Page 1

FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER

OP401

OWNER’S GUIDE

ninjakitchen.com

Page 2

THANK YOU

for purchasing the Ninja® Foodi® Deluxe TenderCrisp™ Pressure Cooker

registeryourninja.com

Scan QR code using mobile device

RECORD THIS INFORMATION

Model Number: �� Serial Number: �� Date of Purchase: ��

(Keep receipt) Store of Purchase: ��

TECHNICAL SPECIFICATIONS

Voltage: 120V~, 60Hz Watts: 1760W

TIP: You can ﬁnd the model and serial numbers on the QR code label located on the back of the unit by the power cord.

CONTENTS

Important Safeguards ..................................2

Parts & Accessories ....................................6

Using the Control Panel ................................8

Function Buttons ........................................8

Operating Buttons .......................................8

Before First Use .......................................9

Installing the Condensation Collector ......................9

Removing & Reinstalling the Anti-Clog Cap .................9

Using Your Foodi® Deluxe TenderCrisp™ Pressure Cooker ..10

Swap the Top ...........................................10

Using the Crisping Lid ................................... 10

Using the Cooking Functions with the Crisping Lid ......... 10

Air Crisp ............................................ 10

Bake/Roast ..........................................11

Broil .................................................12

Dehydrate ...........................................13

Familiarizing Yourself With Pressure Cooking .............. 14

Natural Pressure Release vs. Quick Pressure Release .........15

Pressurizing .............................................15

Installing & Removing the Pressure Lid .....................15

Using the Cooking Functions with the Pressure Lid ..........16

Pressure Cook .......................................16

Steam ...............................................17

Slow Cook ...........................................18

Yogurt ..............................................18

Sear/Sauté ...........................................19

Accessories for Purchase ..............................20

Cleaning & Maintenance ............................... 21

Cleaning: Dishwasher & Hand-Washing .....................21

Removing & Reinstalling the Silicone Ring ..................21

Troubleshooting Guide ................................22

Helpful Tips ..........................................24

Replacement Parts ...................................24

Warranty ............................................25

ninjakitchen.com

Page 3

IMPORTANT SAFEGUARDS

HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE

WARNING

1 This appliance can be used by persons

with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involve

2 Keep the appliance and its cord out of

reach of children. DO NOT allow the appliance to be used by children. Close supervision is necessary when used near children.

3 To eliminate a choking hazard for young

children, discard all packaging materials immediately upon unpacking.

4 DO NOT place appliance on a stovetop

or hot surfaces or near gas or electric burner or in a heated oven.

5 DO NOT use the appliance without the

removable cooking pot installed.

6 When removable cooking pot is empty,

DO NOT heat it for more than 10

minutes, as doing so may damage the cooking surface.

7 Children shall not play with the

appliance.

8 NEVER use electrical outlet below

counter.

9 NEVER connect this appliance to

an external timer switch or separate remote-control system.

10 DO NOT use an extension cord. A short

power-supply cord is used to reduce the risk of children grabbing the cord or becoming entangled and to reduce the risk of people tripping over a longer cord.

11 To protect against electrical shock

DO NOT immerse cord, plugs, or main

unit housing in water or other liquid. Cook only in the pot provided or in a container recommended by SharkNinja placed in the provided pot.

12 Regularly inspect the appliance and

power cord. DO NOT use the appliance if there is damage to the power cord or plug. If the appliance malfunctions or has been damaged in any way, immediately stop use and call Customer Service.

13 ALWAYS ensure the appliance is

properly assembled before use.

14 Before use, A LWAY S check pressure

release valve and float valve for clogging or obstruction and clean them if necessary. Check to make sure the float valve on the pressure lid moves freely. Foods such as apple sauce, cranberries, pearl barley, oatmeal or other cereals, split peas, noodles, macaroni, rhubarb, or spaghetti can foam, froth, and splutter when pressure cooked, clogging the pressure release valve. These and similar expanding foods (such as dried vegetables, beans, grains, and rice) should not be cooked in a pressure cooker, except when following a Ninja Foodi recipe.

15 DO NOT cover the air intake vent, air

exhaust vent or electrical outlet while crisping lid is closed. Doing so will prevent even cooking and may damage the unit or cause it to overheat.

16 To prevent risk of explosion and injury,

use only SharkNinja silicone rings. Make certain silicone ring is installed and lid is properly closed before operating. DO NOT use if torn or damaged. Replace silicone ring before using.

17 Before placing removable cooking

pot into the cooker base, ensure pot and cooker base are clean and dry by wiping with a soft cloth.

18 This appliance is for household use

only. DO NOT use this appliance for anything other than its intended use. DO NOT use in moving vehicles or boats. DO NOT use outdoors. Misuse may cause injury.

19 Intended for worktop use only. Ensure

the surface is level, clean and dry. DO NOT move the appliance when in use.

