10740043 4 F
IVB 961-0L / 965-0L SD XC
INSTRUCTIONS FOR USE
(ORIGINAL INSTRUCTION)
BRUGSANVISNING
BETRIEBSANLEITUNG
MODE D’EMPLOI
INSTRUCC IONES DE USE
auto
2
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
Contents
1 Important safety
instructions
2 Description
3 Before starting the
cleaner
4 Control / Operation
5 Applications and
methods
6 After using the cleaner
7 Maintenance
8 Troubleshooting
9 Further information
............................................................................................3
2.1 Operating elements ..............................................................7
2.2 Operating panel ....................................................................8
3.1 Assembling the vacuum cleaner...........................................9
4.1 Connections .......................................................................12
4.2 Switching on the vacuum cleaner .......................................12
4.3 Cleaning the filter element .................................................13
5.1 Techniques .........................................................................14
6.1 Switching the vacuum cleaner off and storage ...................15
7.1 Maintenance plan ...............................................................16
7.2 Maintenance work ..............................................................17
..........................................................................................22
9.1 Recycling the cleaner .........................................................23
9.2 Guarantee ..........................................................................23
9.3 Tests and approvals............................................................23
9.4 EC declaration of conformity ..............................................23
9.5 Technical data ....................................................................24
9.6 Optional accessories ..........................................................24
3
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
1 Important safety instructions
Symbols used to mark
instructions
Prior to using the appliance for the first time, be sure to read
this document through and keep it ready to hand.
DANGER
Danger that leads directly to serious or irreversible injuries,
or even death.
WARNING
Danger that can lead to serious injuries or even death.
CAUTION
Danger that can lead to minor injuries and damage.
The appliance must
• only be used by persons, who have been instructed in its correct
usage and explicitly commissioned with the task of operating it
• only be operated under supervision
• not be used by children
1. Do not use any unsafe work techniques.
2. Never use the vacuum cleaner without a filter.
3. Switch off the appliance and disconnect the mains plug in the
following situations:
- Prior to cleaning and servicing
- Prior to replacing components
- If foam develops or liquid emerges
Besides the operating instructions and the binding accident prevention regulations valid in the country of use, observe recognised regulations for safety and proper use.
When dust removers are used, the rate at which air is exchanged
in the room must be adequate if the exhaust air from the vacuum
cleaner is blown into the room (please observe regulations valid in
your country).
Before starting work, the operating staff must be informed on
• use of the vacuum cleaner
• risks associated with the material to be picked up
• safe disposal of the picked up material.
Purpose and intended use
The vacuum cleaners described in this operating manual are suitable for
• commercial use, e.g. in hotels, schools, hospitals, factories, shops,
offices and rental businesses.
• for separation of dust with an exposure limit of greater than 1 mg/m³,
(dust class L).
4
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
Transport
1. Before transporting the dirt tank, close all the locks.
2. Do not tilt the cleaner if there is liquid in the dirt tank.
3. Do not use a crane hook to lift the cleaner.
Storage
1. Store the appliance in a dry place, protected from frost.
Electrical connection
1. It is recommended that the vacuum cleaner should be connected
via a residual current circuit breaker.
2. Arrange the electrical parts (sockets, plugs and couplings) and
lay down the extension lead so that the protection class is maintained.
3. Connectors and couplings of power supply cords and extension
leads must be watertight.
Extension lead
1. As an extension lead, only use the version specified by the man-
ufacturer or one of a higher quality.
2. When using an extension lead, check the minimum cross-sec-
tions of the cable:
Cable lenth Cross section
< 16 A < 25 A
up to 20 m 1.5 mm
2
2.5 mm
2
20 to 50 m 2.5 mm
2
4.0 mm
2
Maintenance, cleaning and
repair
Electrical tests must be per formed in accordance with the provisions
of safety regulations (BGV A3) and to DIN VDE 0701 Part 1 and Part
3. In ac cord ance with DIN VDE 0702 these tests must be performed
at regular intervals and after repairs or modifications.
