Nighthawk X10—AD7000, R8900 Data Sheet

Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Ultimate 4K Streaming & VR Gaming
Nighthawk® X10 AD7000 Smart
WiFi Router is the industry’s fastest
router for media streaming with
Plex media server. Nighthawk
with 802.11ac and 802.11ad WiFi
technology delivers ultra-smooth
®
X10
4K streaming, VR gaming and
instant downloads. With a powerful
1.7GHz quad-core processor and
Quad Stream architecture, you can
enjoy combined wireless speeds
of up to 7.0Gbps*. MU-MIMO
supports simultaneous streaming,
while 160MHz doubles WiFi speeds
to mobile devices. Four patent
pending external active antennas
amplify WiFi signals to maximize
range and throughput.
PAGE 1 of 10
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
802.11AC QUAD STREAM WIFI PLUS
802.11AD WIFI
Up to 4600+1733+600Mbps wireless speed
60GHZ 802.11AD WIFI
Fastest WiFi technology for instant downloads and backup
HIGH-PERFORMANCE ACTIVE ANTENNAS
Better WiFi coverage and faster speeds
POWERFUL 1.7GHZ QUAD-CORE PROCESSOR
Fastest processor for home router for better 4K streaming,
VR gaming, surng, or anything you throw at it
PLEX® MEDIA SERVER
All your movie, TV show, music, video, and photo
collections at your ngertips. Anywhere you go, on
the devices you love
PAGE 2 of 10
Speed
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Get the fastest combined WiFi currently available & enjoy a blazing-fast, lag-free WiFi experience for VR
gaming, video streaming or surng.
WiFi Range
60GHZ 802.11AD—Fastest WiFi interface for instant downloads and backup
AD7000 WIFI—Up to 4600+1733+800Mbps† Wireless speed
QUAD STREAM—Up to four data streams per WiFi band maximizes connection speed
MU-MIMO—Go faster by simultaneously streaming to multiple devices
GIGABIT WIRED—Six Gigabit Ethernet LAN ports with the ability to
aggregate two ports for faster le transfers
LINK AGGREGATION—Ability to aggregate two Gigabit LAN ports
for faster le transfers
10G LAN SFP+ PORT—For fast NAS access
Got range? Homes come in all shapes and sizes
®
and Nighthawk
X10 Smart WiFi Router’s 4 external active antennas provide WiFi coverage no matter where you connect in your home.
Sharing
With NETGEAR, sharing across your network is fun and easy, such as accessing stored data, media, photos & music.
ULTIMATE RANGE—WiFi coverage throughout very large homes
FOUR ENHANCED ACTIVE ANTENNAS—Enhances weak signal and reduces interference using a patent pending design
DLNA
READYSHARE
®
—Find & play your media on DLNA TVs & game consoles
®
USB ACCESS—Wirelessly access & share USB hard
drive via two (2) USB ports
TWO SUPERSPEED USB 3.0 PORTS—Up to 10x faster than USB 2.0
PLEX MEDIA SERVER—All your movie, TV show, music, and photo collections, on the devices you love
AMAZON DRIVE BACKUP—Automatically and securely back up your important data to Amazon Drive
PAGE 3 of 10
Reliable Connections
There’s nothing more frustrating than lost connections! With NETGEAR’s advanced features & best-in-class technology, you’ll reduce interference & enjoy more reliable WiFi connectivity.
Ease Of Use
Start enjoying your new device faster than ever. NETGEAR wants to make sure installation and management is simple & easy, so you can connect quickly & make sure you stay that way!
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
BEAMFORMING+—Boosts speed, reliability, & range of WiFi connections for 2.4 & 5GHz bands
NIGHTHAWK APP—Easily set up your router and get more out of your WiFi. Includes access from anywhere to manage your network away from home
EASY INSTALL—Easy setup for iPad®, tablets, smartphones & computers
Security
Ensure your privacy & keep your family safe while online. NETGEAR has you covered.
PUSH ‘N’ CONNECT —Easy push button WiFi connections (WPS)
WIFI & POWER ON/OFF —Convenient power savings
LED ON/OFF—Easily turn LEDs on or off
VPN SUPPORT —OpenVPN Connect app on iOS and Android®
allows remote secure access to the home network
VPN
SECURE WIFI CONNECTIONS—Standards-based WiFi Security (802.11i, 128-bit AES encryption with PSK)
GUEST NETWORK—Separate and secure network for your guests
PERSONAL FTP SERVER—Customized free URL to create FTP server
FTP
PAGE 4 of 10
The Fastest WiFi Just Got Faster
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Speeds of up to 4.6Gbps—that’s 3 times faster than 802.11ac. It’s the fastest Nighthawk
Fastest Wireless for Media Transfers and Backup
®
yet.
