Ninja QB1004 User Manual

®
Master Prep® Professional
OWNER’S GUIDE
QB1004
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING YOUR NINJA® MASTER PREP® PROFESSIONAL.
POLARIZED PLUG
WARNING: To reduce the risk of electric
shock, this appliance has a polarized plug (one blade is wider than the other). This plug will fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician to install the proper outlet. DO NOT
modify the plug in any way.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:
1. Close supervision is necessary when any appliance is used by or near children.
2. To protect against electric shock, DO NOT immerse cord, plug or any part of the main unit in water or any other liquids.
3. DO NOT let cord hang over edge of table or counter, or touch hot surfaces.
4. DO NOT operate any appliance with a damaged cord or plug, or after the appliance malfunctions, has been dropped or damaged in any manner. Return the appliance to EURO-PRO Operating LLC for examination, repair or adjustment.
5. Unplug appliance from outlet when not in use and before cleaning.
6. DO NOT place on or near a hot gas or electric burner.
7. The use of accessory attachments, including canning jars not recommended by EURO-PRO Operating LLC may cause fire, electrical shock or risk of personal injury.
8. Extreme caution must be used when moving an appliance containing hot food, water or other liquids.
9. Use this appliance on a stable work surface away from water.
10. DO NOT remove the motor head before the chopping blades have stopped turning.
11. CAUTION! Chopping blades are sharp, handle with care. When handling the chopping blades, always hold by the plastic shaft.
12. DO NOT attempt to sharpen blades.
2
TOLL FREE: 1-877-646-52882
13. DO NOT expose jars to extreme temperature changes.
14. DO NOT use jars if they are cracked or chipped.
15. DO NOT use the appliance if chopping blades are bent or damaged.
16. Avoid contact with moving parts at all times. Keep hands, hair, clothing as well as spatulas and other utensils away from pitcher or chopping container during operation to prevent risk of personal injury and/or damage to the appliance.
17. Exercise extreme caution when blending hot liquids.
18. Immediately release the On/Off pulse button on the motor head in the event that the appliance malfunctions during use.
19. To reduce the risk of injury, NEVER operate the appliance without the splash guard in place; DO NOT try to defeat the interlock mechanism; make sure that the cutting blades are properly assembled before operating the appliance.
20. DO NOT use outdoors.
21. DO NOT use appliance for other than intended use.
22. DO NOT operate the appliance for more than 15 seconds.
23. DO NOT operate the appliance empty.
24. If the appliance overheats, a thermal switch will become activated and shut off the motor. To reset, unplug the appliance and let it cool down for approximately 10 minutes before using again.
NOTE: This unit has a short power supply cord
to reduce the risk resulting from becoming entangled in or tripping over a long cord. An extension cord may be used if you are careful in its use.
1. If using an extension cord, the electrical rating of the extension cord should be rated at least 15 amperes. Extension cords rated for less amperage may overheat.
2. An extension cord must be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over accidentally.
SAVE THESE INSTRUCTIONS
www.ninjakitchen.com
3
THIS BOOK COVERS MODEL NUMBER:
QB1004 30
TECHNICAL SPECIFICATIONS
Voltage: 120V., 60Hz.
Power: 450 Watts
Pitcher Capacities: 1.5 L (48 ounces) (6 cups)
1.2 L (40 ounces) (5 cups)
Bowl Capacity: 500 ml (16 ounces) (2 cups)
Euro-Pro, Ninja and Master Prep are trademarks of Euro-Pro Operating LLC.
TOLL FREE: 1-877-646-52884
Contents
Thank you for purchasing the Ninja® Master Prep® Professional.