20 DO NOT use accessory attachments

not recommended or sold by SharkNinja. DO NOT place accessories in a microwave, toaster oven, convection oven, or conventional oven or on a ceramic cooktop, electric coil, gas burner range, or outdoor grill. The use of accessory attachments not recommended by SharkNinja may cause fire, electric shock, or injuries.

21 When using this appliance, provide

adequate space above and on all sides for air circulation.

22 A LWAYS follow the maximum and

minimum quantities of liquid as stated in instructions and recipes.

23 NEVER use SLOW COOK setting

without food and liquids in the removable cooking pot.

24 DO NOT use this appliance for deep

frying.

25 DO NOT cover the pressure valves.

26 DO NOT sauté or fry with oil while

pressure cooking.

27 Prevent food contact with heating

elements. DO NOT overfill or exceed the MAX fill level of the pot and the Cook & Crisp Basket or Plate. Overfilling may cause personal injury or property damage or affect the safe use of the appliance.

28 When pressure cooking foods that

expand (such as dried vegetables, beans, grains, rice, etc.). DO NOT fill pot more than halfway, or as otherwise instructed in a Ninja® Foodi® recipe.

29 DO NOT use this unit to cook instant rice.

30 Electrical outlet voltages can vary,

affecting the performance of your product. To prevent possible illness, use a thermometer to check that your food is cooked to the temperatures recommended.

31 DO NOT place the appliance near the

edge of a worktop during operation.

32 To avoid possible steam damage, place

the unit away from walls and cabinets during use.

33 Should the unit emit black smoke,

unplug immediately and wait for smoking to stop before removing the cooking pot and Cook & Crisp™ Basket or Plate.

34 DO NOT touch hot surfaces. Appliance

surfaces are hot during and after operation. To prevent burns or personal injury, A LWAYS use protective hot pads or insulated oven mitts and use available handles and knobs.

35 Extreme caution must be used when

the cooker contains hot food or hot liquids and/or if the cooker is under pressure. Improper use, including moving the cooker, may result in personal injury such as serious burns. When using this appliance to pressure cook, ensure the lid is properly assembled and locked into position before use. Food are under extreme pressure during pressure cooking. Failure to follow all instructions regarding proper usage of the product may result in unintended contact with hot foods or liquids that have been pressurized, resulting in serious burns.

SAVE THESE INSTRUCTIONS

ninjakitchen.com

2 3

ninjakitchen.com

Page 4

IMPORTANT SAFEGUARDS

HOUSEHOLD USE ONLY • READ ALL INSTRUCTIONS BEFORE USE

36 Caution should be used when searing

meats and sautéing. Keep hands and face away from the removable cooking pot, especially when adding new ingredients, as hot oil may splatter.

37 When unit is in operation, hot steam

is released through the air exhaust vent. Place unit so vent is not directed toward the power cord, electrical outlets, cabinets or other appliances. Keep your hands and face at a safe distance from vent.

38 DO NOT tamper with, disassemble, or

otherwise remove the float valve or pressure release assembly.

39 DO NOT attempt to open the lid

during or after pressure cooking until all internal pressure has been released through the pressure release valve and the unit has cooled slightly. Remove lid promptly to avoid re-pressurization of the inner pot.

40 DO NOT use Pressure Lid when

Sear/Sauté function is selected.

41 If using SLOW COOK setting, ALWAYS

keep the pressure lid closed and the pressure release valve in the VENT position. If the lid is closed and the pressure release valve is in the SEAL position, an audible alarm will sound. “VENT” error code will appear on LED display to signal the need to turn the pressure release valve to the VENT position.

42 When using the PRESSURE COOK

setting, ALWAY S keep the pressure lid locked and the pressure release valve turned anticlockwise to the SEAL position.

43 If the lid will not turn to unlock, this

indicates the appliance is still under pressure. DO NOT intentionally press down on float valve. Any pressure remaining can be hazardous. Let unit naturally release pressure or turn the Pressure Release Valve slowly to the VENT position to release steam. Take care to avoid contact with the releasing steam to avoid burns or injury. When steam is completely released the float valve will be in the lower position allowing the lid to be removed. If steam does not release when the pressure release valve is moved to vent, unplug the unit from the wall and let the unit naturally release pressure.

44 Spilled food can cause serious burns.

Keep appliance and cord away from children. DO NOT let cord hang over edge of tables or counters or touch hot surfaces.

45 Serious burns can result from the steam

and hot foods inside the inner pot. ALWAY S keep hands, face, and other body parts away from the pressure release valve prior to or during pressure release and when removing the pressure lid after cooking.

46 When removing the lid, DO NOT lift the

lid straight up as this may not release the seal between the lid and pot, increasing the risk of food splashing.

47 A LWAYS tilt the lid so that it is between

your body and the inner pot so that you can be shielded from steam and hot liquids.

48 The cooking pot, Cook & Crisp™ Basket

or Plate, and reversible rack become extremely hot during the cooking process. Avoid hot steam and air while removing the cooking pot and Cook & Crisp™ Basket or Plate from the appliance, and ALWAYS place them on a heat resistant surface after removing. DO NOT touch accessories during or immediately after cooking.

