6/00 revised 3/04 Form Number 56041496

Whirlamatic™ Pro 21H, 21K

OPERATOR MANUAL AND PARTS LIST

Advance MODELS 56102500(21H), 56102501(21K) 56102670(24K), 56102671(24R)

56102502(27K), 56102503(27N / OBS), 56102620(27R)

Whirlamatic™ Pro 27K, 27N, 27R

Whirlamatic™ Pro 24K, 24R

2 2

2 - FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27

IMPORTIMPORT

IMPORT

ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS

ANT SAFETY INSTRUCTIONS

This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes.

TTENTION!TTENTION!

TTENTION!

Please read and adhere to all of the following Instructions before operating propane equipment.

1 The fuel supply system and cylinder connections of the floor maintenance machine shall be checked for leakage

immediately after a cylinder is connected.

2 Connection and disconnection of cylinders shall be done in a well ventilated area with no source of ignition with

10 ft. (3m) from the point of connection. 3 When the engine of a floor maintenance machine is running the operator shall not leave the unit unattended. 4 When a floor maintenance machine is not in use and stored indoors, the cylinder shall be removed and stored

outdoors and protected from damage and tampering. 5 A sign indicating “NO SMOKING” shall be permanently displayed at the storage area. The sign shall be in

accordance with the sign required In Clause10.12.3 of CAN/CGA-b149.2-M91, Propane Installation Code. (Does not

apply in industrial buildings). 6 When the cylinder is attached to the floor maintenance machine for use, the operator shall not leave the unit

unattended except for short periods of time such as rest stops, washroom or meal stops. 7 A floor maintenance machine shall only be used In buildings:

a. provided with continuous mechanical ventilation that removes the products of combustion to the outdoors of not

less than 300 CFM for each 10,000 Btu input or fraction thereof;

b provided with natural ventilation of not less than 300 CFM for each 10,000Btu input or fraction thereof, based on

a maximum of one quarter air change per hour for the net building volume.

8 The owner of a floor maintenance machine must ensure that the operator has participated in a course authorized

by the manufacturer of the unit on the safe handling of propane and the safe operation of the machine. 9 The owner of a floor maintenance machine shall ensure that the unit is maintained in accordance with the

manufacturer’s recommended maintenance procedures in a safe operating condition and the owner shall

maintain a record of the maintenance for a period of two years. 10 Before transporting a floor machine, the cylinder shall be securely fastened, with the system valve closed and the

cylinder shall be located in a well ventilated space.

SASA

VE THESE INSTRUCTIONSVE THESE INSTRUCTIONS

VE THESE INSTRUCTIONS

FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27 -

SAFETY PRECAUTIONSSAFETY PRECAUTIONS

SAFETY PRECAUTIONS

This LPG (Liquefied Petroleum Gas) machine is intended for commercial

use; It is designed to clean floors. Do not use the machine other than

described in this Operator Manual.

All operators must read, understand and practice the following safety

precautions:

The following safety alert symbol is used throughout this manual as

indicated in their descriptions.

ARNING!ARNING!

ARNING!

To warn of hazards or unsafe practices that could result In

severe personal Injury or death.

CAUTION!CAUTION!

CAUTION!

To Identify actions that must be followed for safety opera-

tion of equipment.

The following information signals potentially dangerous conditions to

the operator of equipment.

1. DO NOT OPERATE:1. DO NOT OPERATE:

1. DO NOT OPERATE: * Unless trained and authorized. * Unless operator manual Is read and understood. * If It Is not In proper operating condition.

2. BEFORE OPERATING MACHINE:2. BEFORE OPERATING MACHINE:

2. BEFORE OPERATING MACHINE: * Check for fuel oil and liquid leaks. If leakage Is detected, shut off

fuel supply at tank Immediately. * Keep sparks and open flame away from refueling area. * Make sure area Is well ventilated. * Remove any loose objects on floor .

3. WHEN OPERATING MACHINE:3. WHEN OPERATING MACHINE:

3. WHEN OPERATING MACHINE: * Always wear eye protection. * Always use extreme caution when maneuvering. * If you smell gas: shut off LPG valve immediately, open windows,

do not touch any electrical switches, extinguish any open flame

and immediately call your gas supplier . * Do not smoke or allow smoking in the vicinity. * Go slow on inclines and slippery surfaces. * Do not place flammable objects such as fuel, matches, etc., close

to the engine. * Report machine damage or faulty operation immediately. * Do not run continually over one minute In the park or tilted back

position, longer periods will affect oil flow and cause damage to

the engine. * Be careful not to touch the muffler. * Do not leave machine unattended while engine Is running. * Keep hands, feet, hair, and loose clothing, etc. away from revolv-

ing pad and pulleys. * Do not attempt to change pad while engine Is running.