Getting Started ......................................................................................................6
Using the Master Prep® Professional Pitchers ..........................................................8
Using the Master Prep® Professional Bowl ...............................................................10
Cleaning and Maintenance .....................................................................................12
Troubleshooting Guide ............................................................................................12
Warranty ...............................................................................................................13
www.ninjakitchen.com
5
Getting Started
a
b
c
d
k
e
h
l
m
f
i
n
g
j
g
g
o
a On/Off Pulse Button
b Power Head
c Pouring Spout
d Pitcher Splash Guard
®
e Ninja
6-Blade
f Master Prep
®
Professional 48 oz. Pitcher
with Non-Slip Base
g Spindle Pin
®
h Ninja
4-Blade
i Master Prep® Professional 40 oz. Pitcher with Non-Slip Base
j Pitcher Storage Lid
k Bowl Splash Guard
l Upper Blade
m Lower Blade
n Master Prep
®
Professional Bowl with Non-Slip Base
o Bowl Storage Lid
p Power Cord (not shown)
TOLL FREE: 1-877-646-52886
The Ninja® Master Prep® Professional is an indispensable kitchen tool that is perfect for blending, chopping, mixing or pureeing when preparing your favorite recipes. For best results, be sure to carefully read all the instructions contained in the manual before using this appliance.
450 Watt Power Head
The 450 watt power head operates on 120V., 60Hz. electrical power. NEVER allow the power head to become wet when plugged into an electrical outlet.
WARNING: The power head should never be immersed in water or any other liquid.
CAUTION: Make sure that the power head is unplugged from the electrical outlet and that the blades have stopped
turning before attaching or removing any accessory.
CAUTION: Blades are sharp! Use extreme caution when handling the blades. Always hold them by the
shaft. Do not attempt to sharpen blades.
IMPORTANT: Never run the appliance empty.
www.ninjakitchen.com
7
Using the Master Prep® Professional Pitchers
Shaft
3
1 2
CAUTION: Blades are sharp! Use extreme caution
when handling the blades. Always hold them by the shaft.
IMPO RTANT: Never run the appliance empty.
1 Place the Master Prep
®
Professional Pitcher on a clean,
dry, level surface.
2 Holding the blade by the shaft, place it onto the spindle
pin inside the Master Prep
• Use the Ninja
• Use the Ninja
®
6-Blade in the 48 oz. Pitcher. (fig. 1)
®
4-Blade in the 40 oz. Pitcher. (fig. 2)
IM POR TA N T: Place blade inside the container carefully
as blades are sharp.
®
Professional Pitcher.
WARNING: DO NOT try to place the blade onto
the power head and then into the Master Prep® Professional Pitcher.
Shaft
TOLL FREE: 1-877-646-52888
4 5
3 Add the ingredients to be processed into the Master
Prep® Professional Pitcher.
IM POR TA N T: Never add ingredients into the Master
Prep® Professional Pitcher before placing the blades in first.
4 Place the pitcher splash guard onto the top of the
Master Prep
®
Professional Pitcher. (fig. 3)
5 Place the power head on top of the pitcher splash
guard making sure that it is securely in place. (fig. 4) DO NOT attempt to operate the appliance without the safety splash guard in place.
6 To start the appliance, plug the power cord into the
electrical outlet, securely hold power head while operating and press on the on/off pulse button located on the top of the power head. (fig. 5)
7 Hold the Master Prep
®
Professional Pitcher firmly while depressing the on/off pulse button to ensure the unit stays in place.
NOTE: DO NOT operate the appliance continuously for
more than 15 seconds at a time.
8 To stop the appliance, remove your fingers from the on/
off pulse button.
9 In order to obtain a better quality of chopping, operate
the appliance by using the “pulse” method.
10 Make sure that the blades have stopped completely
before removing the power head.
11 If the ingredients stick to the side of the Master Prep
®
Professional Pitcher, stop the appliance, remove the power head and the splash guard. Use a spatula to dislodge the pieces and then replace the splash guard and the power head. Continue processing.
12 Depending on the consistency of the contents, use the
pouring spout to empty liquid contents.
13 For thicker consistencies, first remove splash guard and
blade (by its shaft), then empty contents of the Master
®
Prep
Professional Pitcher.
