NightWatcher NW-C720B-BK, NW-C1080B-BK, NW-C1080D-WH, NW-C1080B-WH, NW-C1080D-BK User Manual
...Page 1
USER GUIDE
CCTV CAMERA
NW-C720B-BK
NW-C1080B-BK
NW-C1080B-WH
GB
ww.nightwatcher.co.uk
w
NW-C720D-BK
NW-C1080D-BK
NW-C1080D-WH
0345 900 6764
Page 2
Page 3
Warning: To prevent fire or electric shock, please do not
expose internal camera parts to moisture or rain
Caution: To prevent electric
shock and fire hazard, only
Warning: To reduce the risk of electric
shock, front or rear cover should only
be removed by a qualified professional
Do not install the camera in conditions which exceed the
recommended temperature range.
Recommended temperature range : -20 ℃ to +70 ℃.
Do not install camera in a location subject to pressure,
high temperature or corrosion.
This may caused damage or cause the camera to work improperly.
Do not install the camera in a location where lighting is unstable.
use the power supply
recommended in the manual.
1
Page 4
Unstable lighting may cause the camera to work improperly
Do not install the camera in a location subject to dust or fumes
This may cause the camera to fail
Do not attempt to disassemble the camera
This should only be carried out by a qualified professional
Do not drop or shake the camera
This may cause the camera to fail
Do not expose the camera to excessive water or other liquid
This may cause corrosion and the camera to fail. If this happens,
carefully wipe the camera with a soft cloth to remove any moisture.
Do not touch the camera lens or sensors
Fingerprints or smears will affe t the clarity of the camera image.
Before installation carefully clean the lens and sensors with a dry, soft cloth
High performance chipset, high resolution, clear and sharp images
Supports auto white balance, high colour reduction and realistic image
Supports auto electronic shutter, adapting to varying operating environments
High S/N ratio for sharp and clear picture
Supports privacy zone masking, BLC and digital wide dynamic function
Supports auto AGC, adaptive brightness
Advanced double glass structure, no light leakage
Long service life
Easy installation and customisation
2
Page 5
SPECIFICATIONS
NW-C720B-BK
NW-C1080B-BK/WH NW-C1080D-BK/WH
NW-C720D-BK
3
Page 6
Safety Warnings and Cautions
Please pay attention to the following warnings and cautions:
Hazardous Voltage may be present: Special measures and precautions
must be taken when using this device. Some voltages on the device may
present a hazard to the user. This device should only be installed by a
qualified person with knowledge and training in working with these types
of devices that contain live circuits.
Power Supply Hazardous Voltage: AC mains voltages are present within the power supply
assembly. This device must be connected to a CE approved, completely enclosed power supply,
of the proper rated voltage and current.
System Grounding (Earthing): To avoid shock, ensure that all AC wiring is not exposed and
that the earth grounding is maintained. Ensure that any equipment to which this device
will be attached is also connected to properly wired mains supply.
Power Connect and Disconnect: The AC power supply cord is the main
disconnect device to mains (AC power).The socket outlet should be installed
Maintenance: Do not connect/disconnect any cables to or perform installation/maintenance
on this device during an electrical storm.
near the equipment and should be readily accessible.
No user serviceable parts inside the power supply.
4
