INFORMATION BEFORE USING THIS PRODUCT.
Failure to follow these safety instructions may result in ELECTRICAL SHOCK,
EXPLOSION, FIRE, which may result in a SERIOUS INJURY, DEATH, or PROPERTY
DAMAGE.
Electrical Shock. Product is an electrical device that can shock and cause serious injury. Do not
submerge in water or get wet.
Explosion. Never short-circuit the battery terminals. Do not use with an incompatible charging
o not attempt to jump start, charge, or discharge the battery if damaged or frozen.
device. D
Never charge or discharge the product outside its operating temperatures. Never over-charge or
over-discharge the battery. Never exceed the maximum charging currents of the battery. Never
incinerate.
Fire. The product is an electrical storage device that can emit heat. Do not cover product or place
objects on top of the product. Keep the product away from combustible materials.
Wear eye protection when operating product. Batteries can explode and cause flying
Eye Injury.
and contact poison control immediately.
MULTI-CONNECTION TERMINALS.
Equipped with premium IP 66 waterproof copper PCB
plates. NLP Terminals can be mounted from the front, side,
or top, and can be removed altogether depending on the
application.
Hex Key
User Guide & Warranty
For more information
and support visit:
RAPID RECHARGE.
Use the Lithium mode on a Genius charger to fully
recharge an NLP battery in minutes. See Genius
models and charging times below.
RECHARGE TIME
GENIUS1
GENIUS2
GENIUS5
GENIUS10
480 Minutes
240 Minutes
96 Minutes
48 Minutes
TECHNICAL SPECIFICATIONS
BCI SIZE:
CHEMISTRY:
NOMINAL
VOLTAGE:
AMP-HOURS:
WATT-HOURS (WH):
STARTING
CURRENT:
CHARGING
VOLTAGE (V):
CHARGING
CURRENT (A):
OPERATING
TEMPERATURE:
CHARGING
TEMPERATURE:
STORAGE
TEMPERATURE:
LITHIUM
CONTENT:
INTERNAL
BATTERY WEIGHT:
WEIGHT:
VOLUMETRICS:
Lithium Iron Phosphate (LiFePO4)
12.8
99.84
700
14.6V
24A (Max)
-20ºC to 60ºC
-10ºC to 50ºC
-20ºC to 60ºC
9.36 g
2.37 lbs (1.08 kg)
5.0 lbs (2.27kg)
Retail Packaging:
Dimensions:
7.83” x 3.7” x 8.15”
Weight: 5. 24 lbs
UPC: 0-46221-19010-6
Inner Carton:
Dimensions:
8.50” x 8 .15” x 4.06”
Weight: 5.4 8 lbs
30
7.8
Master Carton:
Dimensions:
16.73” x 8.98 ” x 8.82”
Weight: 22.70 lbs
Quantity: 4
UCC: 10046221190073
Units Per Pallet:
160 U nits
