FCC ID:2ABHA0048
Wireless 5W charging
alarm clock speaker
SPECIFICATION:
Model: SL203
Item No.: 2967
Speaker output power: 5W
Frequency: 20-20kHz
Input: DC 5V/ 2A
Wireless output: DC 5V/0.7A
Charging Distance: max. 6mm
Battery capacity: 4000 mAh
HOW TO USE THE WIRELESS
CHARGING MODULE:
1. Connect the speaker to USB
adapter (Must has 2A output)
with the cable provided， put
the phone centered onto the
device in order to ensure that
your phone will charge correctly.
HIGH CURRENT MOBILE PHONES CAN DRAW TOO MUCH POWER
ENABLING THE USAGE OF BOTH SPEAKER AND CHARGER.
PLEASE USE ONLY ONE FUNCTION AT A TIME!
Please read this manual before using the device to ensure safe
and proper use.
DEVICE LAY-OUT:
11.
1.
2.
4.
3.
5.
6.
8.
7.
1
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning:
Charges or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate the equipment.
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
(ShenZhen C-Star Electronic Tech. Co., Ltd.) is under license. Other
trademarks and trade names are those of their respective owners.
9. 10.
1. Time display
2. Change mode button (M)
3. Previous/Volume –
4. Pause/Play – Answering
incoming calls
5. Next/Volume +
6. Clock / Alarm setting
7. Micro USB input
8. Microphone
9. AUX line in
11. Wireless charging module
HOW TO USE:
Make sure the device is charged fully before using. Please use
the included micro USB cable. It will take about 5 hours to
button (8).
BY PRESSING M YOU CAN CHOOSE THE FOLLOWING MODES:
• FM radio
• AUX
• Bluetooth
HOW TO USE FM RADIO:
1. The included AUX cable can serve as an antenna to improve
the reception.
2. When chosen FM mode long press the Pause/Play button,
the device will automatically search and store the detected
radio frequencies.
3. Press previous and next to switch radio frequencies.
HOW TO USE THE AUX:
1. Connect the AUX cable to the alarm clock speaker and your
mobile phone
2. Choose the AUX function by pressing the M button until
you find AUX.
3. Play your favorite music (up to 5 hours of playtime on a
full charge)
HOW TO USE THE BLUETOOTH FUNCTION:
1. Make sure you turn on Bluetooth mode on your mobile phone
2. Make sure the device is turned on and on Bluetooth mode
by pressing (M)
3. Find the device on your phone.
4. Play your favorite music.
HOW TO SET THE TIME:
1. Long press Clock to set the time
2. Set the hour by pressing + or –
3. Press Clock again to set the minutes
4. Press Clock again to set the day (D1-D7)
5. Finish by pressing Clock again
HOW TO SET THE ALARM CLOCK:
1. Long press M to set your alarm
2. To set the alarm time set the hour by pressing + or –
3. Press M again to set the minutes
4. Press M again to choose the day range (weekdays 1-5;
weekends 6-7 or whole week 1-7)
5. Press M to choose the alarm clock tune (BB, USB, RADIO,
SD or OFF)
6. You can set a 2nd alarm time after finishing setting the
first alarm.
7. If not needed you can choose OFF
HOW TO ANSWER PHONE CALLS:
1. Make sure the Bluetooth mode is on and that your phone
is connected
2. Press the pause/play button to answer incoming calls and
to end calls.
NOTES
:
• Some phone cases may block the wireless charging
• Do not place other materials, like metal objects, magnets,
and magnetic stripe cards, between the mobile device and
the wireless charger pad
• Check your mobile device’s battery percentage using the
charging icon displayed on the screen of your phone
• When the mobile device is not placed on the charging surface
accurately, your mobile device may not charge properly
• If you use the wireless charger in areas with weak network
coverage, you may lose your network reception
• Please do not expose this device to moisture or heat sources
• This is not a toy, not suitable for children under the age of 7
Bluetooth Listing Declaration ID: D026369
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly
approved by the party.
Responsible for compliance could void the user’s authority to operate this
equipment. (Example- use only shielded interface cables when connecting to
computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
RF warning statement:
The device has been evaluated to meet general RF exposure requirement.
The device can be used in portable exposure condition without restriction.
This equipment complies with Part 18 of the FCC Rules.
