E 130.3, E 140.3, E 145.3
User Manual
128332518 b (05.2014)
EN-DA-NO-SV-FI-DE-FR-NL-IT-ES-PT-ELTR-CS-HU-PL-HR-SL-SK-LV-LT-ET-RU-ZH
EN
DA
NO
SV
FI
DE
FR
NL
IT
ES
PT
EL
TR
CS
HU
PL
HR
SL
SK
LV
LT
ET
RU
ZH
User Manual ................................................................ 3 - 18
Instruktionsbog ............................................................ 19 - 34
Instruksjonsbok............................................................ 35 - 50
Instruktionsbok ............................................................ 51 - 66
Käyttöohje.................................................................... 67 - 82
Betriebsanleitung ......................................................... 83 - 100
Instructions d’utilisation ............................................... 101 - 119
Gebruiksaanwijzing ..................................................... 120 - 137
Istruzioni sull’uso ......................................................... 138 - 155
Instrucciones de manejo.............................................. 156 - 173
Instruções de operação ............................................... 174 - 191
Οδηγίες χρήσης ........................................................... 192 - 211
Kullanım Kılavuzu ........................................................ 212 - 229
Návod k obsluze .......................................................... 230 - 245
Használati útmutató ..................................................... 246 - 262
Instrukcja użycia .......................................................... 263 - 279
Priručnik za korisnike................................................... 280 - 296
SL Navodila za uporabo .............................................. 297 - 311
Návod na používanie ................................................... 312 - 328
Lietošanas instrukcijae ................................................ 329 - 345
Naudojimosi instrukcija ................................................ 346 - 361
Kasutamisjuhend ......................................................... 362 - 377
Руководство ............................................................... 378 - 396
操作说明 ...................................................................... 397 - 409
3Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
Contents
1 Introduction .................................................................................................. 4
1.1 Symbols used to mark instruction .......................................................................4
2 Safety precautions and working techniques ................................................4
3 Before you start using your high pressure washer ................................10
3.1 Mounting of trolley handle, hose hook and hose reel .......................................10
3.2 Mounting of quick coupling ...............................................................................10
3.3 Telescopic handle .............................................................................................10
4 Operating your high pressure washer .....................................................11
4.1 Connection of high pressure hose ....................................................................11
4.2 Mounting of spray lance and Click&Clean nozzles ...........................................11
4.3 Water Connection .............................................................................................11
4.4 Starting the high pressure washer ....................................................................12
4.5 Pressure regulation on the TORNADO® PR- nozzle .........................................12
4.6 Stationary use ...................................................................................................12
5 Fields of application and working methods ............................................13
5.1 General .............................................................................................................13
5.2 Typical fi elds of application ...............................................................................14
6 After using the pressure washer ..............................................................15
6.1 Stopping the high pressure washer ..................................................................15
7 Maintenance ............................................................................................... 15
8 Troubleshooting .........................................................................................16
9 Accessories and detergents .....................................................................17
10 Warranty Conditions ................................................................................. 17
11 Main technical Data ...................................................................................17
12 Declaration of Conformity ......................................................................... 18
4
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
1 Introduction
1.1 Symbols used to mark instruction
All pictograms attached to the high pressure washer and its components are shown and explained in this manual.
Safety instructions marked with this symbol must be observed to prevent personal injury or
serious damage to property.
Caution where there is a risk of damaging the machine or its individual components.
This symbol indicates tips and instructions to simplify work and to ensure a safe operation of
the high pressure washer.
2 Safety precautions and working techniques
Before starting up your machine for the fi rst time, this instruction manual must be read through
carefully. Save the instructions for later use.
WARNING!
• Inhalation of aerosols can be hazardous to health.
Where applicable use a device in order to avoid or reduce aerosols production, e.g., a shield covering the
nozzle. For protection against aerosols use a respiratory mask of class FFP 2 or higher.
• The high water pressure generated by the machine
and the power connection are particular sources of
danger.
• Children should be supervised to ensure that they do
not play with the machine.
• Before starting up your machine please check it carefully for any defects. If you fi nd any, do not start up
your machine, contact your Nilfi sk distributor. The insulation of the electric cable should be faultless and
without any cracks. If the electric cable is damaged,
an authorized Nilfi sk di stributor should replace it.
• The operator and anyone in the immediate vicinity of
the site of cleaning should take action to protect themselves from being struck by debris dislodged during
operation.
• Always unplug the power plug before cleaning or
maintenance and when replacing parts or converting
5Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
the machine to another function.
• Observe the national safety regulations issued, for
example, by the employers liability insurance association, social security institutions, occupational safety
and health authorities or other organizations.
Accessories and spare parts
• To ensure the machine safety only use original spare
parts from Nilfi sk or approved by Nilfi sk.