HINTS & TIPS FOR USING YOUR NINJA
®
MASTER
PREP® PROFESSIONAL
• To crush ice into snow, start by using short pulses to break up large chunks. Continue until snow is achieved.
www.ninjakitchen.com
9
Using the Master Prep® Professional Bowl
Shaft
21
CAUTION: Blades are sharp! Use extreme caution
when handling the blades. Always hold them by the shaft.
IM POR TA N T: Never run the appliance empty.
WARNING: DO NOT crush ice in 16 oz. Chopper bowl
or damage may occur to the unit.
1 Place the Master Prep
®
Professional bowl on a clean,
dry, level surface.
2 Holding the lower blade by the shaft, place it over the
spindle pin inside the Master Prep
®
Professional bowl.
(fig. 1)
3 Carefully insert the upper blade over the lower blade
rotating it until it locks onto the lower blade. (fig. 2)
IM POR TA N T: Always assemble the blades inside the
container.
TOLL FREE: 1-877-646-528810
WARNING: DO NOT try to place the blades onto
the power head and then into the Master Prep® Professional bowl.
4 Place the food that you want to process into the Master
®
Prep
Professional bowl.
IM POR TA N T: Never add ingredients into the Master
Prep® Professional bowl before placing the blade assembly in first.
NOTE: DO NOT add more than 2 cups dry or 1 cup
liquid ingredients as this will strain the motor and may cause overflow.
4 53
5 Place the splash guard on the bowl. (fig. 3)
6 Place the power head on top of the splash guard
making sure that it is securely in place. (fig. 4) DO NOT attempt to operate the appliance without the
safety splash guard in place.
7 To start the appliance, plug the power cord into the
electrical outlet, securely hold power head while operating and press on the on/off pulse button located on the top of the power head. (fig. 5)
8 Hold the Master Prep
®
Professional bowl firmly while depressing the on/off pulse button to ensure the unit stays in place.
NOTE: DO NOT operate the appliance continuously for
more than 15 seconds at a time. Be careful not to over process. For coarsely chopped foods, use repeated short pulsing action until the desired consistency is reached.
9 To stop the appliance, remove your fingers from the on/
off pulse button.
10 In order to obtain a better quality of chopping, operate
the appliance by using the “pulse” method.
11 Make sure that the blades have stopped completely
before removing the power head.
12 If the ingredients stick to the side of the Master Prep
Professional bowl, stop the appliance, remove the power head and the splash guard. Use a spatula to dislodge the pieces and then replace the splash guard and the power head. Continue processing.
13 Remove the blade assembly by its shaft before you
empty the contents of the Master Prep
®
Professional
bowl.
HINTS & TIPS FOR USING YOUR NINJA
®
MASTER
PREP® PROFESSIONAL
• The chopping blades can be used for chopping meat, fish, vegetables, cheese etc.
• For mincing, chopping and pureeing, increase the length of pulses.
• For coarse chopping, use short, quick pulses and monitor food texture.
• Pre-cut larger pieces to make them fit into the Master
®
Prep
Professional. When chopping hard foods (e.g.
meat, cheese) cut into 1-inch cubes.
®
www.ninjakitchen.com
11
Cleaning and Maintenance
CAUTION: Make sure that the power head is unplugged from power source before inserting or removing any attachment
and before cleaning.
DO NOT immerse the power head into water or any other liquid. Clean with a damp sponge or cloth and wipe dry.
The Master Prep
guards and chopping blades are all dishwasher safe. It is recommended to place the storage lids and the chopping blades on the top rack. Use extreme caution when handling the chopping blades as they are very sharp.
Clean the Ninja
®
Professional pitchers, Master Prep® Professional bowl, storage lids, Master Prep® Professional splash
®
Master Prep® Professional and all parts before first use and immediately after each use.
Troubleshooting Guide
PROBLEMS POSSIBLE REASONS & SOLUTIONS
Check that the bottom of motor head is clean and there is no food blocking
connection when placing on containers.
There is too much food in the container.
Motor Doesn’t Start or Blades Don’t Rotate.
The unit has overheated. Unplug and wait approximately 10 minutes before
using again.