49 Removable cooking pot can be

extremely heavy when full of ingredients. Care should be taken when lifting pot from cooker base.

50 Cleaning and user maintenance shall

not be made by children.

Indicates to read and review instructions to understand operation and use of product.

Indicates the presence of a hazard that can cause personal injury, death or substantial property damage if the warning included with this symbol is ignored.

Take care to avoid contact with hot surface. Always use hand protection to avoid burns.

51 Let the appliance cool for

approximately 30 minutes before handling, cleaning, or storing.

52 To disconnect, turn any control to

OFF, then unplug from electrical outlet when not in use and before cleaning. Allow to cool before cleaning, disassembly, putting in or taking off parts and for storage

53 DO NOT clean with metal scouring

pads. Pieces can break off the pad and touch electrical parts, creating a risk of electric shock.

54 Please refer to the Cleaning &

Maintenance section for regular maintenance of the appliance.

For indoor and household use only.

SAVE THESE INSTRUCTIONS

ninjakitchen.com

4 5

ninjakitchen.com

Page 5

PARTS & ACCESSORIES

PARTS

A Reversible Rack B Cook & Crisp™ Layered Insert C Cook & Crisp Basket D Detachable Diuser E 8-Quart Removable

Cooking Pot

F Crisping Lid G Heat Shield H Control Panel I Cooker Base J Pressure Lid K Pressure Release Valve L Float Valve M Silicone Ring N Anti-Clog Cap O Air Outlet Vent P Condensation Collector

ACCESSORIES (SOLD SEPARATELY)

Q Skewer Stand R Multi-Purpose Pan S Roasting Rack Insert T Dehydrating Rack

U Loaf Pan V Crisper Pan

Underside of Pressure Lid

6 7

ninjakitchen.com

Page 6

USING THE CONTROL PANEL BEFORE FIRST USE

HH:MM

NOTE: Control panel may dier per model.

FUNCTION BUTTONS

PRESSURE: Use to cook food quickly

while maintaining tenderness. STEAM: Use to gently cook delicate

foods at a high temperature. SLOW COOK: Cook your food at a lower

temperature for longer periods of time. YOGURT: Pasteurize and ferment milk for

creamy homemade yogurt. SEAR/SAUTÉ: To use the unit as a

stovetop for browning meats, sautéing veggies, simmering sauces, and more.

AIR CRISP: To use the unit as an air fryer to give foods crispiness and crunch with little to no oil.

BAKE/ROAST: To use the unit as an oven for tender meats, baked treats, and more.

BROIL: Use to caramelize and brown your food.

DEHYDRATE: Dehydrate meats, fruits, and vegetables for healthy snacks.

OPERATING BUTTONS

TEMP arrows: Use the up and down TEMP

arrows to adjust the cook temperature and/or pressure level.

TIME arrows: Use the up and down TIME arrows to adjust the cook time.

NOTE: While cooking, to adjust temp or time, use the up and down arrows. The unit will then resume at those settings.

START/STOP button: Press the START/STOP button after selecting your temperature (or pressure) and time to start cooking. Pressing this button while the unit is cooking will stop the function.

KEEP WARM button: After pressure cooking, steaming, or slow cooking, the unit will automatically switch to Keep Warm mode and start counting up. Keep Warm will stay on for 12 hours, or you may press KEEP WARM to turn it o. Keep Warm mode is not intended to warm food from a cold state but to keep it warm at

a food-safe temperature. POWER button: The Power button shuts

the unit o and stops all cooking modes.

STANDBY MODE

After 10 minutes with no interaction with the control panel, the unit will enter standby mode.

1 Remove and discard any packaging

material, promotional labels, and tape from the unit.

2 Remove all accessories from the

package and read this manual carefully. Please pay particular attention to operational instructions, warnings, and important safeguards to avoid any injury or property damage.

3 Wash the pressure lid, silicone ring,

removable cooking pot, Cook & Crisp™ Basket, reversible rack, and condensation collector in hot, soapy water, then rinse and dry thoroughly. NEVER clean the cooker base or pressure lid in the dishwasher. Inspect the pressure lid to ensure there is no debris blocking the valves.

4 The silicone ring is reversible and can

be inserted in either direction. Insert the silicone ring around the outer edge of the silicone ring rack on the underside of the lid. Ensure it is fully inserted and lies ﬂat under the silicone ring rack.

INSTALLING THE CONDENSATION COLLECTOR

To install the condensation collector, slide it into the slot on the cooker base. Slide it out to remove it for hand-washing after each use.

NOTE: Prior to each use, make sure the silicone ring is well seated in the silicone ring rack and the anti-clog cap is mounted properly on the pressure release valve.

REMOVING & REINSTALLING THE ANTI-CLOG CAP

Make sure your anti-clog cap is in the correct position before using the pressure lid. The anti-clog cap protects the inner valve of the pressure lid from clogging and protects users from potential food splatters. It should be cleaned after every use with a cleaning brush. To remove, hold the anti-clog cap between your thumb and bent index ﬁnger, then rotate your wrist clockwise to remove.

