NOBLE SERIES

Upright Door Dishmachines

INSTALLATION, OPERATION,

AND SERVICE MANUAL

INSTALLATION MANUAL FOR EXPORT UNITS

SERVICE MANUAL FOR DOMESTIC UNITS

ELECTRICALLY HEATED MODELS:

NOBLE HT-180 HH NOBLE HT-180 HH

with VENTLESS and ENERGY RECOVERY

January 12, 2016

07610-004-26-29-E

Noble Warewashing

Lancaster, Pennsylvania

www.nobleproducts.biz

REVISION HISTORY

Revision

Letter

A 07-24-15 KAP N/A Release to production.

B 10-08-15 KAP N/A Added HH ventless booster tank assembly on pg. 40.

C 11-10-15 JH N/A Corrected part number for item #40 on pg. 37.

D 11-23-15 JH QOF-386 Replaced Plumbing Booster Inlet diagram, pg. 50.

E 01-12-16 JH

Revision

Date

Made By

Applicable

ECNs

QOF-386

N/A

Details

Changed item 12 on pg. 36 to 05700-003-07-76. Added 05700-004-23-78, 05700-004-23-79, and 05700-004-2380 to view (pg. 35) and parts list (pg. 36). Corrected Typical Electrical Circuits for HT-180HH Ventless.

NOMENCLATURE FOR THE MODELS COVERED IN THIS MANUAL

NOBLE HT-180 HH

Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing, with booster heater.

NOBLE HT-180 HH with VENTLESS AND ENERGY RECOVERY

Door-type dishmachine; electrically-heated, high-temp, hot-water sanitizing,

with booster heater and ventless heat recovery system.

Model:

Serial No.:

Installation Date:

Service Rep. Name:

Phone Number:

iii

TABLE OF CONTENTS

SPECIFICATIONS

Operating Capacities ..................................................................................................................... 1

Electrical Requirements ................................................................................................................ 2

Machine Dimensions ..................................................................................................................... 3

Table Dimensions .......................................................................................................................... 8

INSTALLATION & OPERATION

Installation Instructions .................................................................................................................. 9

Electrical Installation Instructions ................................................................................................ 10

Noble HT-180 HH with Ventless and Energy Recovery Mounting ................................................11

Operating Instructions ................................................................................................................. 15

False Panel Installation ............................................................................................................... 18

PREVENTATIVE MAINTENANCE ...................................................................................................... 19

TROUBLESHOOTING ........................................................................................................................ 20

PARTS

Top Mounted Control Box Assembly (Universal Timer) ............................................................... 22

Side Mounted Control Box Assembly (Universal Timer) .............................................................. 26

Side Mounted Control Box Assembly (Mechanical Timer) .......................................................... 29

Hood Assembly (Bolted Single Support Design .......................................................................... 31

Cantilever Arm/Door Assemblies ................................................................................................. 33

Tub Assembly .............................................................................................................................. 35

Frame Assembly .......................................................................................................................... 38

Rinse Tank Assembly .................................................................................................................. 39

Ventless Rinse Tank Assembly ................................................................................................... 40

Wash Motor ............................................................................................................................. 41

Y-Strainer Incoming Plumbing/Outlet Plumbing Assemblies ....................................................... 43

Pressure Regulator Incoming Plumbing/Outlet Plumbing Assemblies ........................................ 46

Noble HT-180 HH with Ventless and Energy Recovery Plumbing Assemblies ........................... 49

Drain Quench Assembly .............................................................................................................. 51

1/2" Solenoid Valve & 1/2" NPT Vacuum Breaker Repair Parts Kits ........................................... 52

Wash & Rinse Arm/Manifold Assemblies ..................................................................................... 53

Transformer Mounting Box Components ..................................................................................... 55

Exhaust Fan Control .................................................................................................................... 56

Noble HT-180 HH with Ventless and Energy Recovery Assembly .............................................. 57

Ventless Door Interlock ............................................................................................................... 59

Standard Door Interlock Instructions ........................................................................................... 60

TABLE OF CONTENTS

SCHEMATICS

Solid State (Top Mount Control Box) 208-230V, 50/60Hz, Single/Three Phase .......................... 61

Noble HT-180 HH (Universal Timer) 208-230V, 50/60Hz, Single/Three Phase .......................... 62

Solid State (Top Mount Control Box) 460V, 60Hz, Three Phase ................................................. 63

Noble HT-180 HH (Universal Timer) 460V, 60Hz, Three Phase .................................................. 64

Door Interlock Option .................................................................................................................. 65

Exhaust Fan Hookup/Drain Quench Options .............................................................................. 66

SPECIFICATIONS

OPERATING CAPACITIES

OPERATING CAPACITY HT-180 HH:

Selection A

Racks per Hour 53 Dishes per Hour 1325 Glasses per Hour 1908

Selection B

Racks per Hour 29 Dishes per Hour 725 Glasses per Hour 1044

Selection C

Racks per Hour 20 Dishes per Hour 500 Glasses per Hour 720

Selection D Racks per Hour 12 Dishes per Hour 300 Glasses per Hour 432

OPERATING CYCLE (SECONDS):

WATER REQUIREMENTS:

NOBLE HH & NOBLE HH Ventless:

Wash Temperature (minimum) (°F) 150 Wash Temperature (minimum) (°C) 66 Rinse Temperature (minimum) (°F) 180 Rinse Temperature (minimum) (°C) 83 Inlet Water Temperature: 12kW Rinse Heater (°F) 140 12kW Rinse Heater (°C) 60 14kW Rinse Heater (°F) 110 14kW Rinse Heater (°C) 44

14KW Ventless (°F) 40-70 14KW Ventless (°C) 4.4-21

Flow Pressure (PSI) 20±5 Water Line Size (NPT) 3/4" Drain Line Size (NPT) 1 1/2"

Minimum (other cycle times are available)

Wash Time 45 Rinse Time 15 Total Cycle Time 60

Ventless Wash Time 45 Rinse Time 15 Dwell Time 2 Condensate Removal 30 Total Cycle Time 92

Tank Capacity:

Rinse Tank (gallons) 3.0 Rinse Tank (liters) 11.4 Wash Tank (gallons) 8.0 Wash Tank (liters) 30.3

ELECTRICAL REQUIREMENTS:

Wash Motor HP 2.0

NOTE: Always refer to the machine data plate for speciﬁ c electrical and water requirements. The material provided on this page is for reference only and is subject to change without notice.

07610-004-26-29-E

SPECIFICATIONS

ELECTRICAL REQUIREMENTS

NOTE: Typical Electrical Circuit is based upon (1) 125% of the full amperage load of the machine and (2) typical ﬁ xed trip circuit breaker sizes as listed in the NEC 2002 Edition. Local codes may require more stringent protection than what is displayed here. Always verify with your electrical service contractor that your circuit protection is adequate and meets all applicable national and local codes. These numbers are provided in this manual simply for reference and may change without notice at any given time.

NOBLE HT-180 HH:

Volts Phase Freq

Rinse Heater

Ratings

T otal Amps

415 3 60 12kW 28A 35AMP

415 3 60 14kW 30A 40AMP

208 1 60 12kW@240V 75A 100AMP

208 1 60 12kW@240V 82A 110AMP

230 1 60 12kW@240V 81A 110AMP

230 1 60 14kW@240V 90A 125AMP

208 3 60 12kW@240V 48A 60AMP

208 3 60 14kW@240V 52A 70AMP

230 3 60 12kW@240V 52A 70AMP

230 3 60 14kW@240V 57A 80AMP

460 3 60 12kW@480V 24A 30AMP

460 3 60 14kW@480V 26A 35AMP

Typical Electrical

Circuit

NOBLE HT-180 HH VENTLESS:

Volts Phase Freq

208 1 60 15.4kW 87A 110AMP

230 1 60 15.4kW 96A 125AMP

208 3 60 15.4kW 55A 70AMP

230 3 60 15.4kW 61A 80AMP

460 3 60 15.4kW 28A 35AMP

Rinse Heater

Ratings

T otal Amps

Typical Electrical

Circuit

07610-004-26-29-E

SPECIFICATIONS

DIMENSIONS (TOP MOUNT CONTROL BOX) Y-STRAINER OPTION

ONS

LEGEND

N SIZE

)

A - Drain 1 1/2" NPTF

CIAL CONNECTION)

B - Water Inlet 3/4" NPTF C - Electrical Connection

M FLOOR

All vertical dimensions are ±1/2" due to adjustable bullet feet.

in [727mm]

25 in [635mm]

17 in [432 mm]

4 in [102 mm]

[641 mm]

3 in [76 mm]

4 in

[102mm]

15 in [387mm]

in [641mm]

[97 mm]

1 in [25 mm]

[1854mm]

27 in

[686mm]

[641 mm]

[2203 mm]

[1 8 7 4 m m ]

[1941 mm]

[1740 mm

]

34 in

[864mm]

in [299mm]

07610-004-26-29-E

DIMENSIONS (TOP MOUNT CONTROL BOX) PRESSURE REGULATOR OPTION

LEGEND

A - Drain 1 1/2" IPS B - Water Inlet 3/4" IPS C - Electrical Connection

All vertical dimensions are +/- 1/2" due to adjustable bullet feet.

