SP10000 Mk.2
WARNING: Parts of this circuit are at mains live potential
R1 33
R2 33
R3 33
R4 33
R5 330
R6 22k
R7 22k
R8 22k
R9 22k
R10 22k
R11 2.2k
R12 22k
R13 22k
R14 22k
R15 22k
R16 22k
R17 22k
R18 22k
R19 100
R20 100
R21 100
R22 100
D6 BZX55C 10V
D7 1N4004
D8 1N4148
D9 Red LED
CSR3 BTA16-600B
CSR4 BTA16-600B
TR1 BC182LB
C3 100nF ceramic
D1 1N4004
D2 1N4004
D3 1N4004
D4 1N4004
D5 Green LED
D12 Red LED
IC1 TIL199
IC2 7805
IC3 74HC163
CSR1 BTA16-600B
CSR2 BTA16-600B
FS1 F250mA
FS2 F10A
FS3 F10A
FS4 F10A
FS5 F10A
C1 2200µF 25V
C2 1000µF 25V
D10 Red LED
D11 Red LED
D8
TR1
R14
R15R16R17R18
T1 15-0-15V 3VA
T2 4.5-0-4.5V 3VA
T2
R11
INPUT 3
INPUT 4
R10
D6
C3
INPUT 2
R9
INPUT1
R8
+10V
R7
C2
D5
ENABLE
R6
D3
D4
R5
+15V
D7
IC2
C4
R12
R13
NEUTRAL - Electronics Supply
LIVE - Electronics Supply
FS1
T1
C1
R1
IC1a
OUTPUT 1
FS2
R2
IC1b IC1c IC1d
FS3
OUTPUT 2
D1 D2
CSR1
CSR2 CSR3
© N.J.D. Electronics 1994.
IC1a IC1b
IC1c IC1d
D9 D10 D11 D12
R22
OUTPUT 3
FS4
OUTPUT 4
FS5
R3
R4
CSR4
LIVE - Controlled Supply
IC3
R19
R21
R20
