Nidec SI-Interbus 500 kBd, SI-Interbus 2 MBd User Manual

Download

User Guide

SI-Interbus 500 kBd SI-Interbus 2 MBd

Part Number: 0478-0614-01 Issue Number: 1

Original Instructions

For the purposes of compliance with the EU Machinery Directive 2006/42/EC, the English version of this manual

is the Original Instructions. Manuals in other languages are Translations of the Original Instructions.

Documentation

Manuals are available to download from the following locations: http://www.drive-setup.com/ctdownloads

The information contained in this manual is believed to be correct at the time of printing and does not form part of any contract. The manufacturer reserves the right to change the specification of the product and its performance, and the contents of the manual, without notice.

Warranty and Liability

In no event and under no circumstances shall the manufacturer be liable for damages and failures due to misuse, abuse, improper installation, or abnormal conditions of temperature, dust, or corrosion, or failures due to operation outside the published ratings. The manufacturer is not liable for consequential and incidental damages. Contact the supplier of the drive for full details of the warranty terms.

Environmental policy

Control Techniques Ltd operates an Environmental Management System (EMS) that conforms to the International Standard ISO 14001.

Further information on our Environmental Policy can be found at: http://www.drive-setup.com/environment

Restriction of Hazardous Substances (RoHS)

The products covered by this manual comply with European and International regulations on the Restriction of Hazardous Substances including EU directive 2011/65/EU and the Chinese Administrative Measures for Restriction of Hazardous Substances in Electrical and Electronic Products.

Disposal and Recycling (WEEE)

When electronic products reach the end of their useful life, they must not be disposed of along with domestic waste but should be recycled by a specialist recycler of electronic equipment. Control Techniques products are designed to be easily dismantled into their major component parts for efficient recycling. The majority of materials used in the product are suitable for recycling.

Product packaging is of good quality and can be re-used. Large products are packed in wooden crates. Smaller products are packaged in strong cardboard cartons which have a high recycled fibre content. Cartons can be re-used and recycled. Polythene, used in protective film and bags for wrapping the product, can be recycled. When preparing to recycle or dispose of any product or packaging, please observe local legislation and best practice.

REACH legislation

EC Regulation 1907/2006 on the Registration, Evaluation, Authorisation and restriction of Chemicals (REACH) requires the supplier of an article to inform the recipient if it contains more than a specified proportion of any substance which is considered by the European Chemicals Agency (ECHA) to be a Substance of Very High Concern (SVHC) and is therefore listed by them as a candidate for compulsory authorisation.

Further information on our compliance with REACH can be found at: http://www.drive-setup.com/reach

Registered Office

Nidec Control Techniques Ltd The Gro Newtown Powys SY16 3BE UK

Registered in England and Wales. Company Reg. No. 01236886.

The contents of this publication are believed to be correct at the time of printing. In the interests of a commitment to a policy of continuous development and improvement, the manufacturer reserves the right to change the specification of the product or its performance, or the contents of the guide, without notice.

All rights reserved. No parts of this guide may be reproduced or transmitted in any form or by any means, electrical or mechanical including photocopying, recording or by an information storage or retrieval system, without permission in writing from the publisher.

Contents

1 Safety information ........................................................... 7

1.1 Warnings, cautions and notes ................................................................... 7

1.2 Important safety information. Hazards. Competence of designers

1.3 Responsibility ............................................................................................ 7

1.4 Compliance with regulations ...................................................................... 7

1.5 Electrical hazards ...................................................................................... 8

1.6 Stored electrical charge ............................................................................. 8

1.7 Mechanical hazards ................................................................................... 8

1.8 Access to equipment ................................................................................. 9

1.9 Environmental limits .................................................................................. 9

1.10 Hazardous environments ........................................................................... 9

1.11 Motor ......................................................................................................... 9

1.12 Mechanical brake control ........................................................................... 9

1.13 Adjusting parameters ................................................................................. 9

1.14 Electromagnetic compatibility (EMC) ......................................................... 9

2 Introduction .................................................................... 10

2.1 General .................................................................................................... 10

2.2 Identification ............................................................................................ 10

2.3 Date code format ..................................................................................... 11

2.4 Terminology ............................................................................................. 11

3 Supported features ........................................................ 12

4 Mechanical installation ................................................. 13

4.1 General installation .................................................................................. 13

4.2 Installation on Unidrive M200 to M400 and Commander C200 / C300

4.3 Installation on Unidrive M600 to M702 .................................................... 15

4.4 Installation on Digitax HD ........................................................................16

5 Electrical installation ..................................................... 17

5.1 Interbus cable .......................................................................................... 19

5.2 SI-Interbus cable shield connections ....................................................... 19

5.3 Interbus network termination ................................................................... 19

5.4 Maximum network length ......................................................................... 19

6 Getting started ............................................................... 20

6.1 Node address .......................................................................................... 20

6.2 Communication data rate ........................................................................ 20

6.3 Parameter reference ................................................................................ 20

6.4 Configuring the cyclic data ...................................................................... 20

and installers ............................................................................................. 7

(frames 5 to 9) ......................................................................................... 14

SI-INTERBUS User Guide

Issue Number: 1

7 Additional features ........................................................ 29

7.1 Load module default parameters ............................................................ 29

7.2 Store option parameters .......................................................................... 29

7.3 Module reset ........................................................................................... 30

7.4 Restore saved option parameters ........................................................... 30

7.5 Reset all option modules ......................................................................... 30

7.6 Saving drive parameters ......................................................................... 31

8 Non-Cyclic data ............................................................. 32

8.1 Mode 1 - CT Single Word mode .............................................................. 32

8.2 Mode 2 - PPO 4 Word mode ................................................................... 46

8.3 Mode 3 - Peripheral Communications Protocol V2.0 .............................. 54

9 Virtual menus ................................................................. 58

9.1 Pr 60.01 to Pr 60.56 (Setup menu shortcut) ........................................... 58

9.2 Pr 61.01 (Parameter 0 access) ............................................................... 58

9.3 Pr 61.40 (Event trigger - lowest slot) ....................................................... 58

9.4 Pr 61.41 (Event trigger – slot 1) .............................................................. 58

9.5 Pr 61.42 (Event trigger – slot 2) .............................................................. 58

9.6 Pr 61.43 (Event trigger – slot 3) .............................................................. 59

9.7 Pr 61.50 (CT Single Word - mode 1 non-cyclic) ...................................... 59

9.8 Pr 61.51 (PPO 4 Word – mode 2 non-cyclic) .......................................... 59

10 SI-Applications parameters .......................................... 60

10.1 Single SI-Applications fitted .................................................................... 60

10.2 Dual SI-Applications fitted ....................................................................... 61

11 Control / status word ..................................................... 62

11.1 Control word ............................................................................................ 62

11.2 Status word ............................................................................................. 64

12 Diagnostics .................................................................... 65

12.1 Module ID code ....................................................................................... 65

12.2 Firmware version ..................................................................................... 65

12.3 Interbus operating status ......................................................................... 65

12.4 SI-Interbus serial number ........................................................................ 66

12.5 Cyclic data mapping status ..................................................................... 66

12.6 Module error status ................................................................................. 68

12.7 Background cycles per second ............................................................... 68

12.8 PCB temperature .................................................................................... 69

12.9 Hardware version .................................................................................... 69

12.10 Date code ................................................................................................ 69

12.11 Status LEDs ............................................................................................ 70

12.12 LED operating sequence ......................................................................... 71

SI-INTERBUS User Guide Issue Number: 1

13 Single line setup parameter descriptions ...................72

14 Full parameter descriptions .......................................... 74

14.1 Module ID ................................................................................................ 75

14.2 Firmware version ..................................................................................... 75

14.3 Interbus data format ................................................................................ 75

14.4 Interbus operating status ......................................................................... 76

14.5 Network loss timeout ............................................................................... 76

14.6 Direct data mapping ................................................................................ 77

14.7 Cyclic input mapping ............................................................................... 77

14.8 Cyclic output mapping ............................................................................. 77

14.9 Default option parameters ....................................................................... 78

14.10 Save option parameters .......................................................................... 78

14.11 Module reset ............................................................................................ 79

14.12 Use saved option parameters .................................................................. 79

14.13 Data compression enable ........................................................................ 79

14.14 Serial number LS ..................................................................................... 80

14.15 Cyclic mapping status .............................................................................. 80

14.16 Module status .......................................................................................... 80

14.17 Background cycles .................................................................................. 81

14.18 PCB temperature ..................................................................................... 81

14.19 Hardware version .................................................................................... 81

14.20 Serial number MS .................................................................................... 81

14.21 Manufacture date code ............................................................................ 82

15 CMD tool support files .................................................. 83

15.1 Interbus CMD tool .................................................................................... 83

15.2 CMD tool configuration formats ............................................................... 83

16 Glossary of terms .......................................................... 85

SI-INTERBUS User Guide

Issue Number: 1

1 Safety information

WARNING

CAUT ION

NOTE

information

Safety

1.1 Warnings, cautions and notes

A Warning contains information, which is essential for avoiding a safety hazard.

A Caution contains information, which is necessary for avoiding a risk of damage to the product or other equipment.

A Note contains information, which helps to ensure correct operation of the product.

1.2 Important safety information. Hazards. Competence of designers and installers

This guide applies to products which control electric motors either directly (drives) or indirectly (controllers, option modules and other auxiliary equipment and accessories). In all cases the hazards associated with powerful electrical drives are present, and all safety information relating to drives and associated equipment must be observed.

Specific warnings are given at the relevant places in this guide.

Drives and controllers are intended as components for professional incorporation into complete systems. If installed incorrectly they may present a safety hazard. The drive uses high voltages and currents, carries a high level of stored electrical energy, and is used to control equipment which can cause injury. Close attention is required to the electrical installation and the system design to avoid hazards either in normal operation or in the event of equipment malfunction. System design, installation, commissioning/ start-up and maintenance must be carried out by personnel who have the necessary training and competence. They must read this safety information and this guide carefully.

1.3 Responsibility

It is the responsibility of the installer to ensure that the equipment is installed correctly with regard to all instructions given in this guide. They must give due consideration to the safety of the complete system, so as to avoid the risk of injury both in normal operation and in the event of a fault or of reasonably foreseeable misuse.

The manufacturer accepts no liability for any consequences resulting from inappropriate, negligent or incorrect installation of the equipment.

descriptions

features

installation

started

features

data

menus

parameters

status word

descriptions

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

1.4 Compliance with regulations

The installer is responsible for complying with all relevant regulations, such as national wiring regulations, accident prevention regulations and electromagnetic compatibility (EMC) regulations. Particular attention must be given to the cross-sectional areas of conductors, the selection of fuses or other protection, and protective ground (earth) connections.

SI-INTERBUS User Guide 7 Issue Number: 1

support files

CMD tool

Glossary

of terms

This guide contains instructions for achieving compliance with specific EMC standards.

All machinery to be supplied within the European Union in which this product is used must comply with the following directives:

2006/42/EC Safety of machinery.

2014/30/EU: Electromagnetic Compatibility.

1.5 Electrical hazards

The voltages used in the drive can cause severe electrical shock and/or burns, and could be lethal. Extreme care is necessary at all times when working with or adjacent to the drive. Hazardous voltage may be present in any of the following locations:

• AC and DC supply cables and connections

• Output cables and connections

• Many internal parts of the drive, and external option units

Unless otherwise indicated, control terminals are single insulated and must not be touched.

The supply must be disconnected by an approved electrical isolation device before gaining access to the electrical connections.

The STOP and Safe Torque Off functions of the drive do not isolate dangerous voltages from the output of the drive or from any external option unit.

The drive must be installed in accordance with the instructions given in this guide. Failure to observe the instructions could result in a fire hazard.

1.6 Stored electrical charge

The drive contains capacitors that remain charged to a potentially lethal voltage after the AC supply has been disconnected. If the drive has been energized, the AC supply must be isolated at least ten minutes before work may continue.

1.7 Mechanical hazards

Careful consideration must be given to the functions of the drive or controller which might result in a hazard, either through their intended behaviour or through incorrect operation due to a fault. In any application where a malfunction of the drive or its control system could lead to or allow damage, loss or injury, a risk analysis must be carried out, and where necessary, further measures taken to reduce the risk - for example, an overspeed protection device in case of failure of the speed control, or a fail-safe mechanical brake in case of loss of motor braking.

With the sole exception of the Safe Torque Off function, none of the drive functions must be used to ensure safety of personnel, i.e. they must not be used for safety-related functions.

The Safe Torque Off function may be used in a safety-related application. The system designer is responsible for ensuring that the complete system is safe and designed correctly according to the relevant safety standards.

The design of safety-related control systems must only be done by personnel with the required training and experience. The Safe Torque Off function will only ensure the safety of a machine if it is correctly incorporated into a complete safety system. The system must be subject to a risk assessment to confirm that the residual risk of an unsafe event is at an acceptable level for the application.

8 SI-INTERBUS User Guide

Issue Number: 1

1.8 Access to equipment

Access must be restricted to authorized personnel only. Safety regulations which apply at the place of use must be complied with.

1.9 Environmental limits

Instructions in this guide regarding transport, storage, installation and use of the equipment must be complied with, including the specified environmental limits. This includes temperature, humidity, contamination, shock and vibration. Drives must not be subjected to excessive physical force.

1.10 Hazardous environments

The equipment must not be installed in a hazardous environment (i.e. a potentially explosive environment).

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

1.11 Motor

The safety of the motor under variable speed conditions must be ensured.

To avoid the risk of physical injury, do not exceed the maximum specified speed of the motor.

Low speeds may cause the motor to overheat because the cooling fan becomes less effective, causing a fire hazard. The motor should be installed with a protection thermistor. If necessary, an electric forced vent fan should be used.

The values of the motor parameters set in the drive affect the protection of the motor. The default values in the drive must not be relied upon. It is essential that the correct value is entered in the Motor Rated Current parameter.

1.12 Mechanical brake control

Any brake control functions are provided to allow well co-ordinated operation of an external brake with the drive. While both hardware and software are designed to high standards of quality and robustness, they are not intended for use as safety functions, i.e. where a fault or failure would result in a risk of injury. In any application where the incorrect operation of the brake release mechanism could result in injury, independent protection devices of proven integrity must also be incorporated.

1.13 Adjusting parameters

Some parameters have a profound effect on the operation of the drive. They must not be altered without careful consideration of the impact on the controlled system. Measures must be taken to prevent unwanted changes due to error or tampering.

1.14 Electromagnetic compatibility (EMC)

Installation instructions for a range of EMC environments are provided in the relevant Power Installation Guide. If the installation is poorly designed or other equipment does not comply with suitable standards for EMC, the product might cause or suffer from disturbance due to electromagnetic interaction with other equipment. It is the responsibility of the installer to ensure that the equipment or system into which the product is incorporated complies with the relevant EMC legislation in the place of use.

descriptions

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 9 Issue Number: 1

2 Introduction

2.1 General

The SI-Interbus option module allows a Control Techniques drive to be connected to an Interbus network and operate as an Interbus slave device. It will allow transfer of up to 10 x 16-bit cyclic input data and 10 x 16-bit cyclic output data between the local drive (and its option modules), and external devices on the Interbus network.

The SI-Interbus module can be fitted to any one of the expansion slots in the Unidrive M200 to M400, Unidrive M600/M7XX, Digitax HD or Commander C200/C300.

2.2 Identification

The SI-Interbus option module can be identified by:

• The label located on the top of the option module (Table 2-1 SI-Interbus top label (500 kBd and 2 MBd))

• The colour of the front bezel (Grey)

Figure 2-1 SI-Interbus option module (2 MBd)

Table 2-1 shows sample module labels that would be fitted to the SI-Interbus modules

Table 2-1 SI-Interbus top label (500 kBd and 2 MBd)

SI-Interbus 500 kBd SI-Interbus 2 MBd

82400000021220 82400000021230

S/N:3000005001 1914 S/N:3000005001 1914

10 SI-INTERBUS User Guide

Issue Number: 1

Two variants are available, 500 kBd and 2 MBd. The specific variant can be identified

NOTE

from the label located on the top of the option module

2.2.1 Part numbers

The following table shows the available options for the SI-Interbus module.

Table 2-2 SI-Interbus option part numbers

Part Number Item

82400000021220 SI-Interbus 500 kBd

82400000021230 SI-Interbus 2 MBd

9500-1067 RJ45 to D9F Cable

information

Safety

Introduction

Supported

features

Mechanical

installation

2.3 Date code format

The module date code is a four digit number. The first two digits indicate the year and the remaining two digits indicate the week of the year in which the option module was manufactured.

Example:

A date code of 1914 would correspond to week 14 of the year 2019.

This date code format (YYWW) is different to the module manufacture date code as displayed in the module parameter Pr MM.056 (YYMM).

2.4 Terminology

2.4.1 Input / Output

Throughout this document, the terms IN (or Input) and OUT (or Output) when referring to the cyclic data, refer to the data in relation to the Interbus master, so IN (or Input) would refer to the data transmitted from the SI-Interbus to the Interbus master and OUT (or Output) would refer to the data transmitted from the Interbus master to the SI-Interbus module.

2.4.2 Parameter reference

The parameters within the SI-Interbus module use a 2-digit number reference for the menu number and a 3-digit number reference for the parameter number. However, some features (such as the cyclic mappings parameters) for compatibility reasons only support a 2-digit number reference for the parameter, any 2-digit parameter reference used in this document may also be used as a 3-digit number reference by adding a leading 0.