SPECIFICATIONS

4 [102mm]

86 3/4 [2203mm]

73 [1856mm]

3 [76mm]

25 [637mm]

17 [432mm]

27 [686mm]

73 1/4 [1873mm]

4 [102mm]

25 1/4 [641mm]

3 [76mm]

1 [25mm]

34 [861mm]

11 3/4 [298mm]

15 1/4 [387mm]

07610-004-26-29-E

SPECIFICATIONS

DIMENSIONS (SIDE MOUNT CONTROL BOX)

LEGEND

A - DRAIN 1 1/2" IPS

B - WATER INLET 3/4" IPS

C - ELECTRICAL CONNECTION All dimensions are in inches. All vertical

dimensions are +/- 1/2" due to adjustable

bullet feet.

4 [102mm]

3 [76mm]

86 1/4

156mm]

27 [687]

[863mm]

25 [637mm]

15 1/4 [388mm]

4 [102mm]

1 [25mm]

25 1/4 [639mm]

73 3/4 [1873mm]

7 1/2 [190mm]

12 3/4 [327mm]

12 1/4 [310mm]

07610-004-26-29-E

LEGEND

A - Drain 1 1/2” B - Water Inlet 3/4” C - Electrical Connection

All vertical dimensions are +/- 1/2” due to adjustable bullet feet.

SPECIFICATIONS

DIMENSIONS (LEFT SIDE CONTROL BOX)

4 [102mm]

15 1/4

[388mm]

3 [76mm]

4 [102mm]

86 1/4 [2156mm]

25 [637mm]

4 [102mm]

1 [25mm]

25 1/4 [639mm]

[687]

73 3/4 [1873mm]

[863mm]

12 3/4 [327mm]

12 1/4 [310mm]

07610-004-26-29-E

SPECIFICATIONS

DIMENSIONS (VENTLESS HEAT RECOVERY)

LEGEND

A) DRAIN 1 B) WATER INLET

C) ELECTRICAL CONN ECTIONS All vertical dimensions are ±

adjustable bullet feet

1 2 IPS

3 4 MIP

(639mm)

1/2" due to

3 (76mm)

4 101mm)

(134mm)

(637mm)

17 (432mm)

88 (2235mm)

(79mm)

93 (2362mm)

73 (1856mm)

34 (861mm)

(387mm)

(298mm)

07610-004-26-29-E

SPECIFICATIONS

TABLE DIMENSIONS

NOTE: Please remove the front dress panel from the dishmachine if mounting dishmachine for a

corner installation and attaching side tables. Corner installation will trap panel making it difﬁ cult to remove.

LETTER DIM (IN) DIM (CM)

OPENING

A 4” (MIN) 10.2 CM (MIN) B 2 1/2” 6.4 CM C 20 1/2” 52.1 CM D 25 1/4” 64.1 CM E 2 1/4” 10.2 CM F 1 1/2” 3.8 CM

G 3/4” 1.9 CM

TABLE DIMENSIONS

CORNER INSTALLATION

OPENING

F (ROLL)

TABLE DIMENSIONS

CONNECTION TO DISHMACHINE

TABLE DIMENSIONS STRAIGHT

OPENING

07610-004-26-29-E

SPECIFICATIONS

INSTALLATION INSTRUCTIONS

VISUAL INSPECTION: Before installing unit check container and machine for damage. A damaged container may be an

indication of damage to the machine. If there is any type of damage to both container and unit, do not throw away the container. The dishmachine has been inspected at the factory prior to shipping and is expected to arrive in new, undamaged condition. However, rough handling by carriers or others may result in damage to the unit while it is in transit. If such a situation occurs, do not return the unit to the manufacturer. Instead, contact the carrier and ask them to send a representative to the site to inspect the damage, and request that an inspection report be completed.

Contact the carrier within 48 hours of receiving the machine (to report possible freight damage) and the dealer from whom the unit was purchased.

UNPACKING THE DISHMACHINE: The machine should be unboxed and removed from the pallet prior to installing. Open

the front door and remove all of the materials from the inside. Once unpacked, verify there are no missing parts. If a part is missing, contact manufacturer immediately.

LEVEL THE DISHMACHINE: The dishmachine is designed to operate while level. This is

important to prevent any damage to the machine during operation and to ensure the best results possible. The unit comes equipped with adjustable bullet feet which can be turned using a pair of pliers. Verify the unit is level from front to back and side to side before making any electrical or plumbing connections.

PLUMBING THE DISHMACHINE: All plumbing connections must be made to adhere to local, state, territorial and national

codes. The installing plumber is responsible for ensuring the incoming water lines are ﬂ ushed of debris prior to connecting to the machine. Note that chips and materials from cutting processes can become lodged in the solenoid valves and prevent them from opening or closing. Any valves that are found to be fouled or defective because of foreign matter left in the water line,

Raise

Lower

and any subsequent water damage, are not the responsibility of the manufacturer.

Frame withAdjustable Foot

A water hardness test must be performed to determine if the HTS-11 (scale prevention & corrosion control) needs to be installed. A hardness test kit can be found on the warning tag that is attached to the incoming plumbing connection on the back of the machine. If water hardness is higher than 5 GPG, the HTS-11 will need to be installed. Please contact manufacturer to purchase the HTS-11.

CONNECTING THE DRAIN LINE: The dishmachine's drain is a gravity discharge drain. All piping from the 1 1/2” FNPT con-

nection on the wash tank must be pitched (1/4” per foot) to the ﬂ oor or sink drain. All piping from the machine to the drain must be a minimum 1 1/2” I.P.S. and shall not be reduced. There must also be an air gap between the machine drain line and the ﬂ oor sink or drain. If a grease trap is required by code, it should have a ﬂ ow capaci- ty of 5 gallons per minute.

WATER SUPPLY CONNECTION: Read the section entitled “PLUMBING THE

DISHMACHINE” before proceeding. Install the water supply line (3/4” pipe size minimum, 1/2" pipe size minimum for LT) to the dishmachine line strainer using copper pipe. It is recommended that a water shut-off valve be installed in the water line between the main supply and the machine to allow access for service.

IncomingPlumbingY-strainerConnection

07610-004-26-29-E

INSTALLATION & OPERATION

INSTALLATION INSTRUCTIONS

The water supply line is to be capable of 20±5 PSI “ﬂ ow” pressure at the recommended temperature indicated on the data plate. Take care not to confuse static pressure with ﬂ ow pressure: Static pressure is line pressure in a “no ﬂ ow” condition (all valves and services are closed); ﬂ ow pressure is the pressure in the ﬁ ll line when the valve is opened during the cycle. It is suggested that a shock absorber (not supplied) be installed on the incoming water line. This prevents water hammer (hydraulic shock)—induced by the solenoid valve as it operates—from causing damage to the equipment.

PLUMBING CHECK: Slowly turn on the water supply to the machine after the incoming ﬁ ll line and the drain line have been

installed. Check for any leaks and repair as required. All leaks must be repaired prior to placing the machine in operation.

ELECTRICAL POWER CONNECTION: Electrical and grounding connections must comply with the applicable portions

of the National Electrical Code ANSI/NFPA 70 (latest edition) and/or other electrical codes. Disconnect electrical power supply and place a tag at the disconnect switch to indicate that you are working on the circuit. The dishmachine data plate is located on the right side and to the front of the machine. Refer to the data plate for machine operating requirements, machine voltage, total amperage load and serial number. To install the incoming power lines, open the control box. This will require taking a Phillips head screwdriver and removing the four (4) screws on the front cover of the control box. Install 3/4” conduit into the pre-punched holes in the back of the control box. Route power wires and connect to power block and grounding lug. Install the service wires (L1, L2, & L3 (three phase only)) to the appropriate terminals as they are marked on the terminal block. Install the grounding wire into the lug provided. Tighten the connections. It is recommended that “DE-OX” or another similar anti-oxidation agent be used on all power connections.

Power Block

Ground Lug

VOLTAGE CHECK: Ensure that the power switch is in the OFF position and ap-

ply power to the dishmachine. Check the incoming power at the terminal block and ensure it corresponds to the voltage listed on the data plate. If not, contact a qualiﬁ ed service agency to examine the problem. Do not run the dishmachine if the voltage is too high or too low. Shut off the service breaker and mark it as being for the dishmachine. Advise all proper personnel of any problems and of the location of the service breaker. Replace the control box cover and tighten down the screws.

IncomingPower Connection

07610-004-26-29-E

INSTALLATION & OPERATION

VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS

Due to shipping constraints the NOBLE HT-180 High Hood is shipped dissembled, you should receive two pieces.