• High pressure hoses, fi ttings and couplings are important for the safety of the machine. Only use hoses, fi ttings and couplings recommended by Nilfi sk.
Physical, sensory or mental conditions
• This machine is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities or lack of experience and
knowledge.
• Anyone who has consumed alcohol, medicines or
drugs affecting their ability to react must not operate
the machine.
Applications
This machine has been developed for domestic use
such as:
• Car, motorbike, boat, caravan, trailer, patio/drive/fl agstones, woodwork, brickwork, barbecue, garden furniture, lawn mower.
Any other use is considered as improper use. Nilfi sk
accepts no liability for any damage resulting from such
use. The risk for such use is borne solely by the user.
Proper use also includes proper operation, servicing
and repairs as specifi ed in this instruction.
Clothing and equipment
Always take action to protect yourself when operating
the machine.
• Wear shoes with non-slip soles.
• Wear goggles, ear protection and protective clothes
during operation.
6
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
Transporting the high pressure washer
• When transporting the machine in or on a vehicle, it
must be secured, e.g. with straps, so that it cannot slip
or tip over.
• Nilfi sk recommends that the machine is positioned
horizontally on the backside, when transported in or
on a vehicle.
Detergents
• This machine has been designed for use with cleaning agents supplied or recommended by Nilfi sk. The
use of other cleaning agents or chemicals may adversely affect the function of the machine.
Before starting the work
Inspecting the machine
• Do not use the machine if a supply cord or important
parts of the machine are damaged, e.g., safety device, high pressure hose, and spray handle and spray
attachments.
• The trigger of the spray handle must move easily and
automatically return to its starting position when released.
• Always keep high pressure hose and spray attachment in good condition (clean, moving easily) and correctly assembled.
Electrical connection
WARNING!
Minimize the risk for electrical shock:
• Voltage and frequency of the machine (see rating
plate) must match the voltage of and frequency of the
mains supply.
• Only connect the machine to electrical installation
made by a certifi ed electrician and com ply with IEC
60364-1.
• It is recommended that the electrical supply to the
machine should include a residual current device that
will interrupt the supply if the leakage current to earth
7Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
exceeds 30 mA for 30 ms.
• Inadequate extension cables can be dangerous. If an
extension cable is used, it shall be suitable for outdoor
use, and the connection has to be kept dry and off the
ground
• Nilfi sk recommends use of an extension cable drum
when cable extension is needed which keeps the
socket at least 60 mm above the ground.
• Cables on extension cable drums should always be
completely unwound to prevent overheating. Extension cables must comply with the below-mentioned requirements for length and cable dimensions:
1.0 mm² Max. 12.5 m
1.5 mm² Max. 20.0 m
2.5 mm² Max. 30.0 m
• If the electric cable is damaged, it must be replaced
by an authorized Nilfi sk distributor or similar qualifi ed
person in order to avoid a hazard.
Water connection
• This high pressure washer is only allowed to be connected with the drinking water mains, when an appropriate backfl ow preventer has been installed, Type BA
according to EN 60335-2-79.
• The backfl ow preventer can be ordered under number
106411177.
• As soon as drinking water has fl own through the backfl ow preventer, it is no longer regarded as drinking
water.
• Operation by suction (e.g. a rainwater vessel) is carried out without a backfl ow preventer – see “Connec-
ting to a pressureless water supply”.
IMPORTANT !
• Only use water without any impurities.
• If there is a risk of running sands in the inlet water
(i.e. from your own well), an additional fi lter should be
mounted.
8
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
During work
WARNING!
• Never use the machine in an environment where there
could be a danger of explosions. If any doubt arises
contact the local authorities.
• It is not allowed to clean asbestos-containing surfaces
with high pressure.
• Never draw in fl uids containing solvents (e.g., gasoline, heating oil, paint thinner or acetone) These substances damage the materials used in the machine.
Their spray is highly combustible, explosive and poisonous.
• Never direct the water jet at yourself, other persons,
not even to clean clothing or footwear - risk of injury.
• Never direct the water jet at pets or other animals.
• Never direct the water jet at live electrical equipment
or the machine itself - danger of short-circuiting.
• Hold the spray lance fi rmly with both hands. The spray
lance is affected by a thrust of up to 16.4 N during
operation.
• This high pressure washer machine must not be operated at temperatures below 0°C.
• Never start up a frozen machine. Frost damages are
not covered by the guarantee!
• Always ensure fi rm and safe footing.
• Keep the machine as far away as possible from the
object being cleaned.
• Always adjust the distance and thus the pressure of
the nozzle to the surface, which is to be cleaned to
avoid any damage to the surface being cleaned.
• The machine shall be operated in an upright position.
• Do not cover the machine or use it in a room without
adequate ventilation.
• If the machine is left or not used for 5 minutes, it must
be switched off on the start/stop switch "O" (1).
9Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
After fi nishing the work
WARNING!
• Always switch off the machine and unplug the power
plug from the socket after work and when leaving the
machine unattended.
• Disconnect water inlet hose between machine and
water supply.
• Wind up electrical cable and high pressure hose – to
avoid damage of cable, plug, high pressure hose and
fi ttings.
• Always empty pump, hose and accessories of water
after use of the machine and prior to storing.
Maintenance and repairs
WARNING!
• Always disconnect the electrical plug from the socket
prior to maintenance, cleaning and repair.
• Any repair should always be made in Nilfi sk
authorized workshop with original Nilfi sk spare parts.
• Do not attempt any maintenance not described in the
instructions.
• If the machine refuses to start, stops, pulsates, pressure fl uctuates, motor busses, fuse blows or no water comes out, check the trouble shooting diagram
in these instructions. In case other problems occur,
please contact your local Nilfi sk distributor.
Recycling the high pressure washer
Make the old machine unusable immediately.
• Unplug the machine.
• Cut the electric cable.
Do not discard electrical appliances with household
waste. As specifi ed in WEEE Directive 2012/19/EC on
old electrical and electronic appliances, used electrical
goods must be collected separately and recycled ecologically. Contact your local authorities or your nearest
dealer for further information.
10
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
3 Before you start using your high pressure washer
See the pictorial quick reference guide – unpacking.
Illustration shows the operation elements and how to prepare your machine for use.
Operation elements
1. Start/stop switch
2. Water inlet with fi lter
3. High pressure connection (models without hose reel)
4. High pressure hose
5. Electric cable
6. Click&Clean spray lance
7. Spray handle with lock (7a)
8. Click&Clean Tornado PR nozzle
9. Click&Clean Powerspeed nozzle
10. Foam sprayer
11. Nozzle cleaning tool
12. Hose reel (not standard)
13. Model tag
14. Trolley handle (telescopic handle)
15. Hose hook
16. Hexagon key for handle and bracket mounting
17. Button for telescopic handle
18. Turnable cable hook
19. Quick coupling
3.1 Mounting of trolley handle, hose hook and hose reel
Mounting of trolley handle and hose hook (standard models)
A1 Push down the trolley handle (14) over the two metal tubes. Make sure that the handle
is mounted as illustrated. Mount screws with nuts (make sure that the screws go through
handle as well as tube).
A2 Mount the hose hook (15) on the handle (2 screws).
Mounting of hose reel handle (models with hose reel)
A3 Click the hose reel handle on to the trolley handle (no screws).
3.2 Mounting of quick coupling
A4 When mounting the quick coupling for the fi rst time, check that the factory fi tted fi lter is
positioned in the water inlet pipe.
A5 Screw the quick coupling tight on to the water inlet (2).
IMPORTANT!
The inlet fi lter must always be fi tted in the water inlet pipe to fi lter out sand, lime stone and other
impurities as these will damage the pump valves. The fi lter is factory fi tted.
If the fi lter is removed this will invalidate the guarantee.
3.3 Telescopic handle
A6 The machine features a tele scopic handle. To raise or lower the handle, press the button
(17) and move the handle upwards or downwards. When a click is heard, the handle is in
right position.
A
11Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
4 Operating your high pressure washer
See the pictorial quick reference guide – operating your high pressure washer.
4.1 Connection of high pressure hose
B1 Attach the high pressure hose (4) to the spray handle (7). Detach the high pressure hose
by pressing the pawl (A).
B2 Mount the high pressure hose on the outlet (3).
4.2 Mounting of spray lance and Click&Clean nozzles
B3 Push the spray lance (6) into the spray handle (7), twist and release.
NOTE!
The spray lance has a built-in low pressure nozzle that can be used for fl ushing away
dirt.
B4 When attaching the nozzles (8, 9), press the nozzles into the spray lance.
IMPORTANT!
When attaching the click & Clean nozzles, the pawl on the side of the spray lance should come
out again. The nozzle should stay in position when pulling it.
B5 Push the foam sprayer (10) into the spray lance (6).
NOTE!
The foam sprayer features a swivel lock, which must be positioned in the hole in the Click &
Clean spray lance. Press the pawl to detach the Click & clean nozzles and the foam sprayer.
IMPORTANT!
Before starting the cleaning job, check that the machine is in an upright position and placed on
an even surface. Do not place the machine in long grass!
4.3 Water Connection
IMPORTANT!
Connecting to pressurized water supply
The inlet water max. pressure is 1 MPa/10 bar and the max. temperature is 60°C – see rating
plate. An ordinary ½" garden hose of min. 10 m and max. 25 m will be suitable.
B6 Check that the fi lter is fi tted in the water inlet pipe and that it is not clogged up.
B7 Connect the water hose to the water supply by means of the quick connector. Turn on the
water.
