107410954 A
UZ 934
INSTRUCTIO NS FOR USE
(ORIGINAL INSTRUCTION)
BRUGSANVISNING
BETRIEBSANLEITUNG
MODE D’EMPLOI
INSTRUCC IONES DE USO
02
03
English ............................................................................................................................... 6
Deutsch ............................................................................................................................. 8
Français ........................................................................................................................... 10
Nederlands ...................................................................................................................... 12
Italiano ............................................................................................................................. 14
Norsk ............................................................................................................................... 16
Svenska ........................................................................................................................... 18
Dansk ............................................................................................................................... 20
Suomi ............................................................................................................................... 22
Español............................................................................................................................ 24
Português ........................................................................................................................ 26
Eλληνικά .......................................................................................................................... 28
Türkçe .............................................................................................................................. 30
Čeština............................................................................................................................. 32
Polski ............................................................................................................................... 34
Magyar ............................................................................................................................. 36
Română ........................................................................................................................... 38
Бългapcки ...................................................................................................................... 40
Pyccкий ........................................................................................................................... 42
Eesti ................................................................................................................................. 44
Latviski ............................................................................................................................ 46
Lietuviškai ....................................................................................................................... 48
日本......................................................................................................................................50
Specifications .................................................................................................................52
04
To open
Hose connection
1 Dust bag
5
5
3
5
5
Tools
5
5
05
Suction control
8
Start / Stop Filter
Exhaust filter
Warning 10
9
10
Original instruction06
Instructions for use
Purpose and intended use
Important warnings
Prior to using the appliance for the first time, be sure to read this document through and keep it ready to hand.
Before using the vacuum cleaner make sure that the voltage shown
on the rating plate on the vacuum cleaner corresponds with the main
voltage.
This machine is intended for commercial use, for example in hotels,
schools, hospitals, factories, shops, offices and rental businesses.
The appliance is suitable for picking up dry, non-flammable dust.
This machine is equipped with a thermal cut-out to protect the
motor and other vital machine parts from overheating. Should the
machine cut out, you will have to wait at least 5-10 minutes for it
to automatically reset. While you are waiting, switch the machine
off and unplug it, then check the hose, dust bag and filters to be
sure that nothing is blocking the flow of air through the machine.
The filter/filters on selected models in this product range are manufactured using HEPA material. This is not a HEPA certified machine and
should not be used in cleaning environments where approved HEPA
machines are required.
The vacuum cleaner is supplied with a paper dust bag already in place.
Never use the vacuum cleaner without a properly fitted dust bag.
WARNING
Danger that can lead to serious injuries or even death.
WARNING
• The vacuum cleaner must not be used for the suction of
water, liquids or inflammable gases.
• No changes to the mechanical, electrical or thermal safety
devices must be made.
• This appliance is not to be used by children or persons
with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been
given supervision or instruction.
• Young children should be supervised to ensure that they
do not play with the appliance.
• Operators shall be adequately instructed on the use of
this machine.
• This machine is for dry use only.
CAUTION
Danger that can lead to minor injuries and damage.
CAUTION
• This machine is for indoor use only.
• This machine shall be stored indoors only.
Symbols used to mark instructions
English
Original instruction 07
Electrical connection
Maintenance
Warranty
Always keep the cleaner in a dry place. The cleaner is designed for
continuous heavy work. Depending on the number of running hours –
the dust filters should be renewed. Keep the container clean with a dry
cloth, and a small amount of spray polish.
For details of after sales service contact Nilfisk directly.
Our general conditions of business are applicable with regard to the
guarantee.
Unauthorised modifications to the appliance, the use of incorrect
brushes in addition to using the appliance in a way other than for the
intended purpose exempt the manufacturer from any liability for the
resulting damage.
As specified in European Directive 2002/96/EC on old electrical
and electronic appliances, used electrical goods must be collected
separately and recycled ecologically.
Contact your local authorities or your nearest dealer for further information.
Hazardous materials
WARNING
Vacuuming up hazardous materials can lead to serious or
even fatal injuries.
The following materials must not be picked up by the vacuum
cleaner:
• hazardous dust
• hot materials (burning cigarettes, hot ash, etc.)
• flammable, explosive, aggressive liquids (e.g. petrol, solvents, acids, alkalis, etc.)
• flammable, explosive dust (e.g. magnesium or aluminum
dust, etc.)
WARNING
• The vacuum cleaner must not be used if the electrical
cable or plug show any sign of damage. Regularly inspect
the cable and the plug for damage. If this becomes damaged, it should be repaired only by Nilfisk or an authorised
Nilfisk Service Dealer, in order to avoid a hazard.
• Do not handle the electrical cable or plug with wet hands.
• Do not unplug by pulling on cable. To unplug, grasp the
plug, not the cable. The plug must always be removed
from the socket outlet before starting any service or repair
work of the machine or the cable.
52
Specifications
UZ 934
Rated power W 1000
Protection class (electrical) II
Airflow with hose and tube litres/sec 32,5
Suction power with hose and tube W 205
Sound pressure IEC 704 dB(A) 76 ± 2
Sack filter, surface area cm
2
3900
Dust bag capacity litres l 10
Weight kg 6,1
Specifications and details are subject to change without prior notice.
CE declaration of conformity
NILFISK-ADV ANCE A/S
Sognevej 25
DK-2605 Brøndby
Product: Vacuum cleaner
Model: UZ 934
Description: 120V / 220-240V, 50/60 Hz
The design of the appliance corresponds to the following pertinent
regulations:
EC - Machinery Directive 2006/42/EC
EC - Directive EMC 2004/108/EC
RoHS Directive 2011/65/EC
Energy labelling of vacuum cleaners 665/2013/EC
Ecodesign requirements for vacuum cleaners 666/2013/EC
Applied harmonized standards: EN 60335-2-69:2009
EN 55014-1:2006, EN 55014-2:2001, EN 61000-3-2:2006, EN
61000-3-3:2008, EN 62233:2008
Applied national standards and technical specifications:
DIN EN 60335-2-69:2010
Anton Sørensen
General Manager EAPC
Technical Operations Brøndby, 2014
Original instruction 53
Annual energy consumptions mentioned are all indicative. They are based on 50 cleaning tasks. Actual annual energy consumption will depend on how the appliance is used.
This machine is not suitable for carpets with the delivered nozzle.
80dB
UZ934
107410470
41
kWh/annum
A
B
C
D
E
F
G
D
665/2013 - I
ABCDEFG
ABCDEF
G