So, for example, in Figure 6-1 Network loss trip detection, the setup parameters

15.07, 16.07 and 17.07 are used, these may be read as 15.007, 16.007 and 17.007 respectively.

descriptions

installation

started

features

data

menus

parameters

status word

descriptions

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

SI-INTERBUS User Guide 11 Issue Number: 1

support files

CMD tool

Glossary

of terms

3 Supported features

• 10 x 16-bit (Input and output) cyclic data transfer

• Cyclic block mapping

• Cyclic mapping to SI-Applications Plus / Compact or MCi2x0 parameters

• Interbus error status (Pr MM.050)

• Basic module status information

• Data compression (Pr MM.034)

• Direct data mapping (Pr MM.009)

• Direct slot addressing to SI-Applications Plus / Compact or MCi2x0

• Non-cyclic mode 1 (CT Single Word)

• Non-cyclic mode 2 (PPO 4 Word)

• Non-cyclic mode 3 (PCP V2.0)

• Network loss trip (Pr MM.007)

• Load module defaults (Pr MM.030)

• Store option parameters (Pr MM.031)

• Restore option parameters (Pr MM.033)

• PC Tools support (Connect V2.13.1 or later)

12 SI-INTERBUS User Guide

Issue Number: 1

4 Mechanical installation

WARNING

NOTE

Before installing or removing a System Integration module, ensure the AC supply (and any DC supply) has been disconnected for at least 10 minutes.

information

Safety

Introduction

Supported

features

4.1 General installation

Figure 4-1 Installation on Unidrive M200 to M400 and Commander C200 / C300

(frames 2 to 4)

installation

started

features

data

menus

parameters

status word

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

• With the option module tilted slightly backwards, align and locate the two holes in

the rear of the option module onto the two tabs (1) on the drive.

• Place the option module onto the drive as shown in (2) until the module clicks into

place. The terminal cover on the drive holds the option module in place, so this must be put back on.

Option modules can only be installed on drives that have the option module slot functionality.

SI-INTERBUS User Guide 13 Issue Number: 1

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

4.2 Installation on Unidrive M200 to M400 and Commander C200 / C300 (frames 5 to 9)

• Place the option module onto the drive as shown in (2) until the module clicks into

place. The terminal cover on the drive holds the option module in place, so this must be put back on.

14 SI-INTERBUS User Guide

Issue Number: 1

4.3 Installation on Unidrive M600 to M702

NOTE

information

features

installation

started

features

data

menus

parameters

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

• Move the option module in direction shown (1/2).

• Align and insert the option module tab in to the slot provided, this is highlighted in

the detailed view (A).

• Press down on the option module until it clicks into place.

Option module slots must be used in the following order: Slot 3 (lower), Slot 2 (middle) and then Slot 1(upper).

SI-INTERBUS User Guide 15 Issue Number: 1

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

4.4 Installation on Digitax HD

NOTE

• Remove the protective interface card covers (1).

• Align and insert the option module tab into the slot provided (2).

• Once the option module tab is located into the slot on the drive, push down at the

rear of the option module until it clicks into place (3).

Once fitted, the SI option module remains at an angle with respect to the drive..

When connecting SI option modules, an additional SI option mounting kit is required for the Digitax HD M75X series, if the drive is not supplied with a SI option mounting kit fitted. The SI option mounting kit can be ordered from the supplier of the drive. Refer to the Digitax HD M75X Series Installation and Technical Guide for further information.

16 SI-INTERBUS User Guide

Issue Number: 1

5 Electrical installation

Ground tab Remote Bus IN Remote Bus OUT

NOTE

The SI-Interbus has a 9-way male ‘D’ type connector for the Remote Bus IN port and an 8-way RJ45 female connector for the Remote Bus OUT port.

The electrical connections are shown in Table 5-1 SI-Interbus connections.

Table 5-1 SI-Interbus connections

IN Terminal

9-way ‘D’ male

1 Yellow DO1 Positive Data line output from PLC

2 Grey DI1 Positive Data line input to PLC

3 Brown 0V ISO IN Isolated 0V Remote Bus OUT

6 Green /DO1 Negative Data line output from PLC

7 Pink /DI1 Negative Data line input to PLC

Shield Shield Remote Bus IN cable shield

OUT Terminal

RJ45

female

9-way ‘D’

female

2 1 Yellow DO2 Positive Data line output from PLC

1 2 Grey DI2 Positive Data line input to PLC

3 3 Brown 0V ISO OUT Isolated 0V Remote Bus IN

7 6 Green /DO2 Negative Data line output from PLC

8 7 Pink /DI2 Negative Data line input to PLC

Shield Shield Shield Remote Bus OUT cable shield

Colour

Colour Function Description

PLC

Function

Description

information

features

installation

started

features

data

menus

parameters

status word

descriptions

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

The terms IN and OUT refer to the physical cable connections for the SI-Interbus module, not the PLC data direction. IN refers to the cable from the PLC to the SI-Interbus module. OUT refers to the cable from the SI-Interbus module to the next slave device.

SI-INTERBUS User Guide 17 Issue Number: 1

support files

CMD tool

Glossary

of terms

The terms ‘Input’ and ‘Output’ in the table above refer to the data direction with regards

NOTE

to the PLC. ‘Input’ refers to the data from a slave device (e.g. SI-Interbus) to the PLC. ‘Output’ refers to the data from the PLC to a slave device (e.g. SI-Interbus).

Figure 5-1 Remote bus IN

Figure 5-2 Remote bus OUT

A suitable cable is provided to connect a standard Interbus 9 pin ‘D’ male connector to the RJ45 port and can be purchased separately from Control Techniques using the part number 9500-1067.

Figure 5-3 Remote bus OUT adapter

18 SI-INTERBUS User Guide

Issue Number: 1

Figure 5-4 Remote bus OUT wiring details

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

Additional

features

Non-Cyclic

data

5.1 Interbus cable

Interbus cable has three twisted pairs plus overall shielding. The colours normally used on Interbus networks are shown in Table 5-1 SI-Interbus connections. It is recommended to follow these wiring guidelines as this will make it easier to trace possible wiring errors during commissioning.

5.2 SI-Interbus cable shield connections

The Remote Bus IN and Remote Bus OUT cable shields MUST be connected to the shell of the connector. There is no requirement to connect the cable shields directly to Ground at any other point in the Interbus network.

5.3 Interbus network termination

Termination resistors are not required on Interbus networks, as each section of cable is automatically terminated on every Interbus device. The Ground Tab of the SI-Interbus must be connected to a suitable grounding point as close to the drive as possible using the minimal cable length.

5.4 Maximum network length

The maximum cable length is 400 metres between Remote Bus devices. Hence, the maximum total length of the Interbus network depends entirely on the number of devices connected to the network.

SI-INTERBUS User Guide 19 Issue Number: 1

descriptions

menus

parameters

status word

descriptions

support files

of terms

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

6 Getting started

6.1 Node address

Interbus devices do not require a specific node address to be configured, the physical wiring of the network determines the Communication Reference (CR) that will be assigned to the device by the Interbus master controller.

6.2 Communication data rate

Interbus networks operate at a fixed baud rate, either 500 kBd or 2 MBd. The SI-Interbus module is configured during manufacture to operate at one of these rates, this configuration is determined by the part number specified at the time of ordering and cannot be changed by the user.

6.3 Parameter reference

Parameters are referenced using the notation Pr MM.xx, where ‘Pr’ means parameter, ‘MM’ represents menu 15, 16 or 17 (depending upon which slot contains the option module) and ‘xx’ is the parameter number within the menu.

Table 6-1 Slot / menu numbering

Slot Menu

115

216

317

The following conventions are used in this document:

•PrMM.ppp – Where MM signifies the slot specific menu allocated to the option

module setup menu and ppp signifies the parameter number within that setup menu.

•Prmm.000 – Signifies parameter number 0 in any drive or option menu.

The SI-Interbus module displays the module ID code in Pr MM.001, this module ID code is used to identify the module variant.

SI-Interbus Module ID

Default 404 (500 kBd) or 414 (2 MBd)

Pr MM.001

Type 1 6- bi t

Access RO

6.4 Configuring the cyclic data

6.4.1 What is cyclic data

Cyclic data is a method of data transfer that must be setup during network configuration, but is transmitted automatically once configuration is complete. The high speed data transfer is achieved by transmitting only data bytes over the Interbus network, and relying on local mapping information within the SI-Interbus and Interbus master controller to ensure that the correct data is sent to the correct locations. This method relies on the master controller program writing and reading data values to and from the registers allocated to the node during network configuration, and the source and destination of IN and OUT data being setup correctly in the drive.

20 SI-INTERBUS User Guide

Issue Number: 1

The flexibility of the SI-Interbus means that each cyclic data OUT channel can be

NOTE

directed to any read-write drive (or option module) parameter. Similarly, each cyclic data IN channel can use any drive (or option module) parameter as a source of data.

The cyclic data mapping cannot be changed dynamically, as changes to the mapping parameters will only take effect during initialisation of the SI-Interbus, i.e. after a reset, or at power up.

6.4.2 Data format

The default data format is 4 words IN and 4 words OUT, this value can be changed to suit the application (up to 10 IN and 10 OUT words). Each cyclic data channel is mapped directly to a drive (or option module) parameter.

information

Safety

Introduction

Supported

features

Mechanical

installation

Interbus Data Format

Default 4 (Words)

Pr MM.005

Type 1 6- bi t

Access RW

The SI-Interbus data format is specified as “NNPP”, where “NN” is the non-cyclic data mode, and “PP” is the number of cyclic data words as shown in the following table.

Table 6-2 Interbus data formats

Pr MM.005 NN PP Non-cyclic Mode Cyclic Words

1 to 10 0 1 to 10 None 1 to 10

100 to 109 1 0 to 9 CT Single Word 0 to 9

200 to 209 2 0 to 6 PPO 4 Word 0 to 6

300 to 309 3 0 to 9 PCP 0 to 9

The default mappings are shown in Table 6-3 Default mappings.

Table 6-3 Default mappings

Cyclic Channel Data Word Default Mapping

IN channel 0 Word 0, 1 Pr 10.040 (Status Word)

IN channel 1 Word 2, 3 Pr 2.001 (Post Ramp Reference)

OUT channel 0 Word 0, 1 Pr 6.042 (Control Word)

OUT channel 1 Word 2, 3 Pr 1.021 (Preset Reference 1)

The SI-Interbus can map a total of up to 10 words as input and 10 words as output, by default with Pr MM.034 (Data Compression Enable) = Off, each cyclic channel will map 2 words to the mapped parameter, irrespective of whether the parameter is a 16-bit or 32-bit parameter, this gives a total number of 5 available mappings. If any desired mapping parameter is less than 32 bits in size, then Pr MM.034 (Data Compression Enable) may be set to On, this will then use only 1 word for each cyclic mapping channel as long as the mapped parameter size is less than 32 bits. This increases the number of available mappings by 1 for each mapped parameter that is not a 32-bit parameter, up to a maximum of 10 parameters.

If the mapped parameter size is actually 32 bits, then 2 words will still be used to transfer the data.

descriptions

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 21 Issue Number: 1

The size of the data mapping will depend on the size of the target / source parameter.

NOTE

If using 16-bit (or less) parameters the data can be sent as 16 bits on the network (Pr MM.034 = On). Parameters larger than 16 bits always use 32 bits on the network irrespective of the setting of Pr MM.034).

6.4.3 Cyclic input mappings

Parameters Pr MM.010 to Pr MM.019 specify the source parameters for the cyclic data input mappings.

Pr MM.010

Pr MM.019

Default

Type 1 6- bi t

Access RW

The reference for the source parameter is entered in the mapping parameter in the form MMPP, where MM represents the menu number of the source parameter and PP represents the parameter number of the source parameter.

6.4.4 Cyclic output mappings

Parameters Pr MM.020 to Pr MM.029 specify the destination parameters for the cyclic data output mappings.

Pr MM.020

Pr MM.029

The reference for the destination parameter is entered in the mapping parameter in the form MMPP, where MM represents the menu number of the destination parameter and PP represents the parameter number of the destination parameter.

Default

Type 1 6- bi t

Access RW

Cyclic Input Mappings 1 to 10

Mapping 1: 1040 Mapping 2: 201 Mapping 3 to 10: 0

Cyclic Output Mappings 1 to 10

Mapping 1: 642 Mapping 2: 121 Mapping 3 to 10: 0

The cyclic data channels do not use decimal points. To write a value of 24.6 Hz to Pr 1.021, the value must be transmitted as 246.

6.4.5 Data compression

Cyclic Data Compression Enable

Default 0 (Off)

Pr MM.034

Type 1-bit

Access RW

By default, the SI-Interbus uses 32 bits for each data channel, even if the mapped parameter is a 16-bit parameter. When cyclic data compression is enabled (Pr MM.034 = On), a data channel will only use 32 bits if the mapped parameter is a 32-bit parameter. If the mapped parameter is only 1, 8 or 16 bits wide 16 bits will be used for that particular data channel.

22 SI-INTERBUS User Guide

Issue Number: 1

6.4.6 Direct data mapping

By default, the cyclic data mapping parameters MM.010 to MM.029 are used as pointers to specify the destination parameters for OUT data received from the Interbus master controller, and the source parameter of IN data to be transmitted to the Interbus master controller.

When direct data mapping is enabled (Pr MM.009 = On), the cyclic data mapping parameters are used as the actual source or destination parameters for the cyclic data.

Hence, IN data values read from Pr MM.010 to MM.019 are transmitted to the Interbus master controller and OUT data values arriving from the Interbus master controller are written directly into Pr MM.020 to Pr MM.029.

Default 0 (Off)

Pr MM.009

Type 1-bit

Access RW

6.4.7 Interbus operating status

The Interbus network activity can be monitored in the operating status parameter, Pr MM.006.

When the SI-Interbus is communicating successfully with the Interbus master controller, the operating status will give an indication of the number of cyclic data messages per second that are being processed.

Default None

Pr MM.006

If Pr MM.006 is a negative value, this indicates a non-operational state as shown in the following table.

Table 6-4 Interbus operating status

Pr MM006 Description

> 0 Network healthy, displays the number of messages processed per second

0 Network health, no cyclic data transfer

-1

-2 The SI-Interbus module reports an internal hardware fault

-3

If Pr MM.006 shows a positive value, this value is dependent upon the Interbus network communication speed, number of mappings and whether non-cyclic communications are active or not.

Type 1 6- bi t

Access RO

SI-Interbus has initialised correctly and waiting for the Interbus master to initialise communication

Configuration error, invalid setting in the SI-Interbus configuration parameters

Direct Data Mapping Enable

Interbus Operating Status

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

SI-INTERBUS User Guide 23 Issue Number: 1

Glossary

of terms

6.4.8 Network loss trip timeout

The SI-Interbus resets an internal timer when a valid cyclic data message is received from the Interbus network. The network loss trip is triggered when no new messages are received before the timer times out. The SI-Interbus error code parameter (Pr MM.050) will show a value of 65 when a network loss trip has occurred.

Default 200 (ms)

Pr MM.007

The network loss trip is not enabled internally until cyclic data has been detected. This prevents spurious network loss trips while the Interbus master controller is initialising the network.

Figure 6-1 Network loss trip detection

Type 1 6- bi t

Access RW

Network Loss Trip Timeout

As the trip delay time is reduced, the network loss trip will occur more quickly in the event of a loss of network. However, if the network loss trip time is reduced too far, spurious network loss trips may occur due to the timeout occurring before the next message has arrived.

The minimum network loss trip time for a particular network depends entirely on the number of messages per second being received under normal operation. As a rough guide, the network loss trip time should be set such that a minimum of 4 messages will be received in the specified time period under normal operating conditions.

The network loss trip can be disabled by setting Pr MM.007 to 0. In this case, the drive will continue to operate using the last received values. It is the user’s responsibility to ensure that adequate safety precautions are taken to prevent damage or injury by disabling the drive in the event of a loss of communications.

24 SI-INTERBUS User Guide

Issue Number: 1

6.4.9 Cyclic data mapping status

NOTE

If the SI-Interbus operating status parameter (Pr MM.006) indicates a value of -3, a mapping configuration error has been detected. The actual reason for the error is indicated by the mapping status parameter, Pr MM.049. When a mapping error has been corrected, reset the SI-Interbus by setting Pr MM.032 to On.

information

Safety

Introduction

Pr MM.049

Possible values for the mapping status are shown in Table 12-2 Mapping status codes.

If the mapping configuration size has changed (Pr MM.005 Interbus Data Format), then the module reset is insufficient to fully initialise the Interbus network and after saving parameters, the module must be power-cycled.

6.4.10 Block mapping

Block mapping provides a quick and convenient way of mapping sequential parameters to the Interbus network with the minimum number of mapping parameters specified.

Block mapping is used automatically if:

• The value entered in the mapping parameters (Pr MM.010 to MM.029) are specified

in ascending order (i.e. lowest value parameter number first).

• The menu number of adjacent mappings are identical.

Care must be taken to ensure the total number of cyclic mappings specified does not exceed the maximum number allowed (Pr MM.005).

For example, the following mappings would map 5 x 32-bit parameters in menu 20, starting from Pr 20.021 to Pr 20.025 inclusive as inputs and 5 x 16-bit parameters in menu 18, starting from Pr 18.011 to Pr 18.015 inclusive and 5 x 16-bit parameters in menu 19, starting at Pr 19.021 to Pr 19.025 inclusive as outputs.

Table 6-5 Block mapping example

Mapping Parameter Mapping Value

Pr MM.010 2021

Pr MM.011 2025

Pr MM.012

Pr MM.019

Pr MM.020 1811

Pr MM.021 1815

Pr MM.022 1921

Pr MM.023 1925

Pr MM.024

Pr MM.029

For this example to work, data compression must be enabled (Pr MM.034 = On).

The following table shows the data structure for the example mappings.

Cyclic Data Mapping Status

Default None

Type 8-bit

Access RO

descriptions

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 25 Issue Number: 1

Table 6-6 Data structure example

Target Parameter Data Word

Pr 20.021 IN Word 0, 1

Pr 20.022 IN Word 2, 3

Pr 20.023 IN Word 4, 5

Pr 20.024 IN Word 6, 7

Pr 20.025 IN Word 8, 9

Pr 18.011 OUT Word 0

Pr 18.012 OUT Word 1

Pr 18.013 OUT Word 2

Pr 18.014 OUT Word 3

Pr 18.015 OUT Word 4

Pr 19.021 OUT Word 5

Pr 19.022 OUT Word 6

Pr 19.023 OUT Word 7

Pr 19.024 OUT Word 8

Pr 19.025 OUT Word 9

To avoid block mapping when parameters of a particular menu are specified, the parameter values should be entered in descending order, i.e. largest value parameter first.