4. BEFORE LEAVING MACHINE:4. BEFORE LEAVING MACHINE:

4. BEFORE LEAVING MACHINE: * Stop on level surface. * Remove key (If applicable). * Turn off LPG valve on tank.

5. WHEN SERVICING MACHINE:5. WHEN SERVICING MACHINE:

5. WHEN SERVICING MACHINE: * Keep hair, hands, feet, clothing, etc., away from moving parts. * Wear eye and ear protection when using pressurized air or

water .

* Keep flames and sparks away from fuel system service area.

Keep area well ventilated. * Do not smoke or allow smoking In the vicinity. * Never use non-U.L. listed fuel tank or component as a substitute. * Use manufacturer supplied or approved replacement parts.

ARNING!ARNING!

ARNING!

Engine emits toxic gases. Severe respiratory damage or asphyxiation can result. Provide adequate ventilation. Consult with your regulatory authorities for exposure limits. Keep engine properly tuned.

ARNING!ARNING!

ARNING!

LP gas Is extremely flammable and is explosive under certain conditions.

ARNING!ARNING!

ARNING!

Machine moves when motor is running. Stop motor before leaving machine.

ARNING!ARNING!

ARNING!

Do not store machine outdoors and avoid getting wet.

ARNING!ARNING!

ARNING!

The use of supplies other than those recommended by manufacturer may cause damage.

4 4

4 - FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27

ABLE OF CONTENTSABLE OF CONTENTS

ABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONSIMPORTANT SAFETY INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

..............................................................................

.......................................

SAFETY PRECAUTIONSSAFETY PRECAUTIONS

SAFETY PRECAUTIONS

............................................................................................................................

..............................................................

INTRODUCTIONINTRODUCTION

INTRODUCTION

......................................................................................................................................................

...........................................................................

MACHINE SETUPMACHINE SETUP

MACHINE SETUP

................................................................................................................................................

........................................................................

CHECKING OIL LEVEL AND FILTERS .......................................... 5

ADJUSTING HANDLE HEIGHT .................................................... 5

INSTALLING OR CHANGING LPG FUELTANK .......................... 5

INSTALLING OR REMOVING

PAD DRIVER AND PADS .............................................................. 5

MACHINE OPERATIONMACHINE OPERATION

MACHINE OPERATION

..............................................................................................................................

...............................................................

STARTING MACHINE ................................................................... 6

OPERATING ELECTRIC CLUTCH (OPTIONAL)........................... 6

STOPPING MACHINE ................................................................... 6

EMERGENCY STOPPING..............................................................6

WHILE OPERATING MACHINEWHILE OPERATING MACHINE

WHILE OPERATING MACHINE

......................................................................................................

...................................................

MAINTENANCEMAINTENANCE

MAINTENANCE

......................................................................................................................................................

...........................................................................

DAILY MAINTENANCE ................................................................. 7

WEEKLY MAINTENANCE.............................................................7

MONTHLY MAINTENANCE ......................................................... 7

QUARTERLY MAINTENANCE ...................................................... 7

LIFE OF MACHINE ......................................................................... 7

FUEL SYSTEM ................................................................................ 7

CHANGING THE OIL......................................................................7

ADJUSTING BELT TENSION ....................................................... 8

REFUELING AND STORING TANKSREFUELING AND STORING TANKS

REFUELING AND STORING TANKS

......................................................................................

...........................................

REFUELING LP GAS TANKS......................................................... 9

STORING LP GAS TANKS ............................................................ 9

STORING MACHINESTORING MACHINE

STORING MACHINE

........................................................................................................................................

....................................................................

1010

TRANSPORTING MACHINETRANSPORTING MACHINE

TRANSPORTING MACHINE

................................................................................................................

........................................................

1010

TROUBLE SHOOTING GUIDETROUBLE SHOOTING GUIDE

TROUBLE SHOOTING GUIDE

............................................................................................................

......................................................

