Page 1
EMINEBEA.COM
Rotation: Counterclockwise Airfl ow Outlet: Air Out Over Struts *1: Average Values in Free Air
Units:
inch
(mm)
Rated Operating Current Input Speed Max. Max. Static Noise Mass
Voltage Voltage Power Air Flow Pressure
Product
(V) (V) (A)
*1
(W)
*1
(min
-1)*1
CFM
*1
(m3/min)
*1
O (Pa)
*1
(dB)
*1
(g)
No.
2410ML-04W-
B10
- X00 12 6.0 ~ 13.8 0.07 0.90 2950 13.7 0.39 .08 20.6 23.0 65
2410ML-04W-
B20
- X00 12 6.0 ~ 13.8 0.12 1.44 3600 16.9 0.48 .13 31.9 28.0 65
2410ML-04W-
B30
- X00 12 6.0 ~ 13.8 0.12 1.44 4000 19.0 0.54 .16 40.2 31.0 65
2410ML-04W-
B40
- X00 12 6.0 ~ 13.8 0.17 2.04 4550 21.5 0.61 .20 51.9 33.5 65
2410ML-04W-
B50
- X00 12 6.0 ~ 13.8 0.20 2.40 4900 23.3 0.66 .25 62.2 35.0 65
2410ML-04W-
B60
- X00 12 6.0 ~ 13.8 0.30 3.60 5300 25.0 0.71 .29 73.0 36.0 65
2410ML-04W-
B70
- X00 12 6.0 ~ 13.8 0.44 5.28 6800 33.1 0.94 .50 125 45.0 65
2410ML-04W-
B80
- X00 12 6.0 ~ 13.2 0.52 6.20 7800 37.0 1.05 .57 142.5 46.0 65
2410ML-05W-
B10
- X00 24 10.0 ~ 27.6 0.06 1.44 2950 13.7 0.39 .08 20.6 23.0 65
2410ML-05W-
B20
- X00 24 10.0 ~ 27.6 0.07 1.68 3600 16.9 0.48 .13 31.9 28.0 65
2410ML-05W-
B30
- X00 24 10.0 ~ 27.6 0.06 1.44 4000 19.0 0.54 .16 40.2 31.0 65
2410ML-05W-
B40
- X00 24 10.0 ~ 27.6 0.09 2.16 4550 21.5 0.61 .20 51.9 33.5 65
2410ML-05W-
B50
X00 24 10.0 ~ 27.6 0.10 2.40 4900 23.3 0.66 .25 62.2 35.0 65
2410ML-05W-
B60
- X00 24 10.0 ~ 27.6 0.13 3.12 5300 25.0 0.71 .29 73.0 36.0 65
2410ML-05W-
B70
- X00 24 10.0 ~ 25.2 0.19 4.56 6800 33.1 0.94 .50 125 45.0 65
Casing : Plastic (Black) 94V-0
Bearing : Ball Bearing
Lead Wire
: UL1007, AWG24, +Red, -Black
0
0.1
0.2
3.5
.04
.08
.16
.20
.24
.28
.32
.36
.40
.44
.48
.52
.56
.60
7.0
10.6
17.62831.7
34
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
10
20
30
40
50
60
70
80
90
100
110
120
130
140
150
Ps
(Pa)
Air Flow
(m3/min)
B10
B20
B30
B40
B50
B60
B70
B80
CFM
In H2O
Rib Type
.169
4 – (φ4.3)
1.97
(
50.0
0.3
)
2.36
(
60.0
±
0.3
)
ROTATION
.98
(
25
+0.5
)
(
φ
)
(
(
φ
)
2.25
(57.0)
1.97
(50.0)
2.25
(57.0)
1.97
(50.0)
All Class: -40°C ~ +70°C (Storage)
AC 700V 1s
Auto Restart/Polarity Protection
2410ML (60
X
L
)
25
MODEL