6.4.11 Disabling cyclic data channels

If any cyclic data channels are not being used, the associated mapping parameters should be set to 0. The Interbus master controller will transmit a value of 0 for the unused cyclic data words, and any unused incoming data values will be set to 0 before being passed to the Interbus master controller.

6.4.12 Cyclic data mapping examples

The following sections show some example data formats that can be selected, and the parameter mapping that will apply (by default) to each format.

6.4.12.1 Two cyclic channels only (default)

This data format provides two cyclic data channels with no non-cyclic data. The total data length is 4 words in and 4 words out. This data format is selected by default.

Configuration parameters:

Pr MM.005 (Interbus Data Format) = 4.

Pr MM.034 (Cyclic Data Compression Enable) = Off.

Table 6-7 Default cyclic data mapping

Cyclic Channel Data Word Parameter Default Mapping

IN Channel 0 Word 0, 1 Pr MM.010 Pr 10.40, Status Word

IN Channel 1 Word 2, 3 Pr MM.011 Pr 2.01, Post Ramp Reference

OUT Channel 0 Word 0, 1 Pr MM.020 Pr 6.42, Control Word

OUT Channel 1 Word 2, 3 Pr MM.021 Pr 1.21, Preset Reference 1

26 SI-INTERBUS User Guide

Issue Number: 1

6.4.12.2 Three cyclic channels with CT Single Word non-cyclic data

This data format provides three cyclic data channels, plus an additional channel for CT Single Word (Mode 1) non-cyclic data (see section 8 Non-Cyclic data). The total data length is 8 words.

Configuration parameters:

Pr MM.005 (Interbus Data Format) = 106.

Pr MM.034 (Cyclic Data Compression Enable) = Off.

Table 6-8 Mapping for 3 cyclic channels with CT Single Word non-cyclic

Cyclic Channel Data Word Parameter Default Mapping

IN Channel 0 Word 0, 1 Pr MM.010 Pr 61.50, CT Single Word non-cyclic mode 1

IN Channel 1 Word 2, 3 Pr MM.011 Pr 10.40, Status Word

IN Channel 2 Word 4, 5 Pr MM.012 Pr 2.01, Post Ramp Reference

IN Channel 3 Word 6 to 7 Pr MM.013 User defined

OUT Channel 0 Word 0, 1 Pr MM.020 Pr 61.50, CT Single Word non-cyclic mode 1

OUT Channel 1 Word 2, 3 Pr MM.021 Pr 10.40, Status Word

OUT Channel 2 Word 4, 5 Pr MM.022 Pr 2.01, Post Ramp Reference

OUT Channel 3 Word 6 to 7 Pr MM.023 User defined

6.4.12.3 Five cyclic channels only

This data format provides five cyclic data channels, with no non-cyclic data channel. The total data length is 10 words.

Configuration parameters:

Pr MM.005 (Interbus Data Format) = 10.

Pr MM.034 (Cyclic Data Compression Enable) = Off.

Block mapping can be used to map the remaining un-used data words. (See section 6.4.10 Block mapping).

Table 6-9 Mapping for 5 cyclic channels only

Cyclic Channel Data Word Parameter Default Mapping

IN Channel 0 Word 0, 1 Pr MM.010 Pr 10.40, Status Word

IN Channel 1 Word 2, 3 Pr MM.011 Pr 2.01, Post Ramp Reference

IN Channel 2 to 4 Word 4 to 9

Pr MM.012

User defined

Pr MM.014

OUT Channel 0 Word 0, 1 Pr MM.020 Pr 6.42, Control Word

OUT Channel 1 Word 2, 3 Pr MM.021 Pr 1.21, Preset Reference 1

OUT Channel 2 to 4 Word 4 to 9

Pr MM.022

User defined

Pr MM.024

6.4.12.4 Three cyclic channels with PPO 4 Word non-cyclic data

This data format provides three cyclic data channels, plus an additional 4 words for PPO 4 Word (Mode 2) non-cyclic data (see section 8 Non-Cyclic data). The total data length is 10 words.

Configuration parameters:

Pr MM.005 (Interbus Data Format) = 206.

Pr MM.034 (Cyclic Data Compression Enable) = Off.

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 27 Issue Number: 1

Table 6-10 Mapping for 3 cyclic channels with PPO 4 Word non-cyclic

Cyclic Channel Data Word Parameter Default Mapping

IN Channel 0 Word 0 to 3 Pr MM.010 Pr 61.51, PPO 4 Word Non-cyclic mode 2

IN Channel 1 Word 4, 5 Pr MM.011 Pr 10.40, Status Word

IN Channel 2 Word 6, 7 Pr MM.012 Pr 2.01, Post Ramp Reference

IN Channel 3 Word 8, 9 Pr MM.013 User defined

OUT Channel 0 Word 0 to 3 Pr MM.020 Pr 61.51, PPO 4 Word Non-cyclic mode 2

OUT Channel 1 Word 4, 5 Pr MM.021 Pr 10.40, Status Word

OUT Channel 2 Word 6, 7 Pr MM.022 Pr 2.01, Post Ramp Reference

OUT Channel 3 Word 8, 9 Pr MM.023 User defined

6.4.12.5 Three cyclic channels with PCP non-cyclic data

This data format provides three cyclic data channels with PCP (Mode 3) non-cyclic data (see section 8.3 Mode 3 - Peripheral Communications Protocol V2.0). The total data length is 7 words.

Configuration parameters:

Pr MM.005 (Interbus Data Format) = 306.

Pr MM.034 (Cyclic Data Compression Enable) = Off.

Table 6-11 Mapping for 3 cyclic channels with PCP non-cyclic

Cyclic Channel Data Word Parameter Default Mapping

IN Channel 0 Word 0, 1 Pr MM.010 Pr 10.40, Status Word

IN Channel 1 Word 2, 3 Pr MM.011 Pr 2.01, Post Ramp Reference

IN Channel 2 Word 4, 5 Pr MM.012 User defined

OUT Channel 0 Word 0, 1 Pr MM.020 Pr 6.42, Control Word

OUT Channel 1 Word 2, 3 Pr MM.021 Pr 1.21, Preset Reference 1

OUT Channel 2 Word 4, 5 Pr MM.022 User defined

There is no mapping required when the peripheral communications protocol (PCP) is enabled.

The PCP channel will use 1 cyclic data word, but it cannot be accessed directly in the Interbus master controller or the SI-Interbus.

28 SI-INTERBUS User Guide

Issue Number: 1

7 Additional features

NOTE

information

Safety

7.1 Load module default parameters

Load Module Defaults

Default Off

Pr MM.030

Type 1-bit

Access RW

If set to “On” when the module is reset (MM.032 = On), this parameter will cause the option module to return to its “Out of Box” configuration any settings stored on the module will be returned to their default values.

This action does not save the parameters in the drive, a drive save must be performed if the parameters are to be saved after loss of power (see section 7.6 Saving drive parameters).

7.2 Store option parameters

Store Option Parameters

Default Off

Pr MM.031

The SI-Interbus module can save a copy of the setup parameters in its flash memory, this allows the user, for example, to keep a copy of a working set of parameters in the module in case the host drive is replaced, or if the user modifies the setup parameters which may result in the Interbus master being unable to communicate with the SI-Interbus module.

To store the SI-Interbus configuration parameters in the flash memory:

• Set Pr MM.031 to On

• Set Pr MM.000 to 1001

• Press the drive red reset button or set Pr 10.038 to 100

The Interbus communication will stop and the SI-Interbus configuration parameters will be saved within the SI-Interbus flash memory. The SI-Interbus will then reset and reinitialise using the configuration parameter values.

Type 1-bit

Access RW

descriptions

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

SI-INTERBUS User Guide 29 Issue Number: 1

descriptions

support files

of terms

Full parameter

CMD tool

Glossary

7.3 Module reset

NOTE

SI-Interbus Module ID

Default Off

Pr MM.032

Type 1-bit

Access RW

Any changes made to the SI-Interbus configuration parameters will not take effect until the SI-Interbus has been reset.

To reset the SI-Interbus option module set Pr MM.032 to On.

When the reset sequence has been completed, Pr MM.032 will be reset to Off and the SI-Interbus will re-initialise using the updated configuration.

This does not store the drive or option module parameters in the drive or option module, please refer to section 7.6 Saving drive parameters.

7.4 Restore saved option parameters

Restore Saved Option Parameters

Default Off

Pr MM.033

If valid configuration parameters have previously been stored in the SI-Interbus flash memory (Pr MM.031), these values can be restored into the host drive parameters by setting Pr MM.033 to On.

When the configuration parameter values have been uploaded to the host drive SI-Interbus will reset and re-configure using the updated parameter values.

This feature allows a pre-configured SI-Interbus module to be installed into a host drive without losing the SI-Interbus configuration.

Type 1-bit

Access RW

7.5 Reset all option modules

To reset all option modules fitted in the drive:

• Set Pr MM.000 to 1070

• Press the red reset button on the drive or set Pr 10.038 to 100

This does not store the drive or option module parameters in the drive or option module, please refer to section 7.6 Saving drive parameters.

30 SI-INTERBUS User Guide

Issue Number: 1

7.6 Saving drive parameters

NOTE

After changing a drive (or option module) parameter, the change needs to be saved in order to be maintained in the event of a loss of power or power-cycle.

This does not apply to drive menu 20 parameters unless the SI-Applications option module is used to save the menu 20 parameters (see the SI-Applications documentation for more information).

To save the drive parameters:

• Set Pr MM.000 to 1001

• Press the red reset button on the drive or set Pr 10.038 to 100

The drive (and option module) parameters are now saved.

information

features

installation

started

features

data

menus

parameters

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

SI-INTERBUS User Guide 31 Issue Number: 1

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

8 Non-Cyclic data

NOTE

The non-cyclic data channel provides a method for the Interbus master controller to read from or write to any parameter within the drive or option module. This channel can be used for single infrequent data transfers, or uploading and downloading parameter sets to or from a particular node.

The SI-Interbus provides three non-cyclic data formats, plus the option to disable noncyclic data.

• CT Single Word format (mode 1, see section 8.1 Mode 1 - CT Single Word mode)

• PPO 4 Word format (mode 2, see section 8.2 Mode 2 - PPO 4 Word mode)

• Peripheral Communications Protocol V2.0 (mode 3, see section 8.3 Mode 3 -

Peripheral Communications Protocol V2.0)

The non-cyclic mode is indicated by the first digit in the value of Pr MM.005 (Interbus Data format) as shown in the following table.

Table 8-1 Non-cyclic modes

Non-cyclic Mode

Disabled 0xx Non-cyclic data disabled

CT Single Word 1xx

PPO 4 Word 2xx

PCP V2.0 3xx

Data Format

(Pr MM.005)

Description

CT Single Word non-cyclic (mode1).

Uses 2 cyclic data words if data compression is disabled or 1 cyclic data word if data compression is enabled (Pr MM.034).

Pr MM.010 and Pr MM.020 will be set to the value 6150 and any existing mappings will be moved down one place.

PPO 4 Word non-cyclic data (mode 2).

Uses four cyclic data words.

Pr MM.010 and Pr MM.020 will be set to the value 6151 and any existing mappings will be moved down one place.

Peripheral Communications Protocol (PCP) V2.0.

Existing mapping configuration will not be affected.

8.1 Mode 1 - CT Single Word mode

The CT Single Word (mode 1) uses one cyclic channel for non-cyclic data. The noncyclic sub-protocol requires a specific sequence of 4 (16-bit parameters) or 6 (32-bit parameters) telegrams to implement the parameter access. Each non-cyclic word or telegram is split into 2 bytes to implement the sub-protocol, with the high byte containing the control codes for each telegram, and the low byte containing the data for each telegram.

If cyclic data compression is disabled (Pr MM.034 = Off), the CT Single Word non-cyclic channel will be 32 bits wide, i.e. uses 2 words, and data must be transferred on the low word. If cyclic data compression is enabled (Pr MM.034 = On), the CT Single Word noncyclic channel will revert to 16 bits and only use 1 word.

32 SI-INTERBUS User Guide

Issue Number: 1

8.1.1 Mapping for CT Single Word non-cyclic data

To configure an SI-Interbus in slot 3 for CT Single Word mode non-cyclic data, the following steps must be performed:

• Set Pr 17.005 to the required mode

• Set Pr 17.032 to On to reset and reconfigure the SI-Interbus

When the SI-Interbus re-initialises, it will map cyclic data IN word 0 and OUT word 0 to the CT Single Word protocol parameter, Pr 61.50. All existing mapping parameters will be moved down by 1 place, i.e. the previous mapping set in Pr 17.010 and Pr 17.020 will now appear in Pr 17.011 and Pr 17.021 respectively.

Table 8-2 Six cyclic words with CT Single Word non-cyclic data mapping shows what happens to the mappings when the data format is changed from 6 cyclic words to 6 cyclic words with CT Single Word non-cyclic data.

Table 8-2 Six cyclic words with CT Single Word non-cyclic data mapping

Mapping

Parameter

Pr 17.010 1040 Pr 10.40, Status W ord 6150

Pr 17.011 201

Pr 17.012 0 User Defined 201

Pr 17.013

Pr 17.019

Pr 17.020 642 Pr 6.42, Control Word 6150

Pr 17.021 121 Pr 1.21, Preset Reference 1 642 Pr 6.42, Control Word

Pr 17.022 0 User Defined 121 Pr 1.21, Preset Reference 1

Pr 17.023

Pr 17.029

The problem with this setup is that the user defined mappings (Pr 17.012 and Pr 17.022) are lost when the SI-Interbus is re-initialised. This is because there is insufficient mappings available to move the user defined channel into.

To maintain all mappings when adding the CT Single Word non-cyclic data channel, the cyclic data format (Pr 17.005) needs to be set to 108, this adds an additional cyclic channel to accommodate the user defined channel as shown in Table 8-3 Eight cyclic words with CT Single Word non-cyclic data mapping.

Before format change

(Pr 17.005 = 6)

Value Mapping Value Mapping

Pr 2.01, Post Ramp Reference

0 Not available 0 Not available

After format change

(Pr 17.005 = 6)

Pr 61.50, CT Single Word non-cyclic mode 1

1040 Pr 10.40, Status Word

Pr 2.01, Post Ramp

Reference

Pr 61.50, CT Single Word non-cyclic mode 1

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

SI-INTERBUS User Guide 33 Issue Number: 1

support files

CMD tool

Glossary

of terms

Table 8-3 Eight cyclic words with CT Single Word non-cyclic data mapping

Mapping

Parameter

Pr 17.010 1040 Pr 10.40, Status Word 6150

Pr 17.011 201

Pr 17.012 0 User Defined 201

Pr 17.013

Pr 17.014

Pr 17.019

Pr 17.020 642 Pr 6.42, Control Word 6150

Pr 17.021 121 Pr 1.21, Preset Reference 1 642 Pr 6.42, Control Word

Pr 17.022 0 User Defined 121 Pr 1.21, Preset Reference 1

Pr 17.023

Pr 17.024

Pr 17.029

Before format change

(Pr 17.005 = 6)

Value Mapping Value Mapping

Pr 2.01, Post Ramp Reference

0 Not available 0 User Defined

0 Not available 0 Not available

0 Not available 0 User Defined

0 Not available 0 Not available

8.1.2 CT Single Word protocol

The CT Single Word protocol uses the lower 16 bits of the non-cyclic channel if data compression is disabled, and all 16 bits if data compression is enabled.

All parameter values are written as signed 32-bit data values. Decimal point information is inserted automatically when the data value is written to the drive, and removed when the data value is read.

Hence, the number of decimal places of the target parameter must be known.

Writing a value of 1234 to a parameter with 2 decimal places will produce a value of

12.34 in the target parameter. Similarly, reading a value of 12.34 will return a 32-bit integer value of 1234.

The CT Single Word format is shown in Table 8-4 CT Single Word bit significance.

Table 8-4 CT Single Word bit significance

b15 b14 b13 b12 b11 b10 b9 b8

READ ERR

Reserved 32-BIT Stamp Number

After format change

(Pr 17.005 = 108)

Pr 61.50, CT Single Word non-cyclic mode 1

1040 Pr 10.40, Status Word

Pr 2.01, Post Ramp

Reference

Pr 61.50, CT Single Word non-cyclic mode 1

b7 b6 b5 b4 b3 b2 b1 b0

Data Byte

The following table (Table 8-5 CT Single Word format) shows the CT Single Word format in more detail.

34 SI-INTERBUS User Guide

Issue Number: 1

Table 8-5 CT Single Word format

NOTE

Bit Function Value Description

0 to 7 Data 0 to 255

8 to 11

12 32-BIT

Stamp

Number

0 to 6

0 = 16-bit 1 = 32-bit

13 Reserved 0 Reserved for future use. Always set to 0.

14 ERR

15 READ

0 = Data OK

1 = Error

0 = Write 1 = Read

Depending on the stamp number of the telegram, this byte contains the menu, parameter or data byte.

Indicates the stamp number of the telegram.

This shows which part of the message is currently in progress. Setting the stamp number to 0 resets the internal non-cyclic state machine.

Specifies whether a 16-bit or 32-bit data value is to be accessed. If 32-BIT is set to 1, telegrams 5 and 6 will be used to transfer the additional data bytes. If 32-BIT is set to 0, then the data bytes will be transferred in telegrams 3 and 4.

Indicates the success or failure of the message. Failure could occur if the parameter does not exist, or is read-only or write-only parameter. This bit will also be set if the parameter value is out of range in 16-bit mode.

Defines whether the data word is part of a READ or WRITE cycle.

