INSTALLATION

If you are installing the MS110 into an existing wall,
take time to consider any possible obstructions
which may be hidden inside the wall, such as wood
or metal studs; electrical, telephone or other types
of wiring; plumbing; AC or heating conduits; old
wall safes; etc.

1. Determine a mounting location for the MS110.
Select a location where you will have access
to the rear of the MS110 after it is installed.
This will allow you to securely tighten the
MS110 to the mounting surface using the
supplied hardware.

2. Drill a 1/2” hole where the MS110 will be
mounted.

3. Run the MS110’s IR cable. Label the cable for
future reference. The MS110 is supplied with
10’ of pre-stripped IR cable. The IR cable may
be shortened or lengthened as needed. If you
want to make the MS110’s cable shorter, use a
pair of wire cutters to cut the cable to the

®

desired length. The IR cable may be lengthened
by splicing it to a recommended IR cable (See
Installation Considerations—Type of Cable). You
may splice the MS110 cable to another cable by
soldering or crimping the connections.

4. Connect the MS110 cable to the main system
unit. Strip 1/4” of insulation from the end of

each wire into the appropriate hole on the main
system units’ screwless connector (Figure 2),
and snap the locking tab down. To help you, the
connector plug is keyed. Insert the smooth side
of the connector plug into the smooth side of
the socket. Don’t force the scalloped side of the
connector plug into the smooth side of the socket.

6. Secure the MS110 by tightening the hex nut.
DO NOT OVER-TIGHTEN.

Tools Required

• 1/8” Standard Slotted Screwdriver

• Adjustable wrench or pliers

• Wire Stripper

NOTE: Do not install the MS110 next to a light
dimmer

OPERATION

Operation of the MS110 is straightforward. Simply
aim your hand-held remote at the MS110. Your
IR command is instantly repeated to your A/V
equipment.

TROUBLESHOOTING

This manual contains instructions for the
MS110 only. For specific information on the
adjustment and operation of your Niles infrared
extender system, please refer to the instruction
manual included with your Niles IR main system
unit (MSU140, MSU250, MSU480 MSU440Z,
IntelliControl).

1. Test the remote control(s) by operating the
A/V equipment directly. Replace the batteries
if needed.

2. Double check the cable connections on the
MS110 and on the main system unit. Look for
open, shorted or reversed wires.

3. Test for interference from the following
sources:

• Neon or halogen lights in the room

• Light dimmers, beginning with those closest
to the MS110

Obser ve the main system unit IR confirmation
LED while performing all the tests. It is possible
to have interference from more than one source.

Eliminating Optical Feedback

In some installations, two conditions combine to
create an optical feedback loop. Symptoms can
include: poor range, intermittent operation or no
operation.

each wire. Tightly twist the end of each wire
until there are no frayed ends. Insert the end of

9

10

11 1312

The conditions which sometimes combine to
create a feedback loop are:

1. Both a sensor and a flasher are located within
the same room.

2. There is some low-level noise or interference
on your system.

You can eliminate optical feedback by replacing
any IRB1 “flooding flasher” with MF1 or MF2
MicroFlashers® and covering all flashers with
the supplied IR blocking covers.

EMI (Electromagnetic Interference)

Identify the source of the interference. The most
common sources of electromagnetic interference
are listed in the Installation Considerations
section. To eliminate EMI try the following
methods:

1. Move the sensor or the sensor cable away
from the EMI source or move the source of
the EMI away from the sensor or the cable.

2. Connect the Sensor’s GND terminal to true
earth ground (if this isn’t feasible use the
main system unit’s GND terminal).

There are many methods for reducing
interference. Which solution is best for you
depends on your situation. If you require further
assistance call Niles Technical Support at
305-238-4373 or 1-800-289-4434 (M-F 8:00
AM - 7:00PM ET).

You can also email Niles Technical Support at
[e-mail].

SPECIFICATIONS

IR System

Compatible with virtually all brands of remotes
using carrier frequencies of 38kHz, 40kHz, and
56kHz

IR Receiving Range

Varies depending on remote strength;

typically 20’ to 35’

IR Receiving Angle

60° off-axis (horizontal and vertical) at 20’

Mounting

Thru-hole, fits into a 1/2” diameter hole;
requires a minimum of 2-5/8” mounting depth

Wiring Requirements

Individual home-run of CAT 5 cable

Unit Dimensions

Front Bezel: 3/4” diameter x 1/4” high

Overall Unit: 1/2” diameter x 2-7/8” long

Contents

MS110 Sensor x 1

Washer x 1

Hex Nut x 1

LIMITED WARRANTY

NILES AUDIO CORPORATION (“NILES”) WARRANTS ITS PASSIVE PRODUCTS
(THOSE NOT REQUIRING AC OR BATTERY POWER) TO THE ORIGINAL
PURCHASER TO BE FREE OF MANUFACTURING DEFECTS IN MATERIAL AND
WORKMANSHIP FOR A PERIOD OF TWO YEARS FROM DATE OF PURCHASE.