8 9

ninjakitchen.com

Page 7

USING YOUR FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER

DROP THE TOP

The two lids allow you to seamlessly transition between all your favorite cooking methods. Use the pressure lid to tenderize, then use the crisping lid to crisp up your food.

USING THE CRISPING LID

The crisping lid is axed to the unit by a hinge and features an easy-open design. The lid can be opened during any convection cooking function so you can check on and access the ingredients. When the lid is opened, cooking will stop, the timer will pause, and the heating element in the lid will turn o. When the lid is closed, cooking will begin again and the timer will resume counting down.

USING THE COOKING FUNCTIONS WITH THE CRISPING LID

To turn on the unit, plug the power cord into a wall outlet, then press the Power button.

Air Crisp 1 Press the AIR CRISP button. The default

temperature setting will display. Use the up and down TEMP arrows to choose a temperature between 300°F and 400°F.

2 Use the up and down TIME arrows to

set the cook time in minute increments up to 1 hour.

3 With the pot installed, place either

the Cook & Crisp™ Basket or reversible rack in the pot. Basket should have diuser attached.

4 Add ingredients to the Cook & Crisp™

Basket or reversible rack. Close the lid and press the START/STOP button to begin cooking.

5 During cooking, you can open the

lid and lift out the basket to shake or toss ingredients for even browning, if needed. When done, lower basket back into pot and close lid. Cooking will automatically resume after lid is closed.

Bake/Roast 1 Press the BAKE/ROAST button. The default

temperature setting will display. Use the up and down TEMP arrows to choose a temperature between 250°F and 400°F.

2 Use the up and down TIME arrows to set

the cook time in minute increments up to 1 hour, 5-minute increments from 1 hour to 4 hours.

NOTE: If you press the STOP during Air Crisp Mode, the unit will wait 10 seconds before entering Standby mode.

6 When cook time is complete, the unit

NOTE: It is recommended to let the

unit preheat for 5 minutes before adding ingredients. If preheating, before step 4, close the lid, and press the START/STOP button to begin.

ninjakitchen.com

10 11

will beep.

NOTE: If running for 1 hour or less, the clock will count down by minutes and seconds. If running for more than 1 hour, the clock will count down by minutes only.

NOTE: It is recommended to let the unit preheat for 5 minutes before adding ingredients. If preheating, before step 3, close the lid, and press the START/STOP button to begin.

3 Add ingredients, along with any

accessories called for in your recipe, to the pot. Close the lid and press the START/STOP button to begin cooking.

4 When cook time is complete, the unit

will beep.

ninjakitchen.com

Page 8

USING YOUR FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER – CONT.

Broil 1 Press the BROIL button.

NOTE: There is no temperature adjustment

available or necessary when using the Broil function.

2 Use the up and down TIME arrows to set

the cook time in minute increments up to 30 minutes.

3 Place the reversible rack in the pot in the

upper broil position or follow directions per recipe.

4 Place ingredients on the rack, then close

the lid.

5 Press the START/STOP button to

begin cooking.

6 When cook time is complete, the unit

will beep.

Dehydrate 1 Press the DEHYDRATE button. The

default temperature setting will display. Use the up and down TEMP arrows to choose a temperature between 105°F and 195°F.

2 Use the up and down TIME arrows to set

the cook time in 15-minute increments up to 12 hours.

3 Place the ingredients on the bottom of

the Cook & Crisp™ Basket.

4 Add ingredients to the Cook & Crisp

Layered Insert in the Cook & Crisp Basket to create two levels for dehydrating.

NOTE: For ﬁve levels of capacity, use the dehydrating rack* directly in the cooking pot.

5 Press the START/STOP button to begin

dehydrating.

6 When cook time is complete, the unit

will beep.

*The dehydrating rack is sold separately on ninjaaccessories.com.

ninjakitchen.com

12 13

ninjakitchen.com

Page 9

USING YOUR FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER – CONT.

FAMILIARIZING YOURSELF WITH PRESSURE COOKING

In order to familiarize yourself with the Pressure Cook function and start cooking, it is highly recommended for ﬁrst-time users to do an initial run.

1 Place the pot in the cooker base and

add 3 cups room-temperature water to the pot.

2 Assemble the pressure lid by aligning

the arrow on the front of the lid with the arrow on the front of the cooker base. Then turn the lid clockwise until it locks into place.

4 Press the PRESSURE button, the unit

will default to high (HI) pressure and a time setting of 2 minutes. Press the START/STOP button to begin.

5 Your Foodi Deluxe will begin to build

pressure, indicated by the rotating lights. The unit will begin counting down when it is fully pressurized

6 When the countdown is ﬁnished, the

Foodi Deluxe will beep, automatically switch to the Keep Warm mode, and begin counting up.

