Page 1
LU44BTS
QUICK START GUIDE
Portable Bluetooth Speaker
®
Page 2
LU44BTS - IntroductionLU44BTS - Introduction
LU48BTS
USB CHARGE
5V 1A
LU44BTS
Silicon carry-strap
& thumb screw
- 1pc
USB to USB
Charging Cable
- 1pc
Wall Hang Hook
and Screw
- 1pc
What’s in the box
Congratulations
On your LU44BTS portable wireless speakers
purchase. Please take your time to explore all of the
features and utilities we have built into this product.
We put all of our products through rigorous
testing and quality control. We take great pride in
presenting this product to you. For your peace of
mind, we oer a one-year limited warranty against
manufacturing defects and workmanship. Please
refer to the warranty section of this user manual for
more details.
SUPPORT
For the latest information on all of our products, please visit:
www.dualav.com
Quick Start Guide
- 1pc
• Call us toll-free at 1-866-382-5476
• E-mail us at [email protected]
All rights reserved. No part of this publication may be reproduced, distributed, or
transmitted in any form or by any means, including photocopying, recording, or
other electronic or mechanical methods, without the prior written permission of
DUAL ELECTRONICS CORP.
All trademarks and trade names are property of their respective owners.
Copyright © 2019 DUAL ELECTRONICS CORP.
Page 3
LU44BTS - InformationLU44BTS - Safety Information
IMPORTANT SAFETY INFORMATION TO THE USER
The lightning ash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of un-isolated,
dangerous voltage within the inside of the
device that may be of sucient magnitude to constitute a risk
of electric shock to persons
WARNING: To reduce the risk of electric shock, do
not remove cover or back plate as there are no userserviceable parts inside.
Refer servicing to qualied personnel
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and servicing instructions in the
literature accompanying the device
IMPORTANT SAFETY PRECAUTIONS
● The LU44BTS has a weather resistant design, it should not be
submerged in or underwater under any circumstances
● Set your volume control at a low setting, then slowly increase the
sound until you can hear it comfortably without distortion, or ear
discomfort.
WARNING - Never leave this product in direct
sunlight, overheating can cause permanent
battery damage
● Wash with a mild soap or detergent and lukewarm water using a
clean sponge or a soft cloth. Rinse well with clean water.
“Don’ts” - Very Important
● DON’T clean in hot sun or on very hot days.
● DON’T use abrasive or highly alkaline cleaners on the main body
● DON’T ever use acetone or carbon tetrachloride
This product must not be disposed of or dumped with your other
household waste. You are liable to dispose of all your electronic or
electrical waste equipment by relocating over to the specied collection
point for recycling of such hazardous waste. Isolated collection and proper
recovery of your electronic and electrical waste equipment at the time
of disposal will allow us to help conserving natural resources. Moreover,
proper recycling of the electronic and electrical waste equipment will
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks is under
license.
2 3
QUICK START GUIDE
ensure safety of human health and environment. For more information
about electronic and electrical waste equipment disposal, recovery, and
collection points, please contact your local city center, household waste
disposal service, shop from where you purchased the equipment, or
manufacturer of the equipment
QUICK START GUIDE
Page 4
LU44BTS - Information LU44BTS - Getting Started
Tips
Tips
EN
EN
INFORMATION TO THE USER
FCC ID: 2AQL2-LU44BTS
FCC COMPLIANCE STATEMENT
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause
undesired operation of this device.
NOTE: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
□ Relocate or reorient the receiving antenna.
□ Increase the separation between the equipment and receiver.
□ Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
□ Consult the dealer or an experienced radio/TV technician for help.