1111

STANDARD PARTSSTANDARD PARTS

STANDARD PARTS

PRO 21 HONDA .............................................................................. 12

PRO 21 KAWASAKI ....................................................................... 12

PRO 24 KAWASAKI ....................................................................... 14

PRO 24 ROBIN................................................................................14

PRO 27 ONAN P248 (20HP) .......................................................... 16

PRO 27 KAWASAKI ....................................................................... 18

PRO 27 ROBIN................................................................................20

ROBIN ZXV 653 ENGINE...............................................................22

ROBIN ZXV 653 CARBURETION SYSTEM ................................. 24

KAWASAKI SHUT DOWN ASSY .................................................26

HONDA FUEL SYSTEM ................................................................. 28

KAWASAKI FUEL SYSTEM .......................................................... 29

ROBIN FUEL SYSTEM ................................................................... 30

ELECTRIC CLUTCH ASSY ............................................................. 31

KILL SWITCH ASSY.......................................................................32

KAWASAKI FUEL LOAD BLOCK .................................................. 33

KAWASAKI WIRING SCHEMATIC & HARNESS ...................... 34

INTRODUCTIONINTRODUCTION

INTRODUCTION

This manual will help you get the most from your

Advance™Advance™

Advance™

Whirlamatic™ ProWhirlamatic™ Pro

Whirlamatic™ Pro. Read it thoroughly before operating the machine. This product is intended for commercial use only.

ARTS AND SERVICEARTS AND SERVICE

ARTS AND SERVICE

Repairs, when required, should be performed by Advance service personnel using Advance original replacement parts and accessories.

Call Advance for repair parts or service. Please specify the Model and Serial Number when discussing your machine.

NAME PLANAME PLA

NAME PLA

TETE

The Model and Serial Number of your machine are shown on the Nameplate on the machine. This information is needed when ordering repair parts for the machine. Use the space below to note the Model and Serial Number of your machine for future reference.

MODEL NUMBER SERIAL NUMBER

UNCRAUNCRA

UNCRA

TINGTING

TING

When the machine is delivered, carefully inspect the shipping carton and the machine for damage. If damage is evident, save the shipping carton so that it can be inspected. Contact the Advance Customer Service Department immediately to file a freight damage claim.

revised 3/04

FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27 -

MACHINE SET UPMACHINE SET UP

MACHINE SET UP CHECKING OIL LEVEL AND FILCHECKING OIL LEVEL AND FIL

CHECKING OIL LEVEL AND FILCHECKING OIL LEVEL AND FIL

CHECKING OIL LEVEL AND FIL

TERSTERS

TERS

1 Check oil level prior to starting machine. Use proper amount and

specified oil, in order to prevent engine damage. When filling or changing oil, add more than one quart (946.3ml) -then check dip stick In cap. Add additional oil If necessary but do not overfull

The manufacturer recommends the use of 10W30 oil. ALWAYS CHECK OIL DAILY BEFORE USING MACHINE.

TTENTION!TTENTION!

TTENTION!

When checking oil, machine should be turned OFF and on level surface. Remove dipstick and wipe clean, then replace dipstick. For Honda, Kawasaki and Robin the cap should not be screwed In. To check Onan engine, the cap must be screwed In all the way. ALWAYS REFER TO YOUR ENGINE MANUAL.

2 Be sure air filter Is free of dust/debris and other obstructions. 3 Check and clean recoil and carburetor filters If necessary. (See

Engine Owners Manual)

ADJUSTING HANDLE HEIGHTADJUSTING HANDLE HEIGHT

ADJUSTING HANDLE HEIGHT

Machine is equipped with an adjustable handle for comfort and use of operators of different heights. With a 9/16" wrench, simply adjust handle at pivot points until desired operating position Is reached and then retighten bolts.

INSTINST

INST

ALLING OR CHANGING LPG FUELALLING OR CHANGING LPG FUEL

ALLING OR CHANGING LPG FUEL

ANKANK

ANK

NOTE: For refueling tank,

see

“REFUELING AND STORING TANKS”.

1 Push machine In a designated safe area.

NOTE: Move to Step 6 for tank installation.