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

Additional

features

8.1.3 16-bit parameter access

16-bit data can be accessed using only 4 telegrams. Telegram 4 becomes the low data byte request (or value, for a write sequence) and telegrams 5 and 6 are not required. If an attempt is made to access a 32-bit parameter, the parameter value will be returned, provided that the parameter value does not exceed the signed 16-bit limits (-32768 to 32767). If the value is not within the signed 16-bit value, the ERR bit will be set.

When writing data to a 32-bit parameter using 16-bit mode, the 16-bit data will be treated as a signed 16-bit data value. This limits the range that can be written to a 32-bit parameter.

8.1.4 Reading parameters using CT Single Word

To read 32-bit parameters using CT Single Word non-cyclic channel, the following “telegrams” must be transmitted to construct the final message.

• Telegram 1 Define menu number.

• Telegram 2 Define parameter number.

• Telegram 3 Request high data byte.

• Telegram 4 Request mid-high data byte (32-bit) or low data byte (16-bit).

• Telegram 5 Request mid-low data byte (32-bit).

• Telegram 6 Request low data byte (32-bit).

Figure 8-1 CT Single Word read sequence shows the normal sequence for reading a parameter using CT Single Word non-cyclic.

If a telegram produces an error at any point in the sequence the reply to the master will have the error bit ERR set to a 1 and the data bits will have no significance. Setting the stamp number to 0 will reset the internal non-cyclic state machine.

descriptions

data

menus

parameters

status word

descriptions

support files

of terms

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 35 Issue Number: 1

Figure 8-1 CT Single Word read sequence

The following example telegrams show how to read the post-ramp reference (rpm) with 1 decimal place from Pr 2.001 in the drive.

Tel egram 1

The first telegram from the Interbus master controller indicates a READ cycle by setting bit b15 to 1 and with stamp number 1.

The data byte contains the menu number of the parameter that is to be read.

36 SI-INTERBUS User Guide

Issue Number: 1

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0001 0000 0010

Data word = 0x9102 Stamp Number = 1 Menu = 2

When the first telegram has been received and processed in the slave node, it is mirrored in the non-cyclic IN word back to the Interbus master controller. This is the signal to the master controller program that the first telegram of the message has been received and understood, the second telegram can now be transmitted.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0001 0000 0010

Data word = 0x9102 Stamp Number = 1 Menu = 2

Tel egram 2

The second telegram from the Interbus master controller also indicates a READ cycle but the stamp number is now 2.

The data byte contains the parameter number of the parameter that is to be read.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0010 0000 0001

Data word = 0x9201 Stamp Number = 2 Parameter = 1

When the second telegram has been received and processed in the slave node, it is mirrored in the non-cyclic IN word back to the Interbus master controller. This is the signal to the master controller program that the second telegram of the message has been received and understood, the third telegram can now be transmitted.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0010 0000 0001

Data word = 0x9201 Stamp Number = 2 Parameter = 1

Tel egram 3

The third telegram from the Interbus master controller acts as the indication to the slave device to transmit the high data byte from the requested parameter. The data byte is not used in this telegram and should be set to 0, the stamp number is now 3.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0011 0000 0000

Data word = 0x9300 Stamp Number = 3

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 37 Issue Number: 1

When the third telegram has been received and processed in the slave node, the slave will mirror the stamp number in the non-cyclic IN word and load the high byte of the parameter value into the data byte to be transmitted back to the Interbus master controller. This is the signal to the master controller program that the third telegram of the message has been received and understood, the fourth telegram can now be transmitted.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0011 0000 0000

Data word = 0x9300 Stamp Number = 3 Data byte = 0x00 = 0

Tel egram 4

The fourth telegram from the Interbus master controller acts as the indication to the slave device to transmit the mid-high data byte (or low data byte for 16-bit parameters) from the requested parameter. The data byte is not used in this telegram and should be set to 0, the stamp number is now 4.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0100 0000 0000

Data word = 0x9400 Stamp Number = 4

When the fourth telegram has been received and processed in the slave node, the slave will mirror the stamp number in the non-cyclic IN word and load the mid-high byte (or low byte for 16-bit parameters) of the parameter value into the data byte to be transmitted back to the Interbus master controller. This is the signal to the master controller program that the fourth telegram of the message has been received and understood. For 32-bit parameters this informs the Interbus master controller the fifth telegram can now be transmitted, but for 16-bit parameters the internal non-cyclic state machine should be reset.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0100 0000 0001

Data word = 0x9401 Stamp Number = 4 Data byte = 0x01 = 1

Tel egram 5

The fifth telegram from the Interbus master controller acts as the indication to the slave device to transmit the mid-low data byte from the requested parameter. The data byte is not used in this telegram and should be set to 0, the stamp number is now 5.

This telegram is not required for 16-bit parameter access.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0101 0000 0000

Data word = 0x9500 Stamp Number = 5

38 SI-INTERBUS User Guide

Issue Number: 1

When the fifth telegram has been received and processed in the slave node, the slave will mirror the stamp number in the non-cyclic IN word and load the mid-low byte of the parameter value into the data byte to be transmitted back to the Interbus master controller. This is the signal to the master controller program that the fifth telegram of the message has been received and understood, the sixth and final telegram can now be transmitted.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0101 0010 0101

Data word = 0x9525 Stamp Number = 5 Data byte = 0x25 = 37

Tel egram 6

The sixth telegram from the Interbus master controller acts as the indication to the slave device to transmit the low data byte from the requested parameter. The data byte is not used in this telegram and should be set to 0, the stamp number is now 6.

This telegram is not required for 16-bit parameter access.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0110 0000 0000

Data word = 0x9600 Stamp Number = 6

When the sixth telegram has been received and processed in the slave node, the slave will mirror the stamp number in the non-cyclic IN word and load the low byte of the parameter value into the data byte to be transmitted back to the Interbus master controller. This is the signal to the master controller program that the sixth telegram of the message has been received and understood, the internal non-cyclic state machine should now be reset.

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 1001 0110 1101 1100

Data word = 0x96DC Stamp Number = 6 Data byte = 0xDC = 220

descriptions

information

features

installation

started

features

data

menus

parameters

status word

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

SI-INTERBUS User Guide 39 Issue Number: 1

descriptions

support files

of terms

Full parameter

CMD tool

Glossary

8.1.5 The parameter re-assembled

The parameter value can be assembled as follows to give the complete value as read from the parameter.

32-bit access

Pr 2.001 = (high byte * 2

= (0 * 16777216) + (1 * 65536) + (37 * 256) + 220 = 75228 = 7522.8 rpm

16-bit access

Pr 2.001 = (high byte * 2

= (37 * 256) + 220 = 9692 = 969.2 rpm

When using 16-bit mode, in this example, as Pr 2.001 is a 32-bit parameter, only the lower two bytes are returned, resulting in an incorrect value being read.

) + (mid-high byte * 216) + (mid-low byte * 28) + low byte

) + low byte

8.1.6 Writing parameters using CT Single Word

To write to parameters using CT Single Word non-cyclic channel, the following “telegrams” must be transmitted to construct the final message.

• Telegram 1 Define menu number.

• Telegram 2 Define parameter number.

• Telegram 3 Send high data byte.

• Telegram 4 Send mid-high data byte (32-bit) or low data byte (16-bit).

• Telegram 5 Send mid-low data byte (32-bit).

• Telegram 6 Send low data byte (32-bit).

Figure 8-2 CT Single Word write sequence shows the normal sequence for writing a parameter value using CT Single Word non-cyclic.

40 SI-INTERBUS User Guide

Issue Number: 1

Figure 8-2 CT Single Word write sequence

information

features

installation

started

features

data

menus

parameters

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

The following telegrams show how to set the preset speed reference 1 (Pr 1.021) to

12553.9 rpm.

Telegram 1

The first telegram from the Interbus master controller indicates a WRITE cycle by setting bit b15 to 0 and stamp number 1.

The data byte contains the menu number of the parameter that is to be written to.

SI-INTERBUS User Guide 41 Issue Number: 1

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0001 0000 0001

Data word = 0x1101 Stamp Number = 1 Menu = 1

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0001 0000 0001

Data word = 0x1101 Stamp Number = 1 Menu = 1

Tel egram 2

The second telegram from the Interbus master controller also indicates a WRITE cycle but the stamp number is now 2.

The data byte contains the parameter number of the parameter that is to be written to.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0010 0001 0101

Data word = 0x1215 Stamp Number = 2 Parameter = 21

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0010 0001 0101

Data word = 0x1215 Stamp Number = 2 Parameter = 21

42 SI-INTERBUS User Guide

Issue Number: 1

Tel egram 3

The third telegram from the Interbus master controller has the stamp number set to 3. The data bits contain the high data byte for the parameter being written to.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0011 0000 0000

Data word = 0x1300 Stamp Number = 3 Data byte = 0x00 = 0

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0011 0000 0000

Data word = 0x1300 Stamp Number = 3 Data byte = 0x00 = 0

Tel egram 4

The fourth telegram from the Interbus master controller has the stamp number set to 4 and contains the mid-high data byte (or low data byte for 16-bit parameters) for the parameter being written to.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0100 0000 0001

Data word = 0x1401 Stamp Number = 4 Data byte = 0x01 = 1

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0100 0000 0001

Data word = 0x1401 Stamp Number = 4 Data byte = 0x01 = 1

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 43 Issue Number: 1

Tel egram 5

The fifth telegram from the Interbus master controller has the stamp number set to 5 and contains the mid-low data byte for the parameter being written to.

This telegram is not required for 16-bit parameter access.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0101 1110 1010

Data word = 0x15EA Stamp Number = 5 Data byte = 0xEA = 234

Response

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0101 1110 1010

Data word = 0x15EA Stamp Number = 5 Data mid-low byte = 0xEA = 234

Tel egram 6

The sixth telegram from the Interbus master controller has the stamp number set to 6 and contains the low data byte for the parameter being written to.

This telegram is not required for 16-bit parameter access.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0110 0110 0011

Data word = 0x1663 Stamp Number = 6 Data byte = 0x63 = 99

Response (success)

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0001 0110 0110 0011

Data word = 0x1663 Stamp Number = 6 Data byte = 0x63 = 99

44 SI-INTERBUS User Guide

Issue Number: 1

If all telegrams have been successful, the SI-Interbus will write the value 12553.9 to Pr 1.021.

The value written to the parameter will be scaled according to the number of decimal places in the target parameter.

If there was a problem with writing the data to the parameter, e.g. the parameter does not exist or the data is outside the range of the parameter, the ERR bit (b14) will be set to 1.

Response (error)

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0101 0110 0110 0011

Data word = 0x5663 Stamp Number = 6 Data byte = 0x63 = 99

8.1.7 Abort CT Single Word non-cyclic message

The internal state machine that controls the non-cyclic data transfer will only accept a new telegram if it contains the next expected telegram stamp number (i.e. after accepting telegram 2, the state machine will only respond to telegram 3. If any other telegram stamp number is received, it will be ignored).

If an error occurs in the Interbus master controller that causes the telegrams to get out of step, the master controller program should timeout, abort the message and reset the non-cyclic state machine. This is done by setting the non-cyclic word to 0.

Request

Bit b15 to b12 b11 to b8 b7 to b4 b3 to b0

Value 0000 0000 0000 0000

Data word = 0x0000 Stamp Number = 0 Data byte = 0x00 = 0

8.1.8 Writing 16-bit parameters

Normally six telegrams would be required to access drive parameters using CT Single Word non-cyclic data. When accessing 16-bit data only four telegrams are required. If an attempt is made to read a 32-bit parameter from the drive, the parameter value will be returned provided that the parameter value does not exceed signed 16-bit limits. If the value is larger than a signed 16-bit value, the ERR bit will be set.

When writing data to a 32-bit parameter, the 16-bit data will be treated as a signed 16-bit data value. This limits the range that can be written to a 32-bit parameter.

descriptions

information

features

installation

started

features

data

menus

parameters

status word

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

SI-INTERBUS User Guide 45 Issue Number: 1

descriptions

support files

of terms

Full parameter

CMD tool

Glossary

8.2 Mode 2 - PPO 4 Word mode

PPO 4 word mode of non-cyclic data is a simple method of accessing non-cyclic data without the need for the telegrams required with Mode 1 non-cyclic data and its associated overheads. Mode 2 has the disadvantage of using four words of mappings and reduces the available free mappings accordingly.

8.2.1 Mapping for PPO 4 Word non-cyclic data

To configure an SI-Interbus in slot 3 for PPO 4 Word mode non-cyclic data, the following steps must be performed:

• Set Pr 17.005 to the required mode

• Set Pr 17.032 to On to reset and reconfigure the SI-Interbus

When the SI-Interbus re-initialises, it will map cyclic data IN words 0 to 3 and OUT words 0 to 3 to the PPO 4 Word protocol parameter, Pr 61.51. All existing mapping parameters will be moved down by one mapping, (i.e. the previous mappings set in Pr 17.010 and Pr 17.020 will now appear in Pr 17.011 and Pr 17.021 respectively).

Table 8-6 Six cyclic words with PPO 4 Word non-cyclic data mapping shows what happens to the mapping parameters when the data format is changed from 6 cyclic words (Pr 17.005=6) to 6 cyclic words with Mode 2 non-cyclic data. (Pr 17.005=206).

Table 8-6 Six cyclic words with PPO 4 Word non-cyclic data mapping

Mapping

Parameter

Pr 17.010 1040 Pr 10.40, Status Word 6151

Pr 17.011 201

Pr 17.012 0 User Defined 201

Pr 17.013

Pr 17.019

Pr 17.020 642 Pr 6.42, Control Word 6151

Pr 17.021 121 Pr 1.21, Preset Reference 1 642 Pr 6.42, Control Word

Pr 17.022 0 User Defined 121 Pr 1.21, Preset Reference 1

Pr 17.023

Pr 17.029

Before format change

(Pr 17.005 = 6)

Value Mapping Value Mapping

Pr 2.01, Post Ramp Reference

0 Not available 0 Not available

After format change

(Pr 17.005 = 6)

Pr 61.51, PPO 4 Word noncyclic mode 2

1040 Pr 10.40, Status Word

Pr 2.01, Post Ramp

Reference

Pr 61.51, PPO 4 Word noncyclic mode 2

There are two problems with this setup, the first is that a configuration error will be raised because PPO 4 Word non-cyclic uses 4 words, so with the 6 words of cyclic data mapped, the number of mappings exceed the number specified (6). The second problem is that the user defined mappings (Pr 17.012 and Pr 17.022) are lost when the SI-Interbus is re-initialised. This is because there is insufficient mappings available to move the user defined channel into.

To maintain all mappings when adding the PPO 4 Word non-cyclic data channel, the cyclic data format (Pr 17.005) needs to be set to 210, this adds additional cyclic channels to accommodate the user defined channel as shown in Table 8-7 Ten cyclic words with PPO 4 Word non-cyclic data mapping.

46 SI-INTERBUS User Guide

Issue Number: 1

Table 8-7 Ten cyclic words with PPO 4 Word non-cyclic data mapping

Mapping

Parameter

Pr 17.010 1040 Pr 10.40, Status Word 6151

Pr 17.011 201

Pr 17.012 0 User Defined 201

Pr 17.013

Pr 17.014

Pr 17.019

Pr 17.020 642 Pr 6.42, Control Word 6151

Pr 17.021 121 Pr 1.21, Preset Reference 1 642 Pr 6.42, Control Word

Pr 17.022 0 User Defined 121 Pr 1.21, Preset Reference 1

Pr 17.023

Pr 17.024

Pr 17.029

Before format change

Value Mapping Value Mapping

0 Not available 0 User Defined

0 Not available 0 Not available

0 Not available 0 User Defined

0 Not available 0 Not available

8.2.2 PPO 4 Word protocol

The PPO 4 Word protocol uses the first four words (IN and OUT) of the non-cyclic channel.

Hence, the number of decimal places of the target parameter must be known.

Writing a value of 1234 to a parameter with 2 decimal places will produce a value of

12.34 in the target parameter. Similarly, reading a value of 12.34 will return a 32-bit integer value of 1234.

The PPO 4 Word protocol format is shown in Table 8-8 PPO 4 Word OUT data structure.

Table 8-8 PPO 4 Word OUT data structure

Out Data Word

OUT Word 0 TASK ID 0 MENU

OUT Word 1 PARAMETER

OUT Word 2 DATA HIGH word

OUT Word 3 DATA LOW word

The PPO 4 Word protocol is controlled by the TASK ID and RESPONSE ID; the TASK ID specifies the transaction required and the remainder of the data words carry the data for the transaction.

The possible TASK ID codes are shown in Table 8-9 TASK ID codes.

b15 to b12 b11 b10 to b8 b7 to b0

(Pr 17.005 = 6)

Pr 2.01, Post Ramp Reference

After format change

(Pr 17.005 = 210)

Pr 61.51, PPO 4 Word noncyclic mode 2

1040 Pr 10.40, Status Word

Pr 2.01, Post Ramp

Reference

Pr 61.51, PPO 4 Word noncyclic mode 2

Function

Reserved

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 47 Issue Number: 1

Table 8-9 TASK ID codes

TASK

0 No task No non-cyclic transaction required.

1 Fieldbus specific

2 Fieldbus specific

3 Fieldbus specific

4 Not implemented Reserved

5 Not implemented Reserved

6 Request parameter value

Function Description

Read parameter value from drive. Specify MENU and PARAMETER. Set DATA HIGH word and DATA LOW word to 0.

Write 16-bit parameter value to the drive.

Change parameter value

(16-bit)

Change parameter value

(32-bit)

Request last parameter

reference

Specify MENU, PARAMETER and DATA LOW word. (Any value in DATA HIGH word will be discarded). This function can be used to write to 32-bit drive parameters, but the range of values is limited to 16 bits.

Write 32-bit parameter value to the drive. Specify MENU, PARAMETER, DATA HIGH word and DATA LOW word. This function can also be used to write to 16-bit drive parameters, but if DATA HIGH word is not set to 0, a value over-range error will be reported.