NATURAL PRESSURE RELEASE VS. QUICK PRESSURE RELEASE

Natural Pressure Release: When pressure

cooking is complete, steam will naturally release from the unit as it cools down. This can take up to 20 minutes or more, depending on the amount of liquid and food in the pot. During this time, the unit will switch to Keep Warm mode. Press the KEEP WARM button if you would like to turn Keep Warm mode o. When natural pressure release is complete, the ﬂoat valve will drop down.

Quick Pressure Release: Use ONLY if your recipe calls for it. When pressure cooking is complete and the KEEP WARM light is on, turn the pressure release valve to the VENT position to instantly release pressure through the valve.

Even after releasing pressure naturally or using the pressure release valve, some steam will remain in the unit and will escape when the lid is opened. Lift and tilt it away from you, making sure no condensation drips into the cooker base.

INSTALLING & REMOVING THE PRESSURE LID

Place the pressure lid on top of the unit with the on the lid and the on the base lined up evenly. Turn the lid clockwise until it locks in place.

To unlock the pressure lid, turn it counterclockwise. Lift the lid at an angle to prevent splatter. Do not lift the lid straight up.

NOTE: The pressure lid will not unlock until the unit is completely depressurized.

NOTE: At any time during the natural release process, you can switch to quick release by turning the pressure release valve to the VENT position.

3 Make sure the pressure release valve

on the lid is in the SEAL position.

ninjakitchen.com

14 15

7 Turn the pressure release valve to the

VENT position to quick release the pressurized steam. A quick burst of steam will spurt out of the pressure release valve. When steam is completely released, the unit will be ready to open.

PRESSURIZING

As pressure builds in the unit, the control panel will display rotating lights. Pressurizing time varies, depending on the amount of ingredients and liquid in the pot. As the unit pressurizes, the lid will lock as a safety measure, and it will not unlock until pressure is released. Once the unit has reached full pressure, the lid pressure icon light will glow steadily. The pressure cooking cycle will begin and the timer will start counting down.

ninjakitchen.com

Page 10

USING YOUR FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER – CONT.

USING THE COOKING FUNCTIONS WITH THE PRESSURE LID

To turn on the unit, plug the power cord into a wall outlet, then press the Power button.

Pressure Cook 1 Place ingredients and at least 1/2 cup of

liquid in the pot, including an accessory if your recipe calls for it. DO NOT exceed the line marked PRESSURE MAX when pressure cooking.

NOTE: When cooking rice, beans, or other ingredients that expand, DO NOT ﬁll the pot more than halfway.

2 Follow the instructions on page 15 to

install the pressure lid. Turn the pressure release valve to the SEAL position.

4 Use the up and down TIME arrows to set

the cook time in minute increments up to 1 hour, and in 5-minute increments from 1 hour to 4 hours.

5 Press the START/STOP button. The

display will show rotating lights during this time. When the unit reaches the proper temperature, the time you set will begin counting down.

6 When cook time is complete, the unit

will beep, automatically switch to Keep Warm mode, and start counting up from 00:00.

Steam 1 Add 1 cup of liquid (or amount of liquid

the recipe speciﬁes) to the pot, then place the reversible rack or Cook & Crisp™ Basket with ingredients in the pot.

2 Follow the instructions on page 15 to

install the pressure lid. Turn the pressure release valve to the VENT position.

4 Press the START/STOP button. 5 The unit will automatically preheat to bring

the steaming liquid to a boil. The display will show rotating lights during this time. When the unit reaches the proper temperature, the time you set will begin counting down.

6 When cook time is complete, the unit will

beep and automatically switch to Keep Warm mode. If the ﬂoat valve pops up, wait for it to drop and then you can open the lid.

NOTE: After Steam cooking is complete,

3 Press the PRESSURE button. The

default pressure level will display. Use the up and down TEMP arrows to select either HIGH or LOW.

NOTE: After Pressure Cooking is complete, you may press the KEEP WARM button to turn the Keep Warm mode o.

7 Let the unit naturally release pressure or,

if the recipe instructs, turn the pressure release valve to the VENT position, quickly releasing steam through the valve.

NOTE: If running for 1 hour or less, the clock will count down by minutes and seconds. If running for more than 1 hour, the clock will count down by minutes only.

ninjakitchen.com

16 17

3 Press the STEAM button. Use the up and

down TIME arrows to set the cook time in minute increments up to 30 minutes.

NOTE: There is no temperature adjustment available or necessary when using the Steam function.

you may press the KEEP WARM button to turn the Keep Warm mode o.

ninjakitchen.com

Page 11

USING YOUR FOODI® DELUXE TENDERCRISP™ PRESSURE COOKER – CONT.

Slow Cook 1 Add ingredients to the pot. DO NOT

exceed the line marked MAX when slow cooking.

2 Follow the instructions on page 15 to

install pressure lid. Turn the pressure release valve to the VENT position.

3 Press the SLOW COOK button. The

default temperature setting will display. Use the up and down TEMP arrows to select either Slow Cook HIGH or LOW.