2 Close LPG tank valve on installed tank. 3 Operate engine until it stops from lack of fuel. (See Machine

Owners Operation)

FOR SAFETY: Never release or bleed tank Inside building or en-FOR SAFETY: Never release or bleed tank Inside building or en-

FOR SAFETY: Never release or bleed tank Inside building or enclosed areas.closed areas.

closed areas.closed areas.

closed areas. FOR SAFETY: When servicing machine, keep flames and sparksFOR SAFETY: When servicing machine, keep flames and sparks

FOR SAFETY: When servicing machine, keep flames and sparksFOR SAFETY: When servicing machine, keep flames and sparks

FOR SAFETY: When servicing machine, keep flames and sparks away from fuel system service area. Keep area well ventilated.away from fuel system service area. Keep area well ventilated.

away from fuel system service area. Keep area well ventilated.away from fuel system service area. Keep area well ventilated.

away from fuel system service area. Keep area well ventilated.

4 Put on gloves and remove service coupling by turning counter-

clockwise.

5 Unlatch and remove empty LPG fuel tank from machine and

store tank in a designated, safe area.

6 Carefully put full LPG tank on machine and position valve nozzle

towards engine.

NOTE: Make sure LPG fuel tank matches fuel system (vapor system only).

CAUTION!CAUTION!

CAUTION!

Never use a fuel tank not Intended for machine.

7 Fasten tank hold-down clamp to securely lock tank in position.

Adjustment to hold-down clamp can be made by threading latch in or out.

8 Connect LPG fuel hose to valve nozzle by turning service cou-

pling clockwise (Tighten according to tank supplier recommendations). Make sure service coupling Is clean and free of damage. Also, make sure It matches machine service coupling.

TTENTION!TTENTION!

TTENTION!

When Installing tank, be careful not to cross thread service coupling.

9 Open tank service valve slowly and check for leaks. Close

service valve immediately if a LPG leak Is detected.

INSTINST

INST

ALLING OR REMOVING PALLING OR REMOVING P

ALLING OR REMOVING P

AD DRIVERAD DRIVER

AD DRIVER

AND PAND P

AND P

ADSADS

ADS

Consult an authorized distributor to assist you in choosing the correct pad for your specific cleaning need. Pad Driver Installation:Pad Driver Installation:

Pad Driver Installation:Pad Driver Installation:

Pad Driver Installation:

1 Lean machine on left side (Dip stick tube down). 2 Place pad driver on drive shaft and spin pad driver clockwise to

install.

Pad Installation:Pad Installation:

Pad Installation:

1 Tilt machine back on the rear caster (Park Position). 2 Remove plastic centerlock ring from pad driver. Center pad on

pad driver and secure with centerlock ring.

Pad Driver Removal :Pad Driver Removal :

Pad Driver Removal :

1 With knee, apply downward pressure on bell of machine deck. 2 Place 3/4" (19 mm). Open end wrench onto top of drive shaft. 3 With rubber mallet, strike wrench to break loose shaft from pad

driver (counter-clockwise). 4 Lean machine on left side (Dip stick tube down). 5 Remove pad driver by spinning off counter-clockwise.

revised 7/03

6 6

6 - FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27

MACHINE OPERAMACHINE OPERA

MACHINE OPERA

TIONTION

TION

FOR SAFETY: Do Not operate machine unless Operation Manual is read and understood.

STST

ARTING MACHINEARTING MACHINE

ARTING MACHINE

1 With machine on level surface. check oil level prior to starting

machine. 2 Tilt machine back onto rear caster (Park Position). 3 Remove any packing materials and obstructions from drive sys-

tem. 4 Turn LPG fuel knob ON tank. Check LPG gas level meter.

NOTE:NOTE:

NOTE: Opening service valve too quickly may cause service check valve to stop flow of LPG fuel. If check valve stops fuel flow, close service valve, wait a few seconds and open valve slowly again.

5 Push throttle lever to choke position for Honda engine only. All

other engines start in IDLE position. 6 Press start button OR turn key (if required) to engage starter. Do

not engage starter button for more than 20 seconds at a time. If

starter overheats it trips an internaI overload switch and will not

crank over. Wait at least 20 to 30 seconds between tries. When

engine starts, ease throttle back to running position. Do not hold

starter button in a continuous ON position, starter will burn out.

NOTE:NOTE:

NOTE: For Electric Clutch model, see “OPERATING ELECTRIC CLUTCH”.

CAUTION!CAUTION!

CAUTION!

Be careful not to allow the machine to come in contact with loose tiles or other loose materials, remember the pad driver Is moving at very high speed, and Injury can occur to the operator or passers by If pad driver flings the loose material.