Returns the last parameter number for the specified menu. Specify MENU. (Values in PARAMETER, DATA HIGH word and DATA LOW word will be discarded.)

The data structure for the response from the drive is similar to the request, the only difference is the TASK ID is replaced by the RESPONSE ID as shown in Table 8-10 PPO 4 Word IN data structure.

Table 8-10 PPO 4 Word IN data structure

OUT Data Word

IN Word 0 RESPONSE ID 0 MENU

IN Word 1 PARAMETER

IN Word 2 DATA HIGH word

IN Word 3 DATA LOW word

b15 to b12 b11 b10 to b8 b7 to b0

Function

Reserved

The RESPONSE ID indicates the success or otherwise of the requested transaction.

The possible RESPONSE ID values are shown in Table 8-11 RESPONSE ID codes.

48 SI-INTERBUS User Guide

Issue Number: 1

Table 8-11 RESPONSE ID codes

RESPONSE

0 No task No non-cyclic transaction active.

1 Fieldbus specific

2 Fieldbus specific

3 Not implemented Reserved

Function Description

Transfer parameter

value (16-bit)

Transfer parameter

value (32-bit)

Transfer last parameter

reference

Returns a 16-bit data value from the request parameter value specified by TASK ID 6, or the successful change parameter value (16-bit) specified by TASK ID 7.

Returns a 32-bit data value from the request parameter value specified by TASK ID 6, or the successful change parameter value (32-bit) specified by TASK ID 8.

Returns the highest parameter for the menu specified by request last parameter reference, TASK ID 9.

The previously specified TASK ID could not be completed.

Error – TASK ID could

not be executed

Error – read-only

parameter

Word 3 will return an error code to indicate the reason for the TASK ID failure (see Table 8-12 PPO 4 Word error codes).

Target parameter specified by TASK ID 7 or TASK ID 8 is Read-only, and cannot be modified.

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

Additional

features

If RESPONSE ID 7 has been received, the error code can be read from word 3. This will indicate the reason why the TASK ID request failed (see Table 8-12 PPO 4 Word error codes).

Table 8-12 PPO 4 Word error codes

ERROR CODE Error Description

0 Invalid menu The specified menu does not exist.

1 Parameter is read-only

2 Value is out of range

3 Invalid parameter or menu The specified parameter does not exist.

18 Parameter error No last parameter information available.

The specified parameter is read-only, and cannot be written to.

The specified data value is out of range for the parameter.

descriptions

data

menus

parameters

status word

descriptions

support files

of terms

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 49 Issue Number: 1

8.2.3 Reading parameters using PPO 4 Word mode

Figure 8-3 PPO 4 Word read sequence shows the sequence of events required to

read a drive parameter using the PPO 4 Word non-cyclic channel.

Figure 8-3 PPO 4 Word read sequence

Table 8-13 PPO 4 Word Read TASK ID and RESPONSE ID combinations shows the

possible TASK ID and RESPONSE ID combinations that may be seen when attempting to read a parameter value from a drive.

50 SI-INTERBUS User Guide

Issue Number: 1

Table 8-13 PPO 4 Word Read TASK ID and RESPONSE ID combinations

NOTE

Function TASK ID RESPONSE ID Message Status

No task 0 0 No non-cyclic transaction active.

Request parameter

value (16-bit)

Request parameter

value (32-bit)

Request parameter

value (16-bit)

Request Last

Parameter Reference

Request Last

Parameter Reference

Parameter read successfully, 16-bit value returned in word 3.

Parameter read successfully, 32-bit value returned in words 2 and 3.

TASK ID 6 could not be executed. Check the error code in IN word 3 for the reason why.

The highest parameter reference in specified menu is available in IN word 3.

TASK ID 9 could not be executed. Check the error code in IN word 3 for the reason why.

Table 8-14 PPO 4 Word read request example shows an example set of data words for PPO 4 Word mode. This example will read the value of the post ramp speed reference (Pr 2.001) in the drive.

Table 8-14 PPO 4 Word read request example

OUT Data

Word

Hex

Value

b15 to b12 b11 b10 to b8 b7 to b0

OUT Word 0 0x6002 TASK ID = 6 0 MENU = 2

OUT Word 1 0x0100 PARAMETER = 1

OUT Word 2 0x0000 DATA HIGH word = 0

OUT Word 3 0x0000 DATA LOW word = 0

Function

Table 8-15 PPO 4 Word read response example shows an example of a successful read response to the read instruction illustrated above. The value returned is 15284, which equates to 1528.4 rpm.

Table 8-15 PPO 4 Word read response example

OUT Data

Word

Hex

Value

b15 to b12 b11 b10 to b8 b7 to b0

IN Word 0 0x5002 RESPONSE ID = 5 0 MENU = 2

IN Word 1 0x0100 PARAMETER = 1

IN Word 2 0x0000 DATA HIGH word = 0

IN Word 3 0x3BB4 DATA LOW word = 15284

Function

It is important that the correct module is selected from the XML file to ensure that the PPO 4 Word mode block is consistent otherwise data skew may occur. If the OUT data words 0 and 1 are left at the same value, the target parameter will be read or written to (depending on the TASK ID) on every data cycle. If the PPO 4 command is left in the data words, the read will be executed on every poll of the network, effectively providing a continuous read. Care should be taken to ensure the parameters for the read are setup before the TASK ID is changed from 0 to prevent incorrect data in the returned value.

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 51 Issue Number: 1

8.2.4 Writing parameters using PPO 4 Word mode

Figure 8-4 PPO 4 Word write sequence of events required to write to a drive

parameter using the PPO 4 Word non-cyclic channel.

Figure 8-4 PPO 4 Word write sequence

Table 8-16 PPO 4 Word Write TASK ID and RESPONSE ID combinations shows the

possible TASK ID and RESPONSE ID combinations that may be seen when attempting to write to the drive.

52 SI-INTERBUS User Guide

Issue Number: 1

Table 8-16 PPO 4 Word Write TASK ID and RESPONSE ID combinations

NOTE

Function TASK ID RESPONSE ID Message Status

No task 0 0 No non-cyclic transaction active.

Transfer parameter

value (16-bit)

Transfer parameter

value (32-bit)

Transfer parameter

value (16-bit)

Transfer parameter

value (32-bit)

Transfer parameter

value (32-bit)

Parameter value (16-bit) written successfully.

Parameter value (32-bit) written successfully.

TASK ID 7 could not be executed. Check the error code in IN word 3 for the reason why.

TASK ID 8 could not be executed. Check the error code in IN word 3 for the reason why.

Parameter is read-only and cannot be written to.

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Table 8-17 PPO 4 Word write request example shows an example set of data words for PPO 4 Word mode. This example will write a value of 1553.9 rpm (32-bit value is

15539) to the digital speed reference 1 (Pr 1.021) to the drive.

Table 8-17 PPO 4 Word write request example

OUT Data

Word

Hex

Value

b15 to b12 b11 b10 to b8 b7 to b0

OUT Word 0 0x8001 TASK ID = 8 0 MENU = 1

OUT Word 1 0x1500 PARAMETER = 21

OUT Word 2 0x0000 DATA HIGH word = 0

OUT Word 3 0x3CB3 DATA LOW word = 15539

Function

Table 8-18 PPO 4 Word write response example shows an example of a successful write response to the write instruction illustrated above in Table 8-17.

Table 8-18 PPO 4 Word write response example

OUT Data

Word

Hex

Value

b15 to b12 b11 b10 to b8 b7 to b0

IN Word 0 0x5001 RESPONSE ID = 5 0 MENU = 1

IN Word 1 0x1500 PARAMETER = 21

IN Word 2 0x0000 DATA HIGH word = 0

IN Word 3 0x3CB3 DATA LOW word = 15539

Function

If the PPO 4 Word command is left in the data words, the write will be executed on every poll of the network, effectively providing a continuous write. Care should be taken to ensure the parameters for the write are setup before the TASK ID is changed from 0 to prevent incorrect data being written.

descriptions

started

features

data

menus

parameters

status word

descriptions

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

SI-INTERBUS User Guide 53 Issue Number: 1

support files

CMD tool

Glossary

of terms

8.3 Mode 3 - Peripheral Communications Protocol V2.0

The PCP non-cyclic mode is an object based protocol for implementing services that are more complex than unconfirmed cyclic data transfer. If selected, the PCP protocol supported by the SI-Interbus module uses the first word of the transmitted and received data. Unlike the non-cyclic modes 1 and 2, PCP mode is not represented in the mapping parameters (Pr MM.010 to MM.029) and can only be selected by the mode parameter (Pr MM.005) and not explicitly mapped.

When an Interbus network is initialised, each node supporting PCP is assigned a Communication Reference, or CR. Supported objects are shown in Table 8-19

PCP object specification and the supported services are shown in Table 8-20 PCP supported services.

8.3.1 PCP object specification

Table 8-19 PCP object specification

Attribute Setting Value

Index 0x5000 0x5000 + Menu

Sub-index Parameter (>0) Parameter (>0)

Object Code ARRAY_OBJECT Array object

Data Type Index INT32 Signed 32 bit value

Length 4 Four Octets

Number of Elements 200 Up to parameter 200

Password 0 None

Access Groups 0 None

Access Rights

Local Address 0 Not used

Variable Name Menu Menu

Extension Not supported Not supported

ACC_WRITE_ALL

and

ACC_READ_ALL

Read and Write

8.3.2 PCP supported services

Peripheral Communication Protocol (PCP) version 2.0 will be used. Only server functionality is provided.

The supported services are shown in Table 8-20 PCP supported services.

54 SI-INTERBUS User Guide

Issue Number: 1

Table 8-20 PCP supported services

Function Category Description

INITIATE

ABORT

READ

WRITE

Context

Management

Variable Access

Opens a PCP connection with the node at the defined Communication Reference.

Closes the PCP connection with the node at the defined Communication Reference.

Reads a number of data bytes from an Index and Subindex reference in the remote device with the defined Communication Reference.

Writes a specified number of data bytes to an Index and Sub-index reference in the remote device with the defined Communication Reference.

Returns the current state and current operating state of

STATUS

VFD Support

IDENTIFY

the remote device at the defined Communication Reference.

Returns the "ID plates" of the device at the defined Communication Reference.

The following is returned: Manufacturer_Name: “Control Techn." Device_Name: "SM-INTERBUS" Revision: "Version 01.00" (To maintain compatibility the information returned is the same as the SM-Interbus)

GET OV LONG OV Management Returns one or more object descriptions.

8.3.3 Accessing drive parameters using the PCP objects

The supported objects permit the user to read or write to any parameter that supports that action, i.e. the user could not write to a read only parameter. Each object will represent a drive menu numbered from 0 to 200. The user will provide a sub-index within either the READ or WRITE service to access a specific parameter.

The objects will represent the Menus as follows: Object = Menu + 0x5000

The sub-index will equate to the required parameter number within the specified menu.

The only exception to this is parameter zero, (Pr MM.000) this can be accessed using the virtual parameter Pr 61.001. A sub-index value of zero will return an error (see Table 8-23 Control Techniques defined service error codes).

8.3.3.1 READ object

Index: 0x5000 + Menu Sub-index: Parameter

The READ object is used to read a value from a parameter within the drive. No additional data bytes are required. If the read is successful, a success response will be returned, with four data bytes containing the value of the target parameter.

Table 8-21 PCP READ response data bytes

Data Byte Data Byte Order

1 High byte

2 Mid-high byte

3 Mid-low byte

4 Low byte

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 55 Issue Number: 1

If an error occurs, an error message is returned, with codes to indicate the reason for

NOTE

failure (see Table 8-23 Control Techniques defined service error codes).

Parameter 0 (Pr MM.000) cannot be accessed directly as the sub-index cannot be set to a value of 0. Access to parameter 0 is provided via virtual parameter Pr 61.01.

Example

This example reads the value from the Post Ramp Reference (Pr 2.001) using the READ service with the following arguments:

Index = 0x5002 Sub-index = 1

If the read is successful, the response message would contain the data value.

If the service is unsuccessful, the error information will be returned (see section 8-23 Control Techniques defined service error codes).

8.3.3.2 WRITE object

Index: 0x5000 + Menu Sub-index: Parameter

The WRITE object is used to send a data value to a parameter within the drive. Four data bytes are written to this object. If the write is successful, a success response will be returned.

Table 8-22 PCP WRITE object data bytes

Data Byte Data Byte Order

1 High byte

2 Mid-high byte

3 Mid-low byte

4 Low byte

If an error occurs, an error message is returned, with codes to indicate the reason for failure (see Table 8-23 Control Techniques defined service error codes).

Parameter 0 (Pr MM.000) cannot be accessed directly as the sub-index cannot be set to a value of 0. Access to parameter 0 is provided via virtual parameter Pr 61.01.

Example

This example writes the value 200 (rpm) to the Preset Reference 1 (Pr 1.021) using the WRITE service with the following arguments:

Index = 0x5001 Sub-index = 21 Data = 200

If the write is successful, the success response will be returned.

If the service is unsuccessful, the error information will be returned. See Table 8-23 Control Techniques defined service error codes.

Any scaling required of the data (i.e. to account for any decimal places the parameter may have) will be handled by the SI-Interbus module.

56 SI-INTERBUS User Guide

Issue Number: 1

8.3.3.3 Service error codes

If an error occurs while accessing a parameter, a Control Techniques defined error code will be returned. These error codes are listed in Table 8-23 Control Techniques defined service error codes.

Table 8-23 Control Techniques defined service error codes

Error Error Class

Parameter Does Not Exist

Parameter Is Read Only

Parameter Is Write Only

Value Outside Permitted

Range

Decimal Place Error

Sub-index Zero Access Error

0x08

(Non-standard error)

0x08

(Non-standard error)

0x08

(Non-standard error)

0x08

(Non-standard error)

0x08

(Non-standard error)

0x06

(Access error)

Error Code

0x01

0x02

0x03

0x04

0x05

Additional Error Code

(No additional information)

(Attempt to access sub-index

0x00

0x11

zero)

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

Additional

features

8.3.4 SI-Interbus setup using non-cyclic data

The SI-Interbus can be configured using the PCP channel, CT Single Word or PPO 4 Word non-cyclic data. The configuration parameters for the slot in which the SI-Interbus is located can be accessed using the virtual menu 60 (see section 9.1 Pr 60.01 to Pr 60.56 (Setup menu shortcut)).

Changes made to the SI-Interbus configuration parameters will not take effect until the SI-Interbus has been reset (see section 7.3 Module reset).

A brief interruption in Interbus communications may be seen while the reset sequence is in progress.

descriptions

data

menus

parameters

status word

descriptions

support files

of terms

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 57 Issue Number: 1

9 Virtual menus

The SI-Interbus module has two internal virtual menus that the user can access over the fieldbus network, the virtual menu parameters are shown in Table 9-1 Virtual menu parameters.

Table 9-1 Virtual menu parameters

Parameter Description

Pr 60.01

Pr 60.56

Pr 61.01 Parameter 0 access, mapped directly to Pr 1.000

Pr 61.40 SI-Applications (or MCi2x0) Event trigger (lowest slot)

Pr 61.41 SI-Applications (or MCi2x0) Event trigger (slot 1)

Pr 61.42 SI-Applications (or MCi2x0) Event trigger (slot 2)

Pr 61.43 SI-Applications (or MCi2x0) Event trigger (slot 3)

Pr 61.50 CT Single word (Mode 1) non-cyclic data mapping parameter

Pr 61.51 PPO 4 word (Mode 2) non-cyclic data mapping parameter

9.1 Pr 60.01 to Pr 60.56 (Setup menu shortcut)

Menu 60 acts as a shortcut to the SI-Interbus module setup menu (menus 15, 16 or 17) for the slot in which the Interbus module is located. The SI-Interbus will redirect any menu 60 parameter access sent over the fieldbus to the menu 15, 16 or 17 as appropriate. This permits the user to configure the SI-Interbus via the fieldbus without knowing in which slot it is located.

9.2 Pr 61.01 (Parameter 0 access)

Pr 61.01 acts as a shortcut to parameter 0 and is directly mapped to Pr 1.000.

Slot 1 SI-Interbus setup menu Pr 15.001 to 15.056

Slot 2 SI-Interbus setup menu Pr 16.001 to 16.056

Slot 3 SI-Interbus setup menu Pr 17.001 to 17.056

9.3 Pr 61.40 (Event trigger - lowest slot)

Pr 61.40 is used to trigger an event task in the SI-Applications (or MCi2x0) module fitted in the lowest slot position. The possible values are shown in Table 9-2 Event trigger values.

9.4 Pr 61.41 (Event trigger – slot 1)

Pr 61.41 is used to trigger an event task in the SI-Applications (or MCi2x0) module fitted in slot 1. The possible values are shown in Table 9-2 Event trigger values.

9.5 Pr 61.42 (Event trigger – slot 2)

Pr 61.42 is used to trigger an event task in the SI-Applications (or MCi2x0) module fitted in slot 2. The possible values are shown in Table 9-2 Event trigger values.

58 SI-INTERBUS User Guide

Issue Number: 1

9.6 Pr 61.43 (Event trigger – slot 3)

Pr 61.43 is used to trigger an event task in the SI-Applications (or MCi2x0) module fitted in slot 3. The possible values are shown in Table 9-2 Event trigger values.

Table 9-2 Event trigger values

Trigger Parameter Value Action

0 No action

1 Event

2Event1

3Event2

4Event3

9.7 Pr 61.50 (CT Single Word - mode 1 non-cyclic)

Pr 61.50 is used as the CT Single Word (mode 1) non-cyclic parameter (see section 8.1 Mode 1 - CT Single Word mode).

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

9.8 Pr 61.51 (PPO 4 Word – mode 2 non-cyclic)

Pr 61.51 is used as the PPO 4 Word (mode 2) non-cyclic parameter (see section 8.2

Mode 2 - PPO 4 Word mode).