Heat Recovery Unit Base Unit

The heat recovery unit box is located inside the dishmachine shipping box.

Fully Assembled Unit

07610-004-26-29-E

INSTALLATION & OPERATION

VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS

Locate and remove the four 1/4-20 bolts using a 7/16 wrench. These are located in top left and right corner of the unit.

Lift the heat recovery unit up and over the lower air inlet, then align and slide unit onto the lower air inlet. Upper unit should slide inside the lower air inlet at the seam.

Heat Recovery UnitLower Air Inlet Seam

Reinstall the four 1/4-20 bolts that were removed in step 1 with a 7/16 wrench. They insert into the machine on the right and left corners.

07610-004-26-29-E

INSTALLATION & OPERATION

VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS

Connect pressure gauge with a 9/16 wrench. Connect the two hoses using an adustable wrench. The hoses are cut to length and will only reach their intended connection point.

A. Connect the Gauge B. Final Rinse Inlet

C. PRV Inlet from Coil D. Booster Outlet

Before moving to the next step, tidy up the hoses by sliding them under the clamps. You may need to loosen the nut to accomplish this.

07610-004-26-29-E

INSTALLATION & OPERATION

VENTLESS HEAT RECOVERY MOUNTING INSTRUCTIONS

Locate the wire connectors at the top of the unit and connect the white and black wires from the base unit.

Slide wire into the hole and push the lever down

Tidy up the wires and lock them in place with the P-Clamp on the top of the unit.

P-Clamp

Now you have a fully assembled unit.

07610-004-26-29-E

INSTALLATION & OPERATION

OPERATING INSTRUCTIONS

The Conserver XL-E Series CAM timer is a 1 minute, 30 second, 8-CAM timer (CAM 8 is a spare) that controls the operation of

the dishmachine. The following is a description of the set points for each CAM and the function of each switch.

CAM 1 is a cut CAM with a single notch that serves as the cycle/reset control.

FUNCTION: When the machine is in the operation mode the notch is in the home position. The machine will remain idle until the door is opened, then CAM 1 moves to the start position and holds until the door is closed. The closing of the door will start the next cycle. The CAM will rotate a complete cycle and return to the home position and hold.

CAM 2 is a cut CAM that provides the wash cycle timing.

FUNCTION: The wash CAM works off the normally open contacts of CAM 2. This requires the microswitch be held closed by the CAM. It will close and energize the wash pump 2 seconds after the cycle switch is activated. The pump will operate through the wash cycle (40 seconds) then shut down for the dwell period (20 seconds). As the CAM rotates it energizes the pump for the rinse cycle (25 seconds). When CAM 1 reaches its home position it will de-energize CAM 2, shutting down the wash pump.

NOTE: The last 6 CAMS are adjustable. The following instructions will require that the timer position have the CAMs to the front and the motor to the left.

CAM 3 is an adjustable CAM that controls the drain valve.

FUNCTION: The drain solenoid works off the normally closed contacts of CAM 3. When the cycle is initiated, the microswitch will be held open until it is allowed to drop into the notch of the CAM. This energizes the drain solenoid which then drains the machine. After a 12 second delay the CAM reverses the microswitch, de-energizing the drain solenoid. This CAM may require adjusting due to varying water pressure. The drain solenoid must remain open long enough to remove whatever water the ﬁ ll valve solenoid allows in the machine. This could vary due to the water supply line pressure.

SETTINGS: The right side of CAM 3 must be set to pick up the microswitch just before the wash/rinse cycle CAM switch drops. It will hold the drain solenoid open to drain all the water in the tank from the unit during the dwell period. Any adjustment made to the drain should be made to the left side of CAM 3. The CAM must be moved back into the wash time until all of the water is drained from the machine.

CAM 4 is an adjustable CAM that controls the ﬁ ll valve and the amount of water used.

FUNCTION: The ﬁ ll valve CAM works off the normally closed contacts of CAM 4. This requires the microswitch to be held open by the CAM and allowed to drop into the notch to operate the ﬁ ll valve. This energizes the ﬁ ll solenoid which opens to start ﬁ lling the machine with fresh water. After a 10 second delay the CAM reverses the microswitch, de-energizing the ﬁ ll solenoid. The ﬁ ll CAM may require adjustment due to varying water pressure. The ﬁ ll solenoid must remain open a sufﬁ cient length of time to ﬁ ll the machine to the correct level.

SETTINGS: The right side of CAM 4 must be set to allow the microswitch to drop 2 seconds before the drain solenoid is de-energized to ensure the detergent residue is ﬂ ushed from the unit. It will hold the ﬁ ll solenoid open until the CAM switch arm is raised. At that time the ﬁ ll solenoid is de-energized, shutting off the incoming water. The tub will be ﬁ lled to the correct level. Any adjustment made to the timing of the ﬁ ll solenoid should be made with the left side of CAM 4. To

07610-004-26-29-E

INSTALLATION & OPERATION

OPERATING INSTRUCTIONS

SHUTDOWN AND CLEANING: At the end of the workday, close the doors. When the unit completes the cycle, turn the

power switch to the OFF position and open the door. Remove and clean the pan strainer. Remove the drain stopper from the tub and allow the tub to drain (NOTE: The wash tank water will be hot so caution is advised). Once the wash tub is drained, remove the pump suction strainer. Dispose of any soil and debris found in the strainer. Unscrew the wash and rinse arms from their manifolds. Remove the endcaps and ﬂ ush the arms with water. Use a brush to clean out the inside of the arms. If the nozzles appear to be clogged, use a toothpick to remove the obstruction. Wipe the inside of the unit, removing all soil and scraps. Reassemble the wash and rinse arms and replace them in the unit. The arms only need to be hand tight, do not use tools to tighten them down. Reinstall the drain stopper and strainers and close the door.

WATER CONSUMPTION ISSUES AND EFFICIENCY: The models covered in this manual provide the customer with the ability

to control the hourly rack capacity of the machine. Extending the wash cycle to wash severely soiled ware, such as mixing bowls, does not increase the machine’s water consumption. However, selecting a longer time cycle does lower the amount of dishes the machine will be able to wash per hour. It is important for operators to select the correct wash cycle depending on the amount of washing required. Not every rack of dishes requires the machine to be set on the longest wash cycle.

07610-004-26-29-E

INSTALLATION & OPERATION

DETERGENT CONTROL

DETERGENT CONTROL: Detergent usage and water hardness are two factors that contribute greatly to how efﬁ ciently

this dishmachine will operate. Using detergent in the proper amount can become a source of substantial savings. A qualiﬁ ed water treatment specialist can relate what is needed for maximum efﬁ ciency from the detergent.

1. Hard water greatly affects the performance of the dishmachine, causing the amount of detergent required for washing to increase. If the machine is installed in an area with hard water, the manufacturer recommends the installation of water treatment equipment.

2. Deposited solids from hard water can cause spotting that will not be removed with a drying agent. Treated water will reduce this occurence.

3. Treated water may not be suitable for use in other areas of operation and it may be necessary to install a water treatment unit for the water going to the dishmachine only. Discuss this option with a qualiﬁ ed water treatment specialist.

4. Dishmachine operators should be properly trained in how much detergent is to be used per cycle. Meet with a water treatment specialist and detergent vendor to discuss a complete training program for operators.

5. Certain dishmachine models require that chemicals be provided for proper operation and sanitization. Some models may require the installation of third-party chemical feeders to introduce those chemicals to the machine. The manufacturer does not recommend or endorse any brand name of chemicals or chemical dispensing equipment. Contact a chemical distributor for questions.

6. Some dishmachines come equipped with integral solid detergent dispensers. These dispensers are designed to accommodate detergents in a certain-sized container. If applicable, relate this to a chemical distributor upon ﬁ rst contacting them.

7. Water temperature is an important factor in ensuring that the dishmachine functions properly, and the machine's data plate details what the minimum temperatures must be for the incoming water supply, the wash tank and the rinse tank. If minimum requirements are not met, there is a possibility that dishes will not be clean or sanitized.

8. Instruct dishmachine operators to observe the required temperatures and to report when they fall below the minimum allowed. A loss of temperature can indicate a larger problem—such as a failed heater—or could indicate that the hot water heater for the operation is not up to capacity and a larger one may need to be installed.

07610-004-26-29-E

INSTALLATION & OPERATION

FALSE PANEL INSTRUCTIONS

Rack rail removed and repositioned for a corner operation.