THIS WARRANTY IS SUBJECT TO THE FOLLOWING ADDITIONAL CONDITIONS
AND LIMITATIONS. THE WARRANTY IS VOID AND INAPPLICABLE IF
NILES DEEMS THAT THE PRODUCT HAS BEEN USED OR HANDLED OTHER
THAN IN ACCORDANCE WITH THE INSTRUCTIONS PROVIDED BY THE
MANUFACTURER, INCLUDING BUT NOT LIMITED TO DAMAGE CAUSED BY
ACCIDENT, MISHANDLING, IMPROPER INSTALLATION, ABUSE, NEGLIGENCE,
OR NORMAL WEAR AND TEAR, OR ANY DEFECT CAUSED BY REPAIR
TO THE PRODUCT BY ANYONE OTHER THAN NILES OR AN AUTHORIZED
NILES DEALER.

TO OBTAIN WARRANTY SERVICE, TAKE THE UNIT TO THE NEAREST
AUTHORIZED NILES DEALER, WHO WILL TEST THE PRODUCT AND IF
NECESSARY, FORWARD IT TO NILES FOR SERVICE. IF THERE ARE NO
AUTHORIZED NILES DEALERS IN YOUR AREA, YOU MUST WRITE TO NILES
AND INCLUDE YOUR NAME, MODEL AND SERIAL NUMBER OF YOUR UNIT,
ALONG WITH A BRIEF DESCRIPTION OF THE PROBLEM. A FACTORY RETURN
AUTHORIZATION NUMBER WILL BE SENT TO YOU. DO NOT RETURN ANY
UNIT WITHOUT FIRST RECEIVING WRITTEN AUTHORIZATION AND SHIPPING
INSTRUCTIONS FROM NILES.

IF THE ABOVE CONDITIONS ARE MET, THE PURCHASER’S SOLE REMEDY SHALL
BE TO RETURN THE PRODUCT TO NILES, IN WHICH CASE NILES WILL REPAIR
OR REPLACE, AT ITS SOLE OPTION, THE DEFECTIVE PRODUCT WITHOUT
CHARGE FOR PARTS OR LABOR. NILES WILL RETURN A UNIT REPAIRED OR
REPLACED UNDER WARRANTY BY SHIPPING SAME BY ITS USUAL SHIPPING
METHOD FROM THE FACTORY (ONLY) AT ITS EXPENSE WITHIN THE UNITED
STATES OF AMERICA. THERE ARE NO OTHER WARRANTIES, INCLUDING
WITHOUT LIMITATION, EITHER EXPRESS OR IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, WITH
RESPECT TO THE PRODUCT.

REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE
EXCLUSIVE REMEDY OF THE CONSUMER/PURCHASER. NILES SHALL NOT BE
RESPONSIBLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES EXCEPT
TO THE EXTENT PROVIDED (OR PROHIBITED) BY APPLICABLE LAW.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION MAY
NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE.

FOR THE NAME OF YOUR NEAREST AUTHORIZED NILES DEALER
CONTACT: NILES AUDIO CORPORATION, P.O. BOX 160818, MIAMI,
FLORIDA 33116-0818.

Please fill in your product information and retain for your records.

Model__________________Purchase Date ________________
Serial No. __________________________________________

I N S T A L L A T I O N & O P E R A T I O N G U I D E

FLUSH-MOUNT IR MICROSENSOR

®

MS110

INTRODUCTION

The MS110 is a flush-mount IR sensor designed for
use with the Niles infrared extender systems.

Installed in a remote room location, the MS110
receives the IR commands transmitted from your
existing hand-held remotes in that room. The
commands are carried via a CAT 5 cable to your
A/V equipment in another room, and instantly
“repeated”.

The MS110 is compatible with all current Niles
infrared systems. It may be used along with, or as
an alternative to, the Niles TS110, WS110R, MS210
and CS110 sensors or the IntelliPad®.

The MS110 is just one part of the three building
blocks necessary to complete a Niles IR repeating
system:

• IR Main System Unit—Models MSU140,
MSU250, MSU480 and MSU440Z.

• IR Sensors/Keypads—Models WS110R, TS110,
MS110, MS210, CS110, and the IntelliPad.

• IR Flashers—Models MF1, MF1VF, MF2, MF2VF
and the IRB1.

An IR sensor expansion hub, Model IRH610, is
available to provide additional sensor inputs to your
system.

IMPORTANT: Refer installation to a professional
custom installer if you are unfamiliar with any of
the following procedures.

FEATURES & BENEFITS

The MS110 offers a number of improvements over
other miniature IR sensors.