Connection to the drinking water mains according to national and local regulations.
Let the water run through the water hose before connecting it to the machine to prevent sand
and dirt from penetrating the machine.
B8 Turn off the water and connect the water hose by means of the quick coupling to the wa-
ter inlet.
Connecting to pressure less water supply
The machine can also operate in suction mode, meaning that you can connect the machine to
e.g. rainwater vessels, rivers, lakes and cisterns etc. When taking in water from non drinking
water mains the backfl ow preventer is not needed.
B
12
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
When connecting the machine to operate from pressure less water supplies – always use additional fi ltering to secure that impurities are not sucked in. Hose length should be max. 3 meter
and of minimum ½".
To meet these requirements, Nilfi sk recommends that you use the original Nilfi sk suction hose
kit.
The Machine is designed for suction up to 100 cm above water surface.
• Position the machine at max. 1.0 meter above the water surface. Detach the high pressure
hose from the outlet.
• Ensure that the inlet fi lter is in position and attach the suction hose kit, secure tight connection to the inlet.
• Turn on the machine, turning the start/stop switch (1) to position "I".
• Wait until a steady jet exits the outlet.
• Switch off the machine and attach high pressure hose (4), spray handle, lance and nozzle.
• Start the machine again and activate the spray handle.
4.4 Starting the high pressure washer
IMPORTANT!
Connecting to mains power supply
The voltage and frequency of the machine (see model tag (13)) must match the voltage and
frequency of the power supply.
Connecting the high pressure washer to a supply system, the max allowed impedance is =
0,29+j0,18 (Zmax). Consult with the supply authority that the equipment is connected only to
a supply of that impedance or less.
B9 Insert the power plug into power supply socket.
B10 Turn on the water.
B11 Release the trigger lock (7a). Remember to unplug, turn off the high pressure washer and
lock the trigger, when leaving the high pressure washer unattended
B12 Activate the trigger of the spray handle and let the water run until all air has escaped from
the water hose.
B13 Turn on the machine, turning the start/stop switch to position "I".
B14 Activate the trigger of the spray handle. When releasing the trigger of the spray handle,
the machine automatically stops. The machine will start again when you reactivate the
trigger of the spray handle.
4.5 Pressure regulation on the TORNADO® PR- nozzle
B15 The pressure can be regulated on the TORNADO
®
PR nozzle.
4.6 Stationary use
B16 If mounting a special wall hook (not standard), the pressure washer can be used as a
stationary solution meaning that it can be operated while hanging on the wall.
Only mount the wall hook on a sturdy wall. Adjust the length of the screws and size of
rawlplugs to the type of wall.
B17 On the wall hook garden/rim brush (a) foam sprayer (b), Click & Clean brush (c) and Click
& Clean nozzles (d) can be stored.
IMPORTANT!
The bearing capacity of the wall hook is max. 30 kg.
13Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
5 Fields of application and working methods
5.1 General
Effi cient high presure cleaning is achieved by following a few guidelines, combined with your
own personal experience of specifi c cleaning tasks. Accessories and detergents, when correctly chosen, can increase the effi ciency of your pressure washer. Here is some basic information
about cleaning.
5.1.1 Detergent and foam
Foam or detergent should be applied onto dry surfaces so that the chemical product is in direct
contact with the dirt. Detergents are applied from bottom to top, for example on a car bodywork, in order to avoid "super clean" areas, where the detergent collects in higher concentration and streams downwards. Let the detergent work for several minutes before rinsing but never
let it dry on the surface being cleaned. Note: It is important that the detergents do not dry up.
Otherwise the surface that has to be cleaned can be da maged.
5.1.2 Mechanical effect
In order to break down tough layers of dirt, additional mechanical effect may be required. Special wash brushes offer this supplementary effect that cuts through dirt (especially by car washing).
14
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
5.2 Typical fi elds of application
Below you will fi nd a description of a lot of cleaning tasks which can be solved by a pressure washer from
Nilfi sk in association with accessories and detergents.
Task Accessories ‘Click
& Clean’
Cleaning method
Car
Car nozzle,
auto brush,
underchassis
nozzle,
Foam sprayer,
Car Combi Cleaner
1. Apply Car Combi Cleaner with the foam sprayer. Always
start from the bottom and work upwards. Let Car Combi
Cleaner act for at least 5 min.
2. Wash the car with the car nozzle, which has been optimized for
quick and gentle cleaning of enamelled surfaces (the jet is wider
and not so sharp). Start at the front of the car and work backwards to avoid water from penetrating by the door mouldings.
3. Use the brush for removal of traffi c fi lm which is not removed by the
nozzle. If the car is very dirty, apply Car Combi Clean er again.
4. Attach the undercarriage nozzle and clean undercarriage and
wheel arches.