False panel positioned in unit

1. Remove the rack assembly from the dishmachine.

2. The false panel will mount inside of the dishmachine.

3. Position the panel in the dishmachine on the side to be closed.

4. Hold the panel against the side of the dishmachine and push upward.

5. The panel will clip in at the top, inside of the unit.

6. The holes in the false panel will line up with the rack assembly holes.

7. Reinstall the screws for the rack assembly which will secure the false panel to the unit.

8. Reassemble the rack track in an "L" shape for a corner operation.

07610-004-26-29-E

PREVENTATIVE MAINTENANCE

Noble Warewashing highly recommends that any maintenance and repairs not speciﬁ cally discussed in this manual

should be performed by QUALIFIED SERVICE PERSONNEL ONLY. Performing maintenance on your dishmachine may

void your warranty if it is still in effect. By following the operating and cleaning instructions in this manual, users should get

the most efﬁ cient results from the dishmachine.

Steps to ensure that the dishmachine is used properly:

1. Ensure that the water temperatures match those listed on the machine data plate (on the front left of machine).

2. Remove as much soil as possible from dishes before loading into racks.

3. Ensure that all strainers are in place, laying ﬂ at in tub and free of soil and debris before operating the machine. To clean

strainers, wipe them out with a rag and rinse under a faucet. For stubborn debris, a toothpick can be used to dislodge any

obstructions from the perforations. Do not beat strainers on waste cans; once bent they will not work properly.

4. If hard water is present, install an HTS-11 into the water line connecting to the dishmachine (see section "Plumbing the

Dishmachine").

5. Ensure that all wash and/or rinse arms are secure in the machine before operating.

6. Ensure that drains are closed/sealed before operating.

7. Do not overﬁ ll racks.

8. Ensure that glasses are placed upside down in the rack.

9. Ensure that all chemicals being injected into machine have been veriﬁ ed as being at the correct concentrations.

9. Clean out the machine at the end of every workday as per the instructions in the manual (see section on "Shutdown &

Cleaning").

10. Always contact a qualiﬁ ed service agency whenever a serious problem arises.

11. Follow all safety procedures, whether listed in this manual or put forth by local, state or national codes/regulations.

07610-004-26-29-E

PROBLEM POSSIBLE CAUSE REMEDY

Dishmachine runs continuously in the wash cycle.

Machine is in delime mode.

Wash cycle delay timer is faulty.

Change operation mode from DELIME to NORMAL position.

During the wash cycle, the cam timer will move for the ﬁ rst 30 seconds of the wash cycle. The cycle delay timer will then cause the cam timer to stop, in order to increase the length of the wash cycle. The red light on the delay timer is in control of the cam timer. If the red light is not turning on (only during cycles B, C or D), replace the cycle timer.

TROUBLESHOOTING

Dishmachine will not ﬁ ll after the door is closed. Power "ON" light is illuminated.

Dishmachine will not ﬁ ll after the door is closed. Power "ON" light is not illuminated.

Wash cycle delay timer settings are not correctly adjusted.

Cam timer is faulty.

Faulty rinse solenoid valve.

Faulty door switch.

Fouled/faulty high level probe.

Service breaker tripped.

Machine not connected to power source.

Faulty power source.

Service breaker tripped.

Machine not connected to power source.

If the wash cycle delay timer and rotating cam timer are working correctly, the time cycles on the delay timer may be incorrectly adjusted. Adjust the delay potentiometer corresponding to the B, C or D cycle. Rerun the appropriate cycle and see if the adjustment has made any change in the length of the cycle. If not, replace the cycle delay timer.

Conﬁ rm that the wash cycle delay timer is functioning correctly (see above). Conﬁ rm that the timer motor is receiving power. If it is, replace the motor and/or timer assembly. Make sure there are no obstructions which limit the rotation of the cam timer.

Repair or replace valve as required.

Verify the wiring of the switch; if correct, replace the switch.

Clean probe if fouled. If clean and not working, replace.

Reset. If the breaker trips again, contact an electrician to verify the amp draw of the machine.

Verify that the machine has been properly connected to the power source.

Verify the wiring of the switch; if correct, replace switch.

Reset. If the breaker trips again, contact an electrician to verify the amp draw of the machine.

Verify that the machine has been properly connected to the power source.

Faulty power source.

Wash or rinse heater does not work.

Dishmachine ﬁ lls slowly and/or rinse is weak.

Rinse water is not reaching required temperature.

Faulty heater element.

Faulty heater contactor.

Misadjusted/faulty thermostat(s).

Clogged or obstructed rinse arms.

Low incoming water pressure.

Y-strainer is clogged.

Faulty rinse heater.

Misadjusted/faulty thermostat(s).

Rinse thermometer is defective.

Verify the wiring of the switch; if correct, replace switch.

Check element for continuity; if open, replace the heater.

Replace the contactor.

Verify the operation and setting of thermostats; replace if necessary.

Remove and clean the rinse arms.

Adjust the water pressure regulator to ensure that there is 20±5 PSI ﬂ ow.

Clean out the Y-strainer.

Check element for continuity; if open, replace heater.

Verify operation and setting of thermostats; replace if necessary.

Replace thermometer.

07610-004-26-29-E

TROUBLESHOOTING

PROBLEM POSSIBLE CAUSE REMEDY

Wash water is not reaching required temperature.

Faulty wash heater.

Misadjusted/faulty thermostat(s).

Check element for continuity; if open, replace heater.

Verify operation and setting of thermostats; replace if necessary.

Doors will not close completely.

Water leaks at the wash pump.

Will not rinse during autocycle.

Dishes are not coming clean.

Wash thermometer is defective.

Improper spring tension.

Obstruction in door channel.

Doors are not square with frame.

Wash pump seal defective.

Petcock or pump drain (if equipped) not shut/tight.

Loose hoses (hose clamps) on the wash pump.

Defective rinse solenoid.

Faulty ﬁ ll microswitch.

No water to the machine.

Machine temperatures are not up to the minimum requirements.

No detergent/too much detergent.

Solid dispenser canister is empty.

Replace thermometer.

Adjust spring tension as required by loosening (not removing) spring bolt nuts and adjusting the tension. Tighten nuts back when done.

Remove the obstruction.

Adjust the frame to accommodate the doors.

Replace the seal.

Close or tighten.

Tighten the hose clamps.

Repair or replace the rinse solenoid as required.

Replace microswitch.

Verify that there is water at 20±5 PSI connected to the machine.

Verify that incoming water, rinse water and wash water match the required temperatures as listed on the machine data plate.

Adjust detergent concentration as required for the amount of water held by the machine.

Replace the canister.

07610-004-26-29-E

PARTS

TOP MOUNTED CONTROL BOX ASSEMBLY

07610-004-26-29-E

PARTS

TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)

6423

37 39

1114

1215

9 10

424041

07610-004-26-29-E

TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Control Box Weldment 05700-003-30-14

2 1 Timer Bracket 05700-003-02-08

3 2 Lock Nut 6-32 05310-373-03-00

4* 2 Heater Contactor 05945-109-01-69

5 1 Terminal Block 05940-011-48-27

6 17 Lock Nut 10-24 05310-373-01-00

7 1 Contactor, Wash Motor 05945-002-74-20

8 1 Relay 05945-111-47-51

1 Relay (415V, 3PH, 5 Wire Only) 05945-111-89-75

9 1 Light, Green 05945-111-44-43

10 1 Light, Red 05945-111-44-45

11 1 Temperature Gauge, Wash 96" Lead 06685-111-68-49

12 1 Temperature Gauge, Rinse 48" Lead 06685-111-68-48

PARTS

13 1 Light, Yellow 05945-111-44-44

14 1 Decal, Wash 150°F Min 09905-002-97-61

15 1 Decal, Rinse 180°F Min 09905-002-97-62

16 1 Ground Lug 05940-200-76-00

17 1 Bracket, Liquid Level Control Board 05700-002-13-22

18 1 Liquid Level Control Board 06680-200-08-21

19 6 Tricnut, 6-32 05340-118-04-00

20 3 Screw, 6-32 x 5/8" 05305-011-39-85

21 3 Plug, 1/2" 05975-011-47-81

22 2 Grommet, 7/8" Split 05975-200-40-00

23 1 Bushing Snap 05975-210-02-00

24 1 Clamp, Hose .25-.312 05975-002-61-43

25 1 Decal, Warning-Disconnect Power 09905-100-75-93

26 1 Cover, Top Mount Control Box 05700-002-23-03

27 1 Decal, Control Box 09905-003-97-38

28 4 Lockwasher, Int. Tooth #10 05311-273-03-00

29 4 Screw, 10-32 x 3/8" Phillips Truss Head 05305-173-12-00

30 1 Decal, Copper Conductors 09905-011-47-35

31 1 Decal, Ground 09905-011-86-86

32 1 Decal, L1, L2 09905-002-78-67

33 1 Bracket, Fuse Strip 05700-002-42-03

07610-004-26-29-E

PARTS

TOP MOUNTED CONTROL BOX ASSEMBLY (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

34 1 Fuse Holder, 6 Pole 05920-002-42-13

35 2 Screw, 6-32 x 3/8" with Ext. Tooth Washer 05305-002-25-91

36 1 Decal, Dispenser Connection 09905-003-34-09

37 1 Timer, Universal 05945-003-33-09

Timer, Universal Fused (Alternate) 05945-003-75-23

38 4 Locknut, 10-32 05310-373-02-00

39 4 Screw 10-32 x 1" 05305-002-19-42

40 1 Switch, Rotary Selector 05930-003-97-61

41 1 Switch, Operation 05930-301-53-00

42 1 Switch, Power 05930-011-49-55

43* 1 Overload, TK-ONY (460 Volt Unit Only) 05945-002-65-02

44* 1 Motor Contactor, SC-03Y (460 Volt Unit Only) 05945-002-65-00

45* 1 Din Rail 2-3/4" (460 Volt Unit Only) 05700-001-84-65

*For a 460V Unit, replace item 4 with items 43, 44 & 45.

