INSTRUCTION MANUAL
M-5500
2x15
2x 15
1
4500 W
8
MP3 DIGI TAL DISP LAY WITH RE MOTE CO NTROL
SD
USB
21
22
MODE
SCAN
MP3 LEVE L
9
SPEAKE R OUT
8 Ω
MIC LEVE L
MIC
INPUT
LINE LEV EL
VOLUME
TREBLE
LINE
OUT
BASS
CLIP POWER
17
10
11
12
LINE
INPUT
13
14
15
16
18
LED
23
OFF ON
115V 230V
AC 115V/230V 60/50Hz
ON
OFF
24
19
20
1.MP3 level c ontrol
2.MIC input l evel contro l
3.Line inpu t level contr ol
4.Volu me c ontrol
5.Treble con trol for high f re quencies
6.Bass cont ro l for low fre qu encies
7.USB input
8.LCD scree n & Mp 3 control
9.MP3 ON/OF F
10.XLR micr ophone inpu t
11.6.35mm mi cr ophone in pu t
12.RCA phone(R +L ) line input
13.XLR line i nput
14.6.35mm l ine output
15.XLR line o utput
16.Clip LED i ndicator
17.Power LE D indicator
18.Speake r ou t 8 Ohm
19.Main pow er switch
20.Fused IE C mains inlet
21.SD card in put
22.
MODE:USB/SD /B T/FM conver to r
:Play / Pause
SCAN:Long p re ss to auto search u nder FM radio
:Repeat one / R ep eat all / Random
:PRE/NEXT und er FM mode
Long hold to se ar ch lower/
higher stat io n manually
:Short pres s to t une to saved stat io n
:Previous S on g
Long press fo r fa st rewind
:Next Song
Long press fo r fa st forward
23.LED Light Sw it ch(ON/OFF)
24.115/230V Swit ch
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