5. Remove water from the surface of the car with the scraper
on the car brush. Make sure that all grains of sand etc. have
been removed before using the scraper. Wipe with a wash leather where the scraper cannot reach.
Rims, alumi-
nium
Rim brush,
auto nozzle,
atomizer,
Alu Cleaner
Apply Alu Cleaner with an automizer. Let it act for approx.
5 min. and wash with the rim brush. For steel rims, use Car Combi Cleaner. Use the foam sprayer and wash with rim brush.
Be careful! The high pressure jet may damage the tyres.
Flagstones,
concrete
fl oors and
other hard
surfaces
Powerspeed®
nozzle,
Stone & Wood
Cleaner,
Patio Cleaner
Wash towards outlets or the like. On surfaces with foulings you
may start by applying Stone & Wood Cleaner with
the foam sprayer. Wash before the soap dries. Another
more effective and quicker method is to use the Patio
Cleaner. Thus you will also avoid splashes.
Garden furni-
ture, wood
Wood Cleaner
Garden brush
Apply Wood Cleaner and wash before the soap dries.
NOTE: Use the garden brush to clean off the dirt.
Brickwork,
Wood work
Powerspeed®
nozzle,
Stone & Wood
Cleaner,
Patio Cleaner
Same method as for fl agstones, but be careful - bad joints and
wood may be damaged by high pressure. You may choose only
to use the Tornado® nozzle. Adjust the distance (pressure) to
the quality of the joints and the wood. Patio Cleaner can also be
used on vertical surfaces.
Gutter
Underchassis spray
lance
Wash the gutter with the nozzle. Always wash towards
downpipes. Beware not to spray under the roofi ng.
Cleaning of
drain pipes,
outlets, down
pipes etc.
Tube cleaner Push the tube cleaner approx. ½ m (to mark) into a tube or drain
and activate the trigger of the spray handle. The nozzle opening
turning backwards will pull the cleaner through the tube. The
nozzle will break down the „plug“ and fl ush the dirt backwards.
Rust, paint
Water/sandblasting
equipment
Mount the water/sand blasting equipment and rust and paint
is effi ciently and quickly removed. Beware not to damage the
surface to be sandblasted.
Greenhouse
Tornado® PR nozzle
brush, Stone &
Wood Cleaner
Wash with high pressure and maybe a brush. You may use Stone
& Wood Cleaner to remove moss and algae.
Garden tools,
lawn mover
Tornado
®
PR
nozzle, Powerspeed
®
nozzle,
multiangle adaptor,
Metal Cleaner
Rinse the worst dirt off with the nozzle. Apply Metal Cleaner with
the foam sprayer and let it act for approx. 5 min. Wash with the
nozzle. You may use the multiangle adaptor for hard to get at
areas to avoid splashing.
15Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
6 After using the pressure washer
See the pictorial quick reference guide – storing the high pressure washer.
The high pressure washer should be stored in a frost free room! Should the machine by a mistake be frozen, it will be necessary to check it for damages.
6.1 Stopping the high pressure washer
C1 Shut off the water supply and activate the trigger of the spray handle and let the machine
run until no more water runs out of the nozzle. This will wash out water hose, high pressure hose, spray lance and nozzles.
C2 Stop the machine, turning the start/stop switch to position "0".
C3 Unplug the machine from the power supply socket.
IMPORTANT!
To avoid accidents, the electric cable and the high pressure hose should always be wound up
carefully.
C4 Wind up the electric cable on the dedicated cable hook (18). The upper hook can be
turned to release the electric cable. The upper hook has a built-in clip for good holding of
the electrical cable.
C5 The high pressure washer comes in two models: A) with hook for storage of high pres-
sure hose (15) - B) with a hose reel (12).
C6 Rinse the spray lance, nozzles and the foam sprayer after use.
C7 Place spray handle (f), lance (a), nozzles (b), foam sprayer (c) in the holders on the high
pressure washer. The nozzle cleaning tool (d) and a Click & Clean brush (e) can also be
stored on the product.
7 Maintenance
See the pictorial quick reference guide - maintenance.
To ensure a long and problem free working life of the high pressure washer, please take the
following advices:
• Wash out water hose, high pressure hose, spray lance and accessory before mounting
• Clean the connectors of dust and sand
• Rinse the detergent bottle and the detergent nozzle
• Clean the nozzle
• Keep the water inlet fi lter clean and unclogged
Cleaning of the water inlet fi lter
D1 Clean the water inlet fi lter regularly once a month or more frequently according to use.
Carefully loosen the fi lter with a screwdriver and clean it. Check that it is intact before remounting it.
Cleaning of nozzle
A clogging up in the nozzle causes a pump pressure which is too high, why cleaning is required immediately.
IMPORTANT!
The nozzle cleaning tool (11) should only be used when the nozzle is detached and the machine is stopped!