SLOW COOK

YOGURT

4 Use the up and down TIME arrows to set

the cook time in 15-minute increments up to 12 hours.

SLOW COOK

YOGURT

5 Press the START/STOP button to begin

cooking.

NOTE: The Slow Cook HIGH time setting may be adjusted anywhere between 4 and 12 hours; the Slow Cook LOW time setting may be adjusted anywhere between 6 and 12 hours.

6 When cook time is complete, the unit will

beep and automatically switch to Keep Warm mode.

Yogurt

1 Add desired amount of milk

to the pot.

NOTE: If you prefer to pasteurize, cool, and add cultures without using the unit, skip steps 1–9. Instead, press the TEMP up arrow to select FMNT, then press the TIME arrows to select desired incubation time. Press START/STOP to begin, then follow steps 10 and 11.

2 Install the pressure lid and turn

the pressure release valve to the VENT position.

3 Press SLOW COOK/YOGURT twice

until YGRT appears on the screen. Press the TEMP arrows up or down to select YGRT or FMNT.

4 Press the TIME arrows to adjust the

incubation time in 30-minute increments between 8 and 12 hours.

NOTE: Selecting a longer time will lead to tangier yogurt with a thicker consistency. Use 12 hours to achieve Greek-style yogurt.

5 Press START/STOP to begin

pasteurization.

6 Unit will display BOIL while

pasteurizing. When pasteurization temperature is reached, the unit will beep and display COOL.

7 Once the milk has cooled, the

unit will display ADD AND STIR in succession.

8 Remove the pressure lid and skim the

top of the milk.

9 Add yogurt cultures to milk and stir

to combine. Install the pressure lid (valve may be in VENT or SEAL position) and press START/STOP to begin incubation process.

10 The display will begin counting down.

When incubation time is complete, the unit will beep and display DONE.

11 Chill yogurt up to 12 hours

before serving.

Sear/Sauté 1 Install the pot.

2 Press the SEAR/SAUTÉ button. The

default temperature setting will display. Use the up and down TEMP arrows to select one of the setting options (low, medium-low, medium, medium-high, or high).

NOTE: There is no time adjustment available or necessary when using the Sear/Sauté function.

3 Press the START/STOP button to

begin cooking.

4 To turn o the Sear/Sauté function, press

the START/STOP button. To switch to a dierent cooking function, press the corresponding function button.

NOTE: You can use this function with either the crisping lid in the open position or the pressure lid with the pressure release valve in the VENT position.

NOTE: ALWAYS use nonstick utensils in the cooking pot. DO NOT use metal utensils, as they will scratch the nonstick coating on the pot.

ninjakitchen.com

18 19

ninjakitchen.com

Page 12

ADDITIONAL ACCESSORIES AVAILABLE FOR PURCHASE

We oer a suite of accessories custom made for your Ninja® Foodi® Deluxe TenderCrisp™ Pressure Cooker. Visit ninjaaccessories.com to expand your capabilities and take your cooking to the next level.

Multi-Purpose Pan Dehydrating Rack

• With this pan, you can create bubbly casseroles, dips, and sweet and savory pies, or bake a ﬂuy, moist cake with a golden top for dessert.

• Dimensions: 8.75" D x 2.5" H

Roasting Rack Insert

• Use this rack in the Cook & Crisp™ Basket to crisp up shells on Taco Tuesday, roast a rack of ribs on BBQ Sunday, or evenly toast garlic bread on pasta night.

Skewer Stand*

• This handy stand holds 15 skewers' worth of chicken, meat, seafood, and vegetables. Because of the Foodi's unique airﬂow, you get that perfect crisp to your juicy, tender creations. Compatible with 8-qt. unit only.

• Five stackable layers enable you to dehydrate fruits and meats or make crispy kale and vegetable chips.

Crisper Pan

• Perforated with holes for improved airﬂow, this pan is great for crisping and reheating pizzas, quesadillas, and vegetables.

• Dimensions: 9" D x 0.75" H

Loaf Pan

• Our specially designed pan is the perfectly sized baking accessory for bread mixes like banana and zucchini.

• Dimensions: 8.25" x 4.25" x 3.5"

Extra Pack of Silicone Rings

• 2-pack silicone ring set helps keep ﬂavors separate—use one when cooking savory foods and the other when cooking sweet foods.

CLEANING & MAINTENANCE

Cleaning: Dishwasher & Hand-Washing

The unit should be cleaned thoroughly after every use.

1 Unplug the unit from the wall outlet

before cleaning.

2 NEVER put the cooker base in the

dishwasher, or immerse it in water or any other liquid.

3 To clean the cooker base and the

control panel, wipe them clean with a damp cloth.

4 The cooking pot, pressure lid, silicone

ring, reversible rack, Cook & Crisp™ Layered Insert, Cook & Crisp Basket, and detachable diuser can be washed in the dishwasher.

NOTE: DO NOT take apart the pressure release valve or ﬂoat valve assembly.