A dust test must be performed at least once every year by NilfiskAdvance service or a trained person. This test includes, for example,
whether there is damage to the filter, the vacuum cleaner is sealed
to the air and the control equipment works properly.
During maintenance and cleaning, handle the vacuum cleaner in
such a manner that there is no danger for maintenance staff or other
persons.
Clean the water level limiting device regularly and check for signs of
damage.
In the maintenance area
• use filtered compulsory ventilation
• wear protective clothing
• clean the maintenance are so that no harmful substances get into
the surroundings.
Any other use is considered as improper use. The manufacturer accepts no liability for any damage resulting from such use. The risk for
such use is borne solely by the user.
Proper use also includes proper operation, servicing and repairs as
specified by the manufacturer.
5
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
Risks
DANGER
Electric shock due to faulty mains connecting lead.
Touching a faulty mains connecting lead can result in
serious or even fatal injuries.
1. Do not damage the mains power lead (e.g. by driving
over it, pulling or crushing it).
2. Regularly check whether the power cord is damaged or
shows signs of ageing.
3. Have the faulty mains connecting lead replaced by your
Nilfisk-Advance service representative or a qualified
electrician prior to using the appliance again.
DANGER
The upper section of the vacuum cleaner contains live
components.
Contact with live components leads to serious or even fatal
injuries.
1. Never spray water on to the upper section of the vacuum
cleaner.
CAUTION
Damage due to unsuitable mains voltage.
The appliance can be damaged as a result of being connected
to an unsuitable mains voltage.
1. Ensure that the voltage shown on the rating plate corresponds to the voltage of the local mains power supply.
Electrical components
Picking up liquids
CAUTION
Picking up liquids.
IVB 965-0L SD XC: Due to their construction vacuum cleaners
with a removable tank (SD) do not have an automatic level
indicator. There is a risk of damage to the vacuum cleaner
due to overfilling or of damage due to leakage of the picked
up liquid.
1. Never pick up more than 40 litres at once.
2. Switch off the vacuum cleaner and empty the dirt tank.
6
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
Hazardous materials
WARNING
Hazardous materials.
Vacuuming up hazardous materials can lead to serious or
even fatal injuries
1. The following materials must not be picked up by the
vacuum cleaner:
- hot materials (burning cigarettes, hot ash, etc.)
- flammable, explosive, aggressive liquids (e.g. petrol,
solvents, acids, alkalis, etc.)
- flammable, explosive dust (e.g. magnesium or alumin-
ium dust, etc.)
Spare parts and accessories
CAUTION
Spare parts and accessories.
The use of non-genuine spare parts and accessories can
impair the safety of the appliance.
1. Only use spare parts and accessories from Nilfisk-Advance.
2. Use only the brushes supplied with the vacuum cleaner
or specified in the operating manual.
Emptying dirt tank
CAUTION
Picking up environmentally hazardous materials.
Materials picked up can present a hazard to the
environment.
1. Dispose of the dirt in accordance with legal regulations.
7
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
2 Description
2.1 Operating elements
11
1
17
16
10
12
14
13
15
2
3
5
4
6
8
2
3
4
6
5
12
1
17
16
10
7
9
13
IVB 961-0L
IVB 965-0L SD XC
8
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
1 Handle
2 Applicance switch "I-0-II"
3 Receptacle for electrical lead
4 Inlet fitting
5 Dirt tank
6 Castor with brake
7 Swivel bar to remove dirt tank
8 Grip to empty tank
9 Handle to remove dirt tank
10 Retaining clamp
11 Suction pipe support
12 Bracket for floor nozzle
13 Accessory holder
14 Clamps and hinges for dirt tank
15 Operating knob for filter cleaning
16 Inlet for fresh air
17 Outlet for waste air
2.2 Operating panel
9
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
3.1 Assembling the
vacuum cleaner
3.1.1 Taking accessories out
of the packaging
1)
1. Take vacuum cleaner and
accessories out of the packaging.