D2 Stop the machine and disconnect the nozzle. Clean the nozzle.
I
O
C
D
16
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
D3 Flush the nozzle backwards with water.
Cleaning of machine vents
D4 The machine should be kept clean so as to let cooling air pass freely through the
machine vents.
Greasing of O-rings
D5 To ensure an easy connection and that O-rings do not dry up the couplings should
be greased regularly.
In case problems other than the above occur, please contact your local Nilfi sk distributor. Local Nilfi sk
distributors are listed on the back cover of this instruction.
Customer Service at Penrith – 01768 868995
8 Troubleshooting
To avoid unnecessary disappointments, you should check the following before contacting the Nilfi sk
service organization.
Symptom Cause Recommended action
Machine refuses to
start
Machine not plugged in
Defective socket
Fuse has blown
Defective extension cable
Plug in machine
Try another socket.
Replace fuse. Switch off other machines.
Try without the extension cable.
Fluctuating pressure
Pump sucking air
Valves dirty, worn out or stuck
Pump seals worn out
Check that hoses and connections are airtight.
Clean and replace or refer to local Nilfi sk distributor.
Clean and replace or refer to local Nilfi skdistributor.
Machine stops
Fuse has blown
Incorrect mains voltage
Thermal sensor activated
Nozzle partially blocked
Replace fuse. Switch off other machines.
Check that the mains voltage corresponds
to specifi cation on the model tag.
Leave the washer for 5 minutes to cool
down.
Clean the nozzle (see section 7)
Fuse blows
Fuse too small Change to an installation higher than the
amp. consumption of the machine.
You may try without the extension cable.
Machine pulsating
Air in inlet hose/pump
Inadequate supply of mains
water
Nozzle partially blocked
Water fi lter blocked
Hose kinked
Allow machine to run with open trigger until
regular working pressure resumes.
Check that the water supply corresponds to
specifi cations required (see model tag)
NB! Avoid using long, thin hoses (min. 1/2")
Clean the nozzle (see section 7)
Clean the fi lter (see section 7)
Straighten out hose.
Machine often starts
and stops by itself
Pump/spray handle is leaking Contact your nearest Nilfi sk Service Centre.
Machine starts, but no
water comes out
Pump/hoses or accessory
frozen
No water supply
Water fi lter blocked
Nozzle blocked
Wait for pump/hoses or accessory to thaw.
Connect inlet water.
Clean the fi lter (see section 7)
Clean the nozzle (see section 7)
17Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
9 Accessories and detergents
Only use original accessories and detergents. For further information, see www.nilfi sk.com.
10 Warranty Conditions
Nilfi sk guarantees high pressure washers for domestic use for 2 years. If your high pressure washer or
ac ces so ries are handed in for repair, a copy of the receipt must be enclosed.
Guarantee repairs are being made on the following con dit ions:
• that defects are attributable to fl aws or defects in materials or workmanship. (wear and tear
as well as misuse are not covered by the gu a ran tee).
• that the directions of this instruction manual have been thoroughly observed.
• that repair has not been carried out or attempted by other than Nilfi sk-trained service staff.
• that only original accessories have been applied.
• that the product has not been exposed to abuse such as knocks, bumps or frost.
• that only water without any impurities has been used.
• that the high pressure washer has not been used for rental nor used com mer cial ly in any
other way.
Repairs under this guarantee include replacement of defective parts, exclusive of packing and postage/carriage. Besides, we refer to your national law of sale.
The machine should be forwarded to one of the service centres of the Nilfi sk organisation with description/
spe ci fi ca ti on of the fault.
Repairs not covered by the guarantee conditions will be invoiced. (I.e. malfunctions due to Causes men ti o ned in section Troubleshooting Chart of the instruction manual).
11 Main technical Data
Type
E 130.3 E 140.3 E 145.3
Electric specifications
Rated voltage V 220-240 220-240 220-240
Rated frequency Hz 50/60 50/60 50/60
Rated power consumption kW 2.0 2.1 2.1
Current A 9.0 9.5 10
Protection class
Class I/
Class II
Class II Class II Class II
Protection degree IP xx IPX5 IPX5 IPX5
Hydraulic specifications
Rated pressure MPa/bar 12.5/125 13.5/135 14.0/140
Max. pressure MPa/bar 13.0/130 14.0/140 14.5/145
Rated water flow l/min/l/h 7.5/450 7.0/420 6.6/400
Max. water flow l/min/l/h 8.3/500 8.3/500 8.3/500
Max. water inlet pressure Mpa/bar 1/10 1/100 1/10
Max. water inlet temperature °C 60 60 60
Max. water inlet temp. suction mode °C 20 20 20
Weight kg 17.8 18.6 19.8
Hand-arm vibration according to ISO 5349-1:
Standard nozzle
m/s
2
< 2.5 ±1 < 2.5 ±1 < 2.5 ±1
Machines without hose reel:
Sound pressure level L
pA
in accordance with ISO 3744
Guaranteed sound power level L
WA in accordance with
2000/14/EC
dB(A)
66.8 ±2
82
66.8 ±2
82
-
-
Machines with hose reel:
Sound pressure level L
pA
in accordance with ISO 3744
Guaranteed sound power level L
WA in accordance with
2000/14/EC
dB(A)
71.8 ±2
86
71.8 ±2
86
-
86
We reserve the right to make alterations.
