NITECORE MT40 User Manual

®

ALL-ROUND Flashlight Expert

Features

• LED Premium CREE XM-L U2 LED

• Maximum output of up to 860 lumens

• High efficiency current circuit board

• Maximum runtime of up to 24 hours

• Two rapid switching modes suit various user requirements.

• User-defined mode allows for customized brightness levels and a
multitude of functions

• Intelligent memory functions

• Anti-rolling design

• Reverse polarity protection

• Broad voltage drive circuit, compatible with rechargeable and
non-rechargeable Li-ion batteries.

• Toughened ultra-clear mineral glass with anti-reflective coating

• Aluminum reflector ensures a smooth and powerful beam

• Aero grade aluminum alloy

• HA III Military grade hard anodized

• Detachable two-way anti-rolling clip

• Purpose-made rhombic knurling for better grip

• IPX-8 standard waterproof (submersible to two meters)

Dimensions

Length: 221.5mm (8.72”)
Head Diameter: 50mm (1.97”)
Tail Diameter: 25.4mm (1”)
Weight: 245grams (8.64oz)(without battery)

Battery Options

Primary Lithium battery

18650 Rechargeable Li-ion battery

Rechargeable Li-ion battery

Accessories

Clip, tactical ring, lanyard,
quality holster, spare plastic cap,
and spare O-ring

SIZE

CR123 3V

18650 3.7V

RCR123 3.7V

Nominal voltage

Compatible

Y (Recommended)

Y (Recommended)

Y

Brightness & Runtime

TURBO HIGH MID LOW

860

LUMENS

18650

1h30

2×CR123

1h30

NITECORE (SYSMAX) is a member of PLATO, participating in and helping to develop

the ANSI FL1 standard of measurement. Product testing data is in accordance with

these internationally recognized scientific standards.

530

LUMENS

min3h30min7h30min

min2h45min6h30min18h30min

363m

33000cd

1.5m

IPX-8, 2m

280

LUMENS

(Beam Distance)

(Peak Beam Intensity)

(Impact Resistant)

(Waterproof AND Submersible)

NOTICE

100

Stated data has been

LUMENS

measured according to

the international flashlight

24

h

testing standards

ANSI/NEMA FL1 using

two quality NITECORE

18650 (3.7V 2600mAh)

batteries or four SYSMAX

CR123 (3V 1550mAh)

batteries under laboratory

conditions. The data may

vary due to individual

usage habits and

environmental conditions.

Operation instructions

Battery installation (as the picture shows)

1. Unscrew the tail cap in a counter-clockwise direction.

2. Insert two 18650 batteries or four CR123 batteries with the positive pole

pointing forward (toward the light head).

User Manual

Switching ON/OFF

Switch ON: Press the button on the tailcap until a “click” is heard.
Switch OFF: Press the button at the tailcap until a second time until a “click” is
heard.

Mode Switching

The Nitecore MT40 has two modes: Turbo and user-defined. These two modes
can be changed by simply tightening and loosening the flashlight head. Turbo
provides 100% output while user-defined users contains five selectable
sub-modes.

Turbo Mode

Turbo mode is accessed when the MT40 flashlight is switched ON and the
head lightly tightened. While in this mode, momentary illumination can be
achieved by switching off the flashlight and then half pressing and holding the
switch. Momentary illumination can be used as a flashing signal indicator or
apply to various tactical applications.

User-Defined Mode

User-defined mode is accessed by slightly loosening the flashlight head. In this
mode, lightly and rapidly pressing the switch will cycle through brightness and
other functions in the following order: “High-Mid-Low- SOS-Strobe”. Pressing
the switch all the way down will save and memorize a desired setting.

Tips: Make NITECORE MT40 your perfect multi-task flashlight.

NITECORE MT40 flashlights essentially have two modes: Turbo mode (100%
output) and custom mode. Turbo mode is accessed by tightening the flashlight
head while any of one of the four customizable modes (strobe, low, medium
and high) are selected by loosening the head and rapidly pressing the on/off
switch to cycle through the modes. A given mode can be saved by simply turn
off the light while in that mode. Real-world examples include: When used as a
flashlight around the home, the head can be loosened and low level selected in
custom mode, providing long runtimes at a lower light intensity. The same
flashlight could then be taken out and used a law-enforcement duty light, with
user-defined mode set in strobe, making it easy to alternate between turbo
mode and strobe with a simple twist of the flashlight head.

Maintenance

Every 6 months, threads should be wiped with a clean cloth followed by a thin
coating of silicon-based lubricant.

Warranty Service

All NITECORE® products are warranted for quality. DOA / defective products
can be exchanged for replacement though a local distributor/dealer within the
14 days of purchase. After 14 days, all defective / malfunctioning NITECORE®
products will be repaired free of charge for a period of 18 months from the date
of purchase. After 18 months, a limited warranty applies, covering the cost of
labor and maintenance, but not the cost of accessories or replacement parts.
The warranty is nullified in all of the following situations:

1. The product(s) is/are broken down, reconstructed and/or modified by
unauthorized parties.

2. The product(s) is/are damaged through improper use.

3. The product(s) is/are damaged by leakage of batteries.

For the latest information on NITECORE® products and services, please
contact your national NITECORE® distributor or send an email to
[e-mail]

Please follow our facebook for more info: NITECORE Flashlights

WARNING

Ensure batteries are inserted
with the positive (+) end
pointing to the head. The
MT40 will not operate with
incorrectly inserted batteries.

SYSMAX Industry Co., Ltd.

TEL: [phone]
FAX: [phone]
E-mail: [e-mail]
Web: www.nitecore.com
Address： Rm1407-08, Glorious Tower, 850 East Dongfeng Road,

Guangzhou, China 510600

Thanks for purchasing NITECORE!