2. The mains plug should not
yet be inserted into a socket.
3. Apply parking brakes (A) on
both castors.
4. Open the retaining clamps
(B) and remove the upper
section of the vacuum cleaner.
5. Take the accessories 1) out of
the dirt tank and the packaging.
x
a
uto
1. Attach the suction pipe holder to the suction pipe.
Accessory
diamater
Distance (x)
from pivot
joint to the
floor nozzle
approx. cm
38 52
50 47
3.1.2 Attaching the suction
pipe holder to the
suction pipe
1)
3 Before starting the cleaner
A
A
B B
10
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
3.1.3 Inserting the filter bag
(IVB 961-0L)
1. The mains plug should not
yet be inserted into a socket.
2. Apply parking brakes (A) on
both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum cleaner.
4. Insert the filter bag (C) in the
dirt tank.
5. Attach the upper section of
the vacuum cleaner.
6. Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.
A
A
B B
B
B
11
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
3.1.4 Inserting the disposal
bag (IVB 965-0L SD XC)
1. The mains plug should not
yet be inserted into a socket.
2. Apply parking brakes (A) on
both castors.
3. Swing the bar (B) upwards.
4. Use the handle (C) to pull the
dirt tank out of the vacuum
cleaner.
5. Insert the disposal bag (D) in
the dirt tank.
6. Fold the top edge of the disposal bag over the rim of the
dirt tank.
7. Push the dirt tank as far as
possible into the vacuum
cleaner.
8. Swing the bar (B) downwards
without forcing it.
A
A
B
C
D
B
12
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
4.2 Switching on the
vacuum cleaner
4.2.1 Switch " I-0-II "
Switch
position
Function
I
Reduced
suction
0
Off
II
Maximum
suction
4 Operation
4.1 Connections
4.1.1 Connecting the suction
hose
4.1.2 Electrical connection
The operating voltage shown on the
rating plate must corres pond to the
voltage of the mains power supply.
1. Ensure that the cleaner is
switched off.
2. Insert the power cord into a
properly installed and fused
socket with earthing contact.
1. Connect the suction hose.
13
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
4.3 Cleaning the filter
element
4.3.1 Cleaning the filter
element " Push&Clean
System " (IVB 961-0L)
Only for vacuum cleaning without a
filter bag and without a cloth insert
filter.
If suction performance drops:
1. Turn switch to position "II" (maximum suction power).
2. Close the nozzles or suction hose opening with the palm of your
hand.
3. Press the button to start filter cleaning three times. The resulting
stream of air removes attached dust from the slats of the filter
elements.
4.3.2 Cleaning the
filter element
" XtremeClean "
(IVB 965-0L SD XC)
Only for vacuum cleaning without a
cloth insert filter.
10 sec.
To ensure that suction performance is always at its best, the filter
element is automatically cleaned during operation. We recommend
complete cleaning if the filter element becomes extremely dirty.
1. Switch off the vacuum cleaner
2. Close the nozzles or suction hose opening with the palm of your
hand.
3. Turn the switch to position „I“ and let the cleaner operate for approx. 10 seconds with the suction hose opening closed.
14
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
5 Applications and techniques
5.1 Techniques
If used correctly, additional accessories, suction nozzles and suction hoses can enhance the cleaning action and reduce the cleaning
effort.
Effective cleaning is achieved if you follow just a few guidelines in
combination with your own practical experience in special fields.
Here are some basic tips.
5.1.1 Picking up dry
substances
CAUTION!
Do not pick up flammable substances.
Before picking up dry substances, always ensure that a filter bag is
inserted in the tank (see section "Accessories" for order number).
Disposal of the picked up material is then simple and hygienic.
After picking up liquids, the filter element is wet. A damp filter element clogs more quickly when dry substances are picked up. For this
reason the filter element should be washed and dried or replaced by
a dry element before dry substances are picked up.
5.1.2 Picking up liquids CAUTION!
Do not pick up flammable liquids.
Before liquids are picked up, always remove the filter bag/disposal
bag.