OPERAOPERA

OPERA

TING ELECTRIC CLUTCH (OP-TING ELECTRIC CLUTCH (OP-

TING ELECTRIC CLUTCH (OP-

TIONAL)TIONAL)

TIONAL)

1 Once engine starts, move throttle control to SLOW rpm. 2 With throttle in SLOW, engage clutch by squeezing trigger switch. 3 After clutch is engaged, move throttle to 3/4 throttle position and

then lower pad driver to floor.

CAUTION!CAUTION!

CAUTION!

Never engage clutch In fast run position or with pad driver on floor, this will cause damage to clutch.

STOPPING MACHINESTOPPING MACHINE

STOPPING MACHINE

1 Turn LPG valve OFF at tank while running. This serves to purge

or bleed fuel hoses and carburetor system of fuel, so that there is no danger of gas escaping from lines when tank is removed for

outside storage. 2 Tilt machine back on rear caster . 3 Engine will stop running when fuel lines bleed clear. 4 Pull throttle lever to STOP position after engine has stopped. 5 Turn key off if equipped.

EMERGENCY STOPPINGEMERGENCY STOPPING

EMERGENCY STOPPING

1 Pull throttle back to STOP OR turn off key if equipped. 2 Turn LPG valve OFF at tank.

NOTE:NOTE:

NOTE: Engine may back fire when stopped in this manner. If machine is equipped with Kill Switch Option, activate switch.

WHILE OPERAWHILE OPERA

WHILE OPERA

TING MACHINETING MACHINE

TING MACHINE

ARNING!ARNING!

ARNING!

Exhaust contains poisonous carbon monoxide gas. Avoid Inhalation of exhaust gases. Never operate machine in a confined area without proper ventilation.

1 Refer to (SAFETY PRECAUTION: WHEN OPERATING MACHINE)

on page 4. 2 Do not run machine for more than 15 seconds in one spot or

damage will occur to the floor. 3 Do not leave unattended in idle position or with engine running

period. If machine needs to be idled for short periods, tilt

machine back and move throttle to idle. Machine should now

idle safely.

TTENTION!TTENTION!

TTENTION!

Do not Idle more than 5 minutes, longer periods will affect oil flow and will cause damage to the engine.

4 For easier maneuverability, always start on right side of aisle.

FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27 -

MAINTENANCEMAINTENANCE

MAINTENANCE

ARNING!ARNING!

ARNING!

Before attempting any maintenance procedures on machine, stop on level surface, shut off machine and turn off LPG valve at tank.

TTENTION!TTENTION!

TTENTION!

Repairs and adjustments must be performed by authorized and trained personnel.

To keep machine in good working condition, simply follow the daily, weekly, and monthly maintenance procedures.

NOTE:NOTE:

NOTE: Always record maintenance and service.

TTENTION!TTENTION!

TTENTION!

Always keep machine free from dust and lint; the engine is air cooled and for proper air flow to cool the engine, the recoil filter must remain clean.

DAILY MAINTENANCE (Every 4 Hours of Operation)DAILY MAINTENANCE (Every 4 Hours of Operation)

DAILY MAINTENANCE (Every 4 Hours of Operation)

1 Check oil level (Use 10W30 oil only). 2 Clean recoil filter . 3 Check belt tension by pinching belt together. Belt should only

depress 1/2" (13mm).

4 Clean all air filters by blowing out dust and dirt and/or washing

the foam filters (recoil and carburetor pre- filter) with warm, sudsy water and rinsing clean.

(Be careful not to wet the paper

carburetor filters.)

Be sure filters are clean and dry before use.

Do not oil foam or filter . 5 Make sure all components are secure and tight. 6 Check pad daily (clean or replace). 7 Clean machine. 8 For Dust Control models, clean dust collection bag.

WEEKLY MAINTENANCE (Every 20 Hours of Operation)WEEKLY MAINTENANCE (Every 20 Hours of Operation)

WEEKLY MAINTENANCE (Every 20 Hours of Operation)

1 Check oil level. Change oil and filters at 50 hours of operation.

Use 10W30 Motor Oil or other no ash motor oils designed for use

in propane engines. Use of non-recommended oil may void the

engine warranty.

See Engine Owners Manual for complete servicing details

2 Inspect carburetor air filter by removing wing nut and over on top

of carburetor. Replace if dry or deposits are present. 3 Check belt for tension. Tighten if loose. If worn, replace with

proper belt.

(See “ADJUSTING BELT TENSION”).

Refer to parts

schematic for size of belt required. 4 Inspect and tighten nuts and bolts on engine and frame. 5 Examine all propane hoses and connections for leaks or wear.