5 To clean the crisping lid, wipe it down

with a wet cloth or paper towel after the heat shield cools.

6 If food residue is stuck on the cooking

pot, reversible rack, or Cook & Crisp Basket, ﬁll the pot with water and allow to soak before cleaning. DO NOT use scouring pads. If scrubbing is necessary, use a non-abrasive cleanser or liquid dish soap with a nylon pad or brush.

7 Air-dry all parts after each use.

Removing & Reinstalling the Silicone Ring

To remove the silicone ring, pull it outward, section by section, from the silicone ring rack. The ring can be installed with either side facing up. To reinstall, press it down into the rack section by section.

After use, remove any food debris from the silicone ring and anti-clog cap.

Keep the silicone ring clean to avoid odor.

Washing it in warm, soapy water or in the dishwasher can remove odor. However, it is normal for it to absorb the smell of certain acidic foods. It is recommended to have more than one silicone ring on hand. You can purchase additional silicone rings on ninjaaccessories.com.

NEVER pull out the silicone ring with excessive force, as that may deform it and the rack and aect the pressure-sealing function. A silicone ring with cracks, cuts, or other damage should be replaced immediately.

Silicone Ring

Silicone Ring Rack

ninjakitchen.com

Page 13

TROUBLESHOOTING GUIDE

Why is my unit taking so long to come to pressure? How long does it take to come to pressure?

• Cooking times may vary based on the selected temperature, current temperature of the cooking pot, and temperature or quantity of the ingredients.

• Check to make sure your silicone ring is fully seated and ﬂush against the lid. If installed correctly, you should be able to tug lightly on the ring to rotate it.

• Check that the pressure lid is fully locked, and the pressure release valve is in the SEAL position when pressure cooking.

Why is the time counting down so slowly?

• You may have set hours rather than minutes. When setting time, the display will show HH:MM and the time will increase/decrease in minute increments.

How can I tell when the unit is pressurizing?

• The rotating lights will display on the screen to indicate the unit is building pressure.

Lights are rotating on the display screen when using the Pressure or Steam function.

• This indicates the unit is building pressure or preheating when using STEAM or PRESSURE. When the unit has ﬁnished building pressure, your set cook time will begin counting down.

There is a lot of steam coming from my unit when using the Steam function.

• It’s normal for steam to release through the pressure release valve during cooking. Leave the pressure release valve in the VENT position for Steam, Slow Cook, and Sear/Sauté.

Why can’t I take the pressure lid o?

• As a safety feature, the pressure lid will not unlock until the unit is completely depressurized. Turn the pressure release valve to the VENT position to quick release the pressurized steam. A quick burst of steam will spurt out of the pressure release valve. When the steam is completely released, the unit will be ready to open. Turn the pressure lid counterclockwise, then lift it up and away from you.

Is the pressure release valve supposed to be loose?

• Yes. The pressure release valve’s loose ﬁt is intentional; it enables a quick and easy transition between SEAL and VENT and helps regulate pressure by releasing small amounts of steam during cooking to ensure great results. Please make sure it is turned as far as possible toward the SEAL position when pressure cooking and as far as possible toward the VENT position when quick releasing.

The unit is hissing and not reaching pressure.

• Make sure the pressure release valve is turned to the SEAL position. If you’ve done this and still hear a loud hissing noise, it may indicate your silicone seal is not fully in place. Press START/STOP to stop cooking, VENT as necessary, and remove the pressure lid. Press down on the silicone ring, ensuring it is fully inserted and lies ﬂat under the ring rack. Once fully installed, you should be able to tug lightly on the ring to rotate it.

The unit is counting up rather than down.

• The cooking cycle is complete and the unit is in Keep Warm mode.

How long does the unit take to depressurize?

• The time it takes to release pressure depends on the quantity of food in the unit and can

vary from recipe to recipe. Always ensure the ﬂoat valve has dropped before trying to remove the lid. If the unit is taking longer than normal to depressurize, unplug the unit and wait until the ﬂoat valve drops before removing the lid.

“POT” error message appears on display screen.

• Cooking pot is not inside the cooker base. Cooking pot is required for all functions.

“LID” error message appears on display screen and lid icon ﬂashes.

• The incorrect lid is installed for your desired cooking function. Place the pressure lid on the unit if you want to use the Pressure, Slow Cook, Steam, Sear/Sauté, or Keep Warm functions. Make sure the lid is in the closed position.

“SHUT” error message appears on display screen.

• The crisping lid is open and needs to be closed for the selected function to start.

“VENT” error message appears on display screen.

• When set to Slow Cook or Sear/Sauté, and the unit senses pressure building up, this message indicates the pressure release valve is in the SEAL position.

• Turn the pressure release valve to the VENT position and leave it there for the remainder of the cooking function.

• If you do not turn the pressure release valve to the VENT position within 5 minutes, the program will cancel and the unit will shut o.

“WATR” error message appears on display screen when using the Steam function.