• Plasma and LCD-proof performance—allows
placement of the MS110 near plasma or LCD
displays

• CFL interference resistant—expands installation
flexibility to areas with fluorescent lighting

• Works under most lighting conditions, including
indirect sunlight—eliminates environmental
restrictions

• Universal system—compatible with virtually all
brands of A/V equipment and remote controls

• Excellent IR receiving range — 20’ to 35’ of
remote control range (depending upon the
strength of your handheld remote)

• 100% factory tested for pickup range and angle.

• Small size of only 1/2” diameter by 2-7/8”
long—fits almost anywhere

• 10’ connecting cable included

• Printed circuit board design uses surface mount
technology, assuring high reliability

• Ideal for both home and commercial installations

• Two year parts and labor warranty

INSTALLATION CONSIDERATIONS

Type of Cable

The MS110 connects to the Niles infrared main
systems unit or IRH610 sensor expansion hub
with an individual home run of CAT 5 cable.
When running wires inside walls, most states and
municipalities in the U.S. specify that you must use
a special type of wire. Usually, the requirement is
that the wire has a specific “CL” fire rating, such
as “CL-2” or “CL-3”. Consult your Niles dealer,
building contractor, or local building and inspection
department if unsure about which type of wire is
best for your application.

MS110 Mounting Location

The MS110 is ideal for use in applications when
tabletop, ceiling, or wall-mounting is undesirable.
Its small size and unobtrusive appearance makes
it ideal for installation in obscure, hidden locations,
in cabinet facings, or in the sensor knockout built
into Niles in-wall loudspeakers. Installing the
MS110 close to the primary location of the user
will ensure best performance.

The MS110 is designed to flush-mount almost
anywhere. Convenient mounting locations for the
MS110 are:

• In a cabinet door

• In a wall, or wall-plate

• Behind a speaker grille.*

NOTE: Some types of speaker grilles will reduce the
IR pickup range of the MS110. If unsure, test
the pickup range before permanently installing the
MS110 behind the speaker grille.

Receiving Range and Pickup Angle

The receiving range of the MS110 will vary
according to the IR output strength of the remote
control being used. Remote strength varies among
brands depending on the number and size of
batteries used, and how many IR emitters the
remote has. For example, remotes that operate
on two small AAA batteries and have only one IR
emitter are generally not as strong as remotes
that use the larger AA size batteries and have two
emitters. Tests with various manufacturers’ remote
controls have shown that the operating range
can vary from a minimum of 20’ to a maximum
of about 75’.

Infrared signals travel essentially line-of-sight.
They will not pass through or around solid objects.
Do not rely on an IR signal being able to “bounce”
off a wall or object to the MS110.

The IR pickup angle of the MS110 is 60° off-axis
(horizontal and vertical) at 20’.

Avoiding Electrical Interference

Avoid locating the MS110 near any potential
sources of electrical or optical noise, such as light
dimmers, low-voltage lights, and neon lights.

Do not install the MS110 into electrical boxes
with 110 volt devices

Some states or municipalities allow devices
such as the MS110 to be installed into the same
electrical box as 110 volt devices, provided a “low­voltage partition” is used between the devices.

We do not recommend this. The cable connected
to the MS110 can act as an “antenna” for
electrical noise. Locating the MS110 cable too
close to a light dimmer or switch may interfere
with the MS110. If you must locate the MS110
near electrical devices, install it in a separate
metal electrical box, ground the box to the
electrical system ground, and route the MS110
cable several feet away from all electrical wiring.

Avoiding Optical Feedback

If installing the MS110 in the same room as an IR
flasher, it is possible for the flasher’s IR output to
be picked-up by the MS110. This effect, known
as an optical feedback loop, can cause erratic
operation. Optical feedback is similar to acoustical
feedback: the howling or whistling sound heard in
a P.A. system when the microphone is too close to
the speaker.

To avoid optical feedback:

1. Re-position the flasher(s) and/or the sensor.

2. Use Niles MF1 or MF2 flashers and cover them
with the supplied IR blockers.

Using the MS110 with the Intellipad Ci System

The MS110 is fully compatible with the Niles
Intellipad Ci line, follow the wiring instructions
in Figure 2. For specific information see your
Intellipad Ci manual.

5 63 41 2

Figure 1.

a Hex Nut (supplied)
b Washer (supplied)
c Mounting Surface
d IR Cable (10 feet supplied)
e MS110 Miniature IR Sensor (supplied)
f MS110 Lens Bezel (supplied)

Figure 2. Wiring legend

Niles IR Flasher

12V DC Power
Supply (Supplied
with the MSU250

Main System

Unit) Plugged into

an Unswitched AC
Outlet Powers the

System

Power, IR data, status signal and ground

MSU250

via CAT 5 wire

Figure 3. Wiring Diagram (Typical installation with an MSU250 Main System Unit)

Figure 4. This color code is based on the industry standard T568A coding for the RJ45 connector. When connecting

the MS110 to the Niles Ci System observe this pin configuration

7

Stereo Receiver

12V DC Power supply

(Not Supplied) plugged

into a switched outlet

(Niles stock# FG01035)

8

MS110 IR Sensor