Additional

features

Non-Cyclic

data

menus

Virtual

SI-Applications

parameters

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

SI-INTERBUS User Guide 59 Issue Number: 1

Glossary

of terms

10 SI-Applications parameters

The SI-Interbus will redirect any menu accesses, for menus 70 to 91, to the SI-Applications (or MCi2x0) module in the lowest numbered slot. This is convenient to use if there is only the one SI-Applications (or MCi2x0) module fitted to the drive, as it guarantees that data will always be written to or read from the module even if it was moved to a different slot position.

If more than one SI-Applications (or MCi2x0) option module is fitted then, to ensure the correct module is accessed, it will be necessary to access the module in a specific slot directly, this is achieved by using the slot specific menus 100 to 121, 130 to 151 and 160 to 181 for menus 70 to 91 in slots 1 to 3 respectively.

Note that only the PLC registers (menus 70 to 79) are available in the MCi2x0 module.

Table 10-1 Applications parameters

SI-Applications Parameters

_Pxx% PLC registers Yes Yes Pr 70.xx Pr 100.xx Pr 130.xx Pr 160.xx

_Qxx% PLC Registers Yes Yes Pr 71.xx Pr 101.xx Pr 131.xx Pr 161.xx

_Rxx% PLC Registers Yes Yes Pr 72.xx Pr 102.xx Pr 132.xx Pr 162.xx

_Sxx% PLC Registers Yes Yes Pr 73.xx Pr 103.xx Pr 133.xx Pr 163.xx

_Txx% PLC Registers Yes Yes Pr 74.xx Pr 104.xx Pr 134.xx Pr 164.xx

_Uxx% PLC Registers Yes Yes Pr 75.xx Pr 105.xx Pr 135.xx Pr 165.xx

_Vxx% PLC Registers Yes Yes Pr 76.xx Pr 106.xx Pr 136.xx Pr 166.xx

_Wxx% PLC Registers Yes Yes Pr 77.xx Pr 107.xx Pr 137.xx Pr 167.xx

_Xxx% PLC Registers Yes Yes Pr 78.xx Pr 108.xx Pr 138.xx Pr 168.xx

_Yxx% PLC Registers Yes Yes Pr 79.xx Pr 109.xx Pr 139.xx Pr 169.xx

Local Configuration Parameters Yes No Pr 81.xx Pr 111.xx Pr 141.xx Pr 171.xx

Timer Configuration Parameters Yes No Pr

Digital IO Parameters Yes No Pr 86.xx Pr 11 6.xx Pr 146.xx Pr 176.xx

Status Parameters Yes No Pr 88.xx Pr 118 .x x Pr 148.xx Pr 178.xx

General Parameters Yes No Pr 90.xx Pr 120.xx Pr 150.xx Pr 180.xx

Fast Access Parameters Yes No Pr 91.xx Pr 121.xx Pr 151.xx Pr 181.xx

SI-Apps

Compact

MCi2x0

Parameter Reference

85.xx Pr 115.x x Pr 145.xx Pr 175.xx

Direct to

slot 1

Direct to

slot 2

Direct to

slot 3

10.1 Single SI-Applications fitted

Consider a drive with the following configuration:

• Slot 1 - Vacant

• Slot 2 - SI-Interbus

• Slot 3 - SI-Applications

If a parameter read request comes over Interbus to read Pr 71.08, this will be redirected to the SI-Applications in the lowest slot number, i.e. the SI-Applications in slot 3. The value in _Q08% from slot 3 will be returned.

If a parameter read request comes over Interbus to read Pr 161.08, this will be sent straight to the SI-Applications in slot 3. The value in _Q08% from slot 3 will be returned.

If a parameter read request comes over Interbus to read Pr 101.08, this will be sent straight to slot 1. As there is no module fitted in slot 1, an error message will be returned, indicating that the parameter does not exist.

60 SI-INTERBUS User Guide

Issue Number: 1

10.2 Dual SI-Applications fitted

NOTE

This scenario involves two SI-Applications or MCi2x0 modules (or one of each).

Consider a drive with the following configuration:

• Slot 1 – MCi2x0

• Slot 2 - SI-Interbus

• Slot 3 - SI-Applications

If a parameter read request comes over Interbus to read Pr 71.08, this will be redirected to the module in the lowest slot number, i.e. the MCi2x0 in slot 1. The value in _Q08% from slot 1 will be returned.

If a parameter read request comes over Interbus to read Pr 101.08, this will be sent straight to the MCi2x0 in slot 1. The value in _Q08% from slot 1 will be returned.

If a parameter read request comes over Interbus to read Pr 161.08, this will be sent straight to the SI-Applications in slot 3. The value in _Q08% from slot 3 will be returned.

If a parameter read request comes over Interbus to read Pr 131.08, this will be sent straight to slot 2. As there is no appropriate module fitted in slot 2 (i.e. SI-Applications or MCi2x0), an error message will be returned, indicating that the parameter does not exist.

information

Safety

Introduction

Supported

features

Mechanical

installation

Electrical

Getting

started

Additional

features

When two SI-Applications or MCi2x0 modules (or one of each) is fitted, it is advisable to use the direct slot access parameters to ensure the correct, and intended, module is accessed.

descriptions

data

menus

param eters

status word

descriptions

support files

of terms

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 61 Issue Number: 1

11 Control / status word

The control and status words allow the digital control and monitoring of the drive to be implemented using a single data word for each function. Each bit in the control word has a particular function and provides a method of controlling the output functions of the drive, such as run and direction.

Each bit in the status word provides feedback about the drive’s state of health and operational condition, such as drive ok, drive at speed, etc.

The default cyclic data mappings of the SI-Interbus module use the drive control word (Pr 06.042) and preset reference 1 (Pr 01.021) for the OUT data, and the drive status word (Pr 10.040) and post ramp reference (Pr 02.001) for the IN data.

If the drive control word is to be used for controlling the drive over the Interbus network, then the control word must be enabled (Pr 06.043 = On).

11.1 Control word

The control word consists of sixteen control bits, some of which are reserved.

Table 11-1 Control word bit functions shows the functions of each bit in the control word, and Table 11-2 Control word bit definitions shows the functions of each control bit in more detail. For further details about the drive control word and sequencing bits please refer to the appropriate drive documentation.

Table 11-1 Control word bit functions

b15 b14 b13 b12 b11 b10 b9 b8

Reserved

KEYPAD

WDOG

RESET TRIP Reserved Reserved JOG REV REMOTE

b7 b6 b5 b4 b3 b2 b1 b0

AUTO

NOT

STOP

RUN FWD/REV RUN REV

JOG

RWD

RUN FWD

ENABLE

To enable fieldbus control, the Control Word Enable (Pr 06.043) must be set to ‘On’, the source of the control signals (RUN, FWD/REV. JOG, etc.) is selected using the AUTO bit (b7). When the AUTO bit (b7) is set to ‘1’, the control word is used as the source for the drive control. When the AUTO bit (b7) is set to 0, the drive will revert to terminal control.

For safety reasons, the external SAFE TORQUE OFF signal must be present before the fieldbus control word can be used to start the drive. This signal is normally provided by an external “Emergency Stop” circuit to ensure that the drive is disabled in an emergency situation.

The control word REMOTE bit (b8) directly controls the drive parameter Pr 01.042, the function of which is to select the digital speed reference as the source of the drive’s speed reference. When the REMOTE bit (b8) is set to 1 the fieldbus speed reference will be used. When the REMOTE bit (b8) is set to 0 the drive will revert to using the external analog speed reference.

62 SI-INTERBUS User Guide

Issue Number: 1

The default digital speed reference selected when REMOTE is set to 1 will be Pr 01.021, however Pr 01.015 can be used to change which of the digital references is selected. For further details on the drive digital speed reference, please refer to the appropriate drive documentation.

Table 11-2 Control word bit definitions

Bit Function Description

b0 ENABLE

b1 RUN FWD

b2 JOG FWD

b3 RUN REV

b4 FWD/REV

b5 RUN

b6 NOT STOP

b7 AUTO

b8 REMOTE

b9 JOG REV

b10 Reserved

b11 Reserved

b12 TRIP

b13 RESET

Set to 1 to enable the drive. Resetting to 0 will immediately disable the drive, and the motor will coast to a stop. The external SAFE TORQUE OFF signal must also be present before the drive can be enabled.

Set to 1 (with ENABLE set to 1) to run the motor in the forward direction. When reset to 0, the drive will decelerate the motor to a controlled stop.

Set to 1 to jog the motor forward. This signal needs to be used in conjunction with the ENABLE bit. This signal is overridden by a RUN, RUN REV or RUN FWD signal

Set to 1 (with ENABLE set to 1) to run the motor in the reverse direction. When reset to 0, the drive will decelerate the motor to a controlled stop

Set to 1 to select the reverse direction. Set to 0 to run in the forward direction. The RUN signal is used to start and stop the motor.

Set to 1 to run the motor. FWD/REV is used to select the direction of motor rotation. When reset to 0, the drive will decelerate the motor to a controlled stop.

Set to 1 to allow the sequencing bit to be latched. If NOT STOP is zero, all latches are cleared and held at 0.

Set to 1 to enable fieldbus control of the drive Control Word. The Control Word Enable (Pr 06.043) must also be set to 1. When set to 0, the drive will operate under terminal control.

Set to 1 to select digital speed reference 1 (Pr 01.021), and set to 0 to select analog reference 1 (Pr 01.036). REMOTE directly controls Pr 01.042, so reference selector (Pr 01.014) and preset selector (Pr 01.015) must both be set to 0 (default) for the REMOTE bit to work properly.

Set to 1 to jog the motor in reverse. This signal needs to be used in conjunction with the ENABLE bit. This signal is overridden by a RUN, RUN REV or RUN FWD command.

Set to 1 to trip the drive at any time. The trip display on the drive will be ‘Control Word’ and the trip code will be 35. AUTO (b7) has no effect on this function. The trip cannot be cleared until TRIP is reset to 0.

A 0 to 1 transition of the RESET bit will reset the drive from a trip condition. If the reason for the trip is still present, or another fault has been detected, the drive will immediately trip again. When resetting the drive, it is recommended to check the status word to ensure that the reset was successful, before attempting to re-start the drive.

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

SI-INTERBUS User Guide 63 Issue Number: 1

support files

CMD tool

Glossary

of terms

Bit Function Description

b14

b15 Reserved

KEYPAD

WDOG

11.2 Status word

The status word consists of sixteen status bits and provides status information about the running conditions of the drive.

Table 11-3 Status word bit definitions shows the function of each status word bit. For further details about the drive status word please refer to the appropriate drive documentation.

Table 11-3 Status word bit definitions

b15 b14 b13 b12 b11 b10 b9 b8

Pr 10.015 Pr 10.014 Pr 10.013 Pr 10.012 Pr 10.011 Pr 10.010 Pr 10.009

b7 b6 b5 b4 b3 b2 b1 b0

Pr 10.008 Pr 10.007 Pr 10.006 Pr 10.005 Pr 10.004 Pr 10.003 Pr 10.002 Pr 10.001

Table 11-4 Drive status parameters

Parameter Description

Pr 10.001 Drive OK

Pr 10.002 Drive active

Pr 10.003 Zero speed

Pr 10.004 Running at or below minimum speed

Pr 10.005 Below set speed

Pr 10.006 At speed

Pr 10.007 Above set speed

Pr 10.008 Rated load reached

Pr 10.009 Current limit active

Pr 10.010 Regenerating

Pr 10.011 Braking IGBT active

Pr 10.012 Braking resistor alarm

Pr 10.013 Reverse direction commanded

Pr 10.014 Reverse direction running

Pr 10.015 Supply loss

This watchdog is provided for an external keypad or other devices where a break in the communication link must be detected. The watchdog system can be enabled and/or serviced if this bit is changed from zero to one while the control word is enabled. Once the watchdog is enabled it must be serviced at least once every second or a ‘Watchdog’ trip will occur (trip code 30). The watchdog is disabled when a ‘Watchdog’ trip occurs, and so it must be re-enabled when the trip is reset.

64 SI-INTERBUS User Guide

Issue Number: 1

12 Diagnostics

information

Safety

This section details the SI-Interbus parameters which can be used to assist in diagnosing any issues which may be encountered relating to the SI-Interbus module, Interbus network or SI-Interbus mapping configuration.

12.1 Module ID code

SI-Interbus Module ID

Default 404 (500 kBd) or 414 (2 MBd)

Pr MM.001

Type 1 6- bi t

Access RO

The SI-Interbus module displays the module ID code in Pr MM.001, this module ID code is used to identify the module variant.

12.2 Firmware version

SI-Interbus Firmware Version

Default None

Pr MM.002

Type 3 2- bi t

Access RO

Pr MM.002 displays the SI-Interbus firmware version in the form ww.xx.yy.zz.

12.3 Interbus operating status

The Interbus network activity can be monitored in the operating status parameter, Pr MM.006.

Interbus Operating Status

Default None

Pr MM.006

If Pr MM.006 is a negative value, this indicates a non-operational state as shown in the following table.

Table 12-1 Interbus operating status

Pr MM006 Description

> 0 Network healthy, displays the number of messages processed per second

0 Network health, no cyclic data transfer

-1

-2 The SI-Interbus module reports an internal hardware fault

-3

Type 1 6- bi t

Access RO

SI-Interbus has initialised correctly and waiting for the Interbus master to initialise communication

Configuration error, invalid setting in the SI-Interbus configuration parameters

descriptions

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 65 Issue Number: 1

If Pr MM.006 shows a positive value, this value is dependent upon the Interbus network

NOTE

communication speed, number of mappings and whether non-cyclic communications are active or not.

12.4 SI-Interbus serial number

The SI-Interbus module serial number is a 10-digit decimal number loaded during manufacture and cannot be changed. Two parameters are used to display the serial number, Pr MM.035 displays the last 8 digits and Pr MM.055 displays the first 2 digits.

SI-Interbus Serial Number LS

Default None

Pr MM.035

Type 3 2- bi t

Access RO

This parameter contains the last 8 digits of the serial number.

SI-Interbus Serial Number MS

Default None

Pr MM.055

Type 3 2- bi t

Access RO

This parameter contains the first 2 digits of the serial number.

12.5 Cyclic data mapping status

Cyclic Mapping Status

Default None

Pr MM.049

The SI-Interbus mapping status parameter, Pr MM.049 displays the status of the mapping configuration as shown in Table 12-2 Mapping status codes. If a mapping error has been corrected, reset the SI-Interbus by setting Pr MM.032 to On.

Type 8-bit

Access RO

Table 12-2 Mapping status codes

Code Meaning Description

0 No error detected

Direct data mapping

3 Invalid non-cyclic mode An invalid non-cyclic mode has been selected in Pr MM.005.

5 Invalid mode value The value entered in Pr MM.005 is not supported.

104

110

error

Multiple non-cyclic

mapping error

Configuration read

error

No error detected with IN or OUT cyclic data mapping configuration.

Non-cyclic data cannot be used when direct data mapping is enabled.

A non-cyclic data mode has been mapped more than once in the IN data mapping configuration parameters (Pr MM.010 to Pr MM.019).

An error has occurred reading the IN cyclic data mapping configuration parameters (Pr MM.010 to Pr MM.019) from the drive.

66 SI-INTERBUS User Guide

Issue Number: 1

Code Meaning Description

111

Invalid source

parameter

112 Read mismatch

113

115

120

Hole in IN data

mapping configuration

Inter-option

communications error

Too many IN data

objects mapped

121 Mapping over length

122

204

210

211

exceeded

Multiple non-cyclic

mapping error

Configuration

read error

Invalid destination

parameter

One or more parameters specified in the IN cyclic data mapping configuration parameters (Pr MM.010 to Pr MM.019) is outside of the allowed range for Interbus. The allowed parameter range is from Pr 0.00 to 199.99.

One or more parameters specified in the IN cyclic data mapping configuration parameters (Pr MM.010 to Pr MM.019) cannot be used as a source parameter for IN data. The parameter may not exist, or is a write-only parameter.

IN cyclic data mapping parameters (Pr MM.010 to Pr MM.019) are not contiguous. It is not possible have an un-used parameter in the middle of the cyclic data.

A request to set up an inter-option communications read block failed. Either the server does not support block transfer or parameters were not legal.

After expanding ranges of block mappings, too many IN cyclic data channels configured.

Total size of all IN cyclic data mappings has exceeded the total size of the cyclic data.

More than 10 cyclic IN data channels have been selected with direct data mapping mode.

A non-cyclic data mode has been mapped more than once in the OUT cyclic data mapping configuration parameters (Pr MM.020 to Pr MM.029).

An error has occurred reading the OUT cyclic data mapping configuration parameters (Pr MM.020 to Pr MM.029) from the drive.

One or more parameters specified in the OUT cyclic data mapping configuration parameters (Pr MM.020 to Pr MM.029) is outside of the allowed range for Interbus. The allowable parameter range is from Pr 0.00 to Pr 199.99.

One or more parameters specified in the OUT cyclic data mapping configuration parameters (Pr MM.020 to Pr MM.029) cannot be used as a destination parameter for OUT data. The

212 Write mismatch

213

214

215

220

Hole in OUT data

mapping configuration

Duplicate mapping

error

Inter-option

communications error

Too many OUT data

objects mapped

221 Mapping over length

222

exceeded

parameter may not exist, or is a read-only parameter. This error will also occur if an attempt is made to map OUT data to the configuration parameters of a fieldbus option in another slot, unless that fieldbus is configured in register mode, i.e. Pr MM.009

OUT data mapping parameters (Pr MM.020 to Pr MM.029) are not contiguous. It is not possible have an un-used parameter in

= On.

the middle of the cyclic data.

Two or more OUT cyclic data mapping configuration parameters (Pr MM.020 to Pr MM.029) have been configured with the same destination parameter reference.

A request to set up an inter-option communications write block failed. Either the server does not support block transfer or parameters were not legal.