• The water level is too low. Add more water to the unit for the function to continue.

“WATR” error message appears on display screen when using the Pressure function.

• Add more liquid to the cooking pot before restarting the pressure cook cycle.

• Make sure the pressure release valve is in the SEAL position.

• Make sure the silicone ring is installed correctly.

“HOT” error message appears on display screen.

• This indicates the unit has overheated. Let the unit cool down.

• Once unit has cooled down, ensure there is no food caked on the bottom of the pot and there is enough liquid in the pot for the recipe you are preparing.

“ERR” message appears.

• The unit is not functioning properly. Please contact Customer Service at 1-877-646-5288.

22 23

ninjakitchen.com

Page 14

HELPFUL TIPS

• For consistent browning, make sure ingredients are arranged in an even layer in the Cook & Crisp make sure to shake them halfway through the set cook time.

• For smaller ingredients that could fall through the nesting broil rack, we recommend ﬁrst placing them on parchment paper or foil.

• When switching from pressure cooking to using the crisping lid, we recommend emptying the pot of any remaining liquid for best crisping results.

• Press and hold down the TIME up or down arrow to get to your desired time faster.

• Use the Keep Warm mode to keep food at a warm, food-safe temperature after cooking. To prevent food from drying out, we recommend keeping the pressure lid closed and using this function just before serving. To reheat cold food, use the Air Crisp function.

Plate or cooking pot with no overlapping. If ingredients are overlapping,

REPLACEMENT PARTS

To order additional parts and accessories, visit ninjaaccessories.com or contact Customer Service at 1-877-646-5288. We ask that you register your product online at registeryourninja.com and have the product on hand when you call, so we may better assist you.

ONE (1) YEAR LIMITED WARRANTY

The One (1) Year Limited Warranty applies to purchases made from authorized retailers of SharkNinja Operating LLC. Warranty coverage applies to the original owner and to the original product only and is not transferable.

SharkNinja warrants that the unit shall be free from defects in material and workmanship for a period of one (1) year from the date of purchase when it is used under normal household conditions and maintained according to the requirements outlined in the Owner’s Guide, subject to the following conditions and exclusions:

What is covered by this warranty?

1. The original unit and/or non-wearable parts deemed defective, in SharkNinja’s sole discretion, will be repaired or replaced up to one (1) year from the original purchase date.

2. In the event a replacement unit is issued, the warranty coverage ends six (6) months following the receipt date of the replacement unit or the remainder of the existing warranty, whichever is later. SharkNinja reserves the right to replace the unit with one of equal or greater value.

What is not covered by this warranty?

1. Normal wear and tear of wearable parts (including removable pot, silicone ring, lids, racks, baskets, etc.) that require regular maintenance and/or replacement to ensure the proper functioning of your unit, are not covered by this warranty. Replacement parts are available for purchase at ninjaaccessories.com.

2. Any unit that has been tampered with or used for commercial purposes

3. Damage caused by misuse, abuse, negligent handling, failure to perform required maintenance (e.g., failure to keep the main unit, pressure lid, and crisping lid clear of food spills and other debris), or damage due to mishandling in transit.

4. Consequential and incidental damages.

5. Defects caused by repair persons not authorized by SharkNinja. These defects include damages caused in the process of shipping, altering, or repairing the SharkNinja product (or any of its parts) when the repair is performed by a repair person not authorized by SharkNinja.

6. Products purchased, used, or operated outside North America.

How to get service

If your appliance fails to operate properly while in use under normal household conditions within the warranty period, visit ninjakitchen.com/support for product care and maintenance self-help. Our Customer Service Specialists are also available at 1-877-646 -5288 to assist with product support and warranty service options. So we may better assist you, please register your product online at registeryourninja.com and have the product on hand when you call.

SharkNinja will cover the cost for the customer to send in the unit to us for repair or replacement. A fee of $19.95 (subject to change) will be charged when SharkNinja ships the repaired or replacement unit.

How to initiate a warranty claim

You must call 1-877-646 -5288 to initiate a warranty claim. You will need the receipt as proof of purchase. We also ask that you register your product online at registeryourninja.com and have the product on hand when you call, so we may better assist you. A Customer Service Specialist will provide you with return and packing instruction information.

How state law applies

This warranty gives you speciﬁc legal rights, and you also may have other rights that vary from state to state. Some states do not permit the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.

ninjakitchen.com

24 25

ninjakitchen.com

Page 15

SharkNinja Operating LLC Needham, MA 02494 1-877-646-5288 ninjakitchen.com

Illustrations may dier from actual product. We are constantly striving to improve our products, therefore the speciﬁcations contained herein are subject to change withoutnotice.

FOODI and NINJA are registered trademarks of SharkNinja Operating LLC.

COOK & CRISP and TENDERCRISP are trademarks of SharkNinja Operating LLC.

For SharkNinja U.S. Patent information, visit sharkninja.com/uspatents/

PRINTED IN CHINA

OP401�IB�E�REV�Mv5

@ninjakitchen