Make sure the splash guard is securely on container.
Make sure the power head is securely placed on splash guard.
Check that the plug is securely inserted into the electrical outlet.
Check fuse or breaker. Replace fuse/reset breaker.
Either you are chopping too much food at one time, or the pieces are not
Food is Unevenly Chopped.
Food is Chopped Too Fine or is Too Watery.
small enough. Try cutting the food into smaller pieces of even size and processing smaller amounts per batch.
The food has been over processed. Use brief pulses or process for shorter
time. Let blades stop completely between pulses.
Food Collects On Splash Guard/Safety Cover or On the Sides of the Master Prep® Professional Pitchers or Master Prep® Professional
You may be processing too much food. Turn the machine off. When the
blades stop rotating, remove the power head and the splash guard. Remove some of the food being processed.
Bowl.
You Cannot Achieve Snow From Solid Ice.
Do not use ice that has been sitting out or has started to melt. Be sure to
use short pulses in the beginning to break up large pieces.
To purchase replacement parts, please visit our website: www.ninjakitchen.com
or contact customer service: 1-877-646-5288.
TOLL FREE: 1-877-646-528812
ONE (1) YEAR LIMITED WARRANTY
EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for a period of
one (1) year from the date of purchase when utilized for normal household use, subject to the following conditions, exclusions and exceptions.
The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option. This Limited Warranty does not cover normal wear of parts and does not apply to any unit that has been tampered with or used for commercial purposes. This Limited Warranty does not cover damage caused by misuse, abuse, negligent handling or damage due to faulty packaging or mishandling in transit. This Limited Warranty does not cover damage or defects caused by or resulting from damages from shipping or repairs, service or alteration to the product or any of its parts, which have been performed by a repair person not authorized by EURO-PRO Operating LLC.
If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return the complete appliance and accessories, freight prepaid. For assistance with warranty service options or customer support, please call our customer care and product specialists at, call 1 (877) 646-5288 or visit our website www.ninjakitchen.com.
If the appliance is found to be defective in material or workmanship, EURO-PRO Operating LLC will repair or replace it free of charge. Proof of purchase is required and a fee of $19.95 will apply to cover the cost of return freight.*
This Limited Warranty is extended to the original purchaser of the unit and excludes all other legal, implied and/or conventional warranties. The responsibility of EURO-PRO Operating LLC if any, is limited to the specific obligations expressly assumed by it under the terms of this Limited Warranty. In no event is EURO-PRO Operating LLC liable for incidental or consequential damages to anyone of any nature whatsoever. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
This Limited Warranty gives you specific legal rights, and you may also have other rights which vary from state to state or from province to province.
*IMPORTANT: Carefully pack item to avoid damage in shipping. Be sure to include proof of purchase date and to attach tag to item before packing with your name, complete address and phone number with a note giving purchase information, model number and what you believe is the problem with the item. We recommend you insure the package (as damage in shipping is not covered by your Limited Warranty). Mark the outside of your package “ATTENTION CUSTOMER SERVICE”. We are constantly striving to improve our products, therefore the specifications contained herein are subject to change without notice.
Product Registration
Please visit www.ninjakitchen.com or call 1-877-646-5288 to register your new Ninja® product within ten (10) days of purchase. You will be asked to provide the store name, date of purchase and model number along with your name and address.
The registration will enable us to contact you in the unlikely event of a product safety notification. By registering you acknowledge to have read and understood the instructions for use, and warnings set forth in the accompanying instructions.
www.ninjakitchen.com
13
Notes
TOLL FREE: 1-877-646-528814
Notes
www.ninjakitchen.com
15
Euro-Pro Operating LLC US: Newton, MA 024 59 CAN: Ville St-Laurent, QC H4S 1A7
1-877-646-5288
www.ninjakitchen.com
Copyright © Euro-Pro Operating L LC 2014
Euro-Pro and Ninja are trademarks of Euro-P ro Operating LLC.
Illustrations may differ from actual product.
QB1004.30.E.140306.3
Loading...
