QUASAR HX
ON 99F3
0-+10V ANALOGUE
INPUTS
R31
R17
R32
D7
IC12
D1
D2
C1
FS2
TO
99F2
C24
MIDI
IN
THROUGH
MIDI
R30
R29
R28
R27
D8
D9
C23
+12V OUTPUT
DMX
INPUT
R22
R21
D3
D4
C2
R33
IC11
IC1
FS1
99F2
TO
T1
R13
IC10
IC3
IC4
CSR1
C21
R19
D5
D6
C18
C4
M1 M2
C7
LA1
D6
D7
D8
C5
C3
C6
R1
R2
C8
R3
ON 99F3
IC8
C20
C19
X1
IC10
IC9
C22
R20
R16
R15
IC2
TR1
R18
R31h
© N.J.D. Electronics 2002
R12
R32h
M6
R14
C26
MIC1
TR2
R11
R24
R25
R26
C25
R4
C11
C9
R6
C14 C17
C12 C15
R8
R10
C10
R5
IC5
R7
IC6
R9
IC7
M3
C13
M4 M5
C16
QUASAR HX
R18 4.7k ¼W
R19 470 ¼W
R20 470 ¼W
R21 PTC 45 265V
R22 PTC 45 265V
R24 1M ¼W
R25 4.7k ¼W
R26 12k ¼W
R27 4.7k ¼W
R28 220 ¼W
R29 220 ¼W
R30 220 ¼W
R31 22k × 8 SIL
R32 22k × 8 DIL
R33 PTC 10 30V
C18 4700µF 50V
C19 15pF 100V ceramic
C20 15pF 100V ceramic
C22 100nF 50V ceramic
C23 100nF 50V ceramic
C24 10µF 16V
C25 10µF 16V
C26 470nF 63V
C27 100nF ceramic
R10 1.5 ½W
R11 47 2W
R12 470 ¼W
R13 4.7k ¼W
R14 150k ¼W
R15 2.2k ¼W
R16 2.2k ¼W
R17 10k ¼W
C10 1µF 50V ceramic
C11 2.2nF 100V mylar
C12 100nF 50V ceramic
C13 1µF 50V ceramic
C14 2.2nF 100V mylar
C15 100nF 50V ceramic
C16 1µF 50V ceramic
C17 2.2nF 100V mylar
R2 1.5 ½W
R3 1.5 ½W
R4 1.5 ½W
R5 1.5 ½W
R6 1.5 ½W
R7 1.5 ½W
R8 1.5 ½W
R9 1.5 ½W
C2 4700µF 25V
C3 100nF 50V ceramic
C4 1µF 50V ceramic
C5 2.2nF 100V mylar
C6 100nF 50V ceramic
C7 1µF 50V ceramic
C8 2.2nF 100V mylar
C9 100nF 50V ceramic
R1 1.5 ½W
C1 4700µF 25V
IC8 PIC17C762-33L
IC9 TIL194
IC10 TLP523
IC11 75176
IC12 H11L1
© N.J.D. Electronics 2002
IC3 TCA3727
IC4 TCA3727
IC5 TCA3727
IC6 TCA3727
IC7 TCA3727
TR1 BC639
TR2 BC547B
CSR1 BTA16-600BW
IC1 7805
IC2 24C00
M6 24V DC 80mm FAN
D1 1N4004
D2 1N4004
D3 1N4004
D4 1N4004
D5 KBL01
D6 1N4004
D7 1N4148
D8 BZT03C 7V5
D9 BZT03C 7V5
FS1 T1.6A 5×20mm
FS2 T1.6A 5×20mm
LA1 A1/259
MIC1 ECM60P
M1 Bipolar stepper motor
M2 Bipolar stepper motor
M3 Bipolar stepper motor
M4 Bipolar stepper motor
M5 Bipolar stepper motor
QUASAR HX
© N.J.D. Electronics 2002
R1 270k ¼W
R2 270k ¼W
R3 12k ¼W
R4 12k ¼W
R5 12k ¼W
R6 3.3k ¼W
R7 12k ¼W
R8 270k ¼W
R9 270k ¼W
R10 100 2W
R11 22k × 8 DIL
QUASAR HX
R14 220 ¼W
R15 220 ¼W
R16 330 × 8 DIL
R17 3.3k ¼W
R18 3.3k ¼W
R19 3.3k ¼W
R20 470 ¼W
C3 100nF 63V polyester
C4 1µF 50V ceramic
C5 100nF 63V polyester
C6 100nF 63V polyester
C7 1µF 50V ceramic
C8 1µF 50V ceramic
C9 100nF 63V polyester
C10 15pF 100V ceramic
C11 15pF 100V ceramic
C13 100nF 50V ceramic
C14 100nF 50V ceramic
C15 2200µF 25V
C16 2200µF 25V
C17 220µF 16V
-15V
C12
R12 3.3k ¼W
R13 3.3k ¼W
C1 1µF 50V ceramic
C2 1µF 50V ceramic
R12
C11 C10
C13
R13
R20
X1
R14
R15
C12 100nF 50V ceramic
DATA in
S1
S2
IC6
R16
R19
R18
R17
TR9
+15V
R10
7-segment
Display
IC3
IC5
TR10
TR11
D1
C14
R6
C17
C15
C2 C8
TR1 2SB1144
TR2 2SD1684
TR3 2SD1684
TR4 2SB1144
TR5 2SB1144
TR6 2SD1684
TR7 2SD1684
© N.J.D. Electronics 2002
TR8 2SB1144
IC1 LM358
IC2 LM358
IC3 TLC5620
IC4 LM385-1.2
IC5 LM385-1.2
IC6 PIC16C62
M1 Bipolar stepper motor
M2 Bipolar stepper motor
TR8
R7
IC4
C16
M2
R11h
R17
TR7
R11g
C9
R9
TR5
IC2
R11f
R5
TR6
R11e
C6
R8
TR4
M1
R11d
R4
TR3
R11c
R2
C5
TR1
IC1
R11b
R3
TR2
R11a
C3
R1
C1
C7
C4
QUASAR HX
© N.J.D. Electronics 2002