After expanding ranges of block mappings, too many OUT cyclic data channels configured.

Total size of all OUT cyclic data mappings has exceeded the total size of the cyclic data.

More than 10 cyclic OUT data channels have been selected.

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 67 Issue Number: 1

12.6 Module error status

Default None

Pr MM.050

If SI-Interbus detects an error during operation, it will force a trip in the drive, and write the error code into this parameter.

Table 12-3 Module error codes

Code Fault Description

0 No error detected

52 User control word trip The TRIP bit has been set in the control word.

61 Configuration error

65 Network loss

70 FLASH transfer error

98 Internal watchdog error

99 Internal software error

SI-Interbus

overtemperature

Inter-option

communication error

Communication error to

Type 8-bit

Access RO

slot 1

slot 2

slot 3

Module Error Status

Indicates that the trip was not caused by the SI-Interbus. It is possible to trip the drive externally via various communication channels.

An invalid configuration has been detected. Refer to Pr MM.049 for configuration error codes.

No new messages have been received for the specified network loss trip time.

The SI-Interbus was unable to upload the configuration parameters from its FLASH memory to the drive.

If the temperature inside the SI-Interbus exceeds 82 °C, the SI-Interbus will trip the drive.

Communications time-out has occurred, but SI-Interbus is unable to determine the reason for the error.

Direct communications between SI-Interbus and an SI-Applications (or MCi2x0) in another slot has timed out. This can occur when the SI-Interbus has been mapped to directly read or write the PLC (_P, _Q, _R, _S, _T, _U, _V, _W, _X or _Y) registers in an SI-Applications (or MCi2x0) and the relevant option module has been reset.

Internal error. Cycle power to the drive to reset from this trip. If trip persists, replace the SI-Interbus.

12.7 Background cycles per second

Background Cycles Per Second

Default None

Pr MM.052

Type 8-bit

Access RO

This parameter displays the number of background cycles processed each second.

68 SI-INTERBUS User Guide

Issue Number: 1

12.8 PCB temperature

NOTE

information

Safety

Pr MM.053

This parameter displays the temperature of the module in °C.

12.9 Hardware version

Pr MM.054

This parameter displays the module hardware revision number.

12.10 Date code

Pr MM.056

This parameter contains the date code of manufacture and is loaded into the module during manufacture and cannot be changed.

The date code is a four-digit number in the form YYMM, where YY represents the year and MM represents the month of manufacture.

For example, a date code of 1910 would indicate a manufactured date of October 2019.

This format differs from the date code as printed on the module and packing carton labels which are in the form YYWW, where YY represents the year and WW represents the week number of manufacture.

PCB Temperature

Default None

Type 8-bit

Access RO

Hardware Version

Default None

Type 1 6- bi t

Access RO

Manufacture Date Code

Default None

Type 1 6- bi t

Access RO

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

SI-INTERBUS User Guide 69 Issue Number: 1

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

12.11 Status LEDs

The SI-Interbus has 6 status LEDs that allow visual diagnostics of the SI-Interbus module and network. The LEDs can be seen through the ventilation holes on top of the plastic case, as shown in Figure 12-1 Status LEDs.

Figure 12-1 Status LEDs

The LED status functions are described in Table 12-4 LED status functions.

Table 12-4 LED status functions

Name Colour Function Description

BA/D Green

RBID Red

RD Yellow Remote bus Disabled

TR Green Transmit / Receive A PCP message is active.

UL Green User LED SI-Interbus is powered up.

RC Green Remote bus Check

Bus Active or Interbus Diagnostic active

Remote Bus Isolated or Disconnected

Either the Interbus network or the remote diagnostics is active.

The Remote bus OUT interface is isolated or disconnected.

Indicates the disconnection of the outgoing remote bus. Only relevant for remote bus devices and is active in the "INTERBUS reset" state.

Monitors bus activity on layer 1 of the incoming bus. RC is active when the incoming cable is connected and the Interbus controller is not in a reset state. RC becomes inactive after an Interbus reset, layer 2 timeout or power-up reset.

70 SI-INTERBUS User Guide

Issue Number: 1

12.12 LED operating sequence

The following table shows the normal state of each of the status LEDs for particular operational states.

Table 12-5 LED operating sequence

Operating State BA/D RBID RD TR UL RC

Power-on, Initialised

(Interbus network disconnected)

Interbus network connected and

in reset state

Interbus network connected and not

in reset state (running)

Interbus network disconnected x x



xxx

information

Safety

Introduction

Supported





features

Mechanical

installation





installation

started

features

data

menus

parameters

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

SI-INTERBUS User Guide 71 Issue Number: 1

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

13 Single line setup parameter descriptions

Table 13-1 Setup menu

Pr Function Deafult Value

MM.001 Option Module ID Code 404 (500 kBd) or 414 (2 MBd)

MM.002 Firmware Version Vww.xx.yy.zz -

MM.005 Interbus Data Format (Mode) 4 (4 cyclic words)

MM.006 Interbus Operating Status -

MM.007 Network Loss Trip Timeout (ms) 200 (ms)

MM.009 Direct Data Mapping Enabled Off (disabled)

MM.010 Cyclic Input 1 Mapping 1040 (Status word Pr 10.040)

MM.011 Cyclic Input 2 Mapping 201 (Post Ramp Reference Pr 2.001)

MM.012 Cyclic Input 3 Mapping 0 (Disabled)

MM.013 Cyclic Input 4 Mapping 0 (Disabled)

MM.014 Cyclic Input 5 Mapping 0 (Disabled)

MM.015 Cyclic Input 6 Mapping 0 (Disabled)

MM.016 Cyclic Input 7 Mapping 0 (Disabled)

MM.017 Cyclic Input 8 Mapping 0 (Disabled)

MM.018 Cyclic Input 9 Mapping 0 (Disabled)

MM.019 Cyclic Input 10 Mapping 0 (Disabled)

MM.020 Cyclic Output 1 Mapping 642 (Control word Pr 6.042)

MM.021 Cyclic Output 2 Mapping 121 (Preset Reference 1 Pr 1.021)

MM.022 Cyclic Output 3 Mapping 0 (Disabled)

MM.023 Cyclic Output 4 Mapping 0 (Disabled)

MM.024 Cyclic Output 5 Mapping 0 (Disabled)

MM.025 Cyclic Output 6 Mapping 0 (Disabled)

MM.026 Cyclic Output 7 Mapping 0 (Disabled)

MM.027 Cyclic Output 8 Mapping 0 (Disabled)

MM.028 Cyclic Output 9 Mapping 0 (Disabled)

MM.029 Cyclic Output 10 Mapping 0 (Disabled)

MM.030 Load Module Defaults Off (0)

MM.031 Store Option Parameters Off (0)

MM.032 Module Reset Off (0)

MM.033 Restore Saved Option Parameters Off (0)

MM.034 Data Compression Enable Off (0)

MM.035 Serial Number LS -

MM.049 Cyclic Data Mapping Status 0 (No errors)

MM.050 Module Error Status -

MM.052 Background Cycles per Second -

MM.053 PCB Temperature -

72 SI-INTERBUS User Guide

Issue Number: 1

Pr Function Deafult Value

MM.054 Hardware Version -

MM.055 Serial Number MS -

MM.056 Manufacture Date Code (YYMM) -

information

features

installation

started

features

data

menus

parameters

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

SI-INTERBUS User Guide 73 Issue Number: 1

status word

Control /

Diagnostics

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

14 Full parameter descriptions

This section describes the SI-Interbus option module parameters in detail.

The following table describes the coding used for the parameter tables in this section.

Table 14-1 Parameter type coding

Bin Binary parameter Displays a binary value

Bit Bit parameter 1 bit parameter

BU Bit default or unipolar

Date Date parameter Parameter value is displayed in date format (DD-MM-YY)

DE Destination Parameter can be used as a destination parameter

FI Filtered Parameter value display is filtered

IP IP address

Mac MAC address

NC Non-copyable Parameter is not copied to or from the NV media card

ND No default value Parameter is not modified if default values are loaded

PS Power-down save

PT Protected Parameter cannot be used as a destination

RA Rating dependant

RO Read-only Parameter is read-only

RW Read / Write Parameter can be read and written to

SMP Slot, Menu, Parameter

Time Time formatted Parameter value is displayed in time format (HH:MM:SS)

Txt Text string Parameter value is displayed as text string

US User save parameter

Ver Version number

Bit parameters with this flag set to 1 are defaulted to 1 (On), non-bit parameters with this flag set to 1 are unipolar.

Parameter value is displayed in IP address format (www.xxx.yyy.zzz)

Parameter value is displayed as a 48-bit (6 bytes) hexadecimal number

Value is automatically saved in the EEPROM when the drive enters the under voltage state

Value is dependent on the drive power rating, These parameters are not transferred from the NV media card if the destination and source drives are different

Parameter value is displayed using the slot/menu/ parameter format (s.mm.ppp)

Parameter value is saved in EEPROM when a parameter save function is executed (Pr MM.000 = Save parameters)

Parameter value is displayed in version format (ww.xx.yy.zz)

The SI-Interbus setup menu 0 parameters are mirrored in the setup menu 15, 16 or 17 for the option module depending on which slot the SI-Interbus is installed in.

74 SI-INTERBUS User Guide

Issue Number: 1

14.1 Module ID

information

Safety

MM.001 SI-Interbus Module ID

Minimum 0 Maximum 999

Default None Units None

Type 16 Bit Volatile Update Rate Power-up write

Display format None Decimal Places 0

Coding RO, ND, NC, PT, BU

The SI-Interbus module displays the module ID code in Pr MM.001, this module ID code can be used to identify the module variant.

Pr MM.001 SI-Interbus variant

404 500 kBd

414 2 MBd

14.2 Firmware version

MM.002 SI-Interbus Firmware Version

Minimum

Default

0 (Display: 0.00.00.00)

Type 32 Bit Volatile Update Rate Power-up write

Display format Version Decimal Places 0

Coding RO, ND, NC, PT

Pr MM.002 displays the SI-Interbus firmware version in the form ww.xx.yy.zz.

14.3 Interbus data format

MM.005 SI-Interbus Data Format

Minimum 0 Maximum 309

Default 4 Units None

Type 16 Bit User Save Update Rate Background read

Display format None Decimal Places 0

Coding RW

The SI-Interbus data format is specified as ‘NNPP’, where ‘NN’ specifies the non-cyclic data mode, and ‘PP’ specifies the number of cyclic process data words as shown in the following table.

Maximum

99999999 (Display: 99.99.99.99)

Units None

descriptions

features

installation

started

features

data

menus

parameters

status word

descriptions

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

Pr MM.005 NN PP Non-cyclic Mode Cyclic Words

1 to 10 0 1 to 10 None 1 to 10

100 to 109 1 0 to 9 CT Single Word 0 to 9

200 to 209 2 0 to 6 PPO 4 Word 0 to 6

300 to 309 3 0 to 9 PCP 0 to 9

SI-INTERBUS User Guide 75 Issue Number: 1

support files

CMD tool

Glossary

of terms

The size of the data mapping will depend on the total size of the target / source

NOTE

parameters. Parameters of 16-bits or less will be cast as 16-bits if MM.34 Data Compression Enable = On, but will be cast as 32-bits if MM.34 Data Compression Enable = Off. Parameters larger than 16-bits will always be cast as 32-bits on the

network.

14.4 Interbus operating status

MM.006 SI-Interbus Operating Status

Minimum -3 Maximum 9999

Default None Units None

Type 16 Bit Volatile Update Rate Background update

Display format None Decimal Places 0

Coding RO, ND, NC, PT

If the operating status shows a negative number, this indicates that the SI-Interbus is not currently communicating with the Interbus master controller. Values above 0 indicate the number of messages per second being processed.

Pr MM.006 Description

> 0 Network healthy, displays the number of messages processed per second

0 Network health, no cyclic data transfer

-1

-2 The SI-Interbus module reports an internal hardware fault

-3

If Pr MM.006 shows a positive value, this value is dependent upon the Interbus network communication speed, number of mappings and whether non-cyclic communications are active or not.

SI-Interbus has initialised correctly and waiting for the Interbus master to initialise communication

Configuration error, invalid setting in the SI-Interbus configuration parameters

14.5 Network loss timeout

MM.007 Network Loss Timeout

Minimum 0 Maximum 3000

Default 200 Units ms

Type 16 Bit User Save Update Rate Background read

Display format None Decimal Places 0

Coding RW, BU

The SI-Interbus resets an internal timer when a valid message is received from the Interbus network. The network loss trip is triggered when no new messages are received before the timer times out. The value is in units of milliseconds.

76 SI-INTERBUS User Guide

Issue Number: 1

14.6 Direct data mapping

information

Safety

MM.009 Direct data mapping

Minimum 0 Maximum 1

Default 1 Units None

Type 1 Bit User Save Update Rate Background Read

Display format None Decimal Places 0

Coding RW

By default, parameters MM.010 to MM.029 are used as pointers to specify the destination parameter for OUT data received from the Interbus master controller, and the source parameter of IN data to be transmitted to the Interbus master controller.

When direct data mapping is enabled, Pr MM.010 to Pr MM.019 are used as the source parameters for IN data and Pr MM.020 to Pr MM.029 are used as the destination parameters for OUT data.

Hence, IN data values read from Pr MM.010 to MM.019 will be transmitted to the Interbus master controller and OUT data values arriving from the Interbus master controller will be written directly into Pr MM.020 to Pr MM.029.

14.7 Cyclic input mapping

MM.010

MM.019

Minimum -32768 Maximum 32767

Default

Type 16 Bit User Save Update Rate Power-up read

Display format None Decimal Places 0

Coding RW

Cyclic Input1 to Input10 Mapping

Input1: 1040 Input2: 201

Units None

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

14.8 Cyclic output mapping

MM.020

MM.029

Minimum -32768 Maximum 32767

Default

Type 16 Bit User Save Update Rate Power-up read

Display format None Decimal Places 0

Coding RW

SI-INTERBUS User Guide 77 Issue Number: 1

Cyclic Output1 to Output10 Mapping

Output1: 642 Output2: 121

Units None

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

The reference for the destination parameter is entered in the mapping parameter in the

NOTE

form MMPP, where MM represents the menu number of the destination parameter and PP represents the parameter number of the destination parameter. Leading zeros are not displayed.

14.9 Default option parameters

MM.030 Default Option Parameters

Minimum 0 (Display: Off) Maximum 1 (Display: On)

Default 0 (Display: Off) Units None

Type 1 Bit Volatile Update Rate Read on reset

Display format None Decimal Places 0

Coding RW, NC

This action does not save the parameters in the drive, a drive save must be performed if the parameters are to be saved after loss of power.

To save the drive parameters:

• Set Pr MM.000 to 1001

• Press the drive red reset button or set Pr 10.038 to 100

14.10 Save option parameters

MM.031 Save Option Parameters

Minimum 0 (Display: Off) Maximum 1 (Display: On)

Default 0 (Display: Off) Units None

Type 1 Bit Volatile Update Rate Background

Display format None Decimal Places 0

Coding RW, NC

The SI-Interbus module has the ability to save a copy of the setup parameters in FLASH memory, this allows the user, for example, to keep a copy of a working set of parameters in the module.

To store the SI-Interbus configuration parameters in the FLASH:

• Set Pr MM.031 to On

• Set Pr MM.000 to 1001

• Press the drive red reset button or set Pr 10.038 to 100 The Interbus communication will stop and the SI-Interbus configuration parameters will

be saved within the SI-Interbus FLASH memory. The SI-Interbus will then reset and re-initialise using the configuration parameter values.

78 SI-INTERBUS User Guide

Issue Number: 1

14.11 Module reset

NOTE

information

Safety

MM.032 Module reset

Minimum 0 (Display: Off) Maximum 1 (Display: On)

Default 0 (Display: Off) Units None

Type 1 Bit Volatile Update Rate Background

Display format None Decimal Places 0

Coding RW, NC

When this parameter is set (On), the module performs a warm reset. When the reset has been completed and the module is performing its initialisation routines, this parameter will be cleared to zero (Off). The drive, and any other modules fitted to the drive will not be affected by the reset.

14.12 Use saved option parameters

MM.033 Use Saved Option Parameters

Minimum 0 (Display: Off) Maximum 1 (Display: On)

Default 0 (Display: Off) Units None

Type 1 Bit Volatile Update Rate Background

Display format None Decimal Places 0

Coding RW, NC

If valid configuration parameters have previously been stored in the SI-Interbus flash memory (see MM.031), these values can be restored into the host drive parameters by setting Pr MM.033 to On.

When the configuration parameter values have been uploaded to the host drive SI-Interbus will reset and re-configure using the updated parameter values.

This feature allows a pre-configured SI-Interbus module to be installed into a host drive without losing the SI-Interbus configuration.

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

14.13 Data compression enable

MM.034 Data Compression Enable

Minimum 0 (Display: Off) Maximum 1 (Display: On)

Default 0 (Display: Off) Units None

Type 1 Bit User Save Update Rate Background

Display format None Decimal Places 0

Coding RW

By default, the SI-Interbus uses 32 bits for each data channel, even if the target parameter in the drive is a 16-bit parameter. This strategy (known as casting) ensures that the cyclic data transmitted over the Interbus network is kept aligned with memory locations in 32-bit PLCs. When cyclic data compression is enabled (Pr MM.34 = On),

SI-INTERBUS User Guide 79 Issue Number: 1

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

a data channel will only use 32 bits if the source/target drive parameter is a 32-bit

NOTE

parameter. If the source/target drive parameter is only 1, 8 or 16 bits wide 16 bits will be used for that particular data channel.

14.14 Serial number LS

MM.035 Serial Number LS

Minimum 0 Maximum 99999999

Default None Units None

Type 32 Bit Volatile Update Rate Power-up write

Display format Lead Zero Pad Decimal Places 0

Coding RO, ND, NC, PT

The SI-Interbus module serial number is a 10-digit decimal number loaded during manufacture and cannot be changed.