Don’t wait to watch! Ultra-smooth 4K streaming, VR gaming, instant downloads and backup.
PAGE 5 of 10
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Industry’s First Home Router with Plex Media Server
Plex. All your movie, TV show, music, video, and photo collections at your ngertips. Anywhere, anytime. Serve all your media with Plex
®
Media Server on your Nighthawk
X10, without need for a computer.
Powerful Quad-core 1.7GHz Processor
Wired or wireless, the 1.7GHz quad-core processor boosts your network performance up to 7.2Gbps†.
PAGE 6 of 10
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Multi-user MIMO (MU-MIMO)
Traditional WiFi routers can stream data to only one device in the home at a time. When multiple devices are connected to the router, each device needs to take its turn, and then wait before receiving more data. This can lead to slower network and Internet speeds. Using multi-user MIMO technology, NETGEAR routers can stream data to multiple devices simultaneously. With MU-MIMO, your WiFi network can deliver faster throughput to every MU-MIMO connected device. That means faster downloads and smoother streaming for your devices.
Enjoy simultaneous streaming with MU-MIMO
Data sent to one device at a time Data sent to multiple devices simultaneously
Traditional WiFi MU-MIMO WiFi
Nighthawk® App
The NETGEAR Nighthawk® App makes it easy to set up your router and get more out of your WiFi, WIth the app, you can install your router in a few steps—just connect your mobile device to the router network and the app will walk you through the rest. Once set up, you can use the intuitive dashboard to pause the Internet on your connected devices, run a quick Internet speed test, and much more.
• Anywhere Access—Easily monitor your home network anytime, anywhere
• Internet Speed Test—Check the broadband speeds from your service provider
• Pause Internet—Pause the Internet to any device
• Trafc Meter—Track Internet data usage
• Guest Networks—Setup separate WiFi access for guests
• Quick Setup—Get connected in just minutes
• Get it at nighthawk-app.com
PAGE 7 of 10
Data Sheet | R8900
and effectively improve signal strength.
Nighthawk® X10—AD7000 Smart WiFi Router
Enhanced Active Antennas
Each new generation of routers grows more powerful than the last, delivering stronger WiFi signals with greater range. At the same time, the WiFi signals on mobile devices are not getting more powerful. This difference in WiFi performance – a strong WiFi signal from the router and weaker ones from mobile devices – reduces overall WiFi range and speed.
To meet this challenge, NETGEAR developed the industry’s rst Active Antennas technology. NETGEAR moved the WiFi ampliers from their usual
location, on the router’s motherboard, up to the top of the antennas.
Active Antennas help improve WiFi performance by amplifying signals in the antenna itself. Thereby avoiding any signal loss during transmission between antenna and router board, as well as avoiding any noise insertion from the router board components. This provides cleaner and stronger receive signals
for amplication from your mobile devices.
In X10, enhanced Active Antennas also amplify the signals as they are sent to the devices, thereby increasing overall range and throughput.
Weak signal strength
Traditional WiFi router has harder time receiving weaker mobile device signals.
Effective signal strength
Nighthawk X8 Active antennas compensate for weaker mobile device signals
PAGE 8 of 10
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Beamforming+—For More Reliable Connections
Unlike typical WiFi routers that just blast the WiFi signals in all directions, with Beamforming+ the router & device communicate with each other, so the router can directly beam the WiFi signal to the device. The result is a stronger, faster, more reliable connection that is locked in even when the device is moved around the home.