The use of a separate filter element or filter screen is recommended.
If foam appears, stop work immediately and empty the tank.
To reduce the amount of foam, use foam killer Alto Foam Stop (see
section "Accessories" for order number).
15
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
6 After finishing work
6.1 Switching the vacuum
cleaner off and storage
1. Switch off the cleaner and
pull the mains plug out of the
socket.
2. Wind up the power cord and
hang it on the handle (A).
Begin winding up the cord at
the cleaner end and not the
plug end to prevent the power cord from tangling up.
3. Empty the dirt tank and clean
the vacuum cleaner.
4. After picking up liquids: Store
the upper section of the vacuum cleaner separately so
that the filter element can
dry.
5. Hang the suction hose with
the floor nozzle (B) in the
brackets and pack the accessories (C) away.
6. Store the cleaner in a dry
room where it is protected
from unauthorized use.
au
to
A
B
C
16
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
7 Maintenance
7.1 Maintenance plan
IVB 961-0L:
After finishing work When required
7.2.1 Emptying the dirt tank
7.2.3 Replacing the filter bag
7.2.5 Replacing filter element
IVB 965-0L SD XC:
After finishing work When required
7.2.2 Emptying the dirt tank
7.2.4 Replacing the disposal bag
7.2.5 Replacing filter element
17
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
7.2 Maintenance work
7.2.1 Emptying the dirt tank
(IVB 961-0L)
Only after picking up harmless
dust.
After emptying the tank: clean the
rim of the tank and the seals in the
intermediate ring and the upper section of cleaner before refitting them.
If the seal or groove is dirty or damaged, the suction performance will
be reduced.
Before reinserting the suction hose:
clean the inlet fitting and hose collar.
1. Switch off the vacuum cleaner and pull the mains plug
out of the socket.
2. Apply parking brakes
(A) on both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum cleaner.
Tilting the dirt tank:
4. Pull the lever in the handle
(C) upwards and tilt the tank.
5. Tip out the collected dirt.
6. Dispose of the dirt in accordance with legal regulations.
or
Removing the dirt tank:
4. Open the tank locks (D).
5. Use the handles (E) to lift the
tank out of the frame.
6. Tip out the collected dirt.
7. Dispose of the dirt in accordance with legal regulations.
8. Place the empty tank in the
frame and close the locks
(D).
9. Attach the upper section of
the vacuum cleaner.
10. Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.
C
A
A
D
E
E
D
B B
B
B
18
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
7.2.2 Emptying the dirt tank
(IVB 965-0L SD XC)
Only after picking up harmless
dust.
After emptying the tank: clean the
rim of the tank and the seals in the
intermediate ring and the upper section of cleaner before refitting them.
If the seal or groove is dirty or damaged, the suction performance will
be reduced.
Before reinserting the suction hose:
clean the inlet fitting and hose collar.
1. Switch off the vacuum cleaner and pull the mains plug
out of the socket.
2. Apply parking brakes (A) on
both castors.
Removing the dirt tank:
3. Swing the bar (B) upwards.
4. Use the handle (C) to pull the
dirt tank out of the vacuum
cleaner.
5. Tipping out the collected dirt:
WARNING!
If heavy dirt has been picked
up, never lift the dirt tank
alone. Use the FORKLIFT
(D), which is available as an
accessory.
6. Use a crane or fork lift truck
to position the FORKLIFT
above the dirt tank.
7. Attach the tank to the accessory.
8. Dispose of the dirt in accordance with legal regulations.
Inserting the dirt tank:
9. Clean the dirt tank.
10. Check the seals (E) between
the tank and the upper section of the vacuum cleaner.
11. Push the dirt tank as far as
possible into the vacuum
cleaner.
12. Swing the bar (B) downwards
without forcing it.
A
A
B
C
D
E
19
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
Removing the filter bag:
4. Carefully remove the filter
bag connection from the inlet
fitting (C).
5. Close the filter bag connection (1) with the hinged lid.
6. Dispose of the filter bag in
accordance with legal regulations.