Replace if necessary. 6 Grease wheels. Use white lithium grease only and use no more

than 1 pump of grease. More grease than recommended will

push seal and dust cover out, allowing dust and other foreign

materials into the bearings, shortening the life of the wheel

significantly.

MONTHLY MAINTENANCE (Every 80 hours of Operation)MONTHLY MAINTENANCE (Every 80 hours of Operation)

MONTHLY MAINTENANCE (Every 80 hours of Operation)

1 Perform all daily and weekly services. 2 Torque the head bolts when engine is cold in a crisscross

pattern as per engine manufacturers specifications

(See En-

gine Owners Manual).

3 Check valve clearance with cold engine as per engine manufac-

turers specifications

(See Engine Owners Manual).

4 Torque valve cover as per engine manufacturers specifications

(See Engine Owners Manual).

5 Inspect spark plug. Replace if necessary. 6 Change oil and oil filter. 7 Inspect fuel hoses for leak (repair as needed). 8 Wash undercarriage of machine to remove all dust and debris. 9 To ensure proper ventilation, remove engine cover and clean

engine.

10 Replace air filter element and foam filter.

QUARTERLY MAINTENANCE (Every 250 Hours of Operation)QUARTERLY MAINTENANCE (Every 250 Hours of Operation)

QUARTERLY MAINTENANCE (Every 250 Hours of Operation)

1 Perform all of the above maintenance procedures and have

engine checked by an Authorized Service Center. 2 Check air gap in electronic ignition coil. 3 Check valves with engine cold.

NOTE:NOTE:

NOTE: Consult Engine Manual for complete servicing and adjustments information.

LIFE OF MACHINELIFE OF MACHINE

LIFE OF MACHINE

1 Change oil regularly. 2 Clean recoil filter regularly. 3 Clean carburetor filter regularly. 4 Keep machine clean from dust and debris.

FUELSYSTEMFUELSYSTEM

FUELSYSTEM Adjustments for the air/fuel mixture must be made only by an Authorized

Service Center. Improper adjustments can cause high levels of carbon monoxide emissions which may cause carbon monoxide poisoning or it can lead to engine damage.

• Idle speed is adjusting by turning adjustment screw on regula-

tor.

• Fuel flow is adjusted by adjustment screw on carburetor spud-

in.

CHANGING THE OILCHANGING THE OIL

CHANGING THE OIL The manufacturer recommendations 10W30 oil.

1 Run engine for five minutes to warm oil. 2 Make sure machine is on level surface. Locate oil drain plug on

rear of engine beside oil cap and remove by turning counter-

clockwise with wrench. 3 Allow oil to run into pan under machine. Allow to completely

drain. 4 Install drain plug and tighten drain plug by turning clockwise

with wrench. 5 Slowly add one quart (946.3 mi) of 10W30 Motor Oil. Then check

oil level with dip stick in oil fill cap. Add additional oil if neces-

sary. 6 Replace oil-fill cap assembly. Hand tighten only.

TTENTION!TTENTION!

TTENTION!

Do not overfill and never run engine low on oil.

TTENTION!TTENTION!

TTENTION!

When checking oil, be sure cap is fully screwed out and free. Do not check oil by screwing cap in and then out again, this will give you a false reading.

8 8

8 - FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27

ADJUSTING BELT TENSIONADJUSTING BELT TENSION

ADJUSTING BELT TENSION Tools required:

• 3/4" (19mm) open end wrench

• 15/16" (24mm) deep-well socket. 1 Loosen Mounting Bolt on top side of machine while applying

counter-pressure to Adjusting Nut on underside of deck.

NOTE:NOTE:

NOTE: The mounting bolt muse be loosened first.

2 Rotate Adjusting Nut counterclockwise with socket to apply

tension to belt.

3 While holding the tension on the Adjusting Nut. Tighten Mount-

ing Bolt.

4 Check belt tension by pinching belt together. Belt should only

depress 1/2" (12mm).

REFUELING AND STORING TREFUELING AND STORING T

REFUELING AND STORING T

ANKSANKS

ANKS

The following information refers to United States regulations on propane. For outside the United States, owner, must assure that required regulations are met.

The manufacturer would like to acknowledge NFPA 58, Standard for Storage and Handling of Liquefied Petroleum Gases, 1993 Edition. This publication is available through the National Fire Protection Association (NFPA) in Quincy, Massachusetts (1-800-344-3555). The NFPA was established to set guidelines for, among other things, the use of propane.