07610-004-26-29-E

PARTS

SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY

1 2 3

1010

2829

30 31 10

18 19 20 2421

21 22 23

07610-004-26-29-E

PARTS

SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Bracket, Electrical Box Mounting 05700-002-18-48

2 9 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00

3 9 Washer, 1/4"-20 I.D. S/S 05311-174-01-00

4 1 Control Box Weldment, Right Hand 05700-002-06-48

1 Control Box Weldment, Left Hand 05700-002-23-08

5 2 Contactor, 4 Pole, 220V, 1 Phase 05945-109-01-69

6 4 Screw, 10-32 x 1/2" Phillips Pan Head with Washer 05305-002-32-37

7 1 Liquid Level Control 06680-200-08-21

8 3 Screw, 6-32 x 5/8" 05305-011-39-85

9 1 Thermometer, 48 Lead, Wash 06685-111-68-48

1 Decal, Wash 150°F 09905-002-97-61

10 1 Relay, 240V, 50/60Hz, Top Mount 05945-002-47-74

11 8 Screw, 6-32 x 3/8" SEMS with External Tooth Washer 05305-002-25-91

12 1 Decal, Control Box Gauge 09905-002-10-69

13 1 Thermometer, 96 Lead Rinse 06685-111-68-49

1 Decal, Rinse 180°F 09905-002-97-62

14 1 Timer, Universal 05945-003-75-23

15 1 Timer, Bracket 05700-003-02-08

6 Holder, Keystone 05940-002-21-87

1 Keying Plug 05940-003-11-66

2 Connector 05940-003-11-65

16 1 Contactor, 2 Pole, 220V, 20 Amp (208-230V Unit only) 05945-002-74-20

17 1 Timer, Cycle Delay (not used with Universal Timer) (not shown) 05945-002-13-78

18 1 Terminal Block, 3 Pole 05940-011-48-27

19 1 Decal, L1, L2, L3 09905-101-12-66

20 1 Decal, Copper Conductors 09905-011-47-35

21 4 Locknut, 10-24 S/S Hex with Nylon Insert 05310-373-01-00

22 1 Wire Lug 05740-200-76-00

23 1 Decal, Ground 09905-011-86-86

24 1 Holder, Fuse 05920-401-03-14

07610-004-26-29-E

SIDE MOUNT UNIVERSAL TIMER CONTROL BOX ASSEMBLY (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

25 1 Cover, Control Box Weldment 05700-002-06-52

26 4 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00

27 1 Switch, Rotary Selector 05930-003-97-61

28 1 Switch, Operation 05930-301-53-00

29 1 Decal, Control Box Cover 09905-003-97-39

30 1 Light, Red 05945-504-07-18

31 1 Light, Green Indicator 05945-504-08-18

32 1 Light, Amber 05945-504-06-18

33 1 Cover, Dielectric Control Panel (not shown) 05700-021-50-89

34 1 Contactor, 2 Pole, 220V, 20 Amp (460V Unit Only) 05945-002-65-00

35 1 Overload (460V Unit Only) 05945-002-65-01

36 1 Switch, Power 05930-011-49-55

PARTS

07610-004-26-29-E

PARTS

SIDE MOUNT MECHANICAL TIMER CONTROL BOX

07610-004-26-29-E

SIDE MOUNT MECHANICAL TIMER CONTROL BOX (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 2 Contactor, 4 Pole, 220V, 1 Phase 05945-109-01-69

2 1 Liquid Level Control 06680-200-08-21

3 1 Decal, 120°F Wash/Rinse (not shown) 09905-002-82-46

4 1 Relay, 240V, 50/60Hz, Top Mount 05945-002-47-74

5 1 Timer, Cam/Mechanical 05945-303-31-00

6 1 Contactor, 2 Pole, 220V, 20 Amp (208-230V Unit only) 05945-002-74-20

7 4 Bolt, 10-32 x 1/2" Slotted Truss 05305-173-04-00

8 1 Bracket, Electrical Box Mounting 05700-002-18-48

9 1 Decal, Control Box Cover 09905-003-97-39

10 1 Switch, Operation 05930-301-53-00

11 1 Switch, Power 05930-011-49-55

PARTS

12 1 Light, Red 05945-504-07-18

13 1 Light, Green Indicator 05945-504-08-18

14 1 Light, Amber 05945-504-06-18

07610-004-26-29-E

PARTS

HOOD ASSEMBL Y

07610-004-26-29-E

HOOD ASSEMBL Y

ITEM QTY DESCRIPTION PART NUMBER

1 1 Hood Weldment 05700-003-05-67

2 2 Hood Support Assembly 05700-004-13-45

3 1 Left Back Inner Door Guide 05700-031-76-34

4 1 Right Back Outer Door Guide 05700-031-76-32

5 1 Right Back Inner Door Guide 05700-031-76-35

6 1 Left Back Outer Door Guide 05700-031-76-33

7 34 Locknut, 1/4-20 Hex w/Nylon Insert 05310-374-01-00

8 26 Washer, S/S 1/4-20 I.D. 05311-174-01-00

9 6 Screw, 1/4-20 x 5/8 S/S Hex Head 05305-274-24-00

10 20 Bolt, 1/4-20 x 1/2 Long 05305-274-02-00

PARTS

07610-004-26-29-E

PARTS

CANTILEVER ARM/DOOR ASSEMBLIES

ITEM QTY DESCRIPTION PART NUMBER

1 1 Cantilever Arm 05700-004-14-29

2 2 Sleeve, Cantilever Arm 05700-000-85-69

3 2 Screw, 1/4"-20 x 1 1/2" Long Hex Head 05305-274-23-00

4 4 Washer, 1/4" I.D. S/S 05311-174-01-00

5 4 Locknut, 1/4"-20 S/S Low Proﬁ le with Nylon Insert 05310-374-02-00

6 4 Plug, Cantilever 05340-011-35-00

7 2 Connecting Link 05700-021-92-45

8 2 Spring Pin, 1/4" x 1 1/8" Long 05315-407-06-00

9 2 Yoke Assembly 05700-000-75-77

10 2 Nut, 3/8"-16 S/S Hex Locking 05310-256-04-00

11 2 Rod, Spring Connecting 05700-002-00-91

12 4 Plate, Spring Multiplier 05700-002-00-88

13 4 Spring, Cantilever Door 05340-111-35-22

14 4 Bolt, Cantilever Hanger Eye 3/8"-16 05306-956-05-00

07610-004-26-29-E

CANTILEVER ARM/DOOR ASSEMBLIES

ITEM QTY DESCRIPTION PART NUMBER

15 4 Washer, Impeller 05311-176-02-00

16 8 Nut, 3/8"-16 S/S Hex 05310-276-01-00

2 Door, Upper, Left & Right Assemblies (not shown) 05700-002-01-30

17 2 Door, Upper, Left & Right Weldment 05700-002-29-59

18 4 Glide, Upper Door 05700-002-00-83

1 Door, Lower, Right Assembly (not shown) 05700-002-01-33

19 1 Door, Lower, Right 05700-004-14-18

20 2 Glide, Lower Door 05700-002-23-64

21 1 Door Stop Magnet Assembly 06401-003-08-68

1 Door Stop Magnet Weldment (not shown) 05700-002-01-27

1 Magnet (not shown) 05930-111-69-25

2 End Cap (not shown) 05700-011-60-92

22 6 Bumper, Noble HT-180 HH Door 05700-004-14-25

PARTS

23 12 Screw, 1/4"-20 x 5/8" 05305-274-24-00

24 12 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00

25 2 Screw, 1/4"-20 x 1/2" Long Hex Head 05305-274-02-00

26 2 Spacer, PB Bolt 05700-000-29-40

27 2 Bracket, Door Connector 05700-004-14-24

28 1 Handle, Front Door Weldment 05700-004-14-30

1 Door, Lower, Front Assembly (not shown) 05700-002-01-31

29 1 Door, Lower, Front 05700-004-14-22

30 2 Glide, Upper Door 05700-002-23-64

1 Door, Upper Front Assembly (not shown) 05700-002-24-92

31 1 Door, Upper, Front Weldment 05700-002-29-57

32 2 Glide, Upper Door 05700-002-00-83

1 Door, Lower, Left Assembly (not shown) 05700-002-01-32

1 Door, Lower, Left Assembly (Door Lock) (not shown) 05700-004-24-21

33 1 Door, Lower, Left 05700-004-14-20

1 Door, Lower, Left (Door Lock) (not shown) 05700-004-24-22

1 Door Interlock Bracket (not shown) 05700-004-23-17

34 2 Glide, Lower Door 05700-002-23-64

35 6 Door Stop Weldment 05700-002-29-60

36 1 Door Stop 06401-003-08-69

37 2 Cantilever Arm Support Bracket (not shown) 09515-003-15-64

38 6 Wear Button (not shown) 05700-011-88-01

07610-004-26-29-E

PARTS

TUB ASSEMBL Y

5 9

7 8

10, 11

Solid State Thermostat

14, 11

16 17

31, 30

22 2321

25 27, 28

W-BRACKET, MOTOR MOUNT INNER

05700-004-13-09

F-BRACKET, MOTOR MOUNT OUTER

05700-004-13-08

LOCKNUT, 1/4-20

BOLT, 1/4-20 X 1/2"

05310-374-01-00

05305-274-02-00

WASHER, 1/4" I.D.X 3/4" O.D.