Inserting the filter bag:
7. Clean the dirt tank.
8. Insert the filter bag in the dirt
tank.
9. Press the bush of the new filter bag firmly on to the inlet
fitting (C).
7.2.3 Replacing the filter bag
(IVB 961-0L)
During the following work, ensure
that dust is not unnecessarily spread
around. Wear a P2 breathing mask.
If the filter bag has heavy dirt, remove the bag by tilting the tank.
1. Switch off the vacuum cleaner and pull the mains plug
out of the socket.
2. Apply parking brakes (A) on
both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum cleaner.
10. Attach the upper section of the
vacuum cleaner.
11. Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.
A
A
B
B
B B
C
C
D
20
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
7.2.4 Replacing the disposal
bag
(IVB 965-0L SD XC)
During the following work, ensure
that dust is not unnecessarily spread
around. Wear a P2 breathing mask.
1. Switch off the vacuum cleaner and pull the mains plug
out of the socket.
2. Apply parking brakes (A) on
both castors.
Removing the disposal bag:
3. Swing the bar (B) upwards.
4. Use the handle (C) to pull the
dirt tank out of the vacuum
cleaner.
5. Close the disposal bag with
string (D) and remove it from
the dirt tank.
WARNING!
If heavy dirt has been picked
up, never lift the dirt tank
alone. Use the FORKLIFT
(E), which is available as an
accessory.
6. Use a crane or fork lift truck
to position the FORKLIFT
above the dirt tank.
7. Attach the tank to the accessory.
8. Dispose of the dirt in accordance with legal regulations.
Inserting the disposal bag:
9. Clean the dirt tank.
10. Check the seals (F) between
the tank and the upper section of the vacuum cleaner.
11. Insert the disposal bag (G) in
the dirt tank.
12. Fold the top edge of the disposal bag over the rim of the
dirt tank.
13. Push the dirt tank as far as
possible into the vacuum
cleaner.
14. Swing the bar (B) downwards
without forcing it.
A
A
B
C
E
F
B
G
D
21
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
7.2.5 Replacing filter element
During the following work, ensure
that dust is not unnecessarily spread
around. Wear a P2 breathing mask.
Never use the vacuum clean er without a filter.
1. Switch off the vacuum cleaner and pull the mains plug
out of the socket.
2. Apply parking brakes (A) on
both castors.
3. Open the retaining clamps
(B) and remove the upper
section of the vacuum cleaner.
Removing the filter element:
4. Lay the upper section of the
cleaner down with the fi lter
element facing upwards.
5. Open the bar handle (C) and
remove it.
6. Remove the filter holder (D).
7. Carefully remove the filter element (E).
8. Dispose of the used filter element in accordance with legal regulations.
Inserting the filter element:
9. Clean the filter seal (F).
Check it for damage and replace it if necessary.
10. Check the antistatic pin (G)
for damage. If necessary,
have it replaced by NilfiskAdvance Service.
11. Push new filter element (E)
onto the filter holder.
12. Attach filter holder (D).
13. Attach bar (C) and close.
14. Attach the upper section of the
vacuum cleaner.
15. Close the retaining clamps
(B). Ensure that the retaining
clamps fit properly.
C
D
C
D
A
A
B B
B
B
E
E
F G
22
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
8 Troubleshooting
Fault Cause Remedy
‡ Motor does not start > Fuse of the mains socket has
blown.
• Connect mains fuse.
> Overload protection switch
has tripped.
• Switch off the vacuum cleaner
and allow it to cool for approx.
5 minutes. If the cleaner
cannot be started again,
contact the Nilfisk-Advance
service department.
> Motor is faulty. • Have motor changed by
Nilfisk-Advance Service.
‡ Reduced suction power > Suction power selected with
suction power control is too
low.
• Set suction power in
accordance with section
„Setting suction power“.
> Clogged suction hose/nozzle. • Clean suction hose/nozzle
> Tank, disposal bag or filter
bag is full.