Propane is a flammable gas whose vapors are heavier than air. It can explode under certain conditions. It is not different than other items commonly used today which must be operated in a safe way such as automobiles, gas stoves, airplanes, etc. Propane is odorized with an agent with a distinct odor that is recognizable at very low concentrations. This helps in identifying leaks even when they are small.

Awareness and basic safely precautions are required. As long as these precautions are followed, risk is negligible. Ignorance, however, could pose needless risk. Therein lies the reason behind NFPA 58 and the Safety Publication.

NFPA 58 categorizes propane-powered buffers with fork lift trucks, (see section 3-6.4.4). In essence, the only difference between the two lies in the ability of the buffer with its 20-pound tank to be stored in concealed areas (like janitor closets, etc.).

If a machine and its tank of propane were stored in a closet and afire occurred, the propane in the tank could be a threat to fire fighters due to the potential for a B.L.E.V.E. (Boiling Liquid Expanding Vapor Explosion). Exposure of the tank to heat can also cause the relief valve to open thereby releasing flammable vapors that can cause the fire to intensify when ignited.

The NFPA Technical Committee prohibits the storage of such containers in buildings.

FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27 -

REFUELING LP GAS TREFUELING LP GAS T

REFUELING LP GAS T

ANKSANKS

ANKS

NOTE:NOTE:

NOTE:

See

‘INSTALLING OR CHANGING LPG FUEL TANK” for Tank

Removal.

The LP gas tank supplied with machine has a 20Ib. (9.3kg), 5-gallon (18.9L) capacity.

DO NOT OVERFILL. DO NOT OVERFILL.

DO NOT OVERFILL. Overfilling will cause the regulator to freeze up. Use only D.O.T. and U.L. Listed propane tank and only fill tank at a reputable propane dealer .

DO NOT attempt to repair the propane tank yourself. Return tank to dealer for repair.

NOTE:NOTE:

NOTE: Never use a tank not intended for the propane machine. Do not substitute tanks from barbecue grills, etc.

The manufacturer exclusively uses aluminum and steel cylinders that meet the Department of Transportation guidelines contained in the D.O.T. # 4ET240 and are additionally U.L. listed.

NFPA 58 discusses the major concerns for filling tanks properly in Chapter 4. In summary, the tank should never be completely filled with liquid. A tank that is completely full could create a hazard. The hazard is known as a hydrostatic pressure situation.

To illustrate this situation, suppose the temperature outside is very cold (perhaps well below freezing). You fill your tank outside and then bring it inside where the temperature is maybe 60 degrees Fahrenheit or warmer. An increase in air temperature will drive up the cylinder pressure placing stress on the tank. Before reaching a critical pressure point, the relief valve should open, relieving the pressure by venting vapor at the top of the tank. However, if there is no vapor at the top of the tank, this safety measure is compromised. Overfilled tanks do not allow this built-in safety feature to function properly.

TTENTION!TTENTION!

TTENTION!

Overfilling a tank usually results in liquid flowing through the hose and down into the regulator. This can result in damage to the machine.

If you observe frost on the regulator, someone has overfilled the tank. Take the tank to a safe outside location and vent the excess propane. Venting is accomplished by:

1 Removing the tank from machine. 2 Taking tank outside of building to safe area. 3 Opening the small relief valve located on top of machine. 4 Keep tank upright. 5 Allow to vent until fuel vapor is not visible.

Whether the tank is filled by weight (most accurate) or by volume, using a gage, make sure the person doing the filling is qualified.

CAUTION!CAUTION!

CAUTION!

Avoid overfilling tanks. Only fill to 80% of capacity. The manufacturer recommends that refueling be accomplished by qualified personnel away from public buildings outside. We further recommend that additional tanks be used so that rather than refueling at the job site, a simple exchange of tanks occurs.

STORING LP GAS TSTORING LP GAS T

STORING LP GAS T

ANKSANKS

ANKS

TTENTION!TTENTION!

TTENTION!

Tanks (20Ib.) should not be stored in buildings used by the public or frequented by anyone passing through or working in the building. Inside storage in buildings designated as shop or machinery facilities are acceptable.

Section 5-2.1.1 of the NFPA 58 says: “Containers in storage shall be so located as to minimize exposure to excessive temperature rise, physical damage or tampering.”

Provision must be made for venting the actual storage area with both floor level and high level openings. This venting assures that the heavier than air propane gas will not settle in pockets, but disperse.