05311-011-76-30

07610-004-26-29-E

TUB ASSEMBL Y (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Tub Weldment 05700-002-12-59

2 1 Rack Assembly 05700-002-01-00

3 2 Bulk Head Plug 04730-609-05-00

4 1 See Page Entitled “Wash Motors” N/A

5 1 Gasket 05700-111-35-03

6 1 O-ring 05330-400-05-00

7 4 Bolt, Hex 3/8”-16 x 1 1/4" Long 05305-276-10-00

8 1 Lower Wash Manifold Weldment 05700-031-46-00

9 1 Suction Strain Weldment 05700-001-22-23

10 1 Suction Strain Bracket 05700-001-22-24

11 8 Locknut, 1/4"-20 with Nylon Insert 05310-374-02-00

12 1 Strainer Weldment 05700-003-07-76

13 1 Wash Overﬂ ow Weldment 05700-001-25-69

PARTS

* 1 Support, Ball Stop Lift 05700-002-91-55

* 1 Ball Stop Lift 05700-002-91-54

* 1 Shim, Overﬂ ow Support 05700-002-96-48

14 1 Overﬂ ow Support Bracket 05700-001-27-55

15 1 O-Ring 05330-400-05-00

16 2 Clamp, Hose 1 5/16” to 2 1/4” 04730-719-01-37

17 1 Discharge Hose 05700-011-88-24

18 1 Nipple 05700-021-34-84

19 1 Pump Support Bracket Assembly 05700-002-00-46

20 1 Clamp, Hose 5 5/8" to 6" 04730-011-34-90

21 1 Connector, 1/2” 90B 05975-111-01-00

22 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00

23 4 Lockwasher 3/8” 05311-276-01-00

24 1

25 1 Probe, High Water 06680-200-02-68

26 5 Locknut, 6-32 with Nylon Insert 05310-373-03-00

See Page Entitled “Wash Heaters/Rinse Heaters” See page 27 to order phase conversion kits for the heater.

N/A

27 4 Lockwasher, 5/16", S/S, Split 05311-275-01-00

28 4 Nut, Hex, 5/16"-18, S/S 05310-275-01-00

29 4 Locknut, 10-24 with Nylon Insert 05310-373-01-00

07610-004-26-29-E

PARTS

TUB ASSEMBL Y (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

30 1 Cover, Wash Heater 05700-031-47-57

31 1 Decal, Warning-Disconnect Power 09905-100-75-93

32 1 Decal, High Limit 09905-011-84-32

33 1 Thermostat Bracket 05700-011-81-64

34 1 Wash Heater Gasket 05330-011-47-79

35 1 Thermostat, Regulating 05930-510-02-79

Kit, Wash Thermostat Replacement

36 1 Thermostat, High Limit 05930-011-49-43

37 1 Fitting, 1/4" Imperial Brass 05310-924-02-05

38 1 Probe, Thermister 4” LG 06685-004-17-26

39 1 Thermostat Mounting Bracket 05700-004-22-17

(Includes: thermostat, brass ﬁ tting, 2 jumper wires & instruc- tions)

06401-003-18-22

40 1 Thermostat, Elan Electric Dual 06685-004-17-27

41 1 Harness, 5-Connector 05700-004-23-78

42 1 Harness, 4-Connector 05700-004-23-79

43 1 Harness, 2-Connector 05700-004-23-80

Magnetic Reed Switch

05930-003-05-84

Associated Hardware:

Lockwasher, #8 Internal Tooth 05311-272-03-00

Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00

Screw, 8-32 x 3/4" Round Head 05305-172-06-00

07610-004-26-29-E

Cover, Front Panel

05700-002-01-42

PARTS

FRAME ASSEMBL Y

Bullet Foot

05340-108-02-06

Bullet Foot

05340-002-14-55

Flange Feet

05340-002-01-15

07610-004-26-29-E

PARTS

RINSE TANK ASSEMBLY

COMPLETE ASSEMBLIES

230V, 14KW 70

◦

Rise - P/N 06401-004-19-57

240V, 12 KW 40◦ Rise - P/N 06401-004-19-55

410V, 12KW 40◦ Rise - P/N 06401-004-19-56

415V, 12KW 40◦ Rise - P/N 06401-004-19-54

SEE PAGE ENTITLED

"WASH HEATERS/RINSE HEATERS."

ITEM QTY DESCRIPTION PART NUMBER

1 1 Booster Tank Weldment 05700-002-10-19

2 2 Locknut, 10-24 with Nylon Insert 05310-373-01-00

3 2 Washer, #10 S/S Flat 05311-173-01-00

4 1 Decal, Warning-Disconnect Power 09905-100-75-93

5 1 Booster Tank Cover Weldment 05700-002-16-51

6 6 Nut, Hex, 5/16"-18 05310-275-01-00

7 1 Thermostat, High Limit 05930-011-49-43

8 1 Thermostat, Regulating with Imperial Brass Fitting 06401-011-66-55

9 6 Lockwasher, 5/16" Split 05311-275-01-00

10 1 Gasket, Rinse Heater 05330-200-02-70

11 4 Locknut, 1/4"-20 with Nylon Insert 05310-374-01-00

12 4 Washer, 1/4" S/S Flat 05311-174-01-00

13 1 Probe, Thermistor 4" LG 06685-004-17-26

07610-004-26-29-E

PARTS

PARTSPARTS

MOTORS — WASH HEATERS — RINSE HEATERS

VENTLESS RINSE TANK ASSEMBLY

COMPLETE ASSEMBL Y

P/N - 05700-004-21-95

(2 PLC'S)

(8 PLC'S)

(3 PLC'S)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Booster Tank Weldment - Ventless HH 05700-004-21-83

2 2 Gasket, Wash Heater 05330-011-47-79

3 1 Heater, 10KW 230V 04540-021-62-57

4 1 Probe, Thermistor 4" LG 06685-004-17-26

5 1 Booster Tank Cover 05700-004-21-94

6 1 Label, Disconnect Power Warning 09905-004-08-16

7 3 Nut, Lock 6-32 Hex w/ Nylon Insert 05310-373-03-00

8 8 Nut, Hex 5/16-18 S/S 05310-275-01-00

9 8 Lockwasher, Split 5/16 S/S 05311-275-01-00

10 1 Thermostat, 220D Hi-Limit 05930-011-49-43

11 1 Clamp 05975-601-10-15

12 1 Heater, 5.45KW 240V, Wash 04540-121-47-39

13 2 Nut, Lock 10-24 S/S Hex w/ Nylon Insert 05310-373-01-00

14 1 Fitting, Brass Nut Sleeve Fitting 05310-924-02-05

07610-004-26-29-E

PARTS

MOTORS — WASH HEATERS — RINSE HEATERS

The models covered in this manual come supplied with various wash motor assemblies (a wash motor assembly includes the wash motor and the pump end), depending on the characteristics of the machine. To ensure that the correct wash motor assembly is ordered for the model being serviced, refer to the following table:

MODEL VOLTS Hz PHASE

NOBLE HT-180 HH 415 50 3 06105-002-45-07

NOTE: When servicing a wash motor please refer to the wiring schematic found on the motor to ensure that it is wired

correctly. Different manufacturers use different wire color codes and your new motor may not connect using the same wires. Always refer to the diagrams on the motor you are installing. If the schematics have been removed from the motor you are installing, contact Noble Warewashing technical support immediately.