• See "Emptying tank" or
"Replacing disposal bag, filter
bag" sections.
> Filter element is clogged. • See section „Cleaning filter
element“ and „Replacing filter
element“.
> Seal between tank and upper
section of vacuum cleaner is
faulty or missing.
• Replace seal.
> Cleaning mechanism is
defective.
• Contact Nilfisk-Advance
Service.
‡ No suction power during
wet cleaning
(IVB 961-0L)
> Tank is full. • Switch off the cleaner. Empty
the tank.
‡ Voltage fluctuations > Impedance of power supply is
too high.
• Connect the cleaner to another
socket closer to the fuse box.
Voltage fluctuations over
7% should not occur if the
impedance at the transfer point
is ≤ 0.15 Ω .
23
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
9 Further information
9.1 Recycling the cleaner
Make the old cleaner unusable immediately.
1. Unplug the cleaner.
2. Cut the power cord.
3. Do not discard of electrical appliances with household waste.
As specified in European Directive 2002/96/EC on old elec-
trical and electronic appliances, used electrical goods must
be collected separately and recycled ecologically. Contact
your local authorities or your nearest dealer for further information.
9.2 Guarantee
Our general conditions of business are applicable with regard to the
guarantee.
Unauthorised modifications to the appliance, the use of incorrect
brushes in addition to using the appliance in a way other than for the
intended purpose exempt the manufacturer from any liability for the
resulting damage.
9.3 Tests and approvals
Electrical tests must be per formed in accordance with the provisions
of safety regulations (VBG4) and to DIN VDE 0701 Part 1 and Part
3. In ac cord ance with DIN VDE 0702 these tests must be performed
at regular intervals and after repairs or modifications.
The vacuum cleaner has been approved in accordance with IEC/EN
60335-2-69.
9.4 EC declaration of
conformity
EC conformity declaration
Product: Vacuum cleaner for wet and dry operation
Type: IVB 961-0L
IVB 965-0L SD XC
The design of the unit corre sponds to the
following pertinent regulations:
EC Machine Directive 2006/42/EC
EC EMC Directive 2004/108/EC
EC - RoHS Directive 2011/65/EC
Applied harmonised standards: EN ISO 12100-1, EN ISO 12100-2
EN 60335-1, EN 60335-2-69, EN 55014-1,
EN 55014-2, EN 61000-3-2
Applied international standards and
technical specifi cations:
IEC 60335-2-69 (2009)
IEC 60335-1
Name and address of the person authorised to compile the technical fi le:
Anton Sørensen
General Manager, Technical Operations
EAPC
Nilfi sk-Advance A/S
Sognevej 25
DK-2605 Brøndby
Identity and signature of the person
empowered to draw up the declaration on
behalf of the manufacturer: Anton Sørensen
General Manager, Technical Operations
EAPC
Nilfi sk-Advance A/S
Sognevej 25
DK-2605 Brøndby
Place and date of the declaration:
Hadsund, 2013-09-26
24
IVB 9 L
1)
Optional accessories / Option depending on model
Original instruction
9.5 Technical data
IVB
961-0L 965-0L SD XC
Voltage V
230 (EU,GB)
110 (GB)
Mains frequency Hz 50/60
Fuse A
13 (GB 230V)
16 (EU)
32 (GB 110 V)
Power consumption
max
W
2 x 1150 (GB 110 V)
2 x 1500 (EU,GB)
Power consumption
IEC
W
2 x 1000 (GB 110 V)
2 x 1200 (EU, GB)
Air flow rate
m3/h
l/min
2 x 216 (EU, GB) / 2 x 174 (GB 110 V)
2 x 3600 (EU, GB) / 2 x 2900 (GB 110 V)
Vacuum
hPa/mbar
kPa
230 (EU, GB) / 210 (GB 110 V)
23 (EU, GB) / 21 (GB 110 V)
Sound pressure level at a
distance of 1 m, EN 60704-1
dB(A) 70 ± 2
Sound level dB(A) 67 ± 2
Power cord: Length m 10
Power cord: Type
H07RN-F3G1.5 mm² (EU, GB 230 V)
H07RN-F3G2.5 mm² (GB 110 V)
Protection class I
Type of protection (splash
water protected)
IP X4
Radio interference level EN 55014-1
Tank volume l 70 50
Width mm 610 640
Depth mm 645 725
Height mm 985 1020
Weight kg 36 42
9.6 Optional accessories
Description Order No.