18
Original Instructions
EN
NO
SV
FI
FR
NL
I
T
L
R
C
SHU
L
HR
SL
SK
V
R
U
Z
H
12 Declaration of Conformity
Declaration of Conformity
Product:
High Pressure Washer
Type:
Nilfi sk E 130.3 / E 140.3 / E 145.3
and accessory variants of above-mentioned types
Description:
220-240 V 1~, 50/60 Hz - IP X5
The design of the unit corre sponds to the following
pertinent regulations:
EC Machine Directive 2006/42/EC
EC Low-voltage Directive 2006/95/EC
EC EMC Directive 2004/108/EC
RoHS Directive 2011/65/EC
EC Noise Emission Directive 2000/14/EC
Applied harmonised standards:
EN 60335-2-79:2012
EN 62233:2008
EN 55014-1:2006 +A1:2009+A2:2011
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-11:2000
EN55014-2:1997+A1:2001+A2:2009
Applied international standards and technical specifi ca-
tions:
IEC 60335-1:2012
IEC 60335-2-79:2012
Name and address of the person autho rised to compile
the technical fi le:
Anton Sørensen
General Manager, Technical Operations EAPC
Nilfi sk-Advance A/S
Sognevej 25
DK-2605 Brøndby
Identity and signature of the person empowered to draw
up the declaration on behalf of the manufacturer:
Anton Sørensen
General Manager, Technical Operations EAPC
Nilfi sk-Advance A/S
Sognevej 25
DK-2605 Brøndby
Place and date of the declaration
Hadsund, 01.10.2013
A6
A1
A2
A3
A4
A5
B14
B10
B 9
B2
B1
B7
B3
B4
B5
Max. 60°C
Max. 60°C
B6
B8
B11
B12
B13
B15 B16 B17
a
c
b
d
C4
C7
C6
C3
C1
C1
I
O
a
b
c
d
f
b
D5
D4
D3
D2
C2
C5
D1
http://www.nilfi sk.com
HEAD QUARTER
DENMARK
Nilfi sk-Advance Group
Sognevej 25
DK-2605 Brøndby
Tel.: (+45) 4323 8100
E-mail: mail.com@nilfi sk-advance.com
SALES COMPANIES
AUSTRALIA
Nilfi sk-Advance Pty Ltd
Unit 1/13 Bessemer Street
Blacktown NSW 2148
Website: www.nilfi sk.com.au
AUSTRIA
Nilfi sk-Advance GmbH
Metzgerstrasse 68
5101 Bergheim bei Salzburg
Website: www.nilfi sk.at
BELGIUM
Nilfi sk-Advance n.v-s.a.
Riverside Business Park
Boulevard Internationalelaan 55
Bâtiment C3/C4 Gebouw
Bruxelles 1070
Website: www.nilfi sk.be
CHILE
Nilfi sk-Advance de Chile
San Alfonso 1462
Santiago
Website: www.nilfi sk.com
CHINA
Nilfi sk-Advance (Suzhou)
Building 18, Suchun Industrial Estate
Suzhou Industrial Park
215021 Suzhou
Website: www.nilfi sk-cs.com
CZECH REPUBLIC
Nilfi sk-Advance
VGP Park Horní Počernice
Do Čertous 1/2658
193 00 Praha 9
Website: www.nilfi sk.cz
DENMARK
Nilfi sk-Advance NORDIC A/S
Sognevej 25
2605 Brøndby
Tel.: (+45) 4323 4050
E-mail: kundeservice.dk@nilfi sk.com
FINLAND
Nilfi sk-Advance Oy Ab
Koskelontie 23 E
02920 Espoo
Website: www.nilfi sk.fi
FRANCE
Nilfi sk-Advance
26 Avenue de la Baltique
Villebon sur Yvette
91978 Courtabouef Cedex
Website: www.nilfi sk.fr
GERMANY
Nilfi sk-ALTO
eine Marke der Nilfi sk-Advance GmbH
Guido-Oberdorfer-Straße 2-10
89287 Bellenberg
Website: www.nilfi sk.de
GREECE
Nilfi sk-Advance A.E.