WASH MOTOR

ASSEMBLY

07610-004-26-29-E

PARTS

MOTORS — WASH HEATERS — RINSE HEATERS

The Noble models covered in this manual come supplied with various heaters, depending on the characteristics of the machine. To ensure that the correct heater is ordered for the model being serviced, refer to the following table:

MODEL V Hz PH

NOBLE HT-180 HH 415 50 3 04540-002-43-09 04540-002-43-10 N/A

NOBLE HT-180 HH 208 60 1 04540-121-47-39 04540-121-47-40 04540-121-63-38

NOBLE HT-180 HH 230 60 1 04540-121-47-39 04540-121-47-40 04540-121-63-38

NOBLE HT-180 HH 208 60 3 04540-121-47-39 04540-121-47-40 04540-121-63-38

NOBLE HT-180 HH 230 60 3 04540-121-47-39 04540-121-47-40 04540-121-63-38

NOBLE HT-180 HH 460 60 3 04540-121-65-99 04540-100-01-15 04540-121-63-39

WASH HEATER

ASSEMBLY

40°F RISE

RINSE HEATER

(12KW)

70°F RISE

RINSE HEATER

(14KW)

07610-004-26-29-E

PARTS

Y-STRAINER INCOMING & OUTLET PLUMBING ASSEMBLIES

07610-004-26-29-E

Y-STRAINER INCOMING & OUTLET PLUMBING ASSEMBLIES (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Fitting, Tee, 1/2” x 1/2” x 1/4” 04730-411-25-01

2 2 Adapter, 1/2” MNPT x CU Male 04730-011-59-53

3 1 Strainer, Y 1/2” 04730-217-01-10

4 1 Vave, Ball Test Cock 1/4” Bronze 04810-011-72-67

5 6 Adapter, 1/2” 04730-401-03-01

6 3 Union, 1/2” 04730-412-05-01

7 1 Bushing, HEX 3/4 MNPT-1/2 FNPT Brass 04730-002-56-27

8 3 F-Tube, Copper 1/2” x 2.5” 05700-002-17-38

9 2 F-Tube, Copper 1/2” x 37” 05700-003-60-80

10 1 F-Tubing, Copper 1/2” x 3” 05700-001-05-21

11 3 Elbow, 1/2" CU x CU, 90B 04730-406-01-01

12 2 F-Tube, Copper 1/2” x 2.406” 05700-003-60-79

13 1 F-Tube, Copper 1/2” x 3.5 05700-003-60-78

PARTS

14 1 Gauge 0-100# Pressure 06685-111-88-34

15 1 Valve, 1/2” 208-240 Red 04810-100-09-18

16 1 Vacuum Breaker, 1/2" NPT 04820-003-06-13

17 1 Adapter, Male 04730-401-03-01

18 1 F-Tube, Copper 1/2” x 30.75” 05700-003-60-81

19 1 Elbow, 1/2” NPT 90 Brass 04730-011-42-96

When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can cause leaks and loss of pressure, which could adversely effect the performance of the NOBLE HT-180 HH dishmachine. It is strongly recommended that teﬂ on thread tape, used in conservative amounts, be applied to threads when joining components together. It is not advised to use thread sealing compounds, sometimes referred to as “pipe dope”. Compounds can be ejected from the threads during the tightening process and become lodged in key components, thereby rendering them useless. Some of the components include the solenoid valve and the pressure gauge isolation ball valve

WPRK KIT OPTION

Water Arrestor, 1/2” 06685-100-05-00

Nipple, 1/2” NPT, Close, Brass 04730-207-15-00

Tee, 1/2” x 1/2” x 1/2” 04730-211-27-00

07610-004-26-29-E

PARTS

Y-STRAINER INCOMING & OUTLET PLUMBING ASSEMBLIES (NOBLE HT-180 HH)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Tee, Brass, 1/2" x 1/2" x 1/4" NPT 04730-411-25-01

2 3 Adapter, 1/2” MNPT x Cu Male 04730-011-59-53

3 1 Strainer, Y 1/2” 04730-217-01-10

4 1 Valve, Ball, Bronze, 1/4" NPT 04810-011-72-67

5 1 Adapter, 1/2” Male/Cu to MSPS 04730-401-03-01

6 1 Pressure Gauge, 0-100 PSI 06685-111-59-66

7 1 Valve, Solenoid, 1/2" NPT 208-240V 04810-100-09-18

8 1 Vacuum Breaker, 1/2" NPT 04820-003-06-13

9 1 Tube, Copper 1/2” x 5.75 05700-002-91-03

10 1 Union, 1/2” 04730-412-05-01

11 1 Elbow, 1/2” 90º Cu to MSPS 04730-406-32-01

07610-004-26-29-E

PARTS

PRESSURE REGULATOR INCOMING & OUTLET PLUMBING ASSEMBLIES

INCOMING PLUMBING

OUTLET PLUMBING

07610-004-26-29-E

PARTS

PRESSURE REGULATOR INCOMING & OUTLET PLUMBING ASSEMBLIES (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Water Pressure Regulator, 3/4" NPT 06685-011-58-22

2 1 Valve, Ball, 1/4" NPT 04810-011-72-67

3 1 Gauge, Pressure, 0-100 PSI 06685-111-88-34

4 2 Nipple, Close 3/4" NPT 04730-207-34-00

5 1 Tee, Brass, 3/4" NPT x 3/4" NPT x 1/4" NPT 04730-211-04-00

6 1 Valve, Solenoid, 3/4" NPT 04810-100-03-18

7 1 Nipple, Brass, 3/4" NPT x 2" Long 04730-207-46-00

8 1 Elbow, 3/4" NPT, Brass, Street 04730-206-04-34

9 3 Union, 3/4" NPT, Brass with O-Ring 05700-002-63-79

10 4 Adapter, 3/4" Male 04730-401-11-01

11 1 Tube, Copper, 3/4" x 48" Long 05700-011-87-89

12 2 Elbow, 3/4" 90°, #707 Copper 04730-406-16-01

13 3 Adapter, 3/4", 604-2 04730-401-10-01

14 1 Tube, Copper, 3/4" x 3 3/4" Long 05700-011-58-28

15 1 Vacuum Breaker, 3/4" NPT 04820-002-53-77

16 1 Tube, Copper, 3/4" x 44 3/8" Long 05700-002-25-05

17 1 Elbow, 3/4" 90° Copper to FSPS Brass 04730-406-41-01

18 1 Elbow, 3/4" 90° Copper to Copper Street 04730-406-40-01

2 Double Pipe Clamp (not shown) 05700-002-23-89

1 Bracket, Incoming Plumbing Support 05700-021-34-02

When servicing plumbing components, take care not to damage the threads of each individual item. Damaged threads can cause leaks and loss of pressure, which could adversely affect the performance of the dishmachine. It is strongly recommended that teﬂ on thread tape be applied conservatively to threads when joining components together. It is not advised to use thread sealing compounds, or "pipe dope," as they can be ejected from the threads during the tightening process and become lodged in key components.

Rinse Injector Weldment

1 per machine

05700-021-47-65

Plug, 1/8” NPT, Brass

3 per Rinse Injector

04730-209-07-37

07610-004-26-29-E

PARTS

PRESSURE REGULATOR INCOMING PLUMBING (NOBLE HT-180 HH)

81 9

4 5 6

ITEM QTY DESCRIPTION PART NUMBER

1 1 Vacuum Breaker, 3/4" NPT 04820-002-53-77

2 1 Elbow, Brass, Street, 3/4" NPT 04730-206-04-34

3 1 Nipple, Brass, 3/4" NPT x 3" Long 04730-011-38-29

4 1 Union, 3/4" NPT, Brass with O-Ring 05700-002-63-79

5 3 Nipple, Close, Brass, 3/4" NPT 04730-207-34-00

6 1 Valve, Solenoid, 3/4" NPT 04810-100-03-18

7 1 Tee, Brass, 3/4" NPT x 3/4" NPT x 1/4" NPT 04730-211-04-00

8 1 Pressure Gauge, 0-100 PSI 06685-111-59-66

9 1 Valve, Ball, Bronze, 1/4" NPT 04810-011-72-67

10 1 Water Pressure Regulator 06685-011-58-22

07610-004-26-29-E

PARTS

INCOMING PLUMBING (NOBLE HT-180 HH VENTLESS)

RINSE INJECTOR

09515-004-22-73

ITEM QTY DESCRIPTION PART NUMBER

1 1 Vac Breaker 1/2 Brass 04820-003-06-13

2 1 Elbow, 90 Degree 1/2 Street Brass 04730-206-08-00

3 1 W-Plumbing, Rinse Injector 05700-004-19-83

4 1 A-Plumbing, Outlet w/ Heat Exc. 05700-004-19-12

5 1 Hose, 1/2" ID X 24" LG Red 05700-004-19-89

6 1 Hose, 1/2" ID X 67" LG Red 05700-004-19-99

7 1 Hose, 1/2" ID X 69" LG Blue 05700-004-20-00

07610-004-26-29-E

INCOMING PLUMBING (NOBLE HT-180 HH VENTLESS)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Bushing, Hex 3/4"M to 1/2" Brass 04730-002-56-27