If storage is in a shop or machine storage area that is connected or a part of an office complex, it should be separated by afire wall along with proper venting to the outside.

Since these requirements can seldom be found, outside open air storage is the most practical alternative.

When this option is used, the storage container may be located with “zero” clearance from the building and with at least 5' of space between the cage and the nearest building opening.

The tank must be in a secure, tamper-proof security storage enclosure that provides safety from accident or vandalism.

CAUTION!CAUTION!

CAUTION!

Tanks must always be stored in the upright position. The upright position assures that the discharge is largely vapor rather than liquid. This is important from the standpoint of both the quantity of the potential flammable vapor/air mixture and the relieving capacity for the pressure relief device. (The escape of vapor presents much less hazard than the escape of liquid).

The manufacturer recommends that tanks be removed from the machine after use and stored accordingly. The machine can then be placed in a secure area inside, away from the tank.

NOTE: NOTE:

NOTE: Local jurisdiction always prevails there may. Be varying requirements. Always check with the local authorities.

10 10

10 - FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27

STORING MACHINESTORING MACHINE

STORING MACHINE

1 Remove LPG tank from machine when not in use.

FOR SAFETY: Never release or bleed tank inside building or inFOR SAFETY: Never release or bleed tank inside building or in

FOR SAFETY: Never release or bleed tank inside building or in enclosed areas.enclosed areas.

enclosed areas.enclosed areas.

enclosed areas.

NOTE:NOTE:

NOTE: See “INSTALLING OR CHANGING LPG FUEL TANK” for Tank Removal.

2 Perform all Daily Maintenance procedures. 3 Change engine oil. 4 Store machine in cool, dry area, away from fuel tanks. Tilt

machine back onto rear caster (Park Position).

5 Store tanks in an approved area.

NOTE: NOTE:

NOTE: See “STORING LP GAS TANKS”.

TRANSPORTING MACHINETRANSPORTING MACHINE

TRANSPORTING MACHINE

For ease of transportation, the machines handle can be folded over the engine. The tank can be transported on machine provided that tank holddown clamp is securely fastened around tank and tank valve is turned completely OFF.

TTENTION!TTENTION!

TTENTION!

Never transport a machine in an enclosed area that has not had sufficient time to cool down.

FORM NO. 56041496 - Whirlamatic Pro™ 21, 24, 27 -

1111

TROUBLE SHOOTING GUIDETROUBLE SHOOTING GUIDE

TROUBLE SHOOTING GUIDE

PROBLEM PROBLEM

PROBLEM

CAUSE CAUSE

CAUSE

SOLUTION SOLUTION

SOLUTION

Will not start. No fuel or dirt in fuel line. See Engine Owners Manual for servicing.

Blown head gasket. Engine overload. Dirty air cleaner. Faulty spark plug. Fuel system out of adjustment. Defective ignition coil.

Hard to start. Improper fuel, no fuel or dirt in fuel line. See Engine Owners Manual for servicing.

Engine overload. Dirty air cleaner . Faulty spark plug. Spark plug or head bolts loose. Blown head gasket. Timing, coil, or valve needs adjusting. Carburetor needs adjusting. Regulator needs adjusting. Insufficient vacuum.

Lacks power . Improper valve clearance. See Engine Owners Manual for servicing.

Improper fuel or dirt in line. Faulty spark plug. Improper oil level. Valve seats need adjusting. Leaking head gasket. Governor needs adjusting.

Worn rings. Smell of burned rubber. Belt out of adjustment. See “ADJUSTING BELT TENSION”. Engine overheats. Dirt in fuel line.

Incorrect oil level.

Engine overload. High fuel consumption. Dirty air filters. See Engine Owners Manual for servicing.

Dirty air cleaners. Machine stops suddenly. Faulty spark plug. See Engine Owners Manual for servicing.

Pad not centered on pad driver .

Incorrect pad size for pad driver.

Oil shut down sensor activated. Add recommended oil. Excess vibration. Bolts loose on engine or deck of unit. See Engine Owners Manual for servicing.

No fuel or dirt in fuel line.

Incorrect oil level.

Engine overload.

Dirty air filters.

Faulty spark plug.

+ 25 hidden pages

Nilfisk-Advance whirlamatic pro 24K, whirlamatic pro 27K, whirlamatic pro 21K, whirlamatic pro 24R, whirlamatic pro 27N Operator's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