Αναπαύσεως 29
Κορωπί Τ.Κ. 194 00
Website: www.nilfi sk.gr
HOLLAND
Nilfi sk-Advance
Versterkerstraat 5
1322 AN Almere
Website: www.nilfi sk.nl
HUNGARY
Nilfi sk-Advance Kereskedelmi Kft.
II. Rákóczi Ferenc út 10
2310 Szigetszentmiklos-Lakihegy
Website: www.nilfi sk.hu
INDIA
Nilfi sk-Advance India Limited
Pramukh Plaza, ‘B’ Wing, 4th fl oor, Unit No. 403
Cardinal Gracious Road, Chakala
Andheri (East) Mumbai 400 099
Website: www.nilfi sk.com
IRELAND
Nilfi sk-Advance
1 Stokes Place
St. Stephen’s Green
Dublin 2
Website: www.nilfi sk.com
ITALY
Nilfi sk-Advance SpA
Strada Comunale della Braglia, 18
26862 Guardamiglio (LO)
Website: www.nilfi sk.it
JAPAN
Nilfi sk-Advance Inc.
1-6-6 Kita-shinyokohama, Kouhoku-ku
Yokohama, 223-0059
Website: www.nilfi sk.com
MALAYSIA
Nilfi sk-Advance Sdn Bhd
Sd 14, Jalan KIP 11
Taman Perindustrian KIP
Sri Damansara
52200 Kuala Lumpur
Website: www.nilfi sk.com
MEXICO
Nilfi sk-Advance de Mexico, S. de R.L. de C.V.
Agustín M. Chavez No. 1, PB ofi cina 004
Col. Centro de Ciudad Santa Fe
01210 Mexico, D.F.
Website: www.nilfi sk.com
NEW ZEALAND
Nilfi sk-Advance
Danish House
6 Rockridge Avenue
Penrose, Auckland 1135
Website: www.nilfi sk.com
NORWAY
Nilfi sk-Advance AS
Bjørnerudveien 24
1266 Oslo
Tel.: (+47) 22 75 17 70
Website: www.nilfi sk.no
POLAND
Nilfi sk-Advance Sp. Z.O.O.
ul. 3 Maja 8
05-800 Pruszków
Website: www.nilfi sk.pl
PORTUGAL
Nilfi sk-Advance
Sintra Business Park
Zona Industrial Da Abrunheira
Edifi cio 1, 1° A
P2710-089 Sintra
Website: www.nilfi sk.pt
RUSSIA
Нилфиск-Эдванс
127015 Москва
Вятская ул. 27, стр. 7
Россия
Website: www.nilfi sk.ru
SLOVAKIA
Nilfi sk-Advance s.r.o.
Bancíkovej 1/A
SK-821 03 Bratislava
Website: www.nilfi sk.sk
SOUTH AFRICA
WAP South Africa
12 Newton Street
Spartan 1630
Website: www.nilfi sk.com
SOUTH KOREA
Nilfi sk-Advance Korea Co., Ltd
3F Duksoo B/D, 90 Seongsui-ro
Seongdong-gu, Seoul, Korea
www.nilfi sk.co.kr
SPAIN
Nilfi sk-Advance S.A.
Torre d’Ara, Planta 9
08302 Mataró
Barcelona
Website: www.nilfi sk.es
SWEDEN
Nilfi sk-Advance AB
Taljegårdsgatan 4
431 53 Mölndal
Website: www.nilfi sk-alto.se
SWITZERLAND
Nilfi sk-Advance
Ringstrasse 19
Kircheberg/Industri Stelzl
9500 Wil
Website: www.nilfi sk-alto.ch
TAIWAN
Nilfi sk-Advance Taiwan Branch
1F, No. 193, sec. 2, Xing Long Rd.
Taipei
Tel.: (+88) 6227 002 268
Website: www.nilfi sk-alto.tw
THAILAND
Nilfi sk-Advance Co. Ltd.
89 Soi Chokechai-Ruammitr
Viphavadee-Rangsit Road
Ladyao, Jatuchak, Bangkok 10900
Website: www.nilfi sk.co.th
TURKEY
Nilfi sk-Advance A.S.
Serifali Mh. Bayraktar Bulv. Sehit Sk. No:7
Ümraniye
Istanbul
Website: www.nilfi sk.com.tr
UNITED KINGDOM
Nilfi sk Advance Ltd.
Nilfi sk House
Bowerbank Way
Gilwilly Industrial Estate, Penrith
Cumbria CA11 9BQ
Tel: 01768 868995
Website: www.nilfi sk.co.uk
UNITED ARAB EMIRATES
Nilfi sk-Advance Middle East Branch
SAIF-Zone
P.O. Box 122298
Sharjah
Website: www.nilfi sk.com
VIETNAM
Nilfi sk-Advance Representative Offi ce
No. 51 Doc Ngu Str.
Ba Dinh Dist.
Hanoi
Website: www.nilfi sk.com
Loading...