Filter bag (5 pcs.) IVB 961-0L 302002892
Disposal bag (5 pcs.) IVB 965-0L SD XC 302001480
Filter element 107400562
Cloth insert filter 302002894
Alto-Foam-Stop (6 x 1 l) 8469
DENMARK
Nilfi sk-Advance A/S
Sognevej 25
DK-2605 Brøndby
Tel.: (+45) 4323 8100
www.nilfi sk-advance.com
SALES COMPANIES
ARGENTINA
Nilfi sk – Advance S.R.L.
Herrera 1855 6º piso Of. A-604
CP 1293 – Ciudad Autónoma de Buenos Aires
www.nilfi sk.com.ar
AUSTRALIA
Nilfi sk-Advance
Unit 1, 13 Bessemer Street Blacktown
NSW 2148 Australia
www.nilfi sk.com.au
AUSTRIA
Nilfi sk-Advance
Metzgerstrasse 68
A-5101 Bergheim/Salzburg
www.nilfi sk.at
BELGIUM
Nilfi sk-Advance NV/SA.
Riverside Business Park
Boulevard Internationale 55
Bruxelles 1070
www.nilfi sk.be
CHILE
Nilfi sk-Advance S.A.
San Alfonso 1462, Santiago
www.nilfi sk.com
CHINA
Nilfi sk-Advance Cleaning Equipment (Shanghai) Ltd.
No. 4189 Yindu Road
Xinzhuang Industrial Park
Shanghai 201108
www.nilfi sk.cn
CZECH REPUBLIC
Nilfi sk-Advance s.r.o.
VGP Park Horní Pocernice
Budova H2, Do Certous 1
Praha 190 00
www.nilfi sk.cz
DENMARK
Nilfi sk Danmark
Sognevej 25
DK-2605 Brøndby
www.nilfi sk-advance.com
FINLAND
Nilfi sk-Advance Oy Ab
Koskelontie 23E
02920 Espoo
www.nilfi sk.fi
FRANCE
Nilfi sk-Advance
26 Avenue de la Baltique
Villebon sur Yvette
BP 246
91944 Courtaboeuf Cedex
www.nilfi sk.fr
GERMANY
Nilfi sk
Geschäftsbereich der Nilfi sk-Advance AG
Siemensstrasse 25-27
25462 Rellingen
www.nilfi sk.de
GREECE
Nilfi sk-Advance A.E.
8, Thoukididou Str.
Argiroupoli,Athens, GR-164 52
www.nilfi sk.gr
HOLLAND
Nilfi sk-Advance BV
Versterkerstraat 5
1322 AN Almere
www.nilfi sk.nl
HONG KONG
Nilfi sk-Advance Ltd.
Room 2001 HK Worsted Mills, Industrial Building
31-39 Wo Tong Tsui Street
Hong Kong, Kvai Chung, N.T.
www.nilfi sk.com
HUNGARY
Nilfi sk-Advance Kereskedelmi Kft.
H-2310 Szigetszentmilós-Lakihegy
II. Rákóczi Ferenc út 10
www.nilfi sk.hu
INDIA
Nilfi sk-Advance India Limited
Pramukh Plaza, “B” Wing, 4th fl oor, Unit No. 403
Cardinal Gracious Road, Chakala
Andheri (East), Mumbai 400 099
www.nilfi sk.com
IRELAND
Nilfi sk-Advance
1 Stokes Place
St. Stephen’s Green
Dublin 2, Ireland
www.nilfi sk.ie
ITALY
Nilfi sk-Advance S.p.A.