• WiFi Signal Focus—Focuses signals from the wireless router to WiFi devices like smartphones, tablets & laptops
• Automatic Signal Management—Checks with your device to keep WiFi signal at its optimal strength
• Device Connections—Designed for home environments to support multiple WiFi device connections for highest quality
• WiFi Coverage—Reduces dead spots, & boosts signal strength
• Implicit & Explicit Beamforming boosts speed, reliability & range for both 2.4 & 5GHz WiFi—an industry rst
Connection Diagram
Plex® Media Server—All your movie, TV show, music, and photo collections. Anywhere you go, on the devices you love. Enjoy premium features with Plex Pass, free for 3 months
ad
60GHz 802.11ad WiFi—Fastest WiFi interface for instant downloads and backup
LED on/o
Four Enhanced Active Antennas—Enhances weak signal and reduces interference using a patent pending design
Link Aggregation—
Ability to aggregate
two Gigabit LAN ports
for faster file transfers
6
Six Gigabit Ethernet LAN ports to connect more wired devices
High-speed Internet
Power on/o
10G LAN SFP+ port for fast network attached storage access
Two USB 3.0 ports for faster file transfer
Amazon® Drive Cloud Back Up—Automatically backup your precious data on cloud. Enjoy 6 months free unlimited storage
PAGE 9 of 10
Data Sheet | R8900
Nighthawk® X10—AD7000 Smart WiFi Router
Package Contents
• Nighthawk® X10—AD7000 Smart WiFi Router (R8900)
• Ethernet cable
• Quick start guide
• Power adapter
Physical Specifications
• Dimensions: 8.81 x 6.61 x 2.91 in
(224 x 168 x 74 mm)
• Weight: 4.11 lb (1.87 kg)
Technical Specifications
• AD7000† WiFi
- Band 1: 600Mbps @2.4GHz - 64-QAM
- Band 2: 1733Mbps @5GHz – 256-QAM
- Band 3: 4600Mbps @60GHz** – SC
• Powerful quad-core 1.7GHz processor
• Memory: 512MB NAND flash and 1GB
DDR3 SDRAM
• Enhanced Ac tive Antennas with high- power amplifiers
• Explicit Beamforming for 2.4 & 5GHz bands
• Seven (7) 10/100/1000Mbps Gigabit
Ethernet ports
- 1 WAN & 6 LAN
- Dual Gigabit Ethernet port aggregation
• 10G LAN SFP+ por t connection for network attached storage (NAS)
• Two (2) USB 3.0 ports
• IPv6 support (Internet Protocol Version 6)
• On/off LED light switch
Key Features
• Plex Media Server—Stream your media on all your devices
• Quad Stream Wave2 WiFi
• MU-MIMO—Simultaneous streaming of data for up to three devices
• Amazon Drive Cloud Backup— Automatically and securely back up your important data to Amazon Drive
• Media streaming & storage
®
• DLNA
server to find & play your media on
TVs & game consoles
• VPN suppor t—Secure remote access to your home network & Internet using PC,
®
computers, and mobile devices
MAC
• Nighthawk App—Easily set up your router and get more out of your WiFi. Includes access from anywhere to manage your network away from homee
• Open Source—Software available at
https://www.myopenrouter.com *
System Requirements
• Microsoft® Windows 7, 8, 10, Vista®, XP®, 2000, Mac OS
• Microsoft® Internet Explorer® 5.0, Firefox®
2.0, Safari browsers or higher
®
, UNIX®, or Linux
®
1.4, Google Chrome™ 11. 0
®
Security
• Customized free URL to set up personal FTP server
• VPN support—secure remote access
• Guest net work access—separate & secure
• Standards-based WiFi Security (802.11i,
128-bit AES encryption with PSK) )
• Double firewall protection (SPI and NAT)
• Denial-of-service (DoS) attack prevention
Warranty
• www.netgear.com/warranty
• Extend your warranty & technical suppor t within 90 days of product purchase [US only]. Visit: prosupport.netgear.com/home
Support
• 90-day complimentary technical support following purchase from a NETGEAR authorized reseller
• Join the NETGEAR Community Forum. Visit http://community.netgear.com
1
Supports
®
Windows
10
* The NETGEAR hardware warranty does not include, and maybe be voided by, the use of open source rmware.
This product comes with a limited warranty that is valid only if purchased from a NETGE AR authorized reseller.
1
90-day complimentary technical support following purchase from a NETGEAR authorized reseller.
**To benet from 11ad features, WiFi client needs to suppor t 60GHz 802.11ad WiFi standard.
Ma ximum wireless signal rate derived from IEEE 802.11 specications. Actual data throughput and wireless coverage will var y and may be lowered by net work and environmental
conditions, including network trafc volume and building cons truction. NETGE AR makes no representations or warranties about this produc t's compatibility with future
standards. Up to 7000Mbps wireless speeds achieved when connecting to other 802.11ad 7000Mbps devices.
MU-MIMO capability requires both router and client device to support MU-MIMO.
NETGEA R, the NETGE AR Logo, Ready SHARE and Ni ghthawk are tr ademarks of N ETGEAR, I nc. Mac, Mac OS , t he Mac logo, and iP hone are trademarks o f Apple Inc. A pp Store
is a ser vice mark of A pple Inc., re gistered in t he U.S. and oth er countri es. Google Pl ay and the Googl e Play logo are tr ademarks o f Google LLC. A ny other trad emarks men tioned herein are for reference purposes only. ©2021 NETGEAR, Inc.
NETGE AR, Inc. 350 E. Plumeria Drive, San Jose, CA 95134-1911 USA, www.NE TGEAR.com/suppor t D-R8900-1
PAGE 10 of 10