This parameter contains the last 8 digits of the serial number. (See also Pr MM.055).

14.15 Cyclic mapping status

MM.049 Cyclic Mapping Status

Minimum 0 Maximum 255

Default None Units None

Type 8 Bit Volatile Update Rate Background write

Display format None Decimal Places 0

Coding RO, ND, NC, PT, BU

If the SI-Interbus operating status parameter (Pr MM.006) indicates -3, a mapping configuration error has been detected. The reason for the error is indicated by the SI-Interbus mapping status parameter, Pr MM.049. When a mapping error has been corrected, reset the SI-Interbus by setting Pr MM.032 to On.

The full list of mapping error codes can be found in the Diagnostics section (see Table 12-2 Mapping status codes).

14.16 Module status

MM.050 Module Status

Minimum 0 Maximum 255

Default None Units None

Type 8 Bit Volatile Update Rate Background write

Display format None Decimal Places 0

Coding RO, ND, NC, PT, BU

If SI-Interbus detects an error during operation, it will force a trip in the drive, and write the SI-Interbus error code into this parameter.

80 SI-INTERBUS User Guide

Issue Number: 1

The full list of module status codes can be found in the Diagnostics section (see Table 12-3 Module error codes).

information

Safety

14.17 Background cycles

MM.052 Background Cycles

Minimum 0 Maximum 65535

Default None Units Cycles per Second

Type 16 Bit Volatile Update Rate Background update

Display format None Decimal Places 0

Coding RO, ND, NC

This parameter displays the number of background cycles processed each second.

14.18 PCB temperature

MM.053 PCB Temperature

Minimum -127 Maximum 127

Default None Units °C

Type 8 Bit Volatile Update Rate Background update

Display format None Decimal Places 0

Coding RO, ND, NC

This parameter displays the temperature of the module in °C.

14.19 Hardware version

MM.054 Hardware Version

Minimum 0.00 Maximum 655.35

Default None Units None

Type 16 Bit Volatile Update Rate Power-up write

Display format None Decimal Places 2

Coding RO, ND, NC, PT, BU

This parameter displays the module hardware revision number.

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

14.20 Serial number MS

MM.055 Serial Number MS

Minimum 0 Maximum 99

Default None Units None

Type 32 Bit Volatile Update Rate Power-up write

Display format None Decimal Places 0

Coding RO, ND, NC, PT

The SI-Interbus module serial number is a 10-digit decimal number loaded during manufacture and cannot be changed.

This parameter contains the first 2 digits of the serial number. (See also Pr MM.035).

SI-INTERBUS User Guide 81 Issue Number: 1

Single line setup

descriptions

parameter

Full parameter

descriptions

support files

CMD tool

Glossary

of terms

14.21 Manufacture date code

NOTE

MM.056 Manufacture Date Code (YYMM)

Minimum 0 Maximum 9999

Default None Units None

Type 16 Bit Volatile Update Rate Power-up write

Display format Lead Zero Pad Decimal Places 0

Coding RO, ND, NC, PT, BU

This parameter contains the date code of manufacture and is loaded into the module during manufacture and cannot be changed.

The date code is a four-digit number in the form YYMM where YY is the year and MM is the month of manufacture.

For example, a date code of 1910 would indicate a manufactured date of October 2019.

This format differs from the date code as printed on the module and packing carton labels which are in the form YYWW, where YY is the year and WW is the week number of manufacture.

82 SI-INTERBUS User Guide

Issue Number: 1

15 CMD tool support files

NOTE

information

Safety

15.1 Interbus CMD tool

The CMD tool is a Windows© (not later than Windows XP) based software package developed by Phoenix Contact and used to configure and diagnose the Generation 4 Interbus master controllers. An external database file, drive icon image files and a text file (README_CT.TXT) with instructions on how to install the drive support files to the appropriate directories, and import them into the CMD configuration tool, are available from Control Techniques for use with the CMD tool application. These files are provided in a compressed file (CT_IBS.ZIP) available from your local Control Techniques Drive Centre.

The Interbus CMD tool support files are not essential when configuring an Interbus network, each node can be entered manually, or the master controller can scan the network to determine which nodes are connected.

15.2 CMD tool configuration formats

The data formats supported by the SI-Interbus are listed in Table 15-1.

Table 15-1 SI-Interbus data formats

Format

(Pr MM.005)

1 0 1 0x03 (3) 16 bits

2 0 2 0x03 (3) 32 bits

3 0 3 0x03 (3) 48 bits

4 0 4 0x03 (3) 64 bits

5 0 5 0x03 (3) 80 bits

6 0 6 0x03 (3) 96 bits

7 0 7 0x03 (3) 112 bits

8 0 8 0x03 (3) 128 bits

9 0 9 0x03 (3) 144 bits

10 0 10 0x03 (3) 160 bits

100 1 0 0x03 (3) 16 bits

101 1 1 0x03 (3) 32 bits

102 1 2 0x03 (3) 48 bits

103 1 3 0x03 (3) 64 bits

104 1 4 0x03 (3) 80 bits

105 1 5 0x03 (3) 96 bits

106 1 6 0x03 (3) 112 bits

107 1 7 0x03 (3) 128 bits

108 1 8 0x03 (3) 144 bits

109 1 9 0x03 (3) 160 bits

200 2 0 0x03 (3) 64 bits

201 2 1 0x03 (3) 80 bits

Non-cyclic Data

Mode

Cyclic Words Interbus ID

Process Data

Channel Width

descriptions

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 83 Issue Number: 1

Format

(Pr MM.005)

202 2 2 0x03 (3) 96 bits

203 2 3 0x03 (3) 112 bits

204 2 4 0x03 (3) 128 bits

205 2 5 0x03 (3) 144 bits

206 2 6 0x03 (3) 160 bits

300 3 0 0xF3 (243) 0 bits

301 3 1 0xF3 (243) 16 bits

302 3 2 0xF3 (243) 32 bits

303 3 3 0xF3 (243) 48 bits

304 3 4 0xF3 (243) 64 bits

305 3 5 0xF3 (243) 80 bits

306 3 6 0xF3 (243) 96 bits

307 3 7 0xF3 (243) 112 bits

308 3 8 0xF3 (243) 128 bits

309 3 9 0xF3 (243) 144 bits

Non-cyclic Data

Mode

Cyclic Words Interbus ID

Channel Width

Process Data

84 SI-INTERBUS User Guide

Issue Number: 1

16 Glossary of terms

information

Safety

Address: This is the unique network identification given to a networked device to allow communication on a network. When a device sends or receives data the address is used to determine the source and the destination of the message.

Bit: A binary digit, this may have the value of 1 or 0.

Block mapping: A method of mapping a range of consecutive parameters using only

two ascending parameters. This means that by using two mapping parameters, up to 10 consecutive mappings may be made.

Byte: A collection of 8 binary digits that collectively store a value. This may be signed or unsigned.

Compression: By default SI-INTERBUS transmits values as 32-bits on the network. It is possible by using compression to reduce the number of bits transmitted when sending 16-bit (or smaller) values on the network to 16-bit (32-bit values will still be transmitted as 32-bit values). This has the advantage of reducing the volume of traffic on the network and allowing more parameters to be mapped within SI-INTERBUS.

Control word: A collection of binary digits that are used to control the drive. Features typically include directional controls, run controls and other similar functions.

Cyclic data: This consists of values that are sent at regular or cyclic intervals across the network. A typical use of cyclic data would be the transmission of a speed reference or a control word.

Data format: Determines the quantity and function of the data sent and received across the network.

Data rate: Determines the communication speed of the network, the higher the value the more data can be sent across the network in the same time period.

Device: A piece of equipment connected to a network, this may be any type of equipment including repeaters, hubs, masters or slaves.

Direct data mapping: Data is sent directly to the mapping parameters in the drive rather than the parameters redirecting the data to another parameter.

descriptions

features

installation

started

features

data

menus

parameters

status word

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

INTERBUS CMD tool: The CMD tool is the software package used to configure and diagnose the INTERBUS master controllers.

Mapping: The process of linking INTERBUS values to parameters within the drive.

Master: The controlling device on the network, generally this will include programming

features.

Mode 1 - CT single word mode: A method of sending non-cyclic data using a single word on a cyclic channel.

SI-INTERBUS User Guide 85 Issue Number: 1

descriptions

support files

of terms

Full parameter

CMD tool

Glossary

Mode 2 - PPO4 word mode: A method of sending 4 non-cyclic data words using cyclic

channels.

Network loss trip: A method to determine when a node has lost communication with the master.

Module ID code: Indicates the type of solutions module that is fitted in the corresponding slot.

Node: A device on the network. This may be either a device such as a drive or part of the network such as a repeater.

Non-cyclic data: Data that is requested or sent by the master as required. This is not sent on a regular basis and generally allows access to any parameter. This is useful for occasional changes or configuration purposes.

Response ID: The response code of the message received when using PPO4 word non-cyclic communication.

Slave: A device on the INTERBUS network such as a drive or sensor. A slave device will only respond to messages from a master.

Status word: A value that denotes the status of the drive. Each bit within the word will have a specific meaning.

Tel egram: A message used within mode 1 non-cyclic data communication. This term is sometimes used to represent a generic message on the network.

Termination: This is used at both ends of a network segment to prevent reflections and reduce noise.

Watchdog: A method used to determine if a communication system is healthy. A typical watchdog scheme uses a handshaking system to check both the master and slave are participating in communications.

86 SI-INTERBUS User Guide

Issue Number: 1

Index

Numerics

16-bit parameter access ........................................................................................35, 45

32-bit parameter

Abort CT Single Word ................................................................................................. 45

Abort CT Single Word non-cyclic message Accessing drive parameters using the PCP objects Adjusting parameters

Background Cycles ..................................................................................................... 81

Background Cycles Per Second Bus IN

.......................................................................................................................... 17

Bus OUT

Communication Reference .......................................................................................... 54

Contents Control word Control word bit definitions Control word bit functions CT Single Word CT Single Word format CT Single Word read sequence CT Single Word write sequence Cyclic Input Mapping Cyclic Mapping Status Cyclic Output Mapping

Data Compression ....................................................................................................... 79

Date code format Default Option Parameters Diagnostics Direct Data Mapping

Electrical installation .................................................................................................... 17

Event trigger

Firmware version ...................................................................................................65, 75

Full parameter descriptions

General installation ...................................................................................................... 13

Getting started

Hardware Version ..................................................................................................69, 81

.......................................................................................................... 35

................................................................. 45

.................................................... 55

.................................................................................................... 9

.................................................................................. 68

...................................................................................................................... 17

........................................................................................................................ 4

................................................................................................................ 62

.......................................................................................... 63

............................................................................................ 62

.............................................................................................. 32, 34, 59

................................................................................................ 35

.................................................................................. 36

.................................................................................. 41

................................................................................................... 77

...........................................................................................66, 80

................................................................................................ 77

......................................................................................................... 11

.......................................................................................... 78

.................................................................................................................. 65

.................................................................................................... 77

................................................................................................................ 58

......................................................................................... 74

............................................................................................................. 20

descriptions

information

features

installation

started

features

data

menus

parameters

status word

descriptions

support files

of terms

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

Full parameter

CMD tool

Glossary

SI-INTERBUS User Guide 87 Issue Number: 1

Input ............................................................................................................................ 11

Interbus cable Interbus CMD tool Interbus ID Interbus network termination Interbus Operating Status Introduction

LED operating sequence ............................................................................................. 71

Manufacture Date Code ........................................................................................69, 82

Maximum cable length Maximum network length Mechanical installation Mode 1 - CT Single Word mode Mode 2 - PPO 4 Word mode Mode 3 - Peripheral Communications Protocol V2.0 Module error codes Module error status Module ID Module ID code Module Reset Module Status

Network Loss Timeout ................................................................................................. 76

Non-cyclic data Non-cyclic modes

Output .......................................................................................................................... 11

Parameter 0 access .................................................................................................... 58

Parameter reference Parameter type coding Parameters, adjusting PCB Temperature PCP object

specification PCP READ object PCP service error codes PCP supported services PCP WRITE object Peripheral Communications Protocol V2.0 PLC registers PPO 4 Word PPO 4 Word IN data structure PPO 4 Word OUT data structure PPO 4 Word read sequence PPO 4 Word write sequence

.............................................................................................................. 19

....................................................................................................... 83

................................................................................................................... 83

....................................................................................... 19

........................................................................................... 65

.................................................................................................................. 10

................................................................................................ 19

............................................................................................ 19

................................................................................................ 13

.................................................................................. 32

....................................................................................... 46

.................................................. 54

..................................................................................................... 68

.................................................................................................................... 75

.....................................................................................................20, 65

.............................................................................................................. 79

............................................................................................................. 80

............................................................................................................ 32

........................................................................................................ 32

................................................................................................... 11

................................................................................................ 74

................................................................................................... 9

.................................................................................................69, 81

.................................................................................................................. 55

........................................................................................................ 54

....................................................................................................... 55

............................................................................................. 57

.............................................................................................. 55

...................................................................................................... 56

.................................................................. 32

............................................................................................................... 60

...................................................................................................32, 47, 59

..................................................................................... 48

................................................................................. 47

....................................................................................... 50

....................................................................................... 52

88 SI-INTERBUS User Guide

Issue Number: 1

Reading parameters using CT Single Word ................................................................35

Remote bus IN Remote bus OUT Reset all option modules Response ID codes Restore Saved Option Parameters

............................................................................................................ 18

........................................................................................................ 18

............................................................................................. 30

..................................................................................................... 49

............................................................................. 30

SAFE TORQUE OFF .................................................................................................. 62

Safe Torque Off Safety information Safety of personnel Save Option Parameters Saving drive parameters Serial Number Setup menu Setup parameter descriptions SI-Applications parameters SI-Interbus SI-Interbus connections SI-Interbus Firmware Version SI-Interbus Module ID SI-Interbus Serial Number LS SI-Interbus Serial Number MS SI-Interbus setup using non-cyclic data Status LEDs Status word Status word bit definitions Supported features

............................................................................................................. 8

......................................................................................................... 7

....................................................................................................... 8

............................................................................................. 78

............................................................................................. 31

.......................................................................................................80, 81

................................................................................................................. 72

..................................................................................... 72

......................................................................................... 60

................................................................................................................... 65

............................................................................................... 17

...................................................................................... 65

...........................................................................................30, 65

..................................................................................... 66

.................................................................................... 66

...................................................................... 57

................................................................................................................ 70

................................................................................................................. 64

........................................................................................... 64

...................................................................................................... 12

Use Saved Option Parameters .................................................................................... 79

Virtual menu 60 (setup menu) ..................................................................................... 58

Virtual menus

.............................................................................................................. 58

What is cyclic data ....................................................................................................... 20

Writing parameters using CT Single Word Writing parameters using PPO 4 Word mode

.................................................................. 40

............................................................. 52

descriptions

information

features

installation

started

features

data

menus

parameters

status word

Safety

Introduction

Supported

Mechanical

Electrical

Getting

Additional

Non-Cyclic

Virtual

SI-Applications

Control /

Diagnostics

Single line setup

parameter

SI-INTERBUS User Guide 89 Issue Number: 1

descriptions

support files

of terms

Full parameter

CMD tool

Glossary

0478-0614-01

Nidec SI-Interbus 500 kBd, SI-Interbus 2 MBd User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Safety information

1.1 Warnings, cautions and notes

1.2 Important safety information. Hazards. Competence of designers and installers

1.3 Responsibility

1.4 Compliance with regulations

1.5 Electrical hazards

1.6 Stored electrical charge

1.7 Mechanical hazards

1.8 Access to equipment

1.9 Environmental limits

1.10 Hazardous environments

1.11 Motor

1.12 Mechanical brake control

1.13 Adjusting parameters

1.14 Electromagnetic compatibility (EMC)

2 Introduction

2.1 General

2.2 Identification

2.3 Date code format

2.4 Terminology

3 Supported features

4 Mechanical installation

4.1 General installation

4.2 Installation on Unidrive M200 to M400 and Commander C200 / C300 (frames 5 to 9)

4.3 Installation on Unidrive M600 to M702

4.4 Installation on Digitax HD

5 Electrical installation

5.1 Interbus cable

5.2 SI-Interbus cable shield connections

5.3 Interbus network termination

5.4 Maximum network length

6 Getting started

6.1 Node address

6.2 Communication data rate

6.3 Parameter reference

6.4 Configuring the cyclic data

7 Additional features

7.1 Load module default parameters

7.2 Store option parameters

7.3 Module reset

7.4 Restore saved option parameters

7.5 Reset all option modules

7.6 Saving drive parameters

8 Non-Cyclic data

8.1 Mode 1 - CT Single Word mode

8.2 Mode 2 - PPO 4 Word mode

8.3 Mode 3 - Peripheral Communications Protocol V2.0

9 Virtual menus

9.1 Pr 60.01 to Pr 60.56 (Setup menu shortcut)

9.2 Pr 61.01 (Parameter 0 access)

9.3 Pr 61.40 (Event trigger - lowest slot)

9.4 Pr 61.41 (Event trigger – slot 1)

9.5 Pr 61.42 (Event trigger – slot 2)

9.6 Pr 61.43 (Event trigger – slot 3)

9.7 Pr 61.50 (CT Single Word - mode 1 non-cyclic)

9.8 Pr 61.51 (PPO 4 Word – mode 2 non-cyclic)

10 SI-Applications parameters

10.1 Single SI-Applications fitted

10.2 Dual SI-Applications fitted

11 Control / status word

11.1 Control word

11.2 Status word

12 Diagnostics

12.1 Module ID code

12.2 Firmware version

12.3 Interbus operating status

12.4 SI-Interbus serial number

12.5 Cyclic data mapping status

12.6 Module error status

12.7 Background cycles per second

12.8 PCB temperature

12.9 Hardware version

12.10 Date code

12.11 Status LEDs

12.12 LED operating sequence

13 Single line setup parameter descriptions
