SPECIFICATIONS SHEET
SERIES 2
SYSTEMS INTEGRATION AMPLIFIER
SI
Offering the classic Niles stability that you’ve come to know and trust, the powerful SI-1230 will exceed your installation
needs. Specically designed to solve the problems of interfacing with different brands and models of equipment, and
different rooms and applications, the SI-1230 makes installation easier and more straight forward than ever before. Fully
congurable, with 12-channels that provide 30W per channel (80W when bridged) and our unique BusMatrix™ Selector, the
SI-1230 is the perfect multi-zone or multi-room solution.
Features & beneFits
-
12- CHANNEL FULLY CONFIGURABLE POWER AMPLIFIER
®
■ Real World Power The SI-1230 is a 12-channel
amplier that delivers a solid 30 watts per channel
RMS into 8 ohms and 40 watts per channel RMS into 4
ohms. A massive toroidal transformer design provides
the energy necessary to efciently deliver solid, deep,
controlled bass response to a house full of speakers.
■ Turn-On Modes The SI-1230 features three turn-on
modes: 1. Manual turn-on via the front panel switch,
2. Audio Sense and 3. External Voltage trigger. Audio
Sense and External Voltage trigger modes enable you
to congure the SI-1230 to interface with any kind of
system and turn on sutomstically.
■ Twelve to Six Channel Configurable Power Each
of the SI-1230’s six adjacent speaker output pairs are
bridgeable. You can create up to six 80 watt channels
by sliding the bridging switches located between each
pair to the “bridged” position. This enables you to
allocate more power to specic locations, such as large
rooms or outdoor applications.
B l e n d i n g H i g H F i d e l i t y A n d A r c H i t e c t u r e
■ BusMatrix™ Selector Our unique BusMatrix™
selector gives you the exibility to assign each channel
to a common Left, Right, or Mono signal bus, or to
a dedicated signal input. With BusMatrix™, routing
surround sound to the master bedroom, stereo to
the den and mono to the powder room is as simple
as icking a switch. BusMatrix™ makes the SI-1230
an ideal multi-room or multi-zone amplier and offers
exciting new features and system design possibilities to
the professional installer.
■ Freedom from Noise and Cross-Talk The SI-1230’s
BusMatrix™ incorporates advanced PCB construction
ensuring extremely high channel to channel isolation.
Signal to noise ratios and cross-talk are equivalent to a
professional mixing board found in a recording studio.
With the SI-1230, the music playing in the living room
cannot interfere with the music in the den.
®
CALL 1-800-BUY-HIFI – 760.710.0992 – www.nilesaudio.com
SyStemS IntegratIon amplIfIer
®
SI-1230 Series 2
12-CHANNEL FULLY CONFIGURABLE
POWER AMPLIFIER
STOCK# FG01704
Featu r e s
■ Fully congurable 12-Channel amplier
■ 30 watts RMS per channel into 8 Ohms (all channels driven)
■ 40 watts RMS per channel into 4 Ohms (all channels driven)
■ Adjacent channels are bridgable to 80 watts RMS into 8 Ohms (all channels driven)
■ Switchable 110V-230V power supply
■ Unique BusMatrix™ selector allows each channel to select from 4 options: left bus,
right bus, left plus right bus (summed stereo), or the channel’s dedicated input
■ Three turn-on modes: music sense, voltage trigger, and manual
■ Audio circuitry constructed with the nest parts available, including 1% metal lm
resistors, high quality capacitors and oversized heat sinks for clear and uncolored
sound
■ Independent level controls for all 12 channels
■ Status display for troubleshooting
speciFications
■ Voltage trigger input accepts 3-24VAC/DC
■ 12-volt control out
■ Removable line cord
■ Two year limited warranty
■ Rack mount ears included
■ Tested and certied to US, Canada, EU , and Australian safety and EMC standards
■ Overall dimensions:
17.25” (43.81cm) wide – 5.75” (14.47cm) high (including feet)
16.25” (41.11cm) deep
■ Weight: 35 lb. (15.8 kg)
applICatIon
HOME THEATER RECEIVER
MUsIC OUtdOORs IN MULtIPLE AREAs WItH A 12-CHANNEL AMPLIFIER
SI-1230 Series 2
S I - 12 3 0 S E RIE S 2
Sy s t e m s I n t e gr a t i o n A m p lif i e r
MAIN
BUS
INPUT
L
R
TURN ON MODE
AUDIO SENSE
CONSTANT
12V CONTROL OUT
®
1
BRIDGED
LEVEL
USE CH 2
CASCADE
WHEN
BUS
BRIDGED
OUTPUT
L
L
R
BUS
L+R
1
R
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
3-24V
AC/DC
TRIGGER
+
INPUT
-
1 2
CLASS 2 WIRING
OS Loudspeakers
OUTDOOR KITCHEN
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
2
LEVEL
L
R
BUS
BUS
BUS
L+R
2
3
BRIDGED
3
BRIDGED
LEVEL
USE CH 4
LEVEL
USE CH 4
WHEN
WHEN
BRIDGED
BRIDGED
L
L
R
R
BUS
BUS
L+R
L+R
3
3
4Ω MINIMUM
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
BRIDGED - BRIDGED +
+
+
-
-
3 4
3 4
CLASS 2 WIRING
4
4
LEVEL
LEVEL
L
L
R
R
L+R
L+R
4
4
Niles Audio, Petaluma, California, USA
Designed and Engineered in the U.S.A. Made in China.
5
BRIDGED
6
LEVEL
LEVEL
USE CH 6
WHEN
BRIDGED
L
R
BUS
BUS
L+R
5
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
+
-
5 6
CLASS 2 WIRING
OS Loudspeakers
DECK
L
R
L+R
6
7
LEVEL
L
R
BUS
L+R
7
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
7 8
CLASS 2 WIRING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) This device must accept any interference
received, including interference that may cause undesired operation.
BRIDGED
8
LEVEL
USE CH 8
WHEN
BRIDGED
L
R
BUS
BUS
L+R
8
+
-
9
BRIDGED
LEVEL
USE CH 10
WHEN
BRIDGED
L
R
L+R
9
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
+
-
9 10
CLASS 2 WIRING
OS Loudspeakers
PATIO #1
Second
Zone
Out
OS Loudspeakers
PATIO #2
30 WATTS PER SPEAKER - 8 Ω
10
11
BRIDGED
LEVEL
USE CH 12
BRIDGED
L
R
BUS
L+R
11
4Ω MINIMUM
(8 Ω MINIMUM IN BRIDGED MODE)
BRIDGED - BRIDGED +
11 12
CLASS 2 WIRING
12
LEVEL
WHEN
220-240V ~
L
R
BUS
L+R
12
100-120V ~
CAUTION: REPLACE WITH SAME TYPE AND
RATING FUSE
100-120V : T10AL/250V
+
FUSE:
220-240V : T5AL/250V
-
100-120 / 220-240 V~
50 / 60 Hz, 500W
LEVEL
L
R
BUS
L+R
10
Rock Loudspeakers
POOL
80 WATTS PER SPEAKER - 8 Ω
Serial No.
1-800-BUY-HIFI – www.nilesaudio.com
©2013 Core Brands, LLC. All Rights Reserved. Niles, the Niles logo and Blending High Fidelity and Architecture are registered trademarks of Core Brands, LLC. All other trademarks are the
property of their respective owners. We reserve the right to change features, descriptions, and/or specifications at any time without notice. CS0333A