1.Changes or modifications made to this equipment not expressly approved
by (manufacturer name) may void the FCC authorization to operate this equipment
2.The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
FIRST TIME USE
● The LU44BTS Li-ion battery should be charged for minimum of 24
hours for the rst time use
iOS Devices can see the approximate battery level from
their phone status bar
● Charge direct from a laptop, computer, phone USB charge adaptor
(500mA minimum required)
BATTERY LEVEL STATUS
GREEN=FULL
RED=CHARGING
● Micro USB charging port is located on the back of the unit
4 5
ADJUSTMENT OR ALTERATIONS OF THIS DEVICE MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.
QUICK START GUIDE
CAUTION!!
AC to USB charge adapter is not included
(500mA minimum required)
QUICK START GUIDE
Page 5
LU44BTS - Getting Started LU44BTS - Wireless Operation
EN
EN
1 2 3
MAIN CONTROL PANEL
1
VOL -
2
ON/OFF + PLAY/PAUSE
BLUETOOTH/CHARGING LED STATUS
1 2 3
BLUETOOTH PAIRING
2
- Turn ON the unit - LONG PRESS
- LONG PRESS
- Turn on your Devices BLUETOOTH in your SETTINGS MENU
- Look and tap on LU44BTS name
- Once paired, a conrmation tone will be heard
- Streaming is now ready
BLUETOOTH LED STATUS
BLUE LED FAST BLINKING = BLUETOOTH NOT PAIRED
BLUE LED ON = BLUETOOTH PAIRED
1
+ 3 3 seconds
2
3 seconds
To disconnect previously paired BT Device - LONG PRESS
1 + 3 for 3 seconds
VOL +
3
6 7
QUICK START GUIDE
Tips
To clear all previously paired BT Devices - LONG PRESS
1 + 3 for 10 seconds
QUICK START GUIDE
Page 6
LU44BTS - Streaming Music LU44BTS - Speaker Placement
EN
EN
1
VOL -
1 2 3
Speaker Placement
Wall Mounting
Your LU44BTS speaker is fully portable, but can also
be permanently placed in many convenient locations
in your home or patio area.
The silicon carry-strap is removable by untwisting the
thumb screw.
If hanging your speaker is desired, hang speaker
from the supplied wall-hook facing the listening area,
this will provide the best audio results.
Do NOT mount on wall surfaces that can get wet, or
that have hazards concealed behind them, such as
electrical wires or plumbing. Always mount speaker
on surfaces that are sturdy enough to support the
speakers weight, and make sure it cannot fall or
cause injury.
2
PLAY/PAUSE
VOL +
3
NOTE: To help conserve battery discharge, the LU44BTS will automatically
power OFF after 9 minutes of non-use.
VOLUME levels will automatically sync with most
Tips
8 9
iOS devices. Supported Android devices may require
additional setup in the BLUETOOTH settings menu,
consult your phone manual for additional information.
QUICK START GUIDE
Experiment for
Better Sound
You should experiment with various placements.
Room acoustics can produce large apparent
dierences in the sound when small changes in the
placement are employed.
For example, although the speaker may be located
at any height above the oor, directing the tweeter
toward ear level or angling the entire speaker toward
the listening position often provides the most realistic
imaging experience. The amount of bass perceived
increases as you move a speaker closer to solid
intersecting room surfaces (walls, ceiling, oor).
QUICK START GUIDE
Page 7
LU44BTS - Warranty LU44BTS - Specs
TROUBLE SHOOTING
Important
The LU44BTS speaker is designed as multi-purpose
portable speakers and will deliver accurate high
delity sound in exterior or interior environments. The
TROUBLE CAUSE SOLUTION
Charge 24 hours for best
results
Turn the LU44BTS
volume level up
Check your Devices
playing / volume status
Raise the Device volume
to a higher level
Unit will not turn on
No sound is heard
The audio quality is
poor
The battery is not charged
Plug charging adaptor into
wall Turn to on position
Speaker volume level is
too low or muted
Device is paused or muted
Device volume level is too
low or muted
Warranty Coverage
weather-resistant design and construction provide
optimum durability for permanent or temporary
outdoor use. They are not meant for in-water or
underwater use.
The grille is not designed or intended to be removed.
