AC Axial Fans
General Specications
Motor Structure: Shaded Pole Induction Motor
Motor Protection: Impedance Protection
Insulation Resistance:
10M Ω or over with a DC500V Megger
Dielectric Withstand Voltage: AC 700V 1s
Allowable Ambient Temperature Range:
-10°C ~ +70°C (Operating)
-40°C ~ +70°C (Storage)
(non-condensing environment)
Expected Life
Failure Rate: 10%
25°C 50,000 Hours
Material
Casing : Aluminum
Impeller : Polycarbonate (Glass Fiber-Containing)
Bearing : Ball Bearing
Lead Wire
: UL3266, CSA CL 1252, AWG22
Characteristic Curves
Outline
Panel Cut-Outs
inch
Units:
(mm)
Specications
Rated Frequency Starting Current Input Speed Max. Max. Static Noise Mass
MODEL Voltage Voltage Power Air Flow Pressure
3110PS-10W-B30-A00
3110PS-12W-B30-A00
Rotation: Counterclockwise Airow Outlet: Air Out Over Struts *1: Maximum Values in Free Air
*2: Average Values in Free Air
*3: Minimum Values in Free Air
3.4
(
100 60 65 0.080 5.0 3100 19.7 0.56 .21 53.9 33 220
115 60 65 0.075 5.0 3100 19.7 0.56 .21 53.9 33 220
V) (Hz)
100 50 65 0.090 6.0 2600 16.2 0.46 .15 39.2 28 220
115 50 65 0.085 6.0 2600 16.2 0.46 .15 39.2 28 220
(V)
(A)
*1
(W
+10%
)
(min-1)*3 CFM (m3/min)
- 20%
*3
in H2O (Pa)*3 (dB)*2 (g)