2 1 Elbow, 3/4 Street Brass 90 Degrees 04730-206-04-34

3 1 Union, 1/2" X 1/2" Brass 04730-003-62-44

PARTS

4 1 Tee, 1/2 FNPT X 1/2 FNPT 1/4 FNPT 04730-002-22-56

5 1 Nipple, Brass 1/2" X 4" NPT 04730-207-04-00

6 1 Fitting, 1/4 Barb 1/4 MNPT Swivel 04730-011-95-41

7 1 Nipple, Brass 1/2" X 2" Long Brass 04730-207-19-00

ITEM QTY DESCRIPTION PART NUMBER

1 1 Bushing, Hex 3/4"M to 1/2" Brass 04730-002-56-27

2 3 Elbow, 3/4 Street Brass 90 Degress 04730-206-04-34

3 1 Regulator, Pressure 3/4 06685-011-58-22

4 1 Nipple, 3/4 NPT X 1-3/8 Closed Brass 04730-207-34-00

5 1 Valve, 3/4" - 220V Solenoid 04810-100-03-18

6 1 Nipple, 1/2 Closed Brass 04730-207-15-00

7 Elbow, 90 Degree 1/2 Street Brass 04730-206-08-00

07610-004-26-29-E

PARTS

DRAIN QUENCH ASSEMBLY

Elbow, 1-1/2” 90 Street

04730-206-32-00

Nipple, 1-1/2” NPT

04730-207-40-00

Modified Compression

Fitting

05700-001-16-52

Drain Quench

Assembly

06401-002-59-52

Lid, Drain Quench 05700-002-67-16

Thermostat 05930-003-13-65

Reducer, 1-1/2” x 1/4”

04730-002-55-76

To Dishmachine Drain

Tee, 1-1/2” x 1-1/2” x 1-1/2”

04730-011-69-93

Reducer, 1-1/2” to 1/2” 04730-002-55-75

Valve, Check, 1/2” (Not Shown) 04820-002-55-77

Nipple, Close, 1/2” NPT (Not Shown) 04730-207-15-00

Solenoid Valve 04810-100-09-18

To Cold Water Supply

Box, Drain Quench 05700-002-69-96

From the existing drain, attach two additional Tees using the 1-1/2" NPT Close Nipples. Tighten the Reducers into the Tees as shown above. Attach the Modiﬁ ed Compression Fitting into the 1-1/2" to 1/4" Reducer. Position the bulb of the thermostat so that it rests approximately 1/4" from the bottom of the Tee. Tighten the Modiﬁ ed Compression Fitting as required. Attach to the incoming cold water line. Use thread tape as required to prevent any leaks.

07610-004-26-29-E

PARTS

3/4" SOLENOID VALVE & 3/4" VACUUM BREAKER REPAIR PARTS KITS

Data Plate

Valve Bonnet

Diaphragm

Retainer

Screen

Retainer

Screw

Coil & Housing

Spring 06401-003-07-40

Plunger 06401-003-07-40

O-Ring 06401-003-07-42

Diaphragm 06401-003-07-42

Data Plate

Cap Retainer

Components of Repair Kit

06401-003-06-24

Cap Screw

Cap

O-Ring

Plunger

Body

Mesh Screen

Valve Body

Complete 240 Volt Solenoid Valve Assembly

04810-100-03-18

Coil & Housing only

06401-003-07-44

1/2" Complete 240 Volt Solenoid Valve Assembly

(LT ONLY)

04810-003-71-56

Complete Vacuum Breaker Assembly

04820-002-53-77

07610-004-26-29-E

PARTS

WASH & RINSE ARM/MANIFOLD ASSEMBLIES

1 5

9, 18

6, 18

17, 8

2, 3, 4

2, 3, 19

07610-004-26-29-E

WASH & RINSE ARM/MANIFOLD ASSEMBLIES (CONTINUED)

ITEM QTY DESCRIPTION PART NUMBER

1 1 Upper Manifold 05700-031-34-82

2 4 Nut, 3/8"-16 S/S Hex 05310-276-01-00

3 4 Lockwasher, 3/8" 05311-276-01-00

4 2 Bolt, Hex 3/8"-16 x 7/8" Long 05306-011-36-95

5 2 O-Ring 05330-111-35-15

6 1 Positioning Bracket, Manifold Tube 05700-011-34-63

7 1 Tube, Wash Manifold 05700-031-92-58

8 2 Gasket, Manifold 05700-111-35-03

9 1 Wash Arm Assembly 05700-004-13-13

10 1 Bearing Assembly 05700-021-35-97

1 Wash Arm Assembly, 415V (not shown) 05700-021-63-81

1 Wash Arm Weldment, 415V 05700-021-63-42

1 Bearing Assembly, 415V 05700-021-63-80

PARTS

2 Rinse Arm Assembly 05700-002-58-09

11 2 Clip, Retaining, Rinse Head Bushing 05340-112-01-11

12 4 Washer 05330-011-42-10

13 2 Bushing, Rinse Head 05700-021-33-84

14 2 Rinse Arm 05700-031-49-58

15 4 Plug 04730-609-04-00

16 2 Bearing 03120-004-12-13

17 1 Lower Wash Manifold Weldment 05700-002-21-70

18 5 Locknut, 1/4"-20 S/S Hex with Nylon Insert 05310-374-01-00

19 1 Rinse Manifold Weldment 05700-002-01-19

20 2 Bolt, Hex 3/8"-16 x 1 1/4" Long 05305-276-10-00

21 1 Wash Arm, Double Assembly 05700-031-92-49

1 Wash Arm, Double Assembly, 415V (not shown) 05700-002-46-86

07610-004-26-29-E

PARTS

460 VOLT MACHINE TRANSFORMER MOUNTING BOX

07610-004-26-29-E

PARTS

EXHAUST FAN CONTROL OPTION

07610-004-26-29-E

PARTS

NOBLE HT-180 HH VENTLESS AND ENERGY RECOVERY SYSTEM ASSEMBLY

07610-004-26-29-E

NOBLE HT-180 HH VENTLESS AND ENERGY RECOVERY SYSTEM ASSEMBLY

ITEM QTY DESCRIPTION PART NUMBER

1 1 Coil, Heat Exchanger 04420-004-19-61

2 1 Inlet, Cold Water 05700-004-19-01

3 1 Ring, Water Inlet 05700-004-19-24

4 1 Plate, Fan Mounting 05700-004-18-07

5 1 Upper Shroud 05700-004-18-06

6 1 Exhaust Box 05700-004-18-04

7 1 Gasket, Heat Exchanger 05330-004-18-22

8 1 Gauge 06680-011-86-42

9 1 Coil Box Back 05700-004-18-03

10 12 Bolt, 1/4-20 X 3/8 Hex 05305-274-20-00

11 1 Bracket, Vacuum Breaker 05700-004-18-91

12 1 Shroud, Hear Exchanger 05700-004-18-92

PARTS

13 6 Nut, Lock 10-24 S/S Hex w/ Nylon 05310-373-01-00

14 6 Washer, Flat 05311-173-02-00

15 2 Fan, 3.62 Square, 85-236V AC Corrosion Resistant 05999-004-19-46

16 8 Screw, 6-32 X 1 1/2 Long 05305-003-11-33

17 4 Nut, Lock 1/4-20 Hex Nylon Insert 05310-374-01-00

07610-004-26-29-E

PARTS

NOBLE HT-180 HH VENTLESS DOOR INTERLOCK

ITEM QTY DESCRIPTION PART NUMBER

1 1 Guide Block, Door Lock 09330-004-22-72

2 1 F-Cover, Door Lock Mounting 05700-004-22-80

3 1 W-Rod, Interlock Weldment 05700-004-23-15

4 1 Soleniod, Horizontal 1" Push 04820-004-24-11

5 1 Spring, Comp. 05935-004-24-10

6 1 W-Base, Door Interlock Box 05700-004-24-25

7 8 Screw 3/8 Pan Head 05305-171-02-00

8 8 Washer, Flat #10 05311-173-02-00

9 2 Locknut, 1/4-20 05310-374-01-00

10 2 Washer, S/S 1/4-20 I.D. 05311-174-01-00

11 1 Fitg, 3216 Liqtite Blk 05975-011-59-50

12 2 Connector, 2-Conductor 05935-004-03-49

13 1 Cord, SJ 55" LG 05700-004-24-31

07610-004-26-29-E

PARTS

DOOR INTERLOCK/DOOR OVERRIDE INSTRUCTIONS

The following instructions are for NOBLE HT-180 HH models equipped with the Door Interlock option. These instructions should only be used if the door interlock fails to unlatch and the doors are unable to be opened.

1. To manually disengage, ﬁ nd the latch access hole.

2. Gently insert the tip of a screwdriver or other metal utensil into the access hole, making contact with the latching arm.

3. Disengage the interlock by pushing the latching arm back with a minimal amount of force.

4. The doors should now open.

07610-004-26-29-E