Strada Comunale della Braglia, 18
26862 Guardamiglio (LO)
www.nilfi sk.it
JAPAN
Nilfi sk-Advance Inc.
1-6-6 Kita-shinyokohama
Kouhoku-ku
Yokohama, 223-0059
www.nilfi sk-advance.co.jp
KOREA
NIlfi sk-Advance Korea
471-4, Kumwon B/D 2F
Gunja-Dong, Gwangjin-Gu, Seoul
www.nilfi sk-advance.kr
MALAYSIA
Nilfi sk-Advance Sdn Bhd
SD 33, Jalan KIP 10
Taman Perindustrian KIP
Sri Damansara
52200 Kuala Lumpur
Malaysia
www.nilfi sk.com
MEXICO
Nilfi sk Advance de Mexico S. de R.L. de C.V.
Agustin M. Chavez 1, PB-004
Col. Centro Ciudad Santa Fe
C.P. 01210 México, D.F.
www.nilfi sk-advance.com.mx
NEW ZEALAND
Nilfi sk-Advance NZ Ltd
Danish House
6 Rockridge Avenue
Penrose Auckland NZ 1135
www.nilfi sk.com.au
NORWAY
Nilfi sk-Advance AS
Bjørnerudveien 24
N-1266 Oslo
www.nilfi sk.no
POLAND
Nilfi sk-Advance Sp. z.o.o
ul. 3-go Maja 8, Bud. B4
Pruszków, PL-05-800
www.nilfi sk.pl
PORTUGAL
Nilfi sk-Advance
Sintra Business Park
Zona Industrial Da Abrunheira
Edifi cio 1, 1° A
P2710-089 Sintra
www.nilfi sk.pt
RUSSIA
Nilfi sk-Advance LLC
Vyatskaya str. 27, bld. 7, 1st fl oor
Moscow, 127015
www.nilfi sk.ru
SOUTH AFRICA
WAP South Africa (Pty) Ltd
12 Newton Street
1620 Spartan, Kempton Park
www.wap.co.za
SPAIN
Nilfi sk-Advance, S.A.
Torre D’Ara
Passeig del Rengle, 5 Plta.10ª
Mataró, E-0830222
www.nilfi sk.es
SWEDEN
Nilfi sk
Sjöbjörnsvägen 5
117 67 Stockholm
www.nilfi sk.se
SWITZERLAND
Nilfi sk-Advance AG
Ringstrasse 19
Kirchberg/Industrie Stelz
Wil, CH-9500
www.nilfi sk.ch
TAIWAN
Nilfi sk-Advance Ltd.
Taiwan Branch (H.K.)
No. 5, Wan Fang Road, Taipei
www.nilfi sk-advance.com.tw
THAILAND
Nilfi sk-Advance Co. Ltd.
89 Soi Chokechai-Ruammitr
Viphavadee-Rangsit Road
Jomphol, Jatuchak
Bangkok 10900
www.nilfi sk.com
TURKEY
Nilfi sk-Advance A.S.
Serifali Mh. Bayraktar Bulv. Sehit Sk. No: 7
Ümraniye, Istanbul 34775
www.nilfi sk.com.tr
UNITED KINGDOM
Nilfi sk (A Division of Nilfi sk-Advance Ltd)
Nilfi sk House
24 Hillside Road
Bury St Edmunds, Suffolk
IP32 7EA
www.nilfi sk.co.uk
UNITED ARAB EMIRATES
Nilfi sk-Advance Middle East Branch
SAIF-Zone, P. O. Box 122298
Sharjah
www.nilfi sk.com
VIETNAM
Northern
Nilfi sk-Advance Co.Ltd.
No.51 Doc Ngu Str.
Lieu Giai Ward
Ba Dinh Dist. Hanoi
www.nilfi sk.com
HEAD QUARTER
Southern
Pan Trading JSC
236/43/2 Dien Bien
Phu Str. Ward 17
Binh Thanh Dist. HCMC
www.nilfi sk.com
Loading...
