Page 1
Produced in China for Next Retail Ltd
Version 1
VISKA CHAIR
674547
Assembly instructions
Actual product size
H819xW565xD512mm
IMPORTANT-RETAIN FOR FUTURE REFERENCE
Page 2
Number of people required to assemble
supplied
1
VISKA CHAIR
674547
Assembly instructions
BEFORE YOU START
Warnings
We suggest you retain these instructions for future reference.
Keep fittings out of children's reach and keep children well
away from the construction area.
This product should only be used on firm, level ground.
Please periodically check all fittings and re-tighten as
necessary.
Please do not stand on your furniture.
Avoid exposing the furniture to excessive heat or direct
sunlight as this can cause cracking of the wood and
deterioration of the colour.
Unwrap all packaging materials and place the components
on top of the carton box or on a clean floor to protect
it from damage.
One person is required assemble this item
Time to assemble
Look out for the symbol throughout this manual. Wherever
you see it we will have a handy tip to help you with the
assembly of your product.
Do's
We suggest you spend a short time reading through this leaflet
before you start.
When you are ready to start, make sure that you have the right
tools and plenty of space.
Unwrap all packaging materials and place the components on a
clean surface to protect it from damage.
We recommend that the packaging is used to protect the surfaces
during assembly.
Carefully check that you have all the parts before beginning
assembly.
Due to the size of the product we recommend that it is assembled
in the room intended for use.
Ensure the product is fully assembled as illustrated and all fixings
fully tightened before use.Check fixings regularly to ensure they
remain tight.
Wood will mellow and change colour over time, we recommend
that ornaments and items placed on the surface are moved
regularly for the first few months to prevent uneven mellowing.
To clean your item, please use a soft cloth slightly dampened
with water and wipe clean. Then buff with a dry clean cloth.
Tools required
Produced in China for Next Retail Ltd
Version 1
Next Retail Ltd,
Desford Road,
Leicester,
LE19 4AT
To View our full furniture range please visit www.next.co.uk
Missing parts
Home service technicians
Home service technicians
If you are missing any fixtures and fittings for your product
please contact our customer service team on 0333 777
8999 and they will be happy to arrange for a replacement to
be sent to you free of charge.
If you have a fault with your product please contact our
customer service team on 0333 777 8999. if you have had
the product for 28 days or less you may be offered a
replacement, refund or for a fully trained home service
technician to visit your home to assess the fault and repair
the product where possible. if you have had the product for
more than 28 days we will send an independant home
service technician to review and repair the product where
possible and recommend further action.
Don’ts
Do not drag or pull your furniture.
Do not use silicone based furniture polish. Silicone in furniture
polishes can break down the lacquer finish.
Ensure that the product is protected with mats & coasters when
items are placed on to its surface. Never put hot dishes directly
onto wooden or glass surfaces as this may mark the furniture.
Never allow any kind of liquid to remain on your furniture.
Absorption can cause finishes to de-laminate and or stain.
Page 3
2
GETTING TO KNOW YOUR PRODUCT
VISKA CHAIR
674547
Assembly instructions
Components supplied. Please use this guide if you require replacement parts.
Produced in China for Next Retail Ltd
Version 1
3
Ref
Dimensions Visual
Qty
Ctn
1
2
1
1
1
1
467x450x400mm
675x433x415mm
113
675x433x415mm
690x422x409mm
422x390x400mm
422x390x400mm
Page 4
3
Produced in China for Next Retail Ltd
Version 1
Fixtures and fittings supplied(not to scale)
supplied (actual size)
VISKA CHAIR
674547
Fixtures and fittings
Assembly instructions
70605040302010
mm
4
G
M6
E
4
4
D
C
5
Qty
Visual
Dimensions
Ref
4X64X25mm
1
F
6X15mm
Ref
Dimensions
Qty
A
B
4
6X28mm
1
Page 5
4
2
1
Produced in China for Next Retail Ltd
Version 1
VISKA CHAIR
674547
Assembly instructions
D X 4
G X 4
G
G
D
D
Page 6
6 x 28mm
5
VISKA CHAIR
674547
Assembly instructions
Produced in China for Next Retail Ltd
Version 1
4 x 64 x 25mm
A X 2 C X 2
6 x 28mm
F X 1
3
A X 2 C X 2
4 x 64 x 25mm
F X 1
4
2
3
1
3
Page 7
6 x 15mm
6
VISKA CHAIR
674547
Assembly instructions
Produced in China for Next Retail Ltd
Version 1
6
4 x 64 x 25mm
B X 1 C X 1 F X 1
5
E X 4