Do not attempt to remove the grille from your
speakers. There are no user-serviceable parts behind
the grille, removal will damage the speaker and will
void the warranty.
You must have proof of purchase to receive warranty
service. Please keep your original sales receipt and
The audio quality is
poor after connection
with a Bluetooth
enabled device
The Bluetooth reception
is poor
Move the device closer
to the audio system or
remove any obstacle
between the device
be prepared to provide this receipt in the event you
require service, as your original receipt is considered
the best proof of purchase and indicates the date you
purchased your Dual product.
SPECIFICATIONS
For Your Records
Model
Dealer Name
BLUETOOTH
• BT: 5.0
• BT Range: 33Ft / 10M (Class 2)
• BT Proles: A2DP / AVRCP / GATT
GENERAL
• Power Source: 5VDC
• Li-ion Battery: 3.7VDC / 2600mA (18650 type)
• Amplier Type: Class D
• Frequency Response: 45Hz-22kHz
• Storage Temperature: 5oF to 113oF / -15oC to 45oC
• Operation Temperature: 14oF to 104oF / -10oC to 40oC
• Weight: 2.15lbs / 0.98Kg
• Dimensions Inches WxHxD: 5.75 x 9.00 x 5.50
• Color: Black
Note: You may want to keep your original sales receipt or a photo copy
with this owner’s manual.
Dealer Phone
Purchase Date
SUPPORT
• Call us toll-free at 1-866-382-5476
• E-mail us at [email protected]
10 11
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Page 8
LU44BTS - Warranty
Limited One-Year Warranty
This warranty gives you specic legal rights. You may also have other rights which vary from state to state.
Dual Electronics Corp. warrants this product to the original purchaser to be free from defects in material
and workmanship for a period of one year from the date of the original purchase.
Dual Electronics Corp. agrees, at our option, during the warranty period, to repair any defect in material
or workmanship or to furnish an equal new, renewed or comparable product (whichever is deemed
necessary) in exchange without charges, subject to verication of the defect or malfunction and proof
of the date of purchase. Subsequent replacement products are warranted for the balance of the original
warranty period.
Who is covered? This warranty is extended to the original retail purchaser for products purchased from an
authorized Dual dealer and used in the U.S.A.
What is covered? This warranty covers all defects in material and workmanship in this product. The
following are not covered: software, installation/removal costs, damage resulting from accident, misuse,
abuse, neglect, product modication, improper installation, incorrect line voltage, unauthorized repair or
failure to follow instructions supplied with the product, or damage occurring during return shipment of the
product.
Specic license conditions and copyright notices for the software can be found via www.dualav.com.
What to do?
1. Before you call for service, check the troubleshooting guide in your owner’s manual. A slight adjustment
of any custom controls may save you a service call.
2. If you require service during the warranty period, you must carefully pack the product (preferably in the
original package) and ship it by prepaid transportation with a copy of the original receipt from the retailer to
an authorized service center.
3. Please describe your problem in writing and include your name, a return UPS shipping address (P.O.
Box not acceptable), and a daytime phone number with your shipment.
4. For more information and for the location of the nearest authorized service center please contact us by
one of the following methods:
• Call us toll-free at 1-866-382-5476
• E-mail us at [email protected]
Exclusion of Certain Damages: This warranty is exclusive and in lieu of any and all other warranties,
expressed or implied, including without limitation the implied warranties of merchantability and tness for
a particular purpose and any obligation, liability, right, claim or remedy in contract or tort, whether or not
arising from the company’s negligence, actual or imputed. No person or representative is authorized to
assume for the company any other liability in connection with the sale of this product. In no event shall the
company be liable for indirect, incidental or consequential damages.
Dual Electronics Corp.
Page 9
LU44BTS
QUICK START GUIDE
®
www.dualav.com
©
NSA319-V01 Printed in China
2019 Dual Electronics Corp. All rights reserved.
Loading...
